Allen-Bradley SLC 500 User manual

Installation
and
Operation
Manual
SLC 500tModular
Hardware Style
(Cat. Nos. 1747-L511, 1747-L514,
1747-L524, 1747-L531, 1747-L532,
1747-L541, 1747-L542, 1747-L543,
1747-L551, 1747-L552, and
1747-L553)
Allen-Bradley
AB PLCs

Because of the variety of uses for the products described in this
publication, those responsible for the application and use of this
control equipment must satisfy themselves that all necessary steps
have been taken to assure that each application and use meets all
performance and safety requirements, including any applicable laws,
regulations, codes and standards.
The illustrations, charts, sample programs and layout examples
shown in this guide are intended solely for purposes of example.
Since there are many variables and requirements associated with any
particular installation, Allen-Bradley does not assume responsibility
or liability (to include intellectual property liability) for actual use
based upon the examples shown in this publication.
Allen-Bradley publication SGI-1.1, Safety Guidelines for the
Application, Installation, and Maintenance of Solid-State Control
(available from your local Allen-Bradley office), describes some
important differences between solid-state equipment and
electromechanical devices that should be taken into consideration
when applying products such as those described in this publication.
Reproduction of the contents of this copyrighted publication, in
whole or in part, without written permission of Allen-Bradley
Company, Inc., is prohibited.
Throughout this manual we use notes to make you aware of safety
considerations:
!ATTENTION: Identifies information about practices
or circumstances that can lead to personal injury or
death, property damage or economic loss.
Attention statements help you to:
•identify a hazard
•avoid the hazard
•recognize the consequences
Important: Identifies information that is critical for successful
application and understanding of the product.
PLC, PLC–2, PLC–3, and PLC–5 are registered trademarks of Rockwell Automation. SLC, SLC 500, SLC 5/01, SLC 5/02, SLC 5/03, SLC 5/04, SLC
5/05, PanelView, PanelView 550, PanelView 900, RediPANEL, ControlView, PBASE, DH+, DTAM, DeviceNet, and Dataliner are trademarks of
Rockwell Automation. RSLogix 500 and RSLinx are trademarks of Rockwell Software, Inc. Ethernet is a registered trademark of Digital Equipment
Corporation, Intel, and Xerox Corporation. IBM is a registered trademark of International Business Machines, Incorporated. Multimodem is a
trademark of Multi–Tech Systems, Inc. Procomm is a registered trademark of Datastorm Technologies, Inc. Tandy is a trademark of the Tandy
Corporation. Gateway 2000 is a trademark of Gateway 2000, Inc. Toshiba is a trademark of Toshiba America, Inc. Compaq is a registered trademark
of Compaq Computer Corporation. Deskpro is a trademark of Compaq Computer Corporation. Intel is a trademark of Intel Corporation.
Important User
Information

Publication 1747-6.2

The information below summarizes the changes to this manual since
the last printing.
To help you find new information and updated information in this
release of the manual, we have included change bars as shown to the
right of this paragraph.
The table below lists sections that document new features and
additional information about existing features, and shows where to
find this new information.
For This New Information See Chapter
SLC 5/05 Ethernet Processor
1, 2, 5, 6, 8, 9, 10, 11
App.A
App. B
App. D
App. E
App. F
App. G
SLC 5/03 8K Processor 1, 2, 5, 6, 10, 11
App. E
App. F
1746–P5 Power Supply 1, 2, 6
App. F
Grounding Guidelines 3
Power Considerations: Isolation Transformer protection
information and Power-Distribution System Diagram 3
1761-NET-AIC Advanced Interface Converter 4
1746-IC16 Discrete Input Module 7, 11
App. E
App. F
1746-IH16 Discrete Input Module 7, 11
App. E
App. F
1746-OB16E Discrete Output Module App. E
App. F
1746-NI8 Analog Input Module App. E
App. F
New Information
AB PLCs

