Advantech EKI-9628G User manual

User Manual
EKI-9628G
24G+4G Combo port L3
Managed Switch

EKI-9628G User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2006
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (5 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for five years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out of-
warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any on screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. XXXXXXXXXX Edition 1
Printed in Taiwan July 2017

iii EKI-9628G User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

EKI-9628G User Manual iv
Warnings, Cautions and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advan-
tech.com
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
1 x Industrial Ethernet Switch
2 x Wall-mounting Bracket
1 x Startup Manual
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

v EKI-9628G User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
15. The power cord or plug is damaged.
16. Liquid has penetrated into the equipment.
17. The equipment has been exposed to moisture.
18. The equipment does not work well, or you cannot get it to work according to the
user's manual.
19. The equipment has been dropped and damaged.
20. The equipment has obvious signs of breakage.
21. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
22. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
23. The sound pressure level at theoperator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

EKI-9628G User Manual vi
Wichtige Sicherheishinweise
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie
Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch
zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht zugän-
glich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen
oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor überhit-
zung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen kann. Es
sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom
Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädigung
vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in
das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag aus-
lösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen
und von einer qualifizierten Servicestelle zu überprüfen:
15. Netzkabel oder Netzstecker sind beschädigt.
16. Flüssigkeit ist in das Gerät eingedrungen.
17. Das Gerät war Feuchtigkeit ausgesetzt.
18. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder
Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
19. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
20. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
21. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der Batterie.Ersatz
nur durch densellben order einem vom Hersteller empfohlene-mahnlichen Typ.
Entsorgung gebrauchter Batterien navh Angaben des Herstellers.
22. ACHTUNG: Es besteht die Explosionsgefahr, falls die Batterie auf nicht fach-
männische Weise gewechselt wird. Verfangen Sie die Batterie nur gleicher oder
entsprechender Type, wie vom Hersteller empfohlen. Entsorgen Sie Batterien
nach Anweisung des Herstellers.
23. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt
70dB(A) oder weiger.
Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC-
704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in die-
sem Zusammenhang getätigten Aussagen ab.

vii EKI-9628G User Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

EKI-9628G User Manual viii
Contents
Chapter 1 Product Overview ...............................1
1.1 Specifications............................................................................................ 2
1.2 Hardware Views........................................................................................ 3
1.2.1 Front View..................................................................................... 3
1.2.2 Rear View..................................................................................... 4
1.3 Dimensions............................................................................................... 5
1.4 Packing List............................................................................................... 5
Chapter 2 Switch Installation .............................. 6
2.1 Warnings................................................................................................... 7
2.2 Installation Guidelines............................................................................... 8
2.3 Environment and Enclosure Guidelines.................................................... 9
2.3.1 Connecting Hardware................................................................... 9
2.4 Verifying Switch Operation........................................................................ 9
2.5 Installing the Switch................................................................................ 10
2.5.1 Rack-Mounting............................................................................ 10
2.6 Installing and Removing SFP Modules................................................... 10
2.6.1 Installing SFP Modules............................................................... 11
2.6.2 Removing SFP Modules............................................................. 12
2.7 Connecting the Switch to Ethernet Ports................................................ 13
2.7.1 RJ45 Ethernet Cable Wiring....................................................... 13
2.8 Connecting the Switch to Console Port .................................................. 14
2.9 Power Supply Installation........................................................................ 15
2.9.1 Overview..................................................................................... 15
2.9.2 Considerations............................................................................ 16
2.9.3 Grounding the Device................................................................. 16
2.9.4 Wiring a Relay Contact............................................................... 17
2.9.5 Wiring the Power Inputs.............................................................. 18
2.10 Reset Button........................................................................................... 19
Chapter 3 Configuration Utility .........................20
3.1 First Time Setup...................................................................................... 21
3.1.1 Overview..................................................................................... 21
3.1.2 Introduction................................................................................. 21
3.1.3 Administrative Interface Access.................................................. 21
3.1.4 Using the Graphical (Web) Interface .......................................... 22
3.1.5 Configuring the Switch for Network Access................................ 22
3.1.6 Configuring the Ethernet Ports ................................................... 23
3.2 Command Line Interface Configuration.................................................. 24
3.2.1 Introduction to Command-Line Interface (CLI) ........................... 24
3.2.2 Accessing the CLI....................................................................... 24
3.3 Web Browser Configuration.................................................................... 25
3.3.1 Preparing for Web Configuration................................................ 25
3.3.2 System Login.............................................................................. 25
Chapter 4 Managing Switch............................... 26
4.1 Log In...................................................................................................... 27
4.2 Recommended Practices........................................................................ 27
4.2.1 Changing Default Password....................................................... 27

