All Pond Solutions 700IF+ User manual

AQUARIUM INTERNAL
FILTER WITH UV
700IF+
TANKS UP TO 150L
9w UV STERILISATION
LOW NOISE | HIGH OUTPUT
FULLY SUBMERSIBLE FILTRATION PUMP
9w UV STERILISATION
INCLUDES VENTURI PIPE
700 LITRES PER HOUR

To ensure your new aquarium filter is set up and running correctly, and to prevent
any accidental damage or injury, please read and follow the below instructions
carefully before using your product.
SAFETY
IMPORTANT! Disconnect the mains electricity supply before attempting any
installation / maintenance of any kind. Do not attempt to modify this unit in
any way and only use the recommended parts for replacement.
· The unit should never be run dry as this will cause it to overheat and cause
permanent damage.
· All connections must be earthed.
· The power cord of this appliance cannot be replaced; if the cord is
damaged, the appliance should be discarded. Never cut the cord.
· Do not connect to any voltage other than that stated.
· This filter is suitable for indoor household aquariums only (do not use in
exterior locations, swimming pools, ponds, bathrooms etc). Do not place in
liquids other than water.
· Do not use with water above 90F or 30C.
· Do not carry or pull the unit by its electrical cable.
· Do not use this unit if it has a damaged cord or plug, if it is malfunctioning
or it is dropped or damaged in any manner
· Do not yank cord to pull plug from outlet. Grasp the plug and pull to
disconnect. Always unplug an appliance from an outlet when not in use.
· Do not attempt to modify this unit in any way and only use the
recommended parts for replacement.
· Before installing, maintaining or handling your equipment, or before placing
your hands in your aquarium, ensure that the unit is disconnected from the
electricity supply.
· Always unplug any electrical devices when not in use.

PARTS DIAGRAM
16
15
17
18
12
13
14 15
1
2
3
4
5
6
11
10
7
8
9
IMPELLER CHAMBER
TOP COVER
AIR INLET VALVE
BIO BALLS BASKET
IMPELLER
BEARING
1
2
3
4
5
6
FILTER CASING
10
11
12 O-RING
BASE
SUCTION CUPS
10
11
12
SCREW
SCREW NUT
QUARTZ TUBE
13
14
15
MOTOR
7
UV BULB
8
5LAMP TUBE PROTECTIVE SLEEVE
9
UV BULB
8
5BULB PROTECTOR CAP
9
FILTER BODY
16
UV BULB
8
5LAMP TUBE PROTECTIVE SLEEVE
9
SPONGE
17
5BACK COVER
18

· The power cable must have a drip loop to
avoid any condensation build up reaching
the mains (see diagram 1). If the plug does
get wet, DO NOT unplug the cord.
Disconnect the fuse or circuit breaker that
supplies power to the appliance. Then
unplug and examine for presence of water in
receptacle.
· Carefully examine your filter after installation. Do not plug the unit in to the
mains if there is water on any parts not intended to be wet.
· If the unit shows any signs of water leakage, disconnect the power supply
cord from the wall socket and consult All Pond Solutions or the retailer you
purchased this unit from for further advice.
· If the plug does get wet, DON'T unplug the cord. First, disconnect the
circuit breaker or fuse that supplies power to the appliance. Next, unplug
and inspect for water presence in the receptacle.
· To avoid injury, do not touch hot or moving parts such as, but not limited to
impellers.
Please note – this appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, provided they are given supervision and
instruction concerning use of the appliance and understand the hazards
involved. Children must not play with the appliance. Any maintenance must not
be made by children without supervision.
WARNING! MUST BE SUBMERGED Diagram 1
Aquarium
Tank
Power
Supply
Cord
Drip
Loop

