2T2R IN D O O R RA D I O UN I T
Installation Guide
Document Part Number: DUG01084
Document Revision: A0.6
Published: March 2022

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
i
© Copyright by Airspan Networks Ltd., 2022. All rights reserved worldwide.
Legal Notices
The information contained within this document is proprietary, privileged and intended only for the recipient. As such, the
information is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any
specific agreements protecting Airspan Networks Ltd. rights in the aforesaid information. Neither this document nor the
information contained herein may be published, reproduced, transmitted or disclosed to third parties, in whole or in part,
without the express, prior, written permission of Airspan Networks Ltd. In addition, any use of this document or the
information contained herein for the purposes other than those for which it is disclosed is strictly forbidden.
Airspan Networks Ltd. reserves the right, without prior notice or liability, to make changes in equipment design or
specifications.
Information supplied by Airspan Networks Ltd. is believed in good faith to be accurate and reliable, while every care has
been taken in preparing these documents. However, Airspan Networks Ltd. does not make any representations and gives
no warranties of whatever nature in respect of these documents, including without limitation, the accuracy or
completeness of any information, facts and/or opinions contained therein. No responsibility is assumed by Airspan
Networks Ltd. for the use of the documents nor for the rights of third parties which may be effected in any way by the use
thereof. The provision of these documents (and the documents themselves) does not constitute professional advice of any
kind. Any representation(s) in these documents concerning performance of Airspan Networks Ltd. product(s) are for
informational purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks
Ltd., its affiliates, directors, employees and agents shall not be held liable for any damages or losses, of any nature
whatsoever, arising from any use of and/or reliance on the documents.
These documents may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in
relation thereto unless specifically undertaken in Airspan Networks Ltd. sales contract or order confirmation. Information
contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have
encountered an error, please notify Airspan Networks Ltd.
Product performance figures quoted within this document are indicative and for information purposes only.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
ii
TABLE OF CONTENTS
Document Information..............................................................................................................1
Revision History......................................................................................................................... 1
Warnings and Cautions..............................................................................................................2
Human Exposure to Radio Frequencies.................................................................................... 2
Radio Interference .................................................................................................................... 2
Modifications ............................................................................................................................ 2
General...................................................................................................................................... 2
Important Safety Instructions ............................................................................................ 2
Safety…...................................................................................................................................... 2
Warning of Hazardous Voltages ............................................................................................... 3
Adherence to European Directive 2014/53/EU........................................................................ 3
Warning Symbols ...................................................................................................................... 3
Service Information................................................................................................................... 4
About This Document................................................................................................................5
Purpose ..................................................................................................................................... 5
Intended Audience.................................................................................................................... 5
Document Conventions ............................................................................................................ 5
Related Reading ........................................................................................................................ 5
1Introduction...................................................................................................................6
1.1 AirStar 1900/1200 5G Sub-6Hz.................................................................................... 6
2Getting Started ..............................................................................................................7
2.1 AirStar 1900/1200 5G Sub-6 Job Sheet....................................................................... 7
3Verifying Prerequisites ..................................................................................................8
3.1 Verifying Site Requirements ........................................................................................ 8
3.2 Verify Installation Requirements................................................................................. 8
4AirStar 1900/1200 5G Sub-6 Installation ....................................................................12
4.1 Ceiling Mount............................................................................................................. 12
4.2 Wall Mount ................................................................................................................ 19
4.3 Extension Kit .............................................................................................................. 23
4.4 LED Display................................................................................................................. 26
4.5 GPS LED Display ......................................................................................................... 27
5Connect and Manage Cables.......................................................................................28
5.1 Physical Interfaces ..................................................................................................... 28
5.2 Mounting the AC to PoE++/DC Power Supply........................................................... 28
Job Sheet .........................................................................................................29
Acronyms, Abbreviations, and Definitions..............................................................................30
Customer Service Help Desk....................................................................................................31
Airspan Encourages Comments ..............................................................................................31