Table of Contents iii
Publication 1747-6.2
Table of Contents
Preface
Who Should Use this Manual P–1. . . . . . . . . . . . . . . . . . . . . . . . . . .
How
to Use this Manual P–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents
of this Manual P–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related
Documentation P–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conventions
Used in this Manual P–4. . . . . . . . . . . . . . . . . . . . . . . .
Allen-Bradley
Support P–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Local
Product Support P–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Product Assistance P–4. . . . . . . . . . . . . . . . . . . . . . . . .
Your Questions or Comments on this Manual P–4. . . . . . . . . . . . . .
Chapter 1
Required T ools and Equipment 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
Procedures
1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
European Union Directive Compliance 2–1 . . . . . . . . . . . . . . . . . . . . .
EMC Directive
2–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Y
our SLC 500 Controller Can Do for Y ou 2–2 . . . . . . . . . . . . . . .
Overview
of Y our Modular Control System 2–2 . . . . . . . . . . . . . . . . . .
Principles
of Machine Control 2–3 . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Chassis
2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Modular Processors
2–4 . . . . . . . . . . . . . . . . . . . . . . . . . .
Processor
Features 2–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Processor Communication Options
2–5 . . . . . . . . . . . . . . . . . . . . .
Physical
Connection Options 2–5 . . . . . . . . . . . . . . . . . . . . . . .
Protocol
Options 2–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SLC 500 System T
est General Specifications 2–8 . . . . . . . . . . . . . .
Processor
General Specifications 2–9 . . . . . . . . . . . . . . . . . . . . . .
Memory
Backup for the 1747-L51 1, SLC 5/01 Processor 2–10 . . . . . .
Selecting Discrete I/O Modules
2–10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Specialty I/O Modules
2–10 . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting
Power Supplies 2–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power
Supply Specifications 2–1 1. . . . . . . . . . . . . . . . . . . . . . . . . .
Example
for Selecting Power Supplies 2–12 . . . . . . . . . . . . . . . . . . .
Example — W
orksheet for Selecting a 1746 Power Supply 2–14 . . . .
Selecting Enclosures
2–15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting
Operator Interfaces 2–15 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming
with a Hand-Held T erminal 2–15 . . . . . . . . . . . . . . . . .
Programming
with an IBMr Compatible Computer 2–15 . . . . . . . . . . .
AIC+
Advanced Interface Converter (1761-NET -AIC) 2–15 . . . . . .
Quick Start for Experienced
Users
Selecting Your Hardware
Components

Table of Contentsiv
Publication 1747-6.2
DH-485 Interface Converter 2–16 . . . . . . . . . . . . . . . . . . . . . . . .
Monitoring
with a Data T able Access Module 2–16 . . . . . . . . . . . . . .
Monitoring
with a DT AM Plus 2–16 . . . . . . . . . . . . . . . . . . . . . . . . .
Monitoring
with a DT AM Micro 2–17 . . . . . . . . . . . . . . . . . . . . . . . .
Monitoring
with a PanelV iew Operator T erminal 2–17 . . . . . . . . . . . .
Selecting
a Memory Module for the
SLC 5/01 and SLC 5/02 Processors
2–18 . . . . . . . . . . . . . . . . . . . .
EEPROM and UVPROM Memory Modules
2–18 . . . . . . . . . . . . . . .
Selecting a Memory Module for
SLC 5/03, SLC 5/04, and SLC 5/05 Processors 2–20 . . . . . . . . . . . .
EEPROM
Burning Options 2–21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting
Isolation T ransformers 2–22 . . . . . . . . . . . . . . . . . . . . . . . . .
Special
Considerations 2–23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Class
I, Division 2 Applications 2–23 . . . . . . . . . . . . . . . . . . . . . . . .
Excessive
Line V oltage V ariations 2–23 . . . . . . . . . . . . . . . . . . . . . .
Excessive Noise
2–23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Surge Suppressors
2–24 . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting
Contact Protection 2–26 . . . . . . . . . . . . . . . . . . . . . . . . . .
Transistor
Output T ransient Pulses 2–27 . . . . . . . . . . . . . . . . . . . . .
Example
2–28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3
Typical Installation 3–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Spacing Y
our Controllers 3–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preventing Excessive Heat
3–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Grounding
Guidelines 3–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special
Grounding Considerations for
DC Applications using 1746-P3 3–5 . . . . . . . . . . . . . . . . . . . . .
Modification
to the SLC 500 Chassis 3–6 . . . . . . . . . . . . . . . . . . . .
Determining
the Date of the SLC 500 Chassis 3–6 . . . . . . . . . . . . .
Master
Control Relay 3–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency-Stop Switches
3–8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power
Considerations 3–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Common Power Source
3–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Isolation
T ransformer 3–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Grounded ac Power-Distribution System with
Master-Control Relay
3–9 . . . . . . . . . . . . . . . . . . . . . . . . . .
Loss
of Power Source 3–10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input
States on Power Down 3–10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Other
T ypes of Line Conditions 3–10 . . . . . . . . . . . . . . . . . . . . . . . .
Safety
Considerations 3–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disconnecting Main Power
3–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Circuits
3–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power
Distribution 3–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Periodic
T ests of Master Control Relay Circuit 3–12 . . . . . . . . . . . . .
Preventive
Maintenance 3–12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Installation
Recommendations
AB PLCs