ix EKI-9628G User Manual
4.3 Monitoring ...............................................................................................28
4.3.1 Device Information......................................................................28
4.3.2 Logging Message........................................................................29
4.3.3 Port Monitoring............................................................................30
4.3.4 Link Aggregation.........................................................................31
4.3.5 LLDP Statistics............................................................................32
4.3.6 IGMP Statistics ...........................................................................33
4.3.7 IGMP Statistics ...........................................................................34
4.4 System ....................................................................................................35
4.4.1 IP Settings...................................................................................35
4.4.2 IPv6 Settings...............................................................................35
4.4.3 System Time...............................................................................36
4.4.4 Network Port...............................................................................37
4.5 L2 Switching............................................................................................38
4.5.1 Port Configuration.......................................................................38
4.5.2 Port Mirror...................................................................................39
4.5.3 Link Aggregation.........................................................................40
4.5.4 802.1Q VLAN..............................................................................43
4.5.5 Q-in-Q.........................................................................................46
4.5.6 GARP..........................................................................................48
4.5.7 802.3az EEE...............................................................................49
4.5.8 Multicast......................................................................................50
4.5.9 Jumbo Frame..............................................................................54
4.5.10 Spanning Tree ............................................................................55
4.5.11 X-Ring Elite.................................................................................60
4.5.12 X-Ring Pro ..................................................................................61
4.5.13 Loopback Detection....................................................................62
4.6 RL3 Switching.........................................................................................64
4.6.1 SNAT (Source NAT) ...................................................................64
4.6.2 DNAT (Destination NAT).............................................................65
4.6.3 Routing........................................................................................66
4.7 MAC Address Table................................................................................66
4.7.1 Static MAC..................................................................................66
4.7.2 MAC Aging Time.........................................................................67
4.7.3 Dynamic Forwarding Table.........................................................67
4.8 Security ...................................................................................................68
4.8.1 Storm Control..............................................................................68
4.8.2 Port Security ...............................................................................70
4.8.3 Protected Ports...........................................................................70
4.8.4 DoS Prevention...........................................................................71
4.8.5 Applications.................................................................................73
4.8.6 802.1x.........................................................................................75
4.8.7 IP Security...................................................................................76
4.9 QoS.........................................................................................................77
4.9.1 General.......................................................................................77
4.9.2 QoS Basic Mode.........................................................................83
4.9.3 Rate Limit....................................................................................84
4.10 Management...........................................................................................86
4.10.1 LLDP...........................................................................................86
4.10.2 SNMP..........................................................................................89
4.10.3 TCP Modbus Settings.................................................................91
4.10.4 DHCP Server..............................................................................92
4.10.5 SMTP Client................................................................................97
4.10.6 RMON.......................................................................................100
4.11 Diagnostics............................................................................................103
4.11.1 Cable Diagnostics.....................................................................103
4.11.2 Ping Test...................................................................................104
4.11.3 IPv6 Ping Test...........................................................................105
4.11.4 System Log...............................................................................106
4.11.5 DDM..........................................................................................108

EKI-9628G User Manual x
4.11.6 LED Indication .......................................................................... 109
4.12 Tools..................................................................................................... 110
4.12.1 Backup Manager....................................................................... 110
4.12.2 Upgrade Manager..................................................................... 111
4.12.3 Dual Image ............................................................................... 111
4.12.4 Save Configuration................................................................... 112
4.12.5 User Account............................................................................ 112
4.12.6 Reset System ........................................................................... 113
4.12.7 Reboot Device.......................................................................... 113
4.13 Modbus/TCP Mapping.......................................................................... 113
4.13.1 Modbus/TCP Mapping Table.................................................... 113
Chapter 5 Troubleshooting..............................133
5.1 Troubleshooting.................................................................................... 134

