Aerial AERCUBE VP2 Series User manual

Page 1 of 18
Instruction manual
Soundbox
Series
VP2
VP3

Page 2 of 18
This instruction manual shall not be reproduced, copied and distributed, neither
in parts nor completely, without the manufacturer's written permit.
All rights reserved.
The instruction manual is based on the technical and product-specific
parameters. The manufacturer reserves the right to add supplementary
information to the instruction manual.
Using a device outside the specified conditions and contrary to its designated
use will lead to the forfeiture of all warranty claims.
As of: 06_2020

NOTES ON THIS INSTRUCTION MANUAL
Page 1 of 18
1Notes on this instruction manual _________________________________________ 2
Target groups________________________________________________________________ 2
Conventions _________________________________________________________________ 3
Designated use ______________________________________________________________ 4
2Safety _______________________________________________________________________ 4
Safety devices________________________________________________________________ 4
Hazards from accessories____________________________________________________ 5
Authorised operator _________________________________________________________ 5
User__________________________________________________________________________ 5
Safety instructions ___________________________________________________________ 5
3Construction________________________________________________________________ 6
4Transport and installation _________________________________________________ 7
Transport ____________________________________________________________________ 7
Scope of delivery ____________________________________________________________ 7
Operating conditions ________________________________________________________ 7
Installation ___________________________________________________________________ 7
5Operation and operator control___________________________________________ 9
Operating elements _________________________________________________________ 9
Commissioning and operator control ______________________________________ 10
6Maintenance and service _________________________________________________11
Maintenance work __________________________________________________________ 11
7Troubleshooting __________________________________________________________13
Fault messages _____________________________________________________________ 13
Shutdown, storage and disposal ___________________________________________ 14
Shutdown___________________________________________________________________ 14
Storage _____________________________________________________________________ 14
Disposal_____________________________________________________________________ 14
8Specifications______________________________________________________________15
9EU Declaration of Conformity ____________________________________________16
re

NOTES ON THIS INSTRUCTION MANUAL
Page 2 of 18
1Notes on this instruction manual
This instruction manual is part of the product. It contains all important
information on how to transport, install, operate, store and dispose of the device
from AERIAL properly and safely. Therefore keep this instruction manual in a safe
place.
Target groups
This instruction manual addresses the users and operators of the devices
manufactured by AERIAL. They must have read and understood the instruction
manual. The physical and psychological preconditions for proper and safety-
conscious handling of the devices must always be guaranteed.

NOTES ON THIS INSTRUCTION MANUAL
Page 3 of 18
Conventions
Warnings
In this instruction manual you will find information intended to warn you of
possible hazards at the beginning of a specific action.
DANGER
Type and source of hazard
This symbol in connection with the signal word "DANGER" refers
to a life-threatening situation. Failure to observe this warning will
result in serious, fatal injury.
This arrow marks precise steps to avert danger which must
always be performed.
WARNING
Type and source of hazard
This symbol in connection with the signal word "WARNING"
refers to a dangerous situation. Failure to observe this warning
can result in life-threatening injury and death.
This arrow marks precise steps to avert danger which must
be performed.
CAUTION
Type and source of hazard
This symbol in connection with the word "CAUTION" warns of
minor or moderate injury and potential material damage.
Measures to prevent personal injury or material damage are
described here.
In this box you find tips and information concerning the use of
the device.

SAFETY
Page 4 of 18
Designated use
The soundbox VP2 / VP3 is designed for conveying air and non-explosive gases
and gas/air mixtures as pressure or vacuum pump.
The soundbox VP2 is designed exclusively for use at atmospheric pressure.
Operating the adsorption dryers within the limits of designated use also involves
observing the specified operating conditions (refer to page 7). Any use of the
device going beyond the designated use specified above is considered contrary
to its designated use.
Misuse is concerned if the soundbox VP2 / VP3 is used for purposes not included
in designated use. In these cases the manufacturer does not assume any liability
for personal and material damage.
2Safety
Safety devices
The soundbox VP2 / VP3 was subjected to thorough safety testing. Improper
operation or misuse will cause danger to
◼the operator,
◼the machine and other material property of the user,
◼efficient operation of the machine.
All persons involved in the installation, commissioning, operation, maintenance
and servicing of the devices must
◼be properly qualified,
◼closely observe the instructions set out in this manual.

