ALIGATOR A420 User manual

A420 – We begin
2

Contents
Contents..............................3
Mobile controls....................4
Putting into operation..........6
Switch on / off .....................8
Charging............................10
mergency call..................12
Making calls.......................15
Flashlight...........................18
Keyboard lock....................20
Safety instructions.............22
Used electric device..........24
3

Battery liquidation..............23
Mobile controls
1 Right functional button
2 Left functional button
3 Navigation button
up / down
4 Red button
5 Green button
6 Button 0
7 Button #
8 Button *
4

9 Micro USB connector
1
0
Connector DCjack 2mm
1
1
Flashlight
1
2
arphone
1
3
Flashlight switch
5

Putting into operation
Insert of battery and SIM card:
1. Remove the battery cover
on the back side of the
mobile phone and insert a
memory and SIM card (see
picture)
6

2. Insert the battery (see
picture). Three metal
contacts must lead
towards the bottom side of
the mobile phone.
3. 3. Put the battery cover
back. Your mobile phone is
now ready to use.
7

Switch on / off
To Switch on - press and
hold the ED button (4) till the
mobile turns on.
(Now you can be asked to
enter the PIN code in case
the PIN protection is
activated)
8

To Switch off - press and
hold the ED button (4), untill
the mobile turns off.
Before Switching On of the
mobile phone be sure that the
battery is inserted and is
charged.
9

Charging
Be sure that the battery is
placed at the mobile phone.
Connect it with the charger
and charging will start
automatically.
Mobile phone can be charged
even if it is in switched on or in
switched off mode.
10

Charging level is indicated on
the mobile screen:
Discharged Fully charged
After the battery is fully loaded
disconnect the charger from
the network and from the
mobile phone !
11

Mobile phone will warn you by
an acoustic signal and by
message on the screen when
the battery is almost
discharged. In this case
charge the battery as soon as
possible.
Emergency call
If you are in danger or you
need an assistance of your
12

relatives or your doctor, press
and hold the SOS button
placed on the back side of the
mobile phone.
Mobile will automatically start
to dial pre-set tel.numbers and
will send emergency SMSs to
these numbers including your
mobile position on the map.
13

Attention ! First you need to
activate this function in your
mobile. You must insert
correct tel.numbers which
should be contacted in case
of emergency.
If you do not insert the
tel.numbers the mobile /
SOS button will not work
properly.
14

Making calls
Dialling
Insert required phone number
on the mobile keyboard and
press the green button (5).
Mobile phone will start dialling
of required number.
If you have dialled by mistake
a wrong number, just press
15

the left button (1) and the last
digit will be deleted.
If you need to delete the
whole number, press and hold
the red button (4) untill the
whole number is deleted.
Answer / reject the call
For answering of the call
press the green button (5)
16

For rejecting of the call,
press the red button (4).
If somebody is calling, you will
see his telephone number on
the display.
If his number is stored in the
contact list you will see his
name on the display.
17

(Function of displaying of the
tel.number need not be
always available)
Flashlight
Mobile phone is provided with
a flashlight placed on the
upper side of the mobile
phone.
18

Flashlight can be turned on by
the switch (13) placed on the
side of the mobile phone.
Flashlight is provided with a
very economical light source
(L D).
Flashlight can be turned on
even in case the mobile
phone is switched off (with
charged battery)
19

Keyboard lock
Mobile phone is provided with
the keyboard lock which
prevents from the unwanted
press of the buttons (f.e.when
placed at the pocket).
Press the left button (2) and
immediatelly *(8) to LOCK the
keyboard.
20
