Agilent Technologies
Agilent TS-5400
Functional Test System
Series IIB
Site Preparation and Getting
Started Manual
*E8770-90037*
*E8770-90037**E8770-90037*
*E8770-90037*
Manual Part Number E8770-90037

Notices
© Agilent Technologies, Inc. 1999 - 2003
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Agi-
lent Technologies, Inc. as governed by
United States and international copyright
laws.
Documentation History
All Editions and Updates of this manual and
their creation date are listed below. The
first Edition of the manual is Edition 1. The
Edition number increments by 1 whenever
the manual is revised. Updates, which are
issued between Editions, contain replace-
ment pages to correct or add additional
information to the current Edition of the
manual. Whenever a new Edition is cre-
ated, it will contain all of the Update infor-
mation for the previous Edition. Each new
Edition or Update also includes a revised
copy of this documentation history page.
Edition 1 (E8770-90010)September 1999
Edition 2 (E8770-90027)September 2000
Edition 3 (E8770-90037) August 2003
Manual Part Number
E8770-90037
Printed in USA
Agilent Technologies, Inc.
1601 California Street
Palo Alto, CA 94304 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warran-
ties, either express or implied, with
regard to this manual and any infor-
mation contained herein, including
but not limited to the implied warran-
ties of merchantability and fitness for
a particular purpose. Agilent shall not
be liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
Caution
A Caution notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
Caution notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and met.

Safety and Support Information 3
Safety Summary
The following general safety
precautions must be observed
during all phases of operation of
this system. Failure to comply
with these precautions or with
specific warnings elsewhere in
this manual violates safety
standards of design,
manufacture, and intended use
of the system. Agilent
Technologies, Inc. assumes no
liability for the customer's
failure to comply with these
requirements.
General
This product is provided with a
protective earth terminal. The
protective features of this
product may be impaired if it is
used in a manner not specified
in the operation instructions.
WARNING: DO NOT OPERATE
IN AN EXPLOSIVE ATMOSPHERE
Do not operate the system in the
presence of flammable gases or
flames.
If the equipment in this system
is used in a manner not
specified by Agilent
Technologies, the protection
provided by the equipment may
be impaired.
Cleaning Instructions
Clean the system cabinet using a
soft cloth dampened in water.
WARNING: DO NOT REMOVE
ANY SYSTEM COVER
Operating personnel must not
remove system covers. Component
replacement and internal
adjustments must be made only by
qualified service personnel.
Equipment that appears damaged or
defective should be made
inoperative and secured against
unintended operation until they can
be repaired by qualified service
personnel.
Environmental Conditions
Unless otherwise noted in the
specifications, this system is
intended for indoor use in an
installation category II,
pollution degree 2 environment.
It is designed to operate at a
maximum relative humidity of
80% and at altitudes of up to
2000 meters. Refer to the
specifications tables for the ac
mains voltage requirements and
ambient operating temperature
range.
Before applying power
Verify that all safety precautions
are taken. Note the external
markings described in “Safety
Symbols and Regulatory
Markings” on page 4.

4 Safety and Support Information
Ground the System
To minimize shock hazard, the
system chassis must have a
hard-wired connection to an
electrical protective earth
ground. The system must also be
connected to the ac power mains
through a power cable that
includes a protective earth
conductor. The power cable
ground wire must be connected
to an electrical ground (safety
ground) at the power outlet. Any
interruption of the protective
grounding will cause a potential
shock hazard that could result in
personal injury.
Fuses
Use only fuses with the required
rated current, voltage, and
specified type (normal blow,
time delay). Do not use repaired
fuses or short-circuited fuse
holders. To do so could cause a
shock or fire hazard.
Operator Safety Information
MODULE CONNECTORS AND
TEST SIGNAL CABLES
CONNECTED TO THEM
CANNOT BE OPERATOR
ACCESSIBLE: Cables and
connectors are considered
inaccessible if a tool (e.g.,
screwdriver, wrench, socket,
etc.) or a key (equipment in a
locked cabinet) is required to
gain access to them.
Additionally, the operator
cannot have access to a
conductive surface connected to
any cable conductor (High, Low
or Guard).
ASSURE THE EQUIPMENT
UNDER TEST HAS
ADEQUATE INSULATION
BETWEEN THE CABLE
CONNECTIONS AND ANY
OPERATOR-ACCESSIBLE
PARTS (DOORS, COVERS,
PANELS, SHIELDS, CASES,
CABINETS, ETC.): Verify there
are multiple and sufficient
protective means (rated for the
voltages you are applying) to
assure the operator will NOT
come into contact with any
energized conductor even if one
of the protective means fails to
work as intended. For example,
the inner side of a case, cabinet,
door, cover or panel can be
covered with an insulating
material as well as routing the
test cables to the module’s front
panel connectors through
non-conductive, flexible conduit
such as that used in electrical
power distribution.
Safety Symbols and
Regulatory Markings
Symbols and markings on the
system, in manuals and on
instruments alert you to
potential risks, provide
information about conditions,
and comply with international
regulations. Table 1 defines the
symbols and markings you may
encounter.

