allen AW16-B Guide

SAFETY &
OPERATIONS MANUAL
Manual Part #: 068517 | Revision: B
Language: English | Original Instructions
WHEEL BUGGIES
AW16-B

068521
Page 2
SAFETY & OPERATIONS MANUAL
Wheel Buggy
Copyright © 2021 Allen Engineering Corporation
All rights reserved
All information, specifications, and illustrations in this manual are subject to change without notice and are based on the latest
information at the time of publication. No part of this manual may be reproduced or transmitted in any form or by any means,
electronics or mechanical, for any purpose, without the express written permission of Allen Engineering Corporation (AEC). AEC
assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
Allen Products are covered under one or more of the following patent numbers:
10,100,537; 9,068,301; 9,068,300; 8,360,680; 7,690,864; 7,114,876B1; 6,857,815B2; 6,582,153
With other Patents Pending.
Printed in U.S.A.
This manual, or a copy of it, must be kept with the machine at all times.
There is a manual storage container located on the machine for your convenience.
This manual covers the Trowel Parts listed below
Part No.Part No. DescriptionDescription
073000 AW16-B, All Electric Wheel Buggy, Poly-Bucket, Foam Filled Tires073000 AW16-B, All Electric Wheel Buggy, Poly-Bucket, Foam Filled Tires

068521 Page 3
GENERAL
INFORMATION
Allen Engineering Corporation (“Allen”) warrants its products to be free of defects in material or
workmanship for:
TWO YEARS FROM END USER’S DATE OF PURCHASE
Warranty period begins on the date of purchase by the End User of the product. All warranty is based on
the following limited warranty terms and conditions, including the disclaimer of implied warranties and
consequential damages.
1. Allen’s obligation and liability under this warranty is limited to repairing or replacing parts if, after Allen’s inspection, there is
determined to be a defect in material or workmanship. Allen reserves the choice to repair or replace.
2. If Allen chooses to replace the part, it will be at no cost to the customer and will be made available to the Allen Distributor, Dealer,
or Rental Center from whom the End User purchased the product.
3. Replacement or repair parts, installed in the product, are warranted only for the remainder of warranty period of the product as
though they were the original parts.
4. Allen does not warranty engines or batteries. Engine warranty claims should be made directly to an authorized factory service center
for the particular engine manufacturer. Batteries are not warranted due to unknown treatment during transport, etc, and any battery
claims should be directed to the battery manufacturer.
5. Allen’s warranty does not cover the normal maintenance of products or its components (such as engine tuneups and oil & lter
changes). The warranty also does not cover normal wear and tear items (such as belts and consumables).
6. Allen’s warranty will be void if it is determined that the defect resulted from operator abuse, failure to perform normal maintenance
on the product, modication to product, alterations or repairs made to the product without the written approval of Allen. Allen
specically excludes from warranty any damage to any trowels resulting from an impact to the rotors.
7. Impact damage to gear boxes is not covered under the Allen warranty and is deemed customer abuse.
8. Allen will pay shop labor on warranty items at the Allen Shop Labor Rate in existence on the date of the warranty claim.An Allen labor
chart will determine the time allowed to complete a repair and will govern the shop labor hours that will be allowed.
9. Allen will pay freight on warranty replacement parts at worldwide standard ground rates. No warranty replacement parts will be
shipped air freight at the expense of Allen. Allen only pays outbound freight charges when sending warranty replacement parts to
the customer via ground service. Allen does not pay any inbound freight. However, if Allen determines this to be a warranted item,
only then will Allen reimburse the customer for inbound freight at standard ground rates.
10. ALLEN ENGINEERING CORPORATION’S WARRANTY POLICY WILL NOT COVER THE FOLLOWING: TAXES; SHOP SUPPLIES;
ENVIRONMENTAL SURCHARGES; AIR FREIGHT; TRAVEL TIME; LOSS OF TIME; INCONVENIENCE; LOSS OF RENTAL REVENUE; RENTAL
COSTS OF EQUIPMENT USED TO REPLACE THE PRODUCT BEING REPAIRED; LOSS OF USE OF THE PRODUCT; COMMERCIAL LOSS;
OR ANY OTHER CHARGES WHATSOEVER OR ANY LIABILITIES FOR DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGE OR DELAY.
11. ALLEN ENGINEERING CORPORATION MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED. THIS LIMITED WARRANTY IS IN
LIEU OF THE WARRANTY OF MERCHANTABILITY AND FITNESS. THERE ARE NO OTHER WARRANTIES THAT EXTEND BEYOND THE
DESCRIPTION ON THIS DOCUMENT.
12. No Allen employee or representative is authorized to change this warranty in any way or grant any other warranty unless such
change is made in writing and signed by an ofcer of Allen Engineering Corporation.
Limited Warranty

