Aiwa CSD-ED27 User manual

COMPACT DISC STEREO RADIO
CASSETTE RECORDER
CSD-ED27
S/M Code No. 09-994-327-4R2
LH(S),HR(S)
HA(S)
SERVICE MANUAL
REVISION
This Service Manual is the “Revision Publishing” and replaces “Simple Manual”
CSD-ED27(HRJ<S>,LH<S>)(S/M Code No.09-994-327-4T2)
.
BASIC TAPE MECHANISM : TN21ZVC-1812
BASIC CD MECHANISM : KSM-213CDM
DATA

2
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
CD PICK-UP ASSY P.C.B.
Precaution to replace Optical block
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
(KSS – 213B)

3
SPECIFICATIONS
<Tuner section>
(FM)
Tuning range 87.5 MHz to 108.0 MHz
Antenna Rod antenna
(AM)
Tuning range 530 kHz to 1,710 kHz (10 kHz step)
531 kHz to 1,602 kHz (9 kHz step)
Antenna Ferrite bar antenna
<Cassette deck section>
Track format 4 track, 2 channels stereo
Frequency response Normal tape: 50 Hz - 12,500 Hz (EIAJ)
Recording system AC bias
Erasing system Magnet erase
Heads Recording/Playback head x1
Erasure head x 1
<Compact disc player section>
Disk Compact disc
Scanning method Non-contact optical scanner
(Semicondactor laser)
<General>
Speakers 80 mm cone type (2)
Power output 2.5 W + 2.5 W (EIAJ 7 ohm DC)
1.9 W + 1.9 W (DIN 1% Rated power)
Output Headphones (stereo minijack)
Power requirements DC 12 V using eight size C (R14)
batteries
AC 110-120 V/220-240 V switchable,
50/60 Hz
Power consumption 14 W
Dimensions (W x H x D)
310 x 156 x 253 mm
Weight (Excluding batteries) 2.6 kg
• Design and specifications are subject to change without notice.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES LIST
1 8Z-CHB-906-010 IB,LH(ESP)FM<LH,HA>
1 8Z-CHB-907-010 IB,H(ECA)FM<HR>
!2 87-A80-081-010 AC CORD SET ASSY,EZ BLK
3 87-099-789-010 PLUG,ADPTR IR44

4
DISASSEMBLY PROCEDURE
1. Remove screws (1x 5) and (2x 2).
1
1
1
2
3
3
QSOUND BUTTON
2. While pushing the QSOUND button, remove the rear cabinet.
3. Widen the handle to the left and right, to remove it.
4. Remove screws (3x 4).
5. Remove the CD player, main C.B., etc. from the front cabinet.