Table of Contents v
Publication 1747-6.2
Chapter 4
Mounting Modular Hardware Style Units 4–1 . . . . . . . . . . . . . . . . . . .
4-Slot Modular Chassis
4–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7-Slot Modular Chassis
4–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10-Slot Modular Chassis
4–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13-Slot Modular Chassis
4–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Link
Coupler (AIC) 4–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data
T able Access Module (DTAM, DTAM Plus, and DTAM Micro) 4–5
AIC+ Advanced Interface Converter (1761-NET -AIC) 4–6 . . . . . . . .
Chapter 5
SLC 5/01 Processor Hardware Features 5–2 . . . . . . . . . . . . . . . . . . .
SLC 5/02 Processor Hardware Features
5–4 . . . . . . . . . . . . . . . . . . .
SLC 5/03 Processor Hardware Features
5–6 . . . . . . . . . . . . . . . . . . .
SLC 5/04 Processor Hardware Features
5–9 . . . . . . . . . . . . . . . . . . .
SLC 5/05 Processor Hardware Features
5–12 . . . . . . . . . . . . . . . . . . .
Keyswitch
for the SLC 5/03, SLC 5/04, and SLC 5/05 Processors 5–15 .
RUN
Position 5–15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PROG
Position 5–15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REM
Position 5–16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 6
Installing Your Processor 6–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing Modules
6–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing Your Memory Module
6–3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing the Memory Module
6–4 . . . . . . . . . . . . . . . . . . . . . . . .
SLC
5/03, SLC 5/04, and SLC 5/05 Operating System
Memory Module 6–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Communicating
via DF1 Full-Duplex to an
SLC 5/04 Processor with DF1 to DH+ Passthru Enabled 6–5 .
Downloading
firmware to the
SLC 5/03, SLC 5/04, and SLC 5/05 Processors 6–5 . . . . . . . .
Component Placement
6–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing Y
our Power Supply 6–8 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing Y
our Chassis Interconnect Cable 6–10 . . . . . . . . . . . . . . . . . .
Chapter 7
Defining Sinking and Sourcing 7–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
Contact Output Circuits — AC or DC
7–2 . . . . . . . . . . . . . . . . . . . .
Solid-State DC I/O Circuits
7–2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sourcing
Device with Sinking Input Module Circuit 7–2 . . . . . . . . . .
Sinking
Device with Sourcing Input Module Circuit 7–3 . . . . . . . . . .
Sinking
Device with Sourcing Output Module Circuit 7–3 . . . . . . . . .
Sourcing
Device with Sinking Output Module Circuit 7–3 . . . . . . . . .
Preparing Y
our Wiring Layout 7–4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting Your SLC 500
Control System
Identifying the Components
of Your Processor
Installing Your Hardware
Components
Wiring Your I/O Modules

Table of Contentsvi
Publication 1747-6.2
Recommendations for Wiring I/O Devices 7–5 . . . . . . . . . . . . . . . . . .
Features
of an I/O Module 7–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Y
our I/O Modules 7–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Octal
Label Kit Installation 7–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Applying
the Octal Filter Label 7–8 . . . . . . . . . . . . . . . . . . . . . . . .
Applying
the Octal Door Label 7–8 . . . . . . . . . . . . . . . . . . . . . . . . .
Octal
Kit and I/O Module Information 7–9 . . . . . . . . . . . . . . . . . . . .
Using
the Removable T erminal Block (RTB) 7–10 . . . . . . . . . . . . . . . . .
Removing
the R TB 7–10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing
the R TB 7–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 8
Procedures for Starting Up the Control System 8–1 . . . . . . . . . . . . . .
Inspect Y
our Installation 8–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disconnect Motion-causing Devices
8–2 . . . . . . . . . . . . . . . . . . . . . .
Initialize
and T est Your Processor 8–3 . . . . . . . . . . . . . . . . . . . . . . . .
Test Y
our Inputs 8–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input
T roubleshooting Steps 8–6 . . . . . . . . . . . . . . . . . . . . . . . . . .
Test Y
our Outputs 8–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output
T roubleshooting Steps 8–8 . . . . . . . . . . . . . . . . . . . . . . . . .
Enter
and T est Your Program 8–9 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Observe
Control Motion 8–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conduct a Dry Run
8–12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 9
Handling and Storing Battery , Catalog Number 1747-BA 9–1 . . . . . . . .
Handling
9–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storing
9–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transporting
9–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing
and Replacing the Battery of the
SLC 5/01 or SLC 5/02 Processor 9–4 . . . . . . . . . . . . . . . . . . . . . .
Replacing Y
our SLC 5/03, SLC 5/04, or SLC 5/05 Battery 9–5 . . . . . . .
Replacing
Retainer Clips on an I/O Module 9–6 . . . . . . . . . . . . . . . . .
Removing
Damaged Retainer Clips 9–6 . . . . . . . . . . . . . . . . . . . . .
Installing
New Retainer Clips 9–7 . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing
a Fuse on the Power Supply 9–8 . . . . . . . . . . . . . . . . . . . .
Chapter 10
Calling Allen-Bradley for Assistance 10–1 . . . . . . . . . . . . . . . . . . . . . .
Tips
for T roubleshooting Y our Control System 10–2 . . . . . . . . . . . . . . .
Removing Power
10–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Fuses
10–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Program
Alteration 10–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting
the SLC 5/01 and SLC 5/02 Processors 10–3 . . . . . . .
Identifying
SLC 5/01 and SLC 5/02 Processor Errors 10–4 . . . . . . . .
Starting Up Your Control
System
Maintaining Your Control
System
Troubleshooting
AB PLCs

