Advantech Touch Panel Computers User manual

Proprietary Technology
PC-based Technology
Numeric Display
Open HMI
Flexible & Rich Functionality
Ethernet & Wireless Communication
Fanless System Design
Graphic User Interface
Text Mode Display
Touchscreen
Operator Interface
Open Platform with X86, RISC CPU
Embedded Windows OS
Rugged Robust Design
Open HMI Solutions
The world market for operator terminals was estimated to have been
worth just over $1.5 billion in 2005. The total market is forecast to grow
at a compound annual growth rate (CAGR) of 7.4% to $2.3 billion in
2011. Open operator terminals are projected to have the fastest growing
revenues and unit shipments over the forecast period 2006 to 2011, with
CAGR’s of 10.5% and 12.7% respectively. The worldwide touchscreen
operator terminal market represented nearly 70% of total worldwide
revenues in 2005, with this percentage set to increase slightly over the
forecast period.
Open HMI operates with a scalable (and open) operating system
(providing standard file formats, interfaces and communications) and
can provide some PC-based functionality, such as increased information
processing. These are diskless and fanless products that offer advanced
functionality over traditional HMI products with improved data handling
and standard interfaces and communications.
Led by the flourishing PC-based technology market, open HMI devices
not only provide interactive, vivid displays for operators & supervisors, but
also Ethernet networking, high performance computing, and open expan-
sion capabilities. Open HMI devices are replacing traditional operator
terminals by offering complete, intelligent HMI/SCADA platforms.
Breaking Through with
12

Open HMI Solutions
Touch Panel Computers (TPC)
Compact & Rugged HMI Platforms for Seamless Interaction between Humans and Machines
The ultra-slim, light, fanless and vibration-resistant design of Advantech’s TPC series provides an ideal HMI platform for
most automation applications. TPC products are available in display sizes of 3.5”, 5.7”, 6.4”, 8”, 10.4”, 12.1”, 15” and 17”.
TPC’s feature processors that are low in power consumption, and they also have a unique fanless design. With their stable
system architecture, TPC is an ideal solution for any industrial environment. In addition, the product housings are made from a
Aluminum-Magnesium Alloy which results in a lightweight unit, with corrosion resistance and excellent heat dissipation.
Industrial Monitors (FPM)
Full Range of Industrial-grade Units with Multi-function Capabilities and Brilliant Displays
Advantech’s industrial monitors are designed specifically for harsh environments. These monitors feature industrial-grade flat
panel LCDs with brightness that is often more than twice that of commercial monitors, making them much easier to see. FPM
products are designed for factory floor environments and can withstand the higher temperatures, vibration, and the dirt and dust
that can be commonplace. High NEMA and IP ratings for the bezel design enable these products to be installed in wet and dusty
areas. A full-range selection is provided in sizes ranging from 6”, 12”,15”, 17” to 19”.
Industrial Panel PC’s (IPPC)
Powerful Computing and Robust Platforms with High Performance for Factory Floors
Advantech’s IPPC series has proven their reliability through years of operation in all parts of the world. They can be built to
achieve a performance and cost ratio that is optimum for any industrial application. Constructed with heavy-duty aluminum
or stainless steel front panels, the rugged design of Advantech’s IPPC series can withstand tough industrial environments.
Equipped with powerful Intel Pentium M & Celeron M processors, the IPPC has high computing power, and also provides
expansion slots for add-on boards. The IPPC can be configured with CPU, Memory, Drives and operating system that meet
your diverse needs.
Heavy-duty, Expandable & Reliable Solutions to Optimize Site Operations and Visualization
Advantech provides a series of powerful Industrial Panel PC’s with open architectures that incorporate widely used PC
technology. These PC’s are designed to be integrated with industrial platforms for controlling machinery or processes; displaying
the information necessary to repair, maintain, or begin applications, and gathering basic production information. The IPPC-7000
series provides industrial motherboards, passive backplanes and accessible front panels with USB ports & multiple membrane
function keys.
Open HMI, Unlimited Potential
Advantech’s vision is to become the leading HMI platform provider in the PC-based industrial
automation market by creating value-added, standard product solutions and by offering
customization to meet unique requirements. We offer a wide range of HMI products for
automation needs, including; hardware platforms such as the Touch Panel Computers (TPC),
Industrial Panel PC’s (IPPC), and Industrial Monitors (FPM). We also offer powerful Windows
XP/XPe/CE and Linux-based HMI solutions to easily migrate applications up or down as
scope changes.
34

TPC Series
Touch Panel Computer Overview
50mm
Grounding protection
PCI-104 expansion
Downward I/O cabling
The X86 TPC series provides a powerful and durable
solution with high computing power and ultra low
voltage processors.
