AGP DM10 User manual

GB Diamond Core Drilling Machine Safety instructions 2
DDiamant-Kernbohrmaschine Sicherheitshinweise 24
FCarotteuse Au Diamant Instructions de sécurité 39
E
Perforadora Con Corona De Diamante Instrucciones de seguridad 54
ISistema Di Foratura Al Diamante Indicazioni per la sicurezza 69
NL Diamant boormotor Veiligheidsvoorschriften 84
(230V & 110V models)
3 Speed Models
DM9, DM10, DM12
For your personal safety, READ and
UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
ORIGINAL INSTRUCTIONS
4 Speed Model
DM14

TECHNICAL DATA
Model DM14 DM12 DM10 DM9
Voltage / Power 220-240V~ 50-60Hz :16A/3500W or 110-120V~ 50-60Hz : 25A /2800W (see nameplate)
No Load Speeds min-1 385 / 530 / 975 / 1340 350 / 600 / 1000 450 / 810 / 1300 550 / 1000 / 1600
Rated Load Speeds min-1 225/ 300 / 565 / 780 220 / 370 / 620 270 / 480 / 780 345 / 630 / 1000
Drilling Capacity Ø400mm (16") Ø350mm (14") Ø300mm (12") Ø250mm (10")
Dimensions 550mm x 155mm x 210mm
Gear Oil Type 90W
Gear Oil Capacity 625ml
SpindleThread 1-1/4" UNC male, 1/2" BSP female
Protection Class Class 1With RCD
Weight 13.5kg 12.9kg 12.9kg 12.9kg
DM14 DM12
3.
1.
2.
4.
9.
5.
7.
8.
230V models
8.
110V models
6.
10.
DM10 DM9
1. Spindle
2. Gear Box
3. Gear Selector(s)
4. Motor Unit
5. Tail Handle
6. Bull's Eye Level
7. Tubular Spirit Level
8. On/O Switch
9. Water Feed Valve
10. Anti-Sieze Ring
11. LED Indicator Light
(Load & Temperature)
11.
11.

3
GB
General Safety Rules
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock,  re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool”in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. WORK AREA SAFETY
a. Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of  ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
d. Never leave the electric power tool unattended. Only leave the machine when the tool in use has come
to a complete standstill.
2. ELECTRICAL SAFETY
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodi ed plugs and matching outlets will reduce risk of
electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. PERSONAL SAFETY
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the in uence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.

GB
4
c. Prevent unintentional starting. Ensure the switch is in the o-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your  nger on
the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dustrelated hazards.
h. Do not let familiarity gained from freuquent use of tools allow you to become complacent and
ignore, tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. POWER TOOL USE AND CARE
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and o. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may aect the power tool‘s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions taking into
account the working conditions and the work to be performed. Use of the power tool for operations
dierent from those intended could result in a hazardous situation.
h. Keep handles dry, clean and free of oil and grease. Slippery handles do not allow for safe handling and
control of the tool in unexpected situations.
5. SERVICE
a. Have your power tool serviced by a qualied repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
b. Only use original parts for repair and maintenance. The use of incompatible accessories or spare parts
can result in electric shocks or other injuries.

5
GB
Drill safety warnings
• Hold power tool by insulated gripping surfaces, when performing an operation where the cutting
accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live" and could give the operator an electric shock.
• Check the ground (earth) connection of the electrical plug.
• Never use the machine without a PRCD fault-current safety switch.
• Always check the PRCD fault-current safety switch for correct functioning before starting a drilling
operation.
• Ensure that no water is allowed to get into the motor unit during operation.
• If you detect a leak in any part of the water supply system, shut the machine down immediately
and repair the fault. Water pressure should not exceed 70 psi (4 bar).
• Take care not to damage gas, water, power and other conduits in the area of the drilling operation.
Drain or shut off these conduits as required.
• Block off the working area and place warning signs on both sides of the wall when drilling through
from one side to the other.
• Take appropriate precautions to ensure that, in the event of a drilling core dropping out, no
personal injury or material damage will result.
• When drilling hollow components, check the flow route of the cooling water in order to prevent
damage.
• WARNING: Pull the plug out of the socket before making device settings or changing accessories.
Symbols used in this manual
V…….........volts
A…….........amperes
Hz…….......hertz
W……........watt
~………....alternating current
n ………...rated speed
min-1….......revolutions or reciprocation
per minute
.........warning of general danger
.........with electrical earth
.......read these instructions
......always wear eye protection
......always wear a dust mask.
.....always wear hearing protection
.....wear safety-approved hard hat
do not dispose of electric tools,
accessories and packaging together
with household waste material

