ADTRAN Total Access 5004 User manual

e ADTRAN Total Access 5004 is a carrier
class multi-service access and aggregation
platform that extends the portfolio of the
world-class Total Access 5000 product line.
With a pure Ethernet core, the Total Access 5004
supports both legacy and emerging service
interfaces over copper and bre, easily scaling
to support even the most bandwidth-intensive
applications in a compact 2RU form factor. In
addition to supporting both legacy and next
generation access interfaces, the Ethernet core
of the Total Access 5004 provides a scalable
and cost-optimised aggregation point in the
network, with interfaces ranging from
E1 to 10 and 20 Gigabit Ethernet.
Environmentally hardened, the
Total Access 5004 is designed with the
service provider in mind and is equally capable
of deployment in central exchange or remote street
cabinet locations. Similar to the Total Access 5000,
the Total Access 5004 chassis provides a truly
scalable architecture that is designed to migrate
with the network, providing exible copper and
bre termination options based on network
applications. With the simple change of a
“personality module,” equipment obsolescence
can be avoided and network investments protected
with a platform that is also capable of scaling to
meet the needs of network evolution for years to
come. e Total Access 5004 supports a variety
of access and line modules with supported
applications including Broadband Digital
Loop Carrier, Fibre-to-the-Home (FTTH),
Fibre to-the-Cabinet (FTTC), Carrier Ethernet,
Ethernet Aggregation, legacy business and
residential aggregation, as well as next generation
Optical Networking Edge (ONE) aggregation and
transport in a 2RU compact design.
e Total Access 5004 supports a wide variety
of management options. Transaction Language
1 (TL1) is used to communicate alarms to legacy
Operation Support Systems (OSS). Alternatively,
Extensible Markup Language (XML) can also be
used. An Ethernet 10/100Base-T or standard
RS-232 connector is used for management access
and connection to SNMP networks. Additionally,
the Total Access 5004 is supported by ADTRAN’s
Advanced Operational Environment (AOE).
ADTRAN AOE provides a Web GUI management
interface and support for XML and TL1 north-
bound OSS interfaces. e XML and TL1
north-bound interfaces provide customers the
ability to automate ow-through services to the
Total Access 5004 platform.
e Total Access 5004 is designed for deploy-
ment in 19-inch or 23-inch relay racks and has
four access module slots, two resource slots,
two dedicated management and switch modules
(MSM), and a eld replaceable fan.
Product Features
nNative Ethernet core
nBroadest support for FTTx,
Packet Optical and Carrier
Ethernet application
nNon-blocking service
architecture
nSupports TDM, ATM and
Ethernet network interfaces
n Copperandbretransport
and access
nFully redundant, carrier
class design
nDigital and metallic test access
nMultiple network management
capabilities including full
FCAPS support
nSupported by ADTRAN AOE
Service Management
nFull turn-key cabinet solutions
Total Access 5004
Carrier class Multi-service Access
and Aggregation Platform

ADTRAN, Inc.
International Department
U.S. Headquarters
901 Explorer Boulevard
Huntsville, Alabama 35806
www.adtran.com/global
[phone]
[phone] fax
[email protected]
International Customer Service
[phone]
Asia—Beijing, China
[phone]
[email protected]
Asia—Hong Kong
[phone]
[email protected]
Asia—Singapore
[phone]
[email protected]
Australia/New Zealand—
Melbourne, Australia
[phone]
[email protected]
Australia/New Zealand—
Sydney, Australia
[phone]
[phone]
[email protected]
Canada Headquarters—
Toronto, Ontario
[phone]
[phone]
[email protected]
Canada—Montreal, Quebec
[phone]
[phone]
[email protected]
Europe, Middle East and Africa
Headquarters—Munich Germany
[phone]
[email protected]
Germany
[phone]
[email protected]
Central/East Europe
[phone]
[email protected]
South Europe
[phone]
[email protected]
West/North Europe
[phone]
[email protected]
Middle East and Africa
[phone]
[email protected]
Mexico and Central America
[phone]
[phone] Mexico
[email protected]
South America
[phone]
[email protected]
[email protected]
ADTRAN believes the information in this publication to be accurate as of publication date, and is not responsible for error. Specifications subject to
change without notice. ADTRAN and Total Access are registered trademarks of ADTRAN, Inc. and its affiliates in various countries. All other trade-
marks mentioned in this document are the property of their respective owners.
