INSTRUCTION MANUAL
SeQual®Regalia
PSA Oxygen Concentrator System

Tables of Contents
1.0 Introduction
1.1 GENERAL 9
1.2 CAUTIONS, WARNINGS AND HAZARDS 9
2.0 Operation
2.1 GENERAL 11
2.2 RECOMMENDED OPERATING ENVIRONMENT GUIDELINES 11
2.3 THE PROPER LOCATION 12
2.4 BEFORE OPERATING YOUR OXYGEN CONCENTRATOR 12
2.5 OPERATING YOUR OXYGEN CONCENTRATOR 13
3.0 Installation
3.1 GENERAL 15
4.0 Power Management Feature
4.1 IN THE EVENT OF A POWER INTERRUPTION: 17
5.0 Operating Conditions
5.1 CONTROL PANEL DISPLAY 19
5.2 DISPLAY OF OPERATING CONDITIONS 20
5.3 NON-USAGE 20
6.0 Maintenance
6.1 ROUTINE MAINTENANCE: 21
6.2 CABINET AND POWER CORD 21
6.3 AIR INLET FILTER 21
6.4 OXYGEN DELIVERY ACCESSORIES 21
6.5 TROUBLESHOOTING CHARTS 22
7.0 Technical Data
7.1 SPECIFICATIONS 25
7.2 DISPOSAL OF EQUIPMENT AND ACCESSORIES 26

7.3 TECHNICAL SUPPORT 26

List of Figures and Tables
Table 2.1: Regalia Operating Environment Guidelines 11
Table 5.2: Display of Operating Conditions 20
Table 6.3: Concentrator is NOT Running 22
Table 6.4: Concentrator is Running 23
Table 7.5: Regalia Specifications 25

6 SeQual Regalia Instruction Manual
AirSep Corporation
Symbols/Abbreviations
Symbols are frequently used on equipment in preference to words with the intention
of lessening any possibility of misunderstanding caused by language differences.
Symbols can also permit easier comprehension of a concept within a restricted
space.
The following table is a list of symbols and denitions that may be used with AirSep
oxygen equipment. These symbols are referenced from the appropriate International
Electro-technical Commission (IEC) standards:
Symbol Description Symbol Description
Read Instructions - This symbol,
when used alone or in conjunction
with any of the following symbols,
indicates the need to consult the
operating instructions provided
with the product. A potential risk
exists if the operating instructions
are not followed
Attention or Caution - Consult
accompanying documents.
This symbol indicates important
information that requires the user
to take special precautions when
certain conditions are present.
No Smoking or Naked Flames
- The use of oxygen requires
that special care be taken to
reduce the risk of re. Materials
that burn in air and even some
material that will not burn in
air are easily ignited and burn
rapidly in high concentrations of
oxygen. For safety concerns, all
possible sources of ignition must
be kept away from the oxygen
concentrator and preferably
out of the room in which it is
being used. Smoking in the
proximity of an operating oxygen
concentrator is dangerous, and
can permanently damage the
device and void the warranty.
Use no oil or grease - Indicates
important information about the
possibility of spontaneous and
violent ignition that may occur
if oil, grease or other petroleum
based substances come into
contact with oxygen under
pressure.
Electrical Shock - Indicates the
presence of an electric shock
hazard. Warning: To reduce the
risk of electric shock, do not
remove cover. There are no user
serviceable parts inside.
Audible Alarm - An audible
indicator is provided to announce,
in a tone distinctly different
from the sounds generated by
the oxygen concentrator during
normal operation, a reduction
in oxygen concentration, or
when the mains power has been
interrupted.
Normal Operation - Green light is
on indicating the concentrator is
running under normal operating
conditions.
ON/OFF (condition) - Push button
starts concentrator running

