Aficio MP1900 User manual

Model K-C3.1
Machine Code: D096
Field Service Manual
29 January, 2010
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Safety Notices
Important Safety Notices
Prevention of Physical Injury
1. Before disassembling or assembling parts of the copier and peripherals, make sure that the power
cord is unplugged.
2. The wall outlet should be near the copier and easily accessible.
3. Note that some components of the copier and the paper tray unit are supplied with electrical voltage
even if the main power switch is turned off.
4. If a job has started before the copier completes the warm-up or initializing period, keep hands away
from the mechanical and electrical components because the starts making copies as soon as the warm-
up period is completed.
5. The inside and the metal parts of the fusing unit become extremely hot while the copier is operating.
Be careful to avoid touching those components with your bare hands.
Health Safety Conditions
Toner and developer are non-toxic, but if you get either of them in your eyes by accident, it may cause
temporary eye discomfort. Try to remove with eye drops or flush with water as first aid. If unsuccessful, get
medical attention.
Observance of Electrical Safety Standards
The copier and its peripherals must be installed and maintained by a customer service representative who
has completed the training course on those models.
Safety and Ecological Notes for Disposal
1. Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly when exposed to an
open flame.
2. Dispose of used toner, developer, and organic photoconductors in accordance with local regulations.
(These are non-toxic supplies.)
3. Dispose of replaced parts in accordance with local regulations.
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Handling Toner
• Work carefully when removing paper jams or replacing toner bottles or cartridges to avoid spilling
toner on clothing or the hands.
• If toner is inhaled, immediately gargle with large amounts of cold water and move to a well ventilated
location. If there are signs of irritation or other problems, seek medical attention.
• If toner gets on the skin, wash immediately with soap and cold running water.
• If toner gets into the eyes, flush the eyes with cold running water or eye wash. If there are signs of
irritation or other problems, seek medical attention.
• If toner is swallowed, drink a large amount of cold water to dilute the ingested toner. If there are signs
of any problem, seek medical attention.
• If toner spills on clothing, wash the affected area immediately with soap and cold water. Never use
hot water! Hot water can cause toner to set and permanently stain fabric.
• Always store toner and developer supplies such as toner and developer packages, cartridges, and
bottles (including used toner and empty bottles and cartridges) out of the reach of children.
• Always store fresh toner supplies or empty bottles or cartridges in a cool, dry location that is not
exposed to direct sunlight.
Laser Safety
The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units
in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite
equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser
chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis and
laser subsystems to the factory or service depot when replacement of the optical subsystem is required.
•Use of controls, or adjustment, or performance of procedures other than those specified in this manual
may result in hazardous radiation exposure.
WARNING FOR LASER UNIT
2
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

WARNING: Turn off the main switch before attempting any of the procedures in the Laser Unit section.
Laser beams can seriously damage your eyes.
CAUTION MARKING:
3
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Symbols and Abbreviations
This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are
as follows:
See or Refer to
Clip ring
Screw
Connector
Clamp
SEF Short Edge Feed
LEF Long Edge Feed
4
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

TABLE OF CONTENTS
Safety Notices.....................................................................................................................................................1
Important Safety Notices...............................................................................................................................1
Laser Safety.....................................................................................................................................................2
Symbols and Abbreviations...............................................................................................................................4
1. Product Information
Specifications....................................................................................................................................................11
Machine Configuration....................................................................................................................................12
Guidance for Those Who are Familiar with Predecessor Products..............................................................13
Overview..........................................................................................................................................................14
Component Layout.......................................................................................................................................14
Paper Path....................................................................................................................................................15
Drive Layout..................................................................................................................................................16
2. Installation
Installation Requirements.................................................................................................................................17
Environment..................................................................................................................................................17
Machine Level..............................................................................................................................................18
Minimum Space Requirements...................................................................................................................18
Power Requirements....................................................................................................................................19
Copier Installation............................................................................................................................................20
Power Sockets for Peripherals....................................................................................................................20
Accessory Check..........................................................................................................................................20
Installation Procedure..................................................................................................................................21
Platen Cover Installation..................................................................................................................................25
Accessory Check..........................................................................................................................................25
Installation Procedure..................................................................................................................................25
ADF Installation................................................................................................................................................26
Accessory Check..........................................................................................................................................26
Installation Procedure..................................................................................................................................27
Anti-condensation Heater Installation............................................................................................................30
Tray Heater.......................................................................................................................................................31
Tray Heater...................................................................................................................................................31
Accessibility Handle Installation.....................................................................................................................33
5
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

