Agogs Barack User manual

ELECTRIC BIKE USER GUIDE

AGOGS electric bikes
Producer:
ekolo.cz s.r.o.
Pod Višňovkou 1 664/29, 1 40 00 Praha 4 - Krč
Czech Republic
Service: +420 226 21 0 226
Email: servis@agogs.com
WWW: www.agogs.cz

Congratulations on your electric bike purchase!
AGOGS electric bikes come with high quality components all of which are carefully
adjusted and tested before distribution. To keep your bike in perfect condition please
read this brief guide.
Happy e-biking!
Version: BRCK1 71 1 .
Components and design may differ.
All rights reserved.
Declaration of conformity
This electric bicycle is compliant with the legislation and standards applicable to
electric bicycles within the EU:
1 . ISO 421 0-2 (Safety requirements for bicycles)
2. EN 1 51 94 (EPAC - Electrically Power Assisted Cycles)

Content
Important information .................................................................................................. 6
General disclaimers ................................................................................................... 8
Electric bike components ........................................................................................... 10
Specifications .............................................................................................................. 12
Before first ride ........................................................................................................... 14
Bike folding ................................................................................................................. 16
Ebike control................................................................................................................ 18
Riding the ebike ........................................................................................................... 20
Ebike running-up ......................................................................................................... 21
Battery care ................................................................................................................ 22
Battery charging .......................................................................................................... 23
Safety recommendations ............................................................................................ 25
Brakes ......................................................................................................................... 26
Tires ............................................................................................................................ 28
Rear derailleur ........................................................................................................... 29
Saddle ......................................................................................................................... 30
Front suspension fork ................................................................................................ 31
Adjustable stem ........................................................................................................... 31

Cleaning and lubrication ............................................................................................ 32
Long-term storage ..................................................................................................... 32
Operating range .......................................................................................................... 33
Lighting and safety ..................................................................................................... 33
Riding in wet conditions ............................................................................................. 34
Parking the bike ......................................................................................................... 34
Returning the battery / Recycling .............................................................................. 35
Rear wheel tube replacement .................................................................................... 36
Rear wheel demount .................................................................................................. 36
Tube replacement ....................................................................................................... 38
Rear wheel mount ...................................................................................................... 40
Warranty ..................................................................................................................... 42
Service records ........................................................................................................... 44
Certificate of warranty ................................................................................................ 45

Important information
Read this guide carefully. If there is anything you do not understand completely
please contact your dealer.
Do not lend your bicycle to anyone who is unfamiliar with it. Defects caused by
inappropriate use are not be covered by warranty.
The bicycle can only legally be used on the road by a person aged 1 5 years or
older.
We strongly advise you to always wear a cycle helmet when using your bicycle
and if you are unfamiliar with cycling to attend a cycle proficiency course prior to
using it . Your electric bicycle is not a toy and should be considered a serious
mode of transport.
As with all bicycles it is important that you stay within safe limits, if you feel as if
you are travelling too quickly for the road conditions you probably are so slow
down.
Test your brakes prior to using the bike every time you use it and remember the
bike will not stop as quickly in wet or icy conditions as it would on a dry road.
NEVER drink alcohol and ride your electric bike. The use of alcohol greatly

reduces reflexes and limits your ability to ride safely. Even a very small amount of
alcohol will limit your ability to be safe on the road.
Frequent braking and accelerating, riding into the wind and long uphill rides
consume more energy from the battery, thus reducing the distance you can
travel.
Rain free days when the outdoor temperature is over 1 0°C are good conditions to
ride in. It is not recommended to ride the bike when the outdoor temperature is
below 0°C.
During long periods of storage and non-use keep your battery at least 70% full
and top up with charge every 5 to 8 weeks. When in storage keep your battery in a
dry room where the temperature is about 1 5°C.
IMPORTANT! Do not attempt to open the casings of the battery, motor or
controller! It could be dangerous and all warranties will become void. If you
experience a problem contact our service department or your retailer.
ONLY use the charger supplied with your battery or a correct model
replacement from AGOGS. AGOGS is not responsible for damage caused by
using a non-compatible charger.

General disclaimers
ekolo.cz s.r.o. shall not be responsible for any damage of any kind, including time
lost, money lost, difficulties and complications that can arise from:
electric bike misuse
infringement of the instructions listed in user guide
infringement of the traffic regulations and laws valid in country of use
rider's failure
using the bike in way other than it has been produced for
cause of external origin

ekolo.cz states to the owner of this electric bike that its use involves risks and
hazards and the owner agrees to assume these risks in full, regardless of their
nature. The owner agrees to take full responsibility for any damage of any kind
related to the electric bike use.
The owner waives all claims against ekolo.cz for compensation in the event of
possible loss, theft, damage or injury of any kind that may incur in the context of
using this electric bike. Defects of the product are covered by the full guarantee
period of 24 months.
We recommend you to insure your electric bike.

