INSTRUCTION MANUAL
Water Separator
Series VT2

This instruction manual shall not be reproduced, copied and
distributed, neither in parts nor completely, without the
manufacturer's written permit.
All rights reserved
The instruction manual is based on the technical and product-specific
parameters. The manufacturer reserves the right to add
supplementary information to the instruction manual.
Using a device outside the specified conditions and contrary to its
designated use will lead to the forfeiture of all warranty claims.
As of: 11_2017

CONTENTS
Page 1 of 15
1Notes on this instruction manual____________________________________________ 2
Target groups ______________________________________________________________ 2
Conventions _______________________________________________________________ 2
Designated use ____________________________________________________________ 3
2Safety ____________________________________________________________________________ 3
Safety devices______________________________________________________________ 3
Hazards from accessories__________________________________________________ 3
Authorised operator _______________________________________________________ 4
User _______________________________________________________________________ 4
Safety instructions _________________________________________________________ 4
3Construction ____________________________________________________________________ 5
Connections on the device rear side _______________________________________ 6
Drain plug on device rear side _____________________________________________ 6
4Transport and installation ____________________________________________________ 7
Transport __________________________________________________________________ 7
Scope of delivery___________________________________________________________ 7
Operating conditions_______________________________________________________ 7
Installation_________________________________________________________________ 7
5Operation and operator control _____________________________________________ 8
Operating elements________________________________________________________ 8
Commissioning ____________________________________________________________ 9
Operation_________________________________________________________________10
6Maintenance and service ____________________________________________________10
Maintenance work ________________________________________________________10
Drain residual water ______________________________________________________11
Clean coarse filter_________________________________________________________11
7Troubleshooting _______________________________________________________________12
Faults _____________________________________________________________________12
8Shutdown, storage and disposal____________________________________________13
Shutdown_________________________________________________________________13
Storage ___________________________________________________________________13
Disposal __________________________________________________________________13
9Specifications __________________________________________________________________14
10 Accessories_____________________________________________________________________14
11 EU Declaration of Conformity _______________________________________________15

NOTES ON THIS INSTRUCTION MANUAL
Page 2 of 15
1Notes on this instruction manual
This instruction manual is part of the product. It contains all important information on
how to transport, install, operate, store and dispose of the device from AERIAL properly
and safely. Therefore keep this instruction manual in a safe place.
Target groups
This instruction manual addresses the users and operators of the devices manufactured
by AERIAL. They must have read and understood the instruction manual. The physical
and psychological preconditions for proper and safety-conscious handling of the devices
must always be guaranteed.
Conventions
Warnings
In this instruction manual you will find information intended to warn you of possible
hazards at the beginning of a specific action.
DANGER
Type and source of hazard
This symbol in connection with the signal word "DANGER" refers to a
life-threatening situation. Failure to observe this warning will result in
serious, fatal injury.
This arrow marks precise steps to avert danger which must
always be performed.
WARNING
Type and source of hazard
This symbol in connection with the signal word "WARNING" refers to a
dangerous situation. Failure to observe this warning can result in life-
threatening injury and death.
This arrow marks precise steps to avert danger which must be
performed.
CAUTION
Type and source of hazard
This symbol in connection with the word "CAUTION" warns of minor
or moderate injury and potential material damage.
Measures to prevent personal injury or material damage are
described here.

SAFETY
Page 3 of 15
In this box you find tips and information concerning the use of the
device.
Designated use
The water separator VT2 shall be used exclusively as a water suction device. The device is
designed for vacuum operation. Please observe the permissible combinations (see chapter
Operator Control, page 8 - 9).
The water separator VT2 is designed exclusively for use at atmospheric pressure. Operating
the adsorption dryers within the limits of designated use also involves observing the specified
operating conditions
(refer to page7). Any use of the device going beyond the designated use specified above is
considered contrary to its designated use.
Misuse is concerned if the water separator VT2 is used for purposes not included in
designated use. In these cases the manufacturer does not assume any liability for personal
and material damage.
2Safety
Safety devices
The water separator VT2 was subjected to thorough safety testing. Improper operation
or misuse will cause danger to
the operator,
the machine and other material property of the user,
efficient operation of the machine.
All persons involved in the installation, commissioning, operation, maintenance and
servicing of the devices must
be properly qualified,
closely observe the instructions set out in this manual.
Hazards from accessories
Air hoses, power cables and air filters must be properly installed,
and must not disable the protection devices of the VT2. The operating elements must
always be accessible.

