Advaning GA Series User manual

DOOR AWNING : GA SERIES
For your safety and the safety of others, please read all of the instructions and
warnings in this manual carefully before peceeding with installation and usage
Owner’s Manual

1
Safety Instructions and Warnings ........................................1~2
Package Contents and Parts .............................................. 3
Assembly Diagram ...................................................... 4
Required Tools ......................................................... 5
Installation
Pre-Installation Guide .............................................. 6
Assembly and Installation ........................................7~11
Maintenance.......................................................... 12
Limited Warranty and Contacts ........................................13~14
TABLE OF CONTENTS
www.advaning.com
SAFETY INSTRUCTIONS AND WARNINGS
A
D
B
E
C
F
Fig.1
Fig.2
For your safety, ensure
to have the following
available:
A. Minimun 3 people to
install
B. Work gloves
C. Safety goggles
DO NOT ATTEMPT
Assembly or Maintenance
if:
D. Rain is in the forecast
E. Wind is in the forecast
F. You are tired or under
the inuence of drugs
or alcohol
4”
HEADER BOARD
4”
SOLID MASONRY
4”
HEADER BOARD
4”
SOLID MASONRY
CAUTION!
GA Series awning MUST be mounted
to main structural supports, header,
or solid masonry 4-inch in thickness
or more.

2
SAFETY INSTRUCTIONS AND WARNINGS
www.advaning.com
ENSURE THAT THE DOOR AWNING IS MOUNTED TO MAIN STRUCTURAL SUPPORTS OF THE BUILDING.
FAILURE TO DO SO MAY RESULT IN INJURY OR DAMAGE TO THE PRODUCT OR PROPERTY.
Owners are solely responsible for proper handling, storage, assembly, installation and use of this product.
Advaning is not responsible for any damages or injury to you, any other parties, or property resulting from
improper handling, storage, assembly, installation, or misuse of the product.
INSTALLATION
• Pay close attention throughout the installation process to ensure that the Advaning awning is installed prop-
erly and according to the safety guidelines outlined herein.
• Keep children away from the assembly area and components.
• Do not attempt installation while under the inuence of alcohol or drug substances.
• Do not proceed with an installation if you feel that you cannot properly and safely complete, please seek
professional help.
• Always wear protective gear and gloves when handling sharp metal parts.
• Only perform installation/maintenance/cleaning in dry and optimal weather conditions.
• 3 or more persons are recommended for installation. Installation will require to lift the glass panel onto the
bracket. Ensure help is available to help lift and secure in position.
• Advaning recommends consulting with your local authorities if any permits or regulations are required prior
to installation of this product.
• Ensure adequate installation substrate, GA Series awning MUST be mounted to main structural supports,
header board, or solid masonry 4-inch in thickness or greater.
USAGE
• Only use Advaning recommended accessories and original replacement parts.
• Only perform installation/maintenance/cleaning in dry and optimal weather conditions.
• Do not place any heat source or open ame under or near the awning.
• Do not place, hang, or stand objects or persons on the awning itself. Doing so can damage the awning or
cause severe personal injury and in extreme cases death.
• Do not carry out any maintenance other than what is shown in this manual. For any issues that are not cov-
ered in this manual, please seek support from Advaning Customer Service. Email: [email protected]
• The product should be used only as described in this Advaning Owner’s manual.
SAFETY FIRST, PLEASE READ THE FOLLOWING POINTS TO REDUCE THE RISK OF PERSONAL INJURY.

3
PACKAGE CONTENTS AND PARTS
Before installation, make
certain that the package
contains all parts as listed
on this page.
Masonry Expansion Bolt,
Part#: ZDA-WEB-R2
NOT INCLUDED / SOLD
SEPARATELY
Fig 3
[Qty: 1] Tempered
Glass Panel
[Qty: 1] Awning
Bracket (Base)
[Qty: 1] Clear PVC Clip
[Qty: 1] Awning
Bracket (Top)
[Qty: 1] Bracket Cover
[Qty: 2] Rubber Strip
[Qty: 6] Lag Screws &
Washers
[Qty: 8] Bracket Bolts
[Qty: 2] Side Cover
Foam
[Qty: 2] Side Cover
[Qty: 6] Side Cover
Screws
www.advaning.com
A
C
D
E
F
G
H
B
A
E
F
C
G
B
D
J
I
J
K
K
H
I