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
iii
FIGURES
Figure 1: AirStar 1900/1200 5G Sub-6Hz................................................................................................... 6
Figure 2: AirStar 1900/1200 5G Sub-6 Dimensions.................................................................................10
Figure 3: Fasten the Ceiling Adaptor Bracket to the Ceiling ...................................................................12
Figure 4: Slide Hanger onto Pole ............................................................................................................. 13
Figure 5: Mounting to the Ceiling Adaptor..............................................................................................13
Figure 6: Insert Screws.............................................................................................................................13
Figure 7: Hook Unit on Hanger ................................................................................................................ 14
Figure 8: Insert the Screws ...................................................................................................................... 14
Figure 9: Tighten Setscrew.......................................................................................................................14
Figure 10: GPS Connection ......................................................................................................................14
Figure 11: Conventional Ceiling Mounted...............................................................................................15
Figure 12: Insert Bottom Sleeve ..............................................................................................................15
Figure 13: Fit Sleeve Cap on the Bottom Sleeve...................................................................................... 16
Figure 14: Slide the Hanger onto Pole.....................................................................................................16
Figure 15: Suspended Ceiling Assembly ..................................................................................................17
Figure 16: Insert the 2 Screws ................................................................................................................. 17
Figure 17: Hook Unit on Hanger ..............................................................................................................17
Figure 18: Insert the Screws ....................................................................................................................18
Figure 19: Insert Screws and Tighten ...................................................................................................... 18
Figure 20: Check GPS Connection............................................................................................................18
Figure 21: Suspended Ceiling Mount.......................................................................................................19
Figure 22: Wall Mount Bracket................................................................................................................19
Figure 23: Fix Wall Mount on Wall ..........................................................................................................20
Figure 24: Slide Wall Mount Cover on Wall Mount.................................................................................20
Figure 25: Slide Hanger on Pole............................................................................................................... 20
Figure 26: Insert the Screws ....................................................................................................................21
Figure 27: Hook Unit on Hanger ..............................................................................................................21
Figure 28: Insert both Screws ..................................................................................................................21
Figure 29: Insert Screws and Tighten ...................................................................................................... 21
Figure 30: Check the GPS Connection .....................................................................................................22
Figure 31: Slide down Cover .................................................................................................................... 22
Figure 32: Mounted on Wall....................................................................................................................22
Figure 33: Extension Assembly ................................................................................................................ 24
Figure 34: Extension Assembled .............................................................................................................. 24
Figure 35: Hook Unit on Hanger ..............................................................................................................25
Figure 36: Insert both Screws ..................................................................................................................25
Figure 37: Insert Screws and Tighten ...................................................................................................... 25
Figure 38: Check the GPS Connection .....................................................................................................25
TABLES
Table 1: Typographic Conventions............................................................................................................. 5
Table 2. Minimum Hardware Requirements ............................................................................................. 8
Table 3. Parts & Kits ................................................................................................................................... 8
Table 4: AirStar Variants...........................................................................................................................10
Table 5: AirStar 1900/1200 5G Sub-6 Physical Dimensions ....................................................................10

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
iv
Table 6: AirStar 1900/1200 5G Sub-6 Operational Tolerances ...............................................................11
Table 7: Status LED Display ......................................................................................................................26
Table 8: BH LED Display............................................................................................................................26
Table 9: GPS LED Display..........................................................................................................................27
Table 10: Job Sheet .................................................................................................................................. 29
Table 11: Acronyms, Abbreviations, and Definitions ..............................................................................30

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
1
Document Information
This document details the procedure for installing the Airspan’s AirStar 1900/1200 5G Sub-6 GHz, RU
aimed as part of the 5G NR standard and its place in the Airspan product suite. This document is
intended for qualified personnel with a working knowledge of 5G.
Revision History
Revision
Date
Summary of Changes
Created by
Rev 0.1 –0.2
February 2022
Initial document –draft
Added new mounting configuration
MSF + YS +SS
Rev 0.3 –0.4
February 2022
Added Variant table
Added Extension Kit
MSF + YS +SS
Rev 0.5 –0.6
March 2022
Name change
Changes from comments
Added ACP-FCC note
MSF + YS +SS
Rev A
TBD
Published
MSF + YS +SS