Table of Contents vii
Publication 1747-6.2
Identifying SLC 5/02 Processor Communication Errors 10–9 . . . . . . .
Troubleshooting
the SLC 5/03, SLC 5/04, and SLC 5/05 Processors 10–1 1
Clearing SLC 5/03, SLC 5/04, and SLC 5/05 Processor Faults
Using the Keyswitch 10–1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identifying
SLC 5/03, SLC 5/04, and SLC 5/05 Processor Errors 10–12
Identifying SLC 5/03, SLC 5/04, and SLC 5/05 Processor
Communication Errors 10–17 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identifying Processor Errors while
Downloading an Operating System 10–21 . . . . . . . . . . . . . . . . . . . .
Returning
the SLC 5/03, SLC 5/04, and SLC 5/05 Processors
to “Initial Factory Conditions” 10–25 . . . . . . . . . . . . . . . . . . . . . . .
TroubleshootingY
our Input Modules 10–26 . . . . . . . . . . . . . . . . . . . . . .
Input
Circuit Operation 10–26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TroubleshootingY
our Input Modules 10–27 . . . . . . . . . . . . . . . . . . . .
TroubleshootingY
our Output Modules 10–28 . . . . . . . . . . . . . . . . . . . . .
Output
Circuit Operation 10–28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TroubleshootingY
our Output Modules 10–29 . . . . . . . . . . . . . . . . . . .
Chapter 11
Replacement Parts 1 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement
T erminal Blocks 1 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix A
DH-485 Network Description A–1. . . . . . . . . . . . . . . . . . . . . . . . . . .
DH-485 Network Protocol A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DH-485
T oken Rotation A–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DH-485
Network Initialization A–2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Devices
that use the DH-485 Network A–2. . . . . . . . . . . . . . . . . . . . .
1747-AIC
Isolated Link Coupler for DH-485 A–4. . . . . . . . . . . . . . . . .
Example
System Configuration A–5. . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring
the SLC 5/03, SLC 5/04, and SLC 5/05
Channel 0 for DH485 A–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important
Planning Considerations A–7. . . . . . . . . . . . . . . . . . . . . . .
Hardware
Considerations A–7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number
of Devices and Length of Communication Cable A–7. . .
Planning
Cable Routes A–7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Software
Considerations A–8. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number
of Nodes A–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Node Addresses A–9. . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Processor Baud Rate A–9. . . . . . . . . . . . . . . . . . . . . . .
Maximum
Node Address Setting A–9. . . . . . . . . . . . . . . . . . . . .
Maximum Number of Communicating Devices A–10. . . . . . . . . . .
Installing the DH-485 Network A–10. . . . . . . . . . . . . . . . . . . . . . . . . . .
DH-485
Communication Cable and Isolated Link Coupler A–10. . . . .
Installing
the DH-485 Communication Cable A–10. . . . . . . . . . . . . .
Replacement Parts
Setting Up the DH-485
Network

Table of Contentsviii
Publication 1747-6.2
Connecting the Communication Cable to the
Isolated Link Coupler A–12. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Single
Cable Connection A–12. . . . . . . . . . . . . . . . . . . . . . . . . .
Multiple
Cable Connection A–12. . . . . . . . . . . . . . . . . . . . . . . . .
Grounding
and T erminating the DH-485 Network A–13. . . . . . . . . . .
Powering
the Link Coupler A–14. . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing
and Attaching the Link Couplers A–16. . . . . . . . . . . . . . . .
Appendix B
RS-232 and SCADA Applications B–1. . . . . . . . . . . . . . . . . . . . . . . .
RS-232 Communication Interface Overview B–1. . . . . . . . . . . . . . . . .
SLC
5/03, SLC 5/04, and SLC 5/05 Processors and
RS-232 Communication B–2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SLC
500 Devices that Support RS-232 Communication B–3. . . . . . . .
1770-KF3
Module B–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1747-KE
Module B–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1746-BAS
Module B–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1
Protocol and the
SLC 5/03, SLC 5/04, and SLC 5/05 Processors B–4. . . . . . . . . . . .
DF1
Full-Duplex Protocol B–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Full-Duplex
(Point-to-Point) B–5. . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1
Half-Duplex Protocol B–5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASCII Communication B–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1 Communication Protocol Modems Overview B–7. . . . . . . . . . . . .
Wiring Connectors for RS-232 Communication B–8. . . . . . . . . . . . . . .
Types
of RS-232 Connectors B–8. . . . . . . . . . . . . . . . . . . . . . . . .
DTE
Pinout B–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DCE
Pinout B–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin Assignments for Wiring Connectors B–10. . . . . . . . . . . . . . . . . .
IBM A
T to a Modem (Hardware Handshaking Enabled) B–11. . . . .
IBM A
T to SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
1770-KF3, 1775-KA, 1773-KA, 5130-RM or PLC-5
(Hardware Handshaking Disabled) B–11. . . . . . . . . . . . . . . . .
SLC
5/03, SLC 5/04, or SLC 5/05 Processor
Connected to a Modem (Hardware Handshaking Enabled)
B–11
SLC 5/03, SLC 5/04, or SLC 5/05 Processor to another
SLC 5/03, SLC 5/04, or SLC 5/05, IBM A
T , 1770-KF3,
1775-KA, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–12. . . . . . . . . . . . . . . . .
SLC
5/03, SLC 5/04, or SLC 5/05 Processor
Connected to an IBM A
T with a 1747-CP3 Cable B–12. . . . . . .
1747-KE
to a Modem (Hardware Handshaking Enabled) B–12. . . .
1747-KE
to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1775-KA, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–13. . . . . . . . . . . . . . . . .
1746-BAS
to a Modem (Hardware Handshaking Enabled) B–13. . .
RS-232 Communication
Interface
AB PLCs

Table of Contents ix
Publication 1747-6.2
1746-BAS to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1775-KA, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–14. . . . . . . . . . . . . . . . .
1770-KF3
to a Modem (Hardware Handshaking Enabled) B–14. . .
2760-RB
to a Modem (Hardware Handshaking Enabled) B–14. . . .
2760-RB
to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1775-KA, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–15. . . . . . . . . . . . . . . . .
1771-KGM
to a Modem (Hardware Handshaking Enabled) B–15. .
1771-KGM
to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1775-KA, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–16. . . . . . . . . . . . . . . . .
1775-KA
to a Modem (Hardware Handshaking Enabled) B–16. . . .
1775-KA
to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1773-KA, 5130-RM, or PLC-5
(Hardware Handshaking Disabled) B–17. . . . . . . . . . . . . . . . .
PLC-5
(Channel 0) to a Modem
(Hardware Handshaking Enabled) B–17. . . . . . . . . . . . . . . . .
PLC-5
(Channel 0) to a SLC 5/03, SLC 5/04, or SLC 5/05
Processor, IBM AT , 1770-KF3, 1773-KA, 5130-RM, PLC-5,
1747-KE, or 1746-BAS
(Hardware Handshaking Disabled) B–18. . . . . . . . . . . . . . . . .
5130-RM
to a Modem (Hardware Handshaking Enabled) B–18. . .
5130-RM
to a SLC 5/03, SLC 5/04, or SLC 5/05 Processor ,
IBM AT , 1770-KF3, 1773-KA, 5130-RM, PLC-5, 1747-KE, or
1746-BAS (Hardware Handshaking Disabled) B–19. . . . . . . . .
Applications
for the RS-232 Communication Interface B–20. . . . . . . . . .
DF1
Full-Duplex Peer-to-Peer B–20. . . . . . . . . . . . . . . . . . . . . . . . .
Half-Duplex
with Slave-to-Slave Routing B–20. . . . . . . . . . . . . . . . .
Appendix C
Data Highway Plus Communication Protocol Overview C–1. . . . . . . . .
SLC 5/04 Processors and DH+ Communication C–2. . . . . . . . . . . . . .
DH+
Channel 1 3-Pin C–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DH+
Channel 1 8-Pin C–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Connectors for DH+ Communication for
SLC 5/04 Processors C–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical
DH+ Network Configuration C–4. . . . . . . . . . . . . . . . . . . . . . .
Appendix D
Allen-Bradley Remote I/O Network D–1. . . . . . . . . . . . . . . . . . . . . . .
Remote I/O Passthru D–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DeviceNet Network D–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DeviceNet
Network Length D–4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix E
Use this T able to Calculate the Power Supply Loading E–1. . . . . . . . .
Setting Up the DH+ Network
Control Networks
Power Supply Worksheet

