All Pond Solutions 200IF User manual

AQUARIUM INTERNAL FILTER
200IF / 300IF / 450IF / 600IF
/ 800IF / 1200IF

To ensure your new filter is set up and running correctly, and to prevent any
accidental damage or injury, please read and follow the below instructions
carefully before using your product.
SAFETY
IMPORTANT! Disconnect the mains electricity supply before attempting any
installation / maintenance of any kind. Do not attempt to modify this unit in
any way and only use the recommended parts for replacement.
· The unit should never be run dry as this will cause it to overheat and cause
permanent damage.
· All connections must be earthed.
· The power cord of this appliance cannot be replaced; if the cord is
damaged, the appliance should be discarded. Never cut the cord.
· Do not connect to any voltage other than that stated.
· This filter is suitable for indoor household aquariums only (do not use in
exterior locations, swimming pools, ponds, bathrooms etc). Do not place in
liquids other than water.
· Do not use with water above 90°F or 30°C.
· Do not carry or pull the unit by its electrical cable.
· Do not use this unit if it has a damaged cord or plug, if it is malfunctioning
or it is dropped or damaged in any manner
· Do not yank cord to pull plug from outlet. Grasp the plug and pull to
disconnect. Always unplug an appliance from an outlet when not in use.
· Do not attempt to modify this unit in any way and only use the
recommended parts for replacement.
· Before installing, maintaining or handling your equipment, or before placing
your hands in your aquarium, ensure that the unit is disconnected from the
electricity supply.
· Always unplug any electrical devices when not in use.

· The power cable must have a drip loop to
avoid any condensation build up reaching
the mains (see diagram 1). If the plug does
get wet, DO NOT unplug the cord.
Disconnect the fuse or circuit breaker that
supplies power to the appliance. Then
unplug and examine for presence of water in
receptacle.
· Carefully examine your filter after installation. Do not plug the unit in to the
mains if there is water on any parts not intended to be wet.
· If the unit shows any signs of water leakage, disconnect the power supply
cord from the wall socket and consult All Pond Solutions or the retailer you
purchased this unit from for further advice.
· If the plug or unit does get wet, DON'T unplug the cord. First, disconnect
the circuit breaker or fuse that supplies power to the appliance. Next,
unplug and inspect for water presence in the receptacle.
· To avoid injury, do not touch hot or moving parts such as, but not limited to
impellers.
Please note – this appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, provided they are given supervision and
instruction concerning use of the appliance and understand the hazards
involved. Children must not play with the appliance. Any maintenance must not
be made by children without supervision.
WARNING! MUST BE SUBMERGED Diagram 1
Aquarium
Tank
Power
Supply
Cord
Drip
Loop

ELECTRIC
This unit comes complete with a generous supply of 3 core cable, however
should any additional cable be required, the use of an approved waterproof
cable connector with a proper rating is essential. A cord rated for less amperes
or watts than the appliance rating may overheat.
Please Ensure:
· The power supply must be earthed and fused at 3amps.
· You regularly inspect the cable for damage and deterioration.
· Do not connect to any voltage other than that stated.
· You consult a qualified electrician if in doubt about any aspects of
wiring.

MAINTENANCE
To ensure optimal performance and that your unit functions correctly, regular
maintenance is essential. Failure to do so may result in damage to your unit and
may invalidate your warranty.
We recommend that a regular cleaning and maintenance schedule is followed
to ensure responsible fishkeeping. Depending on water volume and stocking
levels, regular cleaning of the filter media, foams, impeller, inlet/outlet
pipework during a 10-25% water change will help ensure that the product works
efficiently and the aquarium remains healthy.
For further maintenance guidance, please see the table and additional
information below:
1 MONTH
3 MONTHS
6 MONTHS
ANNUALLY
Impeller
Clean & Inspect
Replace
Shaft
Clean & Inspect
Replace
O-Rings*
Clean & Inspect
Lubricate &
Clean
Replace
Filter Foams &
Other Media
Clean & Inspect
Replace
* Please note the 200IF & 300IF models do not have O-rings.
In general, it is recommended to disconnect your filter and clean the impeller
and filter sponges monthly. The unit will become blocked with waste and
protein slime over time, so regular cleaning is important for optimal
performance.
The frequency of how often you will need to clean and inspect your unit of
course will depend on a lot of factors like how dirty the water is when you first
start using your filter, the volume of your water and also how many fish you
have. How often you feed your fish and how long your lighting is on for will also
affect how quickly your aquarium water gets dirty and will need to be taken into
consideration when planning how often to clean your unit.
It is vital that O-rings are regularly inspected and replaced as the rubber
watertight seal will perish over time, which may cause leaks. Before replacing
your o-rings, ensure they are well lubricated.
O-rings