3. Preventive Maintenance
PM Tables.........................................................................................................................................................35
How to Reset the PM Counter.........................................................................................................................36
4. Replacement and Adjustment
General Cautions.............................................................................................................................................39
PCU (Photoconductor Unit).........................................................................................................................39
Transfer Roller..............................................................................................................................................39
Scanner Unit.................................................................................................................................................39
Laser Unit......................................................................................................................................................40
Fusing Unit....................................................................................................................................................40
Paper Feed...................................................................................................................................................40
Special Tools and Lubricants...........................................................................................................................41
Exterior Covers & Operation Panel................................................................................................................42
Rear Cover...................................................................................................................................................42
Copy Tray.....................................................................................................................................................42
Upper Covers...............................................................................................................................................43
Left Cover......................................................................................................................................................44
Front Cover...................................................................................................................................................44
Front Right Cover.........................................................................................................................................45
Right Rear Cover..........................................................................................................................................45
Right Door.....................................................................................................................................................46
By-pass Tray.................................................................................................................................................46
Platen Cover Sensor....................................................................................................................................47
Scanner Unit.....................................................................................................................................................48
Exposure Glass/DF Exposure Glass .........................................................................................................48
Lens Block.....................................................................................................................................................49
Lamp Stabilizer Board And Exposure Lamp..............................................................................................50
Scanner Motor.............................................................................................................................................51
Scanner Home Position Sensor...................................................................................................................52
Adjusting Scanner Positions........................................................................................................................52
Laser Unit..........................................................................................................................................................57
Location of Caution Decal...........................................................................................................................57
Toner Shield Glass.......................................................................................................................................58
6
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Laser Unit......................................................................................................................................................58
LD Unit...........................................................................................................................................................59
Polygonal Mirror Motor..............................................................................................................................60
Laser Unit Alignment Adjustment................................................................................................................60
PCU Section......................................................................................................................................................63
PCU...............................................................................................................................................................63
Toner Supply Motor.....................................................................................................................................64
Pick-off Pawls and Toner Density Sensor...................................................................................................64
OPC Drum....................................................................................................................................................66
Charge Roller and Cleaning Brush.............................................................................................................67
Cleaning Blade............................................................................................................................................67
Developer.....................................................................................................................................................68
After Replacement or Adjustment...............................................................................................................69
Paper Feed Section..........................................................................................................................................71
Paper Feed Roller .......................................................................................................................................71
Friction Pad...................................................................................................................................................72
Paper End Sensor.........................................................................................................................................72
Exit Sensor....................................................................................................................................................73
By-Pass Feed Roller and Paper End Sensor...............................................................................................74
Registration Roller........................................................................................................................................75
By-Pass Paper Size Switch..........................................................................................................................76
Registration Clutch ......................................................................................................................................77
Registration Sensor......................................................................................................................................77
Paper Feed Clutch and By-Pass Feed Clutch.............................................................................................78
Paper Size Switch........................................................................................................................................79
Image Transfer..................................................................................................................................................80
Image Transfer Roller...................................................................................................................................80
Image Density Sensor..................................................................................................................................81
Fusing................................................................................................................................................................82
Fusing Unit....................................................................................................................................................82
Thermistor.....................................................................................................................................................82
Fusing Lamps................................................................................................................................................83
Hot Roller Stripper Pawls.............................................................................................................................84
7
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Hot Roller......................................................................................................................................................84
Thermostat....................................................................................................................................................85
Pressure Roller and Bushings......................................................................................................................85
NIP Band Width Adjustment.......................................................................................................................86
Cleaning Roller............................................................................................................................................87
Other Replacements.........................................................................................................................................88
Quenching Lamp..........................................................................................................................................88
High-Voltage Power Supply Board............................................................................................................88
BICU (Base-Engine Image Control Unit)....................................................................................................89
Main Motor..................................................................................................................................................90
Left Exhaust Fan............................................................................................................................................90
PSU (Power Supply Unit).............................................................................................................................91
Gearbox.......................................................................................................................................................92
Copy Adjustments Printing/Scanning............................................................................................................95
Printing..........................................................................................................................................................95
Scanning.......................................................................................................................................................97
ADF Image Adjustment................................................................................................................................99
5. Service Tables
Service Program Mode.................................................................................................................................101
SP Tables....................................................................................................................................................101
How to Enter the SP Mode.......................................................................................................................101
Using SP Modes.............................................................................................................................................103
Adjusting Registration and Magnification...............................................................................................103
ID Sensor Error Analysis (SP 2221).........................................................................................................104
Memory Clear...........................................................................................................................................104
Input Check (SP 5803).............................................................................................................................106
Output Check (SP 5804)..........................................................................................................................109
Serial Number Input (SP 5811)...............................................................................................................111
NVRAM Data Upload/Download (SP 5824/5825)...........................................................................112
Firmware Update Procedure ...................................................................................................................114
Test Pattern Print (SP 5902 1)..................................................................................................................115
Paper Jam Counters (SP 7504)...............................................................................................................118
SMC Print (SP 5990)................................................................................................................................118
8
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Original Jam History Display (SP 7508).................................................................................................119
Jam History Codes.....................................................................................................................................119
ADF APS Sensor Output Display (SP 6901)...........................................................................................119
6. Troubleshooting
Service Call Conditions.................................................................................................................................121
Electrical Component Defects.......................................................................................................................122
Sensors.......................................................................................................................................................122
Switches.....................................................................................................................................................123
Blown Fuse Conditions..................................................................................................................................124
LED Display....................................................................................................................................................125
BICU...........................................................................................................................................................125
7. Energy Saving
Energy Save...................................................................................................................................................127
Energy Saver Modes................................................................................................................................127
Energy Save Effectiveness........................................................................................................................128
9
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

