Agilent Technologies E8285A User manual

Agilent Technologies E8285A CDMA
Mobile Station Test Set
Assembly Level Repair
Firmware Version: A.01.29 to A.02.04 (100-1000, 1700-2000 MHz)
Firmware Version: A.04.53 and above (800-1000, 1700-2000 MHz)
Agilent Part Number E8285-90033
Revision C
Printed in U.S.A.
June 2000
DUPLEX OUTRF IN/OUTPOWER ANTENNA IN VOLUME AUDIO OUT AUDIO IN
High Low
Max power 60 mW Max 12V peak Max
42V peak
DO NOT apply RF
when in standby Max power 2.5W
K1
K2
K3
K4
K5
K1'
USER CDMA SCREENS
CALL CONTROL UTILITIES
DATA FUNCTIONS DATA
K2'
K3'
Assign
Release
Call/
Page
Call
control Gen control Authen- tication
Cell config Spectrum SMS
RX test
Shift
TX test
MS report MS FER TX
range
End/
Release Register Tests Config Previous Message
Answer Print Printer I/O config Help
Preset
Meas
reset
Local
Recall
Hold
Address
Save
ANALOG SCREENS
Call
control Duplex Spectrun analyzer
RX test TX test AF
analyzer
Cancel
Increment
10
Low limit
Ref set
IBASIC
reset
Increment
set
Meter
Increment
x 10
High limit
Average 789Enter
456Ghz
dBm
dB
123MHz
V
%
0 . +/- kHz
mV
s
Yes
On/Off No
Ratio
W
%
dB Hz µV
ms
mW

2
S:\agilent\e8285\ALR\Book\chapters\front.fm
Notice
Information contained in this document is subject to change without
notice.
All Rights Reserved. Reproduction, adaptation, or translation without
prior written permission is prohibited, except as allowed under the
copyright laws.
This material may be reproduced by or for the U.S. Government
pursuant to the Copyright License under the clause at DFARS
52.227-7013 (APR 1988).
© Copyright 2000 Agilent Technologies

3
Manufacturer’s Declaration
This statement is provided to comply with the requirements of the
German Sound Emission Directive, from 18 January 1991.
This product has a sound pressure emission (at the operator position) <
70 dB(A).
• Sound Pressure Lp < 70 dB(A).
• At Operator Position.
• Normal Operation.
• According to ISO 7779:1988/EN 27779:1991 (Type Test).
Herstellerbescheinigung
Diese Information steht im Zusammenhang mit den Anforderungender
Maschinenlärminformationsverordnung vom 18 Januar 1991.
• Schalldruckpegel Lp < 70 dB(A).
•AmArbeitsplatz.
• Normaler Betrieb.
• Nach ISO 7779:1988/EN 27779:1991 (Typprüfung).

4
S:\agilent\e8285\ALR\Book\chapters\front.fm
Safety Considerations
GENERAL
This product and related documentation must be reviewed for
familiarization with safety markings and instructions before operation.
This product has been designed and tested in accordance with IEC
Publication 1010, “Safety Requirements for Electronic Measuring
Apparatus,”and has been supplied in a safe condition. This instruction
documentation contains information and warnings which must be
followed by the user to ensure safe operation and to maintain the
product in a safe condition.
SAFETY EARTH GROUND
A uninterruptible safety earth ground must be provided from the main
power source to the product input wiring terminals, power cord, or
supplied power cord set.
CHASSIS GROUND TERMINAL
To prevent a potential shock hazard, always connect the rear-panel
chassis ground terminal to earth ground when operating this
instrument from a dc power source.
SAFETY SYMBOLS
Indicates instrument damage can occur if indicated operating limits are
exceeded. Refer to the instructions in this guide.
Indicates hazardous voltages.
Indicates earth (ground) terminal
WARNING A WARNING note denotes a hazard. It calls attention to a
procedure, practice, or the like, which, if not correctly
performed or adhered to, could result in personal injury. Do not
proceed beyond a WARNING sign until the indicated conditions
are fully understood and met.
CAUTION A CAUTION note denotes a hazard. It calls attention to an operation
procedure, practice, or the like, which, if not correctly performed or
adhered to, could result in damage to or destruction of part or all of the
product. Do not proceed beyond an CAUTION note until the indicated
conditions are fully understood and met.
!