SAFETY
Page 5 of 18
Hazards from accessories
Air hoses, power cables and air filters must be properly installed, and must not
disable the protection devices of the VP2 / VP3.. The operating elements must
always be accessible.
Authorised operator
The soundbox VP2 / VP3 may only be operated by persons commissioned and
instructed by the user. In the working area the operator is responsible to third
parties. For all activities on the device the responsibilities must be clearly defined
and observed. Unclear competences are a safety risk.
User
The user must
◼make the instruction manual accessible to the operator,
◼make sure that the operator has read and understood the instruction manual.
Safety instructions
The devices must not be used under the following conditions:
◼in rooms with potentially explosive atmospheres.
◼in rooms with aggressive atmospheres, e.g. ammonia, wood acids.
◼in rooms with water with a pH value outside the range from 7.0 to 7.4.
◼In rooms with salt or liquids with a salt content > 1%.
◼in rooms with ozone-treated air
◼in rooms with high solvent concentration.
◼in rooms with extreme dust load.
In addition the following must be observed when using the soundbox VP2 / VP3:
◼Work on electrical equipment may only be carried out by skilled electricians.
◼Original spare parts or spare parts approved by the manufacturer shall
exclusively be used.

CONSTRUCTION
Page 6 of 18
3Construction
Fig. 1: AERIAL soundbox series VP2 / VP3 - overview
1
On / Off switch
5
Tube connector, pressure side
2
Appliance socket
6
Power cable
3
Tension lock
7
Control panel with full text
display
4
Tube connector, intake side
The sound box VP2 / VP3 is equipped with a side channel compressor installed with
vibration damping. The installed compressor is air-cooled and works 100 % oil-free.
The integrated noise stop system ensures a low noise level.
Use tubes of 50 mm diameter for efficient drying. Smaller tubes
result in high energy consumption and longer drying times.

TRANSPORT AND INSTALLATION
Page 7 of 18
4Transport and installation
Transport
1. Remove the packaging material completely and dispose of according to the
local regulations.
2. Check the delivery for completeness.
3. Use the lateral handles or the handle in the middle of the cover to transport
the sound box to the place of installation.
Scope of delivery
◼Soundbox VP2 / VP 3
◼One instruction manual
Operating conditions
The soundbox VP2 / VP3 is intended for use in screed and insulation layer drying and
hollow space drying. It works without problems in the temperature range from 0 °C to
+35 °C. In case of floor installation it must be ensured that sensitive floors are protected
against the thermal load from the device.
Installation
The devices can be stacked, and are
provided with fixing points for a belt
system on the right and left.
Fig. 2: Fixing points for belt system

TRANSPORT AND INSTALLATION
Page 8 of 18
Connection
DANGER
Danger to life due to electric shock
Prior to commissioning the technical data of the soundbox
VP2 / VP3 must be compared with the conditions prevailing
in the room of installation!
The following items must be checked prior to electrical connection of the
soundbox:
◼Is the mains voltage in conformity with the voltage of the device?
◼Are socket and supply system sufficiently fused?
◼Has an RCCB (required) been installed?
4. Connect the power plug of the soundbox to a suitable power outlet.

