Agilent 8720E Family
Network Analyzers
Configuration Guide
8719ET, 50 MHz to 13.5 GHz
8720ET, 50 MHz to 20 GHz
8722ET, 50 MHz to 40 GHz
8719ES, 50 MHz to 13.5 GHz
8720ES, 50 MHz to 20 GHz
8722ES, 50 MHz to 40 GHz
The Agilent Technologies 8720E family of microwave
network analyzers integrates a microwave source,
tuned-receiver, and transmission/reflection or
S-parameter test set into a single, cost-effective
instrument. To complete a microwave measurement
system, select the desired network analyzer options,
test port cables, and calibration kits. Also, addi-
tional measurement accessories may be selected.
Discontinued Product Information
— For Support Reference Only —
Information herein, may refer to products/services no longer supported.
We regret any inconvenience caused by obsolete information. For the
latest information on Agilent’s test and measurement products go to:
www.agilent.com/find/products
In the US, call Agilent Technologies at 1-800-829-4444
(any weekday between 8am–5pm in any U.S. time zone)
World-wide Agilent sales office contact information is available at:
www.agilent.com/find/contactus

2
8719ET vector network analyzer,
50 MHz to 13.5 GHz
8720ET vector network analyzer,
50 MHz to 20 GHz
8722ET vector network analyzer,
50 MHz to 40 GHz
Included with a standard network analyzer is
a manual set which includes an installation and
quick start guide, user’s guide, reference guide,
programmer’s guide, example programs CD-ROM,
and a CD-ROM containing the manual set. A
bandpass filter test device (P/N 0955-0446) and
a 3-year return-to-Agilent service warranty are
also included.
Transmission/reflection analyzer options
Any combination of the following options may
be ordered with an ET model analyzer.
004 step attenuator: adds a 55-dB step attenuator
to increase the source output power range.
010 time-domain capability: allows time-domain
measurements.
1D5 high-stability frequency reference: replaces
standard frequency reference with a higher
stability unit.
8719ES vector network analyzer,
50 MHz to 13.5 GHz
8720ES vector network analyzer,
50 MHz to 20 GHz
8722ES vector network analyzer,
50 MHz to 40 GHz
Included with a standard network analyzer is
a manual set which includes an installation and
quick start guide, user’s guide, reference guide,
programmer’s guide, example programs CD-ROM,
and a CD-ROM containing the manual set. A
bandpass filter test device (P/N 0955-0446) and
a 3-year return-to-Agilent service warranty are
also included.
Transmission/Reflection S-parameter Network Analyzers
Network Analyzers

3
S-parameter analyzer options
Some ES options cannot be ordered with other
options. See option compatibility table below.
007 mechanical transfer switch: replaces the solid-
state transfer switch with a mechanical trans-
fer switch. Increases test port power and
dynamic range by 5 dB.
010 time-domain capability: allows time-domain
measurements.
012 direct sampler access: configures the test set
with direct access to A and B sampler receiver
inputs. Operates as a standard instrument
with the jumpers installed.
085 high-power S-parameter test set modification:
deletes bias tees and adds a mechanical trans-
fer switch and internal attenuators. Allows
insertion of an amplifier before the transfer
switch and insertion of isolators in the meas-
urement configuration. Includes direct sam-
pler access (Option 012).
089 frequency offset mode: modifies the test set
and firmware. Provides mixer measurement
capability, allowing a receiver frequency offset
from the source.
1D5 high-stability frequency reference: replaces
standard frequency reference with a higher
stability unit.
400 adds fourth sampler and TRL calibration
firmware: replaces the transfer switch with
a solid-state switch/splitter.
The following options apply to both ET and ES
models:
Hardware options
1CM adds rack mount flange kit for use without
handles
1CP adds rack mount flange kit for use with
handles1
Information options
0B0 deletes manual set
0B1 adds extra manual set
0BWadds service guide, part number 08720-90397
The following language options provide a translated
user’s guide:
ABF French manual, part number 5967-8509
ABJ Japanese manual, part number 5967-8503
Service options
W01 converts three year return-to-Agilent service
warranty to one year on-site service warranty.2
W32 adds three years of return-to-Agilent calibration.
W34 adds three years of return-to-Agilent standards-
compliant calibration.
W52 adds five years of return-to-Agilent calibration.
W54 adds five years of return-to-Agilent standards-
compliant calibration.
