ADLINK Technology NuPRO-710 Series User manual

NuPRO-710 Series
Full Size Socket-370 All-in-one
PICMG™ Bus Industrial SBC
User’s Guide
Recycled Paper

©Copyright 2000 ADLINK Technology Inc.
All Rights Reserved.
Manual Rev. 1.00: October 24, 2000
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental,orconsequentialdamagesarisingoutoftheuseorinabilitytouse
the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
NuPROis registered trademark of ADLINK Technology Inc.
Other product names mentioned herein are used for identification purposes
only and may be trademarks and/or registered trademarks of their respective
companies.

Getting service from ADLINK
♦Customer Satisfaction is always the most important thing for ADLINK
Tech Inc. If you need any help or service, please contact us and get it.
ADLINK Technology Inc.
htt
p://www.
a
dlink.com.tw
Web Site
http://www.adlinktechnology.com.tw
Sales & Service
[email protected]
Technical NuDAQ [email protected]
Support NuDAM [email protected]
NuIPC [email protected]w
NuPRO [email protected]
Software [email protected]
AMB [email protected]
TEL [phone] FAX [phone]
Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan, R.O.C.
♦Please inform or FAX us of your detailed information for a prompt,
satisfactory and constant service.
Detailed Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX
Web Site
Questions
Product Model
¨OS:
¨Computer Brand:
Environment to Use
¨M/B:¨CPU:
¨Chipset: ¨Bios:
¨Video Card:
¨Network Interface Card:
¨Other:
Challenge Description
Suggestions for ADLINK

Table of Contents•i
Table of Contents
Chapter 1 Introduction..............................................................1
1.1 FEATURES ......................................................................................................1
1.2 The NUPRO-710 Package ..........................................................................3
1.3 Board Layout, Jumpers and Connectors...............................................4
Chapter 2 Installation................................................................6
2.1 Static Electricity Precautions ...................................................................6
2.2 Installation Steps .........................................................................................7
2.3 CPU Type and BUS Clock Speed Selector .............................................7
2.4 RTC Clear CMOS Memory: JP9.................................................................9
2.5 Set DOC Memory base address...............................................................9
2.6 Watchdog Timer setting...........................................................................10
2.7 System Memory Installations .................................................................11
2.8 Expansion Card installations ..................................................................11
Chapter 3 Connectors.............................................................13
3.1 CPU/CHASSIS FAN Connector.................................................................13
3.2 IRCON Connector .......................................................................................14
3.3 LCD Connector............................................................................................14
3.4 USBP Connector.........................................................................................15
3.5 ATX Connector............................................................................................15
3.6 PS-ON Switch..............................................................................................16
3.7 KEY Lock Connector..................................................................................16
3.8 Speaker Connector ...................................................................................17
3.9 Reset Switch Connector ..........................................................................17
3.10 Power LED Connector...............................................................................18
3.11 SMI LED Connector....................................................................................18
3.12 SMI Switch Connector ..............................................................................19
3.13 IDE_LED........................................................................................................19
3.14 Internal KB Connector...............................................................................20
3.15 Primary, Secondary IDE Connector.......................................................20
3.16 Parallel Printer Connector.......................................................................21
3.17 Floppy drive connector .............................................................................21
3.18 COM2 Connectors......................................................................................22
3.19 COM1 Connector (9-pin female).............................................................22
3.20 PS/2 Mouse Connector (6-pin female)..................................................23
3.21 PS/2 KB Connector (6-pin female).........................................................23