Electric bike components

1 display
2 BOOST button
3 battery
4 rear hub motor
5 controller
6 PAS sensor
7 battery charge connector
8 motor connector
9 folding hinges
1 0 adjustable stem
1 1 suspension fork
1 2 suspension seatpost
1 3 saddle
1 4 seatpost clamp
1 5 pedal
1 6 brake lever
1 7 front brake
1 8 rear brake
1 9 rear derailleur
20 shifter
21 freewheel
22 chain
23 front reflector
24 rear reflector
25 front fender
26 rear fender
27 rim
28 tire
29 spokes

Technical specifications
Dimensions and weight
Weight:
Maximum load:
Max. carrier load:
Length x height x width:
(folded)
Motor
Output power:
Torque:
Max. assisted speed:
Battery
Nominal voltage:
Maximum voltage:
Minimum voltage:
Capacity:
Weight:
1 9 kg (without battery)
1 1 0 kg including carrier load
25 kg
1 63 x 1 09 x 59 cm
(90 x 74 x 40 cm)
250 W
35 Nm
25 kph
36 V
42 V
32 V
1 1 Ah / 1 6 Ah
3.0 kg / 3.3 kg
Charger
Input:
Output:
1 00-240 VAC
50/60 Hz
42V/3A DC

Frame:
Rims:
Shifter:
Derailleur:
Brakes:
Front fork:
Handlebar:
Stem:
Seatpost:
Pedals:
Drivetrain:
Motor:
Battery:
Battery charger:
Aluminium 6061 .T6, folding
H C DP-24, double-wall, 20"
Shimano SL-M360, 8 speed
Shimano RD-3500-SS, 8 speed
V-Brakes Tektro C31 0 with sensor
Zoom 565 AMS, suspension, lock-out, preload adjust
Zoom, swept back 6°, width 580 mm
Promax, folding, high adjust
Kind Shock KSP525, 400 mm, suspension, preload adjust
Wellgo, folding
Pedal assistance system with BOOST button
Bafang SWXH, 36V/250W, brushless rear hub motor
Sony Li-Ion 36V/1 1 Ah or LG Li-Ion 36V/1 6Ah
MDA Modiary 36V/3A, charging time up to 6 hrs.
Do not overload bicycle or carrier! Carrier can not be used to transport
persons!

Before first ride
There are several keys attached which are related only to your battery. Choose
one of them which you will use and store the other one in case of damage or
loss.
Learn how to release/insert the battery. Release the seat post and saddle.
Unlock the battery bottom lock anticlockwise and release the key. Now you can
pull the battery smootly up. Be very careful when re-inserting the battery. The
slot must fit with the rail perfectly. If the battery won't go smoothly down, you are
doing something wrong. Try again. Lock the battery in frame. Do not leave the
key in lock, you could break it easily.
Battery lock ON/OFF switch / capacity
indicator

Check the state of battery charge. The battery has been formated before sale and
it is probably not completely charged so you will need to recharge it. Connect the
charger to your battery first then plug the charger into the mains. Red lamp on
the charger indicates the battery is charging, when the red light turns green the
battery is fully charged.
Adjust height of saddle. Your knee should be slightly bent when the pedal is in
the lowest position. When you stop you should be able to touch the ground with
both feet. It is important that the nut on the collar is tightened so the post will
not move in the seat post tube. Make this adjustment with the quick release lever
in the open position. Never raise the seat post above the mark of MINIMUM
INSERTION!
Adjust height of handle bar. It is important that the nut on the collar is tightened.
Do not raise the handle bar above the mark of MINIMUM INSERTION.
Check tire pressures. Acceptable limits are 2.8 – 4.5 bar.
Check front and rear brake operation.

Bike folding
Electric bicycle AGOGS Barack was designed as a folding bike for city use. Learn how
to fold your bike quickly and correctly.
4 steps to fold your bike
1 . Push both pedals towards the crank. They can be
folded through 90 degrees.
2. Lower the sear post as low as possible.

3. Release the folding hinge clamp at the base of the handlebar
stem and fold the handlebar downwards taky care not to strain
any of the control cables.
4. Release the folding hinge clamp located on the cross bar.
Swing the clamp around a vertical axis as much as possible
and fold the two halves of the bike together
To unfold the bike follow the reverse steps above
ensuring all quick release clamps are securely fastened
and no cables are trapped. Ensure that the stainless
spring cable protector is in place.

Ebike control
This ebike is equipped with display which
provides rider basic information during the
ride. Pedal assistance system is controlled by
display too.
Turn the battery on by ON/OFF button on its top
and then active the ebike electric system by a long
press M button.
After turning the display on the default shown is running speed and lowest
assistance level is set.
Press M to change the shown information in sequence as below: Running speed -
Battery capacity - Trip distance - Total distance - Battery capacity. After 2 seconds
display will turn back to Running speed automatically.

To clear Trip distance hold both the M button and - button for 2 seconds.
This ebike has 5 levels of assistance plus level 0
with no motor support. Each level as assistance
assists rider with a different motor power. Level
1 is the lowest assistance and level 5 is the
highest assistance.
There is a red boost button on left
handlebar. Use this button when you need
to accelerate rapidly. You can also use this
button independently of PAS up to 6 kph
(walk along mode).
Display will turn off automatically after 1 0 minutes of idle.

Riding the ebike
Learn how to ride your bike before your first trip. It is better to find a place with low
traffic for these purposes. Set assistance to level 1 . Start to pedal. You will feel motor
assistance in a moment. Test brake function and effectivity - as you press any of
brake levers motor turns off automatically. Repeat it untill you get used to bike
behavior. Increase assistance level step by step. Focus to feel bike mass compared to
normal bike. Try out the BOOST button.
When you want to go for a long trip, compare the trip distance with the bike operation
range first.
Table of contents
Other Agogs Scooter manuals
