Advantech AMAX-175 Series User manual

User Manual
AMAX-175x Series
Open Frame Type 32-ch AMONet
RS-485 Isolated Digital I/O Slave
Modules

AMAX-175x Series User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2013
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
AMONet, AMAX-1752, AMAX-1754 and AMAX-1756 are trademarks of Advantech
Inc.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2003A17501 Edition 2
Printed in Taiwan November 2013

iii AMAX-175x Series User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
The package should also include the following items:
AMAX-175x Series Slave Module
Quick Start User Manual

AMAX-175x Series User Manual iv

v AMAX-175x Series User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Features .................................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 General ......................................................................................... 2
1.2.2 Isolated Digital Input ..................................................................... 3
1.2.3 Isolated Digital Output................................................................... 3
1.2.4 Environment.................................................................................. 3
1.3 Distributed Motion Product Selection Guide ............................................. 4
Chapter 2 Hardware Functionality.......................5
Figure 2.1 AMAX-1752 Top View ................................................ 6
Figure 2.2 AMAX-1754 Top View ................................................ 7
Figure 2.3 AMAX-1756 Top View ................................................ 8
Figure 2.4 AMAX-175x Middle View ............................................ 8
2.1 Module Power Connector(CN1) ................................................................ 9
2.2 External Power Input Connector(CN2)...................................................... 9
2.3 External Power Output Connector(CN3)................................................... 9
2.4 Board ID Switch (SW1) ........................................................................... 10
2.5 Configuration Setting (SW2) ................................................................... 10
2.5.1 Baud-Rate Setting....................................................................... 10
2.5.2 TUD............................................................................................. 10
2.5.3 TMD ............................................................................................ 11
2.6 Terminal Resistor .................................................................................... 11
2.7 LED Definition ......................................................................................... 11
2.7.1 AMAX-1752................................................................................. 12
2.7.2 AMAX-1754................................................................................. 12
2.7.3 AMAX-1756................................................................................. 12
2.8 Pin Definitions ......................................................................................... 13
2.8.1 AMAX-1752 (32 DI)..................................................................... 13
2.8.2 AMAX-1754 (32 DO)................................................................... 13
2.8.3 AMAX-1756 (16 DI 16DO) .......................................................... 14
2.9 Signal Connection ................................................................................... 15
2.9.1 Isolated Digital Output................................................................. 15
2.9.2 Isolated Digital Input ................................................................... 15

AMAX-175x Series User Manual vi

Chapter 1
1Introduction
This chapter gives an overview of
the product features, and specifi-
cations for AMAX-175x Series.
Sections include:
Features
Specifications
Distributed Motion Product
Selection Guide

AMAX-175x Series User Manual 2
Products in the AMAX-175x Series are used to increase the number of digital input/
output channels for an AMONet RS-485 distributed motion control network. These
extension slave modules connect serially by a simple and affordable Cat.5 LAN
cable, reducing the wiring between driver and controller. This is very suitable for
highly integrated machine automation applications.
1.1 Features
Communication baud rate, 2.5Mbps, 5Mbps, 10Mbps and 20Mbps are sup-
ported and switchable
Onboard screw terminal for direct wiring
2,500 VRMS Isolation voltage
Suitable for DIN-rail mounting
Board ID is switchable
Easily visible LED indicators on board to do diagnosis
1.2 Specifications
1.2.1 General
BUS TYPE AMONet RS-485
Certifications CE, FCC Class A
Connectors (1) RJ-45 x 2 are for communication port
(2) I/O points use screw terminal type connector
LED Indicators Power, Run, Status, Isolated Digital I/O
Power Consumption 600mW typical, 2 W Max.
Power Supply for
Module VS: 24 Vdc ±10%
Power Supply for
Digital Input/Output VEX: 10-30 Vdc

3 AMAX-175x Series User Manual
Chapter 1 Introduction
1.2.2 Isolated Digital Input
*NOTE: △V=| IDICOMx - IDIx |. For pin assignment definition, please refer to 2.8.1 to
2.8.3 for details. For signal connection, please refer to 2.9.
1.2.3 Isolated Digital Output
1.2.4 Environment
Channels AMAX-1752: 32 DI
AMAX-1756: 16 DI
Input type Dry contact
Input voltage △V *= 0~3V(Low Level) / 10~30V(High Level) (30VDC Max.)
Input resistance 3.2K
Input current 2mA Min.
Input delay 100us Max. (Isolation delay)
Input Isolation 2500Vdc
Channels AMAX-1754: 32 DO
AMAX-1756: 16 DO
Output type Sink(NPN) (open collector Darlington)
Output control voltage 35Vdc Max.
Output sink current 400mA Max. (for each channel)
Output delay 250us Max. (photo coupler delay)
Output Isolation 2500Vdc
Operating Humidity 5 ~ 95% RH, non-condensing (refer to IEC 60068-2-3)
Operating Temperature 0 ~ 65° C (refer to IEC 60068-2-1,2) (32 ~ 149° F)
Storage Temperature -25 ~ 85° C (-13 ~ 185° F))