SeQual Regalia Instruction Manual 7
AirSep Corporation
Symbol Description Symbol Description
Flow Rate Adjustment - The
controlled quantity of oxygen
increases or decreases in
increments of 0.5 LPM with each
press of the “+” and “-” ow rate
adjustment buttons, respectively.
Type BF Equipment - F type
applied part complying with the
specied requirements of IEC
60601-1 to provide a higher
degree of protection against
electrical shock than provided by
type B applied part.
Class II Equipment - Equipment
in which protection against
electrical shock does not rely on
basic insulation only, but in which
additional safety precautions are
provided.
AAmperes
Note – Provides information
important enough to emphasize
or repeat
Alternating Current

SeQual Regalia Instruction Manual 9
AirSep Corporation
1.0 Introduction
1.1 GENERAL
The Regalia Oxygen Concentrator is intended to provide only non-medical oxygen.
It is not for medical purposes.
This oxygen concentrator is not intended for life supporting or life sustaining
applications.
The Regalia Oxygen Concentrator is an electronically operated oxygen concentrator
that separates oxygen from room air. It does not remove oxygen from a room any
more than by simply breathing the same room air. You utilize the oxygen by attaching
tubing to the oxygen outlet tting.
As with any electrically powered device, the user may experience periods of non-
operation as the result of electrical power interruption, or the need to have the
oxygen concentrator serviced by a technician. This instruction manual will inform
you about the use and care of the Regalia Oxygen Concentrator and will serve as
a reference as you use your oxygen concentrator.
1.2 CAUTIONS, WARNINGS AND HAZARDS
Warning and Caution notices used in this manual apply to hazards or unsafe
practices that could result in personal injury or property damage.
Not for medical purposes.
■Keep oxygen concentrator and cord away from hot surfaces. Do
NOT use the oxygen concentrator if it has a damaged cord or plug;
contact qualified service personnel for examination and repair.
■ Air intake of the oxygen concentrator should be located in a well-
ventilated area.
■Oxygen concentrator should be located so as to avoid pollutants
and fumes.
■If the oxygen concentrator has been dropped, damaged or exposed
to water, contact qualified service personnel for examination or
repair.
■Do NOT drop or insert any object into any opening.
■ Do NOT block the air opening of the oxygen concentrator or place
it on a soft surface, such as a bed or couch, where the bottom air
opening may become blocked.
■ Do NOT cover unit with a blanket, towel, quilt, etc.
■ Do NOT place objects (pillow, blanket) under unit. Maintain at least
½ inch clearance under unit.

10 SeQual Regalia Instruction Manual
AirSep Corporation
■Warning: Do NOT remove the cover. Cover should only be removed
by qualified service personnel.
■ Warning: An alternate source of supplemental oxygen is
recommended in the event of a power outage, alarm condition, or
mechanical failure.
Patents, Trademarks and Copyright
The Oxygen Concentrator System is protected by the following US Patents:
■4,925,464
■5,112,367
■5,114,441
■5,268,021
■5,366,541
■5,593,478
■5,730,778
■Re. 35,099
■Other patents pending

SeQual Regalia Instruction Manual 11
AirSep Corporation
2.0 Operation
2.1 GENERAL
The Regalia Oxygen Concentrators are quiet, reliable and low maintenance sources
of oxygen. The Regalia is designed and constructed to consistently provide high
concentrations of oxygen in a lightweight, compact cabinet that is easy to maneuver.
2.2 RECOMMENDED OPERATING ENVIRONMENT GUIDELINES
Temperature 50º F to 104º F (10º C to 40º C)
Electrical Use no extension cords or electrical outlets controlled by a switch.
Placement No closer than 3 inches (7.6 cm) from the wall, draperies and
furniture.
Environment Smoke, pollutant, and fume free. Relative Humidity: 10% - 95%
Operating Time Up to 24 hours per day.
Flow Rate From 0.5 LPM to 10.0 LPM
Table 2.1: Regalia Operating Environment Guidelines
For rated performance at 10 LPM do not operate the oxygen
concentrator above the indicated boundaries. Operating at ow
rates less than 10 LPM will tolerate higher temperature/humidity
conditions.

