Advantech MIC-770 V2 User manual

User Manual
MIC-770 V2
Compact Fanless System with
10th Gen Intel® Xeon®/Core™ i
CPU Socket (LGA 1200)

MIC-770 V2 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2021
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties that may result from its use.
Acknowledgments
AMI is a trademark of American Megatrends Inc.
IBM and PC are trademarks of International Business Machines Corporation.
Intel® Core™, Pentium® and Celeron® are trademarks of Intel® Corporation.
All other product names or trademarks are properties of their respective owners.
A Message to the Customer
Advantech Customer Service
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.
Part No. 2001077020 Edition 1
Printed in China August 2021

iii MIC-770 V2 User Manual
Product Warranty (2 years)
Advantech warrants the original purchaser that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech’s high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced free of charge during the warranty period. For out-of-
warranty repairs, customers will be billed according to the cost of replacement mate-
rials, service time, and freight. Please consult your dealer for more details.
If you believe your product is defective, follow the steps outlined below.
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship the pack-
age prepaid to your dealer.

MIC-770 V2 User Manual iv
Declaration of Conformity
FCC
This device complies with the requirements in part 15 of the FCC rules:
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this device in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his/her own expense. The
user is advised that any equipment changes or modifications not expressly approved
by the party responsible for compliance would void the compliance to FCC regula-
tions and therefore, the user's authority to operate the equipment.
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.comto obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

v MIC-770 V2 User Manual
Warnings, Cautions, and Notes
Warning! Warnings indicate conditions that if not observed can cause personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses. For example,
“Batteries are at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type as recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”
Note! Notes provide additional optional information.

MIC-770 V2 User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all power outlets before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If any of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning, or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment shows obvious signs of breakage.
15. Do not leave the equipment in an environment with a storage temperature of
below -40 °C (-40 °F) or above 85 °C (185 °F) as this may damage the compo-
nents. The equipment should be kept in a controlled environment.
16. CAUTION: Batteries are at risk of exploding if incorrectly replaced. Replace only
with the same or equivalent type as recommended by the manufacturer. Discard
used batteries according to the manufacturer’s instructions.
17. In accordance with the IEC 704-1:1982 specifications, the sound pressure level
at the operator’s position does not exceed 70 dB (A).
18. RESTRICTED ACCESS AREA: The equipment should only be installed in a
Restricted Access Area.
DISCLAIMER: These instructions are provided according to IEC 704-1 standards.
Advantech disclaims all responsibility for the accuracy of any statements contained
herein.

vii MIC-770 V2 User Manual
Safety Precautions
Packing List
Before system installation, check that the items listed below are included and in good
condition. If any item does not accord with the list, contact your dealer immediately.
Warning! Always completely disconnect the power cord from your chassis when-
ever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sud-
den power surges. Only experienced electronics personnel should open
the PC chassis.
Caution! Always ground yourself to remove any static charge before touching the
motherboard. Modern electronic devices are very sensitive to static
electric discharges. As a safety precaution, use a grounding wrist strap
at all times. Place all electronic components on a static-dissipative sur-
face or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-powered Real-time Clock cir-
cuit. There is a danger of explosion if battery is incorrectly replaced.
Replace only with same or equivalent type recommended by the manu-
facturer. Discard used batteries according to manufacturer’s instruc-
tions.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer’s
instructions.
MIC-770 V2 bare-bone system x 1
Startup manual EN\CN\TC for MIC-770 V2 1st Ed P/N: 2041077030
4-pin Phoenix connector P/N: 1652003234
Mounting bracket x 2 P/N: 1960070543T005
SATA cable x 1 P/N: 1700013095
SATA Power cable x 1 P/N: 1700024372-01
CPU thermal grease x 1 P/N: 2170000093-01
RAM thermal pad x 2 P/N: 1990019498N000