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
2
Warnings and Cautions
Human Exposure to Radio Frequencies
The AirStar 1900/1200 5G Sub-6 gHz should be operated from a minimum safe distance of 20 cm (7.87
in.) during normal operation.
Radio Interference
The AirStar 1900/1200 5G Sub-6 generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment on and off, the technician is encouraged to try to correct
the interference by performing one or more of the following measures:
Re-orientate or relocate the unit
Increase separation between the units and/or End Devices
Connect the equipment to a circuit different from that to which the power source is connected
Modifications
Any changes and modifications to this device that are not expressly approved by Airspan Networks
may void the user's authority to operate the equipment.
General
Only qualified personnel should be allowed to install, replace, and service the equipment.
The device cannot be sold retail, to the public or by mail order. It must be sold to operators.
Installation must be controlled.
Installation must be performed by licensed professionals.
Installation requires special training. The AirStar 1900/1200 5G Sub-6 should be installed ONLY by
experienced installation professionals who are familiar with local building and safety codes and,
wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to
do so may void Airspan's product warranty and may expose the end user or the service provider to
legal and financial liabilities. Airspan and its resellers or distributors are not liable for injury,
damage or violation of regulations associated with the installation of outdoor units or antennas.
The device is to be installed in a Restricted Access Location not easily accessible.
Important Safety Instructions
Read and Save these instructions
This Installation Guide contains instructions and warnings that should be followed during
installation, and operation.
Failure to follow these instructions could cause bodily injury and/or product failure
Safety
1. Read this guide and follow all operating and safety instructions.
2. Static sensitive components inside - do not remove the lid or base: No user serviceable parts
inside.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
3
3. Position the power cord to avoid possible damage; do not overload circuits.
4. Do not place this product on or near a direct heat source, and avoid placing objects on the
terminal.
5. Use only a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Disconnect the power
before cleaning.
6. The units should not be located too near power lines or other electrical power circuits, where it
can come into contact with power lines or circuits.
7. The radio transceiver must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in accordance with
the local electrical codes.
8. Installation of the AirStar 1900/1200 5G Sub-6 must be contracted to a professional installer.
9. When installed in the final configuration, the product must comply with the applicable Safety
Standards and regulatory requirements of the country in which it is installed. If necessary, consult
with the appropriate regulatory agencies and inspection authorities to ensure compliance.
The onsite source circuit breaker (10A) should be gang operated, double pole (single
phase type).
Warning of Hazardous Voltages
On AC installations, hazardous voltages exist. Use caution when verifying or working with AC power.
Remove metal jewelry that could come into contact with AC power.
On DC sections, short-circuiting the low voltage, low impedance circuits can cause severe arcing that
may result in burns or eye damage. Remove rings, watches etc. to avoid shorting DC circuits.

Airspan products do not contain hazardous substances (as defined in UK Control of
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances
Regulations 1990). At the end of any Airspan products life cycle, the customer should
consult with Airspan to ensure that the product is disposed of in conformance with the
relevant regulatory requirements.
Adherence to European Directive 2014/53/EU
European Council Recommendation 2014/53/EU details basic restrictions and reference levels on
human exposure to electromagnetic fields as advised by the ICNIRP. Adherence to these
recommended restrictions and reference levels should provide a high level of protection as regards
the established health effects that may result from exposure to electromagnetic fields.
Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These warning
symbols mean danger. Bodily injury may result if you are not aware of the safety hazards involved in
working with electrical equipment and radio transmitters. Familiarize yourself with standard safety
practices before continuing.
Caution, hot surface
Caution
Electro-Magnetic
Radiation
High Voltage
DC

