Safety Information
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
In the interest of safety, some general precautions relating to the
operation of this machine follow.
WARNING
• Failure to install, maintain and/or operate this
product according to the manufacturer’s instruc-
tions may result in conditions which can produce
serious injury, death and/or property damage.
• Do not repair or replace any part of the product or
attempt any servicing unless specifically recom-
mended or published in this Service Manual and
unless you understand and have the skills to car-
ry out the servicing.
• Whenever ground wires are removed during serv-
icing, these ground wires must be reconnected to
ensure that the product is properly grounded and
to reduce the risk of fire, electric shock, serious
injury or death.
W006R2
WARNING
To reduce the risk of electric shock, fire, explosion,
serious injury or death:
• Disconnect electric power to the washer before
servicing.
• Never start the washer with any guards/panels re-
moved.
• Whenever ground wires are removed during serv-
icing, these ground wires must be reconnected to
ensure that the washer is properly grounded.
W003
WARNING
Repairs that are made to your products by unquali-
fied persons can result in hazards due to improper
assembly or adjustments subjecting you, or the inex-
perienced person making such repairs, to the risk of
serious injury, electrical shock, or death.
W007
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. 204666ENR2
https://appliancetechmanuals.com

CAUTION
If you or an unqualified person perform service on
your product, you must assume the responsibility
for any personal injury or property damage which
may result. The manufacturer will not be responsible
for any injury or property damage arising from im-
proper service and/or service procedures.
W008
NOTE: The WARNINGS and IMPORTANT INSTRUC-
TIONS appearing in this manual are not meant to cover
all possible conditions and situations that may occur.
Common sense, caution and care must be exercised
when installing, maintaining or operating the machine.
Always contact your dealer, distributor, service agent or the man-
ufacturer about any problems or conditions you do not under-
stand.
Locating an Authorized Service Person
Alliance Laundry Systems is not responsible for personal injury
or property damage resulting from improper service. Review all
service information before beginning repairs.
Warranty service must be performed by an authorized technician,
using authorized factory parts. If service is required after the war-
ranty expires, Alliance Laundry Systems also recommends con-
tacting an authorized technician and using authorized factory
parts.
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. 204666ENR2
https://appliancetechmanuals.com

Introduction
Model Identification
Information in this manual is applicable to these washer models:
AWN43RSN115CW01 AWN63RSN115CW14
AWN43RSN115CW14 AWN63RSN115TW01
AWN43RSN115TW01 AWN63RSN115TW0P
AWN43RSN116TW01 AWN63RSN116TW01
AWN43RSN305LW01 ZWN43RSN115CW01
AWN43RSN305NW29 ZWN43RSN116CW01
AWN43RSN305XW01 ZWN63RSN115CW01
AWN63RSN115CW01 ZWN63RSN116CW01
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. 204666ENR2
https://appliancetechmanuals.com

How Your Washer Works
1. Electronic Control (inside control hood)
2. Agitator
3. Outer Tub
4. Pump
5. Motor
6. Drive Board
7. Drive Shaft
8. Washtub
9. Mixing Valve
Figure 1
The cycle begins with a wash fill. The water temperature is deter-
mined by the temperature selected on the control. While water
fills the washtub, a column of air is trapped in a pressure bulb and
hose. The air pressure continues to increase as the washtub fills
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. 204666ENR2
https://appliancetechmanuals.com

