Alliance Laundry Systems CCN020HNF Owner's manual

Installation/Operation/Maintenance
Washer-Extractors
Cabinet Hardmount
Design 2 and 3 Models
Refer to Page 8 for Model Identification
CHM1786C_SVG
Original Instructions
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. F8429301ENR18
April 2017

Table of Contents
Safety Information..................................................................................5
Explanation of Safety Messages....................................................................... 5
Important Safety Instructions........................................................................... 5
Safety Decals................................................................................................. 6
Operator Safety.............................................................................................. 6
Introduction........................................................................................... 8
Model Identification........................................................................................8
Delivery Inspection....................................................................................... 13
Serial Plate Location..................................................................................... 13
Replacement Parts ........................................................................................14
Customer Service..........................................................................................14
Manufacturing Date...................................................................................... 14
Specifications and Dimensions.............................................................. 15
General Specifications...................................................................................15
Machine Dimensions.....................................................................................18
20-60 Models............................................................................................18
80 and 100 Models ................................................................................... 20
Mounting Bolt Hole Locations – 20 and 30 Models..........................................22
Mounting Bolt Hole Locations - 40 and 60 Models.......................................... 24
Mounting Bolt Hole Locations – 80 and 100 Models ....................................... 26
Floor Mounting Layout – 20-60 Models..........................................................28
Floor Mounting Layout – 80 and 100 Models.................................................. 31
Installation........................................................................................... 36
Pallet Jack Cover Plate Removal (80 and 100 Models Only)............................. 36
Single Machine Foundation Requirements.......................................................36
Machine Installation with Existing Floor..................................................... 36
Elevated Pad Installation with Existing Floor............................................... 36
Elevated Base Frame Installation with Existing Floor................................... 36
New Foundation........................................................................................37
Isolated Pad Installation............................................................................. 37
Machine Foundation and Pad Installation........................................................ 38
Machine Installation......................................................................................39
Machine Mounting and Grouting....................................................................41
Drain Connection..........................................................................................44
Water Connection Requirements.....................................................................46
Electrical Installation Requirements................................................................48
Input Power Conditioning..............................................................................49
Input Voltage Requirements........................................................................49
© Copyright 2017, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed
written consent of the publisher.
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
3 Part No. F8429301ENR18

Circuit Breakers and Quick Disconnects......................................................... 49
Connection Specifications..............................................................................50
Single-Phase Connections (120V)...............................................................50
Single-Phase Connections (220V)...............................................................50
Three-Phase Connections........................................................................... 51
Grounding................................................................................................ 51
Phase Adder..............................................................................................52
Thermal Overload Protector....................................................................... 52
North American Approval..........................................................................53
CE Approval.............................................................................................58
Steam Requirements (Steam Heat Option Only)...............................................63
Supply Dispensing........................................................................................ 63
External Supplies..........................................................................................63
Chemical Injection Using Internal 24VAC Control Transformer.....................63
Chemical Injection Using External AC Power Source................................... 65
External Supply Signals............................................................................. 65
Connection of External Liquid Supplies.......................................................67
Start Up................................................................................................68
Pallet Jack cover Plate Installation (80 and 100 Models Only)...........................68
Basket Rotation............................................................................................ 68
Operation............................................................................................. 69
Operating Instructions................................................................................... 69
Maintenance......................................................................................... 71
Maintenance.................................................................................................71
Daily........................................................................................................... 71
Beginning of Day...................................................................................... 71
End of Day............................................................................................... 71
Monthly....................................................................................................... 71
Yearly.......................................................................................................... 72
Care of Stainless Steel................................................................................... 74
Disposal of Unit.................................................................................... 76
China Restriction of hazardous substances (RoHS)............................... 77
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
4 Part No. F8429301ENR18