Safety and Support Information 5
Table 1 Safety Symbols and Markings
Safety symbols
Warning: risk of electric shock.
Caution: refer to accompanying documents.
Alternating current.
Both direct and alternating current.
Earth (ground) terminal
Protective earth (ground) terminal
Frame or chassis terminal
Terminal is at earth potential. Used for measurement and control
circuits designed to be operated with one terminal at earth potential.
Switch setting indicator. O = Off, | = On.
Standby (supply); units with this symbol are not completely
disconnected from ac mains when this switch is off. To completely
disconnect the unit from ac mains, either disconnect the power cord, or
have a qualified electrician install an external switch.
Regulatory Markings
The CE mark is a registered trademark of the European Community.
The CSA mark is a registered trademark of the Canadian Standards
Association.
The C-tick mark is a registered trademark of the Spectrum Management
Agency of Australia. This signifies compliance with the Australian EMC
Framework regulations under the terms of the Radio Communications
Act of 1992.
ISM 1-A This text indicates that the product is an Industrial Scientific and
Medical Group 1 Class A product (CISPR 11, Clause 4).
N10149

6 Safety and Support Information
Service and Support
Any adjustment, maintenance,
or repair of this product must be
performed by qualified
personnel. Contact your
customer engineer through your
local Agilent Technologies
Service Center.
Agilent on the Web
You can find information about
technical and professional
services, product support, and
equipment repair and service on
the Web:
http://www.agilent.com
Click the link to Te st &
Measurement. Select your
country from the drop-down
menus. The Web page that
appears next has contact
information specific for your
country.
Agilent by Phone
If you do not have access to the
Internet, call one of the numbers
in Table 2.
Tab le 2 Agilent Call Centers and Regional Headquarters
United States and Canada: Test and Measurement Call Center
[phone] (toll-free in US)
Europe: (41 22) 780 8111
Japan: Measurement Assistance Center
(81) 0426 56 7832
Latin America: 305 269 7548
Asia-Pacific: (85 22) 599 7777

DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014
Revision: B.02 Issue Date: 16 August 2001 Document E8770A.DOC
Manufacturer’s Name: Agilent Technologies, Incorporated
Manufacturer’s Address: 815 – 14th St. SW
Loveland, Colorado 80537
USA
Declares, that the product
Product Name: TS5400, TS5430, TS5450 Series Automotive Test Systems
Model Number: E6170A/B, E6230A/B, E8770A, E8780A, E8785A, E8786A
Product Options: This declaration covers all options of the above product(s).
Conforms with the following European Directives:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, and the EMC Directive 89/336/EEC
(including 93/68/EEC) and carries the CE Marking accordingly.
Conforms with the following product standards:
EMC Standard
IEC 61326-1:1997+A1:1998 / EN 61326-1:1997+A1:1998
CISPR 11:1990 / EN 55011:1991
IEC 61000-4-2:1995+A1:1998 / EN 61000-4-2:1995
IEC 61000-4-3:1995 / EN 61000-4-3:1995
IEC 61000-4-4:1995 / EN 61000-4-4:1995
IEC 61000-4-5:1995 / EN 61000-4-5:1995
IEC 61000-4-6:1996 / EN 61000-4-6:1996
IEC 61000-4-11:1994 / EN 61000-4-11:1994
Canada: ICES-001:1998
Australia/New Zealand: AS/NZS 2064.1
Limit
Group 1 Class A
4kV CD, 8kV AD
3 V/m, 80-1000 MHz
0.5kV signal lines, 1kV power lines
0.5 kV line-line, 1 kV line-ground
3V, 0.15-80 MHz I cycle, 100%
Dips: 30% 10ms; 60% 100ms
Interrupt > 95%@5000ms
As detailed in: Electromagnetic Compatibility (EMC) Certificate of Conformance No. 71301-KRQ/EMC 97-4165,
dated 18 February 1997.
Assessed by: KEMA Registered Quality Nederland B.V.
Utrechtseweg 310
6812 AR Arnhem, 6800 ET Arnhem
The Netherlands
The product was tested in a typical configuration with Agilent Technologies test systems.
Safety IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1993+A2:1995
Canada: CSA C22.2 No. 1010.1:1992
UL 3111-1: 1994 (NRTL approval issued by CSA)
16 August 2001
Date Ray Corson
Product Regulations Program Manager
For further information, please contact your local Agilent Technologies sales office, agent or distributor.
Authorized EU-representative: Agilent Technologies Deutschland GmbH, Herrenberger Straβe 130, D 71034 Böblingen, Germany

