Advantech PCLD-8751 User manual

PCLD-8751/8761/8762
48-Channel Isolated D/I
and Relay Board
User Manual

PCLD-8751/8761/8762 User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2006 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
All product names / trademarks are properties of their respective owners.
Part No. 2003876200 1st Edition
Printed in Taiwan August 2006

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

PCLD-8751/8761/8762 User Manual iv
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (OS, version, software, etc.)
- A complete description of the problem
- The exact wording of any error messages

v
Contents
Chapter 1 Introduction ..................................................... 2
1.1 General Information .......................................................... 2
1.2 Features ............................................................................. 2
Table 1.1:PCLD-8751/8761/8762 Channel Information 2
Chapter 2 Installation ....................................................... 4
2.1 Initial Inspection................................................................ 4
2.1.1 Caution! ........................................................................ 4
2.2 Connectors and Jumpers.................................................... 5
Chapter 3 Operations...................................................... 18
3.1 Power Source Selection................................................... 18
3.2 Control Logic .................................................................. 18
3.3 Wiring.............................................................................. 19
3.3.1 Isolated DI .................................................................... 19
Appendix A Specifications ................................................. 22
A.1 Isolated Digital Input....................................................... 22
A.2 Relay Output ................................................................... 22
A.3 General ............................................................................ 22

PCLD-8751/8761/8762 User Manual vi

2
CHAPTER
1
Introduction
This chapter introduces PCLD-8751,
PCLD-8761, and PCLD-8762.
Sections include:
• General Information
• Features

PCLD-8751/8761/8762 User Manual 2
Chapter 1 Introduction
1.1 General Information
PCLD-8751, PCLD-8761 and PCLD-8762 are daughter boards that fea-
ture 48 isolated digital input/relay output channels. They can only be used
by Advantech’s TTL DI/O cards with a 68-pin SCSI connector (PCI-1751
and PCI-1753 series).
In addition to onboard screw terminals for easy wiring, each channel is
equipped with an LED to indicate the status. If the input voltage level is
high or the output channel is activated, the LED will be lit, otherwise the
LED is off. You may configure the channels to work in either positive
logic mode or negative logic mode by setting the onboard jumpers.
1.2 Features
• Works with Advantech TTL DI/O cards equipped with 48 digital input/
output channels on SCSI 68-pin cable connectors
• 48 opto-isolated digital input/ relay output channels
• Detachable screw terminal for easy wiring
• LEDs indicate input/output logic status
Table 1.1: PCLD-8751/8761/8762 Channel Information
Module PCLD-8751 PCLD-8761 PCLD-8762
Isolated DI Channels 48 24 N/A
Relay Output Channels N/A 24 48

2
CHAPTER
2
Installation
This chapter show how to install and
configure PCLD-8751, PCLD-8761 &
PCLD-8762.
Sections include:
• Initial Inspection
• Connectors and Jumpers

PCLD-8751/8761/8762 User Manual 4
Chapter 2 Installation
2.1 Initial Inspection
PCLD-8751, PCLD-8761 & PCLD-8762 are thoroughly inspected before
being shipped. Before installing the board, make sure that everything has
been included in the package. You should also inspect the board for any
defects or damage that may have occurred during shipping. If you find
anything missing, defective or damaged, contact your dealer immediately.
2.1.1 Caution!
The board should be handled by the edges only. Static electric discharge
can damage the integrated circuits on the board
Packing List
• 1 * PCLD-8751, PCLD-8761 or PCLD-8762.
• 1 * User Manual
Remove the board from its protective packaging. Keep the packaging,
since it may be used to return the card if it needs repairs. The packaging
may also be used if the card is to be stored for any length of time.

5 Chapter2
2.2 Connectors and Jumpers
2.2.1 PCLD-8751 (48-Ch Isolated Digital Input Board)

PCLD-8751/8761/8762 User Manual 6
CN1: SCSI 68-pin Connector

7 Chapter2
TB1/TB2/TB3/TB4: Wiring Terminal Block
TB5: External Power Source Connector
External power source connector for Dry contact mode isolation input
channels. When using Dry contact input mode, it is necessary to provide
external power through TB5. The voltage range is +5V ~ 30V DC.
TB6: Reserved for the Counter Function on PCI-1751/PCI-1751U
SW1~SW12: Wet/Dry Contact Selection
SW1 ~ SW12 are used to switch the input channels as “Wet Contact” or
“Dry Contact”. The factory settings of the switches are in “Off” position,
and the input channels are in Wet contact mode.
You can set each input channel as Dry contact mode by setting the switch
to the “On” position. Following is the mapping table of the DIP switch
and the input channels.
TB1 TB2 TB3 TB4
Name Pin Name Pin Name Pin Name Pin
PA00 1+,1- PB04 13+,13- PA10 25+,25- PB14 37+,37-
PA01 2+,2- PB05 14+,14- PA11 26+,26- PB15 38+,38-
PA02 3+,3- PB06 15+,15- PA12 27+,27- PB16 39+,39-
PA03 4+,4- PB07 16+,16- PA13 28+,28- PB17 40+,40-
PA04 5+,5- PC00 17+,17- PA14 29+,29- PC10 41+,41-
PA05 6+,6- PC01 18+,18- PA15 30+,30- PC11 42+,42-
PA06 7+,7- PC02 19+,19- PA16 31+,31- PC12 43+,43-
PA07 8+,8- PC03 20+,20- PA17 32+,32- PC13 44+,44-
PB00 9+,9- PC04 21+,21- PB10 33+,33- PC14 45+,45-
PB01 10+,10- PC05 22+,22- PB11 34+,34- PC15 46+,46-
PB02 11+,11- PC06 23+,23- PB12 35+,35- PC16 47+,47-
PB03 12+,12- PC07 24+,24- PB13 36+,36- PC17 48+,48-

