ALIGATOR RX550 eXtremo User manual

RX550 eXtremo
Quick guide

Google, Google Play and Android are trademarks of
Google Inc.
Contents
Before you start................................................... 2
DUAL SIM function...............................................
Important instructions ........................................
Insert SIM cards …............................................... 6
Mobile controls. .................................................. 8
Switch on …................................................................. 8
Telephone Reset ................................................. 9
Activation and screen unlock …........................... 9
Operating system Android™................................ 9
Basic control....................................................... 10
Making calls....................................................... 1
SMS messages.................................................... 15
Choice of SIM for calling, SMS + internet …....... 15
Choice of network by connection difficulties... 15
Photography ..................................................... 16
SOS Button …..................................................... 17
PTT Button........................................................ 17
PC connection.................................................. 18
Safety and ecology …......................................... 18
Declaration of conformity ................................ 20
Before you start
We thank you for buying of this resistant
mobile phone ALIGAT R.
Before you start, please read this quick
guide with important instructions.

DUAL SIM function
Your mobile phone can operate on 1 or 2 SIM
cards. If you insert only 1 SIM card, your
mobile phone works like a standard mobile
phone.
If you insert 2 SIM cards, both are working on
line at the same time and it is possible to
make a call on either card.
Important instructions
 In spite of the fact that the mobile phone
is very sturdy , handle the device with
care, protect it against the fall on the
ground, mechanical damage,
contamination or extreme high
temperatures. Protect the screen from
the hits or impacts ! Never put the mobile
phone into parts. Never disassemble the
phone or accessory! Remember that even
by a durable phone the display can crash
damage !
 Your phone is water resistant (not valid for
salt water), assuming that all the hole
covers are properly fitted and sealed. Yet if
possible, keep away from water. In case of
contact, respectively immersion in water,
remove it from water as soon as possible

and let it properly dry.
 When deploying all caps be always sure
that the seal caps are not dirty and that
the covers seal properly and are fully
deployed.
 If the phone or its part gets into the contact
with water, dry it thoroughly before using. Mainly
dry all the folds, crevices and holes for the
speaker, earphone and microphone. Never open
the door (on the back of the phone) after the
phone has come into contact with water and
before the cover and its surroundings were
properly dried.
 I n case of contact with water, do not
tamper with the phone, do not press any
keys and do not tamper with caps openings.
 D o not switch on and do not use the mobile
phone in the prohibited areas
 Do not use the mobile phone while driving the
car
 Turn off the mobile phone near the
sensitive medical device unless you are
sure that the radio transmission of the
mobile phone does not influence its
functions
 Mobile phone can influence the function
of the electronic cardiac pacemaker or

other implanted apparatus please �
consult your medical doctor
 Turn off the mobile phone in the aircraft
 D o not use the mobile phone near the
filling petrol station, turn off the mobile
phone always near explosives
 Use always original batteries supplied
by the producer (danger of damage
or explosion of the mobile phone)
 Do not put the battery at the fire and
do not expose it to the temperature
over +60°C (danger of explosion or fire)
 SAR – mobile phone meets the
prescriptions for maximal emission of
the electromagnetic radiation
 While making a call please keep the
mobile phone at least 2,5 cm away from
the body to minimalise the quantity of
the el. magnetic radiation absorbed by
your body
 Do not place the mobile phone or its
holder in the car at the place over the
airbag
 K eep it out of reach of the children and
do not allow them to play with. It contains

small parts that they can suffocate or can
hurt !
 Failure to comply with these
instructions may void the warranty on
the device
 Software and hardware of the mobile
phone are continuously updated. The
importer reserves the right to alter the
instruction manual or mobile phone
functions without a prior notice
lnsert SIM cards

Make sure that the mobile phone is
switched off. Loosen 2 screws on the back
side of the mobile phone and remove the
cover. Insert one or two SIM cards at the
prepared positions. Pictures by the
positions show in which way the SIM
cards should be inserted.
The phone is equipped with 2 slots for
microSIM cards. Next to SIM cards you
can also insert a MicroSD memory card.
Finally put the battery cover back and tighten
the screws. The screws must be properly
tightened to ensure a watertight seal, but
tighten them carefully not to cross the
thread.
If the package includes a screwdriver use
always the supplied screwdriver for
tightening of the screws.
Overtightening, breakage or other
mechanical damage of the screws are not
covered by warranty !
Mobile controls
1. But to n of t he L au nche d a pp licat io n
2. Button „Main screen“

. Button „Backwards“
4. Volume
5. Button „Switch On / Off „
6. Earphone
7. Ear ph on e co nn ec tor
8. Front camera
9. Micro USB connector
10. Button „Camera“
11. PTT Button
12. SOS Button
Switch on / off
To Turn n – press the button On/Off (5)
and wait for a while till the mobile phone is
on.
The setup wizard is displayed by the first
start. Choose your language and follow the
instructions on the screen.
To Turn off - press and hold the phone
button (5) until the display shows the
window asking to shut down. Then confirm
it and the mobile phone switches off.

Mobile phone reset
In case the phone does not respond or if
you need to reset it, press and hold the
On/Off button (5) until the phone
reboots.
Activation and screen unlock
The screen will be Switched Off after a certain
time of inactivity. You can Switch On/Off the
screen by a short press of the button (5).
Generally it is necessary to unlock the screen
after the activation. Put the finger on symbol
„Lock“ on the screen and move it Up, left (for
calling) or to the right (camera). The screen
will be unlocked.
Android™ operating system
Your mobile phone is provided with the
Android operating system. The mobile phone
is in fact a small personal computer which
can be connected to internet and in which
you can install a lot of various applications
free of charge (via Google Play™ store).

Basic control
Meaning of the touch buttons (1) to (3)
1) Launched applications/Menu –
serves to display a list of recently
opened applications. After a long
press displays the menu of items
available on the current screen or
in a running application
(2) Main screen – short press for return to
the main screen, long press helps to
display the Goggle search.
(3) Back – serves to move back by one
step/level (or to go to the preceding
screen, to close the options, dialog
windows on the screen etc.)
System control
Your mobile phone can be controlled by
the above mentioned buttons but mainly
with the use of the touch screen.
Just click on the selected item to confirm
the item on the screen, to confirm the
dialog windows or graphic buttons on the
screen.

Main screen
Same as on your PC you have available a
main screen on the mobile phone. The
main screen is devided into several pages
that can be displayed by moving of your
finger to the left/right direction. You can
place shortcuts of applications and links or
widgets on the main screen.
Widgets are mini-applications that enable
to display some data, control elements like
watches, weather, charging controll etc.
Google account
You need to have an adjusted Google™
account for the proper use of the system.
The account can be created very easily :
1. Click on the icon Settings on the main screen
2. Select the option Accounts and select
Add account
. Further follow the instructions on the screen
Applications
In the basic equipment of the mobile phone
there are applications for making calls,
sending SMS, emails but also for other useful
and entertaining applications.

There are thousands of various applications
suitable for Android system but not all of
them can work properly in your mobile
phone.
Before buying of any new application please
try first its gratis version if it works correctly
in your mobile phone.
Information and display of status
So called „Status bar“ is placed in the upper
part of the screen. You may find here the
information about time, battery level and
signal but also other useful information. For
example the information about new SMS,
information about the system or applications.
Status bar can be moved down by your finger
or rolled. You will get a detailed overview
about all announcements and information
including the possibility of a quick control of
some mobile functions.
Mobile phone setup
All items of the telephone set up are clearly
arranged at the settings menu. Press the
button Setup on the home page and make
desired changes.

Making calls
Dialling
Click on the earphone icon on the main
screen. Screen with keypad for number
dialling will be displayed. Tap the keyboard
icon at the bottom part of the screen to
display the keyboard. You can enter the
tel.number with the use of the keypad
buttons.
You can enter the tel.number with the use of
the keypad buttons. Similarly as on the
common telephone there are the letters
displayed on the buttons so you can enter
also the name. The dialled number and all
corresponding items of the tel.directory will
be displayed after entering of the letters on
the keys of the screen.
At the bottom part of the screen you can
find the calling button with a symbol of the
head-phone. You can dial the number by its
pressing and make your call.
Answer and reject the call
If somebody is calling you the information

about his telephone number and a button
with the receiver is displayed on the screen (if
available)
To answer the call : move the button to
the right towards the symbol of a Green
receiver
To reject the call : move the button to
the left towards the symbol of a Red
receiver
When working with your phone the call alert
appears as a dialog box with buttons for
admission ("Answer") or rejection of the call
("Close").
Call flow and finish of the call
The screen will automatically switch off
when the mobile phone is attached to the
ear. After the delay from the ear the screen
will switch on within few seconds.
The call can be finished by pressing of the
Red button on the screen.
SMS messages
1. Tap the icon at the bottom part of the
main screen.
2. A list of conversations containing received

