ADLINK Technology MXC-6000 User manual

Advance Technologies; Automate the World.
Manual Rev.: 3.10
Revision Date: Jan. 3, 2013
Part No: 50-1Z083-1010
MXC-6000
Fanless, Expandable Intel®Core™ i7-620LE
Processor 2.0 GHz Embedded Computer
User’s Manual

ii
Revision History
Revision Release Date Description of Change(s)
3.00 Oct 5, 2012 Revised Specification
3.10 Jan. 3, 2013 Paging Anomalies Rectified

Table of Contents iii
MXC-6000
Table of Contents
Revision History...................................................................... ii
List of Tables......................................................................... vii
List of Figures........................................................................ ix
Preface.................................................................................... xi
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Specifications....................................................................... 3
1.4 Mechanical Drawings........................................................... 6
1.5 Front Panel I/O Connectors. ................................................ 9
1.5.1 Power Button ............................................................ 10
1.5.2 LED Indicators .......................................................... 10
1.5.3 Reset Button............................................................. 10
1.6 Digital I/O Connector ......................................................... 10
1.6.1 Isolated Digital Input Circuits .................................... 13
1.6.2 Isolated Digital Output Circuits ................................. 15
1.6.3 Digital I/O Windows Driver and API.......................... 16
1.6.4 Digital I/O Programming I/O Address ....................... 17
1.6.5 USB 2.0 Ports........................................................... 19
1.6.6 Dual Gigabit Ethernet Ports...................................... 19
1.6.7 CompactFlash Socket .............................................. 20
1.6.8 COM Port connectors ............................................... 21
1.6.9 DVI-I connector......................................................... 21
1.6.10 Audio Jacks .............................................................. 23
1.6.11 Keyboard & Mouse PS/2 connectors........................ 23
1.6.12 eSATA connector ..................................................... 24
1.6.13 DC Power connector ................................................ 24

iv Table of Contents
1.6.14 PCI slot ..................................................................... 25
1.6.15 PCI express x4 slot................................................... 25
1.7 Internal I/O connectors....................................................... 26
1.7.1 Clear CMOS Jumper ................................................ 28
1.7.2 Internal Reserved +5V and +12V Connector............ 28
1.7.3 Internal CF Card Connector...................................... 29
1.7.4 LVDS Interface Connector........................................ 30
1.7.5 12V DC Fan Connector ............................................ 31
1.7.6 LVDS Panel Backlight Control Connector ................ 31
1.7.7 Internal USB Connector............................................ 32
1.7.8 SATA Connectors..................................................... 32
1.7.9 Backboard to System PCB Connector...................... 32
2 Getting Started.................................................................. 33
2.1 Unpacking Checklist .......................................................... 33
2.2 Installing Hard Disk Drives................................................. 34
2.3 Installing a PCI/PCIe Card ................................................. 38
2.4 Installing CF Cards ............................................................ 40
2.5 Connecting and Using eSATA Storage Device.................. 44
2.6 Connecting DC Power ....................................................... 45
2.7 Wall-mounting the MXC-6000............................................ 46
2.8 Optional Fan Module.......................................................... 49
2.9 Cooling Configuration ........................................................ 50
3 Driver Installation.............................................................. 51
3.1 Installing the chipset driver ................................................ 51
3.2 Installing the graphics driver .............................................. 52
3.3 Installing the Ethernet driver .............................................. 52
3.4 Installing the audio driver ................................................... 53
3.5 Installing the WDT driver.................................................... 53
3.6 Installing the DIO Driver..................................................... 54
A Appendix: Power Consumption .......................................55