OPERATION AND OPERATOR CONTROL
Page 9 of 18
5Operation and operator control
CAUTION
Danger of injury and damage to appliance
Inadmissible ambient conditions and improper operation of the
device may constitute a risk.
Read the instruction manual before commissioning the
soundbox VP2 / VP3..
Operating elements
Fig. 3: Operating panel Soundbox VP2 / VP3
1
Appliance socket
6
Appliance socket fuse
2
On / Off switch
7
Membrane key "Reset" with red
LED
3
Display LED matrix, blue
8
Membrane key "Info"
4
Watt meter (MID)
9
LED green, yellow, red
5
Compressor fuse
In the standard version, the energy consumption of the units connected to the
unit socket (item 1) is not counted by the calibrated watt meter (MID) (item 4).
Customized solutions are possible.

OPERATION AND OPERATOR CONTROL
Page 10 of 18
Membrane key "Info"
Display also when power plug has been pulled, time 5 seconds.
Press briefly
Operating hours
Temperature in the box
press for 3 s
Software version
Software serial number
Membrane key "Reset"
Press briefly
Reset fault
red LED flashing
Press briefly
Reset after overload
Counter-pressure display
Compressor in normal mode
Compressor at power limit
Compressor overloaded
After 10 seconds of overload:
LED flashes
and
flashes
Compressor off, plug
socket off, fan remains
on
When red LED flashes
press "Reset",
fan on,
compressor on
Commissioning and operator control
1. Connect the soundbox VP2 / VP3 electrically, s. page 6.
2. Ensure that air tubes have been connected properly.
Overload
◼◼◼◼◼◼◼◼◼◼◼
V 6.0
SN 12345
123456 h
T1 = 35 C

MAINTENANCE AND SERVICE
Page 11 of 18
3. Switch on the soundbox VP2 / VP3 via the On switch (s. page 6, Fig. 1, item 1).
The following indication appears in the display:
Then the device starts and the display changes to:
6Maintenance and service
Maintenance work
WARNING
Danger of injury by electric shock and risk of material
damage
Always observe the general safety instructions when
performing any maintenance and service work!
,
CAUTION
Damage to the device
Cleaning agents can cause damage to surfaces.
Use only mild detergents.
The cleaning intervals depend largely on the operating conditions. Therefore
check your soundbox after each drying operation.
In order to guarantee trouble-free functioning of the device it must be cleaned at
regular intervals, and in particular the air filter must be checked. Proceed as
follows:
Fig. 4: Air filter change
Fig. 5: Coarse filter intake socket
123456 h
◼◼◼◼◼◼◼
VP
V6.0

MAINTENANCE AND SERVICE
Page 12 of 18
◼Remove and clean air filter (see fig. 4). Replace, if required.
◼Insert new or cleaned filter. Use only original filters to guarantee proper
functioning of the soundbox VP2 / VP3.
◼Visual inspection: Coarse filter (see fig. 5, arrow) in intake socket. If the coarse
filter is soiled turn out the intake socket and clean the filter.
◼Clean casing on the outside with a moist cloth.

TROUBLESHOOTING
Page 13 of 18
7Troubleshooting
If problems arise with the soundbox VP2 / VP3 please check the following points.
Should the fault not be located please contact your technical advisor.
WARNING
Danger of injury by electric shock and risk of material
damage
The device may only be repaired by trained specialised staff.
Within the warranty period, any work on the device shall
only be carried out by the manufacturer or persons
commissioned by him.
Any work carried out by unauthorised persons shall lead to
the forfeiture of all warranty claims!
Fault messages
Display
Meaning
Remedy
Motor overheat
protection tripped, LED
flashing red
Let the device cool down
Device overloaded,
indicator flashes
LED flashing red
LED in Reset button
flashes red
Remove the cause of the
overload. Check the tube
connections, the device
filter, connected filters.
Replace clogged filters
by new ones. Press the
Reset button.
Overload
◼◼◼◼◼◼◼◼◼◼◼
überhitzt
overheated T2

TROUBLESHOOTING
Page 14 of 18
Shutdown, storage and disposal
Shutdown
If you do not need the soundbox VP2 / VP3 for a longer period of time you can
shut it down for some time. To do so proceed as follows:
1. Switch off the soundbox via the On/Off switch
(page 6, Fig. 1, item 1).
2. Pull the power plug.
Storage
Store the soundbox VP2 / VP3 in conformity with the specified safety instructions
(see page 4).
Disposal
Please do not dispose of this device with the domestic
waste. Dispose of the device in accordance with the
legal regulations.