GB
6
Many accidents are caused by accidental starting of power tools.
• When mounting the stand, fix the base to a firm, level, surface or wall. The power tool cannot be
guided evenly and safely if the base can slip or shake.
• This diamond core drill cannot be used for overhead drilling unless special water control
equipment is used.
WARNING: Hazardous situation due to broken parts: Always check core bits before using. Deformed or
damaged drill core bits must not be used;
WARNING: Use of non-recommended cutting tools can lead to injuries due to the loss of control. Only
use drill core bits designed for this machine only. Follow the minimum and maximum diameter given on
the specifications page and do not exceed the length of the core bits beyond the maximum allowed by
the drill stand. (This is usually 24" or 750mm)
WARNING: Incorrect clamping and positioning of the drill core bit may lead to dangerous situations
by broken and ejected parts of the drill core bit. Core bits must be assembled correctly. Follow the
instructions below under "Fastening the Core Bit"
WARNING: It is necessary to always wear suitable personal protective equipment, including:
• Hearing protection, to reduce the risk of induced hearing loss,
• Gloves, when handling core bits or rough materials, to reduce injuries by sharp edges,
• Safety glasses, to prevent injuries by flying particles,
• Non-slipping footwear, to prevent injuries caused by slippery surfaces;
WARNING: A wrongly assembled machine may cause a hazardous situation. Follow the instructions
provided with the drill stand on how to fix the machine into the stand and fixing to the material to be
drilled; See also the instructions below under "Mounting to a Drilling Stand"
INTRODUCTION
This machine is for the intended purpose of diamond core drilling of concrete, masonry, stone and similar
materials. It must always be mounted on a drilling stand. This machine is for professional use only and only
trained personnel may operate this machine.
All other uses which are not for the intended purpose are prohibited.
It is equipped with a water feed system which is required for the diamond core drilling process. A PRCD
interrupter (portable residual current device) which must be used at
all times.
It is equipped with a three or a four speed mechanical gearbox for
different core drill size ranges and features a mechanical safety
clutch.
The motor has electronics for soft start, overload protection and
thermal (overheating) protection. There is a overload warning to
alert the operator of load and overload conditions.
The machine is equipped with spirit levels which aid in aligning the tool. Use the Tubular Level for horizontal
aligning. Use the Bull's Eye Level for vertical aligning.
Tubular Spirit Level
Bull's Eye Level

7
GB
Electrical connection
The network voltage must conform to the voltage indicated on the tool name plate.
Under no circumstances should the tool be used when the power supply cable is damaged. A damaged
cable must be replaced immediately by an authorized Customer Service Center. Do not try to repair the
damaged cable yourself. The use of damaged power cables can lead to an electric shock.
230V models:
WARNING: Always use the Portable Residual Current Device
(PRCD) also known as a Ground Fault Circuit Interrupter (GFCI).
Always use this device whenever using the machine to reduce
the risk of shock hazards. Always position the device PRCD
as close as possible to the power source. Test and reset the
PRCD device before each use. Press the“Test” button to test.
Press the“Reset”button to energize the circuit to the machine.
110V models:
WARNING: Always use a Residual Current Device (RCD) also known as a Ground Fault Circuit Interrupter
(GFCI). Use an RCD in a separate control box with one or more socket outlets in accordance with EN
60309-2 with the earthing contact position 1 h. Always use this device whenever using the machine to
reduce the risk of shock hazards.
WARNING! 110V UK machines are not equipped with a PRCD portable residual current device or GFCI
ground fault circuit interrupter. The machine must always be used with an isolating transformer for
protection in case an electrical fault should occur.
ASSEMBLY
Thread the water supply assy. Into the hole in the bottom of gearbox and tighten with a wrench.
LIST OF CONTENTS
• Diamond core drilling machine.
• Mounting spacer
• Water feed assembly
• Wrench
OPERATING INSTRUCTIONS
1) MOUNTING THE CORE BIT
CAUTION: Ensure that the threads of the spindle and the core bit match. Attempting to mount
mismatched threads will result in damage to both threads.
Test Button
Reset Button
On Lamp
230V models