with water until the air pressure hose reaches a level determined
by the selected water level (load size switch setting) and the se-
lected cycle. The water will stop filling at the minimum level for
the selected cycle when Auto Fill is selected. In either case, the
washer will begin load sensing to determine if more water is re-
quired for the actual load in the washer and the cycle selected.
The wash agitation segment of the cycle begins at this time and
the lid must be closed and locked for any further washer opera-
tion. On non-Eco cycles, after approximately two minutes of
wash, the washer repeats the load sensing process to confirm that
the water level is still correct for the load and cycle selected.
The washer uses a reversing type of inverter drive motor and a
special stretch drive belt.
During agitation, the motor alternates between the clockwise and
counterclockwise direction. The rapid reversal from one direction
to the other creates the wash action. The stretch belt needs no ad-
justment for belt tension. Proper belt tension is provided by the
pulley spacing and use of the proper size stretch belt. This elimi-
nates belt slippage and ensures an efficient wash action.
After the wash agitation is complete and a short pause occurs, the
control advances into the wash spin. During spin, the washtub
will first rotate at 20 RPM while the electric pump runs to drain
the water from the tub. Once the pressure sensor recognizes that
the tub has been drained, the RPM will increase to extract water
from the load and the pump will continue running to remove the
water.
Water is introduced during the wash spin to spray the garments
and remove suds from them. The wash spin is followed by a rinse
step to rinse away any detergent residue.
During the rinse step in the Normal Eco cycle there will be two
more spray rinses. Water is sprayed into the washtub while it is
spinning. In all other cycles, the washer fills and then agitates
like the wash portion of the cycle.
Following the rinse step a final spin extracts the rinse water from
the clothes preparing them for the dryer. This will also start at 20
RPM with the pump running. After draining the spin will then in-
crease to a higher speed that varies depending on what cycle has
been selected. After the machine has been in spin long enough to
ensure that most of the water has been removed from the load,
the pump will run intermittently for the rest of the spin in order to
improve drain performance and reduce noise.
Refer to Cycle Sequence Charts section for a detailed breakdown
of each cycle.
Customer Service
If literature or replacement parts are required, contact the source
from whom the machine was purchased or contact Alliance
Laundry Systems at [phone] for the name and address of
the nearest authorized parts distributor.
For technical assistance, call [phone].
Serial Plate Location
When calling or writing about your product, be sure to mention
model and serial numbers. Model and serial numbers are located
on Serial Plate as shown.
TLW1851P_SVG
1
1. Serial Plate
Figure 2
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. 204666ENR2
https://appliancetechmanuals.com

Troubleshooting Diagnostics
Factory Test Procedure
It is helpful to run the Factory Test Procedure first to diagnose the
machine’s issue. This procedure tests all machine features and
operations.
To Enter Factory Test Procedure
1. Disconnect electrical power from unit.
2. Reconnect electrical power to unit.
3. Wait about 10 seconds.
4. Turn Cycle Selection knob to opposite of Normal Eco. Stay
on that selection for at least one second.
5. Press and hold the Start/Pause button.
6. Change Cycle Selection knob to Normal Eco within 5 seconds
or Start press will be invalid.
7. Stay on Normal Eco for at least one second. Control will enter
Factory Test Mode.
8. To advance through the sequence of test steps press the Start/
Pause button. Refer to Table 1 for all tests in the Factory Test
Procedure.
To Exit Factory Test Procedure
To exit the Factory Test Procedure, refer to Exit column in Table
1 and Exit Key in Table 2.
Factory Test Procedure Quick Reference Chart
Number
Display
(LEDs lit) Motor Valves Lid Pump Exit Step
0 All LEDs lit Off None Unlocked Off 1 Show Mode
1 Refer to Cycle
Switch Test
Off None Unlocked Off 3 and then 1 Cycle Switch
2 Refer to Tem-
perature
Switch Test
Off None Unlocked Off 3 and then 1 Temperature
Switch
3 Refer to Load
Size Switch
Test
Off None Unlocked Off 3 and then 1 Load Size
Switch
4 Refer to Extra
Rinse Test
Off None Unlocked Off 3 and then 1 Extra Rinse
5 Refer to Lid
Switch Test
Off None Unlocked Off 10 and then 1 Lid Switch
6 Wash Off Hot Unlocked Off 1 Hot Fill
7 Rinse Off Cold Unlocked Off 1 Cold Fill
8 Wash, Rinse Off Hot, Cold Unlocked Off 2 and then 1 Pressure Sen-
sor Fill
9 Lid Lock Off None Locked Off 7 and then 1 Lid Lock
Check
Table 1 continues...
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. 204666ENR2
https://appliancetechmanuals.com