♦ Fanless and compact design
♦ A PC/104 or PCI-104 expansion slot gives a high degree of versatility
♦ Rich standard I/O support: providing multiple standard communications to couple
with different peripherals
♦ Dual LAN and Gigabit Ethernet support
♦ Downward I/O cabling: friendly interface for plugging in cables
♦ Grounding protection
♦ Variety of OS support, including; Windows XP, WinXPe and WinCE
9
123 4
5
6
7811
12 10
1
5.7"/6.4” X86-based Touch Panel Computers
TPC-660E/662G
5.7"/6.4" VGA TFT LCD Geode LX800
Touch Panel Computer with CAN-bus
1. RS-232 COM port
2. RS-232/422/485 COM port
(TPC-660E)
CAN-Bus port (TPC-662G)
3. PS/2
4. USB 2.0 Host x 2
5. Fuse
TPC-870H/1070H
8"/10.4" VGA/SVGA TFT LCD Pentium M/Celeron M
Touch Panel Computer
1. RS-232 COM Port x 2
2. RS-232/422/485 COM Port
3. 10/100B-T Ethernet
4. PS/2
5. Power Switch
6. Fuse
TPC-1570H
15" VGA/SVGA TFT LCD Pentium M/Celeron M
Touch Panel Computer
1. RS-232 COM port x 2
2. RS-232/422/485 COM port
3. VGA
4. USB 2.0 Host x 2
5. Fuse
6. Power Receptor
TPC-1770H
17" SXGA TFT LCD Celeron M Touch Panel Computer
1. Power Switch & Fuse
2. Power Receptor
3. PS/2
4. RS-232 COM port x 3
5. VGA
6. 10/100/1000B-T Ethernet x 2
7. USB 2.0 Host x 4
8. Audio (Line-in,Line-out,MIC)
9. External Interface (PCI/104,RS-485/422)
8"/10.4" X86-based Touch Panel Computers
15” X86-based Touch Panel Computer
17” X86-based Touch Panel Computer
6. Power Receptor
7. Power Switch
8. 10/100B-T Ethernet
9. CompactFlash
10. PC/104
11. Audio (MIC,Line-out) TPC-660E only
7. CompactFlash
8. USB 2.0 Host x 2
9. PCI-104 Slot
10. 10/100/1000B-T Ethernet
(TPC-1070H-P1E)
10/100B-T Ethernet
(TPC-1070H-C1E/870H-C1E)
7. Power Switch
8. (1)10/100B-T Ethernet x 2
(only for TPC-1570H-B1E)
(2)10/100B-Tx1, 10/100/1000B-Tx1
(only for TPC-1570H-P2E/A1E)
9. CompactFlash
10. PCMCIA, Audio (Line-in, Line-out,MIC)
11. Parallel Port
12. PS/2
10
1 2 3 4
56
7
8
9
12
3
4
5
6
7
8
9
10
11
1
2
3 4 5
6
7 8
9
Rich standard I/O support and
dual LAN
4
56

TPC Series
Touch Panel Computer Overview
The RISC kernel consumes less power
without sacrificing performance.
♦ Designed to run on WinCE
♦ Support horizontal & vertical orientation
♦ Provide thin client software solutions
♦ Support CAN-bus 2.0b communication protocol
Horizontal & vertical screen orientation
Support WinCE 6.0/5.0 Remote display
5.7"/5.6" RISC-based Touch Panel Computer
3.5" RISC-based Touch Panel Computers
TPC-66SN
5.7" QVGA CSTN LCD XScale PXA270
Touch Panel Computer
1. RS-232 COM port
2. RS-232/485 COM port
3. USB 1.1 Host
4. USB 1.1 Client
5. Fuse
TPC-30T/32T
3.5" QVGA TFT LCD XScale PXA270
Touch Panel Computer with CAN-bus
1. 10/100B-T Ethernet
2. RS-232/485 COM port (TPC-30T)
CAN-bus/RS-232 COM port (TPC-32T)
3. Power Receptor
4. SD Slot
5. USB 1.1 Host
TPC-66T
5.6" QVGA TFT LCD XScale PXA270
Touch Panel Computer
1. RS-232 COM port
2. RS-232/485 COM port
3. USB 1.1 Host
4. USB 1.1 Client
5. Fuse
TPC-120H
12.1" SVGA TFT LCD XScale PXA270
Touch Panel Computer with CAN-bus
1. RS-232 COM port x 2
2. RS-232/485 COM port
3. USB 1.1 x 2 Host
4. Power Receptor
12.1" RISC-based Touch Panel Computer
1
2
34
5
67
8
9
1 2 3
4
5
1
2
34
5
67
8
9
6
21
35 7
84
5. Power Switch
6. 10/100B-T Ethernet x 2
7. CompactFlash
8. CAN-bus port (Optional)
6. Power Receptor
7. Power Switch
8. 10/100B-T Ethernet
9. CompactFlash
6. Power Receptor
7. Power Switch
8. 10/100B-T Ethernet
9. CompactFlash
78
CAN-bus device support

TPC Selection Guide and Ordering Information
TPC-1770H-C1AE 17” SXGA TFT LCD with Intel Celeron M 1 GHz CPU, 512 MB DDR2 SDRAM
TPC-1570H-P2E 15” XGA TFT LCD with Intel Pentium M 1.4 GHz CPU, 1 GB DDR SDRAM