GENERAL
INFORMATION
068521
Page 4
Table of Contents
Sect Title Page
- General Information
Limited Warranty .....................................................................................................................................3
Information Contained in This Manual......................................................................................................5
Sound & Vibration Testing .......................................................................................................................6
Dealer Information / Ordering Parts .........................................................................................................7
Model Number / Serial Identification, Unit Identification...........................................................................8
Technical Specifications ..........................................................................................................................9
1.0 Safety .....................................................................................................................................................10
Federal / State Warning Regulations........................................................................................................11
Manual Tag Safety Detail.........................................................................................................................12
Hazard Symbols.......................................................................................................................................13
General Safety.........................................................................................................................................14
Lifting Safety ...........................................................................................................................................15
Transportation Safety ..............................................................................................................................16
2.0 Operation ...............................................................................................................................................18
Introduction .............................................................................................................................................19
Operating Instructions..............................................................................................................................20
Charging the Unit.....................................................................................................................................26
3.0 Service ...................................................................................................................................................27
Cleaning Procedure .................................................................................................................................28
4.0 Accessories............................................................................................................................................29
Accessories / Manual Revision Detail.......................................................................................................30
Parts Manual ...........................................................................................................................................31

068521 Page 5
GENERAL
INFORMATION
This manual provides information and procedures to safely operate and maintain the Allen Machine.
For your own safety and protection from personal injury, carefully read, understand, and observe the safety instructions
described in this manual. Keep this manual or a copy of it with the machine at all times.
Always operate this machine in accordance with the instructions described in this manual. A well maintained piece of
equipment will provide many years of trouble free operation.
This manual is divided into the following sections:
Complete any warranty requirements as specified by the engine manufacturer in their instructions found inside the
manual box located on the back of the riding trowel operator’s seat.
Your engine and clutch is not manufactured by Allen Engineering Corporation, Inc, and therefore is not covered under
Allen Engineering Corporation, Inc warranty.
Your engine manufacturer should be contacted if you wish to purchase a parts manual or a repair manual for your
engine.
Refer to enclosed owners engine manual for complete OEM instructions. See your battery manufacturer for battery
warranty.
SECTION 1
SAFETY
SECTION 2
ASSEMBLY
SECTION 3
SERVICE
SECTION 4
ACCESSORIES
Information Contained
in this Manual

GENERAL
INFORMATION
068521
Page 6
Sound Pressure Level Information:
Sound pressure is “A” weighted . Measured at the operators ear position while the ride-on trowel is operating at
full throttle on concrete in a manner most often experienced in “normal ” circumstances. Sound pressure may vary
depending upon the condition of the concrete. Hearing protection is always recommended.
Vibration Level Information:
The vibration level indicated is the maximum RMS (Root Mean Square) velocity value obtained at the handle grip while
operating the ride-on trowel on curing concrete in a manner most often experienced in “normal ” circumstances.
Values were obtained from all three axes of motion. The values shown represent the maximum RMS value from these
measurements.
PENDING INFORMATION
Summary Data Of Sound And Vibration Testing
Operator Ear SPL Seat Vibration Average Left Hand
Vibration Average
Right Hand
Vibration Average
- dB (A) - m/sec² - m/sec² - m/sec²
This information was acquired from sound and vibration analysis tests conducted at Allen Engineering
Corporation test facilities.
Sound & Vibration Testing