Factory Test Procedure Quick Reference Chart
Number
Display
(LEDs lit) Motor Valves Lid Pump Exit Step
10
In Software
Version 3
and higher
this is skip-
ped.
Wash, Spin Delicate Long
Stroke Agitate
Cycle Output Locked Off 1 Long Stroke
Agitate
11
In Software
Version 3
and higher
this is skip-
ped.
Rinse, Spin Delicate Short
Stroke Regular
Agitate
None Locked Off 1 Short Stroke
Agitate
12 Refer to Fac-
tory Spin Test
Factory Spin
Profile
None Locked On 1 Factory Spin
13 Wash, Rinse
always on
Spin, Lid
Lock when
unbalance
switch press-
ed
Off None Unlocked Off 14 and then 1 Unbalance
Switch Test
14 Rinse, Spin
and Lid Lock
when lid
locked
Off Hot, Cold, Cy-
cle output
Unlocked On 1 and then 4 Breakaway
15 None Off None Unlocked Off 13 Power Down
Table 1
Exit Column Key
1 Exit by pressing Start/Pause button
2 Exit by fill level satisfaction
3 Exit when all selections are pressed
4 Exit when lid is unlocked
5 Exit when temperature reaches 104°F [40°C]
6 Exit when step timed out
7 Exit when lid locks
8 Exit when overflow level is reached
Table 2 continues...
Exit Column Key
9 Exit when washtub is empty
10 Exit when lid is closed
11 Exit when lid is opened
12 Exit when drive communication is established
13 Exit when machine unpowered
Table 2
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. 204666ENR2
https://appliancetechmanuals.com

Cycle Switch Test
This step verifies that the Cycle Selection Switch is correctly
wired and working. Turn the Cycle Selection knob through all se-
lections.
A combination of LEDs will light to show which inputs are on
for each selection. Refer to table below.
Press Start/Pause button to advance to the next step.
6-Cycle Washers
Cycle
Wash
LED
Rinse
LED Spin LED
Heavy Duty On
Normal Eco On On
Perm Press On
Delicate On On
Handwash On On
Spin Only On
Table 3
4-Cycle Washers
Cycle
Wash
LED
Rinse
LED Spin LED
Heavy Duty On On On
Normal Eco On On
Perm Press On On
Delicate On On
Table 4
Temperature Switch Test
This step verifies that the Wash Temperature Switch is correctly
wired and working. Turn the Wash Temperature knob through all
selections.
A combination of LEDs will light to show which inputs are on
for each selection. Refer to table below.
Press Start/Pause button to advance to the next step.
6-Cycle Washers
Cycle
Wash
LED
Rinse
LED Spin LED
Hot On On
Warm
Cool On
Cold On On
Table 5
4-Cycle Washers
Cycle
Wash
LED
Rinse
LED Spin LED
Hot On On
Warm On
Cold On On
Table 6
Load Size Switch Test
This step verifies that the Load Size Switch is correctly wired and
working. Turn the Load Size knob through all selections.
A combination of LEDs will light to show which inputs are on
for each selection. Refer to table below.
Press Start/Pause button to advance to the next step.
Cycle
Wash
LED
Rinse
LED Spin LED
Auto Fill On On
Large On
Medium
Small On On
Table 7
Extra Rinse Test
This step verifies that the Extra Rinse Switch is correctly wired
and working. Turn the Extra Rinse button to On and then Off.
When the Switch is On, the SPIN LED (and EXTRA RINSE
LED, if applicable) will be lit.
Press Start/Pause button with Extra Rinse off to exit the step.
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. 204666ENR2
https://appliancetechmanuals.com