MIC-770 V2 User Manual viii
Ordering Information
Optional i-Module
Part
Number VGA HDMI 2.5' HDD /SSD mSATA USB3.2 (Gen2)
USB3.2
(Gen1) USB2.0 GbE COM PCIE/PCI Exp Power
MIC-770W-
20A1 1 1 1 1 2 6 0 2 2, up to 6 (Optional)
i-module
(Optional) 9~36VDC
MIC-770H-
20A1 1 1 1 1 0 4 4 2 2, up to 6 (Optional)
i-module
(Optional) 9~36VDC
Module Number Description
4-slot expansion module
MIC-75M13-00A2 1 x PCIe x16+3xPCI slot i-module
MIC-75M40-00A2 1 x PCIe x8+3xPCIe x4 slot i-module
2-slot expansion module
MIC-75M20-00C1 1 x PCIe x16+1xPCIe x4 slot i-module
MIC-75M20-01A2 2 x PCIe x8 slot i-module
MIC-75M11-00A2 1 x PCIe x16+1xPCI slot i-module
1-slot expansion module
MIC-75M10-00A2 1 x PCIe x16 slot
Featured expansion module
MIC-75S20-00A2 1 x PCIe x16+ 1 x PCIe x4 slot+ 2x2.5” swappable HDD/SSD
MIC-75G20-10A2 1 x PCIe x16 (Doible Deck)+1xPCIe x4+2 x 2.5" hot-swap HDD/
SSD GPU slot i-module
MIC-75G30-00A2 2 x PCIe x8 + 1 x PCIe x4 slot + 2 x 2.5" swappable HDD/SSD
98R17520301 2 x 3.5" HDD kit

ix MIC-770 V2 User Manual
Optional Accessories
i-module Optional Accessories
Part Number Description
96PSA-A230W24P4-3 ADP A/D 100-240V 230W 24V C14 TERMINAL BLOCK 4P
96PSA-A150W19P4-3 ADP A/D 100-240V 150W 19V C14 TERMINAL BLOCK 4P
1702002600 Power cord (USA) UL/CSA, 3-pin, 10A, 125V, 1.83M, 180 D
1700022940-01 Power cord PSE, 3-pin, 7A, 125V, 3M, DAC-ST01
1702002605 Power Cord (EU), 3-pin, 10A, 250V 1.83M, 90D
96PSD-A240W24-MN A/D 100-240V 240W 24V NDR DIN RAIL
1700031170-01 DC-DC power cord, A cable TEM*4/TEM*4 UL2464 18AWG 150cm
1700029720-01 AC-DC power cord (US), M cable AC CONN 3P 183cm
1700030520-01 AC-DC power cord (CN), M cable conn 3P CCC 10A 250V 150cm
1700031408-01 AC-DC power cord (EU), M cable conn 3P/G-TEM*3 80CM
PCA-TPM-00B1E TPM 2.0 module
98R17500101 MIC HDMI/Remote power on/off FIO
98R17500301 MIC HDMI kit FIO
98R17500401 MIC Remote power on/off FIO
98R17500601 MIC COMport kit FIO
98R17500701 MIC Remote power on/off kit for SFIO
98R17500801 MIC Reset/Remote power on/off/5VDC kit FIO
98R17500901 MIC GPIO kit
98R17501001 MIC Display Port kit
98R17501101 MIC COM and HDMI kit
98910770301 MIC NVMe + 4 LAN Advanced FIO
98910770401 MIC NVMe Advanced FIO
98910770501 MIC 4 PoE Advanced FIO
98R1752020E MIC Dual SSD kit
98R17500201 MIC Din Rail Mounting kit (90/180)
98R17500210 MIC Din Rail Mounting kit (180)
98R17500501 MIC Wall Mounting kit
i-Door Module
(MOS series module)
Supports i-Door module (MOS series), except PoE
Please refer to Advantech website below or search "iDoor Module
Mini PCIe Expansion Kit”.
http://www.advantech.com.tw/products/idoor-module-mini-pcie-
expansion-kit/sub_bc858a7f-a52b-441b-a59c-f511289f98bc
i-Door Module
(PCM series module)
Supports i-Door module (PCM series) except PoE
Please refer to Advantech website below:
http://www.advantech.com/products/idoor-technology-mini-pcieex-
pansion-kit/sub_efdb96af-a8f7-4cde-9592-dbf5c9794d16
Note: A bracket is required to fix PCM series i-door module. Please
refer to P/N: 1960065854N001 i Door_bracket
Part Number Description
98R1751300E 1x8cm FAN module (for MIC-75M13/75M40/75S20)
98R1752000E 2x4cm FAN module (for MIC-75M20/MIC-75M11)