Table of Contents v
MXC-6000
A.1 Power Consumption Reference......................................... 55
A.2 Power Supply Reference ................................................... 56
A.3 Accessory Cabling ............................................................. 56
B Appendix: BIOS Setup......................................................57
B.1 Main ................................................................................... 57
BIOS Information .......................................................... 57
Memory Information ...................................................... 57
System Language ......................................................... 57
System Date ................................................................. 58
System Time ................................................................. 58
B.1.1 System Time/System Date ....................................... 58
B.2 Advanced........................................................................... 58
Intel PXE ROM Option .................................................. 58
Intel IGD SWSCI OpRegion .......................................... 58
B.2.1 ACPI Settings ........................................................... 59
B.2.2 Intel IGD SWSCI OpRegion ..................................... 59
B.2.3 CPU Configuration.................................................... 60
B.2.4 SATA Configuration.................................................. 61
B.2.5 Serial Port Configuration .......................................... 61
B.2.6 USB Configuration.................................................... 61
B.2.7 Watchdog Timer ....................................................... 61
B.2.8 H/W Monitor.............................................................. 62
B.3 Chipset............................................................................... 62
B.3.1 Northbridge configuration ......................................... 62
B.3.2 Southbridge configuration......................................... 62
B.4 Security.............................................................................. 63
B.5 Boot ................................................................................... 63
B.5.1 Boot Settings Configuration...................................... 63
B.5.2 Boot Option Priorities................................................ 64
B.6 Exit..................................................................................... 64

vi Table of Contents
C Appendix: Activating RAID Function...............................65
C.1 RAID Activation in System Manangement ......................... 66
C.1.1 Intel Matrix Storage Manager ................................... 68
C.2 OS Activation ..................................................................... 71
C.2.1 Windows XP ............................................................. 71
C.2.2 Windows 7 ................................................................ 74
D Appendix: Watchdog Timer (WDT)
Function Library.....................................................................77
D.1 WDT with API/Windows ..................................................... 77
InitWDT ......................................................................... 77
SetWDT ........................................................................ 78
D.2 WDT with DOS/Linux ......................................................... 80
Important Safety Instructions............................................... 85
Getting Service...................................................................... 87

List of Tables vii
MXC-6000
List of Tables
Table 1-1: Front Panel I/O Connector Legend........................... 10
Table 1-2: LED Indicators .......................................................... 10
Table 1-3: Digital I/O Connector Pin Signals ............................. 12
Table 1-4: Digital I/O Connector Pin Legend ............................. 13
Table 1-5: DI Channel System Interrupt .................................... 18
Table 1-6: Active/Link LED ........................................................ 20
Table 1-7: Speed LED ............................................................... 20
Table 1-8: D-sub 9P signal function of COM ports .................... 21
Table 1-9: DVI-I Connector Signals ........................................... 22
Table 1-10: Audio Jack Signals ................................................... 23
Table 1-11: PS/2 Connector Signals ........................................... 23
Table 1-12: DC Power Supply Connector Signals....................... 25
Table 1-13: Mainboard Connector Legend .................................. 26
Table 1-14: Backplane Board Connector Legend........................ 27
Table 1-15: Clear CMOS Jumper Settings .................................. 28
Table 1-16: +5V and +12V Connector Pin Functions .................. 28
Table 1-17: LVDS Connector Pin Functions................................ 30
Table 1-18: Backlight Connector Pin Functions........................... 31
Table A-1: Power Consumption ................................................. 55
Table A-2: Power Supply ........................................................... 56
Table B-1: Restore On Power Loss ........................................... 63

viii List of Tables
This page intentionally left blank.

List of Figures ix
MXC-6000
List of Figures
Figure 1-1: MXC-6000 Functional Block Diagram ........................ 5
Figure 1-2: MXC-6000 Left Side View .......................................... 6
Figure 1-3: MXC-6000 Right Side View ........................................ 6
Figure 1-4: MXC-6000 Top View .................................................. 7
Figure 1-5: MXC-6000 Front View ................................................ 7
Figure 1-6: MXC-6000 Rear View................................................. 8
Figure 1-7: MXC-6000 Underside View ........................................ 8
Figure 1-8: Front Panel I/O Connector.......................................... 9
Figure 1-9: Isolated Digital Input Circuit...................................... 13
Figure 1-10: Isolated Digital Input Differential Input Circuit........... 14
Figure 1-11: Isolated Digital Input Sample Application Circuit ...... 15
Figure 1-12: Isolated Digital Output Circuits ................................. 16
Figure 1-13: Isolated Digital Output Sample Application Circuit ... 16
Figure 1-14: Mainboard PCB ........................................................ 26
Figure 1-15: Backplane Board PCB.............................................. 27

xListofFigures
This page intentionally left blank.