Lid Switch Test
This step verifies that the Lid Switch is correctly wired and work-
ing. Close the lid. When the lid switch is closed, the SPIN and
LID LOCK LEDs will be lit.
Close the lid and press Start/Pause button to exit the step.
Hot Fill Test
This step checks the hot water valve. The WASH LED is on dur-
ing this test. The valves will shut off once two inches of water
has been reached.
Press Start/Pause button to advance to the next step.
Cold Fill Test
This step checks the cold water valve. The RINSE LED is on dur-
ing this test. The valves will shut off once three inches of water
has been reached.
Press Start/Pause button to advance to the next step.
Pressure Sensor Fill Test
This step checks the water level input. All water valves will be on
until the low water fill level is satisfied (four inches). The WASH
and RINSE LEDs will be lit in this step.
Press Start/Pause button once the water level is satisfied to exit
the step.
Lid Lock Test
This step checks the Lid Lock input. When the step is entered, the
control will lock the lid. It will check to make sure the lid is
locked and if it is, the LID LOCK LED will be on, otherwise the
LID LOCK LED will flash.
Once locked, press Start/Pause button to exit the step.
Long Stroke Agitate Test
In Software Version 3 and higher this is skipped.
Not available on models through Serial Nos. beginning 1810.
This step checks the Low Agitate speed. The WASH and SPIN
LEDs are On, the Cycle Run Output is on, and the machine enters
a Delicate Cycle Long agitate.
The control will remain in this step until the Start/Pause button is
pressed.
Short Stroke Agitate Test
In Software Version 3 and higher this is skipped.
Not available on models through Serial Nos. beginning 1810.
This step checks the Regular Agitate speed. The RINSE and
SPIN LEDs are on and the machine enters a Delicate Cycle Short
agitate.
The control will remain in this step until the Start/Pause button is
pressed.
Factory Spin Test
This step checks the spin speeds. The machine steps through spin
speeds and maintains each speed for a few seconds. After 820
RPM, the motor will stop. All OBL checking is done and if either
the out of balance switch is hit or the OBL check fails at 300
RPM, the time will be reset indefinitely to allow the load to be
rebalanced so that it can spin up and reach full speed.
The control will advance to the next step if the Start/Pause button
is pressed at any time during this step.
During this step, if 300 RPM is reached, the WASH LED will be
lit. If 500 RPM is reached, the RINSE LED will be lit. If 820
RPM is reached, the SPIN LED will be lit and if 800 RPM is
reached, the LID LOCK LED will be lit to indicate that a passing
speed has been reached.
All water valves will be on during this entire test to blow them
out.
Unbalance Switch Test
This step checks that the unbalance switch is working. The
WASH and RINSE LEDs will be on during the entire test. When
the switch is pressed, the SPIN and LID LOCK LEDs will be on.
The switch must be pressed and then Start/Pause button can be
pressed to advance to the next step.
Breakaway Test
This step checks the lid unlock function. All valves will be open
at the beginning of this step to allow the blowing out of the
valves, if needed. The Start/Pause button must be pressed to start
exiting the test. The first Start/Pause press will turn off the water
valves and start the unlock process. Once the lid unlocks, the ma-
chine will exit the test.
The RINSE and SPIN LEDs will be lit during this test. The LID
LOCK LED will be lit when the lid is locked in this test.
Power Down Test
This is the final step of the factory test procedure. All LEDs will
be off to signify that the factory test procedure has been complet-
ed and that the user can safely unplug the machine. Cycling pow-
er to the machine is the only way to resume normal operation.
Advance to Drain and Spin
Models starting Serial Nos. beginning 1804 can be rapid ad-
vanced to the final spin/drain step. For example, when testing a
washer you could enter this mode after the machine fills to ad-
vance to the final spin to drain out the water.
How to Advance:
1. Make sure EXTRA RINSE is in the OFF position.
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. 204666ENR2
https://appliancetechmanuals.com