xi EKI-9628G User Manual
List of Figures
Figure 1.1 Front View .....................................................................................................................3
Figure 1.2 System LED Panel ........................................................................................................3
Figure 1.3 Rear View......................................................................................................................4
Figure 1.4 Dimensions....................................................................................................................5
Figure 2.1 Installing the Rack Mount Brackets .............................................................................10
Figure 2.2 Installing the Switch.....................................................................................................10
Figure 2.3 Removing the Dust Plug from an SFP Slot .................................................................11
Figure 2.4 Installing an SFP Transceiver......................................................................................11
Figure 2.5 Attaching a Fiber Optic Cable to a Transceiver...........................................................12
Figure 2.6 Removing a Fiber Optic Cable to a Transceiver..........................................................12
Figure 2.7 Removing an SFP Transceiver....................................................................................12
Figure 2.8 Ethernet Plug & Connector Pin Position......................................................................13
Figure 2.9 Serial Console Cable...................................................................................................14
Figure 2.10 DB 9 Pin Position.........................................................................................................14
Figure 2.11 Pin Assignment............................................................................................................14
Figure 2.12 Power Wiring for EKI-9628G.......................................................................................15
Figure 2.13 Grounding Connection.................................................................................................17
Figure 2.14 Terminal Receptor: Relay Contact ..............................................................................17
Figure 2.15 Terminal Receptor: Power Input Contacts...................................................................18
Figure 2.16 Installing DC Wires in a Terminal Block ......................................................................18
Figure 4.1 Login Screen ...............................................................................................................27
Figure 4.2 Changing a Default Password.....................................................................................28
Figure 4.3 Monitoring > Device Information..................................................................................28
Figure 4.4 Monitoring > Logging Message ...................................................................................29
Figure 4.5 Monitoring > Port Monitoring > Port Statistics .............................................................30
Figure 4.6 Monitoring > Port Monitoring > Port Utilization............................................................31
Figure 4.7 Monitoring > Link Aggregation.....................................................................................31
Figure 4.8 Monitoring > LLDP Statistics .......................................................................................32
Figure 4.9 Monitoring > IGMP Statistics.......................................................................................33
Figure 4.10 Monitoring > MLD Statistics.........................................................................................34
Figure 4.11 System > IP Settings...................................................................................................35
Figure 4.12 System > IPv6 Settings ...............................................................................................35
Figure 4.13 System > System Time................................................................................................36
Figure 4.14 System > Network Port................................................................................................37
Figure 4.15 L2 Switching > Port Configuration...............................................................................38
Figure 4.16 L2 Switching > Port Mirror...........................................................................................39
Figure 4.17 L2 Switching > Link Aggregation > Load Balance.......................................................40
Figure 4.18 L2 Switching > Link Aggregation > LAG Management................................................40
Figure 4.19 L2 Switching > Link Aggregation > LAG Port Settings ................................................41
Figure 4.20 L2 Switching > Link Aggregation > LACP Priority Settings .........................................41
Figure 4.21 L2 Switching > Link Aggregation > LACP Port Settings..............................................42
Figure 4.22 L2 Switching > 802.1Q VLAN > VLAN Management ..................................................43
Figure 4.23 L2 Switching > 802.1Q VLAN > PVID Settings ...........................................................43
Figure 4.24 L2 Switching > 802.1Q VLAN > Port to VLAN.............................................................45
Figure 4.25 L2 Switching > 802.1Q VLAN > VLAN Interface Management ...................................46
Figure 4.26 L2 Switching > Q-in-Q > Global Settings.....................................................................46
Figure 4.27 L2 Switching > Q-in-Q > Port Settings.........................................................................47
Figure 4.28 L2 Switching > GARP > GARP Settings......................................................................48
Figure 4.29 L2 Switching > GARP > GVRP Settings......................................................................49
Figure 4.30 L2 Switching > 802.3az EEE.......................................................................................49
Figure 4.31 L2 Switching > Multicast > Multicast Filtering..............................................................50
Figure 4.32 L2 Switching > Multicast > IGMP Snooping > IGMP Settings.....................................50
Figure 4.33 L2 Switching > Multicast > IGMP Snooping > IGMP Querier......................................51
Figure 4.34 L2 Switching > Multicast > IGMP Snooping > IGMP Static Groups ............................51
Figure 4.35 L2 Switching > Multicast > MLD Snooping > MLD Settings ........................................52
Figure 4.36 L2 Switching > Multicast > MLD Snooping > MLD Querier .........................................53

