Akai GXR-82 User manual

S/AJ c., 4 ^ 3
qR-8?-
/.rI iG\
STEREO CARTRIDGE RECORDER
OPERATOR'S MANUAL
THIS MANUAL IS ALSO APPLICABLE TO MODEL GXR-82D
STEREO CARTRIDGE DECK.
MANUFACTUREO & DISTRIBUTEO BY AKAI ELECTRIC CO., LTD./AKAI TRADING CO., LTD./AKAI AMERICA LTD.

CONNECTI(NS
FOR PLAYBACK
Make this connec
ml#H,i:J"'Jlil I I
RCA/RCA connectionl
cord A
STEREO AMPLIFIER
The Din Jack can be
used instead of the Line
Jacks. This enables re-
cording or playback
with a single Din/Din
connection cord. Model GXR-82 only
t
I\
t
t

FOR RECORDING
Turntable with magnetic
cartridge.
tl
Stereo tape deck
ot recorder.
Connect one of the desired sources
with an RCA/RCA connection cord
Record player with crystal
or ceramic pick-up.
back with a single Din/Din I
STEREO AMPLIFIER
6 lEl*lEoo
. FlooF-lou E@
Stereo tuner

Track System . .S-track 2-channel stereo
system
Tape Speed. . . .3-314 ips (xl.5%)
Wow & Flutter .Less than 0.25% RMS
at 3-314 ips
Equalization . .Correct equalization for play-
back of tapes recorded to the
NAB curve.
Frequency Response . .40 Hz to 17,000 Hz (t3 dB)
at 3-3i 4 ips
Output Power . 16 W total Music Power
(8w/8W)at8O
(GXR-82 only)
Signal-To-Noise
Ratio . .....Betterthan47dB
Erase Ratio . . .Better than 65 dB
Cross-Talk . . . .Better than 45 dB (stereo)
Heads . ......(2):Recording/playback
GX head, Erase head
Motor . ......(l): 2-speed 218-pole
induction motor
Fast Forward & Rewind
Time . .....Within 230secs.usinga
300 ft. tape
Recording Capacity . . .One hour stereo recording
using a 300 ft. cartridge tape
Output Jacks . .Line(2): 1.23Y (zeroYU)l
100 S-l (Required load imped-
ance: more than 20 kS))
Phone( 1): 30 mV/8 O
Speaker(2): 8 W/ 8 S) each
(GXR-82 only)
Input Jacks . . .Microphone(2):0.5 mYl4.1k9-
Lne(2):50 mV/500 kS)
DinJack. .....0.5V/5mV
Power Requirements . . 100 Y to 24OY A.C., 50/60 Hz
Dimensions . ..346(W)x 135(H)x 266(D)mm
( 13.6 x 5.3 x 10.5")
Weight . 8.6 ke ( 18.9 lbs) (cXR-82)
8.0 ke ( 17.6 lbs) (GXR-82D)
* For improvement purposes, specifications and design
are subject to change without notice.
GXR-82D
ConnectionCord. .......1
Spare Fuses 1 set
Operator'sManual .......1
GXR.82
Spare Fuses I set
Operator'sManual .......1
* Spare fuses not included with CEE, CSA, and UL Standard
models.
MANUFACTURED & DISTRIBUTED BY
AKAI ELECTRIC CO., LTD.
AKAI TRADING CO, LTD.
1 2-1 4, 2-chome, Higashi-Kojiya,
Ohta-ku, Tokyo, Japan
AKAI AMERICA, LTD.
2135 E. Del Amo Blvd., Compton, Calif., 90220, U.S.A
TELEPHONE: [phone]
TELEX:67-7494
s
m
o
Printed in Japan