ADTRAN warranty duration and entitlements vary by product and geography. For specific warranty information, visit www.adtran.com/warranty
ADTRAN products may be subject to U.S. export controls and other trade restrictions. Any export, re-export, or transfer of the products contrary to
law is prohibited. For more information regarding ADTRAN’s export license, please visit www.adtran.com/exportlicense
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
I61187004F1-8A September
Copyright © 2013 ADTRAN, Inc.
All rights reserved.
Mechanical
nDimensions: 89 mm x 450 mm x 295 mm
(H x W x D) (3.5 in. x 17.7 in. x 11.6 in.)
two Rack Mountable Units (RMU)
Interfaces
nTransport: Ethernet
nPhysical: Varies Per Access Module
Electrical
nDC Power: -42 to -72 VDC and +21 to +27 VDC
nConnection: Screw terminals (A and B feed)
Regulatory Standards
nRoHS 6 of 6
nNEBS Level III
nTelcordia GR-1089 CORE, Issue 4 and
GR-63 CORE, Issue 3
nNRTL Listed; UL 60950 and FCC Part 15, Class A
nInternational CE Mark
nETS 300 019 Class 1.2, 2.3, 3.3
nITU K.20
nIEC60950-1 CB Scheme Report including
EN 60950-1 and AS/NZS60950
nETSI EN 300-132-2 and EN 300 386
nEN 55022 Class A
nEN 61000-4-11
nACA SO43 (PSD)
Management
nElectrical: RS-232 Electrical Interface
nEthernet: 10/100Base-T interface
nProtocols: SNMP, TLI, XML, Telnet,
and Secure Telnet (SSHv2)
Environmental
nOperating Temperature: -40° C to +70° C
(-40° F to +158° F)
nStorage Temperature: -40° C to +70° C
(-40° F to +158° F)
nRelative Humidity: Up to 95%, non-condensing
Applications and Services Supported
nFTTH for VoIP, IPTV and Business Ethernet
nFTTCab for VoIP, IPTV and Business Ethernet
nSimpliedFTTCabtoFTTHmigration/transition
nCompact ONE for Premium Services
10G Aggregation and Packet Optical Transport
nCarrier Ethernet services over any medium
(DS1/E1, DS3, SHDSL, ADSL2+, VDSL2, GPON,
Fibre, Wavelength)
Product Specications
Total Access 5004
Ordering Information
Equipment Part No.
Total Access 5004 Kit with
Fan (includes 1187004F1
Chassis, 1187064F1 Power/
Alarm, and 1187094F1 Fan)
4187004F1
Total Access 5004 Individual Parts
Chassis 19-inch 1187004F1
Power/ALM Module 1187064F1
Filter 19-inch Chassis 1187092F1
Fan Mod 19-in Chassis 1187094F1
Total Access 5000 Blanks
AM Blank (Front) 1187921E1
AM Blank Dual Slot (Front) 1187922E1
AMIO2 Blank (Rear) 1187923G1
AMIO1 Blank (Rear) 1187925G1
Total Access 5004 Blanks
MSM Blank Panel (Front) 1187927F1
Resource Blank Panel (Front) 1187928F1
Resource-2 Blank Panel (Front) 1187929F1
Managed Switch Module (MSM) Commons
Total Access 5004 MSM
2-1GE
1187013F1
Total Access 5004 MSM
20-10GE
1187016F1
Total Access 5004
MSAN
AOE
Services
Management
Data, Video, Voice Data, Video, Voice
VDSL2
Business
Business
Residential
FTTP
Mobile
Mobile
FTTN
Data Center
VDSL2
Residential
P-OTS
Bluesocket 1800
Bluesocket 1800
NetVanta 1335
IP Phone
Wi-Fi
Smallcell
IP Business
Gateway
ONT