TPC-1570H-A1E 15” XGA TFT LCD with Intel Celeron M 1 GHz CPU, 512 MB DDR SDRAM
TPC-1570H-B1E 15” XGA TFT LCD with Intel Celeron M 600 MHz CPU, 512 MB DDR SDRAM
TPC-1270H-P2E 12.1” SVGA TFT LCD with Intel Pentium M 1.4 GHz CPU, 1 GB DDR2 SDRAM
TPC-1270H-C1E 12.1” SVGA TFT LCD with Intel Celeron M 1 GHz CPU, 512 MB DDR2 SDRAM
TPC-1261H-A1BE 12.1” SVGA TFT LCD with AMD LX800 500 MHz CPU, 256 MB DDR SDRAM
TPC-1070H-P1E 10.4” SVGA TFT LCD with Intel Pentium M 1.4 GHz CPU, 512 MB DDR SDRAM
TPC-1070H-C1E 10.4” SVGA TFT LCD with Intel Celeron M 1 GHz CPU, 512 MB DDR SDRAM
TPC-870H-C1E 8” VGA TFT LCD with Intel Celeron M 1 GHz CPU, 512 MB DDR SDRAM
TPC-660E-B1E 5.7” VGA TFT LCD with AMD Geode LX800 500 MHz CPU,256 MB DDR SDRAM
TPC-662G-B1E 6.4” VGA TFT LCD with AMD Geode LX800 500 MHz CPU, 256 MB DDR SDRAM with CAN-Bus
TPC-120H-E2AE 12.1” SVGA TFT LCD with Intel PXA270 520 MHz CPU, 64 MB SDRAM, WinCE 5.0 with CAN-Bus
TPC-66SN-E2AE 5.7” QVGA CSTN LCD with Intel PXA270 416 MHz CPU, 64 MB SDRAM, WinCE 5.0
TPC-66T-E2AE 5.6” QVGA TFT LCD with Intel PXA270 416 MHz CPU, 64 MB SDRAM, WinCE 5.0
TPC-30T-E2AE 3.5” QVGA TFT LCD with Intel PXA270 312 MHz CPU, 64 MB SDRAM, WinCE 5.0
Ordering Information
Accessories
TPC-1570H-SMKE
TPC-1570H desktop
TPC-1270H-WMKE
TPC-1270H Wallmount
TPC-1270H-EPKE TPC-660G-EHKE
TPC-1570H-SMKE TPC-1570H Desktop Stand Kit
TPC-1570H-WMKE TPC-1570H Wall Mount Kit
TPC-1270H-SMKE TPC-1270H Desktop Stand Kit
TPC-1270H-WMKE TPC-1270H Wall Mount Kit
TPC-660G-EHKE TPC-660G Extension HDD Kit
TPC-1270H-EPKE TPC Series PC/PCI-104 Extension Kit (bracket only)
Ordering Information
Model TPC-1770H TPC-1570H TPC-1270H TPC-1070H TPC-870H TPC-660E TPC-662G TPC-120H TPC-66SN TPC-66T TPC-30T/32T
CPU Intel Celeron M 1 GHz
Intel Pentium M 1.4 GHz
Intel Celeron M 1 GHz
Intel Celeron M 600 MHz
Intel Pentium M 1.4 GHz
Intel Celeron M 1 GHz
Intel Pentium M 1.4 GHz
Intel Celeron M 1 GHz Intel Celeron M 1 GHz AMD Geode LX800 500 MHz AMD Geode LX80 0 500 MHz Intel PXA270 520 MHz Intel PXA270 416 MHz Intel PXA270 416 MHz Intel PX A270 312 MHz
Memory 512 MB DDR2 SDR AM
(up to 1 GB D DR SDR AM)
512 MB DDR SDR AM
(up to 1 GB D DR SDR AM)
512 MB DDR2 SDRA M
(up to 1 GB D DR2 SDRA M) 512 MB DDR SDRA M 512 MB DDR SDR AM 256 MB DDR SDR AM(up to 1 GB DD R SDR AM)
256 MB DDR SDR AM(up to 1 GB
DDR SDR AM) 64 MB S DR AM on board 64 MB SDRAM on board 64 MB S DR AM on board 64 MB SDRAM on board
Display
Type SXGA TF T LCD XGA T FT LCD SVGA TF T LCD SVGA TF T LC D VGA T FT LCD VGA T FT LCD VGA TF T LCD SVGA TF T LCD QVGA C ST N LCD QVGA TF T LCD QVGA TFT LCD
Size 17” 15" 12.1" 10.4" 8" 5.7" 6.4" 12.1" 5.7" 5.6" 3.5"
Max. Resolution 1280 x 1024 1024 x 768 800 x 60 0 800 x 6 00 640 x 4 80 640 x 4 80 640 x 4 80 800 x 600 320 x 240 320 x 23 4 320 x 240
Max. Colors 16.7 M 262 K 262 K 260 K 64 K 262 K 262 K 262 K 64 K 64 K 64 K
Luminance (cd/m²) 300 350 350 400 350 220 150 340 400 500 200
Viewing Angle (H/V°) 160/160 120/100 140/120 140/100 130/120 140/100 90/50 100/6 0 100/ 55 100/60 120/110
Backlight MTBF (hrs) 50,000 50,000 50,000 50,000 50,000 50,000 20,000 50,000 60,000 30,000 30,0 00
Touchscreen Resistive Resistive Resistive Resistive Resistive Resistive Resistive Resistive Resistive Resistive Resistive
Flash Memory N/A N/A N/A N/A N/A N/A N/A 64 MB on board 64 MB on board 64 M B on board 32 MB on board
HDD 1 x Internal 2.5" SATA (optional ) 1 x Internal 2.5" PATA (optional) 1 x Internal 2.5" SATA (optional ) 1 x Internal 2.5" PATA (optional) 1 x Internal 2.5" PATA (optional) 1 x External 2.5" PATA (optional) 1 x External 2.5" PATA (optional) N/A N/A N/A N/A