4
ASSEMBLY DIAGRAM
Fig.4
Tempered Glass Panel
Awning Bracket (Base)
Clear PVC Clip
Awning Bracket (Top)
Bracket Cover
Rubber Strip
Lag Screws & Washers
Bracket Bolts
Side Cover Foam
Side Cover
Side Cover Screws
www.advaning.com
A
B
E
A
H
C
D
C
B
F
D
E
H
I
K
J
I
G
J
K
F
G

5
3
REQUIRED TOOLS
Fig.5
REQUIRED TOOLS
Marker/Pencil
Scissors
Level
13mm Socket Wrench
Silicone*
9/64” Drill Bit for Lag
Screw (wood installs).
Electric Drill
Phillips Head Screw-
driver
Ladder/s
Work Gloves
Safety Glasses/Gog-
gles
*A slow curing high qual-
ity outdoor silicone is rec-
ommended – Specic for
your exterior surfaces.
Minimum 3 people to
install.
SILICONE
www.advaning.com
NOTE: For solid masonry
installation a 3/8” drill bit
will be required.
Masonry Expansion Bolt,
Part# ZDA-WEB-R2
SOLD SEPARATELY
1
57
24
6
9
8
1
5
6
3
7
2
4
8
9
10
10
11
11

6
PRE-INSTALLATION GUIDE
Fig 6
Fig 7
Side view
Locate your door/window
structural header.
Minimum 2 inches of
clearance below roof/
eave/overhang.
7 inches of clear verti-
cal run length deped-
ing on awning size.
• 55 or 63 inches
Minimum Depth
Clearance depending
on awning size.
• 35 or 39 inches
Run length should be
free & clear of any ob-
structions along the en-
tirety of planned awning
length.
Advaning highly recom-
mends consulting with
a professional installer/
contractor who can best
assess your specic in-
stallation challenges to
avoid possible injury,
property damage and
ensure full product func-
tionality. CAUTION!
GA Series awning MUST be
mounted to main structural
supports, header, or solid
masonry 4-inch in thickness
or more.
Personal & specic structural physicalities may require
deviation from the recommended measurements.
PLANNING YOUR
AWNING
INSTALLATION
4”
HEADER BOARD
4”
SOLID MASONRY
www.advaning.com
Roof, eave or overhang
Roof, eave or overhang
35 or 39 inches
Minimum 2 inches
Ground, oor or deck
7 inches clear
space
B7 inches clear space
AMinimum 2 inches
A
B
C
C

7
Wall
Fig 11
ASSEMBLY AND INSTALLATION
ASSEMBLING AND
INSTALLING THE
DOOR AWNING
Insert the Rubber
Strips into the back
grooves of the Awning
Bracket (Base) and
guide them through
to the other end.
Trim off excess
Rubber Strips with
scissors.
Using a level position
the Awning Bracket
(Base) in the desired
install location.
Mark the location of
the mounting holes
using a marker/pencil
through the bracket
holes.
Remove the Awning
Bracket (Base) and
drill the pilot holes 4”
deep.
TIP: Drill the outer-
most pilot holes rst,
then use the Awning
Bracket (Base) as
guide to drill the re-
maining holes.
Fig 10
Fig 8
Fig 9
Fig 12
NOTE: Installation in-
struction Step#5~8 is for
wood installs only.
For solid masonry instal-
lation guides, please visit
www.advaning.com or
request from Advaning’s
service team.
DO NOT drill where electrical wires,
gas, or water pipes may exist.
www.advaning.com
Marker / Pencil
CAUTION!
1
2
3
4
5
2
1
3
5
4

8
Wall
Wall
Wall
Bracket (Base)
Bracket (Base)
Lag screw
Washer
SILICONE
Fill the mounting
holes with silicone.
Align the Awning
Bracket (Base) to pi-
lot holes and insert
the Lag Screws &
Washers
TIP: Ensure the awning is
level before proceeding
with Step#8.
Securely tighten the
Lag Screws with a
13mm socket wrench.
PreparetheTempered
Glass Panel placing
the Clear PVC Clip
over long edge.
TIP: The Tempered Glass
Panel will arrive with a
stretch wrap plastic –
To avoid scratching the
glass surface during in-
stallation, carefully cut
the plastic wrap to allow
the Clear PVC Clip to be
attached and remove the
remaining plastic wrap
once entire awning is in-
stalled.
ASSEMBLY AND INSTALLATION
Fig 16
Fig 13
Fig 14
Fig 15
www.advaning.com
6
7
8
9
6
7
8
9