SAFETY
Page 4 of 15
Authorised operator
The water separator VT2 may only be operated by persons commissioned and
instructed by the user. In the working area the operator is responsible to third parties.
For all activities on the device the responsibilities must be clearly defined and observed.
Unclear competences are a safety risk.
User
The user must
make the instruction manual accessible to the operator,
make sure that the operator has read and understood the instruction manual.
Safety instructions
The devices must not be used under the following conditions:
in rooms with potentially explosive atmospheres.
in rooms with aggressive atmospheres, e.g. ammonia.
in rooms with water with a pH value outside the range from 4 to 9.
In rooms with salt or liquids with a salt content > 1%.
in rooms with high solvent concentration.
in rooms with extreme dust load.
In addition the following must be observed when using the water separator VT2:
Work on electrical equipment may only be carried out by skilled electricians.
Original spare parts or spare parts approved by the manufacturer shall exclusively
be used.

CONSTRUCTION
Page 5 of 15
3Construction
Fig.
1: AERIAL water separator series VT2 - overview
1 On / Off switch 6 Appliance socket for compressor
2 Connection for compressor 7 Power cable
3 Control panel with full text
display 8 G¾“ threaded connector for waste water
4 Tension lock 9 Holder for power cable
5 Water container and pump
Water separator VT2 ready for connection designed for screed insulation layer drying
in the vacuum mode, with compressor or soundbox VP2/VP3/VP6.
The connected compressor (soundbox VP2/VP3/VP6) draws the air/water taken in (e.g.
from the insulation layer) through the water separator. The water is collected in the
bottom part of the VT2. The integrated level controller switches the side channel
compressor off and the waste water pump on. The waste water pump pumps the water
out of the VT2 through the waste water hose.
When the water level in the VT2 drops below approx. 1 cm, the compressor switches on
again and operates up to the next pumping process.

CONSTRUCTION
Page 6 of 15
Use tubes of 50 mm diameter for efficient drying. Smaller tubes result
in high energy consumption and longer drying times.
Connections on the device rear side
Fig.
2: AERIAL water separator VT2 rear side
1 Screw cap 3 Screw cap
2 Connection pipe
Ø38 mm / Ø50 mm or Ø50 pipe
Three intake pipes are arranged on the device rear side. The intake holes not used can
be closed by screw caps. Screw caps are included in the scope of delivery.
Drain plug on device rear side
Fig.
3: AERIAL water separator VT2 rear side
1 Drain plug for residual water
The device foot is provided with a drain plug. To discharge residual water the drain plug
can be turned out.

TRANSPORT AND INSTALLATION
Page 7 of 15
4Transport and installation
Transport
1. Remove the packaging material completely and dispose of according to the local
regulations.
2. Check the delivery for completeness.
3. Use the lateral handles or the handle in the middle of the cover to transport the
water separator to the place of installation.
Scope of delivery
Water separator VT2, accessories (see chapter 10, page 14)
One instruction manual
Operating conditions
The water separator VT2 is designated for vacuum drying and screed insulation layer
drying in the vacuum mode. It works without problems in the temperature range from
0 °C to 35 °C.
Installation
The devices can be stacked, and are
provided with fixing points for a belt
system on the right and left.
Fig.
4: Fixing points for belt system
Connection
DANGER
Danger to life due to electric shock
Prior to commissioning the technical data of the water
separator VT2 must be compared with the conditions prevailing
in the room of installation!
The following items must be checked prior to electrical connection of the water
separator:
Is the mains voltage in conformity with the voltage of the device?
Are socket and supply system sufficiently fused?
RCCB required!
Connect the power plug of the water separator to a suitable power outlet.