Network (LAN) 10/100/1000Base-T x 2
TPC-1570H-P1E/C1E, A1E
10/100Base-T x 1
10/100/1000Base-T x 1
TPC-1570H-B1E
10/100Base-T x 2
TPC-1270H-P1E/P2E
10/100Base-T x 1
10/100/1000Base-T x 1
TPC-1270H-C1E
10/100Base-T x 2
TPC-1070H-P1E
10/100Base-T
10/100/1000Base-T x 2
TPC-1070H-C1E
10/100Base-T x 2
10/100Base-T x 2 10/100Base-T x 1 10/100Base-T x 1 10/100Base-T x 2 10/100Base-T x 1 10/100Base-T x 1 10/100Base-T x 1
I/O ports
RS-232 x 3
USB x 4
KB x 1, Mouse x 1
VGA x 1
Audio ( Mic-in x 1, Line-in x 1,
Line-out x 1)
Serial Port x 3 (RS-232 x 2 and
RS-232/485 /422 x 1)
Parallel Por t x 1
VGA x 1, US B x 2
Audio ( MIC-in x 1, Line-in x 1,
Line-out x 1)
PS/ 2 x 1
Serial Port x 4
(RS-232 x 3 and
RS-232/485 /422 x 1)
VGA x 1, US B x 4
Audio
(MIC-in x 1, Line-out x 1)
Serial Port x 3
(RS-232 x 2 and
RS-232/485 /422 x 1)
USB x 2, PS/2 x 1
Serial Port x 3
(RS-232 x 2 and
RS-232/485 /422 x 1)
USB x 2, PS/2 x 1
Serial Port x 2
(RS-232 x 1 and
RS-232/485 /422 x 1)
USB x 2
Serial Port x 2
(RS-232 x 1
and RS-232 /48 5/422 x 1)
USB x 2
Serial Ports x 3
(Full RS-232 x 2 and
4-pin R S-232/485 x 1)
VGA x 1
USB x 2 ( Host)
CAN Bus x 1 (optional)
Serial Port x 3
(Full RS-232 x 2 and
4-pin R S-232/485 x 1)
USB x 2 ( Host x 1, Client x 1)
Serial Port x 3
and 4-pin RS-232 /485 x 1
USB x 2 ( Host x 1, Client x 1)
USB x 1 ( Host)
TPC-30T: RS-232/485 x 1
TPC-32T: CAN-Bus /RS-232 x 1
SD x 1
CompactFlash Slot Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 Type II x 1 N /A
PCMCIA Slot N/A Type II x 1 N/A N/A N/A N/A N/A N /A N/A N/A N/A
Expansion Slot N/A N /A PCI-104 x 1 PCI-104 x 1 PCI-104 x 1 PC-104 x 1 PC-104 x 1 N/A N/A N/A N/A
Power Input Voltage 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 18 ~ 32 Vdc 8 ~ 28 Vdc
Dimension(WxHxD)(mm) 414 x 347.5 x 93 mm
(16.3” x 13.68” x 3.6 6”)
383 x 307 x 64.5 mm
(15.08” x 12.0 9” x 2.54”)
311 x 237 x 52.3 mm
(12.24” x 9.33” x 2.06”)
286 x 226 x 58 mm
(11.26” x 8.9” x 2.28”)
286 x 226 x 58 mm
(11.26” x 8.9” x 2.28”)
195 x 148 x 44.4
(7.68” x 5.83” x 1.75”)
195 x 148 x 44.4
(7.68” x 5.83” x 1.75”)
311 x 237 x 52
(12.24” x 9.33” x 2”)
195 x 148 x 44.4
(7.68” x 5.83” x 1.75”)
195 x 148 x 44.4
(7.68” x 5.83” x 1.75”)
120.8 x 85.5 x 26.5
(4.76” x 3.37” x 1.04”)
Weight (Net/Gross) 8 kg (17.64 lbs) 5 kg (11.02 lbs) 3.3 kg (7.28 lbs) 3.5 kg (7.72 lbs) 3.5 kg ( 7.72 lbs) 1 kg (2.2 lbs) 1 kg (2.2 lbs) 2.2 kg (4.85 lbs) 0.8 kg (1.76 lbs) 0.8 kg (1.76 lbs) 0.25 kg (0.55 lbs)
Front Cover Die-Cast Aluminum Alloy Al-Mg Al-Mg Die-Cast Aluminum Alloy Die-Cast Aluminum Alloy A BS ABS A l-Mg AB S ABS ABS
Operating Temperature 0 ~ 45° C (32 ~ 113° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F )
Ingress Protection (Front
Panel) NEMA4/IP65 NEM A4/IP65 N EM A4/IP65 NEM A4 /IP6 5 NEMA4/ IP 65 NEM A4/I P65 NEM A4/IP65 NEMA4/IP65 NE MA 4/ IP65 NEMA4/IP65 NEM A4/I P65
Certifications BSMI, CCC, CE, FCC, UL BSM I, CCC, CE, FCC, UL BSMI, CCC, CE, FCC, UL BSMI, C CC, CE, FCC, U L BSMI, CCC, CE, FCC, UL B SMI, CCC, CE, FCC, UL BSMI, CCC, CE, FCC, UL BSMI, CCC, CE, FCC, U L BSMI, CCC, CE, FCC, UL BSMI, CCC, CE, FCC, UL BSMI, CCC, CE, FCC, UL
Operating System
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows XP
Windows XP Embedded
Windows CE 5.0
Windows CE 5.0 Windows CE 5.0/4.2 Windows C E 5.0/4.2 Windows CE 5.0
910

Industrial Monitor Overview
Complete Product Line
• Complete selection of sizes from 6” to 19”
• For diverse application demands
19"
17"
15"
12"
6"
NEMA4/IP65 Compliant
The IP65 rating means that the monitor is
protected from ingress of dust and jets of
water from all directions.