GB
8
The spindle has two types of threads. The outside male thread is 1-1/4inch UNC, the inside female thread is 1/2
inch BSP. Ensure both the core bit and the machine spindle are clean. Any debris could cause excessive run-out
of the mounted core bit. Excessive run-out can cause premature failure of the core bit and/or a safety hazard.
Tighten the bit to the spindle using two wrenches. Torque to at least 200 newton meters
Choosing the correct core bit for the job:
Ensure that the bit you are using is suitable for the material you are drilling.
We recommend always using wet-type (sintered) bits with this machine.
2) WATER SUPPLY
Water is a basic requirement for diamond core drilling. The water serves as a
coolant to avoid the working surface at the tip of the bit from overheating.
Never use this machine without water feed.
To connect the water supply. Attach the quick-release water coupling to a
water hose.
WARNING: Check all connections of the water feed system to ensure there are no leaks. Inspect hoses
and other critical parts which could deteriorate.
WARNING: The maximum water pressure should not exceed 70 psi (4
bar).
CAUTION: There is a small indicator hole on the water feed collar. If this
hole leaks water, it indicates that the water seals are worn out. Replace
them immediately.
CAUTION: Never use this machine without water feed. Running dry will overheat and destroy its water
seals.
Use a water collector with a wet vacuum to collect cooling water if nearby objects could be damaged by water.
3) SELECTING SPEEDS
There are various ranges to suit the bit size and work piece hardness.
CAUTION: Never attempt to change gears on a running machine! Only adjust when the machine is
at rest.
For 3 speed models, Select the desired gear range by turning the gear selector either clockwise or
counterclockwise into the desired gear. It will usually be necessary to turn the spindle by hand a little to get it
to shift all the way.
For 4 speed models, turn the two gear selectors to the correct combination of A,B,C and D to reach the desired
speed range. (see the chart below).
Indicator Holes
Water Feed Valve
Open
Closed

9
GB
DM9 RECOMMENDED BIT Ø
Speed 1: n0550/min, n 345/min 152-250mm (6"-10")
Speed 2: n01000/min, n 630/min 102-152mm (4"- 6")
Speed 3: n01600/min, n 1000/min 40-102mm (1-1/4"- 4")
DM10 RECOMMENDED BIT Ø
Speed 1: n0450/min, n 280min 180-300mm (7"-12")
Speed 2: n0810/min, n 485/min 122-180mm (5"-7")
Speed 3: n01300/min, n 780/min 40-122mm (1-1/2" - 5")
DM12 RECOMMENDED BIT Ø
Speed 1: n0350/min, n 220/min 280-350mm (11"-14")
Speed 2: n0600/min, n 370/min 180-280mm (7"-11")
Speed 3: n01000/min, n 620/min 60-180mm (2"-7")
DM14 RECOMMENDED BIT Ø
Speed 1: AD n0385/min, n 225/min 300-400mm (12"-16")
Speed 2: AC n0530/min, n 300/min 180-300mm (7"-12")
Speed 3: BD n0975/min, n 565/min 122-180mm (5"-7")
Speed 4: BC n01340/min, n 780/min 40-122mm 1-1/2"-5")
( Recommended bit size based on average hardness concrete. Speeds will
vary with different material hardnesses.
For reinforced concrete, speeds will be signifigantly slower.)
4)MOUNTING TO A DRILLING STAND (NOT INCLUDED)
Warning: Do not attempt to mount to a rig that does not have a perfectly fitting mounting system.
The motor has a standard four bolt pattern for attaching a mounting spacer. Use a mounting spacer suitable for
the stand you are using to mount your drill motor to your stand. Tighten the four bolts evenly to 12Nm.
To mount to the stand, loosen the cradle lock bolt and place the mounting spacer squarely in the cradle. Then
tighten the cradle lock bolt firmly to 17Nm.
The rig may be anchored to the work piece in one of three ways, with a mechanical anchor, with a vacuum
base, or with a jack screw. (Follow the instructions provided with the rig.)
TO INSTALL THE DRILL STAND
1. Measure the distance from the center of the intended cut to the location of the mounting slot in the
base. Follow the concrete anchor manufacturer’s instructions to install. Using an appropriate tool such
as a rotary hammer, drill a correct sized hole to fit the anchor. Then drive in the anchor to below flush.
2. Move the base into position and screw in the anchor bolt, washer and nut, leaving it finger tight for the
moment.
3. Using the bubble level, adjust the four leveling bolts to achieve a good level positioning, then fully
tighten the center anchor bolt. The entire rig must be mounted solidly.
WARNING: Never attempt to drill unless the stand is fixed securely beyond any doubt.
Gear Selectors
3 SPEED MODELS
Gear Selector