MIC-770 V2 User Manual x

xi MIC-770 V2 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 2
1.2.1 General ......................................................................................... 2
1.2.2 Display .......................................................................................... 3
1.2.3 Ethernet ........................................................................................ 3
1.2.4 SUSI API....................................................................................... 3
1.2.5 WISE-iBMC Out-of-band Power Management ............................. 3
1.3 Chipset ...................................................................................................... 4
1.3.1 Functional Specification ................................................................ 4
1.4 Mechanical Specifications......................................................................... 6
1.4.1 Dimensions ................................................................................... 6
Figure 1.1 MIC-770 V2 Mechanical Dimension Drawing ............. 6
1.4.2 Weight........................................................................................... 6
1.5 Power Requirements................................................................................. 7
1.5.1 System Power............................................................................... 7
1.5.2 RTC Battery .................................................................................. 7
1.6 Environment Specification......................................................................... 7
1.6.1 Operating Temperature................................................................. 7
1.6.2 System Safety Certification Test Temperature ............................. 7
1.6.3 Relative Humidity .......................................................................... 7
1.6.4 Storage Temperature.................................................................... 7
1.6.5 Vibration During Operation ........................................................... 7
1.6.6 Shock During Operation................................................................ 7
1.6.7 Safety............................................................................................ 7
1.6.8 EMC .............................................................................................. 7
Chapter 2 H/W Installation....................................9
2.1 Introduction ............................................................................................. 10
2.2 Jumper & Slide Switch ............................................................................ 10
2.2.1 Jumper Description ..................................................................... 10
2.2.2 Jumper List ................................................................................. 11
Table 2.1: Jumper List ............................................................... 11
2.3 Connectors.............................................................................................. 12
2.3.1 MIC-770 V2 External I/O Connectors ......................................... 12
Figure 2.1 MIC-770 V2 Front View ............................................ 12
Table 2.2: COM Connector Pin Assignments............................ 13
Figure 2.2 Ethernet Connector .................................................. 14
Table 2.3: Ethernet Connector Pin Assignments....................... 14
Figure 2.3 Audio Connector....................................................... 14
Table 2.4: Audio Connector Pin Assignments ........................... 14
Figure 2.4 USB3.2/3.1 Connector.............................................. 15
Table 2.5: USB 3.0 Connector Pin Assignment......................... 15
Figure 2.5 VGA Connector ........................................................ 15
Table 2.6: VGA Connector Pin Assignments............................. 15
Figure 2.6 HDMI Receptacle Connector.................................... 16
Table 2.7: HDMI Connector Pin Assignments ........................... 16
Figure 2.7 4-pin Header............................................................. 16
Table 2.8: Pin Assignments for Power Connector Pin Header.. 16
Figure 2.8 Power Button ............................................................ 17
Figure 2.9 LED Indicators .......................................................... 17
2.4 Installation ............................................................................................... 18
2.4.1 HDD Installation .......................................................................... 18

