SERVICE MANUAL
DATA
STEREO CASSETTE PLAYER BASIC TAPE MECHANISM : CL-860 D-GRY
HS-GMX45
HS-GMX50
Y
Y
S/M Code No. 09-016-447-1R1
•This Service Manual is the “Revision Publishing” and replaces “Simple Manual” of
HS-GMX45 / 50 (Y), (S/M Code No. 09-015-447-1T1).
REVISION
SIMPLE-2
Apartofcontentsisadequate.
Re-issuing is under request.

– 2 –
SPECIFICATIONS
ACCESSORIES / PACKAGE LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
Maximum output
Speaker: 4 mW + 4 mW (EIAJ / 16 ohms)
Load impedence
16 - 80 ohms
Power sources
DC 3 V using two R6 (AA) dry cell batteries, AC house current using
the optional AC adaptor AC-D302.
Battery life: (EIAJ, 0.2 mW output)
Approx. 30 hours using two LR6 (AA) alkaline batteries
Maximum outside dimensions
80.1 (W) X 111 (H) X 26.3 (D) mm (excluding projecting parts and controls)
(31/4x 43/8x 11/16 in.)
Weight
Approx. 128 g (4.5 oz) (excluding batteries)
1 8A-HKF-951-010 RC UNIT, RC307 <GMX50>
2 87-B30-482-010 HEADPHONE,HP-M041(T2)SP <GMX50>
3 87-B30-483-010 HEADPHONE,HP-M007(T2)SP <GMX45>
4 8B-HKF-905-010 IB,Y(EGFSI)C 50 <GMX50>
4 8B-HKF-906-010 IB,Y(EDPHNC)C 50 <GMX50>
4 8B-HKF-915-010 IB,Y(EGFSI)C 45 <GMX45>
4 8B-HKF-916-010 IB,Y(EDPHNC)C 45 <GMX45>
• Design and specifications are subject to change without
notice.

KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 3 –
ELECTRICAL MAIN PARTS LIST
IC
87-002-677-080 IC,TA2002F
87-A20-532-140 C-IC,LB1977M-TLM
87-A21-926-040 C-IC,TMP47C443LDM-3B80(EL)
87-A21-566-040 C-IC,S-80820ANNP
87-A21-565-040 C-IC,S-80817ANNP
TRANSISTOR
89-327-125-080 C-TR,2SC2712GR
87-A30-085-040 C-TR,CSA1362GR
87-026-581-080 C-TR,RN2405
87-026-267-080 C-TR,RN2407
DIODE
87-A40-822-040 C-DIODE,CRS01
MAIN C.B
C101 87-012-273-080 C-CAP,U 820P-50 K B
C102 87-012-273-080 C-CAP,U 820P-50 K B
C103 87-012-273-080 C-CAP,U 820P-50 K B
C104 87-012-273-080 C-CAP,U 820P-50 K B
C105 87-012-276-080 C-CAP,U 1500P-50 K B
C106 87-012-276-080 C-CAP,U 1500P-50 K B
C107 87-A10-488-010 CAP,E 47-4 7L SR
C108 87-A10-488-010 CAP,E 47-4 7L SR
C111 87-010-419-010 CAP,E 4.7-16 M 5L SRE
C112 87-012-142-080 C-CAP,S 0.33-16 Z F
C113 87-010-805-080 C-CAP,S 1-16 Z F
C114 87-016-396-080 C-CAP,U 0.22-16 F
C117 87-012-278-080 C-CAP,U 2200P-50 K B
C118 87-012-278-080 C-CAP,U 2200P-50 K B
C119 87-010-831-080 C-CAP,U 0.1-16 Z F
C120 87-010-831-080 C-CAP,U 0.1-16 Z F
C121 87-010-502-010 CAP,E 100-4 M KS
C122 87-A10-489-010 CAP,E 220-4 7L SR
C123 87-010-502-010 CAP,E 100-4 M KS<GMX50>
C124 87-010-502-010 CAP,E 100-4 M KS<GMX50>
C125 87-A10-488-010 CAP,E 47-4 7L SR
C127 87-010-805-080 C-CAP,S 1-16 Z F
C128 87-010-805-080 C-CAP,S 1-16 Z F
C303 87-010-196-080 C-CAP,S 0.1-25 Z F
C304 87-010-196-080 C-CAP,S 0.1-25 Z F
C401 87-A10-201-080 C-CAP,S 0.33-16 K B
C403 87-010-196-080 C-CAP,S 0.1-25 Z F
C404 87-016-526-080 C-CAP,S 0.47-16 BK
C405 87-010-992-080 C-CAP,S 0.047-25 K B
C406 87-010-831-080 C-CAP,U 0.1-16 Z F
C407 87-010-992-080 C-CAP,S 0.047-25 K B
C408 87-010-992-080 C-CAP,S 0.047-25 K B
C409 87-010-992-080 C-CAP,S 0.047-25 K B
C410 87-010-831-080 C-CAP,U 0.1-16 Z F
C701 87-010-831-080 C-CAP,U 0.1-16 Z F
C702 87-012-141-080 C-CAP,S 0.22-16 Z F
C703 87-012-141-080 C-CAP,S 0.22-16 Z F
C705 87-010-831-080 C-CAP,U 0.1-16 Z F
C707 87-010-196-080 C-CAP,S 0.1-25 Z F
C708 87-010-831-080 C-CAP,U 0.1-16 Z F
C709 87-010-831-080 C-CAP,U 0.1-16 Z F
C710 87-010-831-080 C-CAP,U 0.1-16 Z F
C714 87-010-831-080 C-CAP,U 0.1-16 Z F
C731 87-010-831-080 C-CAP,U 0.1-16 Z F
C801 87-A10-489-010 CAP,E 220-4 7L SR
D601 87-A91-355-040 C-LED,BR1112H-TR-RED
J101 87-A60-438-010 JACK,3.5 BLK ST W/O SW<GMX45>
J101 87-A60-437-010 JACK,3.5 BLK ST W/O SW<GMX50>
J801 87-A61-124-110 JACK,DC DIA2.75 BLK TC
PS501 87-A92-120-010 SNSR,PHOTO EL-ITR8307T21F43
R713 87-022-245-080 C-RES,U 18K-1/16W F
R714 87-022-245-080 C-RES,U 18K-1/16W F
R738 87-010-805-080 C-CAP,S 1-16 Z F<GMX45>
S301 87-A90-050-010 SW, SL 2-2-2 NS (BLK)
S701 87-A91-780-180 C-SW,TACT LS15B3T
S702 87-A91-780-180 C-SW,TACT LS15B3T
S703 87-A91-780-180 C-SW,TACT LS15B3T
S704 87-A91-780-180 C-SW,TACT LS15B3T
S705 87-036-379-280 C-SW,SL 1-1-2 SS-350-A12B-C-T
S706 87-A91-365-080 C-SW,PUSH 1-1-1 SPVG21
SFR401 87-A91-653-040 C-SFR,K 33K H RH03AEC
TH401 87-A91-675-080 C-THMS,NTH5G16P39B472K 07TH
VR101 87-A92-047-010 VR,RTRY 20KCX2 H XV010702GPV1N
X701 87-A70-241-010 VIB,CER 4.000MHZ CSTS0400MG03
HEAD FLEX C.B
PH 8B-HR7-606-010 HEAD ASSY, CL-860
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W

KANRI
NO.
REF. NO. DESCRIPTIONPART NO.KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
– 4 –
TRANSISTOR ILLUSTRATION
2SC2712GR
CSA1362GR
RN2405
RN2407
BE
C

WIRING (MAIN / HEAD FLEX)
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
 5 
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U