GB
10
5) THE SWITCH
230V models:
This machine has a rocker switch. Press the switch to the on position to turn on.
Press the switch to the off position to turn off. If there is an interruption to the
power supply, the machine will restart when the power returns.
WARNING: Accidental starting hazard. Always ensure that the switch is in the
OFF position before plugging in.
WARNING: Whenever there is an interruption to the power supply, turn the switch to the OFF position to
avoid an accidental restart when power returns.
110V models:
This machine has a relay-type rocker switch. Press the switch to the on position
to turn on. Press the switch to the off position to turn off. Since this is a relay type
switch, if there is an interruption to the power supply, the machine will not restart
when the power returns. In this case first turn the switch to the off position then
back to the on position to restart.
HOLE STARTING FUNCTION
Whenever the motor is first switched on, for the first 4 seconds, it will run at 50% rotation speed. This is to aid in
starting the hole. After 4 seconds, it will increase to 100% rotation speed.
6) OVERLOAD PROTECTION AND OVERHEAT PROTECTION
Overload Warning System:
When the load approaches overload conditions, the LED indicator light will flash on and off.
Overload:
If the excessive load is sustained too long, the motor will shut down completely
and the LED indicator light will glow solid red. In this case, the motor must be first
shut off and then restarted.
Overheat Thermal Protection:
If the temperature of the motor gets too high, the thermal protection will shut
the motor down and the LED indicator light will glow solid red. The switch must be first shut off and then
restarted.
CAUTION: The motor will be damaged if it is repeatedly overloaded or overheated.
Always cool the motor by running at no load for a few minutes whenever it stops from either overheat or
overload.
On/O Switch
110V models
230V models
On/O Switch
LED Indicator Light

11
GB
7) SAFETY CLUTCH
This machine is equipped with a mechanical clutch to protect the operator and machine from excessive
torque forces. When the preset maximum torque level is reached, the clutch will slip.
After the clutch slips many times, it will become worn and slip at lower and lower torque levels.
When this happens, it must be serviced by an authorized service provider.
The recommended torque of the clutch nut is 21 Nm.
CAUTION: Always ease off the load immediately whenever the clutch slips. Do not allow the clutch to
continue slipping or it will wear out prematurely.
DRILLING INSTRUCTIONS
1. Press the“Reset”button on the PRCD interrupter device to energize the circuit to the machine. Then turn
the machine on.
2. Open the water valve slightly and very gently begin the cut. use very light feed pressure to prevent the
bit from wandering until the bit is fully penetrated into the cut.
3. Make adjustments to the water feed as needed. The water leaving the cut should be a solid colored
slurry with about the consistency of milk.
4. Once in the cut, use steady feed pressure .
5. When the bit is about to break through, reduce feed pressure .
WARNING: Always keep your face away from the machine.
ABOUT DIAMOND BITS
The diamond impregnated segments in a wet type (sintered) diamond core bit operate on a principle of
controlled erosion. The bond matrix holding the diamonds is continually worn away by abrasion with the
work piece, exposing the harder diamonds to stand proud from the bond matrix. Without adequate
water, the bit would overheat and be destroyed.
With too much water and not enough feed pressure, there would not be adequate erosion of the bond
matrix and the bit becomes dull. This is called glazing . If the bit seems to refuse to cut anymore, it is
glazed.
See below: ”SHARPENING A GLAZED BIT ”
Don’t feed too gently or the diamond segments will become glazed. Keep the bit steadily working. If the
cut is very deep, the core plug may be obstructing the flow of cooling water. In this case, stop drilling, and
chisel out the core plug before continuing.
CAUTION: If the bit gets stuck, do not try to rock it loose by turning the switch on and off. That is
hazardous and could damage the motor. Rather, unplug the machine and use a wrench on the bit
mounting to work it loose.
If embedded steel such as rebar is encountered take special care. Reduce the feed pressure by about 1/3
and let the bit go at its own pace, if there is too much vibration the bit will be destroyed.
Once the steel is passed, continue normally.

