Total AccessTM 750/850
QUAD FXS Access Module
Installation and Maintenance
Figure 1. TA 750/850 Quad FXS
Trademarks: Any brand names and product names included in this document are
trademarks, registered trademarks, or trade names of their respective holders.
1. GENERAL
This practice provides installation and maintenance
procedures for the ADTRAN Total AccessTM 750/850
(TA 750/850) Quad Foreign Exchange Station (FXS)
Access Module. Figure 1 is an illustration of the
Quad FXS Module. The Quad FXS is designed
specifically for the ADTRAN Total Access 750 and
850 chassis and is not used in any other product. The
unit is multifunctional and can be provisioned to
operate in any one of the following modes:
• 2-Wire Foreign Exchange Station (2FXS)
• Dial Pulse Originate (DPO)
• Tandem FXS Mode
• Private Line Automatic Ringdown (PLAR)
Revision History
This document has been revised to include Windows
Hyperterminal and PASSWORD information.
Features
The features of the TA 750/850 Quad FXS, part
number 1175408L1, include:
• Provides four individual analog voice
interfaces.
• Automatic short loop provisioning feature.
•µ-law encoding and decoding.
• Supports ground start, loop start, and TR-08
signaling.
• Long loop capability – 1200 ohms (nominal)
including telephone set (16 kfeet @ 24 AWG).
• Hot Swappable.
• V.90 Modem compliant.
• Supports CLASSTM features such as Caller ID.
• Transmit attenuation setting of 0 to -9 dB.
• Receive attenuation setting of 0 to -9 dB.
• Selectable 600Ω, 900Ω, 600Ω+2.16µF,
or 900Ω+2.16µF 2-wire VF interface.
• Occupies a single slot in the TA 750 or TA 850
chassis.
• UL 1950 compliant.
• Extended temperature range of -40 to +65º C.
• Call Forward Disconnect
• Meets NEBS Level 3 reguirements
General Description
The Quad FXS access module is used in the
TA 750/850 platforms to provide analog voice
extension. The Quad FXS resides in the TA chassis
that is next or close to the customer’s telephone and is
usually located on the customer premises. The unit
CONTENTS
1. GENERAL ............................................................................. 1
2. INSTALLATION .................................................................... 2
3. OPTIONS ............................................................................... 3
4. OPERATION .......................................................................... 4
5. TESTING ............................................................................... 5
6. SPECIFICATIONS................................................................. 5
7. MAINTENANCE................................................................... 5
8. WARRANTYAND CUSTOMER SERVICE ........................ 6
Figures
Figure 1. TA 750/850 Quad FXS........................................ 1
Figure 2. FXO to FXS Deployment ................................... 2
Figure 3. CO Switch to FXS Deployment .......................... 2
Figure 4. Circuit Path ......................................................... 3
Figure 5. Connector Pin Assignments ................................ 4
Tables
Table 1. Telecommunications Codes ............................................. 3
Table 2. TA 750 Time Slot Assignments ....................................... 4
Table 3. Specifications................................................................... 6
FXS
BUSY
1175408L1
2
3
4
1

2 Section 61175408L1-5, Issue 3 61175408L1-5C
27 March 00
can be used in conjunction with the TA 750/850 FXO
(Foreign Exchange Office) access module, ADTRAN
part number 1175407L1, which resides in the
TA 750/850 that is located next to the Central Office
Switch.
Figure 2 provides an illustration of a typical
deployment using a TA 750 chassis with both FXO
and FXS access modules. This arrangement is used
where the TR-08 signaling format is not conveniently
available at the CO switch. The TA 750 at the CO will
combine a number of analog lines then multiplex them
for T1 transmission to the TA 750 at the customer
premises.
When using the TR-08 signaling option, the Quad
FXS can communicate directly with the Central Office
Switch without needing a Quad FXO. Figure 3
provides an illustration of a typical TR-08
deployment.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by
ADTRAN could void the user's authority to operate
this equipment.