12 SeQual Regalia Instruction Manual
AirSep Corporation
2.3 THE PROPER LOCATION
Usage in environments other than those described on the previous page may result
in the need for increased oxygen concentrator maintenance. Select a location in
a well ventilated space that avoids fumes and pollutants and allows the oxygen
concentrator to draw in room air through the intake lter on the top of the cabinet
without being restricted. Make sure the oxygen concentrator is at least three to six
(3 - 6) inches (7.6 – 15.2 cm) away from walls, furniture and especially curtains or
draperies that can impede or block adequate airow to the oxygen concentrator. Do
NOT cover unit with a blanket, towel, quilt, etc. Do NOT place objects under unit.
Maintain at least ½ inch clearance under unit. Keep the oxygen concentrator at
least ve (5) feet (1.5 m) away from hot, sparking objects or open sources of ame.
Do NOT locate the unit near any heat source or heat register.
2.4 BEFORE OPERATING YOUR OXYGEN CONCENTRATOR
There are many different types of oxygen tubing that can be used with this oxygen
concentrator.
■Oxygen Tubing - Connect the oxygen tubing directly to the oxygen
outlet port. Connect the other end of the tube to the application, if
not already attached.
The tube tting may be tight.
Do NOT use oil or grease to lubricate.
To ensure there is enough pressure to deliver oxygen, the length of
the tubing should not exceed 50 feet (15.2m). Maximum extension
tubing length is dependent upon environmental conditions, tubing
type, liter ow and any accessories used between DISS tting and
application. Shorter tubing lengths will be required in some cases.
The internal diameter of the tubing should be no less than 3/16-
inch (0.48 cm).
Alarm System - The oxygen concentrator has an alarm system with
a red visual alarm indicator light and buzzer. The alarm system
will activate in the event of an internal fault or power outage. The
red and/or yellow light may stay on for up to ten (10) minutes after
start-up, OM models only. This is a normal condition during the
initial warm-up period.

SeQual Regalia Instruction Manual 13
AirSep Corporation
If the oxygen concentrator is equipped with an oxygen concentration monitor (OM
model), this monitor indicates if the oxygen concentrator is performing to the correct
specifications. At normal oxygen concentration levels, the green light is activated.
At lower than normal oxygen levels, the yellow light is activated. The red light
activates and the unit alarms if the system malfunctions or when service is needed.
The oxygen concentrator will continue to run at lower levels of oxygen but may
shut down under other system malfunctions. If the red light turns on, you should
discontinue use of the oxygen concentrator and refer to the troubleshooting section
of this manual.
2.5 OPERATING YOUR OXYGEN CONCENTRATOR
This manual serves as a supplemental reference to help you operate and maintain
the unit. If you have any further questions or problems call your AirSep dealer or
authorized service representative.
General Precautions – Retain the product’s safety and operating instructions for
future reference. Follow all operating and usage instructions. Observe all warnings
on the product and in the operating instructions. To reduce the risk of re, bodily
injuries, and damage to the oxygen concentrator, observe all safety precautions.
Do NOT connect to an extension cord or electrical outlet controlled
by a switch. No other appliance should be plugged into the wall
outlet. Voltage requirements are marked on the label on back of
unit.
Read “Symbols/Abbreviations” section of this manual before
plugging-in the power cord. Do NOT use the unit if the power cord
is damaged.
Improper use of the power cord and plug may result in a re or
electrical shock hazard.
Check to see if the power cord is plugged in and there is power to
the outlet.
Check that the oxygen concentrator is not placed near a heat
register.
AirSep products operate safely when used according to their
marked electrical ratings and product usage instructions. The
power cord used with the Regalia Oxygen Concentrator must meet
the requirements of the country where the product is used.

