Agilent Technologies J2126A Installation and operation manual

Agilent J2126/7A
Transmission Test Sets
Installation and
Verification Manual

sdh_Lynx2.book Page 148 Wednesday, April 17, 2002 12:49 PM

Agilent Technologies
Agilent J2126/7A
Transmission Test Set
Installation and
Verification Manual

2 Installation and Verification Manual
Notices
© Agilent Technologies UK Limited 2002
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies UK Limited as governed by
international copyright laws.
Manual Part Number
J7280-90012
Edition
First edition, September 2002
Printed in UK
Agilent Technologies UK Limited
Transmission & Transport Test Operation
South Queensferry, West Lothian, Scotland
EH30 9TG
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Tec hnology Li ce ns es
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of a
U.S. Government prime contract or subcon-
tract, Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995),
or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer soft-
ware” as defined in FAR 52.227-19 (June
1987) or any equivalent agency regulation or
contract clause. Use, duplication or disclo-
sure of Software is subject to Agilent Tech-
nologies’ standard commercial license
terms, and non-DOD Departments and
Agencies of the U.S. Government will
receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will receive
no greater than Limited Rights as defined in
FAR 52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November 1995), as
applicable in any technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.

Installation and Verification Manual 3
In This Guide…
You will find information for installing and verifying the
performance of your instrument
1 Introduction
This chapter provides a brief description of the product and
also all safety requirements the user should be aware of when
using the instrument.
2 Installation (Getting Started)
This chapter provides general information on how to install and
connect up the instrument.
3PerformanceTests
This chapter details the procedures to test the performance of
the instrument and provides a test record table to record the
results of the tests.
4 Self Test Overview
This chapter details all of the Self Test procedures.
5 ETSI/ANSI Terminology
This chapter provides a table explaining the equivalent
SDH/SONET terms.

4 Installation and Verification Manual
Conventions Used in this Manual
The conventions used in this manual to illustrate instrument
keys and display information are as follows:
<Menu> This is an example of a hardkey. Hardkeys (located to the right
of the display) are used to give access to different sets of
instrument settings, or select dedicated instrument functions.
Menu Items Menu items appear in text as bold face with the greater than (>)
symbol separating each menu level. For example, if you are
instructed to choose Errors and Alarms from the Test Functions
menu item, it appears as Test Functions > Errors and Alarms.
Field Items Field items you are instructed to select in a window will appear
in bold face, for example select Signal Rate field.
Drop Down Lists The item you must select from a drop down list is also shown in
bold. For example, select Signal Rate field and choose STM-1 or
OC-3 from the drop down list.

Installation and Verification Manual 5
1 Introduction
Product Description 12
SONET/SDH Capability 12
Ethernet Capability 13
Option Guide 15
Mainframes and Potential Test Rate Capability 15
Optical Interfaces 16
Optical Connectors (product options) 16
Alternative Optical Connectors (available accessories) 17
Ethernet Options 17
Other Options 17
Accessories 18
General Information 19
Responsibilities of the Customer 19
Certification 19
Assistance 19
Instruments Covered By Manual 20
Storage and Shipment 21
Temperature 21
Altitude 21
Repackaging for Shipment 21
Weight and Dimensions 22
Safety Information 23
Safety Precautions 23
Safety Symbols 24
Avoiding Problems When Making Measurements 26
Operators Maintenance 27
Cleaning Optical Connectors 27
Statement of Compliance 29
Noise Declaration (German) 30
Electromagnetic Compatibility 30
Declaration of Conformity 30
Contents

6 Installation and Verification Manual
2 Installation (Getting Started)
Preparation 32
Initial Inspection 32
Operating Environment 32
Preparation for Use 33
Power Requirements 33
Connecting to the Power Supply 34
Power Cable 35
Removing the Instrument Covers 36
Connecting the Mouse Cable 36
Useful Information When Requesting Support 37
Operation Checks on Delivery 38
Power-up Sequence 38
Recalling Default Settings 39
Back-to-Back Functional Checks 40
What to do if the Test fails 45
Optical Connector Safety Information 46
Laser Warnings and Cautions 46
Laser Warning Symbols 48
Avoiding Optical Receiver Overload 48
Additional Precautions for Service Engineers 49
ESD Precautions 49
Top Panel Connectors 51
Optical Out Ports 52
Optical In Ports 53
Clock Ports 54
DCC Port 55
Electrical Test Ports 56
Ethernet Ports 57
Connectors on Instrument Front/Left Side Panel 58
Connectors on Instrument Front/Right Side Panel 59
Instrument Reboot (Cold Start) 61

