AEQ NETBOX DSP User manual

AEQ NETBOX 32 AD
AEQ NETBOX 8 AD
AEQ NETBOX DSP
AUDIO OVER IP MULTICHANNEL INTERFACES
USER´S MANUAL
ED. 06/19
V. 1.0 - 03/06/2019
Firmware Versions: NETBOX 32/8 AD: CPU
1.35 / FPGA 1.05 /
AoIP CPU 4.0.9.2 or higher
NETBOX DSP: CPU 1.11 / FPGA 1.07 / DSP 1.05 /
AoIP CPU 4.0.9.3 or higher
Software Versions: NetBox Tool 2.0.0.14 or higher
NetBox RTC 1.0.0.18 or higher
NetBox Server 1.0.0.18 or higher

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
2
CONTENTS
1. INTRODUCTION.......................................................................................................................4
1.1. Fields of application of the product....................................................................................4
1.2. Description of NETBOX 32 AD audio interface. ................................................................4
1.3. Description of NETBOX 8 AD audio interface. ..................................................................4
1.4. Description of NETBOX DSP audio router. .......................................................................5
2. PHYSICAL DESCRIPTION OF THE UNITS. ...........................................................................6
2.1. NETBOX 32 AD interface physical description..................................................................6
2.1.1. Description of the front panel..................................................................................6
2.1.2. Description of the back panel and connections......................................................7
2.1.2.1. Ethernet Ports (LAN 1 and LAN 2)............................................................7
2.1.2.2. Analog Inputs and Outputs. ......................................................................7
2.1.2.3. Digital Inputs and Outputs.........................................................................9
2.1.2.3.1. Digital inputs/outputs jumpers configuration..................................10
2.1.2.4. General Purpose Inputs and Outputs (GPIO).........................................13
2.1.2.5. Power supply...........................................................................................14
2.1.2.6. Remarks on NETBOX 32 AD audio wiring..............................................14
2.2. NETBOX 8 AD interface physical description..................................................................14
2.2.1. Description of the front panel................................................................................14
2.2.2. Description of the back panel and connections....................................................15
2.2.2.1. Ethernet Ports (LAN 1 and LAN 2)..........................................................15
2.2.2.2. Analog Inputs and Outputs. ....................................................................15
2.2.2.3. Digital Inputs and Outputs.......................................................................16
2.2.2.3.1. Digital inputs/outputs jumpers configuration..................................17
2.2.2.4. General Purpose Inputs and Outputs (GPIO).........................................19
2.2.2.5. Power supply...........................................................................................19
2.2.2.6. Remarks on NETBOX 8 AD audio wiring................................................19
2.3. NETBOX DSP router physical description.......................................................................19
2.3.1. Description of the front panel................................................................................19
2.3.2. Description of the back panel and connections....................................................20
2.3.2.1. Ethernet Ports (LAN 1 and LAN 2)..........................................................20
2.3.2.2. General Purpose Inputs (GPI). ...............................................................21
2.3.2.3. General Purpose Outputs (GPO)............................................................22
2.3.2.4. Cooling fan..............................................................................................22
2.3.2.5. Power supply...........................................................................................22
2.3.2.6. Remarks on NETBOX DSP GPIOs wiring..............................................22
3. INSTALLATION AND USE OF APPLICATIONS...................................................................23
3.1. PC Applications for configuration and control..................................................................23
3.2. "AEQ NetBox Tool": control and configuration software for NETBOX 8, NETBOX 32
and NETBOX DSP..........................................................................................................23
3.2.1. Introduction. ..........................................................................................................23
3.2.2. Administration Tools. ............................................................................................24
3.2.2.1. "Configurations" submenu.......................................................................25
3.2.2.2. "GPIO’s" submenu..................................................................................29
3.2.2.3. "DIGITAL IO" submenu...........................................................................30
3.2.2.4. "Remote IP" submenu.............................................................................31
3.2.2.5. "Visual Radio" submenu..........................................................................33
3.2.2.6. "Gains" submenu. ...................................................................................35
3.2.2.7. "About NetBox Tool" submenu. ..............................................................37
3.2.3. Upgrading Tools....................................................................................................39
4. TECHNICAL SPECIFICATIONS. ...........................................................................................42
5. A.E.Q. GUARANTEE..............................................................................................................44
APPENDIX 1. INSTALLATION OF A DANTE NETWORK WITH AEQ MIXING CONSOLES
AND NETBOX.............................................................................................................................45

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
3
A1.1. AEQ Audio over IP System for two digital studios and a Central Control.....................45
A1.1.1. Installation...........................................................................................................45
A1.1.2. Turning ON.........................................................................................................46
A1.1.3. Monitoring audio and creating routes.................................................................46
A1.1.4. Optimization........................................................................................................46
A1.2. AEQ Audio over IP system for medium to large sized stations.....................................46
APPENDIX 2. ADDITIONAL INFORMATION............................................................................49

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
4
1. INTRODUCTION.
1.1. Fields of application of the product.
Using off-the-shelf routing equipment to send audio over IP in small to medium-sized systems
offers cost advantages over synchronous solutions using AES-10 (MADI) or TDM buses. These
have higher capacity, but require powerful hardware. Besides, large TDM systems can reduce
their cost and at the same time increase their flexibility when they are combined with IP audio
links to connect a few circuits with a central router.
That’s why, when developing the IP audio routing system at AEQ, we have created not only IP
connection devices for the consoles, but also connection panels that allow for audio input and
output installation wherever it’s necessary, as well as access boards for the AEQ BC2000D
router.
On the other hand, AEQ insists on offering interoperability with third party devices for the
convenience of our customers. Because of that, the solution we now present is based on
AUDINATE’s technology that is operating with extraordinary performance, making our systems
100% compatible with a wide selection of equipment for Broadcast, Recording Studios and
Professional Audio (see full listing at www.audinate.com).
Please consult the AEQ AoIP user's manual for more information.
Dante™ is a trademark of Audinate Pty Ltd.
Product includes license from Audinate Pty Ltd under US patent number(s) 7747725, 8005939, 7978696,
8171152 and others.Visit Audinate website for more details on Dante: http://www.audinate.com/
1.2. Description of NETBOX 32 AD audio interface.
NETBOX 32 AD is an interface for multi-channel AoIP. It allows you to insert and extract audio
channels in a system based on DANTE technology, at locations where the installation of AEQ
digital consoles is not planned. Due to its high input and output capacity, it is especially suitable
for central controls and link dispatches and also to increase or distribute the capacity of TDM
BUS matrices such as the AEQ BC2000D.
NETBOX 32 AD features 32 input and 32 output channels organized in 16 mono analog and 8
stereo digital channels. The stereo digital audio channels can be configured as AES/EBU or
SPDIF standard. It also incorporates 16 GPIs and 16 GPOs (each GPIO connector includes a
power supply pin to feed the external circuitry), as well as 256 virtual GPIs and 256 virtual
GPOs.
The unit can be turned into a 64x64 mixing and distributing audio matrix ("NETBOX 32 AD MX
Audio Router 64x64") by mixing specific firmware versions, a user license and "AEQ Netbox
RTC" application. Please consult section 3.2.2.1 of this manual and the user's manual of "AEQ
Netbox RTC" application for more information.
1.3. Description of NETBOX 8 AD audio interface.
NETBOX 8 AD is an interface for multi-channel AoIP. It allows you to insert and extract audio
channels in a system based on DANTE technology, at locations where the installation of AEQ
digital consoles is not planned. Due to its small footprint, it can be useful to give IP access to
analog or digital consoles that are not ready for this type of connectivity from factory, for
recording rooms, talk-rooms or any other auxiliary location.

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
5
NETBOX 8 AD features 8 inputs and 8 outputs, organized in 4 mono analog and 2 digital stereo
channels. Stereo digital ones can be configured as AES/EBU or SPDIF standards. The second
digital stereo channel can also be switched to a USB connector to ease the connection to an
audio workstation. It also provides 4 GPIs and 4 GPOs (the GPIO connector includes a power
supply pin to feed the external circuitry), as well as 256 virtual GPIs and 256 virtual GPOs.
The unit can be turned into a 16x16 mixing and distributing audio matrix ("NETBOX 8 AD MX
Audio Router 16x16") by mixing specific firmware versions, a user license and "AEQ Netbox
RTC" application. Please consult section 3.2.2.1 of this manual and the user's manual of "AEQ
Netbox RTC" application for more information.
1.4. Description of NETBOX DSP audio router.
NETBOX DSP device is able to receive audio from the DANTE network and then return it,
mixed and processed, to be used in another device or subsystem. It can also generate a test
tone (1KHz) and vumeters of all the inputs and outputs.
There are 4 different versions of NETBOX DSP: NETBOX DSP 64, NETBOX DSP 96,
NETBOX DSP 128 y NETBOX DSP 160, with routing and mixing capabilities on 64, 96, 128
or 160 inputs to any of the 64, 96, 128 or 160 outputs in the AoIP network, respectively. It's
possible to add any quantity of inputs (up to 160 depending on the version) in any of the
outputs. In addition, there is gain control for all the inputs, outputs and cross points. Any output
can also be muted.
All 4 versions have the same processing capability on a maximum of 64 selectable inputs, that
can be sent processed to any of the outputs. The available processes are:
•Frequency: high-pass, low-pass and band-pass filters and 4-band parametric equalizer.
•Dynamics: compressor, expander, noise gate, limiter and DLP combinations.
•Delay.
It also incorporates 16 GPIs and 16 GPOs (each GPIO connector includes a power supply pin
to feed the external circuitry), as well as 256 virtual GPIs and 256 virtual GPOs that can be
transported through the IP network between compatible devices (this way, a GPI can drive the
GPOs of other devices).

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
6
2. PHYSICAL DESCRIPTION OF THE UNITS.
In order to understand the installation and cabling process associated to each unit, first you
need to be familiar with the connectors and other specific elements of the AoIP solution
described in this manual and the equipment front and back panels.
2.1. NETBOX 32 AD interface physical description.
2.1.1. Description of the front panel.
There are indicators related to the unit status, communications and audio levels.
POWER ON LED: indicates the status of the unit power supply.
•Off: no mains input.
•Green: power supply ON.
LAN LEDs: indicate the status of the audio local area network: LAN 1 (main interface)
and LAN 2 (secondary interface).
Status:
•Off: no local network connection.
•Blinking green: link is established at data level.
If the boards are wired to a dedicated audio network using a switch, only LAN 1 should
be blinking. If the wiring is connected in "Daisy Chain" mode, without switches, or there
is a redundant network, both LEDs should be blinking. IMPORTANT NOTE: When there
is a redundant network, primary and secondary interfaces must be connected to
separated networks.
AUDIO LEVEL LEDs: Each LED indicates the level of the corresponding device audio
input / output:
•LED off: the channel is muted, or transmits or receives (depending on whether
it is an output or an input) at a level below -60dBFS.
•Green LED: channel is transmitting or receiving audio (depending on whether it
is an output or an input) at a level between -60dBFS and -20dBFS.
•Amber LED: channel is transmitting or receiving audio (depending on whether it
is an output or an input) at a level between -20dBFS and -6dBFS.
•Red LED: the channel is saturated or "clipping" (above -6dBFS).
On / Off switch.
A
A
B
C
B
C
D
D

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
7
2.1.2. Description of the back panel and connections.
2.1.2.1. Ethernet Ports (LAN 1 and LAN 2).
NETBOX 32 includes two Ethernet ports: LAN 1 must always be wired, while LAN 2 is only used
when the system is wired in "Daisy Chain" mode or a redundant system is set up. IMPORTANT
NOTE: When there is a redundant network, primary and secondary interfaces must be
connected to separated networks.
Physically, both are RJ45 10/100/1000, connectors, with the pinout described below:
RJ45 connector pinout
2.1.2.2. Analog Inputs and Outputs.
The physical connectors used are DB15-female. INPUTS (IN) connectors are placed in the
bottom row while OUTPUTS (OUT) are located in the upper row, with the following pinout:
Pinout of DB15 ANALOG IN 1 - 4 connector
- Pin 1: ANALOG 1 IN + - Pin 9: ANALOG 1 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 2 IN + - Pin 11: ANALOG 2 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 3 IN + - Pin 13: ANALOG 3 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 4 IN + - Pin 15: ANALOG 4 IN -
- Pin 8: GND
B
A
Pin 4:
Blue
Pin 3:
White and Green
Pin 2:
Orange
Pin 1:
White and Orange
Pin 5:
White and Blue
Pin 6:
Green
Pin 7:
White and Brown
Pin 8:
Brown
E
A
D
C
B

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
8
Pinout of DB15 ANALOG IN 5 - 8 connector
- Pin 1: ANALOG 5 IN + - Pin 9: ANALOG 5 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 6 IN + - Pin 11: ANALOG 6 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 7 IN + - Pin 13: ANALOG 7 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 8 IN + - Pin 15: ANALOG 8 IN -
- Pin 8: GND
Pinout of DB15 ANALOG IN 9 - 12 connector
- Pin 1: ANALOG 9 IN + - Pin 9: ANALOG 9 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 10 IN + - Pin 11: ANALOG 10 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 11 IN + - Pin 13: ANALOG 11 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 12 IN + - Pin 15: ANALOG 12 IN -
- Pin 8: GND
Pinout of DB15 ANALOG IN 13 - 16 connector
- Pin 1: ANALOG 13 IN + - Pin 9: ANALOG 13 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 14 IN + - Pin 11: ANALOG 14 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 15 IN + - Pin 13: ANALOG 15 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 16 IN + - Pin 15: ANALOG 16 IN -
- Pin 8: GND
Pinout of DB15 ANALOG OUT 1 - 4 connector
- Pin 1: ANALOG 1 OUT + - Pin 9: ANALOG 1 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 2 OUT + - Pin 11: ANALOG 2 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 3 OUT + - Pin 13: ANALOG 3 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 4 OUT + - Pin 15: ANALOG 4 OUT -
- Pin 8: GND
Pinout of DB15 ANALOG OUT 5 - 8 connector
- Pin 1: ANALOG 5 OUT + - Pin 9: ANALOG 5 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 6 OUT + - Pin 11: ANALOG 6 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 7 OUT + - Pin 13: ANALOG 7 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 8 OUT + - Pin 15: ANALOG 8 OUT -
- Pin 8: GND
Pinout of DB15 ANALOG OUT 9 - 12 connector
- Pin 1: ANALOG 9 OUT + - Pin 9: ANALOG 9 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 10 OUT + - Pin 11: ANALOG 10 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 11 OUT + - Pin 13: ANALOG 11 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 12 OUT + - Pin 15: ANALOG 12 OUT -
- Pin 8: GND

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
9
Pinout of DB15 ANALOG OUT 13 - 16 connector
- Pin 1: ANALOG 13 OUT + - Pin 9: ANALOG 13 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 14 OUT + - Pin 11: ANALOG 14 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 15 OUT + - Pin 13: ANALOG 15 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 16 OUT + - Pin 15: ANALOG 16 OUT -
- Pin 8: GND
2.1.2.3. Digital Inputs and Outputs.
The physical connectors used are DB15-female. INPUTS (IN) connectors are placed in the
bottom row while OUTPUTS (OUT) are located in the upper row, with the following pinout:
Pinout of DB15 DIGITAL IN 17 - 24 connector
- Pin 1: DIGITAL 17-18 IN + - Pin 9: DIGITAL 17-18 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: DIGITAL 19-20 IN + - Pin 11: DIGITAL 19-20 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: DIGITAL 21-22 IN + - Pin 13: DIGITAL 21-22 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: DIGITAL 23-24 IN + - Pin 15: DIGITAL 23-24 IN -
- Pin 8: GND
Pinout of DB15 DIGITAL IN 25 - 32 connector
- Pin 1: DIGITAL 25-26 IN + - Pin 9: DIGITAL 25-26 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: DIGITAL 27-28 IN + - Pin 11: DIGITAL 27-28 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: DIGITAL 29-30 IN + - Pin 13: DIGITAL 29-30 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: DIGITAL 31-32 IN + - Pin 15: DIGITAL 31-32 IN -
- Pin 8: GND
Pinout of DB15 DIGITAL OUT 17 - 24 connector
- Pin 1: DIGITAL 17-18 OUT + - Pin 9: DIGITAL 17-18 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: DIGITAL 19-20 OUT + - Pin 11: DIGITAL 19-20 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: DIGITAL 21-22 OUT + - Pin 13: DIGITAL 21-22 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: DIGITAL 23-24 OUT + - Pin 15: DIGITAL 23-24 OUT -
- Pin 8: GND
Pinout of DB15 DIGITAL OUT 25 - 32 connector
- Pin 1: DIGITAL 25-26 OUT + - Pin 9: DIGITAL 25-26 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: DIGITAL 27-28 OUT + - Pin 11: DIGITAL 27-28 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: DIGITAL 29-30 OUT + - Pin 13: DIGITAL 29-30 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: DIGITAL 31-32 OUT + - Pin 15: DIGITAL 31-32 OUT -
- Pin 8: GND
C

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
10
Remarks:
-Each of the eight digital audio inputs and outputs include two different audio channels,
according to AES 3 or SPDIF standard.
-The first digital input (17-18) synchronizes NETBOX 32 with the source connected to it,
emitting an AES 3/SPDIF or AES 11 formatted stream.
-The outputs can be used to provide synchronization to other devices that can extract it
from an AES 3 formatted audio stream.
2.1.2.3.1. Digital inputs/outputs jumpers configuration.
IMPORTANT NOTE: Access and configuration of the configuration jumpers require a previous
experience in installing and configuring computer or electronic cads. Don’t open the unit if you
lack this experience in order to avoid risk of electrical shock or damages to the system.
Digital inputs and outputs are programmed by default as AES/EBU. If compatibility with
SPDIF equipment is required, you must open the unit and change the corresponding
configuration jumpers.
-Opening the unit.
It’s VERY IMPORTANT to turn first the equipment off and disconnect the power supply
cable. Remove the 12 screws located at the top cover. Pull up from the top cover and
remove it.
-Finding the jumpers location.
Place the unit with the connectors facing towards you and recognize the following zones
inside it:
5 TO 8 (25 TO 32) DIGITAL INPUTS AND OUTPUTS
PROGRAMMING ZONE
1 TO 4 (17 TO 24) DIGITAL INPUTS AND OUTPUTS
PROGRAMMING ZONE

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
11
-Programming digital outputs 1 to 4 as S/PDIF.
In order to provide outputs to S/PDIF equipments, the programming procedure
described below adapts the levels and unbalances the signals by joining OUT1-, OUT2-
, OUT3- and OUT4- to their corresponding GND, so the signal is taken from each OUT+
to OUT- (or GND).
At the "1 TO 4 DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can
change the outputs one by one from AES/EBU to S/PDIF by moving the 4 jumpers
associated to each output from position 1-2 (down) to position 2-3 (up), as shown in the
following image:
Position 1-2: AES/EBU
Position 2-3: SPDIF
Digital output 4 Digital output 3 Digital output 2 Digital output 1
Jumpers J30, J31, Jumpers J8, J17 Jumpers J25, J26, Jumpers J3, J13,
J36 and J35 J18 and J16 J34 and J33 J14 and J12
-Programming digital inputs 1 to 4 as S/PDIF.
In order to use S/PDIF inputs, the programming described above adapts levels and
unbalance signals by joining IN1-, IN2-, IN3- and IN4- to their associated grounds, so
each signal is taken from the corresponding IN+ and its GND (or IN-).
At the "1 TO 4 DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can
change the inputs one by one from AES/EBU to S/PDIF by moving the 5 jumpers
associated to each input from position 1-2 (down) to position 2-3 (up), as shown in the
previous image.
Digital input 4 Digital input 3 Digital input 2 Digital input 1
Jumpers J28, J21, J22, Jumpers J7, J6, J9, Jumpers J23, J19, J20, Jumpers J2, J1, J4,
J32 and J29 J10 and J15 J27 and J24 J5 and J11
Position 1-2: AES/EBU
Position 2
-
3: S/PDIF

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
12
-Programming digital inputs 5 to 8 as S/PDIF.
In order to use S/PDIF inputs, the programming described below adapts levels and
unbalance signals by joining IN5-, IN6-, IN7- and IN8- to their associated grounds, so
each signal is taken from the corresponding IN+ and its GND (or IN-).
At the "5 TO 8 DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can
change the inputs one by one from AES/EBU to S/PDIF by moving the 5 jumpers
associated to each input from position 1-2 (up) to position 2-3 (down), as shown in the
following image:
Digital output 8 Digital output 7 Digital output 6 Digital output 5
Jumpers J71, J72, Jumpers J52, J54 Jumpers J69, J70, Jumpers J48, J50,
J67 and J66 J53 and J44 J62 and J61 J49 and J39
Position 1-2: AES/EBU
Position 2-3: S/PDIF
-Programming digital outputs 5 to 8 as S/PDIF.
In order to provide outputs to S/PDIF equipments, the programming procedure
described above adapts the levels and unbalances the signals by joining OUT5-, OUT6-
, OUT7- and OUT8- to their corresponding GND, so the signal is taken from each OUT+
to OUT- (or GND).
Position 1
-
2: AES/EBU
Position 2-3: S/PDIF
Digital input 8 Digital input 7 Digital input 6 Digital input 5
Jumpers J65, J68, J58, Jumpers J51, J46, J45, Jumpers J60, 63, J56, Jumpers J47, J41, J40,
J57 and J64
J42
and
J43
J55
and
J59
J37 and J38

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
13
At the "5 TO 8 DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can
change the outputs one by one from AES/EBU to S/PDIF by moving the 4 jumpers
associated to each output from position 1-2 (up) to position 2-3 (down), as shown in the
previous image.
2.1.2.4. General Purpose Inputs and Outputs (GPIO).
The physical connectors used are DB15-female. INPUTS (GPI) connectors are placed in the
bottom row while OUTPUTS (GPO) are located in the upper row, with the following pinout:
Pinout of DB15 GPI 1 - 8 connector
- Pin 1: GPI 1 - Pin 9: GND_GPI 1-4
- Pin 2: GPI 2 - Pin 10: GND_GPI 1-4
- Pin 3: GPI 3 - Pin 11: GND_GPI 1-4
- Pin 4: GPI 4 - Pin 12: +5V GPIO
- Pin 5: GPI 5 - Pin 13: GND_GPI 5-8
- Pin 6: GPI 6 - Pin 14: GND_GPI 5-8
- Pin 7: GPI 7 - Pin 15: GND_GPI 5-8
- Pin 8: GPI 8
Remarks: please note that a common ground (GND) is provided for inputs 1 to 4 and another
one exists for inputs 5 to 8. Pin 12 supplies a +5V reference voltage to ease wiring.
Pinout of DB15 GPI 9 - 16 connector
- Pin 1: GPI 9 - Pin 9: GND_GPI 9-12
- Pin 2: GPI 10 - Pin 10: GND_GPI 9-12
- Pin 3: GPI 11 - Pin 11: GND_GPI 9-12
- Pin 4: GPI 12 - Pin 12: +5V GPIO
- Pin 5: GPI 13 - Pin 13: GND_GPI 13-16
- Pin 6: GPI 14 - Pin 14: GND_GPI 13-16
- Pin 7: GPI 15 - Pin 15: GND_GPI 13-16
- Pin 8: GPI 16
Remarks: please note that a common ground (GND) is provided for inputs 9 to 12 and another
one exists for inputs 13 to 16. Pin 12 supplies a +5V reference voltage to ease wiring.
Pinout of DB15 GPO 1 - 8 connector
- Pin 1: GPO 1 - Pin 9: GND_GPO 1-4
- Pin 2: GPO 2 - Pin 10: GND_GPO 1-4
- Pin 3: GPO 3 - Pin 11: GND_GPO 1-4
- Pin 4: GPO 4 - Pin 12: +5V GPIO
- Pin 5: GPO 5 - Pin 13: GND_GPO 5-8
- Pin 6: GPO 6 - Pin 14: GND_GPO 5-8
- Pin 7: GPO 7 - Pin 15: GND_GPO 5-8
- Pin 8: GPO 8
Remarks: please note that a common ground (GND) is provided for inputs 1 to 4 and another
one exists for inputs 5 to 8. Pin 12 supplies a +5V reference voltage to ease wiring.
D