OPERATION AND OPERATOR CONTROL
Page 8 of 15
5Operation and operator control
CAUTION
Danger of injury and damage to appliance
Inadmissible ambient conditions and improper operation of the device
may constitute a risk.
Read the instruction manual before commissioning the water
separator VT2.
Operating elements
Fig. 5: Water separator VT2 control panel
1 On / Off switch 5 Appliance socket fuse 16 A
2 Membrane key "P" 6 Membrane key "Info"
3 Watt meter (MID) 7 Display LED matrix, blue
4 Appliance socket
The energy consumption of the compressor connected to the appliance socket (item 4)
is not counted by the calibrated watt meter (MID) (item 7).

OPERATION AND OPERATOR CONTROL
Page 9 of 15
Membrane key "Info"
Duration 5 seconds
Press 1x Total delivery volume of the pump
(value not erasable)
Delivery volume since last
switching-on of device
Membrane key "P"
Press Pump switches on and runs as long
as the key is kept pressed,
indicator flashes
Commissioning
To commission the air water separator VT2 proceed as follows:
1. Connect the water separator VT2 electrically, s. page 7.
2. Ensure that the waste water hose has been connected to the threaded connector
for waste water.
3. Ensure that the air tube has been connected to the connector for the compressor
(s. page 5, Fig. 1, item 2) and to the air intake pipe on the compressor.
4. Ensure that the compressor (soundbox VP2/VP3/ VP6) has been connected to the
appliance socket of the water separator VT2.
5. Switch on the water separator VT2 via the "On / Off" switch (s. page 5, Fig. 1, item 1).
The following indication appears in the display:
Software version
Serial number of electronics system
After booting the following indication appears in the display:
Time in h
Pump cycle volume in liters
PG = 54621.0l
435.8l
00:00 h
0 l
VT2 V 2.0
SN 123456
Pump
active

MAINTENANCE AND SERVICE
Page 10 of 15
Operation
The water separator operates as follows:
At the moment when the water separator is switched on the compressor
(soundbox VP2/VP3/VP6) connected to the appliance socket of the water separator
starts running.
The separated water is collected in the water container.
When the water container is full, the appliance socket for the compressor
(soundbox VP2/VP3/VP6) is disconnected.
The pump is switched on and pumps the water out.
When the water container is empty, the pump switches off.
The compressor (soundbox VP2/VP3/VP6) switches on again.
6Maintenance and service
Maintenance work
WARNING
Danger of injury by electric shock and risk of material damage
Always observe the general safety instructions when
performing any maintenance and service work!
,
CAUTION
Damage to the device
Cleaning agents can cause damage to surfaces.
Use only mild detergents.
The cleaning intervals depend largely on the operating conditions.
Therefore check your water separator after every use.
In order to guarantee trouble-free functioning of the device it must be regularly cleaned.
Proceed as follows:
Clean casing on the outside with a moist cloth.
Drain any residual water before longer periods without operation.
Clean coarse filter
Screw out all threaded connectors and threaded caps after each use and clean the
threads. We recommend you to screw in only greased threaded connectors and
threaded caps .

MAINTENANCE AND SERVICE
Page 11 of 15
Drain residual water
Fig.
6: AERIAL water separator VT2, drain plug for residual water
1 Drain plug for residual water
In case of longer periods without operation the residual water in the device must
be discharged. To do so turn out the drain plug (s. fig. 6, item 1). Tilt and move the
housing to and fro so that the residual water can flow out.
Clean coarse filter
Fig.
7: Filter box with filter grille
Fig.
8:Filter grille removed
1, 3 Knurled nuts 1 Intake openings
2 Filter grille 2 Filter box inside
Release tension locks (s. Fig. 1, item 4) and open cover.
Release knurled nuts; remove and clean filter grille.
Remove fluff, insulation material particles and fibres from the inside of the box.
Insert filter grille, tighten knurled nuts, close cover, tighten tension locks.

