ADF Web HD67B39-B2 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 1 of 27
User Manual
Revision 1 000
English
OPC UA Server / EtherNet/IP Slave -
Converter
(Order Code: HD67B39-B2)
for Website information:
http://www adfweb com/?Product=HD67B39
for Price information:
http://www adfweb com/?Price=HD67B39-B2
Benefits and Main Features:
Triple electrical isolation
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others OPC UA Server devices, see also the following links:
OPC UA Server from/to
www adfweb com?Product=HD67B26 (Serial)
www adfweb com?Product=HD67B27 (Modbus Master)
www adfweb com?Product=HD67B28 (Modbus Slave)
www adfweb com?Product=HD67B29 (Modbus TCP Master)
www adfweb com?Product=HD67B30 (Modbus TCP Slave)
www adfweb com?Product=HD67B31 (Bacnet Master)
www adfweb com?Product=HD67B32 (Bacnet Slave)
www adfweb com?Product=HD67B33 (CAN)
www adfweb com?Product=HD67B34 (CANopen)
www adfweb com?Product=HD67B35 (DeviceNet Master)
www adfweb com?Product=HD67B36 (DeviceNet Slave)
www adfweb com?Product=HD67B37 (DMX)
www adfweb com?Product=HD67B38 (EtherNet/IP Master)
www adfweb com?Product=HD67B40 (J1939)
www adfweb com?Product=HD67B41 (KNX)
www adfweb com?Product=HD67B42 (MQTT)
www adfweb com?Product=HD67B43 (NMEA0183)
www adfweb com?Product=HD67B44 (NMEA2000)
www adfweb com?Product=HD67B45 (PROFINET Master)
www adfweb com?Product=HD67B46 (PROFINET Slave)
www adfweb com?Product=HD67B47 (SNMP Manager)
www adfweb com?Product=HD67B48 (SNMP Agent)
Do you have an your customer protocol?
See the following links:
www adfweb com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 2 of 27
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67B39 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
OPC UA ACCESS 17
UPDATE DEVICE 18
PLC CONFIGURATION 20
MECHANICAL DIMENSIONS 24
ORDERING INFORMATIONS 25
ACCESSORIES 25
DISCLAIMER 26
OTHER REGULATIONS AND STANDARDS 26
WARRANTIES AND TECHNICAL SUPPORT 27
RETURN POLICY 27
Pagina 2 di 27
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
Revision Date Author Chapter Description
1 000 13/03/2019 Ff All First release version
WARNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 3 of 27
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESIDUAL R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 4 of 27
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 5 of 27
CONNECTION SCHEME:
Figure
1
: Connection scheme for HD67
B
3
9
-
B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 6 of 27
CHARACTERISTICS:
The HD67B39-B2 is a OPC UA Server / EtherNet/IP Slave converter
It allows the following characteristics:
Up to 496 bytes in reading and 496 bytes in writing;
Two-directional information between EtherNet/IP and OPC UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGURATION:
You need Compositor SW67B39 software on your PC in order to perform the following:
Define the parameter of the OPC UA;
Define the parameter of the EtherNet/IP;
Define the list of OPC UA variables;
Update the device

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 7 of 27
POWER SUPPLY:
The devices can be powered between a wide range of tensions For more details see the two tables below
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B39-B2 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67B39-B2 4
Caution: Not reverse the polarity power
HD67B39-B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 8 of 27
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device
The second, with Dip1 in On position, is used for upload the Project/Firmware
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section)
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section)

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 9 of 27
LEDS:
The device has got six LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: OPC UA comm (yellow) Flashing: OPC UA response
OFF: No OPC UA response
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: EtherNet/IP comm
(yellow)
Flashing: EtherNet/IP communication
OFF: No EtherNet/IP communication
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: An error has occurred
OFF: The device is correctly running
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 10 of 27
ETHERNET:
The Ethernet connection must be made using Connector3 of HD67B39-B2 with at least a Category 5E cable The maximum length of the
cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a
cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 11 of 27
USE OF COMPOSITOR SW67B39:
To configure the Converter, use the available software that runs with Windows called SW67B39 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67B39, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67B
39