MIC-770 V2 User Manual xii
2.4.2 Memory Installation..................................................................... 20
2.4.3 m-SATA/Mini-PCIe Installation ................................................... 20
2.4.4 Internal USB 2.0 Installation (W SKU only) ................................ 21
2.4.5 COM 3/4/5/6 Ports Installation.................................................... 21
2.4.6 Expansion Module Installation (Optional) ................................... 22
2.4.7 MIC-770 V2 MB I/O Connector................................................... 24
Chapter 3 BIOS Operation ................................. 25
3.1 Introduction ............................................................................................. 26
Figure 3.1 Main Setup Screen.................................................. 26
3.2 Entering BIOS Setup............................................................................... 27
3.2.1 Main Menu .................................................................................. 27
Figure 3.2 Main Setup Screen................................................... 27
3.2.2 Advanced BIOS Features Setup................................................. 28
Figure 3.3 Advanced BIOS Features Setup Screen.................. 28
Figure 3.4 iBMC Configuration .................................................. 29
Figure 3.5 Platform Misc Configuration ..................................... 30
Figure 3.6 CPU Configuration ................................................... 31
Figure 3.7 Power & Performance .............................................. 33
Figure 3.8 CPU - Power Management Control.......................... 33
Figure 3.9 PCH-FW Configuration............................................. 34
Figure 3.10AMT Configuration ................................................... 35
Figure 3.11CIRA Configuration .................................................. 35
Figure 3.12ASF Configuration .................................................... 36
Figure 3.13Secure Erase Configuration ..................................... 37
Figure 3.14OEM Flags Settings ................................................. 38
Figure 3.15MEBx Resolution Settings........................................ 39
Figure 3.16Firmware Update Configuration ............................... 40
Figure 3.17TPM Settings............................................................ 41
Figure 3.18 ACPI Settings .......................................................... 42
Figure 3.19SMART Settings....................................................... 43
Figure 3.20Super IO Configuration............................................. 44
Figure 3.21Serial Port 1 Configuration ....................................... 44
Figure 3.22Serial Port 2 Configuration ....................................... 45
Figure 3.23Serial Port 3 Configuration ....................................... 45
Figure 3.24Serial Port 4 Configuration ....................................... 46
Figure 3.25Serial Port 5 Configuration ....................................... 46
Figure 3.26Serial Port 6 Configuration ....................................... 47
Figure 3.27PC Health Status...................................................... 48
Figure 3.28S5 RTC Wake Settings ............................................ 51
Figure 3.29Serial Port Console Redirection ............................... 52
Figure 3.30Legacy Console Redirection Settings ...................... 52
Figure 3.31 Intel® TXT Information ............................................ 53
Figure 3.32USB Configuration.................................................... 54
Figure 3.33Network Stack Configuration.................................... 55
Figure 3.34CSM Configuration ................................................... 56
Figure 3.35NVMe Configuration ................................................. 57
3.2.3 Chipset........................................................................................ 58
Figure 3.36Chipset ..................................................................... 58
Figure 3.37System Agent (SA) Configuration ............................ 59
Figure 3.38Memory Configuration .............................................. 60
Figure 3.39Graphics Configuration............................................. 61
Figure 3.40PEG Port Configuration............................................ 62
Figure 3.41PEG Port Feature Configuration .............................. 62
Figure 3.42PCH-IO Configuration .............................................. 63
Figure 3.43PCI Express Configuration ....................................... 64
Figure 3.44PCI Express Root Port ............................................. 65
Figure 3.45SATA and RST Configuration .................................. 66

xiii MIC-770 V2 User Manual
Figure 3.46USB Configuration.................................................... 67
Figure 3.47Security Configuration .............................................. 68
Figure 3.48HD Audio Configuration............................................ 69
3.2.4 Security ....................................................................................... 70
Figure 3.49Security..................................................................... 70
3.2.5 Boot............................................................................................. 71
Figure 3.50Boot .......................................................................... 71
3.2.6 Save & Exit ................................................................................. 72
Figure 3.51Save & Exit ............................................................... 72
Chapter 4 Software Installation .........................73
4.1 Before you begin ..................................................................................... 74
4.2 Introduction ............................................................................................. 74
4.3 Windows Driver Setup............................................................................. 74
Chapter 5 Integrated Graphic Device Setup .....75
5.1 Introduction ............................................................................................. 76
5.2 Windows Driver Setup............................................................................. 76
Chapter 6 Intel® ME ............................................77
6.1 Introduction ............................................................................................. 78
6.2 Installation ............................................................................................... 78
Chapter 7 LAN Configuration.............................79
7.1 Introduction ............................................................................................. 80
7.2 Features .................................................................................................. 80
7.3 Installation ............................................................................................... 80
7.4 Windows Driver Setup............................................................................. 80
Chapter 8 SATA RAID Setup ..............................81
8.1 Introduction ............................................................................................. 82
8.2 SATA RAID Driver and Utility Setup ....................................................... 82
Chapter 9 HD Audio ............................................83
9.1 Introduction ............................................................................................. 84
9.2 Installation ............................................................................................... 84
Appendix A Programming the Watchdog Timer..85
A.1 Programming the Watchdog Timer ......................................................... 86
A.1.1 Watchdog Timer Overview.......................................................... 86
A.1.2 Programming the Watchdog Timer ............................................. 86
Table A.1: Watchdog Timer Registers ....................................... 88
A.1.3 Example Program ....................................................................... 89
Appendix B Programming the GPIO.....................93