GB
12
CAUTION: Drilling operations are very stressful to the motor and at the end of the cut, the motor
temperature will be very hot, always run the motor at no load the temperature returns to a normal
range before shutting off.
RESHARPENING A GLAZED BIT
If the bit becomes glazed, resharpen is by dressing with an appropriate alumina oxide or silicon carbide
dressing stone. Simply drill into the stone as many times as necessary to restore its cutting performance.
VIBRATION TROUBLESHOOTING
If vibration occurs and it is not caused by embedded steel, stop drilling to find the cause and remedy.
CAUTION: Do not operate with vibration or there will be serious hazard and the diamond core bit
will surely be destroyed.
Vibration is usually caused by:
1. A bit with too much runout
SOLUTION: Replace bit.
2. A bit with diamond segments broken off
SOLUTION: Replace bit.
3. Shifted base or loose gibs
SOLUTION: Retighten mountings or adjust gibs as needed.
MAINTENANCE
Every 50 hours of operation blow compressed air through the motor while running at no load to clean out
accumulated dust. Always check for a damaged power supply cable, check for loose fasteners and always
keep alert for unusual noises and vibration when operating.
WARNING: Never operate a damaged machine. Always tag a damaged machine and take it out of
service until repairs can be made.
CAUTION: This machine is equipped with an oil bath gearbox. To avoid leakage of lubricating oil,
whenever the gearbox is opened, the o-ring seal must be replaced with a new one.
CAUTION: If the gear oil is found to be leaking out, have the machine repaired by a qualified service
center immediately. Running without sufficient oil will lead to certain damage of the gearbox.
Maintenance which should be performed by an authorized service center, include the following:
• Replace water seals as needed.
• Replace the carbon brushes as needed
• Change the gear oil about every 100 hours of operation
• Replace the clutch discs and spring as needed.

13
GB
THE CARBON BRUSHES
The carbon brushes are a normal wearing part and must be replaced when they reach their wear limit. This
machine is equipped with auto-stop carbon brushes. If the machine comes to a stop unexpectedly, the brushes
should be checked. The auto-stop brush design protects the motor by stopping the machine before the carbon
brushes are completely worn out.
Caution: Always replace the brushes as a pair.
To replace:
1. Remove the 4 screws and remove the motor tail cover.
2. Using pliers rotate the brush spring out of the way and slide the old carbon brush out of the brush
holder.
3. Unscrew the screw to remove the brush lead. The old carbon brush may now be lifted away.
4. Install a new brush. Installation is the reverse of removal.
5. Replace the motor tail cover. Take care not to pinch any wires when reassembling.
If the replacement of the power supply cord is necessary, this has to be done by the manufacturer or
their agent in order to avoid a safety hazard.
WARNING: All repairs must be entrusted to an authorized service center. Incorrectly performed repairs
could lead to injury or death.
Do not throw electric power tools into the household waste! In accordance with the European Directive
2002/96/EG on Waste Electrical and Electronic Equipment and transposition into national law, used electric
power tools must be collected separately and recycled in an environmentally friendly manner.

GB
14
Exploded View DM14
NO.01~108 A1 Version 1.5
23
17
14
16
14
69
70
71
26
61
58
57
55
56
55
67
47
46
48
49
50
51
100
46 45
54
30
29 28
31
32
27
13
72
75
76
107
76 83
82 80
81
80
79
78
19
22 21
12
05
34
33
20
18
04
24
24
41
43
44
36 35
42
38
38
44
15
88
59
25
94
10 11
12
96
08
95
98
99
98
99
97
102
73
105 106
02
03
01B
01A
62
62
104
103
97
A1
Optional
108