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
14
Pinout of DB15 GPO 9 - 16 connector
- Pin 1: GPO 9 - Pin 9: GND_GPO 9-12
- Pin 2: GPO 10 - Pin 10: GND_GPO 9-12
- Pin 3: GPO 11 - Pin 11: GND_GPO 9-12
- Pin 4: GPO 12 - Pin 12: +5V GPIO
- Pin 5: GPO 13 - Pin 13: GND_GPO 13-16
- Pin 6: GPO 14 - Pin 14: GND_GPO 13-16
- Pin 7: GPO 15 - Pin 15: GND_GPO 13-16
- Pin 8: GPO 16
Remarks: please note that a common ground (GND) is provided for inputs 9 to 12 and another
one exists for inputs 13 to 16. Pin 12 supplies a +5V reference voltage to ease wiring.
2.1.2.5. Power supply.
The mains power supply connector is located in the back left area of the unit. The internal
power supply is auto ranging, accepting: 90 - 132 V AC & 187 - 264 V AC, 47-63Hz. Optionally,
a second (backup) power supply can be installed in order to have redundancy.
2.1.2.6. Remarks on NETBOX 32 AD audio wiring.
AEQ eases the installation task providing the connection between the system
and the connected pieces of equipment by providing on demand the "FR CAB
INP" wiring accessory, consisting on a DB15 male connected to four balanced
and shielded pairs, 6 meters long, unterminated, in order to ease the wiring of 4
audio pairs.
The "CP CAB GPIO" accessory consists on a DB15 male connector connected
to a 15-way wire, 6 meters long, unterminated, for GPIs and GPOs. Each cable
allows you to connect the 8 GPIs or GPOs provided by each connector.
2.2. NETBOX 8 AD interface physical description.
2.2.1. Description of the front panel.
There are indicators related to the unit status, communications and audio levels.
POWER ON LED: indicates the status of the unit power supply:
•Off: no mains input.
•Green: power supply ON.
LAN LEDs: indicate the status of the audio local area network: LAN 1 (main interface)
and LAN 2 (secondary interface):
•Off: no local network connection.
•Blinking green: link is established at data level.
A
B
C
A
B
E

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
15
If the boards are wired to a dedicated audio network using a switch, only LAN 1 should
be blinking. If the wiring is connected in "Daisy Chain" mode, without switches, or there
is a redundant network, both LEDs should be blinking. IMPORTANT NOTE: When there
is a redundant network, primary and secondary interfaces must be connected to
separated networks.
AUDIO LEVEL LEDs: Each LED indicates the level of the corresponding device audio
input / output:
•LED off: the channel is muted, or transmits or receives (depending on whether
it is an output or an input) at a level below -60dBFS.
•Green LED: channel is transmitting or receiving audio (depending on whether it
is an output or an input) at a level between -60dBFS and -20dBFS.
•Amber LED: channel is transmitting or receiving audio (depending on whether it
is an output or an input) at a level between -20dBFS and -6dBFS.
•Red LED: the channel is saturated or "clipping" (above -6dBFS).
2.2.2. Description of the back panel and connections.
2.2.2.1. Ethernet Ports (LAN 1 and LAN 2).
NETBOX 8 includes two Ethernet ports: LAN 1 must always be wired, while LAN 2 is only used
when the system is wired in "Daisy Chain" mode or a redundant system is set up. IMPORTANT
NOTE: When there is a redundant network, primary and secondary interfaces must be
connected to separated networks.
Physically, both are RJ45 10/100/1000, connectors, with the pinout described below:
2.2.2.2. Analog Inputs and Outputs.
The physical connectors used are DB15-female. INPUTS (IN) connector is placed in the bottom
row while OUTPUTS (OUT) is located in the upper row, with the following pinout:
A
A
C
D
C
B
E
E
Pin 4:
Blue
Pin 3:
White and Green
Pin 2:
Orange
Pin 1:
White and Orange
Pin 5:
White and Blue
Pin 6:
Green
Pin 7:
White and Brown
Pin 8:
Brown
B

