AEG A18SPC3 User manual

A18SPC3
Original instructions

Important!
It is essential that you read the instructions in this manual before
assembling, operating and maintaining the product.
Subject to technical modifications.

3
Keyhole hanger
p. 4 p. 5 p. 6
LED indicator
Battery port

4
34
2
5
1

5
100%
50ºC
0ºC
Evaluate
Evaluate
Charging
Charged
Defective

6
105 mm
1
2

7
CHARGER SAFETY WARNINGS
The product is not intended to be used or cleaned by persons
with reduced physical, sensory or mental capabilities, or lack of
experience or knowledge, unless they have been given instructions
concerning the safe use of the appliance by a person legally
responsible for their safety. They should be supervised whilst using
the product. Children shall not use, clean or play with the product,
which when not in use should be secured out of their reach.
Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or
serious injury.
Do not recharge primary cells (non-rechargeable).
The product must not be damp and should never be used in a
damp environment.
The product is for indoor use only.
Do not cover any ventilation slots, and provide adequate ventilation
during operation.
Mains voltage must correspond with the voltage specications on
the product.
Before using the product, check that the charger enclosure, cable,
and plug are not damaged. If damage is found, do not use the
product and bring it to an authorised service centre for repair.
Do not use the product if it has suffered any heavy shock or jolting,
or if it is damaged in any other way.
When charging, do not expose the product to sunlight or other heat
source. The recommended temperature range at charging vicinity
is 5° to 40°C.
Due to the heat generated during charging, do not use the product
on a combustible surface.
Do not use the product near ammable materials, such as cloth,
packaging materials, paint, spray paint or aerosols, lubricants,
thinners, petrol containers, gas containers, or gas appliances.
Never modify, disassemble, or attempt to repair the product
yourself.
Do not allow the charger or battery packs to become contaminated
with any material that could be conductive, such as metallic
particles from grinding, cutting, or machining processes.
Protect the battery contact terminals from metallic objects to avoid
a short circuit, which can cause re or explosion.
TECHNICAL DATA A18SPC3
Type Charger
Rated voltage 18 V
Quick charge current 3.2 A
Recommended ambient charging temperature +5 to +40 °C
Weight without battery pack 0.65 kg
COMPATIBLE BATTERY PACKS
Battery pack Voltage Battery capacity Number of cell for battery Cell type Approximate charge
time
L1820S
18 V
≤ 2.0 Ah 5
Lithium-Ion
50 minutes
A18FB2 ≤ 2.0 Ah 5 50 minutes
A18B4 ≤ 4.0 Ah 5 x 2 90 minutes
A18FB4 ≤ 4.0 Ah 5 x 2 90 minutes
A18FB5 ≤ 5.0 Ah 5 x 2 115 minutes
A18OB6 ≤ 6.0 Ah 5 x 2 145 minutes
L1860R-X5 ≤ 6.0 Ah 5 x 2 145 minutes
A18OB8 ≤ 8.0 Ah 5 x 2 185minutes
L1890R ≤ 9.0 Ah 5 x 3 205 minutes
LED INDICATORS
MODE BATTERY PACK STATUS GREEN LED RED LED ACTION
Power Without battery pack OFF ON Ready to charge battery pack.
Evaluate
Hot battery pack
OFF Flashing
When battery pack reaches cooled temperature, charger begins fast
charge mode.
Cold battery pack When battery pack reaches warmed temperature, charger begins fast
charge mode.
Defective Defective Flashing Flashing Battery pack or charger is defective.
• If defective, try to repeat the conditions a second time by removing and reinstalling the battery pack. If the LED status repeats a second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see battery pack operator's manual).
• If a different battery also indicates "Defective," the charger may be defective.
Charging Charging Flashing On Battery is being charged.
Full Fully charged ON OFF Battery pack is fully charged
Maintenance Maintenance mode ON OFF Charging is complete; charger maintains fully charged state.