Certification options
UK6 commercial calibration certification with
test data
1BN mil standard 45662A calibration certification
1BP mil standard 45662A calibration certification
with test data
Network Analyzer Options
S-Parameter Network Analyzer Option Compatibility
Option Option 1D5 Option 007 Option 010 Option 012 Option 085 Option 089 Option 400
1D5 High-stability frequency reference — Yes Yes Yes Yes Yes Yes
007 Mechanical transfer switch Yes — Yes Yes No4Yes No3
010 Time domain Yes Yes — Yes Yes Yes Yes
012 Direct sampler access Yes Yes Yes — No5Yes Yes
085 High-power test Yes No4Yes No5—YesNo
3, 4
089 Frequency offset mode Yes Yes Yes Yes Yes — Yes
400 Four-sampler test set Yes No3Yes Yes No3, 4 Yes ––
1. The 8720E family of network analyzers is supplied with handles.
2. Only where on-site service is available.
3. Option 400 uses solid-state switch splitter in place of transfer switch.
4. Option 085 requires and includes a mechanical transfer switch.
5. Option 085 includes direct sampler access (Option 012).

4
Accessories are available in these connector types:
7 mm, K-connector (2.92 mm), Type-N, 3.5 mm
(SMA-compatible), 2.4 mm coaxial, 7-16, WR-90
(X Band), WR-62 (P Band), WR-42 (K Band),
WR-28 (R Band)
For a complete list of Agilent’s coaxial and wave-
guide accessories, ask your Agilent sales represen-
tative for the RF & Microwave Test Accessories
Catalog (literature number 5968-4314E).
Calibration kits
Coaxial measurements
For coaxial measurements, Agilent offers two types
of calibration kits:
Economy, includes:
• open standards (male and female)
• short standards (male and female)
• fixed-termination standards (male and female)
• in-series adapters
Standard, includes the devices in the economy kit
and adds:
• sliding loads
• connector gages
Precision, includes the devices in the economy kit
and adds:
• 50 ohm airline for TRL calibration
• TRL adapters
• connector tools
Waveguide measurements
For waveguide measurements, Agilent offers
calibration kits that include:
• waveguide-to-coax adapters (X, P, K)
• precision waveguide section
• flush short circuit
• fixed terminations
• straight section
Electronic calibration
Agilent also offers electronic calibration systems.
These systems require an Agilent 85097A
interface kit and electronic calibration kit.
The calibration kit includes:
• highband ECal module
• torque wrench
• optional adapters
• optional lowband ECal module
Verification kits
All Agilent verification kits include:
• precision Z0airline
• mismatched airline
• fixed attenuators
• traceable measured data and uncertainties
Cables and adapter sets
Agilent offers cables in the following types:
• single cables in semi-rigid and flexible
• cable set in semi-rigid and flexible
There are also adapter sets available that protect
the test port and convert the port to the desired
connector interface. These kits contain:
• one male adapter
• one female adapter
To attain the best mechanical rigidity for device
connection, use a single cable and the appropriate
special adapter set. To attain the greatest flexibility
for device connection, use a cable set.