SHUTDOWN, STORAGE AND DISPOSAL
Page 15 of 18
8Specifications
General data
Power supply
230 V/50 Hz
Protection class
IP 22
Fusing
RCCB to be installed by user
Operating conditions
0 °C to +35 °C
Type
Unit
VP2
VP3
Air circulation rate
m³/h
140
150
Max. differential
pressure
Vacuum
Pressure
mbar
mbar
140
160
170
190
Power consumption
watt max.
800
1100
Noise level measured
at a distance of 3 m
dB (A)
<48
<48
Dimensions
H x W x D
mm
507/390/455
Weight
kg
26.5
27.5
Power cable length
m
4.5
4.5

Page 16 of 18
9EU Declaration of Conformity
EC declaration of conformity
according to the EU Machinery Directive 2006/42/EC, Annex II 1. A
Manufacturer
Person established in the
Community authorised to
compile the relevant
technical documentation
Dantherm GmbH
Manfred Föhlisch
Dantherm GmbH
Oststrasse 148
Oststrasse 148
D - 22844 Norderstedt
D - 22844 Norderstedt
Description and identification of the machinery
Pru
Product / Article
Soundbox
Type
VP-2, VP-3
Project number
Aerial VP 2, VP-3
Funktion
The soundboxes VP-2 /VP-3 is designed for conveying air and
non-explosive gases and gas/air
mixtures as pressure or vacuum pump.
The soundbox VP6 is designed exclusively for use at atmospheric
pressure. Operating the device within the limits of designated
use also involves observing the specified operating conditions.
Any use of the device going beyond the designated use specified
above is considered contrary to its
designated use.
It is expressly declared that the machinery fulfils all relevant provisions of
the following EU Directives or Regulations:
2006/42/EG
Directive 2006/42/EC of the European Parliament and of the
Council of 17 May 2006 on machinery, and
amending Directive 95/16/EC (recast) (1)
Published in L 157/24 of 09.06.2006
2014/35/EU
Directive 2014/35/EU of the European Parliament and of the
Council of 26 February 2014 on the
harmonisation of the laws of the Member States relating to the
making available on the market of electrical
equipment designed for use within certain voltage limits
Published in L 96/357 of 29.03.2014

Page 17 of 18
2014/30/EU
Directive 2014/30/EU of the European Parliament and of the
Council of 26 February 2014 on the
harmonisation of the laws of the Member States relating to
electromagnetic compatibility (recast)
Published in L 96/79 of 29.03.2014
Reference to the harmonised standards used, as referred to in
Article 7 (2):
EN ISO 12100:2010-11
Safety of machinery - General principles for design - Risk
assessment and risk reduction (ISO 12100:2010)
EN 60204-
1:2006/A1:2009
Safety of machinery - Electrical equipment of machines - Part 1:
General requirements
EN 60335-
1:2012/AC:2014
Household and similar electrical appliances - Safety - Part 1:
General requirements
IEC 60335-1:2010 (Modified)
EN 60335-
1:2012/A11:2014
Household and similar electrical appliances - Safety - Part 1:
General requirements
IEC 60335-1:2010 (Modified)
Norderstedt, 23.06.2020
Place, Date
Signature
Manfred Föhlisch

Page 18 of 18
Dealer stamp:
Dantherm GmbH · Systeme zur Luftbehandlung
Oststraße 148 · D-22844 Norderstedt
Phone [phone] · Telefax 526 879 20
E-Mail: [e-mail] · Internet:
www.aerial.de