2. INSTALLATION
After unpacking the unit, inspect it for damage. If
damage is noted, file a claim with the carrier, then
contact ADTRAN Customer Service.
The Quad FXS inserts into any access card slot of the
TA 750 or TA 850 chassis.
To install the Quad FXS, hold the unit by the faceplate
while supporting the bottom side. Align the card edges
to the guide grooves for the designated slot. Insert the
card until the edge connector seats firmly into the
backplane. Lock the unit in place by pushing in on the
locking lever.
Telecommunications Codes
Table 1 shows the Configuration Codes for the Total
Access 750/850 QUAD FXS Access Module. The
Total Access 750/850 QUAD FXS Access Module is
intended to be installed in restricted access locations
and in the Total Access 750 /850 chassis only, and in
equipment with a Type 'B' or 'E' installation code.
3. OPTIONS
Figure 2. FXO to FXS Deployment
Figure 3. CO Switch to FXS Deployment
C A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.

3Section 61175408L1-5, Issue 361175408L1-5C
27 March 00
There are no hardware options on the Quad FXS
access module. The module has factory default
settings for each of the four analog interfaces on the
module. The DB-9 VT 100 craft interface on the
TA 750 BCU or the TA 850 RCU is used if any other
settings or provisioning options are desired. The
factory default setting for the QUAD FXS interfaces
are as follows:
• Loop start signaling.
• Automatic loop provisioning enabled.
Automatic Loop Provisioning
The Quad FXS incorporates a feature that
automatically detects loop length and sets the
termination impedance and gain for transmit and
receive attenuation levels. This feature is enabled from
the factory and can be disabled through the craft
interface on the Bank Controller Unit (BCU).
For short loops, the termination impedance is set to
600 ohms + 2.16 uF and the gain is set to –6 dB for
transmit and –3 dB for receive attenuation levels. For
longer loops, the termination impedance is set to 900
ohms + 2.16 uF and the gain is set to –3 dB for
transmit and receive attenuation levels.
Setting Attenuation With Known TLP
For applications where input and output Transmission
Level Points are known, the transmit and receive
attentuation levels can be calculated to ensure
optimum VF characteristics. This is defined in AT&T®
Publication 43801 which explains that the value of the
digital signal at reference point TLP0 should be equal
to 0 dBm0, or a digital milliwatt for optimum
performance (proper volume heard through the
telephone). Refer to Figure 4 which displays the TLP
reference points (input, output, TLP0) and attenuation
parameters.
TRANSMIT ATTENUATION
Determine the input TLP. Then use the following
formula to calculate the amount of transmit
attenuation to add to the circuit:
Tx Attenuation = Input TLP
Example: if an input TLP of 3 dB is to produce a
level of 0 dBm0 at TLP0, then the Transmit
Attenuation should be set to 3.0 dB.
RECEIVE ATTENUATION
Determine the output TLP. Then use the following
formula to calculate the amount of receive attenuation
to add to the circuit:
Rx Attenuation = Output TLP
Example: if 0 dBm0 at TLP0 is required to produce
an output TLP level of -3 dB, then the Receive
Attenuation should be set to 3.0 dB.
Electronic Provisioning
The craft interfaces on the TA 750 BCU and the TA
850 RCU are used to change default options and
obtain access module status through menu screens.
To access the menu screens, connect a VT 100
terminal or computer running a terminal emulation
program to the faceplate craft interface ADMIN port
using a standard male-to-male RS-232 DB-9 cable.
Craft port settings are as follows:
• 9600 Baud
• No parity
• 8 Data bits
• 1 Stop bit
WINDOWS HYPERTERMINAL
Windows Hyperterminal can be used as a VT 100
terminal emulation program. Open Hyperterminal by
selecting PROGRAMS / ACCESSORIES /
HYPERTERMINAL. Refer to the Help section of
Hyperterminal for additional questions.