9
ASSEMBLY AND INSTALLATION
CAUTION: Avoid dam-
age and personal injury.
Ensure there are at mini-
mum two persons assist-
ing with the handling of
the Tempered Glass Pan-
el while a third person se-
cures the Awning Bracket
(Top) assembly.
Place the Tempered
Glass Panel with Clear
PVC Clip on top of
the Awning Bracket
(Base) butting up to
the internal bevel.
See g.19
Align the Awning
Bracket (Top) with
Awning Bracket
(Base) bolt holes.
Insert the Bracket
Bolts securing the
Awning Bracket (Top)
and the Tempered
Glass Panel to Awning
Bracket (Base).
CAUTION: Caution – DO
NOT release support of
the Tempered Glass Pan-
el until all bolts are se-
curely fastened, Step#13.
Securely tighten the
Bracket Bolts with
13mm socket wrench.
NOTE: Ensure the Tem-
pered Glass Panel with
Clear PVC Clip is butting
up to the internal bevel.
Fig 17
Fig 18
Fig 19
www.advaning.com
10
11
12
13
11
10
12
13
CAUTION: 3 PERSON INSTALL

10
ASSEMBLY AND INSTALLATION
Place the Bracket
Cover over the
Awning Bracket (Top)
and clip it in place
by applying a gentle
force until secure.
The Awning Bracket
(Base) will include
a white plastic strip
base cover – Please
check and secure in
place if needed.
Prepare the Side
Covers by rst
peeling the Side
Cover Foam exposing
the adhesive backing,
aligning with Side
Covers and rmly
pressing together to
afx.
Align the Side Cover
to the Awning
Bracket assembly
with the Side Cover
Foam facing inward.
Secure the Side
Covers with the
Side Cover Screws
using a Phillips Head
screwdriver.
Fig 20
Fig 21
Fig 22
www.advaning.com
14
16
17
15
18
14
17
18
15
16

11
Apply the Silicone on
the top of the Awning
Bracket running
along the wall for
weatherproong.
NOTE: Allow 24hrs for
the silicone to fully set/
cure.
ASSEMBLY AND INSTALLATION
Fig 23
www.advaning.com
SILICONE
19
19

12
MAINTENANCE
To clean your GA Series awning, we recommend a 1 part (white vinegar) to 10
parts (water) cleaning solution mix. Use the cleaning solution in a spray bottle
or dip into it with a sponge. Scrub off any dirt or debris with a sponge and wipe
clean with lint free chamois cloth or squeegee. Prevent scratching the glass,
only use soft cloth or rubber when cleaning your awning. Never use acetone,
abrasives, detergents containing Hydrouoric (HF) or Phosphoric acid (H3P04)
or Bleach to clean your awning.
Perform inspections (one to two times a year) to ensure that all the screws/
bolts are properly tightened and that the silicone seals are in good condition.
Re-tighten any and all screws/bolts and re-apply silicone as needed to prevent
water leakage.
CLEANING
CARE AND
MAINTENANCE
www.advaning.com

