AEG BL18S User manual

BL18S
Original instructions

2
2
0°C
1 2 3
50°C
0°C
50°C
100%
100 %
4 5
contact?

33
0°C
1 2 3
50°C
0°C
50°C
100%
100 %
4 5
contact?

4
4
Important!
This appliance is not intended to be used or cleaned
by persons with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless
they have been given instructions concerning the safe
use of the appliance by a person legally responsible for
their safety. They should be supervised whilst using the
appliance.
Children shall not use, clean or play with this appliance,
which when not in use should be secured out of their
reach.

55
WARNING! Read all safety warnings instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury. Save all
warnings and instructions for future reference.
CHARGER SAFETY WARNINGS
Do not dispose of used battery packs in the household refuse or by burning
them. AEG Distributors oer to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Use only System AEG GBS chargers for charging System AEG GBS battery packs.
Do not use battery packs from other systems.
Do not try to charge non-rechargeable batteries with this charger.
No metal parts must be allowed to enter the battery section of the charger (short
circuit risk).
Never break open battery packs and chargers and store only in dry rooms. Keep
dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new one.
Before use, check machine, cable, and plug for any damages or material fatigue.
Repairs should only be carried out by authorised service agents.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and product damage
due to a short circuit, never immerse your tool, battery pack or charger in fluid or
allow a fluid to flow inside them. Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
SPECIFIED CONDITIONS OF USE
The quick charger is intended to charge AEG system slide 18V batteries.
Do not use the product in any way other than those stated for intended use.
MAINS CONNECTION
Connect only to single-phase A.C. current and only to the system voltage
indicated on the rating plate.
BATTERIES
Battery packs which have not been used for some time should be recharged
before use.
Temperatures in excess of 50°C (122°F) reduce the performance of the battery
pack. Avoid extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the
charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and away from
moisture.
Store the battery packs in a 30% - 50% charged condition.
Every six months of storage, charge the pack as normal.
CHARACTERISTICS
After inserting the battery into the reception of the charger the battery will
automatically be charged (green lamp is flashing).
When a hot or cold battery pack is inserted into the charger (orange lamp is
illuminated continuously), charging will begin automatically once the battery
reaches the correct charging temperature (0°C - 50°C).
Charging time varies depending on the battery temperature, charge needed and
the type of battery pack being charged.
As soon as charging is completed, the charger switches over to trickle charge
to maintain the full capacity (green control lamp is illuminated continuously, red
lamp o).
If red lamp is illuminated continuously, either the battery has not been completely
TECHNICAL DATA BATTEry CHArgEr BL18S
Rated voltage 18 V
Quick charge current Li-Ion 2.0 A
Recommended ambient charging temperature +5 to +40 °C
Weight - not including battery pack 0.35 kg
TECHNICAL DATA CHArgEr BL1218
Input 220 - 240 V 50 Hz 110 W
Output 18V
Quick charge current Li-Ion 4A max
Weight - not including battery pack 0.83 kg +/-5%
Recommended ambient charging temperature +5 to +40 °C
COMPATIBLE BATTERY PACKS
Battery pack Voltage Battery capacity Number of cell for battery Cell type Approximate charge time
L1820R TYPE II
18 V
≤ 2.0 Ah 5
Lithium-Ion
90 minutes
L1820S ≤ 2.0 Ah 5 90 minutes
L1825R TYPE II ≤ 2.5 Ah 5 110 minutes
L1830R-X5 ≤ 3.0 Ah 5 125 minutes
L1840R TYPE II ≤ 4.0 Ah 5 x 2 170 minutes
L1850R TYPE II ≤ 5.0 Ah 5 x 2 190 minutes
L1860R TYPE II ≤ 6.0 Ah 5 x 2 210 minutes
L1860R-X5 ≤ 6.0 Ah 5 x 2 210 minutes
L1890R ≤ 9.0 Ah 5 x 3 375 minutes

6
6
mounted or there is a fault in the battery or the charger. For safety reasons you
must stop using the charger and battery immediately and have them inspected
by an AEG Customer Service Centre.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with local,
national and international provisions and regulations.
■The user can transport the batteries by road without further requirements.
■Commercial transport of Lithium-Ion batteries by third parties is subject
to Dangerous Goods regulations. Transport preparation and transport
are exclusively to be carried out by appropriately trained persons and the
process has to be accompanied by corresponding experts.
When transporting batteries:
■Ensure that battery contact terminals are protected and insulated to
prevent short circuit.
■Ensure that battery pack is secured against movement within packaging.
■Do not transport batteries that are cracked or leaking.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being overloaded
and helps to ensure long life. Under extreme stress the battery electronics
switch o the machine automatically. To restart, switch the machine o and then
on again. If the machine does not start up again, the battery pack may have
discharged completely. In this case it must be recharged in the battery charger.
MAINTENANCE
The supply cord cannot be replaced. If the cord is damaged the appliance should
be scraped.
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should components need to be
replaced which have not been described, please contact one of our AEG service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the Article
No. as well as the machine type printed on the label and order the drawing at
your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
VVolts
Direct current
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Please read the instructions carefully before starting the
machine.
Class II equipment
Time-lag fuse 2.0A
For indoor use only.
Do not dispose of electric tools together with household
waste material. Electric tools and electronic equipment
that have reached the end of their life must be collected
separately and returned to an environmentally compatible
recycling facility.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
961096683-01A
AEG is a registered trade mark used under
license from AB Electrolux (publ).
© 2020 Techtronic Cordless GP.