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 12 of 27
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “OPC UA Server / EtherNet/IP Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 13 of 27
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67B39 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 14 of 27
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 15 of 27
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, OPC UA and
EtherNet/IP
By Pressing the “Set Communication” button from the main window for SW67B39 (Fig 2)
the window “Set Communication” appears (Fig 3)
The means of the fields for “OPC UA Server” are:
In the field “IP Address” the IP address for OPC UA side of the converter is defined;
In the field “SubNet Mask” the SubNet Mask for OPC UA side of the converter is
defined;
In the field “Gateway” the default gateway of the net is defined This feature can be
enabled or disabled pressing the Check Box field This feature is used for going out
of the net;
In the field “DNS” the IP Address of the DNS server is defined This feature can be
enabled or disabled pressing the Check Box field;
In the field “Port” the port of OPC UA Server is defined
The means of the fields for “EtherNet/IP” are:
In the field “IP Address” the IP address for EtherNet/IP side of the converter is
defined;
In the field “SubNet Mask” the SubNet Mask for EtherNet/IP side of the converter
is defined;
In the field “Gateway” the default gateway of the net is defined This feature can be
enabled or disabled pressing the Check Box field This feature is used for going out
of the net;
In the field “Port” the port used for EtherNet/IP communication is defined;
In the fields “Number Byte IN” the number of input byte of the slave station is
defined;
In the fields “Number Byte Out” the number of output byte of the slave station is
defined
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 16 of 27
The means of the fields for “NTP (Network Time Protocol)” are:
In the field “Server URL” the URL or the IP Address of the NTP Server is defined;
In the field “Poll Time (seconds)” the polling time for the time synchronization is defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 17 of 27
Figure 4: “O C UA Server Access” window
OPC UA ACCESS:
By Pressing the “OPC UA Access” button from the main window for SW67B39 (Fig 2) the window “OPC UA Server Access” appears (Fig 4)
This section is used to define the list of OPC UA variables to read/write
The means of the checkboxes inside the table are:
If the field “Enable” is checked, the OPC UA variable is enabled;
In the field “Type” the data format of the OPC UA variable is defined;
In the field “Position” the starting byte of the internal memory arrays where getting the value is defined;
In the field “Length” the byte length of the OPC UA variable is defined;
In the field “Name” the name of the OPC UA variable is defined;
In the field “R/W” the access type of the OPC UA variable is defined;
In the field “Mnemonic” a description of the OPC UA variable is defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 18 of 27
UPDATE DEVICE:
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary This by using the
Ethernet port
If you don’t know the actual IP address of the device you have to use this procedure:
Turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device
If you know the actual IP address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode
At this point the configuration/firmware on the device is correctly updated
Figure 5: “Update device” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 19 of 27
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67B39 device
Warning:
If Fig 6 appears when you try to do the Update try these points before seeking
assistance:
Try to repeat the operations for the updating;
Try with another PC;
Try to restart the PC;
Check the LAN settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privileges;
In case you have to program more than one device, using the "UDP Update", you
have to cancel the ARP table every time you connect a new device on Ethernet For
do this you have to launch the "Command Prompt" and write the command "arp -
d" Pay attention that with Windows Vista, Seven, 8, 10 you have to launch the
"Command Prompt" with Administrator Rights;
Pay attention at Firewall lock
Warning:
In the case of HD67B39 you have to use the software “SW67B39”: www adfweb com\download\filefold\SW67B39 zip
Figure 6: “Error” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC
UA
Server
/
EtherNet/IP
Slave
Document code: MN67B39_ENG Revision 1 000 Page 20 of 27
PLC CONFIGURATION:
The configuration and commissioning of the EtherNet/IP Converter as described on the following pages was accomplished with the help of
the “RSLogix 5000” software of Rockwell Automation In case of using a control system from another supplier please attend to the
associated documentation
These are the steps to follow:
1) Create a "Generic Ethernet Module" under the Ethernet section in the I/O Configuration tree