AMAX-175x Series User Manual 4
1.3 Distributed Motion Product Selection Guide

Chapter 2
2Hardware
Functionality
This chapter shows the hardware
functionality of AMAX-175x
Series.
Sections include:
Module Dimensions
Power Connector
BoardID Switch
Configuration Setting
LED Definition
Pin Definition
Signal Connection

AMAX-175x Series User Manual 6
AMAX-175x series is open frame type AMONET I/O modules which has on-board
connectors for direct wiring and LED indicators to show the status. Here is the prod-
uct dimension information:
Figure 2.1 AMAX-1752 Top View

7 AMAX-175x Series User Manual
Chapter 2 Hardware Functionality
Figure 2.2 AMAX-1754 Top View

AMAX-175x Series User Manual 8
Figure 2.3 AMAX-1756 Top View
Figure 2.4 AMAX-175x Middle View
Note! The height does not include the male connector. The height of the male
connector is 9mm.

9 AMAX-175x Series User Manual
Chapter 2 Hardware Functionality
2.1 Module Power Connector(CN1)
2.2 External Power Input Connector(CN2)
2.3 External Power Output Connector(CN3)
Pin Descrption
1+VS input 24 VDC ±10%
2-VS
3 Field Ground
Pin Descrption
1+VEX (10-30 VDC)
2 -VEX
3 Field Ground
Pin Descrption
1~3 +VEX (10-30 VDC)
4~6 - VEX

AMAX-175x Series User Manual 10
2.4 Board ID Switch (SW1)
Note: Node Number=32xDN5+16xDN4+8xDN3+4xDN2+2xDN1+DN0.
Default Setting: All the switches are in OFF status.
2.5 Configuration Setting (SW2)
2.5.1 Baud-Rate Setting
2.5.2 TUD
This terminal is used to set output conditions when the watchdog timer times out.
Pin Label ON OFF
1DN5 1 0
2DN4 1 0
3DN3 1 0
4DN2 1 0
5DN1 1 0
6DN0 1 0
Switch Label Description
1 SPD1 Baud-Rate Setting
2 SPD0
3 TUD Time-Out Status Latch
4 TMD Specify watchdog timer time
5 BRK *For internal use only, please keep in OFF
6N/A
SPD1 SPD0
OFF OFF 20 MHz
OFF ON 10 MHz
ON OFF 5 MHz
ON ON 2.5 MHz
OFF The output keeps its current status.
ON The output is Reset.

11 AMAX-175x Series User Manual
Chapter 2 Hardware Functionality
2.5.3 TMD
When the interval between data packets sent from a master card (ex. PCI-1202U) is
longer than the specified interval, the watchdog timer times out.
2.6 Terminal Resistor
2.7 LED Definition
20 Mbps 10 Mbps 5 Mbps 2.5 Mbps
OFF 20 ms 40 ms 80 ms 160 ms
ON 5 ms 10 ms 20 ms 40 ms
PIN
1001/4W Resistor 3
6
Note! Terminal Resistor is used for the last module only.
LED Descrption
PWR Power indicator
RUN Module in communication
STS Communication status

AMAX-175x Series User Manual 12
2.7.1 AMAX-1752
2.7.2 AMAX-1754
2.7.3 AMAX-1756
LED Description
P0 (0~7) CN4 IDI 0~7
P1 (0~7) CN5 IDI 0~7
P2 (0~7) CN6 IDI 0~7
P3 (0~7) CN7 IDI 0~7
LED Description
P0 (0~7) CN4 IDO 0~7
P1 (0~7) CN5 IDO 0~7
P2 (0~7) CN6 IDO 0~7
P3 (0~7) CN7 IDO 0~7
LED Description
P0 (0~7) CN4 IDI 0~7
P1 (0~7) CN5 IDI 0~7
P2 (0~7) CN6 IDO 0~7
P3 (0~7) CN7 IDO 0~7