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
16
Pinout of DB15 ANALOG IN 1 - 4 connector
- Pin 1: ANALOG 1 IN + - Pin 9: ANALOG 1 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 2 IN + - Pin 11: ANALOG 2 IN -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 3 IN + - Pin 13: ANALOG 3 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 4 IN + - Pin 15: ANALOG 4 IN -
- Pin 8: GND
Pinout of DB15 ANALOG OUT 1 - 4 connector
- Pin 1: ANALOG 1 OUT + - Pin 9: ANALOG 1 OUT -
- Pin 2: GND - Pin 10: GND
- Pin 3: ANALOG 2 OUT + - Pin 11: ANALOG 2 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: ANALOG 3 OUT + - Pin 13: ANALOG 3 OUT -
- Pin 6: GND - Pin 14: GND
- Pin 7: ANALOG 4 OUT + - Pin 15: ANALOG 4 OUT -
- Pin 8: GND
2.2.2.3. Digital Inputs and Outputs.
The physical connector used is DB15-female. In addition, there is a switch ("7&8") to assign the
second digital input and output to that DB15 female connector or, alternatively, to a USB
connector.
This way, when the switch is in the upper position, the DB15 female connector will include the 2
INPUTS (IN) and the 2 OUTPUTS (OUT), using the following pinout:
Pinout of DB15 DIGITAL IN/OUT 5-8 connector
- Pin 1: DIGITAL 5-6 IN + - Pin 9: DIGITAL 5-6 IN -
- Pin 2: GND - Pin 10: GND
- Pin 3: DIGITAL 5-6 OUT+ - Pin 11: DIGITAL 5-6 OUT -
- Pin 4: GND - Pin 12: GND
- Pin 5: DIGITAL 7-8 IN + - Pin 13: DIGITAL 7-8 IN -
- Pin 6: GND - Pin 14: GND
- Pin 7: DIGITAL 7-8 OUT+ - Pin 15: DIGITAL 7-8 OUT -
- Pin 8: GND
Remarks:
-Each of the two digital audio inputs and outputs include two different audio channels,
according to AES 3 or SPDIF standard. The second one has also two channels in USB
connector when the switch is in the lower position.
-The first digital input (5-6) synchronizes NETBOX 8 with the source connected to it,
emitting an AES 3/SPDIF or AES 11 formatted stream.
-The outputs can be used to provide synchronization to other devices that can extract it
from an AES 3 formatted audio stream.
USB Digital input and output 2 (7-8).
When the rear switch is in the lower position, AEQ NETBOX 8 provides the second stereo
digital input through the USB type-B connector labeled "USB". NOTE: The second output is
always available through the DB15 connector as well as through the USB connector, regardless
of the switch position.
C

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
17
When connecting the USB module to a PC through the USB port, the PC automatically
recognizes it as a new audio device (identified as "USB Audio CODEC"). Audio can be sent to it
from any playback program, like with any other professional external soundcard. Also, audio
can be recorded from NETBOX by using any recording application. The card is "plug&play" on
Microsoft Windows™ operating systems and Apple Computer Mac OS™, not requiring any
special driver.
The supported sampling rates are 32 KHz, 44.1 KHz y 48 KHz, with internal Sample Rate
Converter (SRC) to the 48 KHz frequency used internally by the DANTE-based AoIP AEQ
system.
2.2.2.3.1. Digital inputs/outputs jumpers configuration.
IMPORTANT NOTE: Access and configuration of the configuration jumpers require a previous
experience in installing and configuring computer or electronic cads. Don’t open the unit if you
lack this experience in order to avoid risk of electrical shock or damages to the system.
Digital inputs and outputs are programmed by default as AES/EBU. If compatibility with
SPDIF equipment is required, you must open the unit and change the corresponding
configuration jumpers.
-Opening the unit.
It’s VERY IMPORTANT to turn first the equipment off and disconnect the power supply
cable. Remove the 3 screws located at the top of the rear panel and the 3 one located
at the front of the unit’s base. Pull up from the top cover and remove it.
-Finding the jumpers location.
Place the unit with the front facing towards you and recognize the following zone inside
it:
DIGITAL INPUTS AND
OUTPUTS PROGRAMMING
ZONE