ELECTRIC
This unit comes complete with a generous supply of 3 core cable, however
should any additional cable be required, the use of an approved waterproof
cable connector with a proper rating is essential. A cord rated for less amperes
or watts than the appliance rating may overheat.
Please Ensure:
· The power supply must be earthed and fused at 3amps.
· You regularly inspect the cable for damage and deterioration.
· Do not connect to any voltage other than that stated.
· You consult a qualified electrician if in doubt about any aspects of
wiring.
MAINTENANCE
To ensure optimal performance and that your unit functions correctly, regular
maintenance is essential. Failure to do so may result in damage to your unit and
may invalidate your warranty.
We recommend that a regular cleaning and maintenance schedule is followed
to ensure responsible fishkeeping. Depending on water volume and stocking
levels, regular cleaning of the filter media, foams, impeller, inlet/outlet
pipework during a 10-25% water change will help ensure that the product works
efficiently and the aquarium remains healthy.
For further maintenance guidance, please see the table and additional
information below:
1 MONTH
3 MONTHS
6 MONTHS
ANNUALLY
Impeller
Clean & Inspect
Replace
Shaft
Clean & Inspect
Replace
O-Rings
Clean & Inspect
Lubricate &
Clean
Replace
Filter Foam &
Other Media
Clean & Inspect
Replace as
required
UV Bulb
Replace
Quartz Sleeve
Clean & Inspect

In general, it is recommended to disconnect your filter and clean the impeller
and sponge monthly. The unit will become blocked with waste and protein
slime over time, so regular cleaning is important for optimal performance.
The frequency of how often you will need to clean and inspect your unit of
course will depend on a lot of factors like how dirty the water is when you first
start using your filter, the volume of your water and also how many fish you
have. How often you feed your fish and how long your lighting is on for will also
affect how quickly your aquarium water gets dirty and will need to be taken into
consideration when planning how often to clean your unit.
UV OPERATION
It is vital that O-rings are regularly inspected and replaced as the rubber
watertight seal will perish over time, which may cause leaks. Before replacing
your o-rings, ensure they are well lubricated.
O-rings
· Always ensure that the filter has water flowing through the unit prior to
operating the UV.
· Never look directly at the UV light when operational.
· Check that the UV is operational visually using the UV indicator.
· Never operate the UV lamp outside its housing.
· Never operate the UV lamp in a housing that’s defective
NEVER look directly at the UV light.
When replacing your UV bulb, use this time to clean your quartz sleeve and
carefully examine for any damage or cracks. Take care when handling the
quartz sleeve and UV bulb to avoid any damage to the glass.
Replacing the UV Bulb

Unplug your filter at the mains and remove the plug from the socket.
Remove the IF+ from the aquarium.
Remove the Body by squeezing both pressure points on the side of the body
and pulling the motor and body apart.
Unscrew the screw and twist the screw nut counter clockwise. Gently pull the
quartz sleeve to access the UV bulb (leave the O-ring located underneath the
quartz glass in place).
Once cooled, UV bulb can be safely removed by gently
moving it from side to side and pulling free of unit.
Remove the old UV bulb and replace with a new UV bulb
Replace the quartz glass ensuring the o-ring at the
quartz base is present.
Reattach the screw nut and screw, replace the 700IF+ body.
IMPORTANT! Check regularly that your UV light is operational by looking at the
UV light indicator located on the front of the 700IF+. This will light up blue if the
UV light is working.
Always change your UV bulb every six months regardless of it working or not,
as its performance will lessen by this stage.
Impeller
Please note: A clogged impeller is often the primary cause of all filter faults,
so it is extremely important to clean and inspect your impeller every month to
ensure it is functioning correctly and remove any debris. Keeping the impeller
clean will improve the performance of your filter and lengthen the life of the
motor. The impeller itself is a perishable part and will be subject to wear and
tear overtime. As a result, it is also very important to replace your impeller and
ceramic shaft annually.