ii •Table of Contents
3.22 VGA Connector ...........................................................................................24
3.23 RT1: Hardware Monitoring connector...................................................24
Chapter 4 BIOS Setup.............................................................25
4.1 UPDATING NUPRO-710 BIOS (Software Flash)...................................25
4.2 Standard CMOS Setup..............................................................................28
4.3 BIOS Features Setup.................................................................................32
4.4 Intel 440BX Chipset Features Setup......................................................35
4.4.1 Cache Features...................................................................................37
4.4.2 PCI and IDE Configuration.................................................................37
4.5 Power Management Setup......................................................................39
4.5.1 PM Timers............................................................................................40
4.5.2 Reload Global Timer Events.............................................................42
4.6 Intel 440BX PnP/PCI Configuration Setup............................................42
4.7 Load BIOS Defaults....................................................................................44
4.8 Load Setup Defaults..................................................................................45
4.9 Integrated Peripherals..............................................................................46
4.10 Setting Supervisor & User Passwords ................................................49
4.11 IDE HDD Auto Detection............................................................................50
4.13 Save and Exit Setup...................................................................................51
Chapter 5 ATI 3D RagePro XL Features...............................52
5.1 General Features........................................................................................52
5.2 Integrated TMDS.........................................................................................53
5.3 Digital Flat Panel Monitor Support..........................................................53
5.4 LCD Panel Control......................................................................................53
5.5 ACPI Power Management........................................................................54
5.6 AGP 2X mode..............................................................................................54
5.7 Floating-Point Set-up Engine ...................................................................55
5.8 125MHz SGRAM..........................................................................................55
5.9 2D Acceleration..........................................................................................56
5.10 3D Acceleration..........................................................................................56
5.11 Motion Video Acceleration.......................................................................58
5.12 Software Features.....................................................................................59

Introduction •1
1
Introduction
This manual explains how to use this SINGLE-BOARD COMPUTER board and
install upgrades. It has an overview of the design and features of the board
and provides useful information if you want to change the configuration of
the board, or a system it is installed in.
The NUPRO-710 Single-board Computer is designed as an All-In-One
complete system. Plugged into a passive backplane. The NUPRO-710 will
be compatible with PICMG Ver 2.0 PCI/ISA Standard and Intel PCI
Ver.2.0/2.1 compliant.
Upgrading your system with a high performance, without the high cost. For
industrialuserswhoneedmoreprocessingpower,itisperfectasabuilding
blockfortheIPCworkstationusedforfactory automation, data acquisition or
distributed process control.
The perfect choice for building a LAN server, a High-End workstation a
multi-user or industry PC system.
1.1 FEATURES
TheADLINKNUPRO-710iscarefullydesigned forthedemandingIndustrial
PC user who wants great many features in a small package. This
Single-board Computer:
lEasyInstallation:IsequippedwithBIOSthatsupportsautodetectionof
hard drives, PS/2 mouse, and Plug and Play devices to make setup of
hard drives, expansion cards, and other devices virtually automatic.
lIntelProcessor:SupportsoneCeleronPPGACPUandIntelPentiumIII
FC-PGA CPU (Coppermine core) onSocket 370.
lIntelAGPset:FeaturesIntel's440BXAGPsetswithI/Osubsystemsand
Intel's FSB (Front-Side Bus) platform, which boasts a 100/66MHz
internal bus speed.
lUSB Interface:Supports the Universal Serial Bus.

2•Introduction
lIrDA Connector: Supports an infrared port module for wireless
interface.
lATI Rage Pro XL Graphics Controllers (only for NUPRO-710):
On-board64-bitgraphicsaccelerator with support for Digital Flatpanel
monitors and superior support for 3D and motion video, with 8MB
SGRAM.
lDesktopManagementInterface (DMI):SupportsDMIthroughBIOSthat
allowshardwareto communicatewithinastandardprotocolcreatinga
higher level of compatibility.
lVersatile SDRAM Memory Support: Is equipped with three DIMM
sockets to support (8MB, 16MB, 32MB, 64MB, 128MB, 256MB)
SDRAM/EDO 168-pin memory module.
lSuper Multi-I/O (Winbond 83977TF_AW Chipset): Provides two
high-speed UART compatible serial ports and one parallel port with
EPP and ECP capabilities. UART2 can also be directed from COM2 to
the Infrared Module for wireless connections. Two floppy drives of
either 5.25" or 3.5" (1.44MB or 2.88MB) are also supported without an
external card.
lH/W monitoring: Winbond 83781D Chipset, monitoring (+/-)Voltage,
System Temperature and fan speed.
lReady-to-UseConnectors:Is equipped with onboard Parallel(Printer)
Port, Serial Ports (COM1&2), PS/2 Mouse, and PS/2 Keyboard
connectors without the need for extra cables and brackets.
lPCI Bus Master IDE Controller: Comes with an onboard PCI Bus
Master IDE controller with two connectors that supports four IDE
devices in two channels, provides faster data transfer rates, and
supports Enhanced IDE devices such as Tape Backup and CD-ROM
drives. This controller supports UltraDMA/33, PIO Modes 3 and 4 and
BusMasterIDE DMA Mode 2. BIOSnowsupport IDE CD-ROM or SCSI
boot-up.
lPICMGCompatible:32 bitsPCI-ISA CARD EDGE Connector supports
32-bit BusMaster 4 x PCI Expansion slots and 16-bit ISA Expansions
slots.
lWatchdog Timer: The function can generate a system reset. Jumper
configurable to always disable or software programmable
enable/disable. The timer interval is 10-80sec.
lUses I/O ports hex 043and 443 to control the watchdog timer.
lDMA channels: 7
lInterrupt levels: 15
lPhysical Size: 13.33" x 4.8"
lPower Requirement: +5V/4.5AMPS.