068521 Page 7
GENERAL
INFORMATION
Dealer Information /
Ordering Parts
Your Dealer has Allen Engineering Corporation trained mechanics and original Allen replacement parts. Always con-
tact the Allen Dealer who sold you this machine for Allen Certified repairs and replacement parts.
Place Allen Dealer information below for future reference.
Dealer Name:
Dealer Phone #:
( ) - -
Address:
City / State / Zip:
Salesman:
Salesman Phone #:
Additional Comments:
The “PARTS & DECALS MANUAL” contain illustrated parts lists for help in ordering replacement parts for your
machine. Follow the instructions below when ordering parts to ensure prompt and accurate delivery:
1. All orders for service parts - include the serial number for the machine. Shipment will be delayed if this information
is not available.
2. Include correct description and part number from the “PARTS & DECALS MANUAL”
3. Specify exact shipping instructions, including the preferred routing and complete destination address.
4. DO NOT return parts to AEC without receiving written authorization from AEC. All authorized returns must be
shipped pre-paid.
5. When placing an order, please contact the AEC dealer nearest you.
ALL INFORMATION, SPECIFICATIONS, AND ILLUSTRATIONS IN THIS MANUAL
ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ARE BASED ON THE
LATEST INFORMATION AT THE TIME OF PUBLICATION.

GENERAL
INFORMATION
068521
Page 8
Model Number / Serial Number
Unit Identication
Manufacturer’s Codes:
When ordering parts or requesting service information, you will always be asked to specify the
model and serial numbers of the machine. The legends below specically denes each signicant
character or group of characters of the Model Number and Serial Number codes.
Serial Number:
The serial number found on the identification plate is a ten digit format. The model number iden-
tifies your machine and will ensure that you receive the correct replacement parts.
Unit Identification Plate Location:
An identification plate listing the model number and the
serial number is attached to each unit and is located on the
inside behind the front door of the unit. This plate should
not be removed at any time.
Please record the information found on this plate below so
it will be available should the identification plate become
lost or damaged. When ordering parts or requesting service
information, you will always be asked to specify the model
and serial numbers of the machine.
Model Number:
Serial Number:
Date Purchased:
Purchased From:
Model Number
AW 16 - B
16ft3- Bucket Capacity
Allen Wheel
Serial Number Example
BW16 01 20 01
Model
Sequence Number
Month
Year
Battery (Full Electric)

068521 Page 9
GENERAL
INFORMATION
Technical Specications
98 1/4" 44"
58"
Dimension with Accessories
Measurements in this manual are in standard units
Machine Features for AW16-B:
•No Emissions
• Ingress Rating.............................................................................IP67
• Run Time............................................................................ 9+ hours
• Charge Time ..........................................................................6 hours
• Motor.............................................................Brushless AC Induction
• Charger Power Input ..................100VAC @ 60Hz - 240VAC @ 50 Hz
• DC Output........................................................................1050 Watts
• Battery......................................................................Lithium-Ion 14S
• Weight (unloaded)...............................................................1,300 lbs
• Dimensions (L x W x H)......................................98-1/4” x 44” x 58”
• Battery Voltage ............................................................................58v
• Wheelbase...................................................................................40”
•Payload...............................................................................2,500 lbs
•Bucket Capacity........................................................................ 16 ft3
•Lift Cylinder ....................................................................2” Diameter
•Dump/Return Speed (Empty)............................................. 5 Seconds
•Top Speed
- Forward ............................................................................ 6 MPH
- Reverse..............................................................................- MPH

SECTION 1
SAFETY
068521
Page 10
SECTION 1
SAFETY

068521 Page 11
SECTION 1
SAFETY
CALIFORNIA PROPOSITION 65 WARNING
Gasoline engine exhaust from this product contains chemicals known to the
State of California to cause cancer, birth defects and other reproductive harm.
RESPIRATORY HAZARDS
Grinding/cutting/drilling of masonry, concrete, metal
and other materials can generate dust, mists and
fumes containing chemicals known to cause serious
or fatal injury or illness, such as respiratory disease,
cancer, birth defects or other reproductive harm.
SILICOSIS WARNING
Grinding/cutting/drilling of masonry, concrete, metal
and other materials with silica in their composition
may give off dust or mists containing crystalline
silica.
Federal / State Warnings
For more information
reguarding Prop 65, please
scan QR code.

