AEG Voxtel D200 User manual

1
UK
CORDLESS
TELEPHONE
Voxtel D200
QUICK START GUIDE
UK DE FR NL IT SW PL GR BUL CZ
V2

2
P1 P2
WXYZ
PQRS
OK
R
7
4GHI
0
8 TUV
5 JKL
9
6
MNO
1 2
ABC 3
DEF
1
2
3
45
6
7
8P3
P4
9
P5

3
UK
1 BECAUSE WE CARE
Thank you for purchasing this product. This product has been designed
and assembled with utmost care for you and the environment. This is
why we supply this product with a quick installation guide to reduce the
number of paper (pages) and therefor save trees to be cut for making this
paper.
A full and detailed user guide with all the features descripted can be
found on our website www.aegtelephones.eu. Please download the full
user guide in case you want to make use of all the advanced features of
your product. To save the environment we ask you not to print this full user
guide. Thank you for supporting us to protect our environment.
2 IMPORTANT SAFETY INSTRUCTIONS
When using your telephone, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury, including the
following:
1. Read and understand all the instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug the power adapter from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Keep your phone away from hot, humid conditions or strong sunlight
and don’t let it get wet or use this product near water (for example,
near a bath tub , kitchen sink, swimming pool).
5. Do not overload wall outlets and extension cords as this can result in
the risk of fire or electric shock.
6. Unplug this product from the wall outlet under the following conditions:
tWhen the power supply cord or plug is damaged.
tIf the product does not operate normally by following the operating
instructions.
tIf the product has been dropped and the cabinet has been damaged.
tIf the product exhibits a distinct change in performance.
7. NEVER use your phone outdoors during a thunderstorm-unplug the
base from the telephone line and the mains socket when there are
storms in your area. Damage caused by lightning is not covered by
the guarantee.
8. Do not use the telephone to report a gas leak in the vicinity of the leak.
9. Use only the supplied NiMH (Nickel Metal Hydride) batteries!

4
10. The use of other battery types or non-rechargeable batteries/primary
cells can be dangerous. These may cause interference and/or damage
to the unit or surroundings. The manufacturer will not be held liable for
damage arising from such non-compliance.
11. Do not use third party charging bays. Damage may be caused to the
batteries.
12. Please ensure the batteries are inserted in the correct polarity.
13. Dispose of batteries safely. Do not immerse them in water, burn them,
or put them where they could get punctured.
3 INTENDED USE
This telephone is intended to be connected to a public analogue
telephone network or to an analogue extension of an compatible PBX
system.
4 UNPACKING YOUR PHONE
In the box you will find:
t1 Handset
t1 Base station
t1 Mains power adapter
t1 Telephone line cord
t2 Rechargeable batteries
t1 User manual
Keep the packing materials in a safe place in case you later need to
transport the device.

5
UK
5GETTING TO KNOW YOUR PHONE
5.1 Handset overview (see P1)
# Meaning
1
Up key
tIn idle mode: press to access the call list
tIn menu mode: press to scroll up the menu items
tIn phonebook list / redial list / call list: press to scroll up
the list
tDuring a call: press to increase the earpiece volume
tDuring ringing: press to increase the ringer volume
2
Right soft key (clear/back/mute/intercom)
tIn main menu mode: press to go back to idle screen
tIn sub-menu mode: press to go back to previous level
tIn sub-menu mode: press and hold to go back to idle
screen
tIn editing / predialling mode: press to clear a character/
digit
tIn editing / predialling mode: press and hold to delete all
the characters / digits
tDuring a call: press to mute / unmute the microphone
tIn idle mode: press to intercom another handset
3
Off / hang up key
tDuring a call: press to end a call and go back to idle
screen
tIn menu / editing mode: press to go back to previous
menu
tIn idle mode: press and hold to power off the handset
tIn idle mode (when the handset is powered off): press
and hold to power on the handset
4RFlash key
tIn idle / predialling mode: press to insert a flash
tDuring a call: press to generate flash signal