Installation and Verification Manual 7
3PerformanceTests
Introduction 64
Equipment Required 64
Performance Test Record 64
Calibration Check Cycle 64
Instrument Option Configuration 64
Recommended Test Equipment 65
Self Test Loopback Cables and Accessories 66
Recall Default Settings 67
Performance Self Test 68
Description of the Performance Self Test 68
Loopback Connections Required for Self Test 69
How to run the Self Test 72
What to do if the Self Test fails 72
Internal Reference Clock Accuracy 73
Specification 73
Description 73
Equipment Required 74
Procedure 74
Alternative DS1 Clock test (if suitable DSn Test Set is not
available) 78
External Clock Reference Inputs and Clock Reference Output 79
Specifications 79
Description 79
Equipment Required 79
Procedure 80
Optical Pulse Mask and Output Characteristics 86
Specifications 86
Description 86
Equipment Required 87
Procedure 87
52/155 and 622 Mb/s Optical Output Checks 88
OC-1/STM-0 Power Level and Eye Mask Tests 88
OC-3/STM-1 Power Level and Eye Mask Tests 90
OC-12/STM-4 Power Level and Eye Mask Tests 91

8 Installation and Verification Manual
2.5 Gb/s Optical Output Checks 93
OC-48/STM-16 Power Level and Eye Mask Tests 93
10 Gb/s Optical Output Checks (if fitted) 95
OC-192/STM-64 Power Level and Eye Mask Tests 95
Optical Receiver Sensitivity, Optical Power and Frequency
Measurement 98
Specifications 98
Description 99
Equipment Required 100
Procedure 100
Checking the Receiver Minimum Sensitivity Margin Against Laser
Transmitter Extinction Ratio (ER) 113
Electrical Pulse Mask and Output Level Characteristics 114
Specifications 114
Description 115
Equipment Required 115
Procedure 115
DS1 Output Mask Test 116
2 Mb/s Balanced Output Mask Tests 118
2 Mb/s Unbalanced Output Mask Tests 121
8 Mb/s Output Mask Tests 123
34 Mb/s Output Mask Tests 125
DSX-3 Output Mask Tests 127
140 Mb/s Output Mask Tests 129
51.84 Mb/s (STS-1) Output Mask Tests 132
155 Mb/s Output Mask Tests 136
Performance Test Record 140

Installation and Verification Manual 9
4 Self Test Overview
Description of the Self Test 148
List of Self Tests 149
Loopback Connections Required for Self Test 151
How to Run a Self Test 155
Error messages and codes 155
List of Self Test Sub Tests 156
What to Do if the Self Test Fails 161
Tips and Checks to Confirm Correct Optical Loopback 161
5 ETSI/ANSI Terminology
ETSI/ANSI Conversion and Equivalent Terms 164

10 Installation and Verification Manual

11
Agilent Technologies
1
Introduction
Product Description 12
Option Guide 15
General Information 19
Safety Information 23
Avoiding Problems When Making Measurements 26
Operators Maintenance 28
Statement of Compliance 29
This chapter provides a brief description of the product and
also all safety requirements the user should be aware of when
using the instrument.

12 Installation and Verification Manual
1Introduction
Product Description
The instrument provides all the test capability you need to
install and verify the performance of today’s high-capacity
transmission systems and networks in one portable package.
In addition, there is an Ethernet module that can fully test the
data capabilities of the new generation of multi-service network
elements.
SONET/SDH Capability
•Global test coverage (SONET, SDH, PDH and T-Carrier).
•Full integrated all-rate testing:
•52 Mb/s to 10 Gb/s optical.
•52/155 Mb/s; DS1/3; 2/8/34/140 Mb/s electrical.
•Full range of standard and concatenated mappings.
•All standard error and alarm measurements, plus:
•optical power, electrical level, pulse mask, frequency.
•service disruption time, pointer movements, delay.
•Simultaneous all-channel testing (up to 192 STSs/AUs).
•Intrusive and non-intrusive Thru-mode.
•Comprehensive SONET/SDH overhead testing.

Introduction 1
Installation and Verification Manual 13
•Electrical interfaces
(DS1/3; 2/8/34/140 Mb/s; 52/155 Mb/s)
•VT/TU payload testing
•DS1/3 and 2/34/140 Mb/s service mappings
•DSn and PDH (En) testing
•Pulse mask testing (up to 52 Mb/s electrical)
•Service disruption measurement
•Round trip delay measurement
•Electrical level measurement
•Graphical error and alarm result displays
•G.821, M2100, M2101, M2101.1, M2110, M.2120 performance
analysis
•Fast access to key measurement tasks using Smart Test.
•Line and payload frequency offset.
•Transmit and Receive can be independently configured.
•Broad range of graphical results tools.
•Comprehensive online help facilities:
•Online User manual.
•Context-sensitive help for each control field.
•Ability to add your own help documents.
See “Option Guide" on page 15, for more product details.
Ethernet Capability
•Test data services at Layer 1 and Layer 2
•Multi-port testing - 8x10/100 Mb/s and 2x1 Gigabit Ethernet
•Simultaneous operation of all ports
•Simultaneous SONET/SDH and Ethernet operation
•Extremely simple to set-up and operate
•Hot-swap GBIC modules for wavelength choice
•Automated RFC 2544 benchmark testing
•Full rate traffic generation and reception