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A21-184-010 IC,TA2104AN
87-A21-185-040 C-IC,LC72121M
87-070-416-010 IC,NJU7201 L55
87-A21-111-040 C-IC,M62495FP
87-A20-946-040 C-IC,MM1434XF
87-A21-193-010 IC,TA8227P
87-A21-145-040 C-IC,BA4560F-E2
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A20-856-010 IC,BA6898S
8Z-CH4-636-010 IC,LC867132V-5H52
TRANSISTOR
89-319-233-080 TR,2SC1923 (0.1W)
87-026-447-080 TR,2SC1740S R
89-320-011-080 TR,2SC2001K(15W)
87-026-215-080 TR,DTC114YS
89-213-702-010 TR,2SB1370E(1.8W)
89-318-154-080 TR,2SC1815 (0.4W)
89-113-184-080 TR,2SA1318T
89-112-965-080 TR,2SA1296GR(0.75W)
87-026-463-080 TR,2SA933S (0.3W)
87-026-291-080 TR,DTC124XS
89-318-155-080 TR,2SC1815 (0.4W)
87-026-462-080 TR,2SC1740 S(RS 0.3W)
89-110-155-080 TR,2SA1015(0.4W)
87-026-496-080 FET,2SJ103GR
89-328-786-080 TR,2SC2878B
87-026-245-080 TR,DTC124ES
87-026-237-080 CHIP-TR,DTC124XK
87-026-464-080 TR,DTC114TS (0.3W)
87-026-239-080 TR,DTC114TK (0.2W)
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-017-072-080 ZENER,HZS3B1
87-017-162-080 ZENER,HZS7C3L
87-017-148-080 ZENER,HZS6A1L
87-070-345-080 DIODE,IN4148
87-027-607-080 ZENER,HZ7B3L
87-017-139-010 ZENER,HZS15-2
87-A40-466-080 ZENER,MTZJ2.7A
87-A40-465-090 DIODE,FR202
MAIN C.B
C1 87-010-314-080 C-CAP,S 22P-50V
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-314-080 C-CAP,S 22P-50V
C5 87-010-196-080 CHIP CAPACITOR,0.1-25
C6 87-010-313-080 CAP, CHIP 18P
C7 87-014-049-080 CAP,PP 470P-100 J
C8 87-012-349-080 C-CAP,S 1000P-50 CH
C10 87-010-197-080 CAP, CHIP 0.01 DM
C11 87-010-197-080 CAP, CHIP 0.01 DM
C12 87-010-197-080 CAP, CHIP 0.01 DM
C13 87-010-150-080 C-CAP,S 6P-50 CH
C14 87-010-303-080 C-CAP,S 330P-50CH
C15 87-012-349-080 C-CAP,S 1000P-50 CH
C16 87-010-380-080 CAP, ELECT 47-16V
C17 87-010-198-080 CAP, CHIP 0.022
C18 87-015-819-080 CAPACITOR,0.01
C19 87-010-112-080 CAP, ELECT 100-16V
C20 87-010-404-080 CAP, ELECT 4.7-50V
C21 87-010-197-080 CAP, CHIP 0.01 DM
C22 87-010-197-080 CAP, CHIP 0.01 DM
C24 87-010-303-080 C-CAP,S 330P-50CH
C25 87-016-460-080 C-CAP,S 0.22-16 B
C27 87-A11-067-080 C-CAP,S 1-10 K B
C28 87-016-669-080 C-CAP,S 0.1-25 K B
C29 87-016-669-080 C-CAP,S 0.1-25 K B
C30 87-010-213-080 C-CAP,S 0.015-50 B<HR>
C30 87-010-198-080 CAP, CHIP 0.022<LH,HA>
C31 87-010-213-080 C-CAP,S 0.015-50 B<HR>
C31 87-010-198-080 CAP, CHIP 0.022<LH,HA>
C33 87-010-401-080 CAP, ELECT 1-50V
C34 87-010-401-080 CAP, ELECT 1-50V
C35 87-015-819-080 CAPACITOR,0.01
C36 87-010-112-080 CAP, ELECT 100-16V
C37 87-010-197-080 CAP, CHIP 0.01 DM
C38 87-010-380-080 CAP, ELECT 47-16V
C39 87-010-404-080 CAP, ELECT 4.7-50V
C40 87-010-197-080 CAP, CHIP 0.01 DM
C41 87-012-349-080 C-CAP,S 1000P-50 CH
C42 87-012-349-080 C-CAP,S 1000P-50 CH
C43 87-012-349-080 C-CAP,S 1000P-50 CH
C44 87-010-311-080 CAP 12P
C45 87-010-312-080 C-CAP,S 15P-50 CH
C46 87-010-197-080 CAP, CHIP 0.01 DM
C47 87-010-197-080 CAP, CHIP 0.01 DM
C48 87-010-197-080 CAP, CHIP 0.01 DM
C49 87-012-140-080 CAP 470P
C50 87-010-197-080 CAP, CHIP 0.01 DM
C71 87-015-819-080 CAPACITOR,0.01
C72 87-016-669-080 C-CAP,S 0.1-25 K B
C73 87-016-669-080 C-CAP,S 0.1-25 K B
C95 87-010-197-080 CAP, CHIP 0.01 DM<LH,HA>
C96 87-A11-132-080 CAP,TC U 0.01-50 K B
C99 87-A11-132-080 CAP,TC U 0.01-50 K B
C202 87-018-209-080 CAP, CER 0.1-50V
C203 87-010-401-080 CAP, ELECT 1-50V
C204 87-010-221-080 CAP, ELECT 470-10V
C205 87-010-263-080 CAP, ELECT 100-10V
C206 87-010-248-080 CAP, ELECT 220-10V
C210 87-010-198-080 CAP, CHIP 0.022
C211 87-010-260-080 CAP, ELECT 47-25V
C212 87-010-198-080 CAP, CHIP 0.022
C213 87-010-248-080 CAP, ELECT 220-10V
C220 87-016-495-090 CAP,E 3300-25 SMG
C230 87-010-405-080 CAP, ELECT 10-50V
C231 87-010-404-080 CAP, ELECT 4.7-50V
C232 87-010-263-080 CAP, ELECT 100-10V
C233 87-018-134-080 CAPACITOR,TC-U 0.01-16
C261 87-018-209-080 CAP, CER 0.1-50V
C262 87-010-384-080 CAP, ELECT 100-25V
C263 87-010-385-080 CAP, ELECT 220-25V
C264 87-010-196-080 CHIP CAPACITOR,0.1-25
C265 87-010-236-080 CAP,E 1000-10 SME
C301 87-010-405-080 CAP, ELECT 10-50V
C302 87-010-405-080 CAP, ELECT 10-50V
C303 87-010-405-080 CAP, ELECT 10-50V
C304 87-010-404-080 CAP, ELECT 4.7-50V
C305 87-010-213-080 C-CAP,S 0.015-50 B
C306 87-010-546-080 CAP, ELECT 0.33-50V
C307 87-010-544-080 CAP, ELECT 0.1-50V
C308 87-010-260-080 CAP, ELECT 47-25V
C309 87-010-263-080 CAP, ELECT 100-10V
C310 87-010-544-080 CAP, ELECT 0.1-50V
C311 87-010-546-080 CAP, ELECT 0.33-50V
C312 87-010-213-080 C-CAP,S 0.015-50 B
C313 87-010-404-080 CAP, ELECT 4.7-50V
C314 87-010-405-080 CAP, ELECT 10-50V
C315 87-010-405-080 CAP, ELECT 10-50V
C316 87-010-405-080 CAP, ELECT 10-50V
C317 87-010-401-080 CAP, ELECT 1-50V
C318 87-010-401-080 CAP, ELECT 1-50V