2. Press and hold the START/PAUSE button. After about three
seconds the current cycle status light will turn off.
3. Continue holding the START/PAUSE button for another 7 - 8
seconds until the SPIN light comes on then release the button.
4. If the lid was unlocked, the LID LOCK light will come on
and the lid will lock. Once locked, the machine will start to
drain and spin.
5. After the final spin/drain step the control will reset to normal
operation.
Feature Configuration - Through Serial
Nos. Beginning 1810
Dipswitch Configuration
Dipswitches exist only on models through Serial Nos. beginning
1810.
OFF ON
Switch 1 120 Volt AC Sup-
ply
240 Volt AC Sup-
ply
Switch 2 Spray Rinse Enable Spray Rinse Disa-
bled
Switch 3 Regulated Water
Temperature/Fill
Levels
Unregulated Water
Temperature/Fill
Levels
Switch 4 Leak and Slow
Drain Errors Off
Leak and Slow
Drain Errors On
Switch 5 Pausing Allowed,
Rapid Advance
Disabled
Rapid Advance En-
abled
Switch 6 Spin Retry Extra
Time Enabled
Spin Retry Extra
Time Disabled
Switch 7 Suds Routine Extra
Time Enabled
Suds Routine Extra
Time Disabled
Switch 8 Unused Unused
Table 8
Switch 2: When set to OFF, spray rinse is enabled and the Eco
Cycles use a spray rinse. When set to ON, spray rinse is disabled
and deep tub fills are used for rinse steps.
Switch 3: When set to ON, water temperature and fill levels are
used for the specific type/region of the machine. When set to
OFF the U.S.A. default water temperatures and fill levels are
used if the temperature and fill levels in use are not already great-
er.
Switch 5: When Pausing Allowed, Rapid Advance Disabled (Off)
is selected, pressing the Start/Pause button during Run Mode will
pause the cycle. When Rapid Advance Enabled (On) is selected,
pressing the Start/Pause button during Run Mode will advance
the current cycle step to the next enabled step.
Switch 6: When set to Spin Retry Extra Time Enabled (Off) the
cycle step time will pause for the amount of time used up to that
point in the current step. This can happen twice per spin step dur-
ing a cycle if the unbalance switch is hit or if an OBL check (at
90 RPM or 350 RPM) needs to restart the spin to rebalance the
load. Additional OBL failures in the same cycle step will not
pause the time but will still restart the spin. When set to Spin Re-
try Extra Time Disabled (On), time will not pause for respins.
Switch 7: When set to Suds Routine Extra Time Enabled (Off)
the cycle step time will pause when Suds Removal Routines are
being run. Up to two Suds Removal Routines are allowed per cy-
cle. When set to Suds Routine Extra Time Disabled (On), time
will not pause if a Suds Removal Routine is run and will only al-
low one Suds Removal Routine to be run per cycle.
Feature Configuration - Starting Serial
Nos. beginning 1810
Audio Signals
An audio signal will sound for three seconds at the end of each
cycle. To turn it off, hold the Extra Rinse button for three sec-
onds. Hold it again for three seconds to turn the signal back on. A
one-second tone will sound to confirm that the End of Cycle sig-
nal is turned off or on.
Audio signals will sound when a knob selection is changed and
when the Start/Pause or Extra Rinse buttons are pressed. To turn
them off, hold the Extra Rinse button for 10 seconds. Hold it
again for 10 seconds to turn the signals back on. A three-second
tone will sound to confirm that these signals are turned off or on.
In addition, the Status lights will be lit in an upward pattern when
the signal is turned on. The lights will be lit in a downward pat-
tern when the signal is turned off.
Rapid Advance
When Rapid Advance is enabled, pressing the START/PAUSE
button during Run Mode will advance the current cycle step to
the next enabled step.
How to Enter Rapid Advance Mode:
1. Press and hold both the START/PAUSE and EXTRA RINSE
button for three seconds. The Status lights will be lit in an up-
ward pattern when rapid advance is turned on.
2. Press START/PAUSE button to advance through the cycle.
3. To exit rapid advance, press and hold both the START/
PAUSE and EXTRA RINSE button for three seconds. The
lights will be lit in a downward pattern when the signal is
turned off.
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. 204666ENR2
https://appliancetechmanuals.com