5
Safety Considerations for this Instrument
WARNING This product is a Safety Class I instrument (provided with a
protective earthing ground incorporated in the power cord). The
mains plug shall only be inserted in a socket outlet provided with a
protective earth contact. Any interruption of the protective conductor
inside or outside of the product is likely to make the product
dangerous. Intentional interruption is prohibited.
Whenever it is likely that the protection has been impaired, the
instrument must be made inoperative and be secured against any
unintended operation.
If this instrument is to be energized via an autotransformer (for
voltage reduction), make sure the common terminal is connected to
the earth terminal of the power source.
If this product is not used as specified, the protection provided by the
equipment could be impaired. This product must be used in a normal
condition (in which all means for protection are intact) only.
No operator serviceable parts in this product. Refer servicing to
qualified personnel. To prevent electrical shock, do not remove
covers.
Servicing instructions are for use by qualified personnel only. To
avoid electrical shock, do not perform any servicing unless you are
qualified to do so.
The opening of covers or removal of parts is likely to expose
dangerous voltages. Disconnect the product from all voltage sources
while it is being opened.
Adjustments described in the manual are performed with power
supplied to the instrument while protective covers are removed.
Energy available at many points may, if contacted, result in personal
injury.
The power cord is connected to internal capacitors that my remain
live for 5 seconds after disconnecting the plug from its power supply.
For Continued protection against fire hazard, replace the line fuse(s)
only with 250 V fuse(s) or the same current rating and type (for
example, normal blow or time delay). Do not use repaired fuses or
short circuited fuseholders.

6
S:\agilent\e8285\ALR\Book\chapters\front.fm
CAUTION Always use the three-prong ac power cord supplied with this product.
Failure to ensure adequate earth grounding by not using this cord may
cause product damage.
This product is designed for use in Installation Category II and
Pollution Degree 2 per IEC 1010 and IEC 664 respectively. For indoor
use only.
This product has autoranging line voltage input, be sure the supply
voltage is within the specified range.
Ventilation Requirements: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The
ambient temperature (outside the cabinet) must be less than the
maximum operating temperature of the product by 4°C for every 100
watts dissipated in the cabinet. If the total power dissipated in the
cabinet is greater than 800 watts, then forced convection must be used.

7
Product Markings
CE - the CE mark is a registered trademark of the European
Community. A CE mark accompanied by a year indicated the year the
design was proven.
CSA - the CSA mark is a registered trademark of the Canadian
Standards Association.

8
S:\agilent\e8285\ALR\Book\chapters\front.fm
Agilent Technologies Warranty Statement
for Commercial Products
E8285A CDMA Mobile Station Test Set
Duration of Warranty: One Year
1. Agilent warrants Agilent hardware, accessories and supplies against
defects in materials and workmanship for the period specified above.
If Agilent receives notice of such defects during the warranty period,
Agilent will, at its option, either repair or replace products which
prove to be defective. Replacement products may be either new or
like-new.
2. Agilent warrants that Agilent software will not fail to execute its
programming instructions, for the period specified above, due to
defects in material and workmanship when properly installed and
used. If Agilent receives notice of such defects during the warranty
period, Agilent will replace software media which does not execute
its programming instructions due to such defects.
3. Agilent does not warrant that the operation of Agilent products will
be uninterrupted or error free. If Agilent is unable, within a
reasonable time, to repair or replace any product to a condition as
warranted, customer will be entitled to a refund of the purchase
price upon prompt return of the product.
4. Agilent products may contain remanufactured parts equivalent to
new in performance or may have been subject to incidental use.
5. The warranty period begins on the date of delivery or on the date of
installation if installed by Agilent. If customer schedules or delays
Agilent installation more than 30 days after delivery, warranty
begins on the 31st day from delivery.
6. Warranty does not apply to defects resulting from (a) improper or
inadequate maintenance or calibration, (b) software, interfacing,
parts or supplies not supplied by Agilent, (c) unauthorized
modification or misuse, (d) operation outside of the published
environmental specifications for the product, or (e) improper site
preparation or maintenance.
7. TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE
WARRANTIES ARE EXCLUSIVE AND NO OTHER WARRANTY
OR CONDITION, WHETHER WRITTEN OR ORAL IS
EXPRESSED OR IMPLIED AND AGILENT SPECIFICALLY
DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OR
MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS
FOR A PARTICULAR PURPOSE.