6
5
Speakerphone key
tDuring a call: press to turn on / off the speakerphone.
tCall list / phonebook entry: press to make a call with
speakerphone
tDuring ringing: press to answer a call with speakerphone
6
Down key (redial/down)
tIn idle mode: press to access the redial list
tIn menu mode: press to scroll down the menu items
tIn phonebook list / redial list / call list: press to scroll
down the list
tDuring a call: press to decrease the earpiece volume
tDuring ringing: press to decrease the ringer volume
7
Talk key
tIn idle / predialling mode: press to make a call
tIn redial list / call list / phonebook list: press to make a
call to the displayed entry
tDuring ringing: Press to answer a call
8O
K
Left soft key (menu/ok)
tIn idle mode: press to access the main menu
tIn sub-menu mode: press to confirm the selection
tDuring a call: press to access Intercom/phonebook/
redial list/ call list
5.2 Display icons and symbols (see P2)
The LCD display gives you information on the current status of the
telephone.
Meaning
Steady when the handset is in range of the base.
Flashes when out of range of the base or not registered to the
base.
Steady when an intercom call is in progress.
Flashes when there is an incoming internal call.
Indicates a call is in progress on that handset.

7
UK
Indicates that speakerphone is being used.
Indicates that the handset ringer is switched off.
Steady when an alarm is set.
Flashes when the alarm is sounding.
Indicates that the keypad is locked.
Indicates when you have a new Voice Mail message.
(This is a caller display service from the network operator.)
Indicates when the battery is fully charged.
Whole icon flashes when the battery is charging.
Internal block icon flashes when the battery is in final charging
stage.
Indicates when the battery needs charging.
Flashes when low battery power level is detected.
Indicates when there are more characters or numbers in front
of those
being displayed.
Indicates when there are more characters or numbers after those
being
displayed.
Left soft key function. Press to access the main menu.
Left soft key function. Press to confirm the current selection.
Indicates new TAM message / new call in TAM message list /
call list.
Indicates more options available in lists, above or below.
Right soft key function. Press to start an intercom call.

8
Right soft key function. Press to go back to the previous menu
(back) level or cancel the current action.
Right soft key function. Press the alarm or mute/unmute the
microphone during a call.
5.3 Base station (see P4)
# Meaning
9
Find
Press to page your registered handset(s).
Press and hold to start the registration process.
6 INSTALLATION
6.1 Connecting the base station (see P5)
tPlug the power supply and line cord into the base station.
tPlug the power adapter into a 230 V ac/50Hz mains socket and the line
cord into your telephone line socket.
Warning:
Use only the provided adaptor, using other power supplies may cause a
hazard or damage the phone.
Install the base unit in a position where the mains adapter plug will reach
an easily accessible mains socket to unplug in case needed. Never try to
lengthen the mains power cable.
Note:
The base unit needs mains power for normal operation, not just for
charging the handset batteries.
6.2 Installing and charging the batteries (see P3)
tPlace the 2 supplied batteries into the battery compartment with
the polarity markings. Use only the NiMH rechargeable battery type
provided with the telephone.
tPosition the battery compartment cover over the batteries and slide up
to click into place.

9
UK
tPut the handset on the base and charge for 15hours before using the
handset for the first time.
>The handset will give a beep when it is properly placed on the base
or charger.
7 TELEPHONE OPERATION
7.1 Make a call
7.1.1 Preparatory dialling
tEnter the phone number and press to connect to the line and dial the
number.
>When entering the number, if you make a mistake, press “ “( )
to delete digits.
7.1.2 Direct dialling
tPress to connect to the line and then enter the phone number.
7.1.3 Call from the phonebook
tPress , , O
K
to access the phonebook and press /to select the
desired phonebook entry.
tPress to dial out the selected phonebook entry.
Note:
The alphanumeric keys provide a short-cut to find entries beginning with
the corresponding letters.
7.1.4 Call from the call list (only available with caller display)
tPress to access the call list and press /to select the desired call
list entry.
tPress to dial out the selected call list entry.
7.1.5 Call from the redial list
tPress to access the redial list and press /to select the desired
redial number.
tPress to dial out the selected redial number.

