ALIGATOR S5070 Duo 4-core IPS User manual

S5070 Duo 4-core IPS
Quick Guide

CONTENTS
Before you start...................................2
DUAL SIM function..............................3
Important instructions........................3
Mobile controls...................................6
Insert battery and SIM card.................7
S itch On / Off....................................8
Activation and screen unlock..............8
Select SIM for calls, SMS, internet......9
Operating system Android™................9
Basic control......................................10
Making calls.......................................14
Messages...........................................16
Selection of net ork.........................17
Photography......................................17
PC connection....................................18
Safety and ecology............................19
Declaration of conformity.................20
Before you start
Thank you for buying of our
ALIGATOR mobile phone
Before you start please read carefully
this instruction manual.
2

DUAL SIM function
Your mobile phone can be operated
ith 1 or 2 SIM cards. If you insert only
one SIM card the mobile phone orks
as an ordinary mobile phone.
In case you insert 2 SIM cards at the
mobile phone both are active at the
same time. It means you can be called
on both SIM cards at the same time
ithout any s itch bet een them.
Both cards are on line.
Important instructions
Do not use the mobile phone at the
prohibited areas . Do not use the
mobile phone hile driving the car
Do not use the mobile phone near the
medical appliances ithout having the
confirmation that the radio aves do
not influence its function
3

Mobile phone can influence the
function of the cardiac pacemakers or
other implanted appliances – please
consult your medical doctor
S itch off the mobile phone al ays in
the aircraft
Do not use mobile phone near the
petrol station. Al ays s itch off the
mobile phone near explosives
Use only the original batteries supplied
by the producer. Danger of damage of
the mobile phone or explostion
Do not thro the battery in the fire
nor expose it to the temperatures over
+60°C. Danger of explosion or fire
SAR – mobile phone meets all
prescriptions for maximal emision of
electromagnetic radiation
4

Please keep the mobile phone 2.5 cm
a ay from the body hile calling. You
lo er by that the quantity of
electromagnetic radiation absorbed
by your body
Handle the mobile phone ith care,
protect it from falling on the ground,
from mechanical damage, impurity or
high temperatures. Never pick it to
pieces !
Do not place the mobile phone or its
holder in the area above the airbag in
the car. Keep it out of reach of
children. It contains small parts that
could be s ollo ed or they may hurt
Soft are and hard are of the mobile
phone are continuously innovated. The
importer reserves the right to alter the
instruction manual or particular
functions of the mobile phone ithout
a prior notice.
5

Mobile controls
1. Button : APK
2. Button : Main screen
3. Button : Back ards
4. Button : Volume
6

5. Button : S itch On / Off
6. Earphones
7. Headset connector
8. Front camera
9. Micro USB connector
lnsert battery and SIM card
Slip your nail at the slot under the
battery cover in the corner on the back
side of the mobile phone and carefully
pull do n the cover.
Insert firstly one or t o SIM cards at
the prepared slots. Insert SIM and
also MicroSD memory cards (if you
have) as per the picture instruction.
Insert the battery. Make sure that the
battery clicks smoothly into the slot in
the mobile phone.
7

Put the battery cover back. Place the
cover on the back side of the mobile
phone and press gently around the
circuit untill the cover clicks properly
on its place.
Switch On / Off
To Switch On - press the button (5).
Starting of the mobile phone can last
fe seconds.
To Switch Off – press and hold the
button (5) till the indicator indo
of a s itch off appears on display.
Confirm it and the mobile phone ill
turn off.
Activation and screen unlock
The screen turns off automatically
after a certain time of inactivity. Turn
on / off the screen by a short press of
the button (5).
8

It is necessary to unlock the screen
after the activation. Put your finger on
a „Lock“ symbol and move it in the
up ards direction. The screen ill be
unlocked.
Selection of SIM card for calls,
SMS and internet
Tap on the main screen, click Settings
and select SIM card. No you can set
hich SIM card to be used for calls,
SMS and for internet.
Operating system Android™
Your mobile phones is provided ith
the operating system Android™ . The
device is in reality a small personal
computer that can be connected ith
internet from hich you can do nload
many useful applications (via Google
Play™ store).
9

Basic control
Meaning of the contact buttons
(1) to (3)
(1) Launched applications/APK –
serves to display a list of recent
applications. After a long press,
the menu items available on the
current screen or in a running
application ill be displayed
(2) Main screen – short press serves
to return to the main screen.
Long press displays the Google
search
(3) Backwards – serves to return by
one level back. (Jump on the
preceding screen, closing of
offers or dialog indo s on the
screen, etc.)
10