TROUBLESHOOTING
Page 12 of 15
7Troubleshooting
If problems arise with the water separator VT2 please check the following points. Should
the fault not be located please contact your technical advisor.
WARNING
Danger of injury by electric shock and risk of material damage
The device may only be repaired by trained specialised staff.
Within the warranty period, any work on the device shall only
be carried out by the manufacturer or persons commissioned
by him.
Any work carried out by unauthorised persons shall lead to
the forfeiture of all warranty claims!
Faults
Problem Possible cause Remedy
Compressor
(soundbox
VP2/VP3/VP6) does
not start running or
has automatically
switched off
Power plug not
plugged into VT2
socket outlet
Plug in power plug
Socket outlet fuse has
tripped
Check the
drying construction! Maximum
current consumption at
appliance socket: 16 A!
Circuit breaker (of
connected soundbox)
tripped
Let the soundbox cool down and
check the installation.
Connected soundbox
defective
Arrange for repair by expert staff
Compressor
(soundbox
VP2/VP3/VP6) draws
in water
Compressor is not
connected to the
appliance socket of the
VT2, but to permanent
voltage
Connect compressor to VT2
appliance socket
"Pump Fault"
appears
in the display
Waste water hose
too long or too thin
Shorten waste water hose
Pump soiled Clean pump

SHUTDOWN, STORAGE AND DISPOSAL
Page 13 of 15
8Shutdown, storage and disposal
Shutdown
If you do not need the water separator VT2 for a longer period of time you can shut it
down for some time. To do so proceed as follows:
1. Switch off the water separator VT2 via the On / Off switch
(s. page 5, Fig. 1, item 6).
2. Pull the power plug.
3. Drain the residual water (s. fig. 6)
Storage
Store the sound water separator VT2 in conformity with the specified safety instructions
(see page 4).
Disposal
Please do not dispose of this device with the domestic waste.
Dispose of the device in accordance with the legal
regulations.

SPECIFICATIONS
Page 14 of 15
9Specifications
General data
Power supply 230 V/50 Hz
Protection class IP 22
Fusing RCCB to be installed by user
Operating conditions 0 °C to + 35 °C
Type Unit VT2
Pump delivery volume m3/h 9
Pump delivery height m 7
Power consumption of pump watt 380
Dimensions
H x W x D mm 507 / 390 / 490
Weight kg 18
Power cable length m 4.5
10 Accessories
Screw cap, 2 pieces
Connection pipe 38/50 mm or Ø50 pipe, 4 pieces
Gasket, 6 pieces
Pipe marked blue (intake side marking), 1 piece

EU DECLARATION OF CONFORMITY
Page 15 of 15
11 EU Declaration of Conformity
EU Declaration of Conformity
according to EC machinery directive 2006/42/EC, Annex II, 1.A
Machinery directive 2006/42/EC
EMC directive 2014/30/EU
Low voltage directive 2014/35/EU
Manufacturer: AERIAL GmbH - Systeme zur Luftbehandlung
Oststraße 148, D-22844 Norderstedt
Product description: Water separator VT2
The product described is a water separator ready for connection.
Applicable
standards:
EN ISO 12100
Safety of Machinery
EN 55 014-1:2006 + A1 :
2009 + A2 : 2011
EN 61 000-3-2:2014
EN 61 000-3-3:2013
Electromagnetic Compatibility (EMC)
This declaration of conformity shall become void if any modification not agreed
with the manufacturer is made to the device.
Norderstedt on 15.06.2015
General Manager
AERIAL GmbH
Oststraße 148
D-22844 Norderstedt

AERIAL GmbH Systeme zur Luftbehandlung
Oststrasse 148 · D-22844 Norderstedt
Phone [phone] · Telefax 526 879 20
E-Mail: [e-mail] · Internet: www.aerial.de
Dealer stamp:
