ALIBI ALI-NT4002R User manual

ALI-NT4002R, ALI-NT2002R 2MP Optical - Thermal
Network Cameras User Manual
ALI-NT2002R camera
ALI-NT4002R camera
PLEASE READ THIS MANUAL BEFORE USING YOUR CAMERAS, and always follow the instructions for safety
and proper use. Save this manual for future reference.
ALI-NT4002R-NT2002R_UM
190930

ii
About this document
This document for the ALI-NT4002Rand ALI-NT2002R Thermal Surveillance cameras includes a summary of its features, installation,
setup and common conguration features. For more information about using the rmware in this camera, refer to the applicable
rrmware user manual to become available on AlibiSecurity.com.
CAUTION
FCC Caution: To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class “A” digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications.
LEGAL NOTICE
Observint Technologies (Observint) products are designed to meet safety and performance standards with the use of
specic Observint authorized accessories. Observint disclaims liability associated with the use of non-Observint
authorized accessories.
The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly
prohibited by law.
Observint makes no representations concerning the legality of certain product applications such as the making,
transmission, or recording of video and/or audio signals of others without their knowledge and/or consent. We
encourage you to check and comply with all applicable local, state, and federal laws and regulations before
engaging in any form of surveillance or any transmission of radio frequencies.
ALIBI and the ALIBI logo are trademarks of Observint.
Microsoft, Windows, and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks
and names or their products. Observint disclaims any proprietary interest in trademarks and trade names other than
its own.
No part of this document may be reproduced or distributed in any form or by any means without the express written
permission of Observint, Inc.
© 2019 by Observint Technologies. All Rights Reserved.
15505 Long Vista Drive, Suite 250, Austin, TX 78728
For Sales and Support, please contact your distributor.

iiiALI-NT4002R, ALI-NT2002R Cameras User Manual
SAFETY INSTRUCTIONS
Regulatory information
FCC information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Preventive and Cautionary Tips
Before connecting and operating your cameras, please be advised of the following:
• Ensure environmental conditions meet factory specications.
• Major shocks or jolts to the unit as a result of dropping it may cause damage to the sensitive electronics within the unit.
• Use the device in conjunction with an UPS if possible.
Safety Instructions
These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
The precaution measure is divided into Warnings and Cautions:
• Warnings: Neglecting any of the warnings may cause serious injury or death.
• Cautions: Neglecting any of the cautions may cause injury or equipment damage.
Warnings
• Proper conguration of all passwords and other security settings is the responsibility of the installer and/or end-user. Settings
are the responsibility of the installer and/or end-user.
• Use of the product only in strict compliance with the local electrical safety regulations. Refer to technical specications for
detailed information.
• Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 Vac or 12 Vdc
according to applicable standards.

iv
• Do not connect several devices to one power adapter. Adapter overload may cause over-heating or a re.
• Make sure that the plug is rmly connected to the power socket. When the product is mounted on wall or ceiling, the device
shall be rmly xed.
Cautions
• Make sure the power supply voltage is correct before using the camera.
• Do not drop the camera or subject it to physical shock.
• Do not touch sensor modules with ngers. If cleaning is necessary, use clean cloth dampened with ethanol and wipe it gently.
• Do not aim the camera at the sun or bright objects. Blooming or smearing may occur, and this may aect the life of sensor.
• The sensor can be damaged by a laser beam. When a laser is in use, make sure that the sensor is not exposed to the laser beam.
• Do not place the camera in extremely hot or cold, dusty or damp locations, and do not expose it to high electromagnetic
radiation. Refer to the specications data for allowable temperatures.
• Provide good ventilation in the operating environment.
• Keep the camera away from liquid while in use.
• When transporting this camera, pack it in its original packaging material, or packing materials providing the same protection.
• If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble
the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)
Read these instructions and keep them in a safe place for future reference.
• Please refer all work related to the installation of this product to qualied service personnel or system installers.
• Do not operate the camera outside of its specied temperature, humidity or power source ratings.
• Install the unit away from heat sources such as radiators, heat registers and stoves.
• Installation of the unit near consumer electronics devices, such as stereo receiver/ampliers and televisions, is permitted as
long as the air surrounding the terminal does not exceed the above mentioned temperature range.
• Handle the camera with care. Do not drop or shake, as this may damage it.
• Do not use strong or abrasive detergents when cleaning the surfaces of this product. When dirt is hard to remove, use a mild
detergent and wipe gently.
• Backup your system conguration.
• Distributing, copying, disassembling, reverse compiling, reverse engineering, and exporting software provided with this
product in violation of export laws is expressly prohibited.

vALI-NT4002R, ALI-NT2002R Cameras User Manual
TABLE OF CONTENTS
Table of Contents
SECTION 1 Overview ..........................................................................1
1.1 Imaging ............................................................................1
1.2 ALI-NT4002R camera .................................................................2
1.2.1 Specications ...................................................................2
1.2.2 Dimensions.....................................................................4
1.3 ALI-NT2002R camera .................................................................5
1.3.1 Specications ...................................................................5
1.3.2 Dimensions.....................................................................7
1.4 Detection Range Table ................................................................8
1.4.1 Smart functions Range ...........................................................8
1.4.2 Wide Range Coverage ............................................................8
SECTION 2 Installation ........................................................................9
2.1 ALI-NT4002R installation..............................................................9
2.1.1 What’s in the box ................................................................9
2.1.2 Install a microSD card (optional) ..................................................10
2.1.3 Installing the camera with the junction box ........................................11
2.1.4 Installing the camera without the junction box .....................................12
2.1.5 Connect extension cables to the camera drop cables .................................13
2.2 ALI-NT2002R installation.............................................................15
2.2.1 What’s in the box ...............................................................15
2.2.2 Install a microSD card (optional) ..................................................15
2.2.3 Install the camera ..............................................................17
2.2.4 Connect extension cables to the camera drop cables .................................18
2.3 Activate the camera .................................................................21
2.3.1 Activate the camera attached to an NVR ...........................................21
2.3.2 Activate the camera attached to a network switch ...................................21
2.4 Log into the camera with a browser....................................................24
2.4.1 Login to the camera connected to the same network switch as your computer ...........25
2.4.2 Login to a camera connected to an NVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
2.5 ALI-NT4002R - Adjust the camera pan, tilt and rotation ...................................31
2.6 ALI-NT2002R - Adjust the camera pan, tilt and rotation ...................................31
2.7 Basic camera conguration setup .....................................................32
2.7.1 Congure local parameters.......................................................32

vi
TABLE OF CONTENTS
2.8 Congure System Settings............................................................33
2.8.1 Congure camera basic information ...............................................33
2.8.2 Congure time settings..........................................................34
2.8.3 Conguring RS-485 Settings .....................................................35
2.8.4 Conguring DST Settings ........................................................35
2.8.5 Conguring Video Settings .......................................................36
2.8.6 Conguring Audio Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
SECTION 3 Image Settings ....................................................................39
3.1 Conguring Display Settings (Channel 01) ..............................................39
3.2 Conguring Display Settings (Channel 02) ..............................................42
3.3 Conguring OSD Settings ............................................................44
3.4 Picture in Picture....................................................................46
3.5 Temperature Measurement...........................................................46
3.5.1 Temperature Measurement Basic Settings ..........................................47
3.5.2 Conguring Temperature Measurement Rule .......................................48
3.5.3 Linkage Method................................................................53
3.5.4 Congure VCA Rule ............................................................54
SECTION 4 Event Setup .......................................................................55
4.1 Basic Events........................................................................55
4.1.1 Conguring Motion Detection ....................................................55
4.1.2 Video Tampering ...............................................................59
4.1.3 Conguring Alarm Input.........................................................61
4.1.4 Conguring Alarm Output .......................................................63
4.1.5 Conguring Exception Events.....................................................65
4.2 Smart Events .......................................................................66
4.2.1 Conguring Fire Source Region Shield .............................................71
4.3 VCA Conguration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
4.3.1 Conguring Basic Settings .......................................................72
4.3.2 Conguring Camera Calibration...................................................73
4.3.3 Conguring Shield Region .......................................................76
SECTION 5 Advanced Network Settings .........................................................78
5.1 Conguring FTP Settings .............................................................78
5.2 Conguring Email Settings ...........................................................79
5.3 Conguring Platform Access ..........................................................80
SECTION 6 Storage Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

viiALI-NT4002R, ALI-NT2002R Cameras User Manual
TABLE OF CONTENTS
6.1 Schedule Settings...................................................................83
6.1.1 Capture .......................................................................86
6.2 Storage Management ...............................................................88
6.2.1 HDD Management ..............................................................88
6.2.2 NetHDD .......................................................................89
APPENDIX A Lightning and Surge Protection ......................................................91
APPENDIX B 24 Vac Wire Gauge and Transmission Distance ..........................................92
APPENDIX C Using the Waterproof Ethernet Fitting ................................................94
APPENDIX D Thermal Emissivity Chart............................................................95

viii
NOTES

1ALI-NT4002R, ALI-NT2002R Cameras User Manual
SECTION 1: OVERVIEW
SECTION 1
Overview
The Alibi Security ALI-NT4002R (bullet) and ALI-NT2002R (turret) thermal and optical network cameras include a built-in GPU
which support an intelligent behavior analysis algorithm to provide high precision video content analytics (VCA) detection and real-
time alarms. It is useful for re-prevention purposes in indoor space such as engine rooms, ATMs, conference rooms, warehouses,
museums, train stations, power stations, etc. The pre-alarm system discovers unexpected events immediately to help protect you
from property loss. Thermal imaging functions include:
• Leading image processing technology: Adaptive AGC, Digital Detail Enhancement (DDE), 3D DNR, Noise Equivalent
Temperature Dierence (NETD) less than 40 mK (25 °C), F#=1.1
• Powerful behavior analysis function, based on deep learning algorithm: Line crossing, Intrusion, Region Entrance & Exit
• Reliable temperature exception alarm function
• Advanced re detection algorithm
• Picture in picture preview
• 160 × 120 (the output image resolution is 320 × 240) resolution, high sensitivity thermal sensor. Supports contrast
adjustment.
• Shutter adjustment in various modes
• 15 palettes of color enhancement
1.1 Imaging
After connecting to the camera with an internet browser either through an NVR or by directly logging into it, the Live View screen
allows you to concurrently view both the real-time video (optical spectrum) from the camera and the thermal image (infrared
spectrum) of the video on separate video channels.
The real-time video channel can have a resolution up to 1920 × 1080 pixels, and the thermal channel can have a resolution up
to 320 × 240 pixels. Both channels are transmitted through the single Ethernet connection to the camera. Both channel support

2
motion detection and video tampering detection. Additionally, the optical video channel (channel 1) supports audio exception
detection, and the thermal channel (channel 2) supports Dynamic Fire Source Detection and Fire Source Region Shield.
1.2 ALI-NT4002R camera
Thermal camera lens
Reset, microSD card slot
addess on underside
camera body
Camera body
Adjustable
bracket
Bracket lock
screw
Sun shield
Junction box
Conduit junction
Optical camera lens
ALI-NT4002R camera with junction box
1.2.1 Specications
Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution 160 × 120 (the resolution of output image is 320 × 240)
Pixel Interval 17 μm
Response Waveband 8 μm to 14 μm
NETD less than 40 mK (25°C), F#=1.1
Lens (Focal Length) 6.2 mm
SECTION 1: OVERVIEW

3ALI-NT4002R, ALI-NT2002R Cameras User Manual
SECTION 1: OVERVIEW
MRAD 2.74 mrad
Field of View 25.0° × 18.7° (H × V)
Min. Focusing Distance 0.6 m
Aperture F1.1
Optical Module
Max. Image Resolution 1920 × 1080
Image Sensor 1/2.8” Progressive Scan CMOS
Min. Illumination Color: 0.002 Lux @ (F1.5, AGC ON), B/W: 0.0002 Lux @ (F1.5, AGC ON)
Shutter Speed 1s to 1/100,000s
Lens (Focal Length) 6 mm
Field of View 53° × 30° (H × V)
WDR Digital WDR
Day & Night IR cut lter with auto switch
Image Function
Bi-spectrum Image Fusion Fusion view of thermal view and overlaid details of the optical channel
Picture in Picture Combines details of thermal and optical image PIP, overlay thermalimage on optical image
Smart Function
VCA (Video Content Analysis) 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules
Temperature Measurement 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line)
Temperature Range -4 °F ~ +302 °F (-20 °C ~ +150 °C)
Temperature Accuracy ± 14.4 °F (± 8 °C)
Fire detection Dynamic re point detection, up to 10 re points detectable.
Infrared
IR Distance Up to 130 ft (40 m)
IR Intensity and Angle Automatically adjusted
Network
Main Stream
Visible Light: 50 Hz: 25 fps (1920 × 1080), 25 fps (1280 × 960), 25 fps (1280 × 720)
Visible Light: 60 Hz: 30 fps (1920 × 1080), 30 fps (1280 × 960), 30 fps (1280 × 720)
Thermal: 25 fps (160 × 120 (the resolution of output image is 320 × 240))
Sub Stream
Visible Light: 50 Hz: 25 fps (704 × 576), 25 fps (352 × 288), 25 fps (176 × 144)
Visible Light: 60 Hz: 30f ps (704 × 480), 30 fps (352 × 240), 30 fps (176 × 120)
Thermal: 25 fps (160 × 120 (the resolution of output image is 320 × 240))
Video Compression H.265 / H.264, H.265+ / H.264+ encoding with Baseline / Main / High Prole
Audio Compression G .711u / G.711a / G.722.1 / MP2L2 / G.726 / PCM
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP,
PPPoE

4
Simultaneous Live View Up to 20
User / Host level Up to 32 users, 3 levels: Administrator, Operator, User
Security Measures User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x, access control, IP address ltering
Integration
Alarm Input 1-ch inputs (0 ~ 5 Vdc)
Alarm Output 1-ch relay outputs, alarm response actions congurable
Alarm Action SD recording / Relay output / Smart capture / FTP upload / Email linkage
Audio Input 1 3.5 mm Mic in / Line in interface. Line input: 2 ~ 2.4 V[p-p], output impedance:1 KΩ ± 10%
Audio Output Linear Level; Impedance: 600 Ω
Reset 1 Reset button
Ethernet 1 RJ45 10M / 100M Self-adaptive Ethernet interface, 1 RS-485 interface
SD Memory Card Built-in microSD card slot, support microSD/SDHC/SDXC card (up to 128 GB), support manual / alarm recording
Analog Video Output 1.0 V[p-p] / 75Ω, PAL / NTSC / BNC
Application Programming Open-ended API, support ISAPI and third-party management platform
Client Alibi Central Management Software (ACMS), ACMS Lite
Web Browser Microsoft Internet Explorer 9 or later
General
Menu language English
Power 12 Vdc± 20 %, two-core terminal block PoE (802.3af, class 4)
Power Consumption 12 Vdc ± 20 %: 12 W
PoE (802.3af, class 4)
Working Temperature/
Humidity -22 °F ~ 140 °F (-30 °C ~ 60 °C), 95% or less
Protection Level IP67 Standard
TVS 6000V Lightning protection, surge protection, voltage transient protection
Dimensions 13.9” × 4.5” × 4.5 “ (352.4 mm × 113.5 mm × 114.7 mm)
Weight 3.3 lb (1.5 K)
1.2.2 Dimensions
SECTION 1: OVERVIEW

5ALI-NT4002R, ALI-NT2002R Cameras User Manual
SECTION 1: OVERVIEW
1.3 ALI-NT2002R camera
Thermal camera lens
Camera
turret
assembly
Mounting
base
Cable
channel
Housing
Optical camera lens
ALI-NT2002R camera
1.3.1 Specications
Thermal Module
Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution 160 × 120 (the resolution of output image is 320 × 240)
Pixel Interval 17 μm
Response Waveband 8 μm to 14 μm
NETD less than 40 mK (25°C), F#=1.1
Lens (Focal Length) 6.2 mm
MRAD 2.83 mrad
Field of View 25.0° × 18.7° (H × V)
Min. Focusing Distance 0.6 m
Aperture F1.1
Optical Module
Max. Image Resolution 1920 × 1080
Image Sensor 1/2.7” Progressive Scan CMOS
Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON)
Shutter Speed 1s to 1/100,000s
Lens (Focal Length) 6 mm

6
Field of View 53° × 30° (H × V)
WDR 120 dB WDR
Day & Night IR cut lter with auto switch
Image Function
Bi-spectrum Image Fusion Fusion view of thermal view and overlaid details of the optical channel
Picture in Picture Combines details of thermal and optical image PIP, overlay thermalimage on optical image
Smart Function
VCA (Video Content Analysis) 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules
Temperature Measurement 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line)
Temperature Range -4 °F ~ +302 °F (-20 °C ~ +150 °C)
Temperature Accuracy ± 14.4 °F (± 8 °C)
Fire detection Dynamic re point detection, up to 10 re points detectable.
Infrared
IR Distance Up to 50 ft (15 m)
IR Intensity and Angle Automatically adjusted
Network
Main Stream
Visible Light: 50 Hz: 25 fps (1920 × 1080), 25 fps (1280 × 960), 25 fps (1280 × 720)
Visible Light: 60 Hz: 30 fps (1920 × 1080), 30 fps (1280 × 960), 30 fps (1280 × 720)
Thermal: 25 fps (160 × 120 (the resolution of output image is 320 × 240))
Sub Stream
Visible Light: 50 Hz: 25 fps (704 × 576), 25 fps (640 × 480)
Visible Light: 60 Hz: 30f ps (704 × 480), 30 fps (640 × 480)
Thermal: 25 fps (160 × 120 (the resolution of output image is 320 × 240))
Video Compression H.265 / H.264, H.265+ / H.264+ encoding with Baseline / Main / High Prole
Audio Compression G .711u / G.711a / G.722.1 / MP2L2 / G.726 / PCM
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS,
IPv6, UDP, Bonjour
Simultaneous Live View Up to 20
User / Host level Up to 32 users, 3 levels: Administrator, Operator, User
Security Measures User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x, access control, IP address ltering
Integration
Alarm Input 1-ch inputs (0 ~ 5 Vdc)
Alarm Output 1-ch relay outputs, alarm response actions congurable
Alarm Action SD recording / Relay output / Smart capture / FTP upload / Email linkage
Audio Input 1 3.5 mm Mic in / Line in interface. Line input: 2 ~ 2.4 V[p-p], output impedance:1 KΩ ± 10%
Audio Output Linear Level; Impedance: 600 Ω
Reset 1 Reset Button
SECTION 1: OVERVIEW

7ALI-NT4002R, ALI-NT2002R Cameras User Manual
SECTION 1: OVERVIEW
Ethernet 1 RJ45 10M / 100M Self-adaptive Ethernet interface, 1 RS-485 interface
SD Memory Card Built-in microSD card slot, support microSD/SDHC/SDXC card (up to 256 GB), support manual / alarm recording
Analog Video Output 1.0V [p-p] / 75Ω, PAL / NTSC / BNC
Application Programming Open-ended API, support ISAPI and third-party management platform
Client Alibi Central Management Software (ACMS), ACMS Lite
Web Browser Microsoft Internet Explorer 9 or later
General
Menu language English
Power 12 Vdc ± 20%, two-core terminal block PoE (802.3af, class 3)
Power Consumption 12 Vdc ± 20%: 0.7 A, max. 8W
PoE (802.3af, class 3): 42.5 V ~ 57 V, 0.14 A ~ 0.22 A, max. 8.5W
Working Temperature/Humidity -22 °F ~ 140 °F (-30 °C ~ 60 °C), 95% or less
Protection Level IP67 Standard
TVS 6000V Lightning protection, surge protection, voltage transient protection
Dimensions 5.45" × 5.45" × 4.85" (138.3 mm × 138.3 mm × 123.1 mm)
Weight 1.98 lb (900 g)
1.3.2 Dimensions

8
1.4 Detection Range Table
* The table is only for reference, the performance may vary from camera to camera.
1.4.1 Smart functions Range
Dierent targets trigger the VCA events within dierent range limits.
VCA Range
(Vehicles:
4.6 × 13.1 ft)
VCA Range
(Humans:
5.9 × 1.6 ft)
Temperature
Measurement
(Object: 6.6 ×
6.6 ft)
Temperature
measurement
(Object: 3.3 ×
3.3 ft)
Fire Detection
(Object: 6.6 ×
6.6 ft)
Fire Detection
(Object: 3.3 ×
3.3 ft)
207 ft 69 ft 217 ft 108 ft 590 ft 2280 ft
1.4.2 Wide Range Coverage
There is range limit for detecting, recognizing, and identifying human/vehicle targets.
Detection Range
(Vehicles:
4.6 × 13.1 ft)
Detection Range
(Humans:
5.9 × 1.6 ft)
Recognition Range
(Vehicles:
4.6 × 13.1 ft)
Recognition Range
(Humans:
5.9 × 1.6 ft)
Identication
Range (Vehicles:
4.6 × 13.1 ft
Identication
Range (Humans:
5.9 × 1.6 ft)
919 ft 298 ft 230 ft 75 ft 115 ft 36 ft
SECTION 1: OVERVIEW

9ALI-NT4002R, ALI-NT2002R Cameras User Manual
SECTION 2: INSTALLATION
SECTION 2
Installation
An ALI-NT4002R camera can be mounted directly to a wall or ceiling, with or without the junction box provided. The surface should
support at least four times the weight of the camera and junction box (if used). The drop cables can be routed either through
mounting surface, through a cable channel in the mounting base, or into the junction box for connection to extention cables for the
network, power, alarms and audio accessories.
After the camera is mounted, it is powered on and then activated. If the camera is attached through to an NVR, it can be using the
NVR. If it is attached to a network switch, the Alibi Conguration Tool is installed and used to activate the camera.
After activation, the camera must be congured for your application needs. To congure the thermal video features and some
optical video features, you must log into the camera with a browser. Which can be done through the NVR, or directly if installed on
a network (connected to a network switch.
2.1 ALI-NT4002R installation
2.1.1 What’s in the box
• ALI-NT4002R camera assembly
• Junction box
• Drill template
• Mounting base seal
• Junction box seal
• Security L-wrench
• Waterproof Ethernet tting
• Mounting hardware (4 screws, wall inserts)
• Camera to junction box screws (4)
Tab for camera safety cable
Locator pin (2) for camera mounting base
Fitting (2) for conduit cable routing
Junction box (left) and drill template* (right)