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
4
Service Information
Refer all repairs to qualified service personnel. Do not modify any part of this device, as this will void
the warranty.
Disconnect the power to this product and return it for service if the following conditions apply:
1. The terminal does not function after following the operating instructions outlined in this manual.
2. The product has been dropped or the housing is damaged.
Locate the serial number of the terminal and record this on your registration card for future reference.
Also, record the MAC address, located on the product sticker.
The unit can be powered by either PoE++ or AC power (using an AC/DC converter).
AirStar 1900/1200 is easy to install on ceiling, suspended ceiling or wall

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
5
Purpose
This guide provides the workflow and step-by-step procedures for installing the Airspan’s AirStar
1900/1200 a high performing RU variant. These procedures include:
Verify prerequisites
Install Mounting bracket Wall or Ceiling (Suspended or Solid)
Install the AirStar 1900/1200
Connect and manage cables
Connect power
Intended Audience
This guide is intended for persons who are responsible for installing the AirStar 1900/1200 5G Sub-6.
These persons should have a working knowledge of the equipment.
Document Conventions
This document uses the following typographic conventions.
Table 1: Typographic Conventions
Convention
Element
Blue underlined text
Cross-reference links.
Bold text
Keyboard buttons and GUI elements.
Command
Command names or phrases.
Computer output
Text displayed by the computer.
Hyperlinks
Website and e-mail addresses.
Danger
Signifies a hazardous situation—if not avoided—will cause death or
serious injury. Describes how to avoid it.
Warning
Signifies a hazardous situation—if not avoided—can cause death or
serious personal injury. Describes how to avoid it.
!Caution
Signifies a hazardous situation—if not avoided—can void the product
warranty, and cause property damage. Describes how to avoid it.
Information/Note
Provides necessary information to explain a task.
Tip
Provides helpful hints.
Related Reading
The following documents contain related information:
AirStar 1900/1200 5G Sub-6 Product Specification

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
6
1Introduction
This section provides a descriptive overview of the installation of Airspan’s AirStar 1900/1200 and its
place in the Airspan product suite.
This document is intended for readers with 5G working knowledge.
All information in this document is for general information only, and is subject for change without
notice.
1.1 AirStar 1900/1200 5G Sub-6Hz
The AirStar1900/1200 is 5G-NR, sub-6 GHz indoor solution that’s part of the OpenRANGE product line.
It consists of both a radio unit (RU), distributed unit (DU) and in a compact unit (CU). It either can
operate as a full gNB solution, or can be based on 3GPP split 2 architecture (SW Roadmap) - thus,
allowing network adaptability for operators. The AirStar1900/1200 delivers enhanced, indoor to
indoor and indoor to outdoor network coverage and capacity.

For management please refer to the system Commissioning Manual.
Figure 1: AirStar 1900/1200 5G Sub-6Hz

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
7
2Getting Started
2.1 AirStar 1900/1200 5G Sub-6 Job Sheet
Plan the installation of the AirStar 1900/1200 5G Sub-6 by using the Job Sheet, which you can find as a
removable job aid in Appendix A for this guide.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
8
3Verifying Prerequisites
Prior to installing the AirStar 1900/1200 5G Sub-6Hz, verify the required safety, power, tools, parts
and components. This chapter includes the hardware, software, and client requirements for
installation.

Important: Set up requirements for the installation is detailed in the Job Sheet, see
Appendix_A.
3.1 Verifying Site Requirements
To set up the AirStar 1900/1200 5G Sub-6Hz, an IP connection to a Network Management System
(NMS) is required.
3.2 Verify Installation Requirements
3.2.1 Verify the Tools
Table 2. Minimum Hardware Requirements
Tool
Use
Philips screwdriver (PH2)
For securing the Wall mounting bracket base, and securing the
Ceiling adaptor bracket
5/32” Allen wrench
For ¼-20 screws –Ceiling adaptor to Pole, Hanger and Extension
coupler
3/32” Allen wrench
For 8-32 screws –Locking screw and GPS bracket
3.2.2 Verify the Parts and Kits
Table 3. Parts & Kits
Installation Kit / Part
Part No.
Consisting of:
AirStar 1900/1200 5G
Sub-6 unit
AR19-N48-DP4C1S
AirStar 1900/1200 5G Sub-6
GPS antenna
PoE++ adaptor + US cable cord with Plug
type B
Ceiling mounting kit
AirStar 1900/1200 5G
Sub-6 Ceiling
Mounting Kit
Ceiling base bracket
Basic pole
Hanger
Top cover
Bottom cover
Hardware