10
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

1. Product Information
Specifications
See "Appendices" for the following information:
•General Specifications
• Supported Paper Size
• Optional Equipment
11
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Machine Configuration
Unit/Component Machine Code Diagram
Copier
Copier (1-tray non-duplex model) D096 [D]
Platen cover (optional) B406 [B]
ADF (optional) B813 [A]
Accessibility Handle Type A (optional) B272 -
1. Product Information
12
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Guidance for Those Who are Familiar with
Predecessor Products
The D096 model is successor models to the B245 model. If you have experience with the predecessor
products, the following information will be of help when you read this manual.
Different Points from Predecessor Products
D096 B245
Duplex Not available Not available
Paper Tray One tray One tray
Printer/ Scanner Not available Not available
Fax Not available Not available
GDI Controller Not available Not available
GW Controller Not available Not available
APS (Mainframe) Not available Available
Copy Speed 19 cpm 15cpm
Guidance for Those Who are Familiar with Predecessor Products
13
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Overview
Component Layout
1. Product Information
14
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

1. 2nd Mirror
2. Exposure Lamp
3. 1st Mirror
4. Exposure Glass
5. Lens Block
6. SBU
7. Exit Sensor
8. Scanner Motor
9. Hot Roller
10. Pressure Roller
11. OPC Drum
12. Image Density Sensor
13. Registration Roller
14. Registration Sensor
15. By-pass Tray
16. By-pass Feed Roller
17. Friction Pad
18. Paper Feed Roller
19. Paper End Sensor
20. Bottom Plate
21. PCU
22. Development Roller
23. WTL
24. Polygon Mirror Motor
25. Laser Unit
26. Toner Supply Bottle Holder
27. Exit Roller
28. 3rd Mirror
29. Scanner HP Sensor
Paper Path
Overview
15
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

1. Original Feed from ADF
2. Paper Feed from Tray 1
3. Paper Feed from By-pass Tray
Drive Layout
1. Scanner Motor
2. Main Motor
3. Hot Roller
4. OPC Drum
5. Development Roller
6. By-pass Feed Clutch
7. Paper Feed Clutch
8. Registration Clutch
1. Product Information
16
1
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

2. Installation
Installation Requirements
• Before installing options, please do the following:
• If there is a printer option in the machine, print out all data in the printer buffer.
• Turn off the main switch and disconnect the power cord, the telephone line, and the network cable.
Environment
–Temperature and Humidity Chart–
• Temperature Range: 10°C to 32°C (50°F to 89.6°F)
• Humidity Range: 15% to 80% RH
• Ambient Illumination: Less than 1,500 lux (do not expose to direct sunlight)
• Ventilation: 3 times/hr/person or more
• Ambient Dust: Less than 0.075 mg/m3 (2.0 x 10-6 oz/yd3)
17
2
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

• Avoid areas exposed to sudden temperature changes:
1) Areas directly exposed to cool air from an air conditioner.
2) Areas directly exposed to heat from a heater.
• Do not place the machine in areas where it can get exposed to corrosive gases.
• Do not install the machine at any location over 2,000 m (6,500 ft.) above sea level.
• Place the machine on a strong and level base. (Inclination on any side should be no more than 5
mm.)
• Do not place the machine where it is subjected to strong vibrations.
Machine Level
Front to back: Within 5 mm (0.2") of level
Right to left: Within 5 mm (0.2") of level
Minimum Space Requirements
Place the copier near the power source, providing clearance as shown:
A (front): 750 mm (30")
B (left): 150 mm (6")
C (rear): 50 mm (2")
D (right): 250 mm (10")
2. Installation
18
2
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