14 Installation and Verification Manual
1Introduction
•Can be used for end-to-end or loopback testing
•Unique “Loopthru” mode allows loopback testing even at
Layer 2
•Measure the “Transmission” elements of Ethernet:
•Throughput
•Latency
•Frame Loss
•Errors
•User selectable full/restricted/fixed auto negotiation
•User selectable VLAN/priority tagging and flow control
•Frame capture facility
•Comprehensive online help facilities:
•Online User manual
•Context-sensitive help for each control field
•Ability to add your own help documents
See “Option Guide" on page 15, for more product details.

Introduction 1
Installation and Verification Manual 15
Option Guide
This guide explains the features offered with each instrument
mainframe and its associated options.
For more information, see:
•“Mainframes and Potential Test Rate Capability" on page 15
•“Optical Interfaces" on page 16
•“Optical Connectors (product options)" on page 16
•“Alternative Optical Connectors (available accessories)" on
page 17
•“Ethernet Options" on page 17
•“Other Options" on page 17
•“Accessories" on page 18
Mainframes and Potential Test Rate Capability
There are three mainframes:
•J2126A - 3-slot chassis
•J2127A - 4-slot chassis
•J2127A - 6-slot extended chassis
Mainframe Optical Test Interfaces Frequency Range
J2126A
(see Note 1)
OC-1, OC-3, OC-12, OC-48
STM-0, STM-1, STM-4, STM-16
52 Mb/s to 2.5 Gb/s
J2127A
(see Notes 1, 2 and 3)
OC-1, OC-3, OC-12, OC-48,
OC-192
STM-0, STM-1, STM-4, STM-16,
STM-64
52 Mb/s to 10 Gb/s
1. With option 103 fitted, maximum line rate restricted to OC-12/STM-4.
2. Can be configured with maximum line rate of OC-48/STM-16 and later
upgraded to OC-192/STM-64.
3. Can have a 4-slot chassis or extended (6-slot) chassis.

16 Installation and Verification Manual
1Introduction
Optical Interfaces
Optical Connectors (product options)
Tx Optical Wavelength Option
Optical interfaces
operating up to 2.5 Gb/s
1310 nm 100
1550 nm 101
1310/1550 nm 102
Optical interfaces
operating up to 10 Gb/s
1550 nm 111 (HS*), 121 (SR**)
1310 nm 120 (SR**)
* HS - High Rx sensitivity optics.
** SR - Short reach optics.
Connector Option
FC/PC Adapters fitted on all optical interfaces 190
SC Adapters fitted on all optical interfaces 191
ST Adapters fitted on all optical interfaces 192

Introduction 1
Installation and Verification Manual 17
Alternative Optical Connectors (available accessories)
Alternative optical connectors are available for your product,
order the appropriate J7283A (FC/PC), J7284A (SC) or
J7285A (ST) accessory (connector). The number of connectors
required for your product is shown below.
Ethernet Options
Other Options
Certificate of Calibration
Option UK6: Calibration certificate with test data
J7283A (FC/PC) J7284A (SC) J7285A (ST)
J2126A with option
100/101
222
J2126A with option 102 3 3 3
J2127A* with option
100/101 and
111/120/121
555
J2127A* with option 102
and 111/120/121
666
* Can have a 4-slot chassis or extended (6-slot) chassis.
Option
Ethernet testing (8 x 10/100 Mb/s; 2 x 1 Gb/s) 323
1000Base-SX (850 nm) GBIC modules (two) 325
1000Base-LX (1310 nm) GBIC modules (two) 326

18 Installation and Verification Manual
1Introduction
Warranty and Service Plans
Terms and conditions of the applicable warranty for this
product are contained in the sales and related documentation
supplied separately.
Please contact your nearest Agilent Technologies Sales Office
for further information on warranty and extended warranty
options.
For access to Agilent Product information and sales/service
contacts, please visit:
http://www.agilent.com.
Accessories
Additional Documentation
J7280A: Full set of printed manuals:
User Guide, Quick Reference Guide, Remote Control, and
Installation and Verification manual.
Carrying Cases
J7286A: Hard transit case (for J2126A)
J7287A: Hard transit case (for J2127A)
J7288A: Soft carrying case (for J2126/7A)
J7289A: Hard transit case (for J2127A 6-slot extended chassis)
J7290A: Soft carrying case (for J2127A 6-slot extended chassis)
Optical Adapters and Cables
J7283A: FC/PC optical connector (exchangeable)
J7284A: SC optical connector (exchangeable)
J7285A: ST optical connector (exchangeable)
J7281A: DCC port converter cable: 9-pin miniature D-type to
37-pin D-type (RS-449, female)