xi
MXC-6000
Preface
Copyright 2013 ADLINK Technology, Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

xii
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

Introduction 1
MXC-6000
1 Introduction
1.1 Overview
The Matrix MXC-6000 series provides powerful, fanless, expand-
able embedded computing using the new Intel®Core™ i7-620LE
Processor 2.0 GHz with improved computing performance. The
MXC-6000 continues the exceptional fanless and cable-free
design from the existing Matrix C series.
The MXC-6000 series features an Intel®Core™ i7-620LE Proces-
sor 2.0 GHz and Intel®QM57 chipset to boost performance, mak-
ing it ideal for image and vision measurement and automation
applications. Its PCI and PCIe slots allow integration of
off-the-shelf PCI/PCIe cards to develop a configurable application
platform. The built-in 16 isolated DIO channels are provided for
general industrial control. A DVI-I connector output on the front
panel allows direct connection to an LCD panel, and the
MXC-6000 series also provides one eSATA port to enable expan-
sion of current storage capacity or use of hot-swappable SATA
drives.
Leveraging a reliable fanless and durable cable-free design, the
MXC-6000 series exhibits excellent dependability in -harsh envi-
ronments, where severe temperature variation and vibration may
occur. The MXC-6000 series provides an optional hot-pluggable
fan module to dissipate heat generated within the system when
high power consumption PCI/PCIe cards are installed. This inno-
vative mechanical design retains a cable-free structure which dra-
matically improves thermal stability when PCI/PCIe cards are
installed.
The MXC-6000 also provides a USB 2.0 port internally on riser
card. This function provides more reliable usage in security appli-
cations where license keys or password encryption through an
internal USB dongle dramatically improve the security of the
Matrix I/O controller. Combining a reliable design with more com-
puting power and innovative features, the Matrix MXC-6000 series
is the optimal choice on which to base any rugged application sys-
tem.

2Introduction
1.2 Features
XIntel®Core i7-620LE 2.0 GHz processor + Intel® QM57
chipset
XExpandable PCI and PCIe x4 slots
XRugged, -10°C to 60°C fanless operation*
XBuilt-in 9 V DC to 32 V DC wide-range DC power input
XVGA+DVI display by DVI-I connector
XDual 1000/100/10 Mbps Ethernet ports
X4 USB 2.0 ports (external),1 USB 2.0 port (internal)
XFour serial ports:, two RS-232 and two RS-232/422/485
(software-selectable)
XBuilt-in 16-CH isolated DI and 16-CH isolated DO
NOTE:
NOTE:
This option guarantees cold boot of the system at -10°c
and operation with 100% loading at 60° without add-on
cards. The industrial solid-state drive storage option is
required.

Introduction 3
MXC-6000
1.3 Specifications
MXC-6101D MXC-6201D
System Core
Processor Intel® Core i7-620LE 2.0 GHz CPU
Chipset Intel® QM57
Video
One DVI connector provides DVI display, with support for
analog VGA with ADLINK Y-cable*
48bit LVDS support by internal header
*The Y-cable converts the DVI connector to one D-DUB
connector for Analog VGA and one DVI-D connector for
digital LCD panel , such that both connectors can function
with requisite driver support
Analog CRT, supports QXGA (2048 x 1536) resolution
DVI-I 1.0 (DVI + VGA) (with external cable for connecting
DVI-I connector to DVI and VGA device)
Optional 48-bit LVDS (by internal box header)
Memory 2 GB DDR3 800/1066 MHz SODIMM module (Max.
capacity 4GB w/ optional SODIMM module support)
I/O Interface
Ethernet 2x GbE port (2x Intel® 82574L)
Serial Port
2x software-programmable RS-232/422/485 (COM1 &
COM2)
2x RS-232 (COM3 & COM4)
USB 4x USB 2.0 ports (external), 1xUSB 2.0 port (internally on
riser card)
Audio 1x mic-in and 1x line-out
KB/MS 1x PS/2 keyboard and 1x PS/2 mouse
Expansion 2* PCI slots 1* PCIex4 slot + 1* PCI slot
DI/O 16DI + 16DO with isolation
Power Supply
DC Input AT/ATX, Built-in 9-32 V DC wide-range DC input , 3P
pluggable connector with latch (V-, GND, V+)