Maintenance & Disassembling
Should you need to disassemble your unit for maintenance or repair purposes,
please follow the steps below:
IMPORTANT! Unplug the power cord from the mains before handling or
attempting maintenance. Move your unit to a flat stable surface near a sink or
other drain. (Be sure to hold upright to avoid spillages.)
Opening your filter - detach the pump from the filter body by pulling it.
600IF / 800IF / 1200IF models - gently depress the push clips located on both
sides and then pull away the body from the pump.
200 /300 / 450IF MODEL 600 / 800/1200IF MODEL
Impeller - can be accessed by removing the impeller cover.
200/300IF models - pull the impeller cover away from the pump’s body.
450IF - rotate the impeller cover in anti clock direction.
600/800/1200IF models - turn the impeller cover so the grooves line up and
lift to reveal the impeller.
The impeller can then be gently pulled away from the housing and inspected.
Clean your impeller with your aquarium water (from a water change). Ensure
that the plastic propeller part of the impeller is attached to the ceramic part
and that they have not come apart or split. If this is the case you need to
replace your impeller. Make sure the O-ring is in place, lubricated and secure
before reassembling your unit (450/600/800 & 1200IF models only).
200 /300IF MODEL 450IF MODEL 600 / 800/1200IF MODEL

The IF filter pipework can be adapted and used in one of two ways:
Outlet with venturi pipe - insert the air pipe into the front of the filter. Connect
the venturi air pipe to the air intake valve. Connect the other end to the air pipe.
Make sure the black air intake valve on the end of the venturi pipe is placed
outside of the water.
*The 450IF model includes an active carbon tray you can access by removing
the filter case. You can also adjust the flow rate by shifting the lever at the front
of the filter case.
450IF MODEL ONLY
Remove and clean filter sponges and filter media - clean through the included
media* and filter foam.
600IF / 800IF / 1200IF models - gently depress the push clips located on both
sides and then pull away the filter bottom from the case to access the bottom
foam.
Rinse them in with your aquarium water to prevent damaging the beneficial
bacteria which help maintain a healthy fish tank.
200 /300 / 450IF MODEL 600 / 800/1200IF MODEL

TROUBLESHOOTING
No Filter Operation / Water Flow
Please note: A clogged impeller is often the primary cause of all filter faults,
so it is extremely important to clean and inspect your impeller every month
to ensure it is functioning correctly and remove any debris. Keeping the
impeller clean will improve the performance of your filter and lengthen the
life of the motor. The impeller itself is a perishable part and will be subject to
wear and tear overtime. As a result, it is also very important to replace your
impeller and ceramic shaft annually.
Your filter foam/s will be saturated with water. Place them in your sink or a
large bucket.
Rinse the inside of the filter casing with clear aquarium water. NEVER use
tap water, or soap or detergents, when cleaning your unit or rinsing media.
Make sure no debris is trapped inside.
Once everything is clean reassemble your filter and top up your aquarium
tank water level from any water used and reconnect the power cord to the
mains.
Solutions:
ŸAlways ensure the power has been turned on.
ŸCheck that your impeller and shaft are seated correctly and not
damaged in any way.
ŸEnsure the impeller is free of any type of blockage and can rotate freely
inside the motor head.
Spray bar
800IF comes supplied with 2 air pipes
1200IF comes supplied with 3 air pipes
Ensure the IF is fully submerged at all times.
200 /300 / 450IF MODEL 600 / 800/1200IF MODEL