8
Notes:

Contents 9
Contents
Declaration of Conformity............................................................................................ 7
Chapter 1
Preparing Your Site for the System ........................................................................... 11
Typical System ........................................................................................................... 11
The System Plan Drawing .......................................................................................... 12
System Power Requirements ...................................................................................... 13
Minimum Power Requirements .......................................................................... 13
Power Recommendations .................................................................................... 14
Additional Power Information ............................................................................ 14
Mains Disconnect Requirements ......................................................................... 15
Site Configuration for AC Power ........................................................................ 15
Mains Wiring and Sizes.............................................................................................. 17
Chapter 2
Installing the Keyboard, Mouse and Printer ............................................................ 21
Tools Required............................................................................................................ 21
Installation Procedure ................................................................................................. 22
Chapter 3
Connecting Power and Getting Started ..................................................................... 27
Tools Required .................................................................................................... 27
Connecting AC Mains Power to the Agilent TS-5400 System .................................. 27
Procedure ............................................................................................................. 28
Determine the Power Cord Type Needed ........................................................... 29
Locate the Agilent E1135C PDU ........................................................................ 31
Set PDU Mains Disconnect to 0 (Off), Attach Strain Relief to the
PDU’s Access Panel ......................................................................................... 32
Connect Power Cord to PDU .............................................................................. 33
Replace Access Panel, Tighten Strain Relief onto Power Cord .......................... 37
Connect Safety Ground ....................................................................................... 38
Attach Power Plug (not supplied) ....................................................................... 39
Plug-In Power Cord, Set PDU Mains Disconnect to 1 (On) ............................... 40
Turn On the System ............................................................................................. 40
Selecting Agilent TestExec SL ................................................................................... 41
Getting Started Examples ........................................................................................... 41
Wiring Information ..................................................................................................... 41
Index ................................................................................................................................ 43

10 Contents

Preparing Your Site for the System 11Chapter 1
Chapter 1
Preparing Your Site for the System
The following gives information to prepares your site for using the Agilent TS-5400 Series IIB System. This
chapter is separated as follows:
•Typical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 11
•The System Plan Drawing . . . . . . . . . . . . . . . . . . . . . . . page 12
•System Power Requirements . . . . . . . . . . . . . . . . . . . . . page 13
•Mains Wiring and Sizes . . . . . . . . . . . . . . . . . . . . . . . . . page 17
Typical System
The Agilent TS-5400 hardware provides the functionality to test control modules for automotive applications.
Figure1-1 shows a typical hardware configuration of a test systems, in a single 2.0 meter rack.
Figure 1-1. Typical Agilent TS-5400 System

12 Preparing Your Site for the System Chapter 1
The System Plan Drawing
Make a system plan drawing and use it for all aspects of the site preparation. A complete drawing details power
availability, communications cabling, and system placement with respect to other equipment. It can also serve to
verify physical access. Refer to Appendix A for specific site requirements (structural, environmental, etc.).
Figure1-2 shows a layout suggestion for a typical Agilent TS-5400 Series IIB System. Allow 1 meter (3 feet) of
space behind the system for service.
Figure 1-2. Recommended Agilent TS-5400 System Layout (overhead view)