Measurement Accessories
Network analyzer
test set
Network analyzer
test set
Test port
adapter
Device
under
test
Single cable
Device
under
test
Cable set

5
For devices with 3.5 mm or SMA connectors
Calibration kits
85052B standard: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
00911-60019 3.5 mm (m) sliding load
00911-60020 3.5 mm (f) sliding load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Option K11 PSC-3.5 slotless female center contact
repair kit
85052C1precision TRL: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
85052-60035 3.5 mm short TRL line
85052-60036 3.5 mm long TRL line
85052D economy: 0.045 to 26.5 GHz. Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85033D economy: DC to 6 GHz. Includes:
1250-1746 3.5 mm (f) to 7 mm adapter
1250-1747 3.5 mm (m) to 7 mm adapter
85033-60009 3.5 mm (m) load
85033-60010 3.5 mm (f) load
85033-60011 3.5 mm (m) open
85033-60012 3.5 mm (f) open
85033-60013 3.5 mm (m) short
85033-60014 3.5 mm (f) short
Option 001 deletes 3.5 mm to 7 mm adapters
Electronic calibration kits
85093B RF ECal:230 kHz to 9 GHz. Includes:
85093-60005 3.5 mm (f) to 3.5 mm (m) RF ECal module
Option 00M substitutes:
85093-60006 3.5 mm (m) to 3.5 mm (m) RF ECal
module
Option 00F substitutes:
85093-60007 3.5 mm (f) to 3.5 mm (f) RF ECal
module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85062B MW ECal:21 GHz to 26.5 GHz. Includes:
85062-60002 3.5 mm (f) to 3.5 mm (m) MW ECal
module
Option 00M substitutes:
85062-60004 3.5 mm (m) to 3.5 mm (m) MW ECal
module
Option 00F substitutes:
85062-60006 3.5 mm (f) to 3.5 mm (f) MW ECal
module
Option 001 adds:
a 30 kHz to 9 GHz RF ECal module
85093-60005 3.5 mm (f) to 3.5 mm (m) RF ECal
module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Verification kits
85053B 0.045 to 26.5 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for either 8719ET/ES or 8720ET/ES
85131C single, semi-rigid: 3.5 mm to 3.5 mm, 81 cm,
32 inches
85131D set, semi-rigid: 3.5 mm to 3.5 mm, 53 cm each,
21 inches
85131E single, flexible: 3.5 mm to 3.5 mm, 96 cm,
38 inches
85131F set, flexible: 3.5 mm to 3.5 mm, 53 cm each,
21 inches
Cables for the 8722ET/ES
85134C single, semi-rigid: 3.5 mm to 2.4 mm, 81 cm,
32 inches
85134D set, semi-rigid: 3.5 mm to 2.4 mm, 53 cm each,
21 inches
85134E single, flexible: 3.5 mm to 2.4 mm, 96 cm,
38 inches
85134F set, flexible: 3.5 mm to 2.4 mm, 53 cm each,
21 inches
Adapter sets
85130D 8719/8720 only: 3.5 mm3to 3.5 mm
85130F 8722 only: 2.4 mm3to 3.5 mm
1. Kit includes open and short circuits, fixed broadband loads, precision short
airlines, TRL adapters, and 3.5 mm connector tools.
2. Requires an Agilent 85097A interface kit.
3. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.

6
For devices with 7 mm connectors
Calibration kits
85050B standard: 0.045 to 18 GHz. Includes:
00909-60008 7 mm coax termination
85050-60006 7 mm fixed broadband load
85050-80007 7 mm short
85050-80010 7 mm open
85050-80011 7 mm sliding load
85050C1precision TRL: 0.045 to 18 GHz. Includes:
00909-60008 7 mm coax termination
85050-60003 7 mm to 7 mm airline
85050-60005 7 mm to 7 mm TRL adapter
85050-60006 7 mm fixed broadband load
85050-80007 pin collet assembly
85050-80008 7 mm short
85050-80009 7 mm short collet
85050-80010 7 mm open
85050D economy: 0.045 to 18 GHz. Includes:
85050-60006 7 mm fixed broadband load
85050-80007 7 mm short
85050-80010 7 mm open
85031B economy: 30 kHz to 6 GHz. Includes:
00909-60008 7 mm coax termination
85050-60001 7 mm open/short
Electronic calibration kits
85091B RF ECal:230 kHz to 9 GHz. Includes:
85091-60003 7 mm to 7 mm RF ECal module
85060B MW ECal:21 GHz to 18 GHz. Includes:
85060-60002 7 mm to 7 mm MW ECal module
Option 001: adds a 30 kHz to 9 GHz RF ECal module
85091-60003 7 mm to 7 mm RF ECal module
Verification kit