6
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C319 87-010-197-080 CAP, CHIP 0.01 DM
C320 87-010-405-080 CAP, ELECT 10-50V
C321 87-010-260-080 CAP, ELECT 47-25V
C322 87-010-402-080 CAP, ELECT 2.2-50V
C325 87-010-400-080 CAP, ELECT 0.47-50V
C326 87-010-400-080 CAP, ELECT 0.47-50V
C329 87-010-401-080 CAP, ELECT 1-50V
C330 87-010-197-080 CAP, CHIP 0.01 DM
C331 87-010-197-080 CAP, CHIP 0.01 DM
C332 87-010-197-080 CAP, CHIP 0.01 DM
C333 87-010-197-080 CAP, CHIP 0.01 DM
C334 87-010-404-080 CAP, ELECT 4.7-50V
C335 87-010-401-080 CAP, ELECT 1-50V
C336 87-010-401-080 CAP, ELECT 1-50V
C337 87-010-178-080 CHIP CAP 1000P
C338 87-010-384-080 CAP, ELECT 100-25V
C339 87-010-404-080 CAP, ELECT 4.7-50V
C340 87-010-401-080 CAP, ELECT 1-50V
C341 87-010-178-080 CHIP CAP 1000P
C342 87-010-384-080 CAP, ELECT 100-25V
C343 87-010-384-080 CAP, ELECT 100-25V
C344 87-010-384-080 CAP, ELECT 100-25V
C345 87-010-384-080 CAP, ELECT 100-25V
C346 87-010-235-080 CAP,E 470-16 SME
C347 87-010-384-080 CAP, ELECT 100-25V
C348 87-010-235-080 CAP,E 470-16 SME
C351 87-010-401-080 CAP, ELECT 1-50V
C355 87-010-384-080 CAP, ELECT 100-25V
C401 87-012-145-080 CAP, CHIP S 270P CH
C405 87-010-178-080 CHIP CAP 1000P
C407 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-402-080 CAP, ELECT 2.2-50V
C411 87-010-177-080 C-CAP,S 820P-50 SL
C412 87-010-260-080 CAP, ELECT 47-25V
C413 87-012-158-080 C-CAP,S 390P-50 CH
C415 87-010-406-080 CAP, ELECT 22-50
C416 87-010-404-080 CAP, ELECT 4.7-50V
C417 87-010-384-080 CAP, ELECT 100-25V
C418 87-010-402-080 CAP, ELECT 2.2-50V
C419 87-010-177-080 C-CAP,S 820P-50 SL
C420 87-012-158-080 C-CAP,S 390P-50 CH
C422 87-010-406-080 CAP, ELECT 22-50
C423 87-010-404-080 CAP, ELECT 4.7-50V
C424 87-010-194-080 CAP, CHIP 0.047
C425 87-010-177-080 C-CAP,S 820P-50 SL
C426 87-010-186-080 CAP,CHIP 4700P
C427 87-010-404-080 CAP, ELECT 4.7-50V
C428 87-010-260-080 CAP, ELECT 47-25V
C429 87-012-153-080 C-CAP,S 120P-50 CH
C430 87-010-213-080 C-CAP,S 0.015-50 B
C431 87-010-405-080 CAP, ELECT 10-50V
C432 87-010-401-010 CAP, ELECT 1-50V
C433 87-010-177-080 C-CAP,S 820P-50 SL
C434 87-010-186-080 CAP,CHIP 4700P
C435 87-010-404-080 CAP, ELECT 4.7-50V
C436 87-012-153-080 C-CAP,S 120P-50 CH
C437 87-010-213-080 C-CAP,S 0.015-50 B
C438 87-010-405-080 CAP, ELECT 10-50V
C439 87-010-401-010 CAP, ELECT 1-50V
C442 87-010-405-080 CAP, ELECT 10-50V
C455 87-010-194-080 CAP, CHIP 0.047
CF1 82-785-747-080 CF,MS2 GHY,R
CF2 82-785-747-080 CF,MS2 GHY,R
CF3 82-785-747-080 CF,MS2 GHY,R
CF4 87-A91-094-010 FLTR,CDA10.7 MG80A
CN210 87-049-919-010 CONN,3P EH V WHT
CN220 87-049-469-010 CONN,4P V
CN230 87-A60-915-010 CONN,16P H TSK-B16P-A1
CN260 87-A60-914-010 CONN,5P H TSK-B05P-A1
CN320 87-049-469-010 CONN,4P V
CN330 87-099-565-010 CONN,6P TUC-P4P-B1
CN410 87-049-469-010 CONN,4P V
CN420 87-009-030-010 CONNECTOR 2P PH M
D3 87-A40-616-070 VARI-CAP,SVC384(S/T)
D4 87-A40-615-070 VARI-CAP,KV1311NT
D5 87-A40-615-070 VARI-CAP,KV1311NT
J301 87-009-216-010 JACK, DIA 3.5
L2 87-A50-347-010 COIL,FM BPF EX
L3 87-A91-095-010 BAR-ANT,MW FOR 2B(SYN)
L4 87-A50-420-010 COIL,MW OSC(SYN)
L5 87-A50-424-010 COIL,FM RF EX(SYN)
L6 87-A50-427-010 COIL,FM OSC EX(SYN)<HR>
L6 87-A50-454-010 COIL,FM OSC U(SYN)<LH,HA>
L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)
L8 87-005-849-080 COIL,10UH(CECS)
L9 87-005-849-080 COIL,10UH(CECS)
L301 87-005-847-080 COIL,2.2UH(CECS)<HR>
L401 87-007-342-010 COIL,OSC 85K BIAS
R290 87-029-124-090 RESISTOR, FUSE 1/4W 2.2
S301 87-A90-815-010 SW,PUSH 2-2-6 SPUN19-S-501
TC1 87-011-220-080 TRIMMER CAP 20P VTC
X1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
FRONT C.B
CN620 87-099-761-010 CONN,23P H 9604
CN640 87-A60-076-010 CONN,12P H 9604S-12F
D643 87-A40-622-010 LED,L-34HDSL RED
D644 87-A40-622-010 LED,L-34HDSL RED
D645 87-A40-622-010 LED,L-34HDSL RED
D646 87-A40-622-010 LED,L-34HDSL RED
FFC2 8Z-CHB-620-010 FF-CABLE, 23P 1.25 140MM DISP
FFC3 8Z-CHB-619-010 FF-CABLE, 12P 1.25 140MM FRONT
LCD601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4
S601 87-A90-164-080 SW,TACT SKQAB(N)
S604 87-A90-164-080 SW,TACT SKQAB(N)
S605 87-A90-164-080 SW,TACT SKQAB(N)
S606 87-A90-164-080 SW,TACT SKQAB(N)
S607 87-A90-164-080 SW,TACT SKQAB(N)
MICOM C.B
C600 87-A11-067-080 C-CAP,S 1-10 K B
C601 87-010-313-080 CAP, CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-197-080 CAP, CHIP 0.01 DM
C605 87-010-318-080 C-CAP,S 47P-50 CH
C606 87-010-311-080 C-CAP,S 12P-50 CH
C607 87-010-317-080 C-CAP,S 39P-50 CH
C608 87-010-196-080 CHIP CAPACITOR,0.1-25
C609 87-010-384-080 CAP, ELECT 100-25V
C610 87-010-196-080 CHIP CAPACITOR,0.1-25
C611 87-010-385-080 CAP, ELECT 220-25V
C612 87-010-402-080 CAP, ELECT 2.2-50V
C613 87-010-196-080 CHIP CAPACITOR,0.1-25
C614 87-010-400-080 CAP, ELECT 0.47-50V
C615 87-010-401-080 CAP, ELECT 1-50V
C621 87-010-197-080 CAP, CHIP 0.01 DM
C623 87-010-197-080 CAP, CHIP 0.01 DM
C624 87-010-178-080 CHIP CAP 1000P
C625 87-010-178-080 CHIP CAP 1000P
C626 87-010-178-080 CHIP CAP 1000P
C627 87-010-178-080 CHIP CAP 1000P
C628 87-010-178-080 CHIP CAP 1000P
C629 87-010-178-080 CHIP CAP 1000P
C630 87-010-178-080 CHIP CAP 1000P
C651 87-010-405-080 CAP, ELECT 10-50V
CN610 87-099-761-010 CONN,23P H 9604
CN630 87-A60-076-010 CONN,12P H 9604S-12F
CN660 87-A60-916-010 CONN,5P B TSK-B05X-A1