The Water In My Aquarium Is Dirty
Causes:
ŸThe beneficial bacteria have not yet established in your new filter.
ŸYour filter is not the correct size for your aquarium set up.
ŸYou have too many fish for your size filter.
ŸYour filter media may be dirty.
Solutions:
ŸYour fish tank can take up to 3 weeks to successfully cycle. You may also
want to add a bacteria start treatment to your tank to speed up this
process.
ŸYou may need to upgrade to a larger filter.
ŸFor reference, you should allow 1 gallon of water per 1 inch of fish in your
aquarium.
ŸFollow the instructions in the maintenance section above.
ŸIf you have not yet done so, you may also need to carry out more regular
water changes in your tank.
No Water Is Coming Out Of My Filter
Causes:
ŸThe impeller is blocked - please refer to the impeller maintenance
section above.
ŸThere is no water in the filter body
ŸThe filter is not switched on.
ŸThe inlet pipe is clogged.
Solutions:
ŸUse a small jug and scoop some water from the surface of your tank and
pour into the filter body.
ŸCheck your filter is plugged into the mains and is switched on.
ŸRemove the filter from your tank and clean the inlet pipe.
Noisy Operation
Solutions:
ŸCheck that your impeller and shaft are seated correctly and not
damaged in any way.
ŸEnsure the impeller is free of any type of blockage and can rotate freely
inside the motor head.

COMMON AQUARIUM QUESTIONS
Why Is My Aquarium Water Cloudy?
Causes:
ŸBacterial blossom - As the new aquarium goes through the initial
break-in cycle, the water can become cloudy or at least a little hazy. It
might take several weeks to establish beneficial bacterial colonies that
are able to clear waste from the water. Over time, that cloudiness will
resolve itself. Decaying plants or excess food that remains uneaten can
also cause the cloudy water seen in bacterial bloom. Keep the
aquarium clean by removing any decaying plants and uneaten food,
vacuuming the gravel regularly, and performing partial water changes.
It is also a good idea to invest in a UV steriliser, which simply kills the
microorganisms creating the cloudy aquarium water problem and
helps to control algae issues.
ŸGravel residue - If the water is cloudy immediately or within an hour or
two of filling the tank, it's probably due to insufficiently washed gravel.
Drain the tank and rinse the gravel until the water runs clear. That
should resolve the problem.
Ÿif washing the gravel doesn't solve the Dissolved constituents -
problem, the next most likely cause of cloudy water in a newly filled
tank is a high level of dissolved constituents, such as phosphates,
silicates, or heavy metals. If you test the water, you'll likely find that the
pH is high (alkaline). In these cases, treating the water with conditioners
will often resolve the problem.
Other things to try:
ŸReduce feeding. Overfeeding introduces a lot of organic waste and is
one of the main causes for cloudy water problems.
ŸDo not perform large water changes as they can severely affect the
balance of the aquarium leading to a further deterioration of the water
quality.
ŸA severely overstocked aquarium will result in excess waste so consider
your fish population. We recommend to not exceed 1 inch of fish per 3.7
litres of aquarium water.
Why Is My Aquarium Water Green?
Causes:
ŸToo much light - Reduce the amount of time the lights are on, and
move the aquarium to a location out of direct sunlight. This will reduce
the photosynthesis that allows the algae to grow.

ŸPhosphates - phosphates result from decaying matter (e.g. fish food)
and from the water source. If your water naturally has a high level of
phosphate, you will need to use a phosphate remover to treat it after
water changes. You may also consider reducing the amount of food you
give your fish.
ŸNitrates - As the amount of fish waste rises so do the nitrates. Make
sure to perform regular water changes, check your filter is clean and
adequate for your aquarium size and do not overstock it.
Other things to try:
ŸUse a UV water steriliser. Algal cells are damaged by the harmful UV
light so continuous use should ensure clear water at all times.

PARTS DIAGRAM
200/300IF MODEL
1
2
3
4
5
6
7
8
450IF MODEL
1
2
3
4
5
6
7
9
10
11
10
11
9
14
12
13
FILTER FOAM
IMPELLER
PUMP
IMPELLER COVER
CURVED PIPE
FILTER CASE
PIPE CONNECTOR
1
2
3
4
5
6
7
SPRAY BAR
8
AIR PIPE
VENTURI AIR PIPE
9
10
AIR INTAKE VALVE
11
IMPELLER
PUMP
1
2
FLOW ADJUSTER CASE
IMPELLER COVER
FILTER FOAM
FILTER MEDIA BOX
FILTER CASE
4
5
6
7
8
CURVED PIPE
9
PIPE CONNECTOR
10
SPRAY BAR
11
AIR INTAKE VALVE
13
AIR PIPE
14
8
VENTURI AIR PIPE
12
IMPELLER O-RING
3