Mixing Valve Solenoid Test
Test mixing valve solenoids using an Ohm meter.
NOTE: Resistance readings slightly out of given ranges
may be due to meter conditions. These readings DO
NOT necessarily indicate mixing valve failure.
120 Volt valves 900 - 1100 Ohms
240 Volt valves 3200 - 4000 Ohms
Table 9
WASH and RINSE LEDs Flash After
Installing New Control
This applies to models through Serial Nos. beginning 1810.
If after changing the upper control board behind the control pan-
el, the new control is sending an error code (WASH and RINSE
LEDs flash once) during the first fill, it could indicate that the
pressure sensor harness has been installed incorrectly. Refer to
Figure 3 and Figure 4 . Follow the steps below to correct the er-
ror.
Incorrect
1
TLW1890B_SVG
1. Lock tab is at 12 o’clock position. (Note: Tab is colored
white for illustration purposes)
Figure 3
Correct
1
TLW1891B_SVG
1. Lock tab is at 3 o’clock position. (Note: Tab is colored
white for illustration purposes)
Figure 4
1. Disconnect electrical power from unit.
2. Remove screws holding hood assembly to rear hood panel.
3. Tip control panel down to locate H7 connection block (4-pin
block with three wires: white, red and gray).
4. Press connection block release arm and remove block.
5. Relocate connection block so release arm is at three o’clock
position and matches lock tab of block on control.
6. Re-install control hood.
7. Reconnect electrical power to unit.
8. Run washer through a cycle to verify proper operation.
Troubleshooting Diagnostics
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. 204666ENR2
https://appliancetechmanuals.com

Error Codes
Status lights may flash or remain on continuously to indicate an
error condition. The number of flashes listed below is followed
by a pause. Then the flash sequence will repeat.
Display Description Cause/Corrective Action
WASH, RINSE 1
time
Pressure Sensor Error Check for broken wires or bad connection on Pressure Sensor
Harness.
WASH, RINSE 2
times
Fill Error Check for low water pressure, clog in line or plugged fill hose
filter screens.
WASH, RINSE 2
times
No Water Flow Error Pressure sensor hose is broken or disconnected. Check for no
water lines connected, no water pressure, or clog in fill hose and
filter screens.
WASH, RINSE 3
times
Suds Lock Error Check for too much soap in machine (use less soap), clogged
drain, stuck pump, item stuck outside of washtub and possibly
between washtub and outer tub.
WASH, RINSE 4
times
Slow Drain Error Draining took longer than expected. Check for clogs and for ex-
cessive amount of soap used.
WASH, RINSE con-
tinuous
Water Leak Error Machine is leaking water due to leaking water valves, a hole in
machine, or disconnected drain hose.
WASH, RINSE con-
tinuous
Overflow Error Check for leaking water valves allowing water to come into ma-
chine. Check for debris in water valves. Check that water pres-
sure is the same on both hot and cold lines and is within spec.
WASH, RINSE con-
tinuous
Drain Error Check for clogged drain or clogged pump. Make sure drain hose
is not too tall. If pump is overheating, frequency/voltage on ma-
chine/pump do not match.
RINSE, LID LOCK
2 times
Non Fatal Lid Locking Error Check if lock is wet. Allow to dry. Check lid lock alignment.
Check for broken wiring to lid lock or broken lid hook. Load/
pressure on lid needs to adjusted.
RINSE, LID LOCK
2 times
Fatal Lid Lock Error The control senses that the lid has unlocked during a running cy-
cle. Check lock and wiring. If lock is wet, allow to dry. Unplug
machine to clear this code.
RINSE, LID LOCK
3 times
Lid Open Error Lid was sensed open during a running cycle. Check lid switch
and wiring.
RINSE, LID LOCK
3 times
Non Fatal Lid Unlocking Error Check if lock is wet. Allow to dry. Check lid lock alignment.
Check for broken wiring to lid lock or broken lid hook. Load/
pressure on lid needs to adjusted.
WASH, SPIN, LID
LOCK 2 times
Broken Belt Error On control software version 4 and lower. Drive belt is sensed as
broken or has fallen off. Replace belt. If belt is not broken, re-
place front end control.
Table 10 continues...
Error Codes
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. 204666ENR2
https://appliancetechmanuals.com