System control
Your phone is operated by using both
the buttons above, but mainly using
the touch screen. Selecting items on
the screen, confirming dialogs and
graphical buttons on the screen are
done by tapping on them.
Google account
It is necessary to create the Google™
account hich can be set up in
follo ing simple steps:
1. Press the button Settings
2. Select in menu Accounts and choose
Add Account
3. Further follow instructions on the
screen
11

Main screen
All installed applications can be
displayed by the button placed in the
middle of the lo er part of the main
screen.
In basic equipment of the mobile
phone you can find applications
for making call, sending
messages and e-mails or many
other useful applications.
There are thousands of various
applications suitable for Android
system but not all of them can ork
properly in your mobile phone.
Before buying of any ne
application please try first its gratis
version if it orks correctly in your
mobile phone.
12

Information and status display
So called „status bar“ is placed in the
upper part of the screen. You may find
here the information about time,
battery level and signal strength but
also other useful information. For
example the information about ne
SMS, information about the system or
applications. Status bar can be moved
do n by your finger and rolled. You
ill get a detailed overvie about all
announcements and information
including the possibility of a quick
control of some mobile functions
Mobile phone setup
All individual items of the telephone
set up are clearly arranged at the
settings menu.
Press the button Menu - select Set
up and make the required changes.
13

Making calls
Dialling
Click on the earphone icon on the
main screen. A screen ith keypad
for number dialling ill be displayed.
You can enter the tel.number ith
the use of the keypad buttons.
Similarly as on the common
telephone there are the letters
displayed on the buttons so you can
enter also the name.
The dialled number and all
corresponding items of the
telephone directory ill be
displayed after entering of the
letters on keys of the screen.
At the bottom part of the screen
you can find the calling button ith
a symbol of the head-phone. You
14

can dial the number by its pressing
and make your call.
Answer and Reject the call
If somebody is calling you the
information about his telephone
number (if available) and a button
ith the receiver is displayed on the
screen
to answer the call : move the button
to the right to ards the symbol of a
green receiver
to reject the call : move the button
to the left to ards the symbol of a
red receiver
Call flow / Finish of the call
The Screen shuts do n automatically
hen you hold the mobile near the
ear. The screen is activated in a fe
15

moments after delaying the phone
a ay from the ear.
Press the red button on the screen to
finish the call .
Messages
1 Click on the icon of Messages on the
lo er part of the main screen op
open the screen ith applications
and select the item Messenger
2 A list of conversations containing
received and sent SMS and MMS
messages ill be displayed.
3 Select the icon „+“ on the right
bottom part of the screen
4 No you can insert the receiver and
the text of the message
16

5 To send the message – press the
arro button placed on the right
side of the text
Selection of network
You can choose hether your phone
ill use 2G or 3G net ork.
Tap on the main screen on the icon
Settings and select Next in the
Wireless & networks section.
Next step, select Mobile networks
and select Preferred network type
for each SIM card. No select item
2G or 3G.
Photography
Start the camera by tapping on the
camera icon. Point the camera at the
scene that you need to focus or ait a
moment till the camera focuses on the
centre automatically.
17

Press the shutter button on the
display to take a picture of the scene.
Every once in a fe seconds, if the
scene is changed, the camera
automatically focuses on the center of
the image.
To speed up the focus or focus on
another part of the image, tap the
desired position on the display.
Attention! Always focus first or wait
for focus, then press the shutter
button, otherwise the images can
become blurred
PC connection
You do not need any special drivers
for connection to the common PC
(valid for OS Windo s Vista, 7, event.
ne er). Follo these steps :
18

1. Connect the mobile phone ith PC
ith the enclosed cabel
2. Do nload the status bar and tap the
line highlighted „Connected as...!
3. A connection mode offer is opened.
We recommend to use the device
mode for MTP media
4. The phone connects to the PC as a
„Media device“
After that the phone's Internal storage
and an inserted MicroSD card are
connected ith your computer in the
section Computer - Portable Devices,
under the name ALIGATOR S5070. The
connection can be cancelled by
disconnecting of the cable.
Safety and ecology
Used electric devices
Mobile phone is an
electronic appliance. It
means it must not be manipulated as
a common residential aste. Never
19

throw the used devices away at the
common municipal waste!!! They
may contain the substances
dangerous to the environment. Hand
over the product to the respective
collection point hich provides the
ecological liquidation. Please contact
your dealer to get more information
ho to deal ith the used products.
Battery liquidation
Used batteries and
accumulators do not belong
to ordinary municipal waste !!!
They may contain the substances
dangerous to the environment. Hand
over the battery to the respective
collection point hich provides the
ecological liquidation. Please contact
your dealer to get more information
ho to deal ith the used products.
20