SECTION 1
SAFETY
068521
Page 12
Safety-Alert Signs
This manual contains Safety-Alert Signs, as defined below, which must be followed to
reduce the possibility of improper service damage to the equipment or personal injury.
Read and follow all Safety-Alert Signs included in this manual.
NOTE defines an operating procedure, condition, etc. which is essential to high-
light that contains useful or important information.
EMERGENCY is used for the identification of safety equipment, first aid, or emer-
gency egress locations.
NOTICE used to convey safety information on labels and signs.
CAUTION is indicative of a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
WARNING Indicative of a potentially hazardous situations that could result in
death or serious injury
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury
Manual Tag Safety Detail

068521 Page 13
SECTION 1
SAFETY
Potential hazards associated with the
operation of this equipment will be ref-
erenced with hazard symbols which
may appear throughout this manual in
conjunction with safety notes.
Hazard Symbols

SECTION 1
SAFETY
068521
Page 14
Familiarity and proper training are required for the safe operation of this equipment! Equipment operated
improperly or by untrained personnel can be dangerous! Read the operating instructions contained in this
manual and familiarize yourself with the location and proper use of all controls.
• NEVER operate this machine in applications for which it is not intended.
• NEVER operate this machine while under the influence of drugs or alcohol.
• NEVER allow anyone to operate this equipment without proper training. People operating this
equipment must be familiar with the risks and hazards associated with it.
• NEVER use accessories or attachments that are not recommended by AEC. Damage to equipment
and injury to the user may result.
• NEVER leave machine running unattended.
• ALWAYS remain aware of moving parts and keep hands, feet, and loose clothing away from the moving parts of
the equipment.
• ALWAYS read, understand, and follow procedures in the Operator’s Manual before attempting to operate the
equipment.
• ALWAYS be sure operator is familiar with proper safety precautions and operation techniques before using
machine.
• ALWAYS store the equipment properly when it is not being used. Equipment should be stored in a clean, dry
location out of the reach of children.
• ALWAYS operate the machine with all safety devices and guards in place and in working order.
• ALWAYS disconnect the battery before servicing the equipment.
• DO NOT attempt to clean or service the machine while it is running. Rotating parts can cause severe injury.
• ALWAYS turn engine off and lockout machine before performing maintenance or making repairs.
• ALWAYS replace worn or damaged components with spare parts designed and recommended by AEC
Corporation.
• ALWAYS switch off the power supply at the battery disconnect before adjusting or maintaining the electrical
equipment.
• ALWAYS keep the machine clean and labels legible. Replace all missing and hard-to read labels. Labels provide
important operating instructions and warn of dangers and hazards.
General Safety

068521 Page 15
SECTION 1
SAFETY
Lifting Safety
FORKLIFT LIFT ONLY!
This product is designed to ONLY be lifted by a forklift.
• DO NOT use straps or chains to attempt to lift the machine.
• When lifting the machine, all personnel must be clear of the machine.
• Make sure the bucket is free of any material or debree before lifting.
• The bucket should be in the “down” position during the lifting process
• DO NOT stand near or under the machine while it is being lifted.
• ALWAYS turn off the buggy before transporting.
PLACE FORKS HERE
PLACE FORKS HERE
PLACE FORKS HERE PLACE FORKS HERE

