Advaning PA SERIES User manual

PA SERIES : Polycarbonate Awning
For your safety and the safety of others, please read all of the instructions and
warnings in this manual carefully before proceeding with assembly and usage.
Owner’s Manual

1
Safety instructions and warnings.........................................1~2
Product model numbers ................................................. 2
Package contents and parts .............................................. 3
Tool requirements ...................................................... 4
Awning terminology..................................................... 5
Pre-Installation guide .................................................... 6
Awning assembly .....................................................7~8
Awning installation...................................................9~11
Maintenance and care .................................................. 12
Warranty and service ................................................13~14
TABLE OF CONTENTS
www.advaning.com
SAFETY INSTRUCTIONS AND WARNINGS
A
D
B
E
C
F
Fig.1
Fig.2
For your safety, we
strongly recommend the
following during assem-
bly and installation:
A: Minimum 2 people
B: Work gloves
C: Safety goggles
DO NOT ATTEMPT to
assemble or install if:
D: Rain is in the forecast
E: Wind is in the forecast
F: You are tired or under
the inuence of drugs,
medication or alcohol

2
SAFETY INSTRUCTIONS AND WARNINGS
www.advaning.com
CAUTION! AWNING MUST BE MOUNTED TO MAIN STRUCTURAL SUPPORTS OR SOLID MASONRY. FAILURE TO
DO SO MAY RESULT IN PERSONAL INJURY, PRODUCT OR PROPERTY DAMAGE.
SAFETY FIRST, PLEASE READ THE FOLLOWING POINTS TO REDUCE THE RISK OF PERSONAL INJURY
Owners are solely responsible for the proper handling, storage, assembly, installation, and use of this product.
Advaning is not responsible for any damages or injury to you, any other parties, or property resulting from
improper handling, storage, assembly, installation, or misuse of the product.
• Consult with your local authorities if any permits are required prior to the installation of this product. This
product is intended for residential use only. Do not use this product other than for its intended purpose.
ASSEMBLY
• Please keep children away from the assembly area and from handling assembly components.
• Ensure that all screws are properly tightened when assembling the awning.
• Use caution with sharp metal edges by wearing protective gloves and safety goggles.
• Follow all 3rd party manufacturer’s safety instructions when using mechanical power tools and ladders
during assembly and installation.
INSTALLATION
• Pay close attention throughout the installation process to ensure that the Advaning awning is installed
properly and according to the safety guidelines outlined herein.
• Do not attempt installation while under the inuence of alcohol or drug substances.
• Do not proceed with an installation if you feel that you cannot properly and safely complete it; please seek
professional help.
• Two or more people are recommended for installation. Installation will require lifting the assembled awning.
Ascertain that assistance is available to lift and secure in position.
• Make certain that the installation substrate is adequate (the PA Series awning MUST be mounted to the main
structural supports) studs, header board, or solid masonry 3-inch in thickness or greater.
• Do not drill into walls where electric wiring, gas pipes, or water pipes may exist.
USAGE
• Only use Advaning-recommended accessories and original replacement parts.
• Only perform installation, maintenance, and cleaning in dry and optimal weather conditions.
• Never put a heat source or an open ame under or near the awning.
• Do not place, hang, or stand objects or people on the awning itself. Doing so can damage the awning or
cause severe personal injury and, in extreme cases, death.
• Do not carry out any maintenance other than what is shown in this manual. For any issues that are not
covered in this manual, please seek support from Advaning Customer Service. Email: [email protected]
• The product should be used only as described within this owner’s manual.
Fig.3
TWO BRACKET
MODELS
THREE BRACKET
MODELS
DA4735-PSS1A
DA4735-PSS2A
DA4735-PSS3A
DA5935-PSS1A
DA5935-PSS2A
DA5935-PSS3A
DA7935-PSS1A
DA9435-PSS1A

3www.advaning.com
PACKAGE CONTENTS AND PARTS
Before attempting your assembly, please ensure that the package contains all parts and qty’s as listed on this
page.
Masonry Expansion Bolt, Part#: ZDA-WEB-R2 NOT INCLUDED / SOLD SEPARATELY
Awning Model Size 47x35 inch
59x35 inch
79x35 inch
94x35 inch
Part Quantity
ASolid Polycarbonate
Sheet 1
BAluminum Front/
Back Bar 2
CRubber Strip Gasket
Front/Back 2
D Aluminum Bracket 2 3
E
Polycarbonate to
Bracket Bolt Set
(Bolt, Gaskets, & Nut)
6 9
F
Lag Screw Set for
Wood Installs
(Lag & Washer)
4 6
GMounting Hardware
Cap 4 6
HWall Rubber Strip
Gasket 1 N/A
Fig.4