9
8. Agilent will be liable for damage to tangible property per incident up
to the greater of $300,000 or the actual amount paid for the product
that is the subject of the claim, and for damages for bodily injury or
death, to the extent that all such damages are determined by a court
of competent jurisdiction to have been directly caused by a defective
Agilent product.
9. TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES
IN THIS WARRANTY STATEMENT ARE CUSTOMER’S SOLE
AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE,
IN NO EVENT WILL AGILENT OR ITS SUPPLIERS BE LIABLE
FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR
OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR
OTHERWISE.
FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW
ZEALAND: THE WARRANTY TERMS CONTAINED IN THIS
STATEMENT, EXCEPT TO THE EXTENT LAWFULLY
PERMITTED, DO NOT EXCLUDE RESTRICT OR MODIFY AND
ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS
APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.

10
S:\agilent\e8285\ALR\Book\chapters\front.fm
European Contact: Your local Agilent Technologies and Service Office or Agilent Technologies GmbH
Department ZQ/Standards Europe, Herrenberger Strasse 130, D-71034 Böblinger, Germany (FAX[phone])
DECLARATION OF CONFORMITY
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name:
Manufacturer’s Address:
declares that the product
Product Name:
Model Number:
Product Options:
Agilent Technologies
Spokane Division
24001 E. Mission Avenue
Liberty Lake, Washington 99019-9599
USA
CDMA Mobile Station Test Set
Agilent Technologies E8285A
All
conforms to the following Product specifications:
Safety: IEC 61010-1:1990+A1+A2 / EN 61010-1:1993+A2
EMC: CISPR 11:1990/EN 55011:1991- Group 1, Class A
IEC 61000-3-2:1995 / EN 61000-3-2: 1995
EN 50082-1:1992
IEC 801-3:1984 3V/m
IEC 801-4:1988 0.5 kV Sig. Lines, 1 kV Power Lines
Supplementary Information:
This product herewith complies with the requirements of
the Low Voltage Directive 73/23/EEC and the EMC
Directive 89/336/EEC and carries the CE-marking
accordingly.
Spokane, Washington USA November 20, 1998
Vince Roland
Reliability & Regulatory
Engineering Manager

11
Table 1
United States of America:
Agilent Technologies
Test and Measurement Call
Center
P.O. Box 4026
Englewood, CO 80155-4026
(tel) 1 800 452 4844
Canada:
Agilent Technologies
Canada Inc.
5159 Spectrum Way
Mississauga, Ontario
L4W 5G1
(tel) 1 877 894 4414
Europe:
Agilent Technologies
European Marketing
Organization
P.O. Box 999
1180 AZ Amstelveen
The Netherlands
(tel) (3120) 547 9999
Japan:
Agilent Technologies Japan Ltd.
Measurement Assistance Center
9-1 Takakura-Cho, Hachioji-Shi,
Tokyo 192-8510, Japan
(tel) (81) 456-56-7832
(fax) (81) 426-56-7840
Latin America:
Agilent Technologies
Latin America Region
Headquarters
5200 blue Lagoon Drive,
Suite #950
Miami, Florida 33126
U.S. A.
(tel) [phone]
(fax) [phone]
Australia/New Zealand:
Agilent Technologies
Australia Pty Ltd
347 Burwood Highway
Forest Hill, Victoria 3131
(tel) 1 800 629 485 (Australia)
(fax) (61 3) 9272 0749
(tel) 0 800 738 378 (New
Zealand)
(fax) (64 4) 802 6881
Asia Pacific:
Agilent Technologies
19/F, Cityplaza One,
111 Kings Road,
Taikoo shing, Hong Kong, SAR
(tel) (852) 2599 7899
(fax) (852) 2506 9233

