ADF Web HD67B80-B2 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 1 of 32
User Manual
Revision 1 000
English
PROFINET Master / MQTT - Converter
(Order Code: HD67B80-B2)
for Website information:
www adfweb com/?Product=HD67B80
for Price information:
www adfweb com/?Price=HD67B80-B2
Benefits and Main Features:
Triple electrical isolation
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others PROFINET Master devices, see also the following links:
PROFINET Master from/to …
www adfweb com?Product=HD67B45 (OPC U Server)
www adfweb com?Product=HD67B70 (Serial)
www adfweb com?Product=HD67B71 (Modbus Slave)
www adfweb com?Product=HD67B72 (PROFIBUS Slave)
www adfweb com?Product=HD67B73 (C N)
www adfweb com?Product=HD67B74 (C Nopen)
www adfweb com?Product=HD67B75 (DeviceNet Slave)
www adfweb com?Product=HD67B76 (Modbus TCP Slave)
www adfweb com?Product=HD67B77 (SNMP gent)
www adfweb com?Product=HD67B78 (EtherNet/IP Slave)
www adfweb com?Product=HD67B79 (KNX)
www adfweb com?Product=HD67B81 (B Cnet Slave)
www adfweb com?Product=HD67B82 (IEC 61850 Server)
www adfweb com?Product=HD67B84 (Ethernet)
Do you have an your customer protocol?
See the following links:
www adfweb com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 2 of 32
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67B80 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
PROFINET ACCESS 21
MQTT SET TOPIC 24
UPDATE DEVICE 26
TEMPLATE STRING: DEFINITION OF MQTT PAYLOAD 28
MECHANICAL DIMENSIONS 29
ORDERING INFORMATIONS 30
ACCESSORIES 30
DISCLAIMER 31
OTHER REGULATIONS AND STANDARDS 31
WARRANTIES AND TECHNICAL SUPPORT 32
RETURN POLICY 32
Pagina 2 di 32
UPD TED DOCUMENT TION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
Revision Date uthor Chapter Description
1 000 13/03/2019 Ff All First release version
W RNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TR DEM RKS:
All trademarks mentioned in this document belong to their respective
owners

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 3 of 32
SECURITY LERT:
G ENER L I NFORM TION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q U LIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESIDU L R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 4 of 32
EX MPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 5 of 32
Figure
1
: Connection scheme for HD67
B
80
-
B2
CONNECTION SCHEME:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 6 of 32
CH R CTERISTICS:
The HD67B80-B2 is a PROFINET Master / MQTT converter
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between PROFINET and MQTT;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGUR TION:
You need Compositor SW67B80 software on your PC in order to perform the following:
Define the parameter of the MQTT;
Define the parameter of the PROFINET;
Define the list of PROFINET slaves connected to the converter;
Define the MQTT topics to publish and subscribe;
Update the device

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 7 of 32
POWER SUPPLY:
The devices can be powered between a wide range of tensions For more details see the two tables below
V C
VDC
Vmin Vmax Vmin Vmax
HD67B80-B2 8V 24V 12V 35V
Consumption at 24V DC:
Device W/V
HD67B80-B2 4
Caution: Not reverse the polarity power
HD67B80-B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 8 of 32
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device
The second, with Dip1 in On position, is used for upload the Project/Firmware
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section)
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section)

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 9 of 32
LEDS:
The device has got six LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: MQTT comm (yellow) Flashing: MQTT message received
OFF: No MQTT messages
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: PROFINET comm (yellow) Flashing: PROFINET communication
OFF: No PROFINET communication
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: PROFINET or MQTT error
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 10 of 32
ETHERNET:
The Ethernet connection must be made using Connector3 of HD67B80-B2 with at least a Category 5E cable The maximum length of the
cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a
cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 11 of 32
USE OF COMPOSITOR SW67B80:
To configure the Converter, use the available software that runs with Windows called SW67B80 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67B80, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67B80

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 12 of 32
NEW CONFIGUR TION / OPEN CONFIGUR TION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “PROFINET Master / MQTT -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 13 of 32
SOFTW RE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67B80 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 14 of 32
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 15 of 32
SET COMMUNIC TION:
By Pressing the “Set Communication” button from the main window for SW67B80 (Fig
2) the window “Set Communication” appears (Fig 3)
The window is divided in different sections in order to define the different parameters of
the converter:
PROFINET Master
MQTT
Ethernet
Wi-Fi
TLS (Transport Layer Security)
NTP (Network Time Protocol)
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 16 of 32
Figure 3b: “Set Communication  ROFINET
Master” window
Figure 3c: “Set Communication  MQTT” window
PROFINET M STER :
This section is used to define the main parameters of PROFINET line The means of
the fields are:
In the fields “IP ddress” the IP address for PROFINET side of the converter
is defined;
In the fields “SubNet Mask” the SubNet Mask for PROFINET side of the
converter is defined;
In the fields “Gateway” the default gateway of the net is defined This
feature can be enabled or disabled pressing the Check Box field This feature
is used for going out of the net;
In the field "Name of Station" the name of the PROFINET node is defined
MQTT:
This section is used to define the main parameters of MQTT line The means of the
fields are:
In the field “Server URL” the URL or the IP Address of the MQTT Server is
defined;
In the field “Server Port” the port used for MQTT communication is defined;
In the field “Client ID” the Client ID of the converter is defined (if ned);
In the field “Keep live (seconds)” the delay with which the Keep Alive
message is sent on MQTT is defined;
If the field “Clean Session” is checked, the last MQTT messages are deleted
by the Server and the Client in case of missing ACK If unchecked, the Server
and the Client hold the last MQTT messages and, in case of incorrect
disconnection or missing ACK, they try to send again them since all the ACK
messages are exchanged correctly (valid only for QoS 1 and QoS 2);
If the field “Will Flag” is checked, the converter will publish the Will topic at
the connection to the Server With this feature, in case of incorrect
disconnection, the Server will publish this topic to all the MQTT Clients that
subscribed it;
In the field “Topic Name Will” the topic used for Will message is defined;