Filter foam can be used repeatedly and can simply be washed in aquarium
water between uses to remove a build-up of dirt, sludge and grime.
However, If your filter sponge is tearing or beginning to wear, consider
replacing it.
The 700IF+ foam can be accessed by removing the base of the body.
To access the filter media remove the top cover from the unit by squeezing
both pressure points on the side of the it and pulling the cover and body apart.
IMPORTANT! Never use tap water, or soap or detergents, when cleaning your
unit or rinsing media. Make sure no debris is trapped inside.
Filter Foam & Media
Remove the top cover from the unit by squeezing both pressure points on the
side of the it and pulling the cover and body apart. The impeller can be
accessed by removing the adjustable outlet.
The impeller can then be gently pulled away from the housing and inspected.
Ensure that the plastic propeller part of the impeller is attached to the
magnetic part and that they have not come apart or split. If this is the case you
need to replace your impeller. Wash parts with fresh water carefully.

Set Up
Should you need to disassemble your unit for maintenance or repair purposes,
please follow the steps below:
Unplug the power cord from the mains. Move your unit to a flat stable surface
near a sink or other drain. (Be sure to hold upright to avoid spillages.)
Remove all parts from the box to check all parts are present.
Before Installation check that the UV bulb inside the IF+ is installed correctly.
Remove the body by squeezing both pressure points
on the side of the body and pulling the motor and body
apart. Visually check that the UV bulb is inserted still
and has not been knocked out of its connection point.
Attach the Suction Cups to the Base Plate. Make sure
you twist them by 90 degrees (as per photo below) or they will keep falling out.
attach the base plate to the back of the IF+.
Attach the Venturi Outlet to the top of the unit and place the IF+ inside your fish
tank with the suction cups against the glass in your preferred location. Make
sure the venturi outlet is positioned above the water level.
IMPORTANT! Ensure this location allows the IF+ to be fully submerged at all
times
Turn the UV on by sliding the front On / Off switch to the left.
Plug the IF+ into the mains ensuring that you leave a drip loop in the cable to
avoid condensation running down the power cable towards your mains power
socket.

TROUBLESHOOTING
Slow Flow RateNo Filter Operation / Slow Flow Rate
1. Always ensure the power has been turned on.
2. Follow the maintenance section. Ensure the water outlet is not blocked.
3. Locate the impeller and shaft and inspect for damage and clear the fittings
and parts of any waste build-up.
4. Check that your impeller and shaft are seated correctly.
5. Ensure the impeller is free of any type of blockage and can rotate freely
inside the motor head.
Slow Flow RateNoisy Operation
1. Locate the impeller and shaft and inspect for damage and clear the fittings
and parts of any waste build-up.
2. Check that your impeller and shaft are seated correctly.
3. Ensure the impeller is free of any type of blockage and can rotate freely
inside the motor head.
The Light on My 700IF+ Isn't Working
If the UV indicator at the front of the filter is not lighting up follow these
troubleshooting steps:
1. Clean the UV indicator.
2. Check that you have power from the mains supply.
3. Please check for signs of damage or water ingress to
quartz sleeve and bulb area. You might need to
replace your quartz sleeve and/or O-Rings if that’s the
case. Ensure that all O-rings are in place and well lubricated.
5. If the above does not solve the issue replace the UV bulb.
6. If you find that the UV light is still not operational after the bulb replacement,
the UV ballast may have developed a fault and you will need to contact the
supplier of your unit to obtain replacement parts.
Please remember that UV bulb should be replaced every 6 months.