15
GB
Parts List DM14
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR 1
4 EXTERNAL STARWASHER M4 1
5 PANHEAD MACHINE SCREW M4 x 10 1
6~7 N/A -
8 SWITCH 1
9 N/A -
10 PANHEAD TAPPING SCREW M4 x 25 4
11 COVER (220V) 1
12 PANHEAD MACHINE SCREW M4 x 12 6
13 ELECTRONICS UNIT 1
14 SOCKET CAP SCREW M5 x 25 6
15 FLAT WASHER Ø5 x Ø12 x 1 2
16 TOP HANDLE 1
17 MOTOR END CASTING 1
18 BRUSH SPRING 2
19 NYLOCK NUT M5 x 8 2
20 PANHEAD MACHINE SCREW M4 x 6 2
21 CARBON BRUSH 7x17x19 2
22 BRUSH HOLDER PLATE ASSY. 1
23 MOTOR HOUSING 1
24 SOCKET CAP SCREW M6 x 75 4
25 MOTOR INSULATION SLEEVE 1
26 STATOR 1
27 PANHEAD MACHINE SCREW M5 x 110 2
28 FAN SHROUD 1
29 BALL BEARING 6200-LLU 1
30 ARMATURE M1.25 x 7T 1
31 BALL BEARING 6202-2NSE 1
32 OIL SEAL Ø14 x Ø25 x 7 1
33 GEAR PLATE 1
34 GASKET 1
35 NEEDLE BEARING TLA 0810 1
36 CLUTCH NUT M12 x P1.75 x 9 1
37 N/A -
38 PRESSURE DISC Ø16 x Ø34.8 x 2.5 2
39~40 N/A -
41 INPUT GEAR M1.25 x 44T 1
42 BUSHING Ø15.9 x Ø22 x 4.9 1
43 INPUT SHAFT M1.75 x 13T ; M1.5 x 12T 1
44 BALL BEARING 6200 ZZ 2
45 NEEDLE BEARING TLA 1010 1
46 INTERNAL CIRCLIP IS-18 2
47 SLIDER GEAR-CD M1.75 x 36T 1
48 LAY GEAR M1.5 x 46T 1
49 COUNTERSHAFT GEAR M2.0 x 26T 1
50 PARALLEL KEY 5 x 5 x 25 1
51 PARALLEL KEY 6 x 6 x 15 1
NO. Parts Name Q'TY
52 N/A -
53 N/A -
54 NEEDLE BEARINGTA1815 1
55 INTERNAL CIRCLIP IS-25 2
56 SLIDER GEAR-AB M2.0 x 28T 1
57 OUTPUT GEAR M2.0 x 40T 1
58 CLUTCH NUT M27 x P1.0 x 7.8 1
59 THRUST BEARING Ø30 x Ø47 x 2 1
60 N/A -
61 GEAR HOUSING 1
62 SOCKET CAP SCREW M5 x 12 2
63~66 N/A -
67 O-RING Ø3 x Ø20 x Ø26 2
68 N/A -
69 NEEDLE BEARING TAF304020 1
70 THRUST BEARING 51106 1
71 OIL SEAL Ø40 x Ø50 x 7 1
72 WATER FEED COLLAR 1
73 WATER FEED CONNECTOR KIT 1
74 N/A -
75 SOCKET CAP SCREW M5 x 40 3
76 OIL SEAL Ø40 x Ø52 x 7 2
77 N/A -
78 DOWEL PIN Ø4 x 11.8 2
79 ANTI-SEIZE CUP 1
80 O-RING Ø1.5 x Ø32 x Ø35 2
81 THRUST RING Ø32 x Ø52 x 1 1
82 ANTI-SEIZE RING 1
83 O-RING Ø1.5 x Ø49 x Ø52 1
84~87 N/A -
88 TERMINAL CONNECTOR BLOCK PA-10-H 24A 2
89~93 N/A -
94 CLUTCH DISC SET 1
95 GASKET 1
96 SWITCH BOOT 1
97 GEAR SELECTOR 2
98 SPRING Ø0.6 x Ø3.8 x Ø5 x 11T x 35L 2
99 RELEASE PIN 2
100 COUNTERSHAFT SET 1
101 N/A -
102 BULLS-EYE LEVEL 1
103 SELECTOR DISC 1
104 SELECTOR DISC 1
105 LED OVERLOAD LAMP Ø10 110V&220V 1
106 LAMP COVER 1
107 SPINDLE SET 1-1/4"-7 x 1/2"BSP-300.5MM 1
108 STAINLESS BUSHING Ø38xØ40x41 1
A1 EXTENSION SPACER 1
GEAR OIL 625cc 1

GB
16
Exploded View DM12
NO.01~101 A1 Version 1.6
23
17
14
16
65
66
67
59
55
56
60
63
47
49
48
50
51
46
45
54
13
68
71
72
72 80
79 77
78 77
76 75
69
19
22 21
12
05
34
33
20
18
04
24
24
41
43
44
87
36 35
42
38
38
74
44
95
14
15
57
26
30
29 28
31
32
27
10 11
25
12
88
81
90
91
08
49
89
92
93
94
96
97 98
99
02
03
01B
01A
A1
Optional
101
100