8
Unplug the product from the power socket when it is not in use or
when cleaning it.
Use only an extension cable that is approved and in good
condition.
Do not charge battery packs that show signs of leaks. Dispose of
them properly.
Never charge a damaged battery pack. Replace damaged battery
packs immediately.
Before every use, examine the supply cord for damage. If there are
signs of damage, it must be replaced by a qualied person at an
authorised service centre to avoid a hazard.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of re, personal injury, and
product damage due to a short circuit, never immerse your tool,
battery pack, or charger in uid or allow uid to ow inside them.
Corrosive or conductive uids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG distributors offer to retrieve old batteries to
protect our environment.
Battery packs that have not been used for some time should be
recharged before use.
For an optimum lifetime, the battery packs have to be fully charged
after use.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C and
away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
Battery pack protection
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life.
Under extreme stress, the battery electronics turn off the product
automatically. To restart, turn the product off and then on again.
If the product does not start up again, the battery pack may have
discharged completely. Recharge the battery pack.
Transporting lithium batteries
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national, and international provisions and regulations.
• Batteries can be transported by road without further requirement.
• Commercial transport of lithium-ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
• Ensure that the battery contact terminals are protected and
insulated to prevent short circuit.
• Ensure that the battery pack is secured against movement within
the packaging.
• Do not transport batteries that are cracked or leaking.
• Check with the forwarding company for further advice.
SPECIFIED CONDITIONS OF USE
The charger is intended only to charge the compatible battery
packs listed in this manual.
The product is only for indoor use, in dry conditions.
The product is not intended to charge any other type of battery or
be used as a power supply. It should never be used in explosive or
ammable environments.
Do not use the product for any other purpose.
WALL MOUNTING
Carefully select a stable wall for mounting the charger. Make sure
that there is no hindrance to mounting work or operation. The
maximum gross weight of the charger is approximately 1.81 kg,
provide sufcient reinforcement for the wall if necessary.
Mount the charger in a vertical orientation only. Install two screws
on the wall to mount the charger. Otherwise, the charger may fall
and cause serious injury.
Check the tightness of the screws on a regular basis. Make sure
that the head of the screws t properly in the wall mounting holes
to hold the charger rmly in place. Otherwise, the charger may fall
because of loose screws.
OPERATION
CHARGING THE BATTERY PACK
• Battery packs are shipped in a low charge condition. Therefore,
you should charge them before first use. If the charger does not
charge the battery pack under normal circumstances, bring both
the battery pack and charger to an authorised service centre.
• Make sure that the power supply is normal household voltage,
220–240V, 50Hz, AC only.
• Make sure that the battery pack latch clicks into place and that
the battery pack is secured in the charger before charging.
NOTE: When the battery becomes fully charged, the green LED
remains on. It is normal for the battery pack to become slightly
warm to touch while charging.
• Do not place the charger and battery pack in an area of extreme
heat or cold. They work best at normal room temperature.
NOTE: When charging, the charger and battery pack should be
placed in a location where the temperature is more than 5°C but
less than 40°C.
CHARGING A COOL BATTERY PACK
1.Insert the battery pack into the charging port. Make sure that the
battery pack latch clicks into place.
2.Connect the product to a power supply.
3.Disconnect the product from the power supply when the battery
pack becomes fully charged.
4.Press the battery pack latches to unlock the battery pack from
the product.
5.Remove the battery pack from the product.
CHARGING A HOT BATTERY PACK
When using a tool continuously, the cells in the battery pack
become hot. A hot battery pack should be allowed to cool down for
approximately 30 minutes before recharging.
MAINTENANCE
When not using or when cleaning the product, disconnect it from
the power supply and remove the battery pack.
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to various types of commercial solvents. Use clean
cloth or soft brush to remove dirt and dust.
Do not, at any time, let brake uids, gasoline, petroleum-based
products, and penetrating oils come in contact with plastic parts.
These products contain chemicals that can damage, weaken, or
destroy plastic.
Hazardous voltages are present within the product; do not
disassemble.
If the supply cord is damaged, it must be replaced by a special cord
or assembly available from the manufacturer or its service agent.
Use only AEG accessories and spare parts. Should components
that have not been described need to be replaced, contact one
of our AEG service agents (see our list of guarantee/service
addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on the
label and order the drawing at your local service agents or directly
at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia

9
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
CLEANING THE CHARGER
Unplug the charger power cord from the power supply before
cleaning to prevent serious personal injury.
Clean the charger surface (except labels) using a damp cloth with
a mild detergent.
Do not use any strong detergents on the plastic housing. They can
be damaged by certain aromatic oils, such as pine and lemon, and
by solvents such as kerosene.
Moisture can cause a shock hazard. Wipe off any moisture with a
soft dry cloth.
STORAGE
Store the product in a cool dry place between 10°C and 38°C.
SYMBOLS
Read the instructions carefully before starting the
product.
CAUTION! WARNING! DANGER!
Class II equipment
For indoor use only
Time-lag fuse 3.15 A
Direct current
Accessory - Not included in standard equipment,
available as an accessory.
Do not dispose of waste electrical and electronic
equipment as unsorted municipal waste.
Waste electrical and electronic equipment must be
collected separately.
Waste light sources have to be removed from the
equipment.
Check with your local authority or retailer for recycling
advice and collection point.
According to local regulations, retailers may have an
obligation to take back waste electrical and electronic
equipment free of charge.
Your contribution to the reuse and recycling of waste
electrical and electronic equipment helps to reduce
the demand of raw materials.
Waste electrical and electronic equipment contain
valuable and recyclable materials, which can
adversely impact the environment and the human
health if not disposed of in an environmentally
compatible manner.
Delete personal data from waste equipment, if any.
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
PLACEHOLDER

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trade mark used under
license from AB Electrolux (publ).
961096967-01A