EKI-9628G User Manual xii
Figure 4.37 L2 Switching > Multicast > MLD Snooping > MLD Static Group................................. 53
Figure 4.38 L2 Switching > Jumbo Frame...................................................................................... 54
Figure 4.39 L2 Switching > Spanning Tree > STP Global Settings................................................ 55
Figure 4.40 L2 Switching > Spanning Tree > STP Port Settings.................................................... 56
Figure 4.41 L2 Switching > Spanning Tree > STP Bridge Settings................................................ 57
Figure 4.42 L2 Switching > Spanning Tree > STP Port Advanced Settings................................... 57
Figure 4.43 L2 Switching > Spanning Tree > MST Config Identification........................................ 58
Figure 4.44 L2 Switching > Spanning Tree > MST Instance ID Settings ....................................... 58
Figure 4.45 L2 Switching > Spanning Tree > MST Instance Priority Settings................................ 59
Figure 4.46 L2 Switching > X-Ring Elite > X-Ring Elite Settings.................................................... 60
Figure 4.47 L2 Switching > X-Ring Elite > X-Ring Elite Groups..................................................... 60
Figure 4.48 L2 Switching > X-Ring Pro > X-Ring Pro Settings....................................................... 61
Figure 4.49 L2 Switching > X-Ring Pro > X-Ring Pro Groups > X-Ring Pro Groups Settings ....... 61
Figure 4.50 L2 Switching > X-Ring Pro > X-Ring Pro Groups > Couple Setting............................ 62
Figure 4.51 L2 Switching > Loopback Detection > Global Settings................................................ 62
Figure 4.52 L2 Switching > Loopback Detection > Port Settings ................................................... 63
Figure 4.53 L3 Switching > SNAT > Global Settings...................................................................... 64
Figure 4.54 L3 Switching > SNAT > Entry Settings........................................................................ 64
Figure 4.55 L3 Switching > DNAT..................................................................................................65
Figure 4.56 L3 Switching > Routing ...............................................................................................66
Figure 4.57 MAC Address Table > Static MAC.............................................................................. 66
Figure 4.58 MAC Address Table > MAC Aging Time..................................................................... 67
Figure 4.59 MAC Address Table > Dynamic Forwarding Table..................................................... 67
Figure 4.60 Security > Storm Control > Global Settings................................................................. 68
Figure 4.61 Security > Storm Control > Port Settings .................................................................... 69
Figure 4.62 Security > Port Security............................................................................................... 70
Figure 4.63 Security > Protected Ports...........................................................................................70
Figure 4.64 Security > DoS Prevention > DoS Global Settings...................................................... 71
Figure 4.65 Security > DoS Prevention > DoS Port Settings ......................................................... 72
Figure 4.66 Security > Applications > TELNET.............................................................................. 73
Figure 4.67 Security > Applications > SSH .................................................................................... 73
Figure 4.68 Security > Applications > HTTP .................................................................................. 74
Figure 4.69 Security > Applications > HTTPS................................................................................ 74
Figure 4.70 Security > 802.1x > 802.1x Settings............................................................................ 75
Figure 4.71 Security > 802.1x > 802.1x Port Configuration............................................................ 76
Figure 4.72 Security > IP Security > Global Settings ..................................................................... 76
Figure 4.73 Security > IP Security > Entry Settings ....................................................................... 77
Figure 4.74 QoS > General > QoS Properties................................................................................ 78
Figure 4.75 QoS > General > QoS Settings................................................................................... 78
Figure 4.76 QoS > General > QoS Scheduling.............................................................................. 79
Figure 4.77 QoS > General > CoS Mapping .................................................................................. 80
Figure 4.78 QoS > General > DSCP Mapping ............................................................................... 81
Figure 4.79 QoS > General > IP Precedence Mapping.................................................................. 82
Figure 4.80 QoS > QoS Basic Mode > Global Settings.................................................................. 83
Figure 4.81 QoS > QoS Basic Mode > Port Settings ..................................................................... 83
Figure 4.82 QoS > Rate Limit > Ingress Bandwidth Control........................................................... 84
Figure 4.83 QoS > Rate Limit > Egress Bandwidth Control........................................................... 84
Figure 4.84 QoS > Rate Limit > Egress Queue.............................................................................. 85
Figure 4.85 Management > LLDP > LLDP System Settings.......................................................... 86
Figure 4.86 Management > LLDP > LLDP Port Settings > LLDP Port Configuration..................... 87
Figure 4.87 Management > LLDP > LLDP Port Settings > Optional TLVs Selection..................... 87
Figure 4.88 Management > LLDP > LLDP Port Settings > VLAN Name TLV VLAN Selection...... 88
Figure 4.89 Management > LLDP > LLDP Remote Device Info..................................................... 88
Figure 4.90 Management > SNMP > SNMP Settings .................................................................... 89
Figure 4.91 Management > SNMP > SNMP Community............................................................... 89
Figure 4.92 Management > SNMP > SNMP User Settings............................................................ 90
Figure 4.93 Management > SNMP > SNMP Trap.......................................................................... 91
Figure 4.94 Management > TCP Modbus Settings > TCP Modbus Settings ................................. 91
Figure 4.95 Management > DHCP Server > Status Settings......................................................... 92
Figure 4.96 Management > DHCP Server > Global Settings......................................................... 93