This model employs Akai's GX recording and play-
back head for better signal-to-noise ratio' extended
high range frequency and a more dynamic ralge'
These features are contributable to the characteristics
of Akai's amaztngfocused-field recording system' The
core of the GX Head consists of a single crystallized
eiement which is mounted and set in glass of the same
hardness characteri.stics' The gem "single crystal" has
no composite particles to eventually separate and
cause head gap damage as the tape passes the head
surface, thus enabling Akai engineers to focus the
magnetic field into a sharp oblong radius' This
focused field system eliminates undue equalization'
minimizes high frequency loss and achieves a wider
;;;"-t. ranle. And GX performance is not just
temporary. It's ful1y maintained for iasting new
machine Performance.
TAPE
TRACK
CHANN EL
This model employs an 8-track 2-channel cartridge
stereo system. The tape has a total of 8-tracks' two of
which are used at a time for stereo performance'
When the first channel terminates, the second channel
is automatically set to position for continued ope-
,u,lorr. Thus, a 300 ft' cartridge tape accomodates
one hour of continuous performance' Desired channel
or program can be easily selected by manually
operating the Program Selector Button'
Your unit is equipped with a convenient Program
fnOi.uto. which enables confirmation of the program
in use. When a program terminates' the next program
i, urrtomati.ully positioned for contiluous operation'
To manually select programs' depress the Program
Selector Button.
t-
CYCLES
Correct tape speed cannot be obtained if the Cycle
lonu.rrion Switch Lever and Drive Belt are not
properlY Positioned'
Unscrew the 3 top panel holding-ltjtt*^t 1"d. rem^ove
VOLTAGE
Your machine is equipped with a universal voltage
,.ilt", "ff.ting six selections of voltage from-l 00 V
to 24OV AC for use anywhere in the world',Voltage
i, nt*., at the factory according to destination'
n.'ur. "orrfirm setting prior to operation and if
readjustment is necessary, proceed as followv
1. Disconnect power cord and remove the Fuse Post
by screwing in di'rection of arrow'
2. R.*ou" the Voltage Selector Plug and, reinsert so
that proper area voltage is shown through the
Plug cut-out'
3. Change fuse to correspond with voltage and
tn,* the Fuse Post' Refer t-o. fuse Tt-l:
i.n - n*.t. Them loosen 5Ol6OHz Switch Lever
n.iuti* t.*w, set Switch Lever to 50 or 60 Hz
position, and tighten holding screw'
lii", ,.i,-* Cycle Switch Ltutt' position drive beit
;;;;" "t cJrresponding pullev' For 50 Hz operation'
"oJtion beit in upper bracket and to run on upper
ffi';;'t;i.vt. e"t 60 Hz operation' position belt ir
iower bracket and to run on lower part of pulleys'
rse dePending uPon stan
structions for ProPer ft
dard area voltage.
+ To maintain optimum performance and prolong the life of
vorrr machine, ir is imporiJni tttui trt" line voltage be held
i'"'itrr" " 1 o% ieviation'of slandard area voltage'

Connect speakers to the Speaker Jacks as shown in
CONNECTIONS FOR PLAYBACK.
A. Connect power cord and depress Power Switch.
B. Insert cartridge into slot provided with groove
facing downward.
C. Depress Play Button.
D. Adjust Volume Controls.
E. Adjust Tone Controls.
* The Program Indicator Lamps will show which track is
being played. For changing program, operate the Program
Selector Button.
x At the end of each program, subsequent programs are
automatically positioned for playback.
Note: If a more poweriul output is desired, connect a stereo
power amplifier to the output jacks and a pair of
speakers to the amplifier as shown in CONNECTIONS
FOR PLAYBACK.
This model is equipped with an Automatic Stop/
Continuous Play Switch. When this switch is at Auto
Stop position, at the end of channel 4, the tape will
return to channel I position and stop automatically.
At this time, both channel 4 and channel I Indicator
Lamps will be lit. To continue operation, depress the
Stop Button and again depress Play Button. When
uninterrupted continuous playback is desired, set this
Switch to CONT'S PLAY Position. The tape will be
played over and over until the unit is tumed off.
Note: When the machine is set to recording or F,Fwd mode,
the tape will return to channel 1 position and
automatic stop will be effected regardless of position
of Automatic Stop/Continuous Play Switch.
Advances tape at fast speed for quick tune selection.
Note: * Fast forward will not function while machine is set
to Pause mode.
* To set cartridge tape to beginning of Program 1, set
to 4 ch position with Program Selector and fast
forward tape.
Connect desired program source to the appropriate
input of the GXR-82(D) as shown in CONNECTIONS
FOR RECORDING.
A. Connect power cord and depress Power Switch.
B. Depress Pause Button.
C. Insert cartridge into slot provided with groove
facing downward.
D. Simultaneously depress Rec and Play Buttons.
Recording Indicator Lamp will light to indicate
recording mode.
E. Adjust recording level with Volume Controls
while observing VU Meters. Normal recording
should not exceed "0" VU on either meter.
F. Release Pause Button to begin recording.
* When using new blank cartridge tape, the Program Selector
should be set to Program 1 before initiating recording
operation. When the tape comes to the end, the next
channel is automatically positioned for recording. Record-
ing time for each channel is 15 minutes with a 300 ft.
cartridge tape. Upon completion of recording on Program
4, the tape will return to Program I position and stop
automatically,
While the GX Head does not normally need cleaning,
if old tapes are used, periodical head cleaning is
recommended. Use Akai's Head Cleaning Pen or a
long cotton swab stick dipped in Akai Head Cleaning
fluid (from Head Cleaning Kit HC-500) or alcohol.
Caution: Do not use chlorothane or other such chemicals, as
the rubber parts will deteriorate.
Connect and extemal amplifier to the Line Outputs
and connect two speakers to the amplifier as shown
in CONNECTIONS FOR PLAYBACK.
A. Connect power cord and depress Power Switch.
B. Insert cartridge into slot provided with groove
facing downward.
C. Depress Play Button.
D. Adjust Volume Controls and adjust external
amplifier controls.
NOTE: FOR RECORDING WITH MODEL GXR-82D,
FOLLOW GXR-82 RECORDING PROCEDURE.