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 17 of 32
Figure 3d: “Set Communication  Ethernet”
window
In the field “Message Will” the payload of the Will message is defined;
In the field “Retained Will” the converter will send the Will message with Retain flag enabled In this way, the Server will hold the
last Will message;
In the field “QoS Will” the QoS type for Will message is defined;
In the field “Username” the username for the connection to the MQTT server is defined;
In the field “Password” the password for the connection to the MQTT server is defined
E THERNET :
This section is used to define the general parameters of Ethernet The means of the
fields are:
In the field “Ip ddress” the IP address of the converter is defined;
In the field “SubNet Mask” the Subnet Mask of the converter is defined;
In the field “Gateway” the default gateway of the net is defined This
feature can be enabled or disabled pressing the Check Box field This feature
is used for going out of the net;
In the field “DNS” the DNS address is defined This field is required if the
server address is define by URL and not IP Address

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 18 of 32
Figure 3
e
: “Set Communication

Wi
-
Fi” window
W I -F I :
This section is used to define the general parameters of Wi-Fi It is possible to defined the type of Wi-Fi communication:
Access Point;
Client
The means of the fields for Access Point configuration are:
In the field “IP ddress” the IP address of the converter is defined;
In the field “Subnet Mask” the SubNet Mask of the converter is defined;
In the field “G TEW Y” the default gateway of the net is defined This
feature can be enabled or disabled pressing the Check Box field This feature
is used for going out of the net;
In the field “DNS” the DNS address is defined This field is required if the
server address is define by URL and not IP Address
In the field “Port” the port used for MQTT communication is defined;
In the field “SSID” the name of the Wi-Fi network to create is defined;
In the field “Password” the password used for Wi-Fi connection is defined;
In the field “Type” the type of security protocol used by the Wi-Fi network is
defined;
If the field “Enable DHCP” is checked, the converter acts as DHCP Server
for the Clients connected If the option is enabled, in the fields “DHCP First
IP ddress” and “DHCP SUBNET Mask” the IP Addresses range used for
DHCP is defined In the field “Lease Time (seconds)” the required time for
the renewing of the IP Address assigned to the Client is defined;
In the field “Max Client” the maximum number of Wi-Fi Clients accepted is
defined;
In the field “Channel” the channel for Wi-Fi communication is defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 19 of 32
Figure 3g: “Set Communication  TLS” window
Figure 3
f
:
“Set Communication

Wi
-
Fi” window
The means of the fields for Client configuration are:
If the field “Obtain an IP ddress automatically” is checked, the
converter gets the IP Address using DHCP Otherwise, the IP Address is
defined as static;
In the field “IP ddress” the IP address of the converter is defined;
In the field “Subnet Mask” the SubNet Mask of the converter is defined;
In the field “G TEW Y” the default gateway of the net is defined This
feature can be enabled or disabled pressing the Check Box field This feature
is used for going out of the net;
In the field “DNS” the DNS address is defined This field is required if the
server address is define by URL and not IP Address
In the field “Port” the port used for MQTT communication is defined;
In the field “SSID” the name of the Wi-Fi network to connect is defined;
In the field “Password” the password used to connect to the Wi-Fi network
is defined
TLS (T R NSPORT L YER S ECURITY ):
This section is used to define the parameters of TLS protocol The means of the
fields are:
If the field “Enable TLS” is checked, the TLS protocol for secure connection
is enabled;
If the field “Server uthentication” is checked, the authentication of the
Server using TLS is enabled If enabled, in the field “Server Certificate” the
certificate from the Server is defined;
If the field “Client uthentication” is checked, the authentication of the
Client using TLS is enabled If enabled:
oin the field “Client Certificate” the certificate from the Client is
defined;
oin the field “Client Key” the private key of the Client is defined;
oin the field “Client Key Password” the password for the private key
of the Client is defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
Us
er Manual
PROFINET
M
aster /
MQTT
Document code: MN67B80_ENG Revision 1 000 Page 20 of 32
Figure 3h: “Set Communication

NT ” window
NTP (N ETWORK T IME P ROTOCOL ):
This section is used to define the parameters of NTP protocol The means of the
fields are:
In the field “Server URL” the URL or the IP Address of the NTP Server is
defined;
In the field “Poll Time (seconds)” the polling time for the time
synchronization is defined