10
* On the drill template, use holes marked #1 when mounting the camera directly to a surface, and holes marked #2 when
mounting the junction box to a mounting surface.
Waterproof Ethernet tting, security L-wrench, mounting hardware
Camera mounting base seal (left) and junction box seal (right)
2.1.2 Install a microSD card (optional)
The camera can accommodate a microSD card. These cards are valuable for recording local alarms, live video and local captures.
If the camera is attached to an NVR, this information is normally uploaded into the NVR. However, if the camera is attached to a
network switch, the microSD card is where local video and alams events are saved.
The microSD card slot is located behind the maintenance panel cover on the underside of the camera. See the Specications section
of this document for card types and capacity. To install a microSD card:
1. Remove the cover on the underside of the camera (see the photo below).
2. Slide a formatted microSD card into the card slot. It should slide in smoothly. Push the card all the way into the slot, and then
release it. The card should latch into place. (To remove the card, push it all the way in to unlatch it, and then release it.)
SECTION 2: INSTALLATION

11ALI-NT4002R, ALI-NT2002R Cameras User Manual
*To reset the camera to
its default parameters,
press and hold the RESET
button, power on the
camera, and then continue to
press the RESET button for 20
seconds.
Maintenance
panel cover
RESET*
button
microSD card slot
3. Reinstall the maintenance panel cover.
NOTE
The microSD card may need to be initialized before it can be used to record data. Refer to the ALIBI™ IP Camera Firmware Version ..
User Manual provided at AlibiSecurity.com/resources for instructions to initialize the card.
2.1.3 Installing the camera with the junction box
1. Determine and acquire the best fasteners for securing the Junction box to mounting surface. The mounting hardware provided
is suitable for many surfaces.
2. Attach the drill template to the surface. Mark the location of the Junction box mounting screw holes. These holes are identied
with #2 on the template. If routing extension cables for the LAN, power, alarm devices, etc. through the mounting surface,
mark the location for that hole, too. If installing the box onto a wall, observe the orientation for TOP and BOTTOM orientation
markings inside the box and on the camera mounting base, and orient the drill template properly.
3. Drill holes in the mounting surface for the mounting screws and extension cables (if necessary).
4. Find the junction box seal in the camera box. Remove the protective paper from the back of the seal, and then apply the seal to
to the mounting surface side of the junction box.
5. Anchor the junction box to the mounting surface using the appropriate fasteners.
SECTION 2: INSTALLATION

12
6. Route the Ethernet, power, alarm, audio and RS-485 (if used) extension cables into the junction box from the devices they
connect to. Extension cables can be routed into the box through a hole in the mounting surface, or through conduit. Do not
apply power to the extension cables at this time.
7. Position the camera mounting base seal onto the camera mounting base. The thick foam side should be toward the camera,
and the camera drop cables should be routed out through the hole in the center of the seal. Adjust the seal so that the holes in
the seal align with the holes in the mounting base and the locator pin holes in the base.
8. Hang the camera on the junction box by placing the loop on the safety cable on the tab inside the box.
9. Continue with “2.1.5 Connect extension cables to the camera drop cables” on page 13.
2.1.4 Installing the camera without the junction box
“Bottom” marking
1. Determine and acquire the best fasteners for securing the camera to mounting surface. The mounting hardware provided is
suitable for many surfaces.
2. Attach the drill template to the surface. Mark the location of the camera mounting screw holes. These holes are identied with
#1 on the template. If routing extension cables for the LAN, power, alarm devices, etc. through the mounting surface, mark the
location for that hole, too. If installing the camera onto a wall, observe the orientation for Bottom markings on the camera
mounting base, and orient the drill template properly.
3. Drill holes in the mounting surface for the mounting screws and extension cables (if necessary).
4. Route the Ethernet, power, alarm, audio and RS-485 (if used) extension cables into the junction box from the devices they
connect to. Extension cables can be routed into the box through a hole in the mounting surface, or through conduit. Do not
apply power to the extension cables at this time.
5. Position the camera mounting base seal onto the camera mounting base. The thick foam side should be toward the camera,
and the camera drop cables should be routed out either through the hole in the center of the seal, or through the cable channel
on the edge of the mounting base. Adjust the seal so that the holes in the seal align with the holes in the mounting base and
the locator of the cable channel in the base.
6. Continue with “2.1.5 Connect extension cables to the camera drop cables” on page 13.
SECTION 2: INSTALLATION