7
CN670 87-A60-917-010 CONN,16P B TSK-B16X-A1
L601 87-003-102-080 COIL, 10UH
L603 87-005-847-080 COIL,2.2UH(CECS)
L604 87-005-847-080 COIL,2.2UH(CECS)
L605 87-005-847-080 COIL,2.2UH(CECS)
X601 87-030-273-010 VIB,XTAL 32.768K5PPM
X602 87-030-376-080 VIB,CER CSA5.76MG200
CD C.B
C501 87-010-197-080 CAP, CHIP 0.01 DM
C502 87-010-221-080 CAP, ELECT 470-10V
C503 87-010-221-080 CAP, ELECT 470-10V
C504 87-010-197-080 CAP, CHIP 0.01 DM
C506 87-018-209-080 CAP, CER 0.1-50V
C507 87-018-209-080 CAP, CER 0.1-50V
C508 87-A10-381-080 CAP,E 1000-10 RE
C509 87-010-197-080 CAP, CHIP 0.01 DM
C510 87-010-197-080 CAP, CHIP 0.01 DM
C511 87-010-263-080 CAP, ELECT 100-10V
C513 87-018-209-080 CAP, CER 0.1-50V
C514 87-018-209-080 CAP, CER 0.1-50V
C515 87-012-157-080 C-CAP,S 330P-50 CH
C516 87-010-545-080 CAP, ELECT 0.22-50V
C525 87-010-176-080 C-CAP,S 680P-50 SL
C527 87-010-186-080 CAP,CHIP 4700P
C528 87-012-156-080 C-CAP,S 220P-50 CH
C529 87-010-545-080 CAP, ELECT 0.22-50V
C530 87-012-140-080 CAP 470P
C531 87-010-374-080 CAP, ELECT 47-10V
C532 87-010-401-080 CAP, ELECT 1-50V
C533 87-010-184-080 CHIP CAPACITOR 3300P(K)
C535 87-010-145-080 C-CAP,S 1P
C536 87-010-312-080 C-CAP,S 15P-50 CH
C538 87-010-196-080 CHIP CAPACITOR,0.1-25
C539 87-010-404-080 CAP, ELECT 4.7-50V
C540 87-010-196-080 CHIP CAPACITOR,0.1-25
C541 87-010-405-080 CAP, ELECT 10-50V
C543 87-010-401-080 CAP, ELECT 1-50V
C545 87-010-197-080 CAP, CHIP 0.01 DM
C546 87-010-374-080 CAP, ELECT 47-10V
C547 87-010-263-080 CAP, ELECT 100-10V
C548 87-010-248-080 CAP, ELECT 220-10V
C549 87-010-198-080 CAP, CHIP 0.022
C550 87-010-374-080 CAP, ELECT 47-10V
C551 87-010-178-080 CHIP CAP 1000P
C552 87-010-197-080 CAP, CHIP 0.01 DM
C553 87-010-248-080 CAP, ELECT 220-10V
C554 87-010-263-080 CAP, ELECT 100-10V
C555 87-010-403-080 CAP, ELECT 3.3-50V
C556 87-010-197-080 CAP, CHIP 0.01 DM
C557 87-010-196-080 CHIP CAPACITOR,0.1-25
C558 87-010-197-080 CAP, CHIP 0.01 DM
C559 87-010-315-080 C-CAP,S 27P-50 CH
C560 87-010-263-080 CAP, ELECT 100-10V
C561 87-010-196-080 CHIP CAPACITOR,0.1-25
C562 87-010-196-080 CHIP CAPACITOR,0.1-25
C563 87-012-156-080 C-CAP,S 220P-50 CH
C564 87-018-121-080 CAP, CER 150P-50V
C565 87-010-263-080 CAP, ELECT 100-10V
C566 87-010-196-080 CHIP CAPACITOR,0.1-25
C569 87-010-404-080 CAP, ELECT 4.7-50V
C571 87-010-248-080 CAP, ELECT 220-10V
C572 87-010-196-080 CHIP CAPACITOR,0.1-25
C573 87-010-196-080 CHIP CAPACITOR,0.1-25
C574 87-018-134-080 CAPACITOR,TC-U 0.01-16
C575 87-010-312-080 C-CAP,S 15P-50 CH
C576 87-010-312-080 C-CAP,S 15P-50 CH
C578 87-018-209-080 CAP, CER 0.1-50V
C579 87-010-263-080 CAP, ELECT 100-10V
C582 87-010-196-080 CHIP CAPACITOR,0.1-25
C583 87-010-405-080 CAP, ELECT 10-50V
C584 87-012-156-080 C-CAP,S 220P-50 CH
C585 87-010-405-080 CAP, ELECT 10-50V
C586 87-012-156-080 C-CAP,S 220P-50 CH
C587 87-010-322-080 C-CAP,S 100P-50 CH
C588 87-018-209-080 CAP, CER 0.1-50V
C589 87-010-322-080 C-CAP,S 100P-50 CH
C590 87-010-322-080 C-CAP,S 100P-50 CH
C591 87-010-322-080 C-CAP,S 100P-50 CH
C592 87-010-322-080 C-CAP,S 100P-50 CH
C593 87-010-196-080 CHIP CAPACITOR,0.1-25
C594 87-010-178-080 CHIP CAP 1000P
CN510 87-099-554-010 CONN,6P TUC-P6X-B1
CN520 87-A60-424-010 CONN,16P V TOC-B
CN550 87-009-030-010 CONNECTOR 2P PH M
CNA510 87-099-554-010 CONN,6P TUC-P6X-B1
FFC1 8Z-CHB-622-010 FF-CABLE, 16P 1.0 150MM CD-RF
L501 87-003-102-080 COIL, 10UH
L502 87-008-372-010 FILTER, EMI BL OIRNI
L504 87-005-847-080 COIL,2.2UH(CECS)
L505 87-008-372-010 FILTER, EMI BL OIRNI
L506 87-003-102-080 COIL, 10UH
SFR501 87-024-176-080 SEMI-FIXED RESISTOR, 100K
X501 81-592-641-080 CERALOCK 16.93MHZ
KEY-R C.B
D641 87-A40-623-010 LED,L-34GDSL GRN
D642 87-A40-623-010 LED,L-34GDSL GRN
S608 87-A90-164-080 SW,TACT SKQAB(N)
S609 87-A90-164-080 SW,TACT SKQAB(N)
S610 87-A90-164-080 SW,TACT SKQAB(N)
KEY-L C.B
S613 87-A90-164-080 SW,TACT SKQAB(N)
S620 87-A90-164-080 SW,TACT SKQAB(N)
S621 87-A90-164-080 SW,TACT SKQAB(N)
POWER C.B
C901 87-A11-132-080 CAP,TC U 0.01-50 K B
C902 87-A11-132-080 CAP,TC U 0.01-50 K B
C903 87-A11-132-080 CAP,TC U 0.01-50 K B
C904 87-A11-132-080 CAP,TC U 0.01-50 K B
CN910 87-049-919-010 CONN,3P EH V WHT
!F901 87-A90-092-080 PROTECTOR,2.5A 491
BATT C.B
CD MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.