85051B 8719/8720 only: 0.045 to 18 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for either 8719ET/ES or 8720ET/ES
85132C single, semi-rigid: 7 mm to 3.5 mm, 81 cm,
32 inches
85132D set, semi-rigid: 7 mm to 3.5 mm, 53 cm each,
21 inches
85132E single, flexible: 7 mm to 3.5 mm, 96 cm, 38 inches
85132F set, flexible: 7 mm to 3.5 mm, 53 cm each,
21 inches
Cables for the 8722ET/ES
85135C single, semi-rigid: 7 mm to 2.4 mm, 81 cm,
32 inches
85135D set, semi-rigid: 7 mm to 2.4 mm, 53 cm each,
21 inches
85135E single, flexible: 7 mm to 2.4 mm, 96 cm, 38 inches
85135F set, flexible: 7 mm to 2.4 mm, 53 cm each,
21 inches
Adapter sets
85130B 8719/20 only: 3.5 mm3to 7 mm
85130E 8722 only: 2.4 mm3to 7 mm
For devices with Type-N connectors
Calibration kits
85054B standard: 0.045 to 18 GHz. Includes:
00909-60011 Type-N (m) fixed lowband load
00909-60012 Type-N (f) fixed lowband load
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7 mm adapter
85054-60032 Type-N (m) to 7 mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-80010 Type-N (f) sliding load
85054-80009 Type-N (m) sliding load
85054-60050 Type-N (f) connector gage
85054-60052 Type-N (f) gage master
85054-60051 Type-N (m) connector gage
85054-60053 Type-N (m) gage master
Option K11 PSC-N slotless contact repair kit
85054D economy: 0.045 to 18 GHz. Includes:
85054-60025 Type-N (m) short
85054-60026 Type-N (f) short
85054-60027 Type-N (m) open
85054-60028 Type-N (f) open
85054-60031 Type-N (f) to 7 mm adapter
85054-60032 Type-N (m) to 7 mm adapter
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85054-60046 Type-N (m) fixed load
85054-60047 Type-N (f) fixed load
Electronic calibration kits
85092B RF ECal:230 kHz to 9 GHz. Includes:
85092-60005 Type-N (f) to Type-N (m) RF ECal module
Option 00M substitutes:
85092-60006 Type-N (m) to Type-N (m) RF ECal
module
Option 00F substitutes:
85092-60007 Type-N (f) to Type-N (f) RF ECal module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
85064B MW ECal:21 GHz to 18 GHz. Includes:
85064-60002 Type-N (f) to Type-N (m) MW ECal module
Option 00M substitutes:
85064-60004 Type-N (m) to Type-N (m) MW ECal
module
Option 00F substitutes:
85064-60006 Type-N (f) to Type-N (f) MW ECal
module
Option 001: adds a 30 kHz to 9 GHz RF ECal module
85092-60005 Type-N (f) to Type-N (m) RF ECal
module
Option 00A adds:
85054-60037 Type-N (f) to Type-N (f) adapter
85054-60038 Type-N (m) to Type-N (m) adapter
Measurement Accessories, continued
1. Kit includes open and short circuits, fixed loads, precision short airline,
7 mm connector tools, and gauges.
2. Requires an Agilent 85097A interface kit.
3. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.

7
Verification kit
85055A 8719/8720 only: 0.045 to 18 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables
Use the test port cables recommended for devices
with 7 mm connectors, and 7 mm to Type-N adapters
that are from the 85054B/D Type-N calibration kit
(see 7 mm connector section).
Adapter set
85130C 8719/8720 only: 3.5 mm1to Type-N
For devices with 2.4 mm connectors
Calibration kits
85056A standard: 0.045 to 50 GHz. Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
00915-60003 2.4 mm (m) sliding load
00915-60004 2.4 mm (f) sliding load
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
85056D economy: 0.045 to 50 GHz. Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
Verification kit
85057B 8722 only: 0.045 to 50 GHz
Option 1BP MIL-STD 45662A calibration certificate
with test data
Cables for the 8722ET/ES
85133C single, semi-rigid: 2.4 mm, 81 cm, 32 inches
85133D set, semi-rigid: 2.4 mm, 53 cm each, 21 inches
85133E single, flexible: 2.4 mm, 81 cm, 32 inches
85133F set, flexible: 2.4 mm, 53 cm each, 21 inches
Adapter set
85130G 8722 only: 2.4 mm1to 2.4 mm
For devices with K connectors (2.92 mm)
Calibration kit
85056K2economy, 2.92/2.4 mm: 0.045 to 40 GHz.