PARTS DIAGRAM
O-RING
SUCTION CUP PLATE
SUCTION CUPS
PUMP
STAINLESS STEEL SHAFT
IMPELLER
IMPELLER COVER
1
2
3
4
5
6
7
FILTER CASE CONNECTION
8
FILTER FOAM
FILTER CASING
9
10
FILTER BOTTOM
11
SPRAY BAR END
12
SPRAY BAR
13
CURVED PIPE
14
AIR PIPE
15
VENTURI AIR PIPE
16
AIR INTAKE VALVE
17
600IF
123
4
5
6
7
8
9
10
11 12
13
314
15
16
17

PARTS DIAGRAM
O-RING
SUCTION CUP PLATE
SUCTION CUPS
PUMP
STAINLESS STEEL SHAFT
IMPELLER
IMPELLER COVER
1
2
3
4
5
6
7
FILTER CASE CONNECTION
8
FILTER FOAM
FILTER CASING
9
10
FILTER BOTTOM
11
SPRAY BAR END
12
SPRAY BAR
13
CURVED PIPE
14
AIR PIPE
15
VENTURI AIR PIPE
16
AIR INTAKE VALVE
17
800IF
12
3
4
5
6
7
9
10
11 12
13
14
15
16
17
8

PARTS DIAGRAM
O-RING
SUCTION CUP PLATE
SUCTION CUPS
PUMP
STAINLESS STEEL SHAFT
IMPELLER
IMPELLER COVER
1
2
3
4
5
6
7
FILTER CASE CONNECTION
8
FILTER CASING
9
FILTER FOAM
10
FILTER BOTTOM
11
SPRAY BAR END
12
SPRAY BAR
13
CURVED PIPE
14
AIR PIPE
15
VENTURI AIR PIPE
16
AIR INTAKE VALVE
17
12
3
4
5
6
7
9
10
8
11
14
15
12
13
16 17
1200IF

MODEL
VOLTAGE
POWER
H-MAX
MAX OUTPUT
DIMENSIONS
(mm)
200IF 3000IF 450IF 600IF
220-240V
2W 2W 6W 10W
0.45M 0.6M 0.9M 1.1M
200L/H 300L/H 450L/H 600L/H
32x38x105 36x44x115 43x53x112 76x505x152
SPECIFICATIONS
800IF
16W
1.4M
800L/H
95x62x287
1200IF
22W
2M
1200L/H
74x70x382
MAX AQUARIUM
VOLUME
35L 70L 90L 110L 150L 250L
HEIGHT MAX

WARRANTY
The All Pond Solutions IF filter range is guaranteed against defects in material or
workmanship under normal aquarium usage and comes with 12 months
warranty for all electrical parts. The warranty period commences from the date
of purchase.
If you require support on how to use your unit, replacement parts or if your filter
develops a fault during the warranty period, please contact the supplier of your
unit.
Non-replaceable, non-perishable and non-serviceable parts will be repaired or
replaced free of charge, once the unit is returned with all components along
with a valid proof of purchase and postage paid. We reserve the right to replace
or repair the unit at our discretion.
Please be aware that perishable parts that are subject to normal wear and tear,
such as impellers, impeller covers and motor seals are not covered by your
warranty and a charge may be required for replacements of these.
This warranty does not apply to any unit that has been subjected to misuse,
accidental damage, negligence, tampering or customisation. It does not apply
to units which have been assembled incorrectly, improperly maintained, or
where the instructions and safety information in this manual has not been
followed correctly.
No liability is assumed with respect to loss or damage to livestock or personal
property irrespective of the cause thereof.
Please ensure that only genuine All Pond Solutions components are used when
completing a replacement or repair. Spare parts are available at our official
website or from your local supplier.
Before returning your unit under warranty terms, check that all setup and
maintenance instructions have been correctly followed. If you are in doubt,
please contact your local aquatic retailer for further advice before returning the
product.
This does not affect your statutory rights.

www.allpondsolutions.co.uk
All Pet Solutions Limited Trading as All Pond Solutions
Unit 203 Riverside Way, Uxbridge, Middlesex,
England, UB8 2YF