Preparing Your Site for the System 13Chapter 1
System Power Requirements
This section describes the electrical power requirements of the Agilent TS-5400 Series IIB Test Systems using
the Agilent E1135C Power Distribution Units (PDUs). It also describes how to connect AC mains power to the
system. Figure1-3 shows the location of the power distribution unit in your system.
Minimum Power Requirements
The following lists the minimum power requirements for the TS-5400 systems (see “Site Configuration for AC
Power” on page 15" for more information).
The TS-5400 system requires the following:
1. AC mains power must be supplied to the system's Agilent E1135C Power Distribution Unit (PDU).
2. Customer must supply a power cord for all systems and power options.
Figure 1-3. Rear View of Agilent TS-5400 System
Agilent E1135C Power
Distribution Unit

14 Preparing Your Site for the System Chapter 1
3. The power cord must be wired by an electrician.
4. For the Agilent E1135C Power Distribution Unit, a jumper wire may need to be installed for some power
options.
Power Recommendations
•Provide a separate AC mains service for the system due to high current requirements of the system.
•Use copper wire for the System Drop between the AC source and system.
•The power service must have a mains disconnect installed adjacent to the system to quickly remove power
in case of emergency (see "Mains Disconnect Requirements" for more information). The Agilent E1135C
PDU, used with newer TS-5400 Systems, contains a mains disconnect.
•On the PDU is a 25.4-millimeter (1-inch) hole to install a cable clamp and power cord. Use a power cord
with a locking plug (one that cannot be easily pulled from its outlet) or hard-wire the system to the AC
power.
Caution Verify the AC source and that service conductors are sized correctly before
connecting the system.
Additional Power Information
•Conventional 50/60-hertz current probes can not make accurate input current measurements of the system's
power supplies due to the harmonics on the currents. A current measuring instrument needs a bandwidth
that is above 10 kHz. Improper instruments may yield results that are 50 percent less than actual.
•System input power connections on the PDU are made to an input connector block and the ground
connection to a terminal bolted to the chassis. In the E1135C PDU, the power is connected to the mains
disconnect switch and a ground terminal attached to the chassis. These connectors can accept wire up to
16-mm (4-AWG). For ease of installation, in areas where it meets local code requirements, use
multi-strand wire from a AC mains to the PDU.
Caution Ten thermally-activated circuit breakers designed to protect the output terminal
block are located on the front of the Agilent E1135B/C PDU. Under normal
operation, a detected fault sets the rocker on the breaker to the open position.
Reset the rocker by gently pushing it back in place. These breakers must not be
opened by force, or permanent damage can result. Damage caused by
intentionally opening the breaker is not covered by warranty.

Preparing Your Site for the System 15Chapter 1
Mains Disconnect Requirements
The Agilent 1135C PDU contains a lockable mains disconnect switch. If may also want to install an external
mains disconnect circuit breaker. Be sure the circuit breaker is adjacent to the equipment for easy access. Usual
mounting is an approved enclosure on a floor-mounted pedestal.
Disconnect Circuit Breaker Requirements
The disconnect circuit breaker must be:
•Rated for the maximum system amperes,
•Approved for use in building installations in your locality,
•Marked "Mains Disconnect" or the equivalent in your local language,
•Marked for the "Off" position,
•Capable of locking in the "Off" position, but not in the "On" position,
•Open all phases and neutral conductors, but not the safety grounding conductor.
Mains Circuit Breaker Requirements
Requirements for the mains circuit breaker are the same as the “Disconnect Circuit Breaker Requirements” above
plus the breaker must be rated a minimum 10,000 amperes interrupting capacity (AIC), for 100-240 V AC circuit,
or 14,000 AIC for higher voltage circuit.
Site Configuration for AC Power
The following information is not required, but may save time and effort implementing this configuration when
installing the system.
Note The following requires that you:
1. Use a wire, and not conduit for the safety ground conductor
2. Use the same size wire for the neutral and ground as is used for the phase conductors
3. Bond the neutral and the ground wires together at the transformer, and not at the breaker box
or anywhere else.
Use the following information to configure your site:
Tap into the main AC power source of the building consisting of 200, 208, 220, 230, 240 380, 400, 415 volts
AC. Connect the power through a one-to-one or step-down transformer to the correct voltage for the system.
Important recommendations about wiring:

16 Preparing Your Site for the System Chapter 1
•Make certain that the wire used for the neutral is the same size as the hot leads or larger.
•Do not rely on conduit for the ground; always use at least one wire for the ground-the more strands the
better.
•Use the same lengths of wire for the phase conductors, the neutral, and the ground.
•It is extremely important that the neutral and ground be connected only at the transformer using an X-O
bond.

Preparing Your Site for the System 17Chapter 1
Mains Wiring and Sizes
The AC mains wires and size depend on the type of system and the wire length from the AC power source to the
system. Table 1-1 to Table 1-7 lists the maximum required wire gauge needed according to length, the maximum
circuit breaker size, and the current requirements of the system according to options. Determine these sizes using
the system power option numbers.
Note The sizes given are for systems with the maximum number of instruments installed, including a
VXI Mainframe. For systems without a VXI Mainframe, subtract approximately 500W of
power. This comes to approximately 4.2 Amps of current for a line voltage of 120V and 2.4
Amps for a line voltage of 208V.
Table 1-1. Agilent TS-5400 System Power Options 05B, 05G 05K
Power Type
Power
Option Country
Phase
Voltage
Single-Phase Wye with Neutral 05B Brazil, China, Denmark, France, Germany,
Hong Kong, Italy, S. Korea, United Kingdom
220/380V
05G Finland, Germany, Singapore, United Kingdom 230/400V
05K Malaysia, United Kingdom 240/415V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 20 Amps 30 Amps / 2 Poles 6 (10) 4
23-30 (75-100) 20 Amps 30 Amps / 2 Poles 6 (10) 4
30-38 (100-125) 20 Amps 30 Amps / 2 Poles 6 (10) 4
38-46 (125-150) 20 Amps 30 Amps / 2 Poles 6 (10) 4
46-69 (150-225) 20 Amps 30 Amps / 2 Poles 10 ( 8) 4
69-76 (225-250) 20 Amps 30 Amps / 2 Poles 10 ( 8) 4
76-91 (250-300) 20 Amps 30 Amps / 2 Poles 16 ( 6) 4
L1
L2
N
G

18 Preparing Your Site for the System Chapter 1
Table 1-2. Agilent TS-5400 System Power Options 0ED, 05C, 05H, 0E6
Power Type
Power
Option Country
Phase
Voltage
Three-Phase Delta 0ED Japan 200V
05C Brazil, France, S. Korea, Philippines, Taiwan 220V
05H Brazil, France, Philippines 230V
0E6 United States 240V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 29 40 Amps / 3 Poles 10 (8) 4
23-30 (75-100) 29 40 Amps / 3 Poles 10 (8) 4
30-38 (100-125) 29 40 Amps / 3 Poles 10 (8) 4
38-46 (125-150) 29 40 Amps / 3 Poles 10 (8) 4
46-69 (150-225) 29 40 Amps / 3 Poles 16 (6) 4
69-76 (225-250) 29 40 Amps / 3 Poles 16 (6) 4
76-91 (250-300) 29 40 Amps / 3 Poles 16 (6) 4
* Includes Safety Grounding Conductor
Table 1-3. Agilent TS-5400 System Power Options 0EF, 05D
Power Type
Power
Option Country
Phase
Voltage*
Three-Phase Wye 0EF United States 208V
05D Brazil, France, Italy, Mexico, Philippines 220V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 29 40 Amps / 3 Poles 10 (8) 4
23-30 (75-100) 29 40 Amps / 3 Poles 10 (8) 4
30-38 (100-125) 29 40 Amps / 3 Poles 10 (8) 4
38-46 (125-150) 29 40 Amps / 3 Poles 10 (8) 4
46-69 (150-225) 29 40 Amps / 3 Poles 16 (6) 4
69-76 (225-250) 29 40 Amps / 3 Poles 16 (6) 4
76-91 (250-300) 29 40 Amps / 3 Poles 16 (6) 4
L3
L2
L1
G
3
2
L
G
L
L
1