SECTION 1
SAFETY
068521
Page 16
Transportation Safety
• Make sure the hitch and coupling of the towing vehicle are rated equal to, or greater than the trailer
“gross vehicle weight rating.”
• ALWAYS inspect the hitch and coupling for wear. Never tow a trailer with defective hitches, couplings,
chains, etc.
• Check the tire air pressure on both towing vehicle and trailer. Trailer tires should be inated to 50 psi cold.
Also check the tire tread wear on both vehicles.
• ALWAYS make sure the trailer is equipped with a safety chain.
• ALWAYS properly attach trailer’s safety chains to towing vehicle.
• ALWAYS make sure the vehicle and trailer directional, backup, brake and trailer lights are connected and
working properly.
• DOT Requirements include the following:
- Connect and test electric brake operation.
- Secure portable power cables in cable tray with tie wraps.
• The maximum speed for highway towing is 55 MPH unless posted otherwise. Recommended off-road
towing is not to exceed 15 MPH or less depending on type of terrain.
• Avoid sudden stops and starts. This can cause skidding, or jack-kning. Smooth, gradual starts and stops
will improve towing.
• Avoid sharp turns to prevent rolling.
• Trailer should be adjusted to a level position at all times when towing.
• Raise and lock trailer wheel stand in up position when towing.
• Place chock blocks underneath wheel to prevent rolling while parked.
• Place support blocks underneath the trailer’s bumper to prevent tipping while parked.
• Use the trailer’s swivel jack to adjust the trailer height to a level position while parked.
• Use tie downs to ensure machine does not move during transportation.

068521 Page 17
GENERAL
INFORMATION
Transportation Safety Continued
Transportation - Battery Disconnect:
When transporting the buggy always disconnect the battery. To disconnect the battery from the electronic
controls pull apart the blue connector, shown in the gure below.
Battery
Battery Disconnect
Reconnect the battery after transporting the buggy to the desired location.

SECTION 2
OPERATION
068521
Page 18
SECTION 2
OPERATION

068521 Page 19
SECTION 2
OPERATION
Introduction
This machine is built with user safety in mind. However, it can present hazards if improperly operated and ser-
viced. Follow operating instructions carefully. If you have any questions about operating or servicing this equip-
ment, please contact your Allen Engineering Dealer or AEC Customer Service
at 800-643-0095 or 870-236-7751.
Before Starting Procedures
Before operation each day check for the following:
1. All guards, side screens and panels are in place
2. All safety and information signs are in place and legible
3. Check that the battery is connected, reference Transportation Safety (pg 17)
4. Hydraulic Oil levels
5. Check the battery level
6. Verify that daily maintenance of grease points have been performed.
7. Check operating controls for proper operation and adjustment
8. Check speed control operation before and after starting the buggy for proper operation
9. Check the steering left and right, for proper operation
10. Check for any hydraulic leaks (if applicable)
11. Remove any loose objects that could interfere with the operation of the machine
Note: If there is any indication that faulty equipment exists, shutdown safely, inform the proper
authority and DO NOT operate the machine until the problem has been xed.

SECTION 2
OPERATION
068521
Page 20
Operating Instructions
CONTROL PANEL
1234
5 6 7
1. Digital Diagnostic Display:
Display will allow access to settings, error warnings, and system information. Pressing the
“Left Button” will cycle through the diffrent pages.
2. System Enable (E-Stop):
Emergency stop button. Button will disable operation of machine when enguaged. Disenguage
button (pull out) to enable operation of the machine.
3. Vehical ON/OFF Switch:
Turn switch to the “ON” position to enable operation of machine. Turning the switch to the
“OFF” position will disable operation of the machine.
4. Horn:
Use momentary switch to enable machine horn.
5. Bucket Dump:
Push switch forward to “raise” the dump bucket. Pull switch backward to “lower” the dump
bucket.
6. Light Switch:
Switch will enable the machine light. Light is located at the front of the machine, under the
bucket.
7. Forward/Neutral/Reverse Switch:
- Placing the switch in the “UP” position will allow the machine to move forward.
- Placing the switch in the “MIDDLE” position will put the machine in neutral and not allow
the machine to move.
- Placing the switch in the “DOWN” position will allow the machine to move in reverse.
