Agrimate AM22-NT User manual

USER MANUAL
DESCLAIMER : DUE TO CONTANT UPGRADATION FEATURES & SPECIFICATIONS ARE SELECT TO CHANGE
WITHOUT NOTICE . BEFORE OPERATING THIS MACHIN PLEASE READ THE INSTRUCTIONS MANUAL CAREFULLY
HTP POWER SPRAYER
AM22-NT

OPERATION INSTRUCTION
1. Check every fasteners and make sure that the sprayer and the motor are installed rmly on the frame.
2. Set the two pullies in a straight-line, and the belt in an appropriate ghtness
3. Every joint of the hoses must be ghtened to prevent from leaking
4. Before starng the motor, shut o the (43) cook(valve) loose the (56) pressure adjusng screw and pull the (59) pressure
adjuster to the top.
5. Start the motor to power the sprayer, keep a proper revoluon, press the (59) pressure
adjuster to the boom. Keep the pressure around 21-35Kgs by adjusng the (56) pressure adjusng screw
6. Open the (43) cock valve to start spraying
7. Alter the spraying is over. Pul the (59) pressure adjuster to the top and operate the sprayer with fresh water to clean out
the remaining chemicals.

PUMP LUBRICATIONS
1. Replace the engine oil aer the sprayer has been used for the rst 10
hours, 50 hours, and then
every 100 hours.
2. Drain away the dirty engine oil by screwing o the (5) drain plug
3. Aer the (5) drain plug is screwed on, remove the (9) oil inlet cover
and to ll new engine oil
grade #30-40
4. Keep the oil level at 2/3 of the (4) oil glass
5. Always ll the (31) grease cups 2-3 cycles every 4 hours of spraying.
AM-22 HTP Power Sprayer
Used for Spraying Irrigaon
Revoluon / RPM 800 1200
Pressure / kg /cm2 21-35 10
Sucon Volume / L / min 14 22
Power Required / KW 1.5-2.2 1.5-2.2
Imported & Marketed by
Ratnagiri Impex Pvt. Ltd., Bangalore

TROUBLE SHOOTING
1. Feeding failure & pressure instability
2. Check whether the (54) sucon hose is leaking or is stuck
3. Open the (43) cock (valve) to release the surous air
4. Remove the (39) sucon chamber and the (41.44AB) water outlet chamber check if the (33)
valve assembly are stuck of damaged.
5. Pressure insuciency
6. Check whether the pressure has been adjusted properly.
(Refer to the operaon instrucon No.5)
7. Check whether the belt is too loose
8. Check whether the spray hose and the couplings are broken and damaged.
CYLINDER LEAKAGE
1. Remove the (8) dust proof cover and wind up the (25) adjusng rings.
2. It sll in vain replace the (2.8) v-packing in the (30) cylinder
Remark ( ) indicates the ‘part number’ of relave art

Spare parts Diagram of AM22-NT HTP Power Sprayer

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
1AM-22 - 1 Crank Case 17 AM-22 - 17 Bearing
2AM-22 - 2 Gasket Crank Case 18 AM-22 - 18 Oil Seal crank Sha
3AM-22 - 3 Cover Crank Case 19 AM-22 - 19 Bolt
4AM-22 - 4 Oil Gauge 20 AM-22 - 20 Key
5 AM-22 - 5 Plug Drain 21 AM-22 - 21 Pulley
6 AM-22 - 6 O Ring 22 AM-22 - 22 Bolt
7AM-22 - 7 Screw 23 AM-22 - 23 Oil Seal Plunger
8 AM-22 - 8 Plunger Cover 24 AM-22 - 24 Stopping Ring Water
9 AM-22 - 9 Plug 25 AM-22 - 25 Grand
10 AM-22 - 10 Red Crank Case 26 AM-22 - 26 Crease Seal
11 AM-22 - 11 Bolt Washer spring 27 AM-22 - 27 Crease Ring
12 AM-22 - 12 Crank Sha 28 AM-22 - 28 V. Packing
13 AM-22 - 13 Connecng Rod 29 AM-22 - 29 V Packing Seat
14 AM-22 - 14 Bolt Washer spring 30 AM-22 - 30 Cylinder
15 AM-22 - 15 Plunger Pin 31 AM-22 - 31 Grease Cup
16 AM-22 - 16 Plunger 32 AM-22 - 32 Bolt Washer spring

SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION
33 AM-22 - 33 Valve Assy 54 AM-22 - 54 P.V.C.Hose
34 AM-22 - 34 Valve Box 55 AM-22 - 55 Strainer Assy
35 AM-22 - 35 Valve Spring 56 AM-22 - 56 Screw
36 AM-22 - 36 Valve Flat 57 AM-22 - 57 Fly Nut
37 AM-22 - 37 Valve Seat 58 AM-22 - 58 Spring Box
38 AM-22 - 38 Valve Seal 59 AM-22 - 59 Knob Control
39 AM-22 - 39 Sucon Metal 60 AM-22 - 60 Pin
40 AM-22 - 40 Bolt Washer Spring 61 AM-22 - 61 Bolt Washer Spring
41 AM-22 - 41 Discharge Metal 62 AM-22 - 62 Spring
42 AM-22 - 42 Bolt Washer spring 63 AM-22 - 63 Upper Metal
43 AM-22 - 43 Cock 64 AM-22 - 64 Packing
44 AM-22 - 44 Air Chamber 65 AM-22 - 65 Oil seal
45 AM-22 - 45 Pressure Gauge 66 AM-22 - 66 Body Over Flow
46 AM-22 - 46 Bolt Washer Spring 67 AM-22 - 67 Spindle
47 AM-22 - 47 O-Ring 68 AM-22 - 68 Valve
48 AM-22 - 48 O-Ring 69 AM-22 - 69 O-Ring
49 AM-22 - 49 Packing 70 AM-22 - 70 Valve Seat
50 AM-22 - 50 Core Coupling 71 AM-22 - 71 Bolt Washer spring
51 AM-22 - 51 Coupling 72 AM-22 - 72 Cover Oil Seal
52 AM-22 - 52 P.V.C.Hose 73 AM-22 - 72 Cover Oil Seal
53 AM-22 - 53 Core Strainer

INSPECTION & MAINTENANCE
For safety use, make sure the machine is cleaned every three-months. Before working, make sure
to inspect the lter and the nozzle,and ensure there is no impurity. Aer working, make sure there
is no water in the pump and the hose.
If the machine needs to be repaired in the guarantee period, please return the machine to the
shop. You need to provide the cercate of purchase in order to repair or get the substute.
Before Packing, the machine should be cleaned, then use closed packaging, packaging should be
rm. Store the machine in dry place.
For transportaon safety. The machine should comply with ISTA.
Meaning of crossed - out wheeled dustbin:
Do not dispose of electrical machines as unsorted municipal waste, use separate collecon
facilies.
If electrical machines are disposed of in landlls or dumps, hazardous substances can leak into
the groundwater and get into the food chain, damaging your health and well-being.
When replacing old machines with new ones, the retailer is legally obligated to take back your
old machine for disposals at least free of charge.
KEY FEATURES
1. Products are totally uniformed in size in accordance with specic requirement.
2. Professional treated materials for longer durability, compact design for easy carrying.
3. Compact and sleek design To take care of cylinder, sucon metal & discharge metal to prevent
leaking of tradional type and increase durability.
4. Long life leakless pump. Made of high durability FCD45 casng ducle.

WARRANTY CARD
DATE
PURCHASERS NAME & ADDRESS
DATE OF DELIVERY DEALERS OFFICIAL SEAL
PRODUCT NAME PRODUCT SERIAL NO.
DEALERS SIGN
CUSTOMER SIGN
CUSTOMER COPY
DEALERS COPY
INVOICE/DN NO.
DATE
PURCHASERS NAME & ADDRESS
DATE OF DELIVERY DEALERS OFFICIAL SEAL
PRODUCT NAME PRODUCT SERIAL NO.
DEALERS SIGN
CUSTOMER SIGN
INVOICE/DN NO.
DATE
PURCHASERS NAME & ADDRESS
DATE OF DELIVERY DEALERS OFFICIAL SEAL
PRODUCT NAME PRODUCT SERIAL NO.
DEALERS SIGN
CUSTOMER SIGN
INVOICE/DN NO.
COMPANY COPY
I/Will accept the terms and conditions of warranty as in the warranty card
I/Will accept the terms and conditions of warranty as in the warranty card
I/Will accept the terms and conditions of warranty as in the warranty card