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
9
Installation Kit / Part
Part No.
Consisting of:
Optional Accessories –available separately
AirStar 1900/1200 5G
Sub-6 Extension Kit
Extension pole
Extension coupler
Extension Coupler Cap
Hardware
AirStar 1900/1200 5G
Sub-6 GPS Extension
kit

AirStar 1900/1200 5G
Sub-6 Suspended
Ceiling Mounting Kit
Ceiling base bracket
Long pole
Hanger
Top and bottom sleeve(s)
Bottom cover
Hardware
AirStar 1900/1200 5G
Sub-6 Wall Mounting
Kit
Basic Wall Mounting Bracket Base, hanger
bracket & covers
Hardware

Standard ceiling mounting kit is included. Available separately - there is a Suspended
ceiling mounting kit or a Wall mounting kit, please contact your Airspan supplier.

The AirStar 1900/1200 requires operation using an Airspan FCC-specific version of ACP
acting as a CBRS Domain Proxy.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
10
3.2.3 Product Variants
Table 4: AirStar Variants
Variant
Description
AR19-N48-DP4C1S
AirStar 1900/1200 5G, 3.55-3.7GHz (n48), PoE/DC
AR19-N48-DP4C1S-CN
AirStar 1900/1200 5G, 3.55-3.7GHz (n48),
PoE/DC Connectorized
3.2.4 Power Supply and Current
AirStar 1900/1200 5G Sub-6 supports a direct connection to DC power source or Standard 802.3bt
Type4 class 8 90w adaptor.
Operational Range: 40.5-57vDC
Safety approved (certified) according to IEC/EN/TUV 60950-1
The use of other power sources may impair safety and will invoke warranty.
3.2.5 Physical Dimensions
AirStar 1900/1200 5G Sub-6 is in an indoor enclosure.
Table 5: AirStar 1900/1200 5G Sub-6 Physical Dimensions
Dimensions (H x W x D)
Weight
8.66 x 8.31 x 6.8 in. / 220 x 211 x 172.5
mm
3.7 Kg / 8.2 Lbs.
Figure 2: AirStar 1900/1200 5G Sub-6 Dimensions

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
11
3.2.6 Environmental

AirStar 1900/1200 5G Sub-6RU is not for external/outdoor use.
Table 6: AirStar 1900/1200 5G Sub-6 Operational Tolerances
Type
Parameters
Operating temperature
0°C to 40°C
Operating humidity
5% - 85% non-condensing
Storage temperature
-25°C to 70°C
Storage humidity
5% - 95% non-condensing
Rain and dust ingress protection
IP30
Operational altitude
70-106 kPa as well as:
From -60m to 1800m @ 40C
From 1800m to 4000m @ 30C
Radio Performance
AirStar 1900/1200 conforms to the TS 38.104 - Local Area
Base Station type 1-O (OTA FR1)
Safety
IEC62368-1:2018 (Edition No. 3)
ROHS
RoHS 3 directive
FCC
FCC Title 47 CFR Part 96.
EMC
FCC Title 47 CFR Parts 15.107 and 15.109 Class-B
Environmental
ETSI EN 300-019-1-3 Operational (class 3.1 - temperature
protected locations)
ETSI EN 300-019-1-1 Storage (class 1.2 -weather protected,
not temperature controlled locations)
ETSI EN 300-019-1-2 Transportation (class 2.3 –Public
Transportation)
MTBF
50 Years

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
12
4AirStar 1900/1200 5G Sub-6 Installation
AirStar 1900/1200 5G Sub-6 supports Ceiling (conventional and suspended) and Wall mounting.
4.1 Ceiling Mount
The following defines the AirStar 1900/1200 ceiling-mount assembly procedure for conventional
ceiling or suspended ceilings.