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
18
-Programming digital inputs 1 and 2 as S/PDIF.
In order to use S/PDIF inputs, the programming described below adapts levels and
unbalance signals by joining IN1- and IN2- to their associated grounds, so each signal
is taken from the corresponding IN+ and its GND (or IN-). Take note that when the rear
switch is in USB position, the digital input 2 will be placed at the USB connector
regardless of the configuration programmed by jumpers.
At the "DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can change
the inputs one by one from AES/EBU to S/PDIF by moving the 5 jumpers associated to
each input from position 1-2 (up) to position 2-3 (down), as shown in the following
image:
-Programming digital outputs 1 and 2 as S/PDIF.
In order to provide outputs to S/PDIF equipments, the programming procedure
described above adapts the levels and unbalances the signals by joining OUT1- and
OUT2- to their corresponding GND, so the signal is taken from each OUT+ to OUT– (or
GND). Take note that the digital output 2 will be duplicated at the USB connector
regardless of the configuration programmed by jumpers.
At the "DIGITAL INPUTS AND OUTPUTS PROGRAMMING ZONE", you can change
the outputs one by one from AES/EBU to S/PDIF by moving the 4 jumpers associated
to each output from position 1-2 (up) to position 2-3 (down), as shown in the previous
image.
Position 1-2: AES/EBU
Position 2-3: S/PDIF
Digital input 1 Digital input 2
Jumpers J7, J10, J5, Jumpers J17, J16, J15,
J4 and J6 J13 and J14
Digital output 1 Digital output 2
Jumpers J11, J12, Jumpers J18, J21,
J9 and J8 J20 and J19
Position 1-2: AES/EBU
Position 2
-
3: S/PDIF

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
19
2.2.2.4. General Purpose Inputs and Outputs (GPIO).
The physical connector used is DB15-female, with the following pinout:
- Pin 1: GPI 1 - Pin 9: GND_GPI 1-4
- Pin 2: GPI 2 - Pin 10: GND_GPI 1-4
- Pin 3: GPI 3 - Pin 11: GND_GPI 1-4
- Pin 4: GPI 4 - Pin 12: +5V GPIO 1-4
- Pin 5: GPO 1 - Pin 13: GND_GPO 1-4
- Pin 6: GPO 2 - Pin 14: GND_GPO 1-4
- Pin 7: GPO 3 - Pin 15: GND_GPO 1-4
- Pin 8: GPO 4
Remarks: please note that a common ground (GND) is provided for inputs and another one
exists for outputs. Pin 12 supplies a +5V reference voltage to ease wiring.
2.2.2.5. Power supply.
The conector for external 48V DC adapter is located in the back left area of the unit. The
provided universal mains adapter operates from 90 to 264 V AC, 47-63Hz.
2.2.2.6. Remarks on NETBOX 8 AD audio wiring.
AEQ eases the installation task providing the connection between the system
and the connected pieces of equipment by providing on demand the "FR CAB
INP" wiring accessory, consisting on a DB15 male connected to four balanced
and shielded pairs, 6 meters long, unterminated, in order to ease the wiring of 4
audio pairs.
The "CP CAB GPIO" accessory consists on a DB15 male connector connected
to a 15-way wire, 6 meters long, unterminated, for GPIs and GPOs. Each cable
allows you to connect the GPIs or GPOs provided by the unit.
2.3. NETBOX DSP router physical description.
2.3.1. Description of the front panel.
There are indicators related to the unit status and communications.
E
D
C
D
B
A

AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel inter aces
20
ERROR LED: indicates the initialization status or a hardware error of the unit
•It is red lit during the boot of the system. If it doesn’t extinguish within some
seconds, the unit needs servicing.
POWER LEDs: indicate the status of the unit power supply: MAIN (main power supply)
and BACKUP (redundant power supply).
Status:
•Off: no mains input.
•Green: power supply ON.
LAN LEDs: indicate the status of the audio local area network: LAN 1 (main interface)
and LAN 2 (secondary interface).
Status:
•Off: no local network connection.
•Blinking green: link is established at data level.
If the boards are wired to a dedicated audio network using a switch, only LAN 1 should
be blinking. If the wiring is connected in "Daisy Chain" mode, without switches, or there
is a redundant network, both LEDs should be blinking. IMPORTANT NOTE: When there
is a redundant network, primary and secondary interfaces must be connected to
separated networks.
On / Off switch.
2.3.2. Description of the back panel and connections.
2.3.2.1. Ethernet Ports (LAN 1 and LAN 2).
NETBOX DSP includes two Ethernet ports: LAN 1 must always be wired, while LAN 2 is only
used when the system is wired in "Daisy Chain" mode or a redundant system is set up.
IMPORTANT NOTE: When there is a redundant network, primary and secondary interfaces
must be connected to separated networks.
Physically, both are RJ45 10/100/1000, connectors, with the pinout described below:
A
C
D
A
B
E
A
B
C
D