4
3
TOOL REQUIREMENTS
Fig.5
SUGGESTED TOOLS
Marker / Pencil
Scissors
Level
1/2" Wrench or
Socket Wrench
Rubber Mallet
Small wood block
Slow Curing Outdoor
Silicone
15/64" or 1/4" Drill
Bit/s for Wood
Installs
Drill
Ladder/s
OPTIONAL: Weather
Stripping Adhesive
Minimum 2 people to
install.
SILICONE
RECOMMENDATION
www.advaning.com
W.S.A.
1
5
8
6
24
7
10 11
9
1
5
6
3
7
2
4
8
9
10
11

5
AWNING TERMINOLOGY AND LOCATION
Fig.6
Awning Polycarbonate Sheet
Awning Bracket
Bracket Bolt Set
Front/Back Rubber Strip
Awning Front Bar
Awning Back Bar
Mounting Hardware (Lag or Expansion)
Mounting Hardware Cap
Silicone Seal or Wall Rubber Strip
Gasket (select models only)
www.advaning.com
1
1
7
5
3
3
3
3
5
6
6
7
9
8
2
2
4
4
4
8
9

6
Locate your door/window
structural header.
Minimum 2 inches of
clearance below roof/
eave/overhang.
10 inches of clear ver-
tical run length.
Minimum Depth of 35
inches.
Run length should be
free & clear of any ob-
structions along the en-
tirety of planned awning
length.
Advaning highly recom-
mends consulting with
a professional installer/
contractor who can best
assess your specic in-
stallation challenges to
avoid possible injury,
property damage and
ensure full product func-
tionality.
PLANNING YOUR
AWNING
INSTALLATION
A
B
C
PRE-INSTALLATION GUIDE
Fig 7
Fig 8
Side view
www.advaning.com
Roof, eave or overhang
Roof, eave or overhang
36 inches
Minimum 2 inch
Ground, oor or deck
Minimum 10 inch
clear space
BMinimum 10 inch clear space
AMinimum 2 inch
C

7
WALL
THIS SIDE FACE UP
Fig 9
Fig 10
Fig 11
AWNING ASSEMBLY
PREPARING THE
POLYCARBONATE
SHEET
Carefully peel the
protective lm ap-
proximately 2 inches
from both the top
and bottom on front
and back edges of
the sheet.
Dry t the gaskets
to polycarbonate or
(OPTIONAL) apply a
small bead of Weath-
er Stripping Adhesive
(W.S.A) to the gasket
inner side before con-
necting. Ensure to
follow W.S.A. instruc-
tions & have a rag to
wipe off any excess.
Ensure the Rubber
Strip Gaskets are
smoothly connected
to the sheet and with
scissors trim off the
excess Rubber Strip
Gasket.
Join the Awning
Front/Back Bars to
sheet by pressing
onto the Rubber Strip
Gasket edges. Ensure
the Awning Front/
Back Bar are correctly
oriented as illustrat-
ed in g. 11, labeled
THIS SIDE UP.
www.advaning.com
NOTE: Locate the indicat-
ing label on the polycar-
bonate protective lm.
This label will indicate the
proper orientation.
W.S.A.
THIS SIDE UP
1
2
3
4
4
4
5
1
2
2
3

8
Using a small wood-
en block and rubber
mallet, tap along the
entire length of the
Awning
Carefully peel away
the protective lm
from both the top
and bottom.
ATTACHING THE
BRACKETS
From the bottom of
the sheet, align the
bracket to pre-drilled
connection holes.
Secure the sheet to
brackets with the
Bracket Bolt Set
(From Top: Bolt, Gas-
ket, Sheet, Bracket,
Gasket, Nut).
Sizes: 47x35 & 59x35Sizes: 47x35 & 59x35
Only, Dry t the Wall Only, Dry t the Wall
Rubber Strip to BackRubber Strip to Back
Bar or (OPTIONAL)Bar or (OPTIONAL)
apply a small beadapply a small bead
of Weather Strippingof Weather Stripping
Adhesive (W.S.A) toAdhesive (W.S.A) to
the gasket inner sidethe gasket inner side
before connecting.before connecting.
Ensure to followEnsure to follow
W.S.A. instructions &W.S.A. instructions &
have a rag to wipe offhave a rag to wipe off
any excess.any excess.
AWNING ASSEMBLY
Fig 12
Fig 13
Fig 14
www.advaning.com
W.S.A.
5
6
7
8
87
6