Preparing Your Site for the System 19Chapter 1
Table 1-4. Agilent TS-5400 System Power Options 05M, 05F, 05J
Power Type
Power
Option Country
Phase
Voltage
Single-Phase Earthed 05M Brazil, China, Denmark, France, Germany,
Hong Kong, Italy, S. Korea, United Kingdom
220V
05F Finland, Germany, Philippines, Singapore,
United Kingdom
230V
05J Malaysia, United Kingdom 240V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 39 50 Amps / 1 Pole 10 (8) 3
23-30 (75-100) 39 50 Amps / 1 Pole 10 (8) 3
30-38 (100-125) 39 50 Amps / 1 Pole 10 (8) 3
38-46 (125-150) 39 50 Amps / 1 Pole 10 (8) 3
46-69 (150-225) 39 50 Amps / 1 Pole 16 (6) 3
69-76 (225-250) 39 50 Amps / 1 Pole 16 (6) 3
76-91 (250-300) 39 50 Amps / 1 Pole 16 (6) 3
* Includes Safety Grounding Conductor
Table 1-5. Agilent TS-5400 System Power Options AWX, 0EB, 0EJ, 0EC
Power Type
Power
Option Country
Phase
Voltage
Single-Phase, Non-Earthed AWX Japan 200V
0EB Brazil, France, Italy, Mexico, Philippines, S.
Korea, Taiwan
220V
0EJ Brazil, France, Philippines 230V
0EC United States 240V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 39 50 Amps / 2 Poles 10 (8) 3
23-30 (75-100) 39 50 Amps / 2 Poles 10 (8) 3
30-38 (100-125) 39 50 Amps / 2 Poles 10 (8) 3
38-46 (125-150) 39 50 Amps / 2 Poles 10 (8) 3
46-69 (150-225) 39 50 Amps / 2 Poles 16 (6) 3
69-76 (225-250) 39 50 Amps / 2 Poles 16 (6) 3
76-91 (250-300) 39 50 Amps / 2 Poles 16 (6) 3
L1
N
G
L1
N
G

20 Preparing Your Site for the System Chapter 1
Table 1-6. Agilent TS-5400 System Power Options AWV, AWZ
Power Type
Power
Option Country
Phase
Voltage
Single-Phase Wye with Neutral AWV United States 120V/208V
AWZ Brazil, France, Italy, Mexico, Philippines 127/220V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors**
0-23 (0-75) 39 50 Amps / 2 Poles 10 (8) 3
23-30 (75-100) 39 50 Amps / 2 Poles 10 (8) 3
30-38 (100-125) 39 50 Amps / 2 Poles 10 (8) 3
38-46 (125-150) 39 50 Amps / 2 Poles 10 (8) 3
46-69 (150-225) 39 50 Amps / 2 Poles 16 (6) 3
69-76 (225-250) 39 50 Amps / 2 Poles 16 (6) 3
76-91 (250-300) 39 50 Amps / 2 Poles 16 (6) 3
* Includes Safety Grounding Conductor
* * Includes Safety Grounding Conductor; neutral conductor is not required for the system
Table 1-7. Agilent TS-5400 System Power Options 0EA, 0EN
Power Type
Power
Option Country
Phase
Voltage
Single-Phase, Non-Earthed 0EA United States 120V
0EN Mexico 127V
Source to System Distance in
Meters (Feet)
Full Load
Amperes
Circuit Breaker
Amperes / # Poles
Wire Size
mm2(AWG)
Number of
Conductors*
0-23 (0-75) 47 50 Amps / 1 Pole 10 (8) 3
23-30 (75-100) 47 50 Amps / 1 Pole 10 (8) 3
30-38 (100-125) 47 50 Amps / 1 Pole 10 (8) 3
38-46 (125-150) 47 50 Amps / 1 Pole 10 (8) 3
46-69 (150-225) 47 50 Amps / 1 Pole 16 (6) 3
69-76 (225-250) 47 50 Amps / 1 Pole 16 (6) 3
76-91 (250-300) 47 50 Amps / 1 Pole 16 (6) 3
* Includes Safety Grounding Conductor
L1
L2
N
G
L1
N
G