17
GB
Parts List DM12
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR 1
4 EXTERNAL STARWASHER M4 1
5 PANHEAD MACHINE SCREW M4 x 10 1
6 N/A -
7 N/A -
8 SWITCH 1
9 N/A -
10 PANHEAD TAPPING SCREW M4 x 25 4
11 COVER (220V) 1
12 PANHEAD MACHINE SCREW M4 x 12 6
13 ELECTRONICS UNIT 1
14 SOCKET CAP SCREW M5 x 25 6
15 FLAT WASHER Ø5 x Ø12 x 1 2
16 TOP HANDLE Ø5 1
17 MOTOR END CASTING 1
18 BRUSH SPRING 2
19 NYLOCK NUT M5 x 8 2
20 PANHEAD MACHINE SCREW M4 x 6 2
21 CARBON BRUSH 7x17x19 2
22 BRUSH HOLDER PLATE ASSY. 1
23 MOTOR HOUSING 1
24 SOCKET CAP SCREW M6 x 75 4
25 MOTOR INSULATION SLEEVE 1
26 STATOR 1
27 PANHEAD MACHINE SCREW M5 x 110 2
28 FAN SHROUD 1
29 BALL BEARING 6200-LLU 1
30 ARMATURE M1.25 x 7T 1
31 BALL BEARING 6202-2NSE 1
32 OIL SEAL Ø14 x Ø25 x 7 1
33 GEAR PLATE 1
34 GASKET 1
35 NEEDLE BEARING TLA 0810 1
36 CLUTCH NUT M12 x 9 1
37 N/A -
38 PRESSURE DISC Ø16 x Ø34.8 x 2.5 2
39~40 N/A -
41 INPUT GEAR M1.25 x 44T 1
42 BUSHING Ø15.9 x Ø22 x 4.9 1
43 INPUT SHAFT M1.5 x 27T x 20T x 13T 1
44 BALL BEARING 6200 ZZ 2
45 NEEDLE BEARING TLA 1010 1
46 INTERNAL CIRCLIP IS-14 1
47 COUNTERSHAFT SET 1
48 SPINDLE GEAR M1.5 x 38T 1
49 INTERNAL CIRCLIP IS-18 2
50 LAY GEAR M1.5 x 45T 1
NO. Parts Name Q'TY
51 PARALLEL KEY 5 x 5 x 40 1
52 N/A -
53 N/A -
54 NEEDLE BEARING TA1815 1
55 NYLOOK NUT M20 x P1.5 1
56 OUTPUT GEAR M2.0 x 41T 1
57 THRUST BEARING Ø30 x Ø47 x 2 1
58 N/A -
59 GEAR HOUSING 1
60 SOCKET CAP SCREW M5 x 12 1
61~62 N/A -
63 O-RING Ø3 x Ø20 x Ø26 1
64 N/A -
65 NEEDLE BEARING TAF304020 1
66 THRUST BEARING 51106 1
67 OIL SEAL Ø40 x Ø50 x 7 1
68 WATER FEED COLLAR 1
69 WATER FEED CONNECTOR KIT 1
70 N/A -
71 SOCKET CAP SCREW M5 x 40 3
72 OIL SEAL Ø40 x Ø52 x 7 2
73 N/A -
74 PARALLEL KEY 6 x 6 x 25 1
75 DOWEL PIN Ø4 x 11.8 2
76 ANTI-SEIZE CUP 1
77 O-RING Ø1.5 x Ø32 x Ø35 2
78 THRUST RING Ø32 x Ø52 x 1 1
79 ANTI-SEIZE RING 1
80 O-RING Ø1.5 x Ø49 x Ø52 1
81 TERMINAL CONNECTOR BLOCK PA-12-H 2
82~86 N/A -
87 CLUTCH DISC SET 1
88 PARALLEL KEY 4 x 4 x 30 1
89 OIL IMPELLER 1
90 GASKET 1
91 SWITCH BOOT 1
92 GEAR SELECTOR 1
93 SPRING Ø0.6 x Ø3.8 x Ø5 x 11T x 35L 1
94 RELEASE PIN 1
95 COUNTERSHAFT SET 1
96 BULLS-EYE LEVEL 1
97 SELECTOR DISC 1
98 LED OVERLOAD LAMP Ø10(110V&220V) 1
99 LAMP COVER 1
100 SPINDLE 1-1/4"-7xPS1/2"-296.5MM 1
101 STAINLESS BUSHING Ø38xØ40x41 1
A1 EXTENSION SPACER 1
GEAR OIL SHELL SPIRAX A80/90 625cc 1

GB
18
Exploded View DM10
NO.01~101 A1 Version 1.6
23
17
14
16
65
66
67
59
55
56
60
63
47
49
48
50
51
46
45
54
13
68
71
72
72 80
79 77
78 77
76 75
19
22 21
12
05
34
33
20
18
04
24
24
41
43
44
87
36 35
42
38
38
74
44
95
14
15
57
26
30
29 28
31
32
27
10 11
25
12
88
81
90
91
08
49
89
92
93
94
96
97
69
98 99
02
03
01B
01A
100
101
100