Introduction •3
1.2 The NUPRO-710 Package
Item Checklist
Please check that your package is complete. If you discover damaged or
missing items, please contact your retailer.
The NUPRO-710 Single-board Computer Package comes with the
following:
lThe NUPRO-710 Single-board Computer with built-in 2 Serial, 1
Parallel, PS/2 Keyboard, PS/2 Mouse connectors
l1 IDE ribbon cable, 1 Floppy Disk ribbon cable
lone NUPRO-710 user's manual & CD
lSmall bag for spare jumpers & screws.
lTemperature sensor for two pins connector into RT1 and V shape
metal

4•Introduction
1.3 Board Layout, Jumpers and Connectors
NUPRO-710 NUPRO-711

Introduction •5
Jumpers:
JP1, JP2, JP3, JP4: Bus & External Clock Selector
JP5, JP6, JP7: CPU to Bus Frequency Ratio
JP9: RTC Clear CMOS Memory
JP8, JP10/JP11: Watchdog Timer Setting
JP12, JP13, JP14: Set DiskOnChip will be mapped to Memory base
address
Connectors:
Fan Connector: Connector for CPU cooler & chassis fan
IRCON Connector: Connector for Optional IrDA-Compliant Infrared
Port module
LCD Connector: 28 pins Connector for LCD
USB Connector: Connector for USB port
ATX Connector: Connect to backplane ATX connector
PS-ON: Two pin for Case power switch
Reset Switch
Connector: Two pin Connector for a Reset Switch
IDE_LED: Two pin Connector for an IDE Activity LED
Speaker Connector: 4 pins Connector for a System Case Speaker
Key Lock Connector: Connector for a Keyboard Lock
Power LED Connector:
Connector for a Power-On Indicator LED
SMI Switch Connector:
Connector for a Suspend Switch lead
SMI LED Connector: Connector for a Suspend Switch lead
Primary,Secondary
IDE Connector: Two 40-pin Block
Parallel Printer
Connector: 26-pin Block
Floppy Drive
Connector: 34-pin Block
COM2 Connector: 10-pin Block
COM1 Connector: 9-pin Female
PS/2 Mouse
Connector: 6-pin Female
PS/2 KB Connector: 6-pin Female
VGA Connector: (Only
for NUPRO-710) 15-pin Female
RT1: 2-pins, hardware monitor connector

6•Installation
2
Installation
Several hardware settings are made through the use of jumper caps to
connect jumper pins (JP) on the Single-board Computer. See“Map of the
Single-board Computer”for locations of jumpers. The jumper setting will
be described numerically such as
1
2
3
,
1
2
3
,
1
2
3
for no connection, connect pins 1 & 2, and connect pin 2 & 3 respectively.
Pin 1 for our Single-board Computers is always on top or on the left when
holdingtheSingle-board Computer with the keyboard connector away from
you.A“1”iswrittenbesidespin1onjumperswiththreepins.Thejumpers
will also be shown graphically such as to connect pins 1 & 2 and to connect
pin 2 & 3. Jumpers with two pins will be shown as for Short (On) and for
Open (Off). For manufacturing simplicity, the jumpers may be sharing pins
fromothergroups.Use the diagramsinthismanualinsteadof followingthe
pin layout on the board. Settings with two jumper numbers require that both
jumpers be moved together. To connect the pins, simply place a plastic
jumper cap over the two pins as diagrammed.
2.1 Static Electricity Precautions
Under the right conditions, static electricity will build up. If you touch the
board or other sensitive components, the build-up will discharge into the
components and circuitry. Computer components are sensitive to damage
from static electric discharge. They can be damaged or destroyed if the
dischargeispowerfulenough.Staticbuild-up is most likely to occur in dryer
and cooler conditions but it is always important to be cautious.