Figure 4. Circuit Path
0 to -9 dB TLP0
Tx Atten
T
R
0 dBm0
0 to -9 dB
0 to +9 dB
-9 to 0 dB TLP0
Rx Atten
0 dBm0
Transmit Path (To Backplane)
Receive Path (From Backplane)
Input TLP
Point
Output TLP
Point
Code Input Output
IC F C
TC - X
PC A -
Table 1. Telecommunications Codes

4 Section 61175408L1-5, Issue 3 61175408L1-5C
27 March 00
NOTE
Toensureproperdisplay background,select
VT 100 terminal emulation under
SETTINGS.
PASSWORD
Upon Hyperterminal can be used as a VT 100 terminal
emulation program. To enable the password, select
Back Controller (1) /Password control (8) /Enable
Password (2). The factory default is PASSWORD in
all capital letters. The password can be changed to a
user-selected password if desired.
MENU NAVIGATION
To traverse through the menus, select the desired entry
and press ENTER. To work backwards in the menu
press the ESC (escape) key.
Signaling States
The Quad FXS signaling states are provisioned
through the BCU/RCU craft interface. The following
signaling states are supported:
• Loop Start
• Ground Start
• TR 08 Signal Party
• TR008 Universal Voice Grade
• Tandem
• DP0
4. OPERATION
The Quad FXS goes operational upon insertion into an
active TA 750/850 chassis. Initialization with the
network is indicated by the faceplate LEDs. Refer to
Section 5, Testing for initialization procedures.
LED Status
After the initialization sequence, status of the analog
service for each customer loop is shown by four
(green) faceplate LEDs. Indication is as follows:
Off - On Hook
Flashing - Ringing
On - Off Hook (Busy)
Sequencing - Time Slot Unavailable
NOTE
Iftheunitisinsertedintoabankwhichhasits
timeslots allocated to the module assigned to
the DSX-1 or Nx56/64 port, the LEDs will
sequence,indicatingaproblem. Thetimeslots
must be freed up before the unit will become
operational.
Time Slot Assignment
The TA 750/850 platforms can have multiple time
slots in the T1 data stream assigned to each physical
slot in the channel bank. Table 2 outlines the
correlation between the T1 and physical slot for the
TA 750.
NOTE
Once inserted, the Quad FXS access module
utilizesallfourDS0timeslotsallocatedtothe
physical slot. DS0s can not be reassigned to
other ports (i.e., DSX-1 port, V.35 port).
Connections
A single 50-pin male amphenol connector on the rear
of the TA 750/850 chassis provides the interconnect
wiring for the four analog circuits on each access
module. Figure 5 details the pinout of the connector.
Table 2. TA 750 Time Slot Assignments
tolSlacisyhPdengissAtolSemiT1T
14-1
28-5
321-9
461-31
502-71
642-12

5Section 61175408L1-5, Issue 361175408L1-5C
27 March 00
5. TESTING
Self Test
A self test is performed on the Quad FXS when it is
inserted into an active TA 750 or TA 850 chassis. The
test verifies proper operation of critical circuits. If the
test is successful all four LEDs turn On in a
predefined sequence, the unit is placed in service, and
the LEDs then return to normal operation showing
current status of the FXS.
Initiated Tests
Other tests conducted on the Quad FXS are initiated
via the screen menus and VT 100 terminal.
DIGITAL LOOPBACK TEST
The Digital Loopback Test is used to loopback DS0
data coming from the network for each individual
channel. Received data is latched in on the appropriate
receive time slot on the receive bus. This data is then
placed on the transmit bus in the unit’s transmit time
slot.
NETWORK ON-HOOK / OFF-HOOK TEST
The Network On-hook / Off-hook test is used to test
signaling sent to the network by the unit. When
On-hook Test is selected, On-hook signaling is sent to
the network. When Off-hook Test is selected,
Off-hook signaling is sent to the Network. The
customer loop is forced On-hook while this test is
active.
CUSTOMER RING TEST
The Customer Ringing Test will activate the unit’s
ring relay in a 2-on / 4-off ring cadence, providing
ringing to the customer loop.