Has a tempered glass screen, which is nearly
4X stronger than annealed glass. When struck
by an outside force, a tempered glass screen
won’t shatter into pieces, making it very easy
to clean in the event of breakage
Robust design with stainless steel chassis
and aluminum front panel
Swing Arm WallmountMounting Kit for
Desktop
Aiming to be a leader in the display market, Advantech provides a full-range of industrial
monitors for versatile applications. The Advantech FPM series ranges in size from 6”, 12”,
15”, 17” to 19”. Their industrial-grade high-brightness LCD and anti-glare design provide
a long-lasting and reliable information interface. The FPM series supports panel mount-
ing, VESA and desktop mounting to fit various kinds of applications.
User-friendly Features
DC adapter with plug bracket makes
the machine more reliable in critical
environments
Industrial 24Vdc power input is
compatible for factory installation
Front-accessible USB port provides a
convenient & practical solution
FPM Series
A combination of touchscreen
interfaces with lockable connectors is
provided, allowing secure attachments
for a variety of uses
OSD provides a user friendly
interface for brightness
adjustment
Rack MountPanel Mount
Versatile Mounting Methods for Different
Application Environments
11 12

Accessories
FPM-3150G-RMKE
19” rack mounting kit for
FPM-3150G series
FPM-2150G-RMKE
19” rack mounting kit for
FPM-2150G series
FPM-2150G-SMKE
Stand / desk / wall mounting kit
for FPM-2150G, FPM-3150G,
FPM-3120G
PWR-246E
Industrial DC to DC converter
w/24~48VDC power input
RS-232 Cable 9-pin
to 9 pin
1700091800 (1.8m)
VGA Cable 15-pin
to 15-pin
1700151801 (1.8m)
1700155000 (5m)
1700151000 (10m)
1700155001 (50m)
FPM-3060G-VMKE
VESA mounting kit for
FPM-3060G series
FPM-5151G-SMKE
Stand Kit for FPM-5151G
Model FPM-3190G/3191G FPM-3170G/3171G FPM-5171G FPM-5151G
LCD Display
Size (diagonal) 19" 17" 17" 15"
Resolution 1280 x 1024 1280 x 1024 1280 x 1024 1024 x 768
Colors 16.2M 16.2 M 16.7 M 16.2 M
Viewing Angle (H/V°) 178, 178 140, 130 160, 160 140, 120
Luminance (cd/m2) 300 300 300 250
Backlight Life (hrs) 50000 40000 50000 50000
Contrast Ratio 1000 : 1 700 : 1 800 : 1 500 : 1
Direct VGA Input Yes Yes Yes Yes
DVI Input FPM-3190G FPM-3170G Yes Yes
S-Video FPM-3190G F PM-3170G - -
Video Input FPM-3190G FPM-3170G - -
Touchscreen (optional) Resistive Resistive Resistive Resistive
OSD (onscreen display) Yes Yes Yes Yes
Touchscreen Sensor ELO ELO AMT A MT
Inverter T DK TDK TDK TDK
Power Adapter (voltage, AC) 100-240 V 100-240 V 100-240 V 100-240 V
DC Power Input (voltage) N/A N/A 10-30 V 10-30 V
Front Panel Ingress Protection NEMA4/ IP 65 N EM A4/I P65 NEMA4/IP65 N EM A4/I P65
Operating Temperature 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F )
Storage Temperature -20 ~ 60° C (-4 ~ 140° F ) -20 ~ 60° C (-4 ~ 140° F ) -20 ~ 60° C (-4 ~ 140° F ) -20 ~ 60° C (-4 ~ 140° F )
Certifications BSMI, CCC, CE, FCC BSMI, CCC, CE, FCC B SMI, CC C, CE, FCC BSM I, CCC, CE, FC C, UL
Dimensions (W x H x D) 312 x 244 x 44.6 mm
(12.28” x 9.61” x 1.76”)
220 x 150 x 4 6 mm
(8.7” x 5.9” x 1.8” )
422 x 310 x 86 mm
(16.6” x 12.2” x 3.4”)
383 x 307 x 48 mm
(15” x 12” x 1.89”)
Model FPM-2150G FPM-3150G FPM-3120G FPM-3060G
LCD Display
Size (diagonal) 15" 15" 12.1" 6.5"
Resolution 1024 x 768 1024 x 768 800 x 600 640 x 4 80
Colors 16.2 M 16.2 M 262 k 262 k
Viewing Angle (H,V) 140, 125 140, 120 140, 120 140, 120
Luminance (cd/m2) 250 550 350 300
Backlight Life (hrs) 50,000 50,000 50,0 00 50,000
Contrast Ratio 500 : 1 500 : 1 200 : 1 500 : 1
Direct VGA Input Yes Yes Yes Yes
DVI Input - Yes - -
S-Video - - - -
Video Input - - - -
Touchscreen (optional) Resistive Resistive Resistive Resistive