Table of Contentsx
Publication 1747-6.2
Appendix F
Definition of Key T erms F–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module
Heat Dissipation: T otal W atts Vs. Calculated W atts F–1. . . . . .
Use
this T able to Calculate Heat Dissipation F–2. . . . . . . . . . . . . . . . .
Use
these Graphs to Determine the Power Supply Dissipation F–5. . .
Example
Heat Dissipation Calculation F–6. . . . . . . . . . . . . . . . . . . . .
Example W
orksheet for Calculating Heat Dissipation F–7. . . . . . . .
Worksheet
for Calculating Heat Dissipation F–8. . . . . . . . . . . . . . .
Appendix G
SLC 5/05 Processors and Ethernet Communication G–1. . . . . . . . . . .
SLC 5/05 Performance Considerations G–2. . . . . . . . . . . . . . . . . . . .
SLC 5/05 and PC Connections to the Ethernet Network G–2. . . . . . . .
Ethernet Network Topology G–2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet
Channel 1 8-Pin 10Base-T Connector G–3. . . . . . . . . . . .
Cables G–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet
Connections G–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring
the Ethernet Channel on the SLC 5/05 G–5. . . . . . . . . . . .
Configuration
Using RSLogix500 Programming Software G–5. . . . . . .
Configuration Via BOOTP G–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using DOS/Windows BOOTP G–6. . . . . . . . . . . . . . . . . . . . . . . . .
Install the DOS/Windows BOOTP server G–7. . . . . . . . . . . . . . .
Edit
the DOS/Windows BOOTP Configuration File G–7. . . . . . . .
Run
the Boot Server Utility G–9. . . . . . . . . . . . . . . . . . . . . . . . . . .
Running the DOS-Based Utility G–10. . . . . . . . . . . . . . . . . . . . . .
Running
the Windows-Based Utility G–10. . . . . . . . . . . . . . . . . . .
Using Subnet Masks and Gateways G–11. . . . . . . . . . . . . . . . . . . . . .
Manually
Configuring Channel 1 for Processors on Subnets G–12. . .
Using
BOOTP to Configure Channel 1 for Processors on Subnets G–13
Glossary
Index
Calculating Heat
Dissipation for the SLC 500
Control System
Communicating with
Devices on an Ethernet
Network
AB PLCs

Publication 1747-6.2

Read this preface to familiarize yourself with the rest of the manual.
This preface covers the following topics:
•who should use this manual
•how to use this manual
•related publications
•conventions used in this manual
•Allen-Bradley support
Use this manual if you are responsible for designing, installing,
programming, or troubleshooting control systems that use
Allen-Bradley small logic controllers.
You should have a basic understanding of SLC 500tproducts. You
should understand programmable controllers and be able to interpret
the ladder logic instructions required to control your application. If
you do not, contact your local Allen-Bradley representative for
information on available training courses before using this product.
Who Should Use this
Manual

PrefaceP–2
Publication 1747-6.2
As much as possible, we organized this manual to explain, in a
task-by-task manner, how to install and operate (preliminary start-up
operations) the SLC 500 modular programmable controller. This
manual also provides some system design information.
Before using this manual, read the table below and familiarize
yourself with the general content of the chapters and appendixes. If
you already have a topic in mind that you want to find specific
information about, turn to the index at the back of the manual.
Contents of this Manual
If You Want See
An overview of the manual the Preface
Serves as a Quick Start Guide for the SLC 5/01t ,
SLC 5/02t, SLC 5/03t, and SLC 5/04t, and SLC 5/05t
modular processors chapter 1 — Quick Start for Experienced Users
Information on how to select certain components for your SLC
500 control system chapter 2 — Selecting Your Hardware Components
A guide on how to prepare for the installation of your control
system chapter 3 — System Installation Recommendations
Mounting dimensions of your modular chassis, DTAMt,
1747-AIC, and 1761-NET-AIC chapter 4 — Mounting Your SLC 500 Control System
Specification information concerning your processor chapter 5 — Identifying the Components of Your Processor
Procedures on how to install your hardware components chapter 6 — Installing Your Hardware Components
Information on how to wire the components of your SLC 500
control system chapter 7 — Wiring Your I/O Modules
A guide on how to start up your control system chapter 8 — Starting Up Your Control System
Information on how to maintain your control system chapter 9 — Maintaining Your Control System
To identify error messages generated by your control system chapter 10 — Troubleshooting
To replace parts of your SLC 500 control system or purchase
other SLCtcomponents chapter 11 — Replacement Parts
Information on setting up the DH-485 network appendix A — Setting up the DH-485 Network
Information on using the RS-232 communication interface appendix B — RS-232 Communication Interface
Information on setting up the DH+ network appendix C — Setting up the DH+ Network
Information on the 1771-Remote I/O, 1746-ASB, and
DeviceNettappendix D — Control Networks
The worksheet on selecting your power supply appendix E — Power Supply Worksheet
Information on how to calculate the heat dissipation of your
controller appendix F — Calculating Heat Dissipation for the SLC 500 Control System
Information on Ethernet appendix G — Communicating with Devices on an Ethernet Network
Definitions of terms used in this manual the Glossary
How to Use this Manual
AB PLCs