Prior to assembly, in any mounting scenario, determine where the unit it to be installed.
4.1.1 Conventional Ceiling Assembly
The following are instructions for assembly to a conventional ceiling.
1. Select the required location where the AirStar 1900/1200 unit is to be installed, on the ceiling
opposite a window.
2. Position the Ceiling adaptor bracket on the ceiling. Be sure to position the Ceiling adaptor so the
unit will be opposite a window.
3. Mark the screw positions carefully through the holes in the Ceiling adaptor bracket onto the
ceiling.
4. After drilling holes and inserting approved ceiling anchors (plugs) fasten the Ceiling adaptor
bracket to the ceiling with screws and washers (not included).

Screws and washers (x4) and any necessary hardware are not supplied by Airspan and are
the responsibility of the installer. Use appropriate ceiling hardware according to field
conditions. The holes in the Ceiling adaptor are 5/16 (8mm).
Figure 3: Fasten the Ceiling Adaptor Bracket to the Ceiling
5. Slide the Hanger onto the pole, till the bottom.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
13
Figure 4: Slide Hanger onto Pole
6. Slide the decorative (lower) cover over the pole. Verify that the opening is facing downward.
7. Slide the decorative (upper) cover over the pole. Verify that the opening is facing upward.
8. Lift the mounting pole (with the Hanger and covers) into position and insert into the Ceiling
adapter.
Figure 5: Mounting to the Ceiling Adaptor
9. Align the holes of the pole and the Ceiling adaptor.
10. Insert the two (2) 1/4 -20 screws, washers and tighten. Tighten to a torque of no more than
17.5lb*in (1.98 Nm) max.
Figure 6: Insert Screws
11. At this time, route the cables through the opening in pole and out the bottom, connection will be
made later.
12. The Ceiling adaptor bracket is installed and ready for AirStar 1900/1200 unit mounting.
13. Lift the plastic lower cover, up out of the way in order to hang the unit.
14. Lift and hook the AirStar 1900/1200 on the hanger.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
14
Figure 7: Hook Unit on Hanger
15. Insert the two (2) 1/4 -20 screws, washers and tighten through the holes in the hanger holes and
tighten. Tighten to a torque of no more than 17.5lb*in (1.98 Nm) max.
Figure 8: Insert the Screws
16. Rotate the AirStar 1900/1200 so that the GPS plate faces the window.
17. Tighten the setscrew to lock the unit in the current position (facing the window). Tighten to a
torque of no more than 22 lb*in (2.48 Nm) max.
Figure 9: Tighten Setscrew
18. Connect the necessary cables to the relevant ports.
19. Once all connections are completed, slide up the decorative top cover over the Ceiling adaptor
and snap it closed.
20. Check that the GPS is connected properly.
Figure 10: GPS Connection
21. Next slide down the decorative bottom cover over the top of the and snap it on to fasten it.
22. After assembly, the GPS can be adjusted by loosening the 8-32 screw (with a 3-32 Allen wrench)
on the GPS bracket. After adjustment, re-tighten the screw. Tighten to a torque of no more than
8lb*in (0.90 Nm) max.

AirStar 1900/1200 5G Sub-6 GHz Full gNB/RDU
2T2R Indoor Radio Unit –Installation Guide
© Copyright Airspan Networks Ltd., 2022 P/N: DUG01084 Rev. A0.6, Mar 2022
15
Figure 11: Conventional Ceiling Mounted
4.1.2 Suspended Ceiling Assembly
The following are instructions for assembly to a Suspended (acoustical) ceiling.
1. Determine the position where the AirStar unit is to be installed.
2. Determine which acoustical ceiling tile the pole will pass thru and remove it to gain access to the
conventional ceiling above.
3. Prepare a hole (using a 64mm (2.5 in) hole-saw) in the acoustical tile where the pole will pass
through, in order to be fastened to the upper ceiling.
4. Insert the bottom sleeve into the hole in the acoustical tile.
Figure 12: Insert Bottom Sleeve
5. Turn the tile over and fit the sleeve cap onto the bottom sleeve.