8
2SA1015
2SA1296
2SA1318
2SC1815
2SC1923
2SC2001
2SC2878
2SA933S
2SC1740S
DTC114TS
DTC114YS
DTC124ES
DTC124XS
2SB1370
2SJ103 DTC114TK
DTC124XK
E C B E C B B C E
S G D
E
C
B
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
TRANSISTOR ILLUSTRATION

9
IC DESCRIPTION
IC, LC78622ED
1
2
3
4
5
6
7
8
9
10
11
12, 13
14
15
16
17
18
19, 20
21
22
23
24-28
29
30
31
32, 33
34
35
36
37
38
39
40
41
42
DEFI
TAI
PDO
VVSS
ISET
VVDD
FR
VSS
EFMO
EFMIN
TEST2
CLV+, CLK–
___
V/P
HFL
TES
TOFF
TGL
JP+, JP–
PCK
FSEQ
VDD
CONT1-CONT5
EMPH
C2F
DOUT
TEST3, TEST4
N.C.
MUTEL
LVDD
LCHO
LVSS
RVSS
RCHO
RVDD
MUTER
I
I
O
—
I
—
I
—
O
I
I
O
O
I
I
O
O
O
O
O
—
I/O
O
O
O
I
—
O
—
O
—
—
O
—
O
Defect sense signal (DEF) input pin. (Connect to 0V when not used).
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Phase comparator output pin to control external VCO.
For PLL. GND pin for built-in VCO. Be sure to connect to 0V.
Pin to which external resistor adjusting the PD0 output current.
Power supply pin for built-in VCO.
Pin for VCO frequency range adjustment.
Digital system GND. Be sure to connect to 0V.
For slice level control. EFM signal output pin.
EFM signal input pin.
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Disc motor control output. Three level output is possible using command.
Rough servo or phase control automatic selection monitoring output pin. Rough servo
at H. Phase servo at L.
Track detect signal input pin. Schmidt input.
Tracking error signal input pin. Schmidt input.
Tracking OFF output pin.
Tracking gain selection output pin. Gain boost at L.
Track jump control signal output pin. Three level output is possible using command.
EFM data playback clock monitoring pin 4.3218 MHz when phase is locked in.
Sync signal detection output pin. H when the sync signal which is detected from EFM
signal and thesync signal which is internally generated agree.
Digital system power supply pin.
The pin is controlled by the serial data
command from microprocessor. When
General purpose input/output pin 1 to 5. the pin is not used, set the pin to the input
terminal and connect to 0V, or alternately
set the pin to output terminal and leave
the pin open.
De-emphasis monitor output pin. De-emphasis disc is being played back at H.
C2 flag output pin.
DIGITAL OUT output pin. (EIAJ format).
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Not used. Set the pin to open.
L-channel mute output pin.
L-channel 1-bit DAC. L-channel power supply pin.
L-channel output pin.
L-channel GND. Be sure to connect to 0V.
R-channel GND. Be sure to connect to 0V.
R-channel 1-bit DAC. R-channel output pin.
R-channel power supply pin.
R-channel mute output pin.
Pin No. Pin Name I/O Description

10
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
XVDD
XOUT
XIN
XVSS
SBSY
EFLG
PW
SFSY
SBCK
FSX
WRQ
RWC
SQOUT
COIN
___________
CQCK
________
RES
TST11
16M
4.2M
TEST5
______
CS
TEST1
—
O
I
—
O
O
O
O
I
O
O
I
O
I
I
I
O
O
O
I
I
I
Crystal oscillator power supply pin.
Pin to which external 16.9344 MHz crystal oscillator is connected.
Crystal oscillator GND pin. Be sure to connect to 0V.
Subcode block sync signal output pin.
C1, C2, single and dual correction monitoring pin.
Subcode P, Q, R, S, T, U and W output pin.
Subcode frame sync signal output pin. Falls down when subcode enters standby.
Subcode read clock input pin. Schmidt input. (Be sure to connected to 0V when not in
use.)
Pin outputting the 7.35 kHz sync signal which is generated by dividing frequency of
crystal oscillator.
Subcode Q output standby output pin.
Read/write control input pin. Schmidt input.
Subcode Q output pin.
Command input pin from microprocessor.
Command input read clock or subcode read input clock from SQOUT pin
LC78622 reset input pin. Set this pin to L once when the main power is turned on.
Test signal output pin. Use this pin as open (normally L output).
16.9344 MHz output pin.
4.2336 MHz output pin.
Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V.
Chip select signal input pin with built-in pull-down resistor. Be sure to connect to 0V
while it is not controlling.
Test signal input pin without built-in pull-down resistor. Be sure to connect to 0V.
Note: The same potential must be applied to the respective power supply terminals. (VDD, VVDD, LVDD, RVDD, XVDD)
Pin No. Pin Name I/O Description