1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defecve part(s) by authorized
dealer are free of charges. If found defecve by reasons of defecve material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims
under warranty will be accepted on submission of Warranty Card duly lled and stamped by authorized dealer together with the original purchase document. : b. Shipping / transportaon / Incidental charges
incurred in replacing defecve parts under warranty shall be borne by the purchaser
WARRANTY null & void if
(i) Lack of maintenance, (ii) Incorrect use of the machine or tampering, (iii) Use of non-genuine spare parts, (iv) Usage of acids, solvents, or any ammable materials, (v) Non-usage of lter water / clear water / so water & using water
above 40°C temperature, (vi) While using the pressure washers to draw water which is contaminated with dust & solvents (eg. paint thinners, gasoline, oil, etc.), (vii) Repair done by unauthorized service people, (viii) Those parts subject
to wear & tear due to normal operaons and plasc parts, rubber items etc, (ix) Loose connecons, faulty electrical xtures & uctuaons in power supply.
4. Should any failure occur during or aer the warranty period, customer does not have the right to interrupt payment / price discount.
5. Incidental or consequenal damages like inconvenience commercial loss, loss of e, mental agony etc.
6. Loss of any nature due to operaon or non-operaon is not covered under warranty.
7. All free service are at Dealer’s service point only.
8. Warranty ceases if service is not done periodically.
9. The aached card should be completed and returned to Ratnagiri Impex Pvt. Ltd. for registraon immediately aer sale / delivery.
10. The warranty is void unless you register the warranty card with Ratnagiri Impex Pvt. Ltd.
11. The decision of Ratnagiri Impex Pvt. Ltd., in seling the warranty is nal in all respects.
12. All disputes are subject to Bangalore Courts Jurisdicon
1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defecve part(s) by authorized dealer are free of charges.
If found defecve by reasons of defecve material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty
Card duly lled and stamped by authorized dealer together with the original purchase document. : b. Shipping / transportaon / Incidental charges incurred in replacing defecve parts under warranty shall be borne by the purchaser.
WARRANTY null & void if
(i) Lack of maintenance, (ii) Incorrect use of the machine or tampering, (iii) Use of non-genuine spare parts, (iv) Usage of acids, solvents, or any ammable materials, (v) Non-usage of lter water / clear water / so water & using water
above 40°C temperature, (vi) While using the pressure washers to draw water which is contaminated with dust & solvents (eg. paint thinners, gasoline, oil, etc.), (vii) Repair done by unauthorized service people, (viii) Those parts subject
to wear & tear due to normal operaons and plasc parts, rubber items etc, (ix) Loose connecons, faulty electrical xtures & uctuaons in power supply.
4. Should any failure occur during or aer the warranty period, customer does not have the right to interrupt payment / price discount.
5. Incidental or consequenal damages like inconvenience commercial loss, loss of e, mental agony etc.
6. Loss of any nature due to operaon or non-operaon is not covered under warranty.
7. All free service are at Dealer’s service point only.
8. Warranty ceases if service is not done periodically.
9. The aached card should be completed and returned to Ratnagiri Impex Pvt. Ltd. for registraon immediately aer sale / delivery.
10. The warranty is void unless you register the warranty card with Ratnagiri Impex Pvt. Ltd.
11. The decision of Ratnagiri Impex Pvt. Ltd., in seling the warranty is nal in all respects.
12. All disputes are subject to Bangalore Courts Jurisdicon
1. LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defecve part(s) by authorized dealer are free of charges.
If found defecve by reasons of defecve material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty
Card duly lled and stamped by authorized dealer together with the original purchase document. : b. Shipping / transportaon / Incidental charges incurred in replacing defecve parts under warranty shall be borne by the purchaser.
WARRANTY null & void if
(i) Lack of maintenance, (ii) Incorrect use of the machine or tampering, (iii) Use of non-genuine spare parts, (iv) Usage of acids, solvents, or any ammable materials, (v) Non-usage of lter water / clear water / so water & using water
above 40°C temperature, (vi) While using the pressure washers to draw water which is contaminated with dust & solvents (eg. paint thinners, gasoline, oil, etc.), (vii) Repair done by unauthorized service people, (viii) Those parts subject
to wear & tear due to normal operaons and plasc parts, rubber items etc, (ix) Loose connecons, faulty electrical xtures & uctuaons in power supply.
4. Should any failure occur during or aer the warranty period, customer does not have the right to interrupt payment / price discount.
5. Incidental or consequenal damages like inconvenience commercial loss, loss of e, mental agony etc.
6. Loss of any nature due to operaon or non-operaon is not covered under warranty.
7. All free service are at Dealer’s service point only.
8. Warranty ceases if service is not done periodically.
9. The aached card should be completed and returned to Ratnagiri Impex Pvt. Ltd. for registraon immediately aer sale / delivery.
10. The warranty is void unless you register the warranty card with Ratnagiri Impex Pvt. Ltd.
11. The decision of Ratnagiri Impex Pvt. Ltd., in seling the warranty is nal in all respects.
12. All disputes are subject to Bangalore Courts Jurisdicon