Includes:
00901-60003 2.4 mm (m) fixed broadband load
00901-60004 2.4 mm (f) fixed broadband load
00915-60003 2.4 mm (m) sliding load
00915-60004 2.4 mm (f) sliding load
11904-60001 2.4 mm (m) to 2.92 mm (m) adapter
11904-60002 2.4 mm (f) to 2.92 mm (f) adapter
11904-60003 2.4 mm (m) to 2.92 mm (f) adapter
11904-60004 2.4 mm (f) to 2.92 mm (m) adapter
85056-60005 2.4 mm (m) to 2.4 mm (m) adapter
85056-60006 2.4 mm (f) to 2.4 mm (f) adapter
85056-60007 2.4 mm (m) to 2.4 mm (f) adapter
85056-60020 2.4 mm (m) short
85056-60021 2.4 mm (f) short
85056-60022 2.4 mm (m) open
85056-60023 2.4 mm (f) open
Option 001 adds 2.4 mm sliding loads and gages
Cables3
85133C single, semi-rigid: 2.4 mm, 81 cm, 32 inches
85133D set, semi-rigid: 2.4 mm, 53 cm each, 21 inches
85133E single, flexible: 2.4 mm, 81 cm, 32 inches
85133F set, flexible: 2.4 mm, 53 cm each, 21 inches
Adapters
11904A 2.4 mm (m) to K (m)
11904B 2.4 mm (f) to K (f)
11904C 2.4 mm (m) to K (f)
11904D 2.4 mm (f) to K (m)
11904S 2.4 mm to K adapter set
For devices with 7-16 connectors
Calibration kits
85038A standard: 30 kHz to 7.5 GHz. Includes:
85038-80002 7-16 (f) open
85038-80003 7-16 (m) open
85038-80004 7-16 (f) short
85038-80005 7-16 (m) short
85038-80006 7-16 (f) fixed load
85038-80007 7-16 (m) fixed load
8710-2175 torque wrench
8710-2174 open-end wrench
85038F economy: 30 kHz to 7.5 GHz. Includes:
85038-80002 7-16 (f) open
85038-80004 7-16 (f) short
85038-80006 7-16 (f) fixed load
11906-80016 7-16 (f) to 7-16 (f) adapter
1. Special rugged female connector specifically for connecting to the network
analyzer test port, but does not mate with a standard male connector.
2. This kit can be used to calibrate in the 2.4 mm interface, as well as measure
in the 2.92 mm (K connector).
3. 2.4 mm to K type adapters are required in addition to these cables.

8
85038M economy: 30 kHz to 7.5 GHz. Includes:
85038-80003 7-16 (m) open
85038-80005 7-16 (m) short
85038-80007 7-16 (m) fixed load
11906-80015 7-16 (m) to 7-16 (m) adapter
Electronic calibration kit
85098B RF ECal:130 kHz to 7.5 GHz. Includes:
85098-60005 7-16 (m) to 7-16 (f) RF ECal module
Option 00F substitutes:
85098-60007 7-16 (f) to 7-16 (f) RF ECal module
Option 00M substitutes:
85098-60006 7-16 (m) to 7-16 (m) RF ECal module
Option 00A adds:
11906-80015 7-16 (m) to 7-16 (m) adapter
11906-80016 7-16 (f) to 7-16 (f) adapter
Cables
Use the test port cables recommended for devices
with 7 mm, 3.5 mm, or Type-N connectors and use
the appropriate 11906 series adapter kit.
Adapter kits
11906A 7-16 to 7-16. Includes:
11906-80015 7-16 (m) to 7-16 (m) adapter
11906-80016 7-16 (f) to 7-16 (f) adapter
11906-80017 7-16 (m) to 7-16 (f) adapter (two included)
11906B 7-16 to Type-N. Includes:
11906-80007 Type-N (m) to 7-16 (m) adapter
11906-80008 Type-N (f) to 7-16 (f) adapter
11906-80009 Type-N (f) to 7-16 (m) adapter
11906-80010 Type-N (m) to 7-16 (f) adapter
11906C 7-16 to 7-mm. Includes:
11906-80012 7-mm to 7-16 (m) adapter (two included)
11906-80013 7-mm to 7-16 (f) adapter (two included)
11906D 7-16 to 3.5-mm. Includes:
11906-80002 3.5-mm (m) to 7-16 (m) adapter
11906-80005 3.5-mm (m) to 7-16 (f) adapter
11906-80004 3.5-mm (f) to 7-16 (m) adapter
11906-80003 3.5-mm (f) to 7-16 (f) adapter
For devices with waveguide
X Band
X11644A calibration kit (standard, WR-90, 8.2 to
12.4 GHz). Includes:
00896-60008 X-band standard section
00910-60003 X-band termination
11644-20018 X-band short