Wall
3 inch
9
AWNING INSTALLATION
MARKING & PRE-
DRILLING
With a helper, hold
the assembled aw-
ning in place over the
desired installation
area. Ensure to use a
level for proper nish.
With a marker/pen-
cil mark the bracket
mounting hole posi-
tions.
Using a power drill
and drill bit, drill
through your wall sur-
face ensuring your pi-
lot holes go through
main structural sup-
ports.
CAUTION: DO NOT drill
where electrical, gas, or
water supply lines may
exist.
Fig 15
Fig 16
Fig 17
www.advaning.com
Marker / Pencil
Marker / Pencil
1
1
2
2
3
3

10
Wall
Wall
SILICONE
SILICONE
AWNING INSTALLATION
Apply slow curing
outdoor silicone di-
rectly into the pilot
holes.
Align the awning
brackets to pilot
holes and insert the
Lag Screw and Wash-
er (illustrated).
NOTE: For solid ma-
sonry instructions,
please visit or request
detailed expansion
bolt instructions via
www.advaning.com
Ensure to check the
product is level be-
fore securely tight-
ening the mounting
hardware.
Securely tighten
the lag screw with
a wrench/socket
wrench.
Apply slow curing
outdoor silicone
around lag screw.
Fig 18
Fig 19
Fig 20 Fig 21
MOUNTING THE
AWNING
www.advaning.com
4
6
4
5
5
7
67

Wall
11
Cover each lag
screw with a Mount-
ing Hardware Cap
by gently tapping in
place with a rubber
mallet.
Apply a bead of slow
curing outdoor sili-
cone to the wall and
Back Bar connection.
9
INSTALLATION
Fig 23
Fig 22
www.advaning.com
FINISHING
& WEATHER
PROOFING
8
9
8
SILICONE

12
CARE AND MAINTENANCE
Cleaning the polycarbonate on your awning can be achieved with a simple
solution of mild soap and water (1 part soap to 2 parts water) and a standard
garden hose with a pressure nozzle to remove any accumulated dust, dirt, or
debris. A specialty polycarbonate cleaner can be used, however, we recommend
testing a small section before proceeding to entire polycarbonate. Never use
acetone, abrasive cleaners, or other detergents to clean the awning.
Advaning recommends an annual inspection of the screw connections and seal
condition. Tighten and replace parts or reapply silicone as needed. All parts can
be easily obtained from Advaning should there ever be a need for replacement.
Although the awning is made to handle signicant loads, we recommend clearing
accumulated and packed snow whenever possible. A long handled squeegee
can be used to assist with removing excess snow. Please visit www.advaning.com
for full independent weight capacity test results.
CLEANING
CARE AND
MAINTENANCE
SNOW LOADS
www.advaning.com