10
7.1.6 Call timer
Your handset automatically times the duration of every call.
The call timer is displayed as soon as you answer a call or 15seconds after
dialling and remains on the screen for 5seconds after the end of the call.
It is shown in hours, minutes and seconds format (HH:MM:SS).
7.2 Answer a call
If the handset is not on the charging cradle:
tWhen the phone rings, press to answer a call.
Note:
If “AUTO ANSWER” is set to “ON”, then lifting the handset off the base or
charger will answer the call automatically and no keys need to be pressed.
7.3 End a call
tDuring a call press to end the call.
OR
tPut the handset on the base station or charger to end the call.
7.4 Handset speakerphone
During a call, you can press to alternate between hands-free
speakerphone and normal handset use.
7.5 Adjust volume
There are 5levels (“VOLUME 1” to “VOLUME 5”) to choose from for each
of the earpiece and speaker volumes.
During a call:
tPress /to select volume 1-5. The current setting is shown.
>When you end the call, the setting will remain at the last selected
level.
7.6 Turn off the handset ringer
In idle, press and hold #to turn off the handset ringer. The icon is
displayed on the LCD.
Note:
The display will still flash the call icon and show “CALL” or the caller
display number, when there is an incoming call, even if the ringer is turned
off. To turn the ringer back on, press and hold #again.

11
UK
7.7 Turn on the keypad lock
You can lock the keypad so that it cannot be used accidentally while
carrying it around.
tIn idle, press and hold *to turn on the keypad lock and the icon will
display.
Note:
You can still use to answer a call when the handset is ringing.
To turn the keypad lock off, press and hold *again.
7.8 Redial the last number
You can redial any of the 5last numbers called. If you have stored a name
in phonebook to go with the number, the name will be displayed instead.
The most recent last number will display at the top of the redial list.
7.8.1 Redial a number from the redial list
tIn idle mode, press to access the redial list.
Note:
If the redial list entry shows a name, press # to view the number of this
entry.
tPress /to browse the redial list.
tPress to dial to the selected redial number.
Note:
If there are no numbers in the redial list, the display shows “EMPTY ”.
7.9 Find the handset
You can locate the handset by pressing the find key 14. All the handsets
registered to the base will produce the paging tone and show “PAGING“
on the display for 60 seconds.
You can stop the paging by pressing on any handset or on the
base again.
Note:
If there is an incoming call during paging, the phone will ring with the
incoming call instead of paging.

12
8 PRIVATE PHONEBOOK
Each handset can store up to 50 private phonebook entries with names
and numbers. Each phonebook entry can have a maximum of 20
digits for the phone number and 12 characters for the name. You can
also select different ringtones for your phonebook entries. (Note: the
different ringtones only play when you receive a call if you subscribe to
caller display and the incoming number matches the stored number.)
Phonebook entries are stored alphabetically by name.
8.1 Add a new phonebook entry
In idle:
tPress and /to select “PHONEBOOK” and then press O
K
to
access the phonebook.
tPress O
K
to show “ADD”.
tPress O
K
and then enter the name.
tPress O
K
and then enter the number.
tPress O
K
and /to select the desired ringtone for your phonebook
entry.
tPress O
K
to store the phonebook entry.
8.2 Search for a phonebook entry
In idle:
tPress and /to select “PHONEBOOK” and then press O
K
to
access the phonebook.
tEnter the first letter of the name using the alphanumeric keys (e.g. if it
begins with C, press the 2 key three times) and then /to scroll to
the entry you want.
8.3 Edit a phonebook entry
In idle:
tPress and /to select “PHONEBOOK and then press O
K
to
access the phonebook.
tPress /to select the desired phonebook entry.
tPress O
K
and /to select “EDIT”.
tPress O
K
to display the current name.
tEdit the name and press O
K
.
tEdit the number and press OK.
tPress /to select the ringtone and press O
K
to confirm.