PCLD-8751/8761/8762 User Manual 8
JP1: Logic Control Isolated Digital Input Channels
The control logic is positive when pin1 and pin2 of JP1 are shorted. If
pin2 and pin3 of JP1 are shorted, then the control logic becomes negative.
The factory setting is positive control logic. (Also see Chapter 3.2)
No.1 No.2 No.3 No.3
SW1 PA00 PA01 PA02 PA03
SW2 PA04 PA05 PA06 PA07
SW3 PB00 PB01 PB02 PB03
SW4 PB04 PB05 PB06 PB07
SW5 PC00 PC01 PC02 PC03
SW6 PC04 PC05 PC06 PC07
SW7 PA10 PA11 PA12 PA13
SW8 PA14 PA15 PA16 PA17
SW9 PB10 PB11 PB12 PB13
SW10 PB14 PB15 PB16 PB17
SW11 PC10 PC11 PC12 PC13
SW12 PC14 PC15 PC16 PC17
JP1
Jumper Setting
Description Positive control logic.
(Default setting)
Negative control logic.

9 Chapter2
2.2.2 PCLD-8761 (24-Ch Isolated DI and 24-Ch Relay Output Board)

PCLD-8751/8761/8762 User Manual 10
CN1: SCSI 68-pin Connector

11 Chapter2
TB1/TB2/TB3/TB4: Wiring Terminal Block
TB5: External Connector for Dry Contact Isolated DI Channels
External power source connector for Dry contact mode isolation input
channels. When using Dry contact input mode, it is necessary to provide
external power through TB5. The voltage range is +5V ~ 30V DC.
TB6: Reserved for the Counter Function on PCI-1751/PCI-1751U
TB7: External Power Source Connector
PCLD-8761’s driving power can be set as external by JP3, and the input
voltage range is DC +7 ~ +30V.
TB1 TB2 TB3 TB4
Name Pin Name Pin Name Pin Name Pin
PA00 1+,1- PB04 13+,
13-
PA10 25COM,25
NC,25NO
PB14 37COM,37
NC,37NO
PA01 2+,2- PB05 14+,
14-
PA11 26COM,26
NC,26NO
PB15 38COM,38
NC,38NO
PA02 3+,3- PB06 15+,
15-
PA12 27COM,27
NC,27NO
PB16 39COM,39
NC,39NO
PA03 4+,4- PB07 16+,
16-
PA13 28COM,28
NC,28NO
PB17 40COM,40
NC,40NO
PA04 5+,5- PC00 17+,
17-
PA14 29COM,29
NC,29NO
PC10 41COM,41
NC,41NO
PA05 6+,6- PC01 18+,
18-
PA15 30COM,30
NC,30NO
PC11 42COM,42
NC,42NO
PA06 7+,7- PC02 19+,
19-
PA16 31COM,31
NC,31NO
PC12 43COM,43
NC,43NO
PA07 8+,8- PC03 20+,
20-
PA17 32COM,32
NC,32NO
PC13 44COM,44
NC,44NO
PB00 9+,9- PC04 21+,
21-
PB10 33COM,33
NC,33NO
PC14 45COM,45
NC,45NO
PB01 10+,1
0-
PC05 22+,
22-
PB11 34COM,34
NC,34NO
PC15 46COM,46
NC,46NO
PB02 11+,1
1-
PC06 23+,
23-
PB12 35COM,35
NC,35NO
PC16 47COM,47
NC,47NO
PB03 12+,1
2-
PC07 24+,
24-
PB13 36COM,36
NC,36NO
PC17 48COM,48
NC,48NO

PCLD-8751/8761/8762 User Manual 12
SW1~SW6: Wet/Dry Contact Selection
SW1 ~ SW12 are used to switch the input channels as “Wet Contact” or
“Dry Contact”. The factory settings of the switches are in “Off” position,
and the input channels are in Wet contact mode.
You can set each input channel as Dry contact mode by setting the switch
to the “On” position. Following is the mapping table of the DIP switch
and the input channels.
JP1/JP2: Logic Control for Isolated Input & Relay Output Channels
The control logic of isolated digital input and relay output channels can
be set separately. The control logic is positive when pin1 and pin2 are
shorted. If pin2 and pin3 are shorted, then the control logic becomes neg-
ative. The factory setting is positive control logic. (Also see Chapter 3.2)
No.1 No.2 No.3 No.3
SW1 PA00 PA01 PA02 PA03
SW2 PA04 PA05 PA06 PA07
SW3 PB00 PB01 PB02 PB03
SW4 PB04 PB05 PB06 PB07
SW5 PC00 PC01 PC02 PC03
SW6 PC04 PC05 PC06 PC07
JP1 (Isolated DI)/ JP2 (Relay Output)
Jumper Setting
)
Description Positive control logic.
(Default setting)
Negative control logic.

13 Chapter2
JP3: Relay Driving Power Source Selection
It is necessary to provide +5 V as the relay channels driving power
source. And the power source can be selected as internal or external by
JP3.
The default setting of JP3 is an internal power source, which means +5V
is provided from the PC. However, you can also select an external power
source by shorting pin2 and pin3 of JP3.
The external power source is provided through TB7. Since there is a
transformer on the circuit, the voltage range of external power should be
within DC +7V ~ +30V.
JP3
Jumper Setting
Description Internal power source
(Default setting)
External power source

PCLD-8751/8761/8762 User Manual 14
2.2.3 PCLD-8762 (48-Channel Relay Output Board)