MIC-770 V2 User Manual xiv
B.1 Supported GPIO Register ....................................................................... 94
B.1.1 GPIO Registers........................................................................... 94
B.1.2 GPIO Example Program ............................................................. 95

Chapter 1
1General Introduction
This chapter gives background
information on MIC-770 V2.

MIC-770 V2 User Manual 2
1.1 Introduction
MIC-770 V2 is a compact, fanless system incorporating latest generation Intel ® 14nm
platform with new PCH W480E/H420E on a proprietary form factor M/B. MIC-770 V2
system design concept focus on an “expansion slot module”, so different applications
can integrate the MIC-770 V2 system to form a complete industrial computer.
The MIC-770 V2 also can serve as an independent, fanless, Compact Embedded Box
computer and accepts a wide range of DC power inputs. The rugged aluminum case
not only provides a great thermal solution, but also resists high EMI/shock/vibration.
MIC-770 V2 is equipped with 10th Gen Xeon/Core i desktop CPU featuring up to 10
cores, making it highly suitable for embedded and industrial PC applications requiring
high processor performance within limited spaces. It features powerful I/O interfaces,
including Ethernet, USB 3.0, serial port, and two Mini PCIe.
MIC-770 V2 (W SKU) also adopts Advantech WISE-iBMC out-of-band management
solution for remote power control via NIC port, LAN2, while OS is abnormal.
With all the excellent features and outstanding performance, the MIC-770 V2 is the
ideal platform for today’s industrial applications.
1.2 Product Features
1.2.1 General
CPU: Intel
®
10th Gen Xeon/Core i CPU socket (LGA1200) (Xeon support by
W480E SKU only)
PCH: Intel
®
W480E/H420E
System Memory: Dual-channel DDR4 2666/2933 MHz (ECC SO-DIMM)
(W480E SKU only)), up to 64GB
Storage Devices: Supports 1 drive bay space for SATA 2.5" HDD/SSD (Up to
2x with optional kit)
mSATA: Supports 1 x mSATA by mini-PCIe slot
Graphic: VGA + HDMI
Ethernet Port: 2 x RJ45
Watchdog Timer: Single chip watchdog 255-level interval timer, setup by soft-
ware
I/O Interface: 2 x RS-232/422/485 supports auto flow control; 4 x RS-232 via
optional cable
USB:
–W480E: W480E: 2 x USB3.2 (Gen.2), 6 x USB3.2 (Gen.1)
–H420E: 4 x USB 3.2 (Gen.2) and 4 x USB 2.0
Audio: High Definition Audio (HD), Line-out, Mic-in
Expansion interface:
–W480E: 1 x mini PCIe (via Nano-SIM), 1x mini PCIe/mSATA
–H420E: 1 x mini PCIe (via Nano-SIM), 1x mSATA

3 MIC-770 V2 User Manual
Chapter 1 General Introduction
1.2.2 Display
Chipset:
–W480E: Intel® HD Graphics 630, supports DirectX 12
–H420E: Intel® HD Graphics 610, supports DirectX 12
Resolution:
–VGA: Supports up to 2048 x 1152 @ 60 Hz
–HDMI: Supports up to 3840 x 2160 @ 30Hz
1.2.3 Ethernet
Controller:
–W480E LAN1: Intel® I219LM, LAN2: Intel® i210IT (supports iBMC)
–H420E LAN1: Intel® I219V, LAN2: Intel® i210IT
Speed: 10/100/1000 Mbps
Interface: 2 x RJ45
Standard: Compliant with IEEE 802.3, IEEE802.3u, IEEE 802.ab.
1.2.4 SUSI API
MIC-770 V2 supports SUSI API which helps customers to develop their own remote
management programs under Windows 10.
1.2.5 WISE-iBMC Out-of-band Power Management
MIC-770 V2 W480E SKU is equipped with WISE-iBMC solution which pro-
vides out-of-band management for remote power-on/power-off/reset/
force-shutdown via LAN2 if abnormal conditions are selected.
Note! WISE-iBMC power control function is operated on Advantech WISE-
DeviceOn software. Before installation and setup of WISE-Agent pro-
gram, changing device IP address to the same as your network IP via a
utility tool is necessary. Please refer to product support website to down-
load iBMC utility, DeviceOn software, and SOP/user manual.