11644-20021 X-band shim (open)
X281C waveguide to 7 mm coax adapter
8719/8720: 85132F cable set (set, flexible, 7 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85135F cable set (set, flexible,
7 mm to 2.4 mm, 53 cm each, 21 inches)
X281C adapter (included in calibration kit):
WR-90 to 7 mm
P Band
P11644A calibration kit (standard, WR-62, 12.4 to
18 GHz). Includes:
00896-60007 P-band standard section
00910-60002 P-band termination
11644-20017 P-band short
11644-20020 P-band shim (open)
P281C waveguide to 7 mm coax adapter
8719/8720: 85132F cable set (flexible, 7 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85135F cable set (flexible, 7 mm to 2.4 mm,
53 cm each, 21 inches)
P281C adapter (included in calibration kit):
WR-62 to 7 mm
K Band
K11644A calibration kit (standard, WR-42, 18 to
26.5 GHz). Includes:
00896-60006 K-band standard section
00910-60001 K-band termination
11644-20016 K-band short
11644-20019 K-band shim (open)
K281C waveguide to 3.5 mm (f) coax adapter
8719/8720: 85131F cable set (set, flexible, 3.5 mm to
3.5 mm, 53 cm each, 21 inches)
8722: 85134F cable set (set, flexible, 3.5 mm to 2.4 mm,
53 cm each, 21 inches)
K281C adapter (included in calibration kit):
WR-42 to 3.5 mm (f)
Option 012 WR-42 to 3.5 mm (m)
R Band
R11644A calibration kit (standard, WR-28, 26.5 to
40 GHz). Includes:
00914-60028 R-band termination
11644-20005 R-band short
11644-20003 R-band shim (open)
11644-60001 R-band 10 cm straight waveguide
11644-60016 R-band 5 cm straight waveguide
8722: 85133F cable set (set, flexible, 2.4 mm, 53 cm
each, 21 inches)
R281A adapter (2.4 mm (f) to WR-28 waveguide
adapter)
R281B adapter (2.4 mm (m) to WR-28 waveguide
adapter)
Measurement Accessories, continued
1. Requires an Agilent 85097A ECal interface kit.

9
Power meters1
E4418B EPM series, single channel
E4419B EPM series, dual channel
Power sensors
8481B 10 MHz to 18 GHz, Type-N (m), 25 watt
8482B 100 kHz to 4.2 GHz, Type-N (m), 25 watt
8485A 50 MHz to 26.5 GHz, APC-3.5 mm (m), 100 mW
8481A 10 MHz to 18 GHz, Type-N (m), 100 mW
8482A 100 kHz to 4.2 GHz, Type-N (m), 100 mW
8483A 100 kHz to 2 GHz, Type-N (m), 75 ohm, 100 mW
R8486A 26 GHz to 40 GHz, waveguide flange UG-599/U,
100 mW
8487A 50 MHz to 50 GHz, 2.4 mm (m), 100 mW
Power amplifiers2
83006A 0.01 to 26.5 GHz, 20 dB gain, power out:
+18 dBm to 10 GHz or +16 dBm to 20 GHz or
+14 dBm to 26.5 GHz
83017A 0.05 to 26.5 GHz, 25 dB gain, power out:
+20 dBm to 20 GHz or +15 dBm to 26.5 GHz
83018A 2 to 26.5 GHz, 27 dB gain to 20 GHz or 23 dB
to 26.5 GHz, power out: +24 dBm to 20 GHz or
+21 dBm to 26.5 GHz
83020A 2 to 26.5 GHz, 30 dB gain to 20 GHz or 27 dB
to 26.5 GHz, power out: +30 dBm to 20 GHz or
+26 dBm to 26.5 GHz
83050A 2 to 50 GHz, 23 dB gain, power out:
+20 dBm to 40 GHz or +17 dBm to 50 GHz
83051A pre-amplifier, 0.045 to 50 GHz, 23 dB gain,
power out: +12 dBm to 45 GHz or +10 dBm to 50 GHz
Couplers
87300B coaxial: 1 to 20 GHz, SMA (f), 10 dB coupling
87300C coaxial: 1 to 26.5 GHz, 3.5 mm (f), 10 dB
coupling
87301D coaxial: 1 to 40 GHz, 2.4 mm (f) or optional
2.92 mm (f), 13 dB coupling
87310B 90° coaxial: 1 to 18 GHz, SMA (f), 3 dB
coupling
87301E coaxial: 2 to 50 GHz, 2.4 mm (f), 10 dB
coupling
Test fixtures
For TRL/LRM and TOSL calibration standards,
microstrip adapters, and test fixtures, Agilent recom-
mends ICM3adjustable test fixture mainframe series
TF-3000, which is compatible with the ICM TRL-3000
series calibration kits.