11
IC DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30, 31
32, 33
34
35
FIN2
FIN1
E
F
TB
TE–
TE
TESI
SCI
TH
TA
TD–
TD
JP
TO
FD
FD–
FA
FA–
FE
FE–
AGND
SP
SPI
SPG
SP–
SPD
SLEQ
SLD
SL–, SL+
JP–, JP+
TGL
TOFF
I
I
I
I
I
I
O
I
I
I
O
I
I
I
O
O
I
I
I
O
I
—
O
I
I
I
O
I
O
I
I
I
I
Pin to which external pickup photo diode is connected. RF signal is created by adding
with the FIN1 pin signal. FE signal is created by subtracting from the FIN1 pin signal.
Pin to which external pickup photo diode is connected.
Pin to which external pickup photo diode is connected. TE signal is created by
subtracting from the F pin signal.
Pin to which external pickup photo diode is connected.
DC component of the TE signal is input.
Pin to which external resistor setting the TE signal gain is connected between the TE pin.
TE signal output pin.
TES “Track Error Sense” comparator input pin. TE signal is passed through a band-
pass filter then input.
Shock detection signal input pin.
Tracking gain time constant setting pin.
TA amplifier output pin.
Pin to which external tracking phase compensation constants are connected between
the TD and VR pins.
Tracking phase compensation setting pin.
Tracking jump signal (kick pulse) amplitude setting pin.
Tracking control signal output pin.
Focusing control signal output pin.
Pin to which external focusing phase compensation constants are connected between
the FD and FA pins.
Pin to which external focusing phase compensation constants are connected between
the FD– and FA– pins.
Pin to which external focusing phase compensation constants are connected between
the FA and FE pins.
FE signal output pin.
Pin to which external FE signal gain setting resistor is connected between the FE pin.
Analog signal GND.
Single ended output of the CV+ and CV– pin input signal.
Spindle amp input.
Pin to which external spindle gain setting resistor in 12 cm mode is connected.
Pin to which external spindle phase compensation constants are connected together
with SPD pin.
Spindle control signal output pin.
Pin to which external sled phase compensation constants are connected.
Sled control signal output pin.
Sled advance signal input pin from microprocessor.
Tracking jump signal input pin from DSP.
Tracking gain control signal input from DSP. Low gain when TGL = H.
Tracking off control signal input pin from DSP. Off when TOFF = H.
IC, LA9241ML
Pin No. Pin Name I/O Description

12
36
37
38
39, 40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
TES
HFL
SLOF
CV–, CV+
RFSM
RFS–
SLC
SLI
DGND
FSC
TBC
NC
DEF
CLK
CL
DATA
CE
DRF
FSS
VCC2
REFI
VR
LF2
PH1
BH1
LDD
LDS
VCC1
O
O
I
I
O
I
O
I
—
O
I
—
O
I
I
I
I
O
I
—
—
O
I
I
I
O
I
—
Pin from which TES signal is output to DSP.
“High Frequency Level” is used to judge whether the main beam position is on top of
bit or on top of mirror.
Sled servo off control input pin.
CLV error signal input pin from DSP.
RF output pin.
RF gain setting and EFM signal 3T compensation constant setting pin together with
RFSM pin.
“Slice Level Control” is the output pin which controls the RF signal data slice level by
DSP.
Input pin which control the data slice level by the DSP.
Digital system GND.
Output pin to which external focus search smoothing capacitor is connected.
“Tracking Balance Control” EF balance variable range setting pin.
No connection.
Disc defect detector output pin.
Reference clock input pin. 4.23 MHz of the DSP is input.
Microprocessor command clock input pin.
Microprocessor command data input pin.
Microprocessor command chip enable input pin.
“Detect RF” RF level detector output.
“Focus Search Select” focus search mode (±search/+ search) select pin.
Servo system and digital system Vcc pin.
Pin to which external bypass capacitor for reference voltage is connected.
Reference voltage output pin.
Disc defect detector time constant setting pin.
Pin to which external capacitor for RF signal peak holding is connected.
Pin to which external capacitor for RF signal bottom holding is connected.
APC circuit output pin.
APC circuit input pin.
RF system Vcc pin.
Pin No. Pin Name I/O Description

13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 ~24
25
26
27
28
29 ~ 40
41
42
43 ~ 44
45 ~ 50
51 ~ 54
55
56
57
58
59
60
61 ~ 63
64 ~ 66
67
O-RMC
O-DATA
O-CLK
–
O-CLKSFT
I-HOLD
_______
I-RST
XT1
XT2
VSS1
CF1
CF2
VDD1
FM ST.
I-KEY0
I-CDSW
I-KEY1
I-MOTOR
I-REC
–
I-TUDO
–
O-INT
I-DRF
I-WRQ
I-REMO
S0 ~ S11
VDD3
VSS3
S12 ~ S13
S16 ~ S21
–
O-CD LED
O-TU LED
–
O-ROCK LED
O-POP LED
O-JAZZ LED
–
COM0 ~ COM2
–
O
O
O
–
O
I
I
I
O
–
I
O
–
I
I
I
I
I
I
–
I
–
O
I
I
I
O
–
–
O
O
–
O
O
–
O
O
O
–
O
–
CD read/write control and TU chip enable
Data for shift register 2092, PLL LC72121 and IC M62439.
Clock for shift register 2092 and PLL LC72121.
Not connected.
Clock shift output for system microprocessor
Hold status detection. "H": HOLD
Microprocessor reset. ("L" when reset)
Connected to 32.768kHz crystal.
GND
Connected to 6 MHz ceramic lock.
Microprocessor power supply (µ-com 5 V).
FM stereo detection input.
Key AD input.
CD tray open/close status detection input (AD)
Operation key A/D input.
DECK mechanism motor control input.
Tape record detection input.
Not connected.
Data input from tuner LC72121.
Not connected.
Initial diode matrix detection output.
CD (DETECT RF) RE level detection input.
CD subcode Q standby input.
Remote input.
LCD common output.
Microprocessor power supply (µ-com 5 V).
GND.
LCD segment outputs.
LCD segment outputs.
Not connected.
CD LED ON/OFF output.
RADIO LED ON/OFF output.
Not connected.
ROCK LED ON/OFF output.
POP LED ON/OFF output.
JAZZ LED ON/OFF output.
Not connected.
LCD common outputs.
Not connected.
IC, LC867132V-5H52
Pin No. Pin Name I/O Description

14
–
–
O
O
O
–
O
–
O
–
O
I
O
Pin No. Pin Name I/O Description
68
69
70
71
72
73
74
75
76
77
78
79
80
VSS2
VDD2
O-CD ON
O-TU ON
O-P CONT
–
O-MUTE
–
O-BEAT CONT
–
O-COIN
I-SQOUT
D-CQCK
GND.
Microprocessor power supply.
CD power supply control output.
Tuner power supply control output.
Unit power control output.
Not connected.
Main muting output.
Not connected.
AM record beat control output.
Not connected.
CD command output.
CD subcode Q input.
Clock for CD command and subcode.