13
WARRANTY AND CUSTOMER SERVICE
www.advaning.com
ADVANING 1-YEAR LIMITED MANUFACTURER’S WARRANTY FOR PA SERIES AWNINGS
Advaning warrants all Advaning PA Series original products, sold and installed within the United States of
America and Canada, to be free of defects in materials and workmanship. This warranty only applies to the
original owner or purchaser of the product and is only effective on a basis for twelve (12) months or one (1)
year from the date of purchase.
Any defects or issues presented to Advaning within the warranty period will be handled by Advaning Customer
Service within a reasonable time.
The entire awning framework, including polycarbonate sheet, brackets and parts (page 3 of the Owner’s
Manual), is covered under the limited warranty.
Powder coated nishes and painted nishes are excluded and are NOT covered under this limited warranty.
During the warranty period, owners in Canada, Hawaii, Alaska, and Puerto Rico are covered for parts and
replacements at no charge. However, the owner would assume all shipping and handling and applicable duties
and taxes. Advaning’s warranty does not cover any return shipping or prepaid return labels.
Should the original owner/purchaser submit a claim within the warranty period from the date of the purchase
and after being deemed defective by Advaning, will the warranty claim be resolved by either of the following:
A. Defective components are replaced (shipping charges may apply).
and/or
B. Detailed correctional/resolving instructions will be provided.
EXCLUSIONS AND LIMITATIONS OF WARRANTY
ANY MODIFICATIONS OR ALTERATIONS TO THE PRODUCT WILL VOID THIS WARRANTY.
ADVANING, INCLUDING ITS SUBSIDIARIES AND AFFILIATES, SHALL NOT BE RESPONSIBLE IN ANY
MANNER WHATSOEVER FOR INJURY, DEATH OR DAMAGE TO PROPERTY AS A RESULT OF INTENTIONAL
OR ACCIDENTAL MISUSED FOR PURPOSES FOR WHICH THE PRODUCT WAS NOT DESIGNED FOR.
The warranty will be in effect once the awning is fully paid for.
Advaning is not responsible for damage due to faulty modications, installation, or re-installation. Advaning
assumes no liability for damage to the structure to which the awning is attached, or to the property located
underneath the awning. This limited warranty does not cover damage from ice, snow, hail, high winds,
vandalism, neglect, improper use, or any natural disaster. This limited warranty does not cover degradation
due to salt corrosion, oxidation, and chipping or peeling of the paint.
What is Not Covered by the Advaning Limited Warranty
This warranty is non-transferable and does not cover product purchases from the initial buyer to a third party.
This warranty does not cover incidental damages, such as loss of time, loss of use, or installation costs of
defective, repaired, or replaced products. This warranty does not cover products that have been damaged or
rendered defective as a result of:

14
WARRANTY AND CUSTOMER SERVICE
www.advaning.com
(a) Neglect, abuse or misuse.
(b) Modication of the original product.
(c) Improper use or installation using products not manufactured by Advaning.
(d) Service provided by anybody other than Advaning.
(e) Abnormal mechanical or environmental conditions.
(f) Unusual physical or electrical stress -including failure or uctuation of electrical power, lighting, static
electricity, re, tornadoes, or other natural disasters.
WARRANTY CLAIMS:
If you experience a problem with your Advaning product, please contact Advaning Customer Service
representatives by email at [email protected], by phone at 714-622-2600 or by submitting a Warranty
Claim via our website, advaning.com/warranty-support
Advaning Customer Service is available Monday through Friday from 8:30 a.m. to 4:00 p.m. PST
• Prior to contacting Advaning for warranty claims, please have your model name/number, *original proof of
purchase, photos and/or videos along with a description of the issue experiencing ready for our Customer
Service team to assess.
• Submitting a claim will not extend or alter the warranty coverage period.
• Work performed by a third party or not authorized by an Advaning agent voids the warranty.
*Original Proof of Purchase: A valid sales/purchase receipt is required with authorized reseller/retailer name,
the purchase date, and the model number of the item purchased.
SHIPPING DAMAGE/MISSING PARTS CLAIMS
On the occasion of a damage claim caused by the shipper/shipping company, the owner must contact their
point of sale and the delivery carrier within 3-days of signing for the delivery in order to make a claim.
Likewise, there is a 7-day window from the time of delivery to report missing parts to Advaning.
Failure to report shipping damage and missing parts in a timely manner and in accordance with the shipper/
carrier guidelines may result in the owner incurring all costs.
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED. NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ARE GIVEN, ANY AND ALL LIABILITY FOR BREACH OF ANY IMPLIED WARRANTY OR WARRANTY CREATED
BY LAW IS DISCLAIMED. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. UNDER NO CIRCUMSTANCES SHALL ADVANING, INCLUDING
ITS SUBSIDIARIES AND AFFILIATES BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WITH
RESPECT TO ECONOMIC LOSS, INJURY, DEATH OR PROPERTY DAMAGE, WHETHER AS A RESULT OF
BREACH OF THIS WARRANTY, NEGLIGENCE OR OTHERWISE. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you
in whole or in part. This warranty gives you specic legal rights. You may also have other rights that vary from
state to state.

CONTACT
INFORMATION
Product Questions?
Please contact Advaning via email at [email protected],
by phone at 714-622-2600, or by chat on our website;
www.advaning.com
Advaning Customer Service is available Monday through
Friday from 8:30 a.m. to 4:00 p.m. PST
www.advaning.com
PA.OM.V04.112022