xiii EKI-9628G User Manual
Figure 4.97 Management > DHCP Server > Port Settings.............................................................94
Figure 4.98 Management > DHCP Server > VLAN Settings ..........................................................95
Figure 4.99 Management > DHCP Server > Option 82 Settings....................................................96
Figure 4.100 Management > SMTP Client > Global Settings...........................................................97
Figure 4.101 Management > SMTP Client > Profile Settings > Profile Settings...............................97
Figure 4.102 Management > SMTP Client > Profile Settings > Profile Target Mail Settings............98
Figure 4.103 Management > SMTP Client > Sending Message ......................................................99
Figure 4.104 Management > RMON > Rmon Statistics .................................................................100
Figure 4.105 Management > RMON > RMON History ...................................................................100
Figure 4.106 Management > RMON > Rmon Alarm ......................................................................101
Figure 4.107 Management > RMON > RMON Event.....................................................................102
Figure 4.108 Diagnostics > Cable Diagnostics...............................................................................103
Figure 4.109 Diagnostics > Ping Test.............................................................................................104
Figure 4.110 Diagnostics > IPv6 Ping Test.....................................................................................105
Figure 4.111 Diagnostics > System Log > Logging Service...........................................................106
Figure 4.112 Diagnostics > System Log > Local Logging ..............................................................107
Figure 4.113 Diagnostics > System Log > System Log Server......................................................108
Figure 4.114 Diagnostics > DDM....................................................................................................108
Figure 4.115 Diagnostics > DDM....................................................................................................109
Figure 4.116 Diagnostics > LED Indication.....................................................................................109
Figure 4.117 Tools > Backup Manager...........................................................................................110
Figure 4.118 Tools > Upgrade Manager.........................................................................................111
Figure 4.119 Tools > Dual Image ...................................................................................................111
Figure 4.120 Tools > User Account................................................................................................112

Chapter 1
1Product Overview

2 EKI-9628G User Manual
1.1 Specifications
Specifications Description
Interface I/O Port 24 x 10/100/1000BaseT(X) + 4 x 10/100/1000Base-
T(X) or 4 x 100/1000Base-X SFP Port
Power Connector 4-pin removable screw terminal (power)
3-pin removable screw terminal (relay)
Physical Enclosure Metal Shell
Protection Class IP30
Installation Rack mounting
Dimensions
(W x H x D) 438.0 x 43.6 x 259.2mm
LED Display System LED SYS, PWR1, PWR2, P-Fail, Loop detection, R.M.,
Ring Fail, Temp
Port LED Speed, Link, Activity
Environment Operating
Temperature -40°C ~ 70°C (-40°F ~ 158°F)
Storage
Temperature -40°C ~ 85°C (-40°F ~ 185°F)
Ambient Relative
Humidity 10 ~ 95% (non-condensing)
Switch Properties MAC Address 8K-entry
Switching Band-
width 56 Gbps
Power Power
Consumption 20W @ 24V
Power Input 12V~48VDC
Certifications Safety UL 61010-2-201
EMC CE, FCC
EMI EN55022 Class A
EMS EN 61000-4-2 (ESD) Level 3
EN 61000-4-3 (RS) Level 3;
EN 61000-4-4 (EFT) Level 3
EN 61000-4-5 (Surge) Level 3;
EN 61000-4-6 (CS) Level 3
EN 61000-4-8 (Magnetic Field) Level 3
Shock IEC 60068-2-27
Freefall IEC 60068-2-32
Vibration IEC 60068-2-6
Railway Track
Side EN 50121-4

