Agilent Technologies InfiniiVision 6000 Series User manual

Agilent Technologies
Agilent 6000 Series
Oscilloscopes
Service Guide

6000 Series Oscilloscopes Service Guide
Notices
© Agilent Technologies, Inc. 2005-2008
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation
into a foreign language) without prior agree-
ment and written consent from Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Manual Part Number
54684-97029, August 2008
54684-97001, February 2005
54684-97003, April 2005
54684-97008, January 2006
54684-97010, June 2006
54684-97014, November 2006
54684-97018, March 2007
54684-97021, April 2007
54684-97026, March 2008
Printed in Malaysia
Agilent Technologies, Inc.
1900 Garden of the Gods Road
Colorado Springs, CO 80907 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connec-
tion with the furnishing, use, or per-
formance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of a
U.S. Government prime contract or subcon-
tract, Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995),
or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer soft-
ware” as defined in FAR 52.227-19 (June
1987) or any equivalent agency regulation or
contract clause. Use, duplication or disclo-
sure of Software is subject to Agilent Tech-
nologies’ standard commercial license
terms, and non-DOD Departments and
Agencies of the U.S. Government will
receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will receive
no greater than Limited Rights as defined in
FAR 52.227-14 (June 1987) or DFAR
252.227-7015 (b)(2) (November 1995), as
applicable in any technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and
met.
A newer version of this manual
may be available at
www.agilent.com/find/6000
Microsoft ®is a U.S. registered trademark
of Microsoft Corporation.

6000 Series Oscilloscopes Service Guide 3
In This Service Guide
This book provides the service information for the Agilent 6000
Series Oscilloscopes. This manual is divided into these
chapters:
1Characteristics and Specifications
This chapter lists characteristics and specifications for the
Agilent 6000 Series Oscilloscopes.
2Testing P e r f orman c e
This chapter explains how to verify correct oscilloscope
operation and perform tests to ensure that the oscilloscope
meets the performance specifications.
3Calibrating and Adjusting
This chapter explains how to adjust the oscilloscope for
optimum operating performance.
4Troubleshooting
This chapter begins with suggestions for solving general
problems that you may encounter with the oscilloscope.
Procedures for troubleshooting the oscilloscope follow the
problem solving suggestions.
5Replacing 6000A Assemblies
This chapter describes how to remove assemblies from the
6000A Series oscilloscope.
6Replacing 6000L Assemblies
This chapter describes how to remove assemblies from the
6000L Series oscilloscope.
7Replaceable Parts
This chapter describes how to order replaceable assemblies and
parts for the Agilent 6000 Series Oscilloscopes. It includes
diagrams and parts lists for hardware that you can order.

46000 Series Oscilloscopes Service Guide
At the front of the book you will find safety notice descriptions
and document warranties.
Using this book with the 6000L Series oscilloscopes
The 6000L Series oscilloscopes do not have a built-in display or front panel
control keys. If you are using a 6000L Series oscilloscope, and this book refers to
using front panel controls, you can use the built-in Web control feature described
in the 6000 Series Oscilloscopes User’s Guide to complete the instructions. If you
do not have the 6000 Series Oscilloscopes User’s Guide, you may obtain a
printable electronic copy at www.agilent.com/find/6000manual.
Digital Channels
Because all of the oscilloscopes in the Agilent 6000 Series have analog channels,
the analog channel topics in this book apply to all instruments. Whenever a topic
discusses the digital channels, that information applies only to Mixed-Signal
Oscilloscope (MSO) models or DSO models that have been upgraded to an MSO.
Abbreviated instructions for pressing a series of keys
Instructions for pressing a series of keys are written in an abbreviated manner.
Instructions for pressing Key1, then pressing Key2, then pressing Key3 are
abbreviated as follows:
Press Key1 & Key2 & Key3.
The keys may be front panel keys, or softkeys, which are located directly below
the oscilloscope display.

6000 Series Oscilloscopes Service Guide 5