15
IC BLOCK DIAGRAMS
IC, M62495FP IC, TA8227P
IC, TA2104AN

16
IC, LC72121M
IC, MM1434XF
IC, BA6898S

1817
SCHEMATIC DIAGRAM-1 (MAIN-TUNER SECTION)
IF GAIN
CONT.
IF GAIN
CONT.
LH,HA :0.022
HR :0.015
R74
180
C20 4.7/50
C49 470p
LH,HA C95 0.01

2019
SCHEMATIC DIAGRAM-2 (MAIN-EQ AMP, POWER, BATT, KEY-L, R SECTION)
MAIN MUTE
+
+
–
–
Q430~433
REC/PB BIAS SW
Q434
DTC124
ES
R468 1K D413
1N4148
D412
1N4148
R462
4.7K
R461
4.7K
R467
4.7K R465
10K
R466
10K
R237
12K
R240
1.8K
D225
HZ7B3L
C415
22/10
C422
22/10
Q222
2SA933AS
Q223
DTC124XS
R235
10K
R234
47K
D221 1N4148
D220 1N4148
F901
2.5A
220V
240V
110V
120V
SW901
AC VOLTAGE
AC110–120V/220–240V
50/60Hz
R327
18K
R333
18K
L301 2.2µH
HR
LH,HA

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
2221
WIRING-1 (MAIN, FRONT, MICOM, KEY-L, R SECTION)
3
IC260
S301
S301
Q SOUND
ON/ OFF
C220
C202
CN210
CN210
Q202
R338
R360
J301
J301 CN320 C346
IC303
CN220
CN220
To DECK
R239 C431
Q403
Q401
Q409
C442
D411
Q410
Q433 Q432
Q406 C427
CN420
Q411
R312
R402
C351 IC430
R428
Q430
Q434
Q431
R462
R431
CN410
R426D410
D406
R420R422
Q207
Q206
Q420
C45
IC2
R20
R22 R23
C35 C42
C41
C43
C49
C39 C36
L9 D6 TP1(VT)
R25
C27
C29
R17
C19
L8
CF3
C18
C46
R9
C25
L4
IC1
D3
R6 C48
R8
C3
C17 TM4
R72Q71
Q1
R13
C47
CF1 Q72
C71
R74
TM3
C1
TM5
R4
TM2
TM1
Q611 Q612
C96
R2
R31
C15
R38
R16
R34
C99
Q421
D407
IC301
Q407
C418
C419
C412
C410
C411
C415
C414
Q408
D405
C318
CN330
C303
C423
C416
R333
R327
C325
C329
C339
C334
R308
R309
C305
C407
C401
C404 TP401
C210
R272
C345 Q223
C348
C265
C264
C263
R261
R262
C262
Q201
R238
Q225
Q222
R206
C206
C230
D205
D220
R361
C343
C349
C344
R339
C347
C350
C342
R329
C338
C336 C355 R335
C341
C337
C211
C212
R290
R211Q271 R241
Q204
C204
R467
R408
R453
R452
R455
R456
R465
R466
R464
R468
R454
R457
C320
R441
R318
C307
C306
R304
C304
C313
R447 C439
R320
C323
C328
C310
C326
C311
C309
C314
R423
R414
C417
R417
C413
R418
R425
R424
R419
D408
R355
C316
C301
C315
C302
R223
R446
C438
R310
R306
R352
R303
C317 C432
R605
D403
D402
C405
R323
R322
R305
R301 R324
R325
C408
R404
R317
C319
C330
C331
R302
C308
D301
R307
C312
R351
R350 R353
R354
C332
R443
R442
C434
C433
R430
C455
R440
R438
R463
R461
C333
C437
R445
C421
C420
R415
R416 R410
R412
R222
R71
X1 C38
R27
R28
C44
C37
C40
R24
R29
R30
R26
R91
R15
C28
R14
C31
R21
C20
C30
C24
C16
C11
R32
C7
R634
R633
D4
C10
C2
C72
R75
R73 C73
R1
D2
D1
R10
CF2
L7
C21
R12
R11
C22
TC1
C6
R3
C5
CF4
R19
C34
C33
R18
C436
R444
R433
C322
R316
R315
R314
R437
R439
R413
R411
R427
R432
R434
C428
C435
C424
C213
R220
R221
R472
R471
C422
R313
R436
C426
C425
R429
C430
R435
C429
C321
C406
R451
D206
Q226
Q270
R264
R230
R263
C335
R330
R331
R332
R328
C340
D222
R233
R231
Q210 Q211
R232
C231
D225
R240
R203
C205
D204
C233
Q302
Q301
R334
C232
R201
D201
C203
D202
R202
Q203
D203
R311
R204
R236
Q205
R205
D261
C261
1
31
1
5
1
3
7
4
2
6
1
134
3
12 10
46
97
3
4
13 13 65
E
C
B
E
C
B
E
C
B
B
C
E
B
C
E
E
C
B
B
C
E
E
C
BB
C
E
B
C
E
E
C
B
E
C
B
B
C
E
B
C
E
B
C
EE
C
B
E
C
B
B
C
E
E
C
B
B
C
E
B
C
E
B
C
E
B
C
E
B
C
E
S
G
D
S
G
D
B
C
E
E
C
B
B
C
E
B
CE
E
C
B
E
C
B
B
C
E
B
C
E
B
C
E
Q260
R234
R235
R237
D221
D412
D413
1615 13 11 9 7 5 3 1
12
CN230
B
CE
135
CN260
134
65 13
143
578
1
3
5
7
9
11
12
13
15
17
19
21
23
24
12
131517192124
1
135
7
91112
13 15 17 19 21 2324
357911
IC302
13578
911131516
IC420
587
134
C40
C95
L5
R33
C8
L2
E
C
B
E
C
B
WHT
PNK
GRN
GRN
RED
PNK
BLK RED
BLK
B
C
E
EB
C
E
B
C
E
B
C
EB
C
1
1212 10
6
211
5
9
11
1615 13 11 9 7 5 3 1
1
1
23
3
5
3579
1
2
6
10
14
18
5
9
13
17
23
21
22
CN630
Q604
C612
C613
R603 R675
R673 R674
R655 R656
D602
Q603
CN670
R652
R658
R662
R663
R667
R668
R670
R669
R678
R677
Q602
Q651
Q652
R651
R615
R639
L605
L601
C609
C608 C621
CN660
C605
X601
X602 C603
C602
C607 R621 C600
IC601
CNA680
13579
R614
D651
C615
R602
D603
FFC3
D604
C611
D605
R604
R601
C614
C610
R613
C651
R608
R625
R619
R618
R672
C606
R612 L604
R635
R610
R609
R631
R679
R671
C627
R661
R659
R657
CN610
FFC2
C623
C630
C629
C628
C626
D627
D623
C625
C624
R607
L603
C601
RED
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
To D CD C.B
CN530
To D CD C.B
CN510
15 10152024
41
45
50
55
60
64
25303540
65
70
75
80
C MICOM C.B
F KEY-L C.B
A MAIN C.B
1
5
9
11 12
10
6
2
CN640
S601
S601
S605
R645 R644Q623
Q624
D644
D644
ROCK D646
POP D645
JAZZ D643
OPE/BATT
D646
D645 D643 S604
S607
Q625
LCD601
LCD601
(DISPLAY)
S606
R642
R641
R640
R643
FFC3
R636
R637
R638
SLEEP/REPEAT/
FM MODE/OSC
1357911131517192123
23
6
2
10
14
18
22 21
17
13
9
5
1
23
1
CN620
FFC2
EB
C
BE
C
BE
C
1
12
B FRONT C.B
S605
SKIP/SEARCH
/TUNE +
S606
SKIP/SEARCH
/TUNE -
S604
STOP/MEMORY
/SLEEP
S607
PLAY/PUASE
R319
R321
R326
FM ANT.
L3
(AM BAR ANT.)
To DECK
CN410
To DECK
CN420
To G POWER C.B
CNA920
13
S621 R660
R650
S620
S613
S613
3-MODE
EQUALIZER
S620
VOLUME
S621
VOLUME
RED
BLK
ORG
BLK
134
SP1
LCH
SPEAKER
()
SP2
RCH
SPEAKER
()
S610 S610
POWER
STANDBY/
TAPE RADIO/
BAND
D642 D642,
S608
D641,
S609
D641
R646
R648
R649
R653
R647
S608
S609
1356
CD
E KEY-R C.B
L401
63
41
321
46
L6
D5
C12
C13
C14
43
61
C50
L301
R632
<HR> <LH, HA>
<LH, HA>
<LH, HA>