 6 
SCHEMATIC DIAGRAM (MAIN / HEAD FLEX)

 7 
IC BLOCK DIAGRAM

– 8 –
Pin No. Pin Name I/O Description
1 XOUT O
Oscillator connection terminal (4MHz ceralock).
2 XIN I
3 RESET I Reset signal input.
4 EJECT SW I EJECT SW input. EJECT L
5 BUZR O Buzzer sound (pulse) output.
6 TEST I TEST (mechanism strength test) mode input. TEST H (Connected to GND)
7 HOLD I MAIN key HOLD SW input. HOLD L
8NC—Connected to GND.
9 L.V. STOP I Reduced voltage detection input. L.V. L
10 MAIN IN I MAIN key input (A/D).
11 REMOTE IN I REMOTE key input (A/D).
12 MOT HI O Motor high-speed initialization output. ON H
13 NC — Not connected.
14 POWER ON O AUDIO system power supply output. ON L
15 GND — Power supply terminal (0V).
16 PHOTO OUT O P-SNSR (tape rotation detection) waveform monitor ouput.
17 LOAD CTL O Current voltage check output. ON L
18 MOT ON O Motor initialization output. ON L
19 MOT DIR O Motor rotating direction output. CW H, CCW L
20 BRAKE O Motor break output. ON H
21 NC — Not connected.
22 MOT CH I Motor initialization detection output. Motor initializing L (50msec)
23 NC — Connected to GND.
24 P–SNSR I P-SNSR (tape rotation detection) waveform input.
25 C–SW I Cassette detection input. Cassette inserted L (Connected to GND)
26 AUTO SW I AUTO operation judgment input. No AUTO operation L
27 F/R CTRL O FWD/REV control output. FWD H, REV L
28 MUTE O Muting output. ON L
29 WAKE UP I Microcomputer HOLD (edge release mode) release input.
30 VDD I Power supply terminal (+3V).
IC DESCRIPTION
IC, TMP47C443LDM – 3B80(EL)

– 9 –
ADJUSTMENT
<TAPE PLAYER SECTION>
1. Tape Speed (4.8cm/sec) Adjustment
Settings : • Test tape : TTA - 100 (TAPE CENTER)
• Test point : PHONES JACK (J101)
• Adjustment location : SFR 401
• Super bass : OFF
• Volume : MAX
Method : Play back the test tape and adjust SFR 401 so that the
frequency is 3010 Hz ±10 Hz (FWD) and FWD SPEED
±50 Hz (REV). Then confirm WOW is less than 0.52%.

– 10 –
MECHANICAL EXPLODED VIEW 1 /1
A
A
2
3
1
4
5
6
B
PLATE,SPEC
23
F
F
24 7
C
C
22
E
G
C21
17
18
19
20 26
25
27
28
12
MECHA SA
8
10 9
11
PWB
A
A
A
A13
14
C
C
C
C
D
16
15
HS-GMX45Y1BSC,Y1BGC

– 11 –
MECHANICAL PARTS LIST 1 / 1
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8B-HR7-023-010 LID,ASSY YZ SIL<45Y1BSC,50Y1BSC>
1 8B-HKF-027-010 LID,ASSY GRN<45Y1BGC>
1 8B-HKF-029-010 LID,ASSY BLU<50Y1BLC>
2 8B-HR7-201-010 HLDR,CASS L
3 8B-HR7-005-110 WINDOW,CASS<EXCEPT 45Y1BGC>
3 8B-HKF-003-110 WINDOW,CASS GRN<45Y1BGC>
4 8B-HR7-202-010 HLDR,CASS R
5 8B-HR7-233-010 HINGE,ASSY
6 8B-HR7-221-010 SPR-P,EARTH
7 8B-HKF-201-010 HLDR,HP JACK
8 8B-HR7-220-010 HLDR,HINGE
9 8B-HKF-004-010 LID,BATT SIL<45Y1BSC,50Y1BSC>
9 8B-HKF-023-010 LID,BATT GRN<45Y1BGC>
9 8B-HKF-024-010 LID,BATT BLU<50Y1BLC>
10 8B-HR7-214-010 BAT-CONTACT,P
11 8B-HR7-237-110 SHAFT,BAT P
12 8B-HKF-208-010 BAT-CONTACT,M C
13 8B-HR7-231-010 SPR-C,EARTH C
14 8B-HKF-014-010 CABI,REAR SIL GMX45<45Y1BSC>
14 8B-HKF-015-010 CABI,REAR GRN GMX45<45Y1BGC>
14 8B-HKF-001-010 CABI,REAR SIL GMX50<50Y1BSC>
14 8B-HKF-018-010 CABI,REAR BLU GMX50<50Y1BLC>
15 8B-HKF-007-010 LENS,LED
16 8B-HR7-019-010 RING,DC
17 8B-HR7-002-010 PANEL,LOCK DG
18 8B-HR7-011-010 PANEL,OPEN L
19 8B-HR7-010-010 KNOB,RTRY OPEN
20 8B-HR7-012-010 PANEL,OPEN R
21 8B-HR7-207-010 GEAR,OPEN
22 8B-HR7-206-010 LEVER,OPEN
23 8B-HR7-205-010 PLATE,LOCK
24 8B-HR7-229-010 SPR-T,OPEN C
25 8B-HKF-006-010 KEY,CONT
26 8B-HKF-203-010 HLDR,KNOB HOLD
27 8B-HKF-005-010 PANEL,KEY
28 8B-HKF-008-010 KNOB,SL HOLD
A 8B-HR7-250-010 S-SCREW,+1.4-4.5-0.3 CR HL
B 87-067-288-010 HINGE SCREW +1.4-1
C 8B-HR7-251-010 S-SCREW,+1.4-3.5-0.3 CR HL
D 8A-HK5-218-010 S-SCREW,+1.4-3-0.4 CR NL
E 8B-HR7-252-010 S-SCREW,HINGE+1.4-2.5 CR HL
F 87-HK5-235-010 S-SCREW,1.4-0.6-2.5
G 87-067-388-010 S-SCREW,HINGE+1.4-1 BLK
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
LA Aqua Blue GL Light Green HT Transparent Gray
COLOR NAME TABLE