Preface P–3
Publication 1747-6.2
Related Documentation
The table below provides a listing of publications that contain
important information about Allen-Bradley Small Logic Controllers
and their installation and application. You may want to reference
them while you are installing the SLC 500 controller. (To obtain a
copy of one of these publications, contact your local Allen-Bradley
office or distributor.)
For Read This Document Document
Number
An overview of the SLC 500 family of products SLC 500 System Overview 1747-2.30
A description on how to install and use your Modular SLC 500
programmable controller Installation & Operation Manual for Modular Hardware Style Programmable Controllers 1747-6.2
A description on how to install and use your Fixed SLC 500
programmable controller Installation & Operation Manual for Fixed Hardware Style Programmable Controllers 1747-6.21
A procedural and reference manual for technical personnel who
use an HHT to develop control applications Allen-Bradley Hand-Held Terminal User Manual 1747-NP002
An introduction to HHT for first-time users, containing basic
concepts but focusing on simple tasks and exercises, and allowing
the reader to begin programming in the shortest time possible Getting Started Guide for HHT 1747-NM009
In-depth information on grounding and wiring Allen-Bradley
programmable controllers Allen-Bradley Programmable Controller Grounding and Wiring Guidelines 1770-4.1
A description on how to install a PLC-5rsystem PLC-5 Family Programmable Controllers Hardware
Installation Manual 1785-6.6.1
A description of important differences between solid-state
programmable controller products and hard-wired
electromechanical devices Application Considerations for Solid-State Controls SGI-1.1
An article on wire sizes and types for grounding electrical
equipment National Electrical Code
Published by the
National Fire
Protection
Association of
Boston, MA.
A complete listing of current Allen-Bradley documentation,
including ordering instructions. Also indicates whether the
documents are available on CD-ROM or in multi-languages. Allen-Bradley Publication Index SD499
A glossary of industrial automation terms and abbreviations Allen-Bradley Industrial Automation Glossary AG-7.1

PrefaceP–4
Publication 1747-6.2
The following conventions are used throughout this manual:
•Bulleted lists such as this one provide information, not procedural
steps.
•Numbered lists provide sequential steps or hierarchical
information.
•Italic type is used for emphasis.
•Text in this font indicates words or phrases you should type.
Allen-Bradley offers support services worldwide, with over 75
Sales/Support Offices, 512 authorized Distributors and 260
authorized Systems Integrators located throughout the United States
alone, plus Allen-Bradley representatives in every major country in
the world.
Local Product Support
Contact your local Allen-Bradley representative for:
•sales and order support
•product technical training
•warranty support
•support service agreements
Technical Product Assistance
If you need to contact Allen-Bradley for technical assistance, please
review the information in the Troubleshooting chapter first. Then
call your local Allen-Bradley representative.
Your Questions or Comments on this Manual
If you find a problem with this manual, please notify us of it on the
enclosed Publication Problem Report.
If you have any suggestions for how this manual could be made
more useful to you, please contact us at the address below:
Allen-Bradley Company, Inc.
Control and Information Group
Technical Communication, Dept. A602V, T122
P.O. Box 2086
Milwaukee, WI 53201-2086
Conventions Used in this
Manual
Allen-Bradley Support
AB PLCs

Chapter 1
Publication 1747-6.2
Quick Start for Experienced
Users
This chapter can help you to get started using the SLC 500 Modular
Processors. We base the procedures here on the assumption that you
have an understanding of SLC 500 products. You should understand
electronic process control and be able to interpret the ladder logic
instructions required to generate the electronic signals that control
your application.
Because it is a start-up guide for experienced users, this chapter does
not contain detailed explanations about the procedures listed. It
does, however, reference other chapters in this book where you can
get more information.
If you have any questions or are unfamiliar with the terms used or
concepts presented in the procedural steps, always read the
referenced chapters and other recommended documentation before
trying to apply the information.
This chapter:
•tells you what tools and equipment you need
•lists how to install and wire your power supply
•lists how to install and apply power to your processor
•lists how to establish communications with the processor
•describes how to return the SLC 5/03, SLC 5/04, and SLC 5/05
processors to initial factory conditions if required
Have the following tools and equipment ready:
•medium blade screwdriver
•programming equipment
•a 1747-PIC and 1747-CP3 programmer cable, or 1784-KT, -KTX,
-KT2, or -PCMK communication interface, or standard Ethernet
PC board or standard Ethernet hub (SLC 5/05 only)
Required
T
ools
and
Equipment