19
GB
NO. Parts Name Q'TY
51 PARALLEL KEY 5 x 5 x 40 1
52~53 N/A -
54 NEEDLE BEARING TA1815 1
55 NYLOOK NUT M20 x P1.5 1
56 OUTPUT GEAR M2.0 x 39T 1
57 THRUST BEARING Ø30 x Ø47 x 2 1
58 N/A -
59 GEAR HOUSING 1
60 SOCKET CAP SCREW M5 x 12 1
61~62 N/A -
63 O-RING Ø3 x Ø20 x Ø26 1
64 N/A -
65 NEEDLE BEARING TAF304020 1
66 THRUST BEARING 51106 1
67 OIL SEAL Ø40 x Ø50 x 7 1
68 WATER FEED COLLAR 1
69 WATER FEED CONNECTOR KIT 1
70 N/A -
71 SOCKET CAP SCREW M5 x 40 3
72 OIL SEAL Ø40 x Ø52 x 7 2
73 N/A 1
74 PARALLEL KEY 6 x 6 x 25 1
75 DOWEL PIN Ø4 x 11.8 2
76 ANTI-SEIZE CUP 1
77 O-RING Ø1.5 x Ø32 x Ø35 2
78 THRUST RING Ø32 x Ø52 x 1 1
79 ANTI-SEIZE RING 1
80 O-RING Ø1.5 x Ø49 x Ø52 1
81 TERMINAL CONNECTOR BLOCK (PA-10-H)(24A) 2
82~86 N/A -
87 CLUTCH DISC SET 1
88 PARALLEL KEY 4 x 4 x 30 1
89 OIL IMPELLER 1
90 GASKET 1
91 SWITCH BOOT 1
92 GEAR SELECTOR 1
93 SPRING Ø0.6 x Ø3.8 x Ø5 x 11T x 35L 1
94 RELEASE PIN 1
95 COUNTERSHAFT SET 1
96 BULLS-EYE LEVEL 1
97 SELECTOR DISC 1
98 LED OVERLOAD LAMP Ø10(110V&220V) 1
99 LAMP COVER 1
100 SPINDLE 1-1/4"-7xPS1/2"-296.5MM 1
101 STAINLESS BUSHING Ø38xØ40x41 1
A1 EXTENSION SPACER 1
GEAR OIL SHELL SPIRAX A80/90 - 625cc 1
Parts List DM10
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR 1
4 EXTERNAL STARWASHER M4 1
5 PANHEAD MACHINE SCREW M4 x 10 1
6~7 N/A -
8 SWITCH BOOT 1
9 N/A -
10 PANHEADTAPPING SCREW M4 x 25 4
11 COVER (220V) 1
12 PANHEAD MACHINE SCREW M4 x 12 6
13 ELECTRONICS UNIT 1
14 SOCKET CAP SCREW M5 x 25 6
15 FLATWASHER Ø5 x Ø12 x 1 2
16 TOP HANDLE Ø5 1
17 MOTOR END CASTING 1
18 BRUSH SPRING 2
19 NYLOCK NUT M5 x 8 2
20 PANHEAD MACHINE SCREW M4 x 6 2
21 CARBON BRUSH 7x17x19 2
22 BRUSH HOLDER PLATE ASSY. 1
23 MOTOR HOUSING 1
24 SOCKET CAP SCREW M6 x 75 4
25 MOTOR INSULATION SLEEVE 1
26 STATOR 1
27 PANHEAD MACHINE SCREW M5 x 110 2
28 FAN SHROUD 1
29 BALL BEARING 6200-LLU 1
30 ARMATURE M1.25 x 7T 1
31 BALL BEARING 6202-2NSE 1
32 OIL SEAL Ø14 x Ø25 x 7 1
33 GEAR PLATE ( 1
34 GASKET 1
35 NEEDLE BEARING TLA 0810 1
36 CLUTCH NUT M12 x P1.75 x 9 1
37 N/A -
38 PRESSURE DISC Ø16 x Ø34.8 x 2.5 2
39~40 N/A -
41 INPUT GEAR M1.25 x 44T 1
42 BUSHING Ø15.9 x Ø22 x 4.9 1
43 INPUT SHAFT M1.5 x 27T x 20T x 13T 1
44 BALL BEARING 6200 ZZ 2
45 NEEDLE BEARING TLA 1010 1
46 INTERNAL CIRCLIP IS-14 1
47 COUNTERSHAFT SET 1
48 SPINDLE GEAR M1.5 x 38T 1
49 INTERNAL CIRCLIP IS-18 2
50 LAY GEAR M1.5 x 45T 1

GB
20
Exploded View DM9
NO.01~101 A1 Version 1.6
23
17
14
16
65
66
67
59
55
56
60
63
47
49
48
50
51
46
45
54
13
68
71
72
72 80
79 77
78 77
76 75
69
19
22 21
12
05
34
33
20
18
04
24
24
41
43
44
87
36 35
42
38
38
74
44
95
14
15
57
26
30
29 28
31
32
27
10 11
25
12
88
81
90
91
08
49
89
92
93
94
96
97 98
99
02
03
01B
01A
A1
Optional
100
101