OSD (onscreen display) Yes Yes Yes Yes
Touchscreen Sensor AMT AMT AMT AMT
Inverter T DK T DK TD K TDK
Power Adapter (voltage, AC) 100-240 V 100-240 V 100-240 V 100-240 V
DC Power Input (voltage) N/A N/A N/A N /A
Front Panel Ingress Protection NEMA4/IP65 NEMA4/ IP 65 NEMA 4/ IP65 N EMA4/IP65
Operating Temperature 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F) 0 ~ 50° C (32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F )
Storage Temperature -20 ~ 60° C (- 4 ~ 140° F ) -20 ~ 60° C (-4 ~ 140° F) -20 ~ 60° C (-4 ~ 140° F) -20 ~ 60° C (- 4 ~ 140° F )
Certifications BSMI, CCC, CE, FCC, UL BSMI, CCC, CE, FCC BSMI, CC C, CE, FCC BSMI, CCC, CE, FCC
Dimensions (W x H x D) 383 x 307 x 48 mm
(15” x 12” x 1.89”)
422 x 310 x 86 mm
(16.6” x 12.2” x 3.4”)
312 x 244 x 44.6 mm
(12.28” x 9.61” x 1.76”)
220 x 150 x 4 6 mm
(8.7” x 5.9” x 1.8” )
FPM Selection Guide and Ordering Information
FPM-3190G-XBE Industrial 19” TFT LCD Display with 19” Rack-Mount Bezel, Direct-VGA, DVI-D, S-Video & Video Input
FPM-3190G-RBE FPM-3190G-XBE with Resistive Touchscreen (RS-232 Interface)
FPM-3190G-UBE FPM-3190G-XBE with Resistive Touchscreen (USB Interface)
FPM-3191G-XBE Industrial 19” SXGA Flat Panel Monitor
FPM-3191G-RBE FPM-3191G-XBE with Resistive Touchscreen (RS-232 Interface)
FPM-3191G-UBE FPM-3191G-XBE with Resistive Touchscreen (USB Interface)
FPM-3170G-XBE Industrial 17” TFT LCD Display with 19” Rack-Mount Bezel, Direct-VGA, DVI-D, S-Video & Video Input
FPM-3170G-RBE FPM-3170G-XBE with Resistive Touchscreen (RS-232 Interface)
FPM-3170G-UBE FPM-3170G-XBE with Resistive Touchscreen (USB Interface)
FPM-3171G-XBE Industrial 17” SXGA Flat Panel Monitor
FPM-3171G-RBE FPM-3171G-XBE with Resistive Touchscreen (RS-232 Interface)
FPM-3171G-UBE FPM-3171G-XBE with Resistive Touchscreen (USB Interface)
FPM-5171G-X0AE Industrial 17" TFT LCD Display with Direct-VGA & DVI-D Port
FPM-5171G-R3AE FPM-5171G-X0AE with Resistive Touchscreen (RS-232 & USB Interface)
FPM-5151G-X0AE Industrial 15" TFT LCD Display with Direct-VGA & DVI-D Port
FPM-5151G-R3AE FPM-5151G-X0AE with Resistive Touchscreen (RS-232 & USB Interface)
FPM-3150G-XCE Industrial 15” TFT LCD Display with Direct-VGA & DVI-D Port
FPM-3150G-RCE FPM-3150G-XCE with Resistive Touchscreen (RS-232 & USB Interface)
FPM-2150G-XCE Industrial 15” TFT LCD Display with Direct-VGA Port
FPM-2150G-RCE FPM-2150G-XCE with Resistive Touchscreen (RS-232 Interface)
FPM-2150G-UCE FPM-2150G-XCE with Resistive Touchscreen (USB Interface)
FPM-3120G-XAE Industrial 12.1” SVGA TFT LCD with Direct-VGA Port
FPM-3120G-RAE FPM-3120G-XAE with Resistive Touchscreen (RS-232 Interface)
FPM-3060G-XAE Industrial 6” VGA TFT LCD with Direct-VGA Port
FPM-3060G-RAE FPM-3060G-XAE with Resistive Touchscreen (RS-232 Interface)
FPM-3060G-UAE FPM-3060G-XAE with Resistive Touchscreen (USB Interface)
FPM-3150G-RMKE Mounting Kit for 19” Industrial Rack (For FPM-3150G Series)
FPM-2150G-RMKE Mounting Kit for 19” Industrial Rack (For FPM-2150G Series)
FPM-2150G-SMKE Mounting Kit for Desktop & Wall (For FPM-2150G/3120G/3150G Series)
FPM-3060G-VMKE FPM-3060G VESA Mounting Kit
FPM-5151G-SMKE Stand Kit for FPM-5151G
PWR-246E Industrial DC to DC Converter with 24 ~ 48VDC Power Input
Ordering InformationOrdering Information
13 14

Industrial Panel PC Overview
Complete Product Line for IPPC
The robust design and compact size of the IPPC series make it a good fit for almost
any industrial application. Constructed with heavy-duty aluminum or stainless steel
front panel and tempered glass, the rugged design of IPPCs stand up to the toughest
industrial operating environments. Equipped with powerful Intel Pentium M / Celeron M
processors, IPPC’s provide high performance with excellent expansion capabilities.