Installation •7
2.2 Installation Steps
Before using your computer, you must follow the six steps as follows:
1. Set Jumpers on the Single-board Computer
2. Install SDRAM on board
3. Install Celeron CPU or Pentium III FC-PGA CPU intoSocket 370.
4. Plug into PICMG PCI/ISA Backplane
5. Connect Ribbon Cables, Cabinet wires, and Power supply
6. Setup the BIOS Software
2.3 CPU Type and BUS Clock Speed Selector
JP5/JP6/JP7, JP1/JP2/JP3/JP4
Bus & CPU External Clock Selector: JP5, JP6 and JP7
These jumpers tell the clock generator what frequency to send to the CPU.
These allow the selection of the CPU's External frequency (or BUS Clock).
The BUS Clock times the BUS Ratio equals the CPU's internal frequency.
(The advertised CPU Speed) Set the jumpers by the internal speed of the
Intel CPU as follows:
External
JP5JP6JP7
66MHz
1-2
1 2 3
1-2
1 2 3
2-3
1 2 3
100MHz
1-2
1 2 3
1-2
1 2 3
1-2
1 2 3
JP5/JP6/JP7

8•Installation
CPU to Bus Frequency Ratio: JP1, JP2, JP3, and JP4
These jumpers set the frequency ratio between the internal frequency of the
CPU and the External frequency (Called the BUS Clock) within the CPU.
These must be set together with the above jumpers CPU External (BUS)
Frequency Selector. Set the jumpers by the internal speed of the Intel CPU
as follows:
CPU/Bus clock
JP1JP2JP3JP4
8.0 xOPEN
SHORT
SHORT
OPEN
7.5 xOPEN
OPEN
OPEN
SHORT
7.0 xOPEN
SHORT
OPEN
SHORT
6.5 xOPEN
OPEN
SHORT
SHORT
6.0 xOPEN
SHORT
SHORT
SHORT
5.5 xSHORT
OPEN
OPEN
OPEN
5.0 xSHORT
SHORT
OPEN
OPEN
4.5 xSHORT
OPEN
SHORT
OPEN
4.0 xSHORT
SHORT
SHORT
OPEN
3.5 xSHORT
OPEN
OPEN
SHORT
JP1/JP2/JP3/JP4

Installation •9
2.4 RTC Clear CMOS Memory: JP9
You can use this jumper to clear the CMOS memory that stores the BIOS
Setup Utility configuration record, including any passwords. After clearing
the CMOS memory you must run the BIOS Setup Utility again to create and
store a new configuration record.
RTC Clear Selector JP9
Normal (default) 1-2
1 2 3
Clear (must input voltage)
2-3
1 2 3
2.5 Set DOC Memory base address
JP12, JP13 and JP14
TheDiskOnChipshould bemappedtooccupyan8KBwindowofexpansion
BIOS space, which is usually located between 0C0000H to 0EFFFFH.
Memory window base
address JP12 JP13 JP14
C8000-CFFFF OPEN
SHORT
OPEN
D0000-D7FFF (Default)
SHORT
OPEN
OPEN
D8000-DFFFF OPEN
OPEN
SHORT
JP12/JP13/JP14

10 •Installation
JP1
0
2.6 Watchdog Timer setting
JP8, JP10/ JP11
The Watch-Dog Timer is enabled by reading port 443H.The Watch-Dog
Timer should be triggered before the Watch-Dog Timer time-out period
ends, otherwise the Watch-Dog Timer assumes the program operation is
abnormal and will issue a reset signal to start again, or activate NMI (by
Pull-LowIOCHK#)totheCPU. TheWatch-DogTimer is disabled by reading
port 043H.
TheWatch-DogTimertime-out period can be set 10sec, 15sec, 25sec and
80sec.
Watchdog Timer setting
WT DOG
JP8
NMI 1-21 2 3
Reset 2-31 2 3
Default
Disabled
OPEN 123
WDT Time-Out Period setting: JP10, JP11
WDT Period
JP10 JP11
80sec. OPEN
OPEN
25sec. OPEN
SHORT
15sec. SHORT
OPEN
10sec. SHORT
SHORT
(default)