1–2 Quick Start for Experienced Users
Publication 1747-6.2
1. Check the contents of shipping box.
Reference
Unpack the shipping boxes making sure that the contents include:
•SLC 500 Modular Processor
•installation instructions (Publication 1747-5.25 or 1747-5.27)
•SLC 500 Modular Chassis (Catalog Numbers 1746-A4, 1746-A7, 1746-A10, or 1746-A13)
•installation instructions (Publication 1746-5.8)
•SLC 500 Modular Power Supplies (Catalog Numbers 1746-P1, 1746-P2, 1746-P3, 1746-P4, or
1746-P5)
•installation instructions (Publication Number 1746-5.1)
If the contents are incomplete, call your local Allen-Bradley representative for assistance.
–
2. Install the power supply
Reference
Follow the steps below:
1. Align the circuit board of the power supply with the card guides on the left side of the chassis, and
slide the power supply in until it is flush with the chassis.
Chapter 6
(Installing Your
Hardware
Components)
2. Fasten the power supply to the chassis.
Use these screws to fasten the
power supply to the chassis.
Procedures
AB PLCs

1–3 Quick Start for Experienced Users
Publication 1747-6.2
3. Make
jumper selection for 120/240V ac on 1746-P1, 1746-P2, and
1746-P4 Power Supplies.
Reference
Place the input voltage jumper to match the input voltage. This does not apply to the 1746-P3, or
1746-P5 which do not have jumpers. Chapter 6
(Installing Your
Hardware
Components)
ATTENTION: Set the input jumper before applying
power. Hazardous voltage is present on exposed pins
when power is applied; contact with the pin may cause
injury to personnel.
!
POWER
100/120 Volts
200/240 V olts
Catalog Number
1746-P1 & P2
Fuse
85–132 V AC
170–265 V AC
Catalog Number
1746-P4
Jumper Selection
Jumper Selection
POWER

1–4 Quick Start for Experienced Users
Publication 1747-6.2
4. Wire power to power supply. Reference
ATTENTION: Turn off incoming power before
connecting wires; failure to do so could cause injury to
personnel and/or equipment.
!Chapter 6
(Installing Your
Hardware
Components)
Connect incoming power.
120/240V ac
V ac NEUT
CHASSIS GROUND
dc NEUT
+ 24V dc
CHASSIS GROUND
JUMPER
170–265V ac
L2 NEUTRAL
L185–132/170–265
85–132V ac
CHASSIS GROUND
+125V dc
dc NEUT
CHASSIS GROUNDCHASSIS GROUND
PWR OUT COM
PWR OUT COM
PWR OUT +24V dc
PWR OUT +24V dc
PWR OUT +24V dc
PWR OUT COMMON
NOT USED
NOT USED
User
Power
1746-P1 and -P2
1746-P4 1746-P5
1746-P3
Incoming
Power Incoming Power
User
Power
Incoming
Power
User
Power
Incoming
Power
AB PLCs

1–5 Quick Start for Experienced Users
Publication 1747-6.2
5. Install the processor .Reference
Make sure system power is off; then insert the processor into the 1746 chassis.
Important: The SLC 500 Modular Processors must be inserted into the left slot (slot 0), as
shown below. Remove the protective label after installing the processor.
Chapter 2
(Selecting Your
Hardware
Components)
Chapter 6
(Installing Your
Hardware
Components)
6. Apply power to to the processor .Reference
Follow the steps below:
1. Energize the chassis power supply.
2. Check the chassis power supply and processor LEDs. The power LED on the power supply
should be on and the fault LED on the processors should be flashing.
Chapter 8
(Starting Up Your
Control System)
Chapter 10
(Troubleshooting)
POWER RUN
CPU FAULT
FORCED I/O
BATTERY LOW
COMM
Refer to the following key to determine the status of
the LED indicators:
Indicates the LED is OFF.
Indicates the LED is ON.
Indicates the LED is FLASHING.
Status of LED does not matter.
The RUN LED on the SLC 5/01 processor is
actually labeled “PC RUN.” Also, the SLC 5/01
processor does not have a COMM LED.
POWER RUN
FLT
BATT
FORCE
DH485
RS232
The DH485 LED on the SLC 5/03
processor is labeled “DH+” on the SLC
5/04 processor.
Power supply and SLC 5/01 and SLC 5/02 LEDs Power supply and SLC 5/03 and SLC 5/04 LEDs
Power supply and SLC 5/05 LEDs
POWER RUN
FLT
BATT
FORCE
ENET
RS232
Card
Guide
Module Release
Protective
Label