2423
ELECTRICALADJUSTMENT
<TUNER SECTION>
1. FM VT Adjustment
Settings: • Test point: TP1 (VT)
• Adjustment location: L6
Method: Set to FM 108.0 MHz and adjust L6 so that the test
point becomes 5.6 V ±0.2 V.
2. FM Tracking Adjustment
L5 ............................................................................... 90.0 MHz
3. AM VT Adjustment
Settings: • Test point: TP1 (VT)
• Adjustment location: L4
Method: Set to AM 1710 kHz and adjust L4 so that the test
point becomes 6.0 V ±0.2 V.
4. AM Tracking Adjustment
L3................................................................................. 600 kHz
TC1 ............................................................................ 1400 kHz
L5 L6
L4
L3
L401
TP401 C404
C36 C39
IC1 IC2
TC1
13
24
TP1(VT)
6
A MAIN C.B (PARTS SIDE VIEW)
J301
<DECK SECTION>
5. Head Azimuth Adjustment
Settings: • Test tape: TTA-320
• Test point: J301 (Phones jack)
• Adjustment location:
Head Azimuth Adjustment Screw
Method: Play back the 8 kHz signal of test tape and adjust screw
so that the output becomes maximum.
6. Bias OSC Fequency Adjustment
Settings: • Test point: TP401
• Adjustment location: L401
Method: Set to recording mode and adjust L401 so that the test
point becomes 85 kHz ±1 kHz
PRACTICAL SERVICE FIGURE
<TUNER SECTION>
<FM SECTION>
IHF Sensitivity: Less than 18 dB
(THD 3 %) [at 87.5/98.0/108.0 MHz]
Signal to noise ratio: More than 58 dB
(Input - 54 dB) [at 98.0 MHz ]
Distortion: Less than 3.0%
(Input - 54 dB) [at 98.0 MHz]
Stereo separation: More than 20 dB
[at 98.0 MHz]
Intermediate frequency: 10.7 MHz
<AM SECTION>
Sensitivity: Less than 50 dB
(S/N 10 dB) [at 600 kHz]
Less than 48 dB
[at 1000 kHz]
Less than 44 dB
[at 1400 kHz]
Signal to noise ratio: More than 34 dB
(Input -74dB) [at 1000 kHz]
Distortion: Less than 1.5%
(Input -74 dB) [at 1000 kHz ]
Intermediate frequency: 450 kHz
<DECK SECTION>
Tape speed: 3000 Hz ±60 Hz
Wow & flutter: Less than 0.35%
(JIS RMS)
Take-up torque: 30 ~ 60 g-cm
F.F & REW torque 55 ~ 140 g-cm
Back tension: 1 ~ 5 g-cm
S/N ratio: More than 50 dB
(PB, SP OUT, DC)
More than 44 dB
(PB, SP OUT, AC)
Distortion: Less than 2.0%
(PB, SP OUT, DC)
Less than 2.5%
(R/PB, SP OUT, DC)
Noise level Less than 20 mV
(PB, SP OUT, VOL MAX, AC)
Less than 25 mV
(R/PB, SP OUT, VOL MAX, AC)
Other manuals for CSD-ED27
4
This manual suits for next models
6
Table of contents
Other Aiwa Cassette Player manuals