13
UK
8.4 Delete a phonebook entry
In idle:
tPress and /to select “PHONEBOOK” and then press O
K
to
access the phonebook.
tPress /to select the desired phonebook entry.
tPress O
K
and /to select “DELETE”.
tPress O
K
to confirm, and the entry will be deleted.
9 CALLER DISPLAY (NETWORK DEPENDENT)
This feature is available if you have subscribed to the calling Line
Identification service with your network service provider. Your phone can
store up to 20 received calls with date/time information in the call list. The
number will be shown on the handset display when the phone is ringing.
If the number matches with one of the entries in your private phonebook,
the caller‘s name stored in the private phonebook will be displayed
alternately with the number, and the handset will ring with the ringtone
associated with that phonebook entry.
If the call is from someone who withheld their number, “WITHHELD” will
display.
If the call is from someone whose number is unavailable, e.g. an
international call or from a private exchange, “OUT OF AREA” will display.
If you‘ve got new caller display records, the handset will display “X NEW
CALLS“ in standby mode. The New calls indication will remain until all the
new call records have been viewed on that handset.
9.1 View the call list
All received calls are saved in the call list with the latest call at the top of
the list. When the call list is full, the oldest call will be replaced by a new
call. Any unanswered calls which have not been viewed are marked with a
icon at the centre of the bottom line of the display.
tPress to access the call list.
OR Press and /to show “CALL LIST”, then press O
K
.
tPress /to select the desired entry.
tPress #to view the caller’s number if applicable.
tPress , /to show “DETAILS”, and then O
K
to display the date
and time of the call.
tPress O
K
to go back to the previous screen.

14
9.2 Delete an entry in the call list
tFollow steps 1 and 2 in section “9.1 View the call list”.
tPress and /to select “DELETE”.
tPress O
K
to confirm.
9.3 Delete all call list entries
Follow steps 1 and 2 in section “9.1 View the call list”.
tPress and /to select “DELETE ALL”.
tPress O
K
to display “CONFIRM?”.
tPress O
K
to confirm.
>All entries will be deleted and the display will show “EMPTY”.
10 PHONE SETTINGS
Your phone comes with a selection of settings that you can change to
personalise your phone the way you like it to work.
10.1 Set the handset language
tPress and /to select “HS SETTINGS”.
tPress O
K
and /to select “LANGUAGE”.
tPress O
K
and /to select the desired language.
tPress O
K
to confirm.
10.2 Base Settings
10.2.1 Set the base ringer melody
tPress and /to select “BS SETTINGS”.
tPress O
K
and /to select “BS RINGER”.
tPress O
K
and /to select the desired melody you want from a
choice of 5.
tPress O
K
to confirm.
Note:
The respective ringer melody will be played while browsing the melody
list.
10.2.2 Set the ringer volume
tPress and /to select “BS SETTINGS”.
tPress O
K
and /to select “RING VOLUME”.

15
UK
tPress O
K
and /to select the desired ringer volume (a total of 6
ringer volume levels including “VOLUME OFF”).
tPress O
K
to confirm.
Note:
The respective ringer volume will be played during your selection.
10.3 Handset registration
Important:
When you purchase your phone, all handsets are already registered to
your base, so you do not need to register them.
Handset registration is only necessary when you buy extra handsets or if a
handset has become faulty.
You can register additional handsets to have up to five handsets per base
unit, with each handset‘s number (1 to 5) shown on its display. (Note: each
handset can only be registered to one base.)
To register a new handset to your base:
tPress and hold on the base station for more than five seconds, to
put the base station into registration mode. It will stay in registration
mode for about 1 minute, so the following handset sequence must be
completed within this time.
tPress and /to select “REGISTRATION”.
tPress O
K
to display “PIN?------”.
tEnter the 4-digit system PIN (default 0000).
tPress O
K
to confirm, and the display will show “SEARCHING”.
If the handset registration is successful, you will hear a confirmation tone
and the will stop flashing.
The handset will automatically be allocated the next available handset
number. This handset number is shown in the handset display in standby
mode. If the handset registration is unsuccessful, the will still flash.

16
11 GUARANTEE AND SERVICE
The phone is guaranteed for 24 months from the date of purchase shown
on your sales receipt. This guarantee does not cover any faults or defects
caused by accidents, misuse, fair wear and tear, neglect, faults on the
telephone line, lightning, tampering with the equipment, or any attempt
at adjustment or repair other than through approved agents.
Please keep your sales (till) receipt this is your proof of guarantee.
11.1 While the unit is under Guarantee
tDisconnect the base unit from the telephone line and the mains
electricity supply.
tPack up all parts of your phone system, using the original package.
tReturn the unit to the shop where you bought it, making sure you take
your sales receipt.
tRemember to include the mains adapter.
11.2 After the Guarantee has expired
If the unit is no longer under Guarantee, contact us via www.
aegtelephones.eu
This product works with rechargeable batteries only. If you put
nonrechargeable batteries in the handset and place it on the base, the
handset will be damaged and this in NOT covered under the warranty
conditions.
12 TECHNICAL DETAILS
Standard Digital Enhanced Cordless Telecommunication
(DECT)
1.88 to 1.9 GHz (bandwidth = 20 MHz)
Channel bandwidth 1.728 MHz
Operating range Up to 300m outdoors; Up to 50m indoors
Operating time Standby: 100 hours, Talking: 10 hours
Battery charge time:15hours
Temperature range Operating 0° C to 40° C,
Storage -20° C to 60° C