Bias supplies4
6626A precision DC power supply; 2 A, 50 V maximum
6629A quad-out precision GPIB DC power supply
4142B modular DC source/monitor; 10 A, 200 V
maximum
Bias networks5
11590B 100 MHz to 12.4 GHz, Type-N, 0.5 A and 100 V
maximum bias
Option 001 100 MHz to 18 GHz, 7 mm, 0.5 A and 100
V maximum bias
11612A 45 MHz to 26.5 GHz, 3.5 mm (f), 0.5 A and 40 V
maximum bias
Option 001 2 A maximum bias
11612B 45 MHz to 50 GHz, 2.4 mm (f), 0.5 A maximum
bias
System software
85070C high-temperature dielectric probe kit.
Includes the dielectric probe, software on 3.5 inch
disk, cables, port/cable adapters, switch, short cir-
cuit, mounting bracket, adapters, 50-ohm termination,
stand, vials, and stoppers. Measures complex permit-
tivity of materials. Standard software version runs
on PC with Windows® 95, 98, or NT 4.0.
85071C materials measurement software.
Measures complex permeability and permittivity
of materials in a transmission line environment.
Software runs on a PC with Windows® 95, 98, or
NT 4.0.
85190A IC-CAP modeling suite6
Design Software, Advanced Design System series
(ADS) and Series IV6connector repair kits
Application support
Agilent 50629E productivity assistance; provides one
hour of on-site consulting and assistance delivered
by an application engineer. Hourly charges apply
from portal to portal to cover travel costs.
Test Configuration Accessories
1. A power meter with the appropriate Agilent 8480 series power sensor is required
for use with the power meter calibration feature.
2. RF connectors: 3.5 mm (f) on RF input and output; BNC (f) detector out. 2.4 mm (f)
on RF input and output for 85050A, 83051A.
3. Inter-Continental Microwave, 1515 Wyatt Drive, Santa Clara, CA 95054-1524,
Telephone: [phone]
Fax: [phone]
4. For internally biasing with the 8719ES/8720ES/8722ES.
5. For supplying DC bias externally from test sets. Internal bias networks have
a current limit of 0.5 A.
6. Consult with an Agilent systems application engineer. The product you order
will depend on the test environment.

10
Printers
For a current list of compatible printers, consult our
printer-compatibility guide on the World Wide Web at
www.agilent.com/find/pcg
Interface cables
10833A GPIB cable: 1.0 m (3.3 ft.)
10833B GPIB cable: 2.0 m (6.6 ft.)
10833D GPIB cable: 0.5 m (1.6 ft.)
Keyboard
A keyboard with mini-DIN cable can be connected to
the Agilent 8720E family of netowrk analyzers inter-
face to form a remote front panel and to provide a
quicker, more convenient way to enter titles, labels,
and file names.
Equipment racks
5063-9223 rack mount flange kit, for use with handles;
includes handles1
5063-9236 rack mount kit, for use with handles; does
not include handles. May be ordered as Option 1CP.
5063-9216 rack mount kit, for use without handles.
May be ordered as Option 1CM.
1181B system testmobile, 3 ft. tall (see literature
number 5091-1233E)
1540-1695 operating case
9211-2657 transit case
Computers
Any computer configured with a GPIB interface card
and software drivers
Monitors
Any VGA-compatible monitor
Literature
Agilent 8720E family overview, literature number
5968-5161E
Agilent 8720E family data sheet, literature number
5968-5163E
For more information about the Agilent 8720E family,
visit our Web site at www.agilent.com/find/8720
Manuals
One manual set is included with each network
analyzer. Additional manual sets and service manuals
may be ordered as options when a network analyzer
is purchased, or separately using the part numbers.
For on-line manuals, visit our Web site at
www.agilent.com/find/manuals
8719/20/22 ET/ES manual set,
part number 08720-90390. Includes:
Installation and Quick Start Guide, 08720-90391
User’s Guide, 08720-90392
Reference Guide, 08720-90393
Programmer’s Guide, 08753-90475
CD-ROM, 08720-90418; includes all documents
in the manual set
8719/20/22 ET/ES service guide, part number
08720-90397. Includes service guide on CD-ROM,
part number 08720-90419.
Peripheral Accessories Literature and Manuals
1. The 8720E series of network analyzers is supplied with handles.