Flat-sealed front panel
impervious to water
and dust
NEMA4/IP65 compliant
IPPC-6152A
15” XGA TFT LCD Pentium M/Celeron M Industrial Panel PC
with 2 x PCI Slots
•15" XGA TFT LCD with touchscreen (optional)
•Intel Pentium M Processor up to 2.0 GHz/Celeron M 1.5 GHz
•System memory supports dual channel DDR2 SDRAM up to 2 GB
•Offers two expansion slots for PCI add-on card
•Dual Lan, supports one Gigabit Lan
•Front USB access and system reset function
•Flat-sealed front panel
•Control Box with gull-wing design for easy installation and maintenance
•Front panel is NEMA4/IP65 compliant
IPPC-6172A
17” SXGA TFT LCD Pentium M/Celeron M Industrial Panel PC
with 2 x PCI Slots
•17” SXGA TFT LCD with touchscreen (optional)
•Intel Pentium M Processor up to 2.0 GHz/Celeron M 1.5 GHz
•System memory supports dual channel DDR2 SDRAM up to 2 GB
•Offers two expansion slots for PCI add-on card
•Dual Lan, supports one Gigabit Lan
•Front USB access and system reset function
•Flat-sealed front panel
•Control Box with gull-wing design for easy installation and maintenance
•Front panel is NEMA4/IP65 compliant
IPPC-7157A
15” XGA TFT LCD Pentium D/Pentium 4/Celeron D Industrial Panel PC with
7 x PCI/PCle Slots and Membrane Keypad
•Pentium D up to 3.2 GHz/Pentium 4 up to 3.8 GHz/Celeron D up to 3.06 GHz
•15” XGA TFT LCD with touchscreen (optional) provides vivid, sharp images
•Offers 7 expansion slots for PCI and PCIe interface
•Detachable side-open front panel makes maintenance fast & easy
•Programmable membrane function keys for varied application access
•Heavy-duty design with anti-rust chassis and NEMA4/IP65 aluminum front panel
•One front-accessible USB 2.0 port
IPPC-7158B
15” XGA TFT LCD Industrial Panel PC with 14 x ISA/PCI/PICMG Slots, Passive
Backplane and Membrane Keypad
•15” XGA TFT LCD with touchscreen (optional) provides vivid, sharp images
•Offers 14 expansion slots for PCI, PICMG and ISA
•Detachable side-open front panel makes maintenance fast & easy
•Programmable membrane function keys for varied application access
•Heavy-duty design with anti-rust chassis and NEMA4/IP65 aluminum front panel
•One front-accessible USB 2.0 port
Industrial-proven and Rugged Design
Tempered glass is stronger,
providing more industrial safety
protection
Anti-shock / Anti-vibration
HDD design
Aluminum front panel
(stainless steel optional)
15 16
IPPC Series

IPPC Selection Guide & Ordering Information
IPPC-6172A-X0AE
17" SXGA TFT LCD Pentium M/Celeron M Industrial Panel PC with 2 x PCI Slots
IPPC-6172A-R0AE
17" SXGA TFT LCD Pentium M/Celeron M Industrial Panel PC with 2 x PCI Slots with resistive touchscreen
IPPC-6152A-X0AE
15" XGA TFT LCD Pentium M/Celeron M Industrial Panel PC with 2 x PCI Slots
IPPC-6152A-R0AE
15" XGA TFT LCD Pentium M/Celeron M Industrial Panel PC with 2 x PCI Slots with resistive touchscreen
IPPC-9151G-XAE
15" XGA TFT LCD Pentium 4 Industrial Panel PC with 2 x PCI Slots
IPPC-9151G-RAE 15" XGA TFT LCD Pentium 4 Industrial Panel PC with 2 x PCI Slots with resistive touchscreen
IPPC-9171G-XAE 17" SXGA TFT LCD Pentium 4 Industrial Panel PC with 2 x PCI Slots
IPPC-9171G-RAE 17" SXGA TFT LCD Pentium 4 Industrial Panel PC with 2 x PCI Slots with resistive touchscreen
IPPC-7157A-X1AE 15" Pentium D Industrial Panel PC with 7 x PCI/PCIe slots
IPPC-7157A-R1AE 15" Pentium D Industrial Panel PC with 7 x PCI/PCIe slots and resistive touchscreen
IPPC-7158B-X1AE 15" XGA TFT LCD Passive Backplane Industrial Panel PC with 14 x ISA/PCI/PICMG Slots and Membrane Keypad
IPPC-7158B-R1AE 15" XGA TFT LCD Passive Backplane Industrial Panel PC with 14 x ISA/PCI/PICMG Slots and Membrane Keypad and resistive touchscreen