and sent SMS and MMS messages will be
displayed
. Select the icon New Message with symbol +.
4. Now you can insert the receiver of the text
message.
5. To send the text message press the arrow
button placed on the right side of the text.
Choice of SIM card for calling, SMS and
internet
Click on icon Settings/Setup on the main
screen and choose the item SIM Cards. You
can choose which SIM card will be used for
calls, SMS and internet access.
Choice of network by difficulty with
connectivity
You can choose whether your phone will use a
2G network, G or 4G, respectively you can
switch between them automatically.
If you have problems with access to calls or
you can not be called despite showing
sufficient signal, restart mobile phone and
possibly temporarily disable the 4G network
connection:

Tap on the main screen and select Settings
icon in the Wireless connection &
networks click Next.
Further select the Mobile networks and
select preferred network type for each
SIM card. Now select GSM / WCDMA
auto (2G / G) or GSM only (2G only).
Photography
Start the camera by tapping the camera icon
or press and hold the side button (10). Aim
the camera at the scene and tap your finger
on the screen to the point that you want to
focus.
After focusing the scene you can take a
picture by pressing the shutter button on
the side of the display. Attention!
After focusing the scene you can take a
picture by pressing the shutter button on
the side of the display. Attention! Always
perform focus or wait for automatic focus and
then press the shutter button otherwise the
images may be blurred.

When you start the camera, you can take a
shot by a short press of the side button (10)
and make a video by a long press of the side
button (10).
S S button
You can easily run the emergency calls to preset
tel.numbers by pressing the SOS button.
To set - tap the Settings icon on the main screen
and choose Setting S S Button in section
Personal
PTT Button (Push-to-talk)
PTT button is possible to use for so-called
Push-to-talk communication in connection
with a suitable application, ie communication
with a group of friends or colleagues simply
by pressing a button, just as through radio
transmitters. The communication works via
Internet.
PTT function requires the installation of an
additional application Zello PTT Walkie Talkie
in your mobile phone.

More information to download see at
www.zello.com or look up the application in
the Google Play ™ store.
PC connection
You do not need any special drivers (Vista, 7,
event. newer) for connection to the
common PC . Follow these steps :
1. Connect the mobile phone with PC with the
enclosed data cabel
2. Drag the status bar down and click on the line
„Connected as...“
. Menu of the connection modes will be
opened. We recommend to use the
device mode for media MTP.
4. Subsequently, the phone will connect to a PC
as a "Media device"
5. Internal storage in your phone and
inserted MicroSD card will be connected to
a computer in the file Computer in section
Portable Devices and under the name
RX550.
Connection can be cancelled by disconnecting of
the cable.

Safety and ecology
Used electric device
Mobile phone is an electronic
appliance. It means it must not
be manipulated as a common
residential waste.
Never throw the used device away at the
common municipal waste !!! Hand over the
electric devices to the respective collection
point which provides the ecological
liquidation.
Battery liquidation
Used/old batteries and accumulators do not
belong to the common residential waste !!!
Hand over the battery or electric
devices to the respective
collection point which provides
the ecological liquidation.
Please contact your dealer to get more
information how to deal with the used
products. Do not put the battery at the fire
and do not expose it to the temperature

over +60°C (danger of explosion or fire)
Handling with the used batteries in
contradiction with given instructions is
illegal!
0700
Declaration of conformity
No. 20/2/2017
Issued in accordance with the prescription : EU R&TTE,
1999/5/EC
Product: Mobile Phone for GSM, WCDMA a LTE network
Model: ALIGATOR RX550
Importer: ADART COMPUTERS s.r.o., Sokolovská 161,
180 00 Praha 8, Reg.No. 25074547
Evaluated product is a mobile phone intended to be used and
stored in standard conditions. The importer declares that the
product is for its use safe and during the production there
are taken control and other measurements securing the
confirmity of the product with the basic requirements and
technical documentation. Relevant harmonized norms have
been applied to evaluate the conformity.
The tests of confirmity were carried out and the protocol
made by authorised person: PHOENIX TESTLAB GmbH,
Königswinkel 10, 2825 Blomberg, Germany.
The product bears the European conformity mark CE 0700 in
accordance with the prescriptions of the EU.
Issued in Prague, on 20.2.2017
ADART COMPUTERS s.r.o.