17
UK
Electrical power Base unit:
Ten Pao - S004LB0600045/ S004LV0600045
input 100-240VAC 50/60Hz 150mA,
output 6VDC 300mA
13 CE DECLARATION
This product is in compliance with the essential requirements and other
relevant provisions of the R&TTE directive 1999/5/EC.
The Declaration of conformity can be found on: www.aegtelephones.eu
14 DISPOSAL OF THE DEVICE (ENVIRONMENT)
At the end of the product lifecycle, you should not throw this product
into the normal household garbage but bring the product to a collection
point for the recycling of electrical and electronic equipment. The symbol
on the product, user guide and/or box indicate this. Some of the product
materials can be re-used if you bring them to a recycling point. By reusing
some parts or raw materials from used products you make an important
contribution to the protection of the environment. Please contact your
local authorities in case you need more information on the collection
points in your area.
Batteries must be removed before disposing of the device. Dispose of
the batteries in an environmental manner according to your country
regulations.
15CLEANING AND CARE
Do not clean any part of your phone with benzene, thinners or other
solvent chemicals as this may cause permanent damage which is not
covered by the Guarantee.
When necessary, clean it with a damp cloth.
Keep your phone system away from hot, humid conditions or strong
sunlight, and don‘t let it get wet.

18
1 UNSER EINSATZ FÜR DIE UMWELT
Vielen Dank, dass Sie sich für dieses Produkte entschieden haben. Dieses
Gerät wurde mit größter Sorgfalt entwickelt und zusammengebaut, um
Ihnen ein exzellentes Produkt zu bieten und gleichzeitig die Umwelt
zu schonen. Deshalb liegt diesem Produkt eine Kurzanleitung bei, um
die Papiermenge zu reduzieren. So müssen weniger Bäume für die
Herstellung von Papier abgeholzt werden.
Eine vollständige und ausführliche Bedienungsanleitung finden Sie
auf unserer Website www.aegtelephones.eu. Downloaden Sie bitte
die vollständige Bedienungsanleitung, wenn Sie alle fortschrittlichen
Funktionen Ihres Produkts nutzen möchten. Zum Schutz der Umwelt
bitten wir Sie, die vollständige Bedienungsanleitung nicht auszudrucken.
Vielen Dank, dass Sie uns beim Umweltschutz unterstützen.
2 WICHTIGE SICHERHEITSANWEISUNGEN
Beim Gebrauch Ihres Telefons sollten die grundlegenden
Sicherheitsvorkehrungen befolgt werden, um das Risiko von Feuer,
Stromschlag und Verletzungen zu vermeiden. Dies gilt einschließlich dem
Folgenden:
1. Lesen und verstehen Sie alle Anweisungen.
2. Befolgen Sie alle auf dem Produkt markierten Warnungen und
Anweisungen.
3. Ziehen Sie vor der Reinigung den Stecker des Netzadapters aus
der Steckdose. Benutzen Sie keine flüssigen Reinigungsmittel oder
Sprühreiniger. Benutzen Sie zum Reinigen ein feuchtes Tuch.
4. Setzen Sie Ihr Telefon weder Hitze, feuchten Bedingungen noch
starkem Sonnenlicht aus und lassen Sie es nicht nass werden. Benutzen
Sie es auch nicht in der Nähe von Wasser (zum Beispiel in der Nähe
einer Badewanne, einer Küchenspüle oder eines Swimming-Pools).
5. Überlasten Sie die Steckdosen und Verlängerungskabel nicht, weil
dies zum Risiko eines Feuers oder eines Stromschlags führen kann.
6. Ziehen Sie den Netzstecker bei den folgenden Umständen aus der
Steckdose:
tWenn das Netzkabel oder der Netzstecker beschädigt sind.
tWenn das Produkt bei Befolgung der Bedienungsanweisungen nicht
ordnungsgemäß funktioniert.
tWenn das Produkt herunter gefallen ist und das Gehäuse beschädigt
wurde.