CONTROLS
OPERATING PRECAUTIONS
* Heads should always be ciean and free of dust.
* For optimum recording performance, it is im-
portant to use only new and first quality
magnetic tapes.
* Machine should always be set to proper area
voltage and cycles.
* When using microphones, in order to avoid
picking up outside disturbances or hum, place
microphone as close to the sound source as
possible.
* When loading cartridge tape, make sure that the
cartridge is properly set.
The following conditions do not mean mechanical
failure of your unit. If any of these conditions should
be exhibited, please check for the trouble as indi-
cated.
A. Loss of sensitivity and tone quality
* Dirty erase head. . . . Clean the heads.
x A.C. power voltage lower than the voltage to which
your unit is adjusted . . . . Check and re-adjust if
nec essary -
B. Will not play or record
* Machine set to Pause Mode.
* Faulty plug connection . . . Check the various con_
ne ctions.
* Switch or control at incorrect operating position.
* Cartridge inserted up-side-down-
C. Will not fast forward
x Machine set to Pause mode.
D. Distorted sound and reduced sound level
* Disconnect the power supply cord and check the
wiring of both speakers. Shorted wiring should of
course be corrected.
RECORD BUTTON
To effect recording mode, depress this button
and the Play Button simultaneously.
HEADPHONE JACK
For monitoring or private listening.
PROGRAM INDICATOR LAMPS
Indicates channel being used.
PROGRAM SELECTOR
For manual Selection of desired channel.
CARTRIDGE RECEPTACLE
PAUSE BUTTON & INDICATOR
Depress to momentarily stop tape travel during recording or
playback. Pause Indicator Lamp lights when Button is
depresse d.
Caution: F.FWD wili not function during Pause mode.
4 PFOGR
SELECf
LEFT VU I
Indicates le
or playback
VOLTAGE SELECTOR & FUSE POST
(CEE, CSA, UL and LA models not equipped with this facility.)
Universal Voltage Selector offers six selections of vottage
from 100 to 240 V AC. When changing voltage it is also
necessary to change the fuse accordingly. Refer to Voltage
& Cycle Conversion procedure.
DIN JACK
Enables connection
single Din Cord. an external amplifier by use of a
AC CORD
Should any mechanical problem develop, please take
your machine to your nearest authorized Akai Service
Agent or inquire at the service department of Akai
Company, Tokyo, Japan.

STOP BUTTON PLAY BUTTON
Advances tape for recording or playback"
^AUTO STOP
I coNT,s FLAY FOWER4 PROGTAM PAUSE SELECTOT
F.FWD BUTTON
Advances tape at high speed for fast program selection.
POWER SWITCH
AUTO STOP/CONTINUOUS PLAY BUTTON
Depress for automatic stop at end of tape, or leave at out
position for continuous playback.
Note: At recording mode, automatic stop will be effected
at end of tape regardless of position of this Button.
l_l_t_l
MICROPHONE
JACKS (left/right)
LEFT VU METER
Indicates left channel recording
or playback level.
RIGHT VU METER
Indicates right channel recording or playback level.
RECORDING
INDICATOR LAMP
Lights when Recording
Button is depressed.
RIGHT VOI-UME & TONE CONTROLS
Volume: 1. Adjusts right speaker volume at
(GXR-82 only)
2. Adjust right ch recording 1evel
ing right VU Meter.
Tone: Adjusts right ch tone (GXR-82 only)
LEFT VOLUME & TONE CONTROLS
Volume: 1. Adjusts left speaker volume at
(GXR-82 only).
2. Adjust left ch recording level
left VU Meter.
Tone: Adjusts left ch tone (GXR-82 only)
playback time.
while observ-
playback time.
while observing
LINE INPUT JACKS (left/right)
Connects to outputs of external source.
* Be sure to disconnect Microphones before attempting to use
these input jacks.
SPEAKER JACKS (left/right) (GXR-82 only)
LINE OUTPUT JACKS
Connects to tape inputs of external amplifier or recorder