13 AMAX-175x Series User Manual
Chapter 2 Hardware Functionality
2.8 Pin Definitions
2.8.1 AMAX-1752 (32 DI)
2.8.2 AMAX-1754 (32 DO)
CN4 (P0) CN5 (P1) CN6 (P2) CN7 (P3)
Pin1 COM 0 Pin1 COM 1 Pin1 COM 2 Pin1 COM 3
Pin2 IDI 0 Pin2 IDI 0 Pin2 IDI 0 Pin2 IDI 0
Pin3 IDI 1 Pin3 IDI 1 Pin3 IDI 1 Pin3 IDI 1
Pin4 -VEX Pin4 -VEX Pin4 -VEX Pin4 -VEX
Pin5 IDI 2 Pin5 IDI 2 Pin5 IDI 2 Pin5 IDI 2
Pin6 IDI 3 Pin6 IDI 3 Pin6 IDI 3 Pin6 IDI 3
Pin7 COM 0 Pin7 COM 1 Pin7 COM 2 Pin7 COM 3
Pin8 IDI 4 Pin8 IDI 4 Pin8 IDI 4 Pin8 IDI 4
Pin9 IDI 5 Pin9 IDI 5 Pin9 IDI 5 Pin9 IDI 5
Pin10 -VEX Pin10 -VEX Pin10 -VEX Pin10 -VEX
Pin11 IDI 6 Pin11 IDI 6 Pin11 IDI 6 Pin11 IDI 6
Pin12 IDI 7 Pin12 IDI 7 Pin12 IDI 7 Pin12 IDI 7
IDI 0-7 IDI 8-15 IDI 16-23 IDI 24-31
CN4 (P0) CN5 (P1) CN6 (P2) CN7 (P3)
Pin1 +VEX Pin1 +VEX Pin1 +VEX Pin1 +VEX
Pin2 IDO 0 Pin2 IDO 0 Pin2 IDO 0 Pin2 IDO 0
Pin3 IDO 1 Pin3 IDO 1 Pin3 IDO 1 Pin3 IDO 1
Pin4 -VEX Pin4 -VEX Pin4 -VEX Pin4 -VEX
Pin5 IDO 2 Pin5 IDO 2 Pin5 IDO 2 Pin5 IDO 2
Pin6 IDO 3 Pin6 IDO 3 Pin6 IDO 3 Pin6 IDO 3
Pin7 +VEX Pin7 +VEX Pin7 +VEX Pin7 +VEX
Pin8 IDO 4 Pin8 IDO 4 Pin8 IDO 4 Pin8 IDO 4
Pin9 IDO 5 Pin9 IDO 5 Pin9 IDO 5 Pin9 IDO 5
Pin10 -VEX Pin10 -VEX Pin10 -VEX Pin10 -VEX
Pin11 IDO 6 Pin11 IDO 6 Pin11 IDO 6 Pin11 IDO 6
Pin12 IDO 7 Pin12 IDO 7 Pin12 IDO 7 Pin12 IDO 7
IDO 0-7 IDO 8-15 IDO 16-23 IDO 24-31

AMAX-175x Series User Manual 14
2.8.3 AMAX-1756 (16 DI 16DO)
CN4 (P0) CN5 (P1) CN6 (P2) CN7 (P3)
Pin1 COM 0 Pin1 COM 1 Pin1 +VEX Pin1 +VEX
Pin2 IDO 0 Pin2 IDO 0 Pin2 IDO 0 Pin2 IDO 0
Pin3 IDO 1 Pin3 IDO 1 Pin3 IDO 1 Pin3 IDO 1
Pin4 -VEX Pin4 -VEX Pin4 -VEX Pin4 -VEX
Pin5 IDI 2 Pin5 IDI 2 Pin5 IDO 2 Pin5 IDO 2
Pin6 IDI 3 Pin6 IDI 3 Pin6 IDO 3 Pin6 IDO 3
Pin7 COM 0 Pin7 COM 1 Pin7 +VEX Pin7 +VEX
Pin8 IDI 4 Pin8 IDI 4 Pin8 IDO 4 Pin8 IDO 4
Pin9 IDI 5 Pin9 IDI 5 Pin9 IDO 5 Pin9 IDO 5
Pin10 -VEX Pin10 -VEX Pin10 -VEX Pin10 -VEX
Pin11 IDI 6 Pin11 IDI 6 Pin11 IDO 6 Pin11 IDO 6
Pin12 IDI 7 Pin12 IDI 7 Pin12 IDO 7 Pin12 IDO 7
IDI 0-7 IDI 8-15 IDO 16-23 IDO 24-31