12
S:\agilent\e8285\ALR\Book\chapters\front.fm
Agilent Technologies E8285A Support
Contacts
The documentation supplied with your Test Set is an excellent source of
reference, application, and service information. Please use these
manuals if you are experiencing technical problems:
Table 2 Support Documentation
If you have used the manuals and still have application questions,
contact your local Agilent Technologies Sales Representative.
Repair assistance is available for the Agilent E8285A CDMA Mobile
Station Test Set from the factory by phone and e-mail. External and
internal Agilent users can contact the factory via email. Parts
information is also available from Agilent.
When calling or writing for repair assistance, please have the following
information ready:
•Instrument model number (E8285A)
•Instrument Serial Number (tag located on the rear panel).
•Installed options - if any (tag located on the rear panel).
•Instrument firmware revision (displayed at the top of the screen
when the Test Set is powered up, and is also displayed on the
CONFIGURE screen).
Support Telephone Numbers:
1 800 827 3848 (RF Comms Service Assistance, U.S. only)
1 509 921 3848 (RF Comms Service Assistance, International)
1 800 227 8164 (Agilent Direct Parts Ordering, U.S. only)
1 800 403 0801 (Agilent Instrument Support Center, U.S. only)
1 916 783 0804 (Agilent Service Parts Identification, U.S. & Intl.)
User’s Guide Quick Reference Guide
Application Guide Assembly Level Repair
Reference Guide CD-ROM

13
Power Cables
Table 3
Plug type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°8120-1689
8120-1692 79 inches, mint gray 79 inches, mint gray
Used in the following locations:
Bangladesh, Belgium, Benin, Bolivia, Boznia-Herzegovina, Bulgaria, Burkina Faso, Burma,
Burundi,Byelarus
Cameroon, Canary Islands, Central African Republic, Chad, Chile, Comoros, Congo, Croatia,
Czech Republic, Czechoslovakia
Denmark, Djibouti
East Germany, Egypt, Estonia, Ethiopia
Finland, France, French Guiana, French Indian Ocean Areas
Gabon, Gaza Strip, Georgia, Germany, Gozo, Greece
Hungary
Iceland, Indonesia, Iran, Iraq, Israel, Italy, Ivory Coast
Jordan
Kazakhstan, Korea, Kyrgystan
Latvia, Lebanon, Libya, Lithuania, Luxembourg
Macedonia, Madeira Islands, Malagasy Republic, Mali, Malta, Mauritania, Miquelon, Moldova,
Mongolia, Morocco, Mozambique
Nepal, Netherlands, Netherlands Antilles, Niger, Norway
Oman
Pakistan, Paraguay, Poland, Portugal
Rep. South Africa, Romania, Russia, Rwanda
Saudi Arabia (220V), Senegal, Slovak Republic, Slovenia, Somalia, Spain, Spanish Africa, Sri
Lanka, St. Pierce Islands
Earth
Ground
Line Neutral

14
S:\agilent\e8285\ALR\Book\chapters\front.fm
Table 4
Table 5
Sweden, Syria
Tajikistan, Thailand, Togo, Tunisa, Turkey, Turkmenistan
USSR, Ukraine, Uzbekistan
Western Africa, Western Sahara
Yugoslavia
Zaire
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°8120-0698 90 inches, black
Used in the following locations:
Peru
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°8120-2104 8120-2296 79 inches, gray 79 inches, gray
Used in the following locations:
Switzerland
Plug type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Earth
Ground
Line Line
Earth
Ground
Line Neutral