19
ENDE
tWenn bei dem Produkt eindeutige Leistungsänderungen auftreten.
7. Benutzen Sie das Telefon NIEMALS während eines Gewitters. Trennen
Sie die Basisstation vom Telefonnetz und ziehen Sie den Netzstecker
aus der Steckdose, wenn in Ihrer Umgebung Gewitter auftreten.
Durch Blitzschlag verursachte Schäden werden nicht von der Garantie
abgedeckt.
8. Verwenden Sie das Telefon nicht in der Nähe des Gaslecks, wenn Sie
ein Gasleck melden wollen.
9. Benutzen Sie ausschließlich die mitgelieferten NiMH (Nickel-
Metallhydrid)-Akkus!
10. Die Verwendung von anderen Akku-Typen oder nicht
wiederaufladbaren Batterien/Primärzellen kann gefährlich sein. Dies
könnte Störungen verursachen und/oder das Gerät beschädigen oder
die Umgebung beeinflussen. Der Hersteller haftet nicht für Schäden,
die durch eine solche Nichtbeachtung verursacht wurden.
11. Verwenden Sie keine Ladegeräte von anderen Herstellern. Die Akkus
könnten beschädigt werden.
12. Stellen Sie sicher, dass die Akkus mit der richtigen Polarität eingelegt
sind.
13. Entsorgen Sie die Akkus sicher. Tauchen Sie sie nicht in Wasser ein,
verbrennen Sie sie nicht oder legen Sie sie nicht an einen Ort, wo sie
durchstochen werden könnten.
3 VERWENDUNGSZWECK
Dieses Telefon ist für den Anschluss an ein öffentliches analoges
Telefonnetz oder an eine analoge Verlängerung einer kompatiblen PBX-
Telefonanlage vorgesehen.
4 LIEFERUMFANG
Im Lieferumfang ist Folgendes enthalten:
t1 Mobilteil
t1 Basisstation
t1 Netzteil
t1 Telefonanschlusskabel
t2 Akkus
t1 Benutzerhandbuch

20
Bewahren Sie das Verpackungsmaterial für spätere Transporte Ihres
Telefons an einem sicheren Ort auf.
5EINFÜHRUNG
5.1 Überblick Mobilteil (siehe P1)
# Symbol- und Zeichenerklärung
1
Aufwärts-Taste
tIm Ruhezustand: Drücken, um zur Anrufliste zu gelangen.
tIm Menümodus: Drücken, um die Menüpunkte nach
oben zu durchsuchen.
tIn der Telefonbuchliste/Wahlwiederholungsliste/
Anrufliste: Drücken, um die Liste nach oben zu
durchsuchen.
tWährend eines Anrufs: Drücken, um die Lautstärke der
Höreinheit zu erhöhen.
tWährend dem Klingeln: Drücken, um die Lautstärke des
Ruftons zu erhöhen.
2
rechte Softtaste (Eingabe löschen/zurück/stumm/
interne Anrufe)
tIm Hauptmenümodus: Drücken, um zurück zum
Ruhezustand zu gelangen.
tIm Untermenü-Modus: Drücken, um zur vorigen
Menüebene zu gelangen.
tIm Untermenü-Modus: Gedrückt halten, um zurück zum
Ruhemodus zu gelangen.
tIm Bearbeitungs-/Wählvorbereitungsmodus: Drücken,
um einen eingegebenen Buchstaben/eine eingegebene
Ziffer zu löschen.
tIm Bearbeitungs-/Wählvorbereitungsmodus: Gedrückt
halten, um alle eingegebenen Buchstaben/Ziffern zu
löschen.
tWährend eines Anrufs: Drücken, um den Lautsprecher
stumm/laut zu schalten.
tIm Ruhezustand: Drücken, um einen internen Anruf zu
einem anderen Mobilteil zu tätigen.