MIC-770 V2 User Manual 4
1.3 Chipset
1.3.1 Functional Specification
1.3.1.1 Processor
1.3.1.2 Chipset
Processor Intel® 10th Gen Xeon/Core i CPU socket (LGA1200) (Xeon support by
W480E SKU only)
PCH Intel® W480E/H420E chipset
Memory
Supports DDR4 2666/2933 MHz ECC RAM (W480E SKU only)
(without ECC)
SODIMM Socket:
–260-pin SODIMM socket*2 (up to 32GB per socket)
Chipset
integrated Intel
HD Graphic
Intel® HD Graphics 630/610
Supports DirectX 12
Supports OpenGL 4.4
Supports Intel® Quick Sync Video
IO interface
–VGA: Supports resolutions up to 2048 x 1152 @ 60 Hz
(VGA connector: On-board D-SUB 15P)
–HDMI: Supports resolution up to 3840×2160 @30Hz
(HDMI Connector: On-board HDMI)
SATA Interface
3 x SATA3.0 (W SKU), 2 x SATA3.0 (H SKU)
Legacy IED (Including IRQ)/Native AHCI appearance to OS
Partial/slumber power management modes with wake
Capable of 6Gbit/s transfer rate
USB Interface
W480E: 2 x USB3.2 (Gen.2) , 6 x USB3.2 (Gen.1)
H420E: 4 x USB 3.2 (Gen.2) and 4 x USB 2.0
Supports high-speed, full-speed, and low-speed capable
Supports legacy keyboard/mouse software
Power
Management
Supports ACPI 5.0
ACPI Power Management Logic supported
Power Connector: plug-in block 4Px1
BIOS AMI 256Mb (W SKU)/128Mb (H SKU) Flash BIOS via SPI
Note! Legacy platform is not supported.

5 MIC-770 V2 User Manual
Chapter 1 General Introduction
1.3.1.3 Others
Serial ports
Nuvoton NCT 6106D supported
Up to 6 serial ports by Nuvoton NCT6106D supported
High speed NS16C550A compatible UARTs with date rates to 1.5
Mbps
Supports IRQ sharing among serial port
COM1/2: Supports RS-232/422/485 and setting mode by BIOS and
supports auto flow control
COM 3~6: Support for RS-232, via optional cable
Serial ports connector: D-SUB CON.9P
LAN
W480E LAN1: Intel® I219LM (PHY), LAN2: Intel® i210IT I210IT (NIC)
(Support iBMC)
H420E LAN1: Intel® I219V (PHY), LAN2: Intel® i210IT I210IT (NIC)
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.ab.
Supports 10/100/1000 Mbps
Supports Wake on LAN
Audio
Audio Codec: Realtek ALC888:
 Compliant with HD Audio specifications
 Supports to 16/20/24-bit DAC and 16/20/24-bit ADC resolution
 Supports: Line-out, Mic-in
DAC supports 16/20/24-bit PCM format, multiple stereo recording
Industrial
Features
Watchdog timer:
Can generate system reset or NC. The watchdog timer is program-
mable, with each unit equal to one second (255 levels).
Battery backup BR2032 3 V/190mAh

MIC-770 V2 User Manual 6
1.4 Mechanical Specifications
1.4.1 Dimensions
Figure 1.1 MIC-770 V2 Mechanical Dimension Drawing
1.4.2 Weight
2.8kg (6.17lbs)
77
192
230
UNIT : mm