13
LIMITED WARRANTY AND CONTACTS
LIMITED WARRANTY COVERS
Advaning warrants all Advaning GA Series original products, sold and installed within the United States of
America and Canada, to be free of defects in materials and workmanship. This warranty only applies to the
original owner or purchaser of the product and is only effective on a basis for twelve (12) months or one (1)
year from the date of purchase.
Any defects or issues presented to Advaning within the warranty period will be handled by Advaning Customer
Service within a reasonable time.
The entire awning aluminum bracket, including the tempered glass panel and parts (page 3 of the Owner’s
Manual), is covered under the limited warranty.
Powder coated nishes and painted nishes are excluded and are NOT covered under this limited warranty.
During the warranty period, owners in Canada, Hawaii, Alaska, and Puerto Rico are covered for parts and
replacements at no charge. However, the owner would assume all shipping and handling and applicable duties
and taxes. Advaning’s warranty does not cover any return shipping or prepaid return labels.
Should the original owner/purchaser submit a claim within the warranty period from the date of the purchase
and after being deemed defective by Advaning, will the warranty claim be resolved by either of the following:
A. Defective components are replaced (shipping charges may apply).
and/or
B. Detailed correctional/resolving instructions will be provided.
EXCLUSIONS AND LIMITATIONS OF WARRANTY
ANY MODIFICATIONS OR ALTERATIONS TO THE PRODUCT WILL VOID THIS WARRANTY.
ADVANING, INCLUDING ITS SUBSIDIARIES AND AFFILIATES, SHALL NOT BE RESPONSIBLE IN ANY
MANNER WHATSOEVER FOR INJURY, DEATH OR DAMAGE TO PROPERTY AS A RESULT OF INTENTIONAL
OR ACCIDENTAL MISUSED FOR PURPOSES FOR WHICH THE PRODUCT WAS NOT DESIGNED FOR.
The warranty will be in effect once the awning is fully paid for.
Advaning is not responsible for damage due to faulty modications, installation, or re-installation. Advaning
assumes no liability for damage to the structure to which the awning is attached, or to the property located
underneath the awning. This limited warranty does not cover damage from ice, snow, hail, high winds,
vandalism, neglect, improper use, or any natural disaster. This limited warranty does not cover degradation
due to salt corrosion, oxidation, and chipping or peeling of the paint.
What is Not Covered by the Advaning Limited Warranty
This warranty is non-transferable and does not cover product purchases from the initial buyer to a third party.
This warranty does not cover incidental damages, such as loss of time, loss of use, or installation costs of
defective, repaired, or replaced products. This warranty does not cover products that have been damaged or
rendered defective as a result of:
www.advaning.com

14
LIMITED WARRANTY AND CONTACTS
(a) Neglect, abuse or misuse.
(b) Modication of the original product.
(c) Improper use or installation using products not manufactured by Advaning.
(d) Service provided by anybody other than Advaning.
(e) Abnormal mechanical or environmental conditions.
(f) Unusual physical or electrical stress -including failure or uctuation of electrical power, lighting, static
electricity, re, tornadoes, or other natural disasters.
WARRANTY CLAIMS:
If you experience a problem with your Advaning product, please contact Advaning Customer Service
representatives by email at [email protected], by phone at 714-622-2600 or by submitting a Warranty
Claim via our website, advaning.com/warranty-support
Advaning Customer Service is available Monday through Friday from 8:30 a.m. to 4:00 p.m. PST
• Prior to contacting Advaning for warranty claims, please have your model name/number, *original proof of
purchase, photos and/or videos along with a description of the issue experiencing ready for our Customer
Service team to assess.
• Submitting a claim will not extend or alter the warranty coverage period.
• Work performed by a third party or not authorized by an Advaning agent voids the warranty.
*Original Proof of Purchase: A valid sales/purchase receipt is required with authorized reseller/retailer name,
the purchase date, and the model number of the item purchased.
SHIPPING DAMAGE/MISSING PARTS CLAIMS
On the occasion of a damage claim caused by the shipper/shipping company, the owner must contact their
point of sale and the delivery carrier within 3-days of signing for the delivery in order to make a claim.
Likewise, there is a 7-day window from the time of delivery to report missing parts to Advaning.
Failure to report shipping damage and missing parts in a timely manner and in accordance with the shipper/
carrier guidelines may result in the owner incurring all costs.
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED. NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ARE GIVEN, ANY AND ALL LIABILITY FOR BREACH OF ANY IMPLIED WARRANTY OR WARRANTY CREATED
BY LAW IS DISCLAIMED. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. UNDER NO CIRCUMSTANCES SHALL ADVANING, INCLUDING
ITS SUBSIDIARIES AND AFFILIATES BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WITH
RESPECT TO ECONOMIC LOSS, INJURY, DEATH OR PROPERTY DAMAGE, WHETHER AS A RESULT OF
BREACH OF THIS WARRANTY, NEGLIGENCE OR OTHERWISE. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you
in whole or in part. This warranty gives you specic legal rights. You may also have other rights that vary from
state to state.
www.advaning.com

CONTACT
INFORMATION
Product Questions?
Please contact Advaning via email at [email protected],
by phone at 714-622-2600, or by chat on our website;
www.advaning.com
Advaning Customer Service is available Monday through
Friday from 8:30 a.m. to 4:00 p.m. PST
www.advaning.com
GA.OM.V02.062022