Display Description Cause/Corrective Action
WASH, SPIN 2
times
Non-Fatal Unbalance Error, maximum in-
tended speed not reached in final spin
Machine has sensed load is unbalanced. Re-balance load and try
spin step again. Do not adjust balance switch first. Most likely
not due to unbalance switch mounting. If load is only one big
item, add towels on opposite side to balance load. May also be
due to excessive suds in load or too much water left in tub due to
slow draining.
WASH, SPIN 2
times
Fatal Unbalance Error (through Serial No.
1912999999)
Wires to unbalance switch are broken or not connected. Switch
may be stuck closed. Broken spring or unleveuicontrol machine
causing tub to lean on unbalance switch.
WASH, SPIN 4
times
Fatal Unbalance Error (starting Serial No.
2001000001)
Wires to unbalance switch are broken or not connected. Switch
may be stuck closed. Broken spring or unleveuicontrol machine
causing tub to lean on unbalance switch.
SPIN, LID LOCK
continuous
Communication Error Check H2 connector on FEC to drive board wire harness for bro-
ken wire or pin not making contact.
WASH, SPIN, LID
LOCK 4 times
Board ID Error Incorrect replacement control. Replace FEC or drive board with
the correct part.
WASH, SPIN, LID
LOCK 3 times
Board Shorted Error Relay K1 on drive board is stuck/welded. Try tapping on relay to
free contacts, otherwise replace drive board.
WASH, SPIN, LID
LOCK 1 time
Drive Board Not Ready Hardware failure. Replace drive board if error persists. Unplug
machine to clear this code.
Red LED on control
board on continu-
ously instead of
flashing
Dipswitch/Voltage Configuration Error Unexpected supply voltage: Check the harness connections be-
tween the front end control and the drive board. If the front end
control was replaced, set dip switch 1 to the same setting as the
previous control. If reworking the machine to use a different
voltage supply, dip switch 1 setting may need to be changed. If
dip switch 1 setting is changed, power down, power up and try
again. Also check pin H2-7 on the front end control to ensure
good connection between front end control and drive board.
Drive Errors
All LEDs 6 times Voltage Select Error Wrong input voltage seen at drive board. (120 Volt or 240 Volt)
Dip switch 1 on front end control set wrong. There could possi-
bly be water on drive board (let drive dry out and determine
cause of water). Unpower to clear error. Replace drive board if
error persists.
All LEDs 1 time Over Voltage AC-Main Input Error Machine voltage is too high. Check supply voltage to the ma-
chine and verify that it is within machine specifications. Unpow-
er to clear error. Replace drive board if error persists.
All LEDs continu-
ous
Power Fail Dangerous Error The neutral line power input to the machine was seen out of
range. Unpower to clear error. Check for damage in the power
supply harness. Replace power supply harness or drive board if
error persists.
All LEDs 5 times Over Voltage DC Bus Error Unpower to clear error. Check voltage input to machine. If it
happens only at start of spin, replace motor. Replace drive board
if error persists.
Table 10 continues...
Error Codes
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. 204666ENR2
https://appliancetechmanuals.com