15
Table 6
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°
Straight/Straight
8120-1378
8120-1521
8120-1751
90 inches, jade gray
90 inches, jade gray
90 inches, jade gray
Used in the following locations:
American Samoa
Bahamas, Barbados, Belize, Bermuda, Brazil
Caicos, Cambodia, Canada, Cayman Islands, Columbia, Costa Rica, Cuba
Dominican Republic
Ecuador, El Salvador
French West Indies
Guam, Guatemala, Guyana
Haiti, Honduras
Jamaica
Korea
Laos, Leeward and Windward Islands, Liberia
Mexico, Midway Islands
Nicaragua
Other Pacific Islands
Panama, Philippines, Puerto Rico
Saudi Arabia (115V, 127V), Suriname
Taiwan, Tobago, Trinidad, Trust Territories of Pacific Islands
Turks Island
United States
Venezuela, Vietnam, Virgin Islands of the U.S.
Wake Island
125V
Earth
Ground
LineNeutral

16
S:\agilent\e8285\ALR\Book\chapters\front.fm
Table 7
Table 8
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°8120-4753 8120-4754 90 inches, dark gray 90 inches, dark gray
Used in the following locations:
Japan
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
90°/Straight
90°/90°
Straight/Straight
8120-2956
8120-2957
8120-3997
79 inches, gray
79 inches, gray
79 inches, gray
Used in the following locations:
Denmark
Greenland
JIS C 8303, 100 V
Earth
Ground
LineNeutral
Earth
Ground Line
Neutral

17
Table 9
Table 10
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Description
Straight/Straight
Straight/90°8120-4211 8120-4600 79 inches, mint gray 79 inches, mint gray
Used in the following locations:
Botswana
India
Lesotho
Malawi
South-West Africa (Namibia), Switzerland
Zambia, Zimbabwe
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/Straight
Straight/90°
Straight/90°
8120-1860
8120-1575
8120-2191
8120-4379
60 inches, jade gray
30 inches, jade gray
60 inches, jade gray
15.5 inches, jade gray
Used in the following locations:
System Cabinets
Earth
Ground
Line Neutral
Line Neutral
Earth
Ground

18
S:\agilent\e8285\ALR\Book\chapters\front.fm
Table 11
Plug Type (Male) Plug Descriptions
male/female Agilent Part # (cable and plug) Cable Descriptions
90°/Straight
90°/90°8120-1351 8120-1703 90 inches, mint gray 90 inches, mint gray
Used in the following locations:
Bahrain, British Indian Ocean Terr., Brunei
Canton, Cyprus
Enderbury Island, Equatorial Guinea
Falkland Islands, French Pacific Islands
Gambia, Ghana, Gibraltar, Guinea
Hong Kong
Ireland
Kenya, Kuwait
Macao, Malaysia, Mauritius
Nigeria
Qatar
Seychelles, Sierra Leone, Singapore, Southern Asia, Southern Pacific Islands, St. Helena, Sudan
Tanzania
Uganda, United Arab Emirates, United Kingdom
Yeman (Aden & Sana)
Earth
Ground
Line Neutral

19
Table 12
Plug Type Plug Descriptions
male/female Agilent Part # (cable & plug) Cable Descriptions
Straight/Straight
Straight/90°8120-1369 8120-0696 79 inches, gray 80 inches, gray
Used in the following locations:
Argentina, Australia
China (People’s Republic)
New Zealand
Papua New Guinea
Urugray
Western Samoa
Line Neutral
Earth
Ground

20
S:\agilent\e8285\ALR\Book\chapters\front.fm
ATTENTION
Static Sensitive
Devices
This instrument was constructed in an ESD (electro-static discharge) protected environment. This is
because most of the semi conductor devices used in this instrument are susceptible to damage by
static discharge.
Depending on the magnitude of the charge, device substrates can be punctured or destroyed by
contact or mere proximity of a static charge. The result can cause degradation of device performance,
early failure, or immediate destruction.
These charges are generated in numerous ways such as simple contact, separation of materials, and
normal motions of persons working with static sensitive devices.
When handling or servicing equipment containing static sensitive devices, adequate precautions must
be taken to prevent device damage or destruction.
Only those who are thoroughly familiar with industry accepted techniques for handling static
sensitive devices should attempt to service circuitry with these devices.
In all instances, measures must be taken to prevent static charge build-up on work surfaces and
persons handling the devices.