– 12 –
TAPE MECHANISM EXPLODED VIEW 1 /1
BB
31
31
32
23
35
34
30
27 27
27
25
25
4
5
6
8
7
9
26
18
18
A
A
A
29
28
324
1
2
17
1711
11
13
13
14
14
12
12
15
15
16
33
39
21
22
37
3610
19
20
38 10

– 13 –
TAPE MECHANISM PARTS LIST 1 / 1
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8B-HR7-001-010 FRAME CENTER
2 S8-605-100-000 FWD ARM
3 S8-605-110-000 REV ARM
4 S8-605-140-000 SUB CHASSIS ASSY
5 S8-605-070-000 GEAR PLATE
6 S8-605-060-000 FWD GEAR
7 S8-605-210-000 GEAR PLATE PIN
8 S8-505-220-000 FWD GEAR SP
9 S8-605-230-000 GEAR SHAFT
10 S8-605-330-000 FF GEAR 1
11 S8-605-370-000 RELL GEAR T
12 S8-605-080-000 CLUTCH GEAR
13 S8-605-390-000 FELT
14 S8-605-470-000 CLUTCH SP
15 S8-605-510-000 REEL GEAR BUSH
16 S8-505-290-000 REFLECTING PLATE
17 S8-605-260-000 BACK TENSION SP
18 S8-000-10B-000 REEL CAP
19 S8-605-360-000 FF CEAR HOLDER
20 S8-605-340-000 FF GEAR 2
21 S8-605-03K-000 FLY WHEEL R ASSY
22 S8-605-04K-000 FLY WHEEL L ASSY
23 S8-605-490-000 SPR-P,HEAD
24 8B-HR7-239-010 SPR-P,CASS
25 S1-6X2-5X0-2S0 SOMARAIT W
26 S8-605-380-000 CENTER GEAR
27 S1-15X-26X-025 L W CUT
28 M8-AZS-394-040 MOTOR
29 S8-605-450-000 LEAD WIRE 5P
30 S8-605-020-000 HEAD BASE ASSY
31 S8-605-170-000 PINCH ROLLER
32 8B-HR7-606-010 HEAD ASSY CL-860
33 SV-594-000-000 SUB BELT
34 S8-605-290-000 PINCH SP FWD
35 S8-605-300-000 PINCH SP REV
36 S8-605-320-000 STOPPER SP
37 S8-605-280-000 HEAD BASE SP
38 S8-605-350-000 FF SP
39 SV-582-700-000 MAIN BELT
A SB-TF1-7X5-0HO SCREW
B S3-PW1-4X5-000 SCREW

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:[phone]
Printed in Singapore2000068 9630472 921338