1000 H Z DRS TONE GENERATION TEST
The 1000 Hz DRS (Digital Reference Signal) Tone
Generation Test is used to send DRS signal on the
receive path to the loop. The loop receive level that
should be received is determined by the following
equation:
Receive Level = 0 dB - Attenuation
6. SPECIFICATIONS
Refer to Table 3 for TA 750/850 Quad FXS
specifications.
7. MAINTENANCE
The TA 750/850 Quad FXS requires no routine
maintenance for normal operation.
ADTRAN does not recommend that repairs be
performed in the field. Repair services are obtained by
returning the defective unit to ADTRAN Customer
Service.
Figure 5. Connector Pin Assignments
261
272
283
294
305
316
327
338
349
3510
3611
3712
3813
3914
4015
4116
4217
4318
4419
4520
4621
4722
4823
4924
5025
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
R
T
NC
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
50 PIN
AMP
RECEPTACLE
Slot 1
Slot 2
Slot 3
Slot 4
Slot5
T
T
R
T
T
R
R
Slot 6
P
P
P
P
Circuit 1
Circuit 2
Circuit 3
Circuit 4
Circuit 1
Circuit 2
Circuit 3
Circuit 4
Circuit 1
Circuit 2
Circuit 3
Circuit 4
Circuit 1
Circuit 2
Circuit 3
Circuit 4
Circuit 1
Circuit 2
Circuit 3
Circuit 4
Circuit 1
Circuit 2
Circuit 3
Circuit 4
R

6 Section 61175408L1-5, Issue 3 61175408L1-5C
27 March 00
8. WARRANTY AND CUSTOMER SERVICE
ADTRAN will replace or repair this product within 10
years from the date of shipment if it does not meet its
published specifications or fails while in service (see:
ADTRAN Carrier Networks Equipment Warranty,
Repair, and Return Policy and Procedure, document:
60000087-10A).
Contact Customer And Product Service (CAPS) prior
to returning equipment to ADTRAN. For service,
CAPS requests, or further information, contact one of
the following numbers:
ADTRAN Part Number
1175408L1
ADTRAN Sales
Pricing and availability
(888) 4-ADTRAN
ADTRAN Technical Support
Presales Applications / Post-sale Technical Assistance
[phone]
Standard support hours:
Monday-Friday, 7 a.m. - 7 p.m. CST
Emergency support: 7 days/week, 24 hours/day
ADTRAN Repair/CAPS
Return for repair / upgrade
[phone]
Repair and Return Address:
ADTRAN, Inc.
CAPS
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
Table 3. Specifications
lacirtcelESXFdauQ
:rewoP :tnerruCpooL
:ecnatsiseRpooL
:ecnadepmIgnitanimreT
:ssoLnruteR
:ssoLdirbyHsnarT
:ecnalaBlanidutignoL
:esnopseRycneuqerF
:esioNlennahCeldI :oitaRnoitrotsiD-ot-langiS
.)koohffo(sttaW6 lanimonpmAm32 muminimpmAm02 /lanimonsmho0021 *mumixamsmho0561 -smho0531/smho009( )enohp-smho003,enil ,Fµ61.2+smho009 ,Fµ61.2+smho006 .smho006dna,smho009 ,Fµ61.2+smho009 ,Bd82>LRE .Bd02>LRS ,Fµ61.2+smho009 ,Bd82>LRE .Bd02>LRS :zH0001dna,005,002 .evaBd36>,.nimBd85> :zH0003 .evaBd85>,.nimBd35> :zH0043ot003 .Bd0.1dna5.0- .CnrBd02< Bd33>:0mBd03-ot0 Bd72>:0MBd04-ot03- .Bd22>:0mBd54-ot04-
lacisyhP
:snoisnemiD :thgieW D"01xH"4/13 .bl1
tnemnorivnE
:erutarepmeTgnitarepO :erutarepmeTegarotS :ytidimuHevitaleR Cº56otº04- Cº07otº04- gnisnednoc-non%59otpU
tnerrucpoolAm02,tupniCDV84-htiwderusaeM*