Industrial Panel PC Overview
Ordering Information
IPPC Series
Model Name IPPC- 6172A IPPC-6152A IPPC-9171G IPPC-9151G IPPC-7157A IPPC-7158B
LCD Display
Type SXGA TF T LCD XGA TF T LCD SXGA T FT LCD XGA TF T LCD XGA TFT LCD
Size 17" 15" 17 15" 15"
Max. Resolution 1280 x 1024 1024 x 768 1280 x 1024 1024 x 768 1024 x 768
Max. Colors 16.2 M
(RG B 6-bit + FRC data)
16.2 M
(RG B 6-bit + FRC data) 16.2 M 262K,144K 16.2 M (RGB 6-bit + FRC data)
Viewing Angle (H, V°) 160, 160 140, 120 160, 160 120, 100 140, 120
Luminance (cd/m2) 300 250 300 350 250
Backlight Life (hrs) 50,00 0 50,00 0 50,000 5 0,000 50,000
Contrast Ratio 800 : 1 500 : 1 800 : 1 400:1 50 0 : 1
CPU
Socket 478 Pentium M
(up to 2 GHz)/
Celeron M 1.6 GHz
Socket 478 Pentium M
(up to 2 GHz)/
Celeron M 1.6 GHz
Socket 478 Pentium 4
(up to 2.8 G Hz)/
Celeron 2.4 GHz
Socket 478 Pentium 4
(up to 2.8 G Hz)/
Celeron 2.4 GHz
Socket 775 Pentium D (up to 3.2 GHz)
Socket 775 Pentium 4 (up to 3.8 GHz)
Socket 775 Celeron D (up to 3.06 GHz)
-
Memory Up to 2 GB DDR2 S DR AM
400/533 MHz
Up to 2 GB DDR 2 SDRAM
400/533 MHz
Up to 2 GB DDR S DR AM
(DDR-DIMM 184 pin)
Up to 2 GB DDR S DR AM
(DDR-DIMM 184 pin)
Up to 4 GB DDR 2 SDRAM
(Dual Channel DDR2 DIMM 240 pin) -
IEEE 1394 (Firewire) Ports - - Two Two N /A -
Serial Ports 1 x RS-232 1 x RS-232 1 x RS-232,
1 x RS-232/422/485
1 x RS-232,
1 x RS-232/422/485 1 x RS-232, 1 x RS-232/422/4 85 -
Parallel Ports One One One One One -
Video Ports VG A VGA VGA/ S-Video VGA /S-Video VG A -
USB Ports 5 x USB 2.0
(one at front)
5 x USB 2.0
(one at front)
5 x USB 2.0
(one at front)
5 x USB 2.0
(one at front)
1 x USB2.0 on front panel
4 x USB2.0 on rear I/O -
Network (LAN) 10/100 Base-T x1
10/100/1000Base-T x 1
10/100Base-T x1
10/100/1000Base-T x 1 10/100Base-T 10/100Base-T Dual 10/100/1000Base-T -
Floppy Disk Drive
(Optional) - - One One 1 1
CD-ROM Drive (Optional) Slim Type x 1 Slim Type x 1 Slim Type x 1 Slim Type x 1 5.25" half length 5.25” half length
Hard Disk Drive (Optional) 1 x 2.5" SATA 1 x 2.5" SATA 1 x 3.5 1 x 3.5 2 x 3.5" SATA 1 x 3.5"
PCMCIA Slot - - Type II x 2 Type II x 2 N/A N/A
Expansion Slots 2 x PCI 2 x PCI 2 x PCI 2 x PCI 5 x PCI, 2 x PCIe 14 Slots Backplane ( PCI
x10, ISA x2, PCI/ISA x2)
Touchscreen Type
(Optional) Resistive Resistive Resistive Resistive Resistive
Power Supply (AC) 180 W 180 W 180 W 180 W 300 W
Operating Temperature 0 ~ 50° C
(32 ~ 122° F )
0 ~ 50° C
(32 ~ 122° F )
0 ~ 50° C
(32 ~ 122° F )
0 ~ 50° C
(32 ~ 122° F ) 0 ~ 50° C (32 ~ 122° F )
Storage Temperature -20 ~ 60° C
(-4 ~ 140° F )
-20 ~ 60° C
(-4 ~ 140° F )
-20 ~ 60° C
(-4 ~ 140° F )
-20 ~ 60° C
(-4 ~ 140° F ) -20 ~ 60° C (-4 ~ 140° F)
Certifications B SMI, CCC, CE, FCC, UL BSM I, CCC, CE, FC C, UL BSM I, CCC, CE, FC C, UL B SMI, CCC, CE, FCC, UL BSMI, CC C, CE, FCC
Dimensions
(W x H x D)
481.92 x 355.87 x 146 mm
(18.97" x 14.01" x 5.75")
449.92 x 315.6 3 x 141.7 mm
(17.73" x 12.44" x 5.58")
482 x 354.8 x 162 mm
(18.97 x 13.96 x 6.37 )
482 x 354.8 x 162 mm
(18.97 x 13.96 x 6.37 ) 482 x 354.8 x 162 mm (18.97" x 13.96" x 6.37")
Front Accessible
♦ Programmable membrane
macro keys
♦ Function keys
♦ Cursor keys
♦ Touchpad
Designed for Easy Installation & Flexible Expansion
User-Friendly Interface
Front USB access OSD control behind
the front panel of
IPPC-7000 series
17 18
Flexible board configura-
tion between industrial
motherboard (IPPC-7157A)
or passive backplane
(IPPC-7158B)
IPPC-7000’s detachable sideopen
front panel
Gull-wing rear cover allows easy
access to CPU, RAM, PCI and HDD