SeQual Regalia Instruction Manual 15
AirSep Corporation
3.0 Installation
3.1 GENERAL
1. Select a Location
Locate oxygen concentrator in a well-ventilated space that provides
adequate airow and check if air is being prevented from entering
the oxygen concentrator by furniture, draperies or clothing.
2. Inspect Inlet Air Filter
Air lter cleaning instructions are located in the maintenance section of this manual.
Always check to see if the inlet air lter is clean.
3. ON/OFF Button
Insert the plug into the electrical wall outlet. Push the On/Off button; the green light
will illuminate to indicate the unit is running.
4. Warm-up Period
After initially turning on the unit, allow three (3) to ten (10) minutes for the unit to
reach its specied performance. If the unit is equipped with an oxygen concentration
monitor (OM models only), the red, yellow and green light will intermittently
illuminate while the unit is warming up. For details on warm-up refer to the Display
of Operating Conditions table.

16 SeQual Regalia Instruction Manual
AirSep Corporation
After an initial startup or after a power interruption the unit may
automatically reduce the ow rate briey before returning to the set
ow rate.
5. Flow Rate Adjustment
Adjust the ow rate to desired setting. Press the Plus “+” button to increase or the
Minus “+” button to decrease the ow rate until the proper level is displayed.

SeQual Regalia Instruction Manual 17
AirSep Corporation
4.0 Power Management Feature
4.1 IN THE EVENT OF A POWER INTERRUPTION:
Because the duration of a power interruption is unknown, seek an
alternate supply of oxygen during the power interruption. Resume
use of the Regalia when power is restored.
If a power outage occurs, the Regalia will activate both an audible and a visual red
light alarm to inform you that the Regalia is not operating. The Regalia should be
located where the alarms can be seen and heard.
If the duration of the interruption is shorter than twenty seconds and the unit has not
been turned off, the Regalia will resume operation twenty seconds after the initial
interruption.
During the power interruption:
The user can press the ON/OFF button to silence the alarms and
turn the unit off.
If the unit was not turned off the Regalia will automatically resume
operation once power is restored.
If the unit was turned off during the power interruption, the user
must press the ON/OFF button again, after the power is restored,
to turn the unit on.

SeQual Regalia Instruction Manual 19
AirSep Corporation
5.0 Operating Conditions
5.1 CONTROL PANEL DISPLAY
If the concentrator is an OM Model (equipped with an oxygen monitor), the oxygen
concentration is being continuously monitored while the Regalia is running and
oxygen is being produced. If the concentration level falls below preset levels, an
indicator light will activate. Operating conditions are described in the table on the
following page.

20 SeQual Regalia Instruction Manual
AirSep Corporation
5.2 DISPLAY OF OPERATING CONDITIONS
Flow Rate
Shown?
Green
Light
Yellow
Light
Red
Light
Audible
Alarm Unit State Operating Condition
No Off Off Off Off Not
Energized
Unit not running / Flow
Indicator Display Not Lit
No Off Off Off Off Energized Unit not running / Flow
Indicator Display Lit
Yes On On On On for 3
seconds
Started
Running Unit is Starting
Yes On On On Periodic
Beep Running
Unit is warming up*
Yes On On Off Periodic
Beep Running
Yes On Off Off Off Running Normal Operating
Condition
Yes Off On Off Periodic
Beep
Not
Running
Unit turned On/Off/On
Quickly
Yes Off
Flashing Off Off Running Oxygen Concentration
Below Normal Level*
Yes Off Off
Flashing On Running Oxygen Concentration
Abnormal Level *1
Yes Off On Off Off Running Button Stuck
Yes On On Off Off Running 9V Battery Low Voltage
(if enabled)
No Off Off
Flashing On Not
Running
Unit is overheating
Compressor Malfunction
Power Interruption
Internal Fuse Blown
No On/Off On/Off On On Running System Malfunction2
*These conditions are displayed only on units equipped with oxygen monitor.
1If abnormal conditions are detected and cannot be remedied, refer to the Troubleshooting section.
2During System Malfunction condition, the Green and Yellow lights may be On or Off.
Table 5.2: Display of Operating Conditions
5.3 NON-USAGE
When not using the oxygen concentrator, press the On/Off button to turn it off.