Installation •11
2.7 System Memory Installations
The NUPRO-710 supports three 128-pin DIMMs for SDRAMs or EDO
DRAMs of either 8MB, 16MB, 32MB, 64MB, 128MB or 256MB to form a
memory size between 8MB to 768MB.
IMPORTANT: Do not mix SDRAMs or EDO DRAMs .
To use Error Checking and Correction (ECC), you must used a DIMM
module with 9 chips per side (e.g. 8 chips + 1 parity chips) and make the
proper settings in the BIOS Chipset Feature Setup.
Install memory in any combination as follows:
DIMM socket 168-pin DIMM Memory Module
DIMM Slot 1 8MB, 16MB, 32MB, 64MB, 128MB, 256MB
SDRAM or EDO
DIMM Slot 2 8MB, 16MB, 32MB, 64MB, 128MB, 256MB
SDRAM or EDO
DIMM Slot 3 8MB, 16MB, 32MB, 64MB, 128MB, 256MB
SDRAM or EDO
Total System Memory =
2.8 Expansion Card installations
First read your expansion card documentation on any hardware and
software setting that may be required to setup your specific card.
Expansion Card Installation Procedure
1. Read the documentation for your expansion card.
2. Set any necessary jumpers on your expansion card.
3. Carefully align the card's connectors and press firmly.
4. Setup the BIOS if necessary.
5. Install the necessary software drivers for your expansion card.
Assigning IRQs for Expansion cards
Some expansion cards need to use an IRQ to operate. Generally an IRQ
must be exclusively assigned to one use. In a standard design there are 16
IRQs available but most of them are already in use by parts of the system
which leaves 6 free for expansion cards.

12 •Installation
BothISAand PCI expansion cards may need to use IRQs. System IRQs are
available to cards installed in the ISA expansion bus first, and PCI cards
then use any remaining IRQs. Currently, there are two types of ISA cards.
The original ISA expansion card design, now referred to as " Legacy " ISA
cards, requires that you configure the card's jumpers manually and then
install it in any available slot on the ISA bus. You may use Microsoft's
Diagnostic(MSD.EXE)utility includedintheWindowsdirectorytoseeamap
of you’re used and free IRQs. For Windows 95 users, the "Control Panel"
icon in " My computer" contains a "System" icon which give you a "Device
Manager"tab.Doubleclickingonaspecificdevicegiveyou"Resources"tab
which shows the Interrupt number and address. Make sure that no two
devices use the same IRQs or your computer will experience problems
when those two devices are in use at same time.
TosimplifythisprocessthisSingle-board Computer has complied with the
Plug and Play specification, which was, developed to allow automatic
system configuration whenever a PNP Compliant card is added to the
system. For PNP card, IRQs are assigned automatically from those
available.
If the System has both Legacy and PNP ISA Cards installed, IRQs are
assigned to PNP cards from those not used by Legacy cards. The PCI and
PNP configuration of the BIOS setup utility can be used to indicate which
IRQs are being used by Legacy cards. For older Legacy cards that does not
work with the BIOS. You can contact your vendor for an ISA Configuration
Utility.
An IRQ number is automatically assigned to PCI expansion cards after
those used by Legacy and PNP ISA cards. In the PCI bus design, the BIOS
AUTOassignsanIRQtoPCIslotthathasacardinitthatrequiresanIRQ.To
install a PCI card, you need to set something called the INT (Interrupt)
assignment. Since all the PCI slots on the NUPRO-710 use an INTA#, be
sure that the jumpers on your PCI cards are set to INTA.
Assigning DMA Channels for ISA Cards
SomeISAcards,bothLegacyandPNPmayalsoneedtouseaDMAchannel.
DMA assignments for the NUPRO-710 are handled the same way as the
IRQ assignment process described above. You can select a DMA channel
in the PCI and PNP configuration section of the BIOS Setup utility.
IMPORTANT: In BIOS setup, you should choose “YES” for those IRQ’s and
DMA’s you wish to reserve for Legacy (Non-PNP) ISA cards,
otherwise conflicts may occur.
