JOBAID
TECHNICAL SUPPORT 800.726.8663
61152182L1-22A9904
TRI-CDP/
BR1/10
CLEI:D4CIA9T2
BR1/10 CHANNEL PIN-OUT
Channel
Position Pin Lead
127R
2T
229R
4T
331R
6T
433R
8T
535R
10 T
637R
12 T
739R
14 T
841R
16 T
943R
18 T
10 45 R
20 T
STATUS LED
STATUS ●RED No synchronization on either or both Total
Reach
and T1 interfaces
●GREEN Synchronizatin on bothTotal Reach andT1
interfaces
HARDWARE SWITCH SW1
SW1-1: B1 - along with SW1-2 and SW1-3,selects the service level
SW1-2: B2
SW1-3: D
■Service Option SW1-1 SW1-2 SW1-3
(B1) (B2) (D)
2B+D On On On
2B On On Off
B1+D On Off On
B2+D Off On On
B1 On Off Off
B2 Off On Off
D Off Off On
SW1-4: Zero Byte Substitution (ZBS)
■Enables or disables ZBS
Note: ZBS must be set the same as the U-BR1TE terminating theT1
carrier facility. For AMI-provisioned carriers, ZBS should be enabled.
Setting is optional for B8ZS-provisioned carriers.

JOBAID
FOR COMPLETE I&M PRACTICE 877.457.5007
DOCUMENT # 094
HAVE YOUR FAX NUMBER AVAILABLE
TRISDN
CLEI:DDRPLRC1AA
DEPLOYMENT GUIDELINES
TOTAL REACH SC PAM SIDE
Maximum Loop Loss .......................46 dB @ 20 kHz using a 135 ohm termination
52 dB @ 28 kHz using a 135 ohm termination
Maximum Noise................................34 dBrn using a 135 ohm termination with a 50 kB filter
Maximum DC Resistance.................2000 ohms
Maximum Single BridgedTap...........2 kft
MaximumTotal Bridged Tap..............6 kft
Maximum # of BridgedTaps..............3
NominalVoltage.................................-130VDC fromTIP (GND) to RING (-130 v)
Note:Bridged Tap length must be included as part of the total loop length.
U-INTERFACE SIDE
Maximum Loop Loss .......................42 dB @ 40 kHz using a 135 ohm termination
Maximum Noise................................33 dBrn using a 135 ohm termination with a 50 kB filter
Maximum DC Resistance.................1300 ohms
Maximum Single BridgedTap...........3 kft
MaximumTotal Bridged Tap..............6 kft
Maximum # of BridgedTaps..............3
Voltage.................................-48VDC from TIP (GND) to RING (-48 v)
T400 EDGE CONNECTOR PIN ASSIGNMENTS
55 TIP, U-Interface
49 RING, U-Interface
47 RING, Total Reach Interface
41 TIP, Total Reach Interface
27 Frame GND
11 Frame GND
Note:ISDN connections are not polarity sensitive
STATUS LEDs
NT1 I/F ●ON Indicates a loss of signal from or synchronization
with the 2B1Q BRI interface towards customer’s
NT1.
✷FLASHING Once per second indicates receipt of a Near End
Block Error from the 2B1Q BRI interface.
TRI I/F ●ON Indicates a loss of signal or synchronization with
the TRI-C (Total Reach ISDN CO) unit
✷FLASHING Once per second indicates receipt of a Near End
Block Error from theTRI-C unit
LOOPBACK ●ON Indicates theTRI-R unit is in a 2B+D loopback
✷FLASHING Oncer per second for B1 loopback, twice per second
for B2 loopback
ACT ●ON Indicates the terminal equipment has exchanged
ACT bits with the ISDN switch
✷FLASHING Once per second indicates that the ACT bit is being
sent from only the terminal equipment (CPE)
OPTIONS
■S1-1 SX
ON Default and normal condition. Provides between 4 to 10 mA of sealing
current toward the customer’s NT1/TA.
OFF Disables sealing current to the customer’s NT1/TA.
■S1-2TEST
ON Used for factory test only.
OFF Default and operational mode.
COMPATIBILITY