1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY
FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER
MODEL SERIAL NUMBER
PDI DATE SERVICE NO. PURCHASE BILL NO. DATE
DEALERS OFFICE SEAL OPERATIONS
1. Check and test the fuel mixture 2. check and clean the air lter
3.Check , clean and adjust the spark plug 4. Check and adjust the carburetor tuning
5. Check and sparken the cutting tools 6.Product familirisation on usage
7. Start and check the noise, vibration, loosen etc.. 8. Routine maintenance and shortage.
MODEL
PDI DATE SERVICE NO. PURCHASE BILL NO.
DEALERS OFFICE SEAL OPERATIONS
1. Check and test the fuel mixture 2. check and clean the air lter
3.Check , clean and adjust the spark plug 4. Check and adjust the carburetor tuning
5. Check and sparken the cutting tools 6.Product familirisation on usage
7. Start and check the noise, vibration, loosen etc.. 8. Routine maintenance and shortage.
FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER
FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER
SERIAL NUMBER
MODEL
PDI DATE SERVICE NO. PURCHASE BILL NO.
OPERATIONS
1. Check and test the fuel mixture 2. check and clean the air lter
3.Check , clean and adjust the spark plug 4. Check and adjust the carburetor tuning
5. Check and sparken the cutting tools 6.Product familirisation on usage
7. Start and check the noise, vibration, loosen etc.. 8. Routine maintenance and shortage.
DATE
DATE
DEALERS OFFICE SEAL
SERIAL NUMBER

DOS DONTS
1. Always read the instrucon manual supplied along with the equipments and understand the correct installaon and operang procedures before
2. It is important to use the personal protecon equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes,
3. Avoid untrained persons using the equipments. Children must not be allowed to handle these equipments
4. Always use genuine spares and accessories in repairs and usage to derive maximum life of the equipments.
5. Always keep the equipments in good working condition to minimize loss of output as well as to reduce the pollution and save the environment
6.Do not use the machine within range of persons unless they wear protecve clothing
7. Do not operate the machine when fagued or under the inuence of alcohol or drugs
8. When the machine is running, please maintain a constant water supply. Without water circulaon will damage the sealing rings of the machine.
9. For more query kindly contact for our Service Center/Dealer/ franchise
aempng to use the equipments.
trousers and jackets while operang potenally dangerous machines

Agrimate Army For Pest Control
RATNAGIRI IMPEX PVT., LTD.,
Annapurna House, #1 / 1G, 7th Cross, New
Guddadahalli
Mysore Road, Bangalore - 560 026
Missed Call : 7393 938 938
Email: [email protected]
ANY WHERE - ANY TIME - ANY CROP