4Introduction
AC Input Optional 100 W external AC-DC adapter for AC input
Storage
SATA HDD 2 x Onboard SATA port for 2.5" HDD/SSD installation
CF 1x external type I CompactFlash socket, 1x internal type I
CompactFlash socket
eSATA 1x eSATA port
Mechanical
Fan Optional hot-pluggable fan module cooling PCI/PCIe card
Dimensions 130(W) x 225 (D) x 183(H) mm (5.12x8.86x7.2 in)
Weight 3.5 kg (7.71 lb)
Mounting Wall-mount kit
Environmental
Operating
Temperature
Standard: 0°C to 50°C (32 to 122°F) (w/ HDD)
Extended: -10°C to 60°C (-14 to 140°F) (w/o HDD or w/
Industrial SSD/CF)
Storage
Temperature -40°C to 85°C (-40 to 185°F)
Humidity approx. 95% @ 40°C (non-condensing)
Vibration
Operating, 5 Grms, 5-500 Hz, 3 axes (w/ CF or SSD)
Operating, 0.5 Grms, 5-500 Hz, 3 axes (w/ HDD)
EMC CE, FCC
Shock Operating, 50 G, half sine 11ms duration (w/ CF or SSD)
Power Consumption
Power Off 0.72 W
In shutdown status with DC
input and only PS2
keyboard/mouse connected
System Idle 41.28 W
Under Windows XP desktop
with no application
programs executed

Introduction 5
MXC-6000
Figure 1-1: MXC-6000 Functional Block Diagram
System Full Load 78.72 W
Under Windows XP with
100% CPU utilization and
simultaneous access to all
I/O devices
Recommended
Power Supply 100 W
Additional power supply is
necessary if add-on cards
are installed and in use
Intel
࿗
Core
i7-620LE 2.0GHz
Processor
Channel A
204 pin SODIMM
Intel࿗QM57
Express Chipset
DDR3
800/1066MHz
FDI DMI
GbE controller
Intel 82574L
RJ45 &
USB x 2
Connector
IO Board
RJ45 &
USB x 2
Connector
Line out &
Mic in
Connector
PS2
Connector
Dsub -9
x4
GbE I/F
USB 2.0
Audio
PS2
COM x4
PCIe x1
PCIe x1
GbE controller
Intel 82574L
GbE I/F
USB 2.0
Super I/O
Fintek
F81216
LPC
DVI
CRT
DVI-I
Connector DVI
level shifter
USB
AU6320
Riser Card
PCI slot
PCIe x4
slot
SATA
Connector
SATA
Connector
Internal
USB
USB 2.0
SATA II
SATA II
PCIe x4
PCI
PCI PCI9052 16ch
D I/O
eSATA
Connector
SATA II
SATA
JM20330
Internal
CF Card slot
External
CF Card slot
CF
CF

6Introduction
1.4 Mechanical Drawings
This section describes the appearance and connectors of the
MXC-6000 controllers, including chassis dimensions, front panel
connectors, rear panel connectors, and internal IO connectors.
Figure 1-2: MXC-6000 Left Side View
Figure 1-3: MXC-6000 Right Side View
NOTE:
NOTE:
All dimensions shown are in mm (millimeters).
209.1
225.1
8.0

Introduction 7
MXC-6000
Figure 1-4: MXC-6000 Top View
Figure 1-5: MXC-6000 Front View
130.1
182.8

8Introduction
Figure 1-6: MXC-6000 Rear View
Figure 1-7: MXC-6000 Underside View
4.0
11.0
91.0 16.5
15.9 189.1
60.0