Display Description Cause/Corrective Action
WASH, RINSE,
SPIN 1 time
Over Motor Temperature Error Motor temperature is detected to be too high. Check that wash-
tub spins freely when empty. Check for overloading of machine.
Check motor harness for damage. Reduce agitation time and du-
ty cycle if rotate/pause times are very short and programmable.
Unpower to clear error. Replace drive board if error persists.
All LEDs 4 times Fatal IPM Over Current Shunt Error Check that washtub and motor spins freely. Unpower to clear er-
ror. Check the motor phase windings. Continuity should be uni-
form between phases L1 and L2, L2 and L3, L1 and L3. Replace
motor if not uniform. Replace drive board if error persists.
All LEDs 3 times Fatal I2T Hardware Over Current Error Check that washtub and motor spins freely. Rotor may be locked
up. Check the motor phase windings. Continuity should be uni-
form between phases L1 and L2, L2 and L3, L1 and L3. Replace
motor if not uniform. Unpower to clear error. Replace drive
board if error persists.
WASH, RINSE,
SPIN 2 times
IPM Over Temperature Error IPM temperature is detected to be too high. Check that washtub
spins freely when empty, check for overloading of machine, re-
duce agitation time and duty cycle if rotate/pause times are very
short and programmable. Unpower to clear error. Check for lint
build-up on heat sink on drive board. Replace drive board if er-
ror persists.
All LEDs 2 times Motor Not Connected Error The motor or one of its electrical phases is not connected. Check
that the harness from the motor to the drive board is fully plug-
ged in on both ends and that there is no damage to the motor
harness. Make sure to push in the motor harness on both ends
just in case it is a little loose and not fully inserted. If the harness
looks fine and the error still occurs, try replacing the drive board
or harness. Unpower to clear error.
WASH, RINSE,
SPIN 3 times
Fatal Overload Current Detection The drive stopped the motor because it is too hot. Let motor
cool, check for anything that may be preventing free rotation of
washtub and fix. If error persists, try replacing motor and/or
drive board.
WASH, RINSE,
SPIN 4 times
Back EMF Error The phases of motor are decompensated. It is not possible to
control the motor. The drive stopped the motor. Cycle power and
try to run machine again. If error persists, try replacing motor
and/or drive board.
WASH, RINSE,
SPIN 5 times
Fatal Start-up Failure After more than five occurences the drive turns off all outputs
and fatal error will be set. Cycle power and try to run machine
again. If error persists, replace drive board.
WASH, RINSE,
SPIN 6 times
Locked Rotor Failure Locked rotor detected due to high motor current with low motor
voltage. Check for anything that may be preventing free rotation
of washtub and fix. If error persists, try replacing motor and/or
drive board.
All LEDs continu-
ous
Over Current Shunt Detection Circuit Fail
Error at Startup
Hardware failure. Unpower to clear error. Replace drive board if
error persists.
Table 10 continues...
Error Codes
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. 204666ENR2
https://appliancetechmanuals.com

Display Description Cause/Corrective Action
All LEDs continu-
ous
Overcurrent Shunt Detection Circuit Fail
Error
Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Lid Lock Pin HW On/Off Fail Error Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Hot Valve Pin HW On/Off Fail Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Cold Valve Pin HW On/Off Fail Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Inrush Pin HW On/Off Fail Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Voltage Doubler Pin HW On/Off Fail Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Lid Lock Select Voltage Pin HW On/Off
Fail
Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Pump Pin HW On/Off Fail Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Recirculation Pin HW On/Off Fail Error Hardware failure. Unpower to clear error. Replace drive board if
error persists.
All LEDs continu-
ous
Inverter Hardware Acquisition failure The drive disabled motor activation. Cycle power and try to run
machine again. If error persists, replace drive board.
All LEDs continu-
ous
Voltage Bus acquisition failure The drive disabled motor activation. Cycle power and try to run
machine again. If error persists, replace drive board.
All LEDs continu-
ous
Motor error initialization If there is an error when the inverter is powered on the error will
be detected. Cycle power and try to run machine again. If error
persists, replace drive board.
All LEDs continu-
ous
Unbalance Switch Error Hardware failure. Check unbalance switch and wiring. Unpower
to clear error. Replace drive board if error persists.
Table 10
Error Codes
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. 204666ENR2
https://appliancetechmanuals.com

Troubleshooting Flowcharts
In some of the following procedures it will be necessary to check
voltage using a multimeter. Refer to the washer's serial plate to
determine proper voltage it is designed to operate on.
Refer to Figure 2 for serial plate location.
Troubleshooting Flowcharts
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. 204666ENR2
https://appliancetechmanuals.com
