Advantech ICR-4401 Guide

Start Guide
ICR-4401, ICR-4434, ICR-4453

Start Guide
Safety Instructions
Please take care to following instructions:
•Use the router in compliance with national and international law and in compliance with
any special or additional restrictions regulating the use of the router in various applica-
tions and environments.
•To avoid possible injury and/or damage to the device, observe the relevant provisions
and standards. Use only the original accessories as recommended. Unauthorized de-
vice or accessory modification or using accessories that have not been approved can
result in router damage and/or violation of the regulations.
•Unauthorized device or accessory modification or using the accessories that have not
been approved can result in warranty termination.
•Do not open the router.
•Caution! This equipment is not suitable for use in locations where children are likely to
be present. The SIM card could be swallowed by small children.
•When connecting the device to a power supply, do not exceed the defined voltage.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture, and high temperature.
•It is recommended that you do not use the router at petrol filling stations. We recommend
observing local restrictions concerning radio-based devices while working with explosive
material, such as at petrol filling stations or in chemical plants.
•While using the router close to personal medical devices, such as cardiac pacemakers
or hearing aids, proceed with heightened caution.
•Operating the router too close to TV sets, radio receivers, personal computers, or tele-
phones can cause interference.
•It is recommended that you create a copy or backup of the essential settings stored in
the memory of the router.
QSG-0010-EN, November 8, 2021 1Released in the Czech Republic

Start Guide
Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) di-
rective was introduced to ensure that electrical/electronic products are recycled
using the best available recovery techniques to minimize the impact on the en-
vironment. This product contains high-quality materials and components which
can be recycled. At the end of its life, this product MUST NOT be mixed with
other commercial waste for disposal. The device contains a battery. Remove
the battery from the device before disposal. The battery in the device needs to be disposed of
apart accordingly. Check the terms and conditions of your supplier for disposal information.
Open Source Software License
The software in this device uses various pieces of open-source software governed by the
following licenses:
•GPL versions 2 and 3
•LGPL version 2
•BSD-style licences
•MIT-style licences
The list of components together with complete license texts can be found on the device
itself. See the Licenses link at the bottom of the router’s main Web page (General Status)
or point your browser to this address (replace the DEVICE_IP string with the real router’s IP
address):
https://DEVICE_IP/licenses.cgi
This is a written offer valid for three years since the device purchase, offering any third party
for a charge no more than the cost of physically performing source distribution, a complete
machine-readable copy of the corresponding source code on a flash drive medium. If you are
interested in obtaining the source, please get in touch with us at:
[email protected]
Modifications and debugging of LGPL-linked executables:
The device manufacturer hereby grants the right to use debugging techniques (e.g., de-
compilation) and making customer modifications of any executable linked with an LGPL library
for its purposes. Note these rights are limited to the customer’s usage. No further distribution
of such modified executables and no transmission of the information obtained during these
actions may be done.
QSG-0010-EN, November 8, 2021 2Released in the Czech Republic

Start Guide
First Use
Before applying power to the router, connect all the components that you need for your
applications. A cross-shaped screwdriver is necessary to insert a SIM card or a microSD card.
Do not run the router without antennas connected to the main antenna connectors as the
energy from the transmission is effectively reflected by the open end and can damage
the equipment.
ICR-4401 routers are not equipped with a cellular module, which means that the SIM
card slots together with the cellular and GNSS antenna connectors are not available on
the router.
1. Antenna
Use SMA connectors to connect the antennas to the router; see the figure below. It is highly
recommended to connect all the antennas.
QSG-0010-EN, November 8, 2021 3Released in the Czech Republic

Start Guide
2. SIM Card
The SIM card reader for two mini-SIM cards (2FF with size of 25.0 x 15.0 x 0.76 mm)
is located on the router’s rear panel under a metal cover. If you intend to use this device to
communicate over a cellular network, please place an activated data-provisioned SIM card
into the SIM card reader. Unscrew the cover and push your SIM card into the SIM1 or SIM2
slot until it clicks into place. You can install two SIM cards simultaneously to utilize the SIM
card switching feature.
Disconnect the router from the power supply before handling the SIM card.
QSG-0010-EN, November 8, 2021 4Released in the Czech Republic

Start Guide
3. Power
The router requires an external DC power supply. The DC voltage required is between
+9 and +48 V DC. The router has built-in protection against reverse polarity without signaling.
Connect the power supply cable to the PWR connector on the router’s front panel; see the
figure below.
The power voltage for the PoE router version must be 48 V DC to work as the PoE PSE
device.
4. Ethernet
For an initial configuration, made in a web browser, connect a PC by an Ethernet cable to
the default LAN interface, use one of the ETH0 ports, see the figure above. By default, this
interface has the following configuration:
Connectors Purpose Default Setting
ETH0 LAN ports (default)
Connect your PC to one of these ports to
get the router web interface.
DHCP Server enabled
IP Address: 192.168.1.1
NetMask: 255.255.255.0
QSG-0010-EN, November 8, 2021 5Released in the Czech Republic

Start Guide
Configuration
1. Configuring the Device Using the Web Browser
You can use a web browser running on your PC to get access to the router web interface.
Here you can perform router monitoring, configuration, and administration. First, connect
the PC to the default LAN interface as described in the Ethernet chapter. To get the router
interface, enter the https://192.168.1.1 address in a web browser. Please note that usage
of the HTTPS protocol for secure communication over the network is required.
By default, there is just the root user account created on the router. See the product label
on the router for its default password. Log in to the web interface by the root user and his
password. See the configuration manual of the router for a detailed description and examples
of the router configuration.
After logging on to the device for the first time, we strongly recommend changing the
default password due to security reasons.
For security reasons, it is highly recommended to update the firmware of the router to the
latest version regularly. Downgrading the firmware to an older version than the production
version or uploading a firmware intended for a different device may cause the malfunction
of the device.
2. Configuration Settings via WebAccess/DMP
Your router has been pre-installed with the WebAccess/DMP client. For its activation,
enable it in the router’s web interface (Customization -> User Modules -> WebAccess/DMP
Client). For more information see the configuration manual of your router.
The activated client periodically uploads router identificators, its configuration, and cellu-
lar network statistics to the WebAccess/DMP server.
With the WebAccess/DMP client activated, you may configure the router from WebAc-
cess/DMP portal. Navigate your browser to https://www.wadmp.com.
If this is your first time, please self-sign-up with the site. If not, please log in with your
username and password. Once logged in, further assistance can be found at https://docs.
wadmp.com.
QSG-0010-EN, November 8, 2021 6Released in the Czech Republic

Start Guide
3. Restoring and Backing up the Router Configuration
If you reset the router, the current configuration replaces by the default factory settings.
Therefore, we recommend you back up the router configuration before resetting the device.
Refer to the configuration manual for more information.
You can restore the default router configuration once the router boots up and the PWR
LED starts blinking. To do so, press the RST button on the router’s front panel for more than
4 seconds. After you press this button, all settings reset to the default values, and the router
will reboot.
Support
All product-related manuals, documents, and software can be found and downloaded on
the website at icr.advantech.cz/download address.
Hereby we, Advantech Czech s.r.o., declare that the radio equipment type ICR-4401
(WiFi version), ICR-4434, and ICR-4453 comply with Directive 2014/53/EU.ICR-4401
(non-WiFi version) complies with Directives 2014/30/EU and 2014/35/EU.
The full text of the EU Declaration of Conformity is available at the following internet address:
icr.advantech.cz/eudoc
QSG-0010-EN, November 8, 2021 7Released in the Czech Republic