COMMON AQUARIUM QUESTIONS
Why Is My Aquarium Water Cloudy?
Causes:
ŸBacterial blossom - As the new aquarium goes through the initial break-in
cycle, the water can become cloudy or at least a little hazy. It might take
several weeks to establish beneficial bacterial colonies that are able to
clear waste from the water. Over time, that cloudiness will resolve itself.
Decaying plants or excess food that remains uneaten can also cause the
cloudy water seen in bacterial bloom. Keep the aquarium clean by
removing any decaying plants and uneaten food, vacuuming the gravel
regularly, and performing partial water changes.
ŸGravel residue - If the water is cloudy immediately or within an hour or two
of filling the tank, it's probably due to insufficiently washed gravel. Drain the
tank and rinse the gravel until the water runs clear. That should resolve the
problem.
Ÿif washing the gravel doesn't solve the problem, Dissolved constituents -
the next most likely cause of cloudy water in a newly filled tank is a high
level of dissolved constituents, such as phosphates, silicates, or heavy
metals. If you test the water, you'll likely find that the pH is high (alkaline). In
these cases, treating the water with conditioners will often resolve the
problem.
Other things to try:
ŸReduce feeding. Overfeeding introduces a lot of organic waste and is one of
the main causes for cloudy water problems.
ŸDo not perform large water changes as they can severely affect the balance
of the aquarium leading to a further deterioration of the water quality.
ŸA severely overstocked aquarium will result in excess waste so consider
your fish population. We recommend to not exceed 1 inch of fish per 3.7 litres
of aquarium water.
Why Is My Aquarium Water Green?
ŸToo much light - Reduce the amount of time the lights are on, and move
the aquarium to a location out of direct sunlight. This will reduce the
photosynthesis that allows the algae to grow.
ŸPhosphates - phosphates result from decaying matter (e.g. fish food) and
from the water source. If your water naturally has a high level of phosphate,
you will need to use a phosphate remover to treat it after water changes.

The Water In My Aquarium Is Dirty
Causes:
ŸThe beneficial bacteria have not yet established in your new filter.
ŸYour filter is not the correct size for your aquarium set up.
ŸYou have too many fish for your size filter.
ŸYour filter media may be dirty.
Solutions:
ŸYour fish tank can take up to 3 weeks to successfully cycle. You may also
want to add a bacteria start treatment to your tank to speed up this process.
ŸYou may need to upgrade to a larger filter.
ŸFor reference, you should allow 1 gallon of water per 1 inch of fish in your
aquarium.
ŸFollow the instructions in the maintenance section.
ŸIf you have not yet done so, you may also need to carry out more regular
water changes in your tank.
No Water Is Coming Out Of My Filter
Causes:
ŸThe impeller is blocked - please refer to the impeller maintenance section.
ŸThe filter is not switched on.
ŸThe inlet sides are clogged.
Solutions:
ŸCheck your filter is plugged into the mains and is switched on.
ŸRemove the filter from your tank and clean the filter’s body.
You may also consider reducing the amount of food you give your fish.
ŸNitrates - As the amount of fish waste rises so do the nitrates. Make sure to
perform regular water changes, check your filter is clean and adequate for
your aquarium size and do not overstock it.

WARRANTY
The All Pond Solutions 700IF+ is guaranteed against defects in material or
workmanship under normal aquarium usage and comes with 12 months
warranty for all electrical parts. The warranty period commences from the date
of purchase.
If you require support on how to use your unit, replacement parts or if your
filtration develops a fault during the warranty period, please contact the
supplier of your unit.
Non-replaceable, non-perishable and non-serviceable parts will be repaired or
replaced free of charge, once the unit is returned with all components along
with a valid proof of purchase and postage paid. We reserve the right to replace
or repair the unit at our discretion.
Please be aware that perishable parts that are subject to normal wear and tear,
such as impellers, impeller covers and motor seals are not covered by your
warranty and a charge may be required for replacements of these.
This warranty does not apply to any unit that has been subjected to misuse,
accidental damage, negligence, tampering or customisation. It does not apply
to units which have been assembled incorrectly, improperly maintained, or
where the instructions and safety information in this manual has not been
followed correctly.
SPECIFICATIONS
UV POWER
POWER
MAX OUTPUT
MAX TANK VOLUME
DIMENSIONS
(LxWxH) mm
20W
700L/H
150L
76X90X290
9W

No liability is assumed with respect to loss or damage to livestock or personal
property irrespective of the cause thereof.
Please ensure that only genuine All Pond Solutions components are used when
completing a replacement or repair. Spare parts are available at our official
website or from your local supplier.
Before returning your unit under warranty terms, check that all setup and
maintenance instructions have been correctly followed. If you are in doubt,
please contact your local aquatic retailer for further advice before returning the
product.
This does not affect your statutory rights.

www.allpondsolutions.co.uk
All Pet Solutions Limited Trading as All Pond Solutions
Unit 203 Riverside Way, Uxbridge, Middlesex,
England, UB8 2YF
