Alderon Industries Wireless Versa'larm VA01B User manual

1. DISCONNECT ALL ELECTRICAL SERVICE BEFORE INSTALLING OR WORKING ON THE PRODUCT.
2. DO NOT USE WITH FLAMMABLE OR EXPLOSIVE FLUIDS SUCH AS GASOLINE, FUEL OIL, KEROSENE, ETC.
DO NOT USE IN EXPLOSIVE ATMOSPHERES.
3. ALARM PANEL AND RECEIVER MUST BE MOUNTED INDOORS. FOR OUTDOOR APPLICATIONS CONSULT FACTORY.
The 1-Zone Wireless Versa’larm™alarm panel is powered by 120 VAC coming from standard wall outlets and is trans-
formed to 9-11.1 VDC. Installing a 9 Volt battery provides battery backup during power outages. The power LED (green) will
illuminate when powered. The Wireless Versa’larm™is a multipurpose alarm panel used in a variety of applications such
as: septic tanks, sumps, holding tanks, pump chambers, water tanks, flow, pressure, condensate, temperature, and any
others where a “dry contact” can be connected to the alarm panel.
When the liquid level rises, a switch (signaling device) contact “closes” which will activate the transmitter and sends a signal
to the alarm/receiver activating the alarm system. The buzzer will annunciate, alarm LED (red) will illuminate, and the built
in auxiliary contacts will be activated. The auxiliary contacts can be used to connect to an Alderon Industries Auto Dialer, an
existing security system, or building automation system (BAS).
Pressing the “Alarm Silence” pushbutton will silence the buzzer and the alarm LED (red) remains on. When alarm condition
is cleared, the system automatically resets itself for the next alarm cycle. Part number 7991 includes an indoor rated high
water alarm panel, indoor wireless receiver, outdoor rated wireless transmitter and float switch. Part number 7992 includes
all items in the 7991 alarm system, plus a riser connection kit and mounting post (actual riser not included).
1. Phillips screw driver
2. Drill and 3/16” drill bit
3. 3/8” Wrench
4. (Qty 4) #6 self tapping screws
5. Access to 120 VAC power receptacle
6. Optional - Plastic anchors (#8; Qty 4) if mounting to sheet rock (alarm and wireless receiver)
7. Optional - 9V battery (used for battery backup during power outages)
8. Optional - Wire stripper (used if you need to strip wire to connect to a BAS or SCADA system)
9. Optional - Needle nose pliers if using auxiliary contacts
10. Optional - 3” screws if mounting wireless receiver without mounting kit (plastic anchors for sheet rock; Qty 2)
Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
Introduction of Installation
Safety Guidelines
Description of Operation
Tools, Supplies and Requirements for Installation - Not Included
1-Zone Alarm - Model VA01B
Part Numbers - 7991 and 7992
Before proceeding with the installation or operation of the product, read all
instructions thoroughly, as well as complying with all federal, state and local
codes, regulations, and practices. The product must be installed by qualified
personnel familiar with all applicable local electrical and mechanical codes.
Refer to the National Electrical Code (NFPA 70). Failure to properly install and
test this product can result in personal injury or equipment malfunction.
Alarm Systems Control Panels Float Switches Leak Detection Systems Page 1 of 6P/N: 101985

1. The wireless transmitter and receiver are both programmed in the factory and do not need to be adjusted or
programmed. Important! - Allow 10 minutes after the Versa’larm™ is powered up to establish a communication link with
the float switch and wireless transmitter. Wait at least 10 minutes before attempting to test the system.
NOTE: THE WIRELESS TRANSMITTER CAN BE ACTIVATED BY OPENING THE COVER AND PRESSING THE
BLACK BUTTON FOR FIVE SECONDS.
a. Pretest the system before mounting wireless transmitter, float switch, wireless receiver, and alarm panel.
b. Plug the alarm panel into a power outlet (120 VAC, 50/60 Hz).
c. Attach the float switch (black) to the wireless transmitter (yellow) using the screw in quick connect/disconnect.
d. Tilt the float switch above horizontal to activate the alarm panel (keep above horizontal through step 3). Press and
hold the “Alarm Test” pushbutton to test system weekly after installation or when testing the battery backup feature.
2. Once the float switch activates the alarm panel, the buzzer should annunciate and alarm LED (red) should illuminate.
3. Press the “Alarm Silence” pushbutton, the buzzer should silence while the alarm LED (red) remains on.
4. Tilt the float switch below horizontal to deactivate the alarm panel, the alarm LED (red) should turn off. If performing the
weekly test or testing battery backup, release pressure from the “Alarm Test” pushbutton.
5. The “Auto Reset” function will reset the system after alarm condition is cleared for the next alarm cycle.
6. Repeat a couple times to ensure proper system operation prior to installing the product and weekly after installation.
If the alarm panel and wireless receiver are properly communicating with the float switch and wirelss transmitter, disconnect
all power sources before moving on to the steps for installation. If not, call the factory for troubleshooting assistance.
Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
Alarm System Product Overview
1
2
34 5
Indoor Mounted Wireless Receiver
Indoor Mounted Alarm Panel/Power Supply
Alarm Features:
▪Alarm Buzzer
▪Green Power and Red Alarm LEDs
▪Auxiliary Contacts
▪Auto Reset Function
1
2
Wireless Transmitter with
Mounting Screws
Float Switch
4-Foot Post and 2” Riser
Connection Kit (7992 only)
(Actual Riser Not Included)
• Single Phase
• 120VAC/9-11.1 VDC
• 50/60 Hz
(actual riser not included)
Electrical Ratings Indoor Components Outdoor Components
3
4
5
Pretest the Alarm System and Testing Alarm Panel
1-Zone Alarm - Model VA01B
Part Numbers - 7991 and 7992
Alarm Systems Control Panels Float Switches Leak Detection Systems Page 2 of 6P/N: 101985

Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
Installation of the Wireless Transmitter and Float Switch
1. Disconnect all power sources for the wireless transmitter, float
switch, wireless receiver and alarm panel. Unscrew the float
switch (black) from the wireless transmitter (yellow) using the
quick connect/disconnect (Fig. 1).
(Fig. 1)
2. Determine a mounting location for the wireless transmitter. The included mounting kit has a washer, black threaded
locking nut, bolts, and nuts (Fig. 2) which can be used with the threaded post or mounting holes on the transmitter (Fig. 3).
Note: If drilling into a post or bracket using the provided bolts, nuts, and mounting holes in transmitter, a drill with 3/16” bit
and 3/8” wrench are required (not included). The transmitter can also be mounted to a wall or permanent structure with user
provided screws, minimum size of 3” to securely fasten (use plastic anchors if mounting to sheet rock, not included).
(Fig. 2) (Fig. 3)
Mounting Holes
Threaded Post
3. Mount the float switch, product comes with both a stainless steel pipe
clamp and cast iron cable weight.
a.For pipe clamp models, determine desired activation level (Fig. 4),
then mount the pipe clamp at desired location and tether float switch
cable to approximately four inches.
b.For cable weight models, determine desired activation level (Fig. 5),
then suspend the float switch cable with weight at desired location
and tether cable to approximately six inches.
Note: Wireless Versa’larm™system (7991 and 7992) is used as a high
level alarm. Alderon normally open float switches activate at 5 degrees
above horizontal and deactivate at 5 degress below horizontal. Check
installation by cyling the float switch on and off to ensure proper operation
for desired activation range after installation is complete.
Pivot
Point
Control
Switch
Pump
Switch
Pivot
Point
Control
Switch
Pump
Switch
(Fig. 4) (Fig. 5)
1-Zone Alarm - Model VA01B
Part Numbers - 7991 and 7992
Alarm Systems Control Panels Float Switches Leak Detection Systems Page 3 of 6P/N: 101985

Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
Installation of the Wireless Transmitter and Float Switch Continued
4. Connect the float switch to the wireless transmitter (yellow)
using the screw in quick connect/disconnect (Fig. 6).
CAUTION: Hand tighten only while attaching the float switch to
the wireless transmitter. Overtightening or using tools will cause
irreversible damage to the product.
(Fig. 6)
Installation of the Alarm Panel and Wireless Receiver
1. The maximum line of sight distance between the wireless transmitter and wireless receiver is 3,250 feet (990.6 meters).
Many factors will reduce this range, some of which include: hills, trees, buildings, etc. Before permanently mounting the
alarm panel and wireless receiver (step 3), plug into the intended wall outlet and perform another pretest of the system as
described on page 2 of these instructions. If the alarm activates, disconnect all power sources before proceeding to step 3
for permanent mounting of the alarm panel and wireless receiver.
Note: If the alarm does not activate, choose another wall outlet that is closer to your wireless transmitter. If moving alarm
panel and wireless receiver closer does not work, remove the wireless receiver from the alarm panel and splice cable, add
up to 100 feet maximum of 18 gauge 3-conductor cable. See step 2 example.
(Fig. 7)
2. If normal installation does not work, use example below (Fig. 7) to increase the signal strength. The alarm panel and
wireless receiver must be mounted indoors.
a. Remove the wireless receiver from the alarm panel.
b. Splice the 3-conductor 18 gauge wire to a maximum of 100 feet. Consult factory for further distances.
c. Position the antenna on the wireless receiver to communicate the alarm panel with the wireless transmitter.
Wireless Transmitter
Wireless Receiver
3-Conductor Wire
Alarm Panel
Antenna
1-Zone Alarm - Model VA01B
Part Numbers - 7991 and 7992
Alarm Systems Control Panels Float Switches Leak Detection Systems Page 4 of 6P/N: 101985

Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
3. Determine the mounting location for the alarm panel and wireless receiver. Make sure power outlet (120 VAC, 50/60 Hz)
is within 5-feet of the alarm panel (Fig. 8). The power outlet should be on a separate circuit breaker from any other device
and not on a switched receptacle to maintain power integrity. Mount the alarm panel and wireless receiver using two #6
self-tapping screws (not included/Fig. 9) for both devices. Use two #8 plastic anchors (not included/Fig. 10) for both devices
if mounting the alarm panel and wireless receiver to sheet rock.
(Fig. 8) (Fig. 9)
(Fig. 10)
5 ft. Max
Installation of the Alarm Panel and Wireless Receiver Continued
4. To install/replace the battery for the backup power feature, remove the access cover (Fig. 11) and install 9 VDC battery
(Duracell model MX 1604B2 / Fig. 12). After installing battery, the green power LED should illuminate, then press and hold
the “Alarm Test” pushbutton (Fig. 13) to activate the alarm and make sure the battery is working properly. The buzzer should
annunciate and the alarm LED should illuminate. If using the auxiliary contacts, leave the access cover off until step 5 is
completed. If the auxiliary contacts are not used, replace the access cover (Fig. 14).
(Fig. 11) (Fig. 12) (Fig. 13) (Fig. 14)
1-Zone Alarm - Model VA01B
Part Numbers - 7991 and 7992
Alarm Systems Control Panels Float Switches Leak Detection Systems Page 5 of 6P/N: 101985

Wireless Versa’larm™
Operation, Maintenance and Installation Manual
Alderon Industries - Hawley, MN | 218.483.3034 | [email protected] | alderonind.com
5. If connecting to an existing alarm security system or building automation system (BAS), leave Terminals “+” and “-” open
and use 18 gauge 2-conductor wire to connect the existing product to Terminals 1A and 1B (Fig. 15). When connected,
replace the access cover and pull wire(s) through the knockout(s) on the access cover (see step 6). The alarm panel is
factory wired with knockout for wireless receiver, use additional knockouts for auxiliary contacts. CATUION! - Route all wires
away from sharp objects and internal components when installing wires.
Installation of the Alarm Panel and Wireless Receiver Continued
AUXILIARY CONTACTS: (Fig. 15)
Terminals “+” and “-”
“+” Not Used
“-” Factory Wired (green)
Terminals 1A and 1B
Normally Open
Class 2, 24 VDC/VAC (50/60 Hz)
100 Milliamps Maximum
Terminals 2A and 2B
2A Factory Wired (black/red)
2B Factory Wired (red/red)
Note: The auxiliary contacts 1A and 1B of the alarm panel are Normally Open only.
+-
2A 2B1A 1B
6. After the access cover has been removed from the alarm panel (Fig. 16), use a needle nose pliers (not included) to
remove the desired “break away tabs” from the access cover, lightly pull and twist off tab(s) (Fig. 17). Replace the access
cover and run wire(s) through the knockout(s) (Fig. 18).
(Fig. 16) (Fig. 17) (Fig. 18)
Wireless Receiver
Knockout (pre-installed)
Field Wired Knockout
(separate from receiver knockout)
Testing and Maintenance
1. Plug the alarm panel power supply into a 120 VAC, 50/60 Hz standard wall outlet and the green “Power” LED should
illuminate. Test by pressing and holding the “Alarm Test” pushbutton or activating the “Signaling Device” (float switch). The
buzzer should annunciate and the alarm LED should illuminate. Press the “Alarm Silence” pushbutton and the buzzer
should silence while the alarm LED remains on. After you remove pressure from the “Alarm Test” pushbutton or deactivate
the “Signaling Device”, the “Auto Reset” feature reactivates the alarm panel for the next alarm cycle. Test product weekly to
ensure system intergrity. Refer to step-by-step testing instructions on page 2 for further details.
Transmitter Maintenance: The transmitter is a waterproof unit that comes with an internal lithum battery (BWA-BATT-006) which has
an approximate battery life of 5 years under normal operating conditions. Consult the factory for ordering a replacement battery.