EKI-9628G User Manual 3
1.2 Hardware Views
1.2.1 Front View
Figure 1.1 Front View
1.2.1.1 System LED Panel
Figure 1.2 System LED Panel
No. Item Description
1 Reset button Button allows for system soft reset (3 sec.) or factory default reset
(5 sec.).
2 System LED
panel See “System LED Panel” on page 3 for further details.
3 ETH port RJ45 ports x 4.
4 SFP LEDs SFP link activity LEDs.
5 ETH port Fiber ports x 4.
6 LNK/ACT LED Link activity LED.
7 Speed LED Orange: 100M
Green: 1G
8 ETH port RJ45 ports x 24.
EKI-9628G
R.M. LINK / ACT
28
27
26
25
28
27
26
25
28
27
26
25
2 LINK/ACT Speed
LINK/ACT Speed
LINK/ACT Speed
LINK/ACT Speed
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
18
17
20
19
22
21
24
23
R-Fail
Temp
LOOP
SYS
PW1
PW2
P-FAIL
Reset
12534 67 8
No. LED Name LED Color Description
1 SYS Solid green System is operating normally.
Off System is powered down / system crash / oper-
ation initiating.
2 PWR1 Solid green Powered up.
Off Powered down or not installed.
3 PWR2 Solid green Powered up.
Off Power down or not installed.
4 P-FAIL Solid red When PW1 or PW2 is disconnected, the LED
lights.
Off When PW1 and PW2 is connected, the LED is
off.
5 LOOP Detection Solid red When loop detected, the LED lights.
Off No loop detected.
R.M. LINK / ACT
R-Fail
Temp
LOOP
SYS
PW1
PW2
P-FAIL
28
27
26
25
1
2
3
4
57
6
8910 11

4 EKI-9628G User Manual
1.2.2 Rear View
Figure 1.3 Rear View
6R.M.
(Ring Master) Solid green An active switch within the ring is a designated ring master.
Off No ring master determined in current ring.
7 Ring Fail Solid red A ring port within the ring loop is identified has
having a ring ID within a second ring loop.
Off No ring ports having a ring ID within a second-
ary ring loop are detected.
8 Temp Solid red IC sensor detects a temperature range exceed-
ing set temperature range.
Off IC sensor detects normal operating tempera-
ture.
SFP
9 SFP LED Solid green SFP or GBIC plug-in and link up.
Blink green Packet transmit and receive.
Off SFP or GBIC plug-out or link down.
RJ45
10 PoE Solid green Connect to PD and supply power.
Blink green Not applicable.
Off Disconnect from PD and No supply Power.
11 LNK/ACT Solid green Current link speed is 1000M.
Blink green Packet transmit and receive.
Off No link.
Solid amber Current link speed is 100/10M.
Blink amber Packet transmit and receive.
Off No link.
Solid green Connect to PD and supply power.
No. LED Name LED Color Description
No. Item Description
1 Ground terminal Screw terminal used to ground chassis.
2 Console serial
port Console cable port to COM port (DB9 male) on computer to RS232 managed switch (RJ45 female).
3 P-Fail block An open circuit occurs upon detecting a power failure.
A close circuit denotes normal power activity.
4 Power block Connect cabling for power wiring.
Console
V1- V1+ V2- V2+
P-Fail PWR1
12~48VDC
PWR2
31 42

EKI-9628G User Manual 5
1.3 Dimensions
Figure 1.4 Dimensions
1.4 Packing List
The product package you have received should contain the following items. If any of
them are not included or damaged, please contact your local vendor for support.
1 x Industrial Ethernet Switch
1 x Rack Mount Kit
1 x Startup Manual
1 x EKI Device Configuration Utility CD ROM
438
22 41
426
12~48VDC
12~48VDC

Chapter 2
2Switch Installation

EKI-9628G User Manual 7
2.1 Warnings
Warning: Before working on equipment that is connected to power lines, remove any
jewelry (including rings, necklaces, and watches). Metal objects can heat up when
connected to power and ground, which can cause serious burns or weld the metal
object to the terminals.
Caution! Exposure to chemicals can degrade the sealing properties of materials
used in the sealed relay device.
Caution! It is not recommended to work on the system or connect or disconnect
cables during periods of lightning activity.
Caution! Before performing any of the following procedures, disconnect the
power source from the DC circuit.
Caution! Read the installation instructions before connecting the system to its
power source.
Caution! The device must be grounded. Never defeat the ground conductor or
operate the equipment in the absence of a suitably installed ground con-
ductor.
Caution! This unit may have more than one power supply connection. All connec-
tions must be removed to de-energize the unit.
Caution! The installation, replacement, or service of the device must be Only be
performed by trained and qualified personnel.