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and
“CAUTION”), followed by specific instructions, are found in this
manual and on machine decals. These precautions are intended
for the personal safety of the operator, user, servicer, and those
maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or
property damage.
Additional precautionary statements (“IMPORTANT” and
“NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to in-
form the reader of specific procedures where minor
machine damage will occur if the procedure is not fol-
lowed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions
WARNING
To reduce the risk of fire, electric shock, serious in-
jury or death to persons when using your washer,
follow these basic precautions:
W023
• Read all instructions before using the washer.
• Install the washer according the INSTALLATION instruc-
tions. Refer to the EARTH/GROUND instructions in the IN-
STALLATION manual for the proper earth/ground connection
of the washer. All connections for water, drain, electrical
power and earth/ground must comply with local codes and be
made by licensed personnel when required. It is recommen-
ded that the machine be installed by qualified technicians.
• Do not install or store the washer where it will be exposed to
water and/or weather.
• To prevent fire and explosion, keep the area around machine
free from flammable and combustible products. Do not add
the following substances or textiles containing traces of the
following substances to the wash water: gasoline, kerosene,
waxes, cooking oils, vegetable oils, machine oils, dry-clean-
ing solvents, flammable chemicals, thinners, or other flamma-
ble or explosive substances. These substances give off vapors
that could ignite, explode or cause the fabric to catch fire by
itself.
• Under certain conditions, hydrogen gas may be produced in a
hot water system that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using a
washing machine or combination washer-dryer, turn on all hot
water faucets and let the water flow from each for several mi-
nutes. This will release any accumulated hydrogen gas. The
gas is flammable, do not smoke or use an open flame during
this time.
• To reduce the risk of an electric shock or fire, DO NOT use an
extension cord or an adapter to connect the washer to the elec-
trical power source.
• Do not allow children to play on or in the washer. Close su-
pervision of children is necessary when the washer is used
near children. This appliance is not intended for use by young
children or infirm persons without supervision. Young chil-
dren should be supervised to ensure that they do not play with
the appliance. This is a safety rule for all appliances.
• DO NOT reach and/or climb into the tub or onto the washer,
ESPECIALLY if the wash drum is moving. This is an immi-
nently hazardous situation that, if not avoided, will cause se-
vere personal injury or death.
• Never operate the washer with any guards, panels and/or parts
removed or broken. DO NOT bypass any safety devices or
tamper with the controls.
• Use washer only for its intended purpose, washing textiles.
Never wash machine parts or automotive parts in the ma-
chine. This could result in serious damage to the basket or
tub.
• Use only low-sudsing, no-foaming types of commercial deter-
gent. Be aware that hazardous chemicals may be present.
Wear hand and eye protection when adding detergents and
chemicals. Always read and follow manufacturer’s instruc-
tions on packages of laundry and cleaning aids. Heed all
warnings or precautions. To reduce the risk of poisoning or
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
5 Part No. F8429301ENR18

chemical burns, keep them out of the reach of children at all
times [preferably in a locked cabinet].
• Do not use fabric softeners or products to eliminate static un-
less recommended by the manufacturer of the fabric softener
or product.
• Always follow the fabric care instructions supplied by the tex-
tile manufacturer.
• Loading door MUST BE CLOSED any time the washer is to
fill, tumble or spin. DO NOT bypass the loading door switch
by permitting the washer to operate with the loading door
open. Do not attempt to open the door until the washer has
drained and all moving parts have stopped.
• Be aware that hot water is used to flush the supply dispenser.
Avoid opening the dispenser lid while the machine is running.
• Do not attach anything to the supply dispenser’s nozzles, if
applicable. The air gap must be maintained.
• Do not operate the machine without the water reuse plug or
water reuse system in place, if applicable.
• Be sure water connections have a shut-off valve and that fill
hose connections are tight. CLOSE the shut-off valves at the
end of each wash day.
• Keep washer in good condition. Bumping or dropping the
washer can damage safety features. If this occurs, have wash-
er checked by a qualified service person.
• DANGER: Before inspecting or servicing machine, power
supply must be turned OFF. The servicer needs to wait for at
least 5 minutes after turning the power OFF and needs to
check for residual voltage with a voltage meter. The inverter
capacitor or EMC filter remains charged with high voltage for
some time after powering OFF. This is an imminently hazard-
ous situation that, if not avoided, will cause severe personal
injury or death.
• Do not repair or replace any part of the washer, or attempt any
servicing unless specifically recommended in the user-mainte-
nance instructions or in published user-repair instructions that
the user understands and has the skills to carry out. ALWAYS
disconnect the washer from electrical, power and water sup-
plies before attempting any service.
• Disconnect the power by turning off the circuit breaker or by
unplugging the machine. Replace worn power cords.
• Before the washer is removed from service or discarded, re-
move the door to the washing compartment.
• Failure to install, maintain, and/or operate this washer accord-
ing to the manufacturer’s instructions may result in conditions
which can produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant
to cover all possible conditions and situations that may
occur. Common sense, caution and care must be exer-
cised when installing, maintaining, or operating the
washer.
Any problems or conditions not understood should be reported to
the dealer, distributor, service agent or the manufacturer.
WARNING
Machine installations must comply with minimum
specifications and requirements stated in the appli-
cable Installation Manual, any applicable municipal
building codes, water supply requirements, electrical
wiring regulations and any other relevant statutory
regulations. Due to varied requirements and applica-
ble local codes, this machine must be installed, ad-
justed, and serviced by qualified maintenance per-
sonnel familiar with applicable local codes and the
construction and operation of this type of machinery.
They must also be familiar with the potential hazards
involved. Failure to observe this warning may result
in personal injury, property damage, and/or equip-
ment damage, and will void the warranty.
W820
IMPORTANT: Ensure that the machine is installed on a
level floor of sufficient strength. Ensure that the recom-
mended clearances for inspection and maintenance are
provided. Never allow the inspection and maintenance
space to be blocked.
WARNING
Never touch internal or external steam pipes, con-
nections, or components. These surfaces can be ex-
tremely hot and will cause severe burns. The steam
must be turned off and the pipe, connections, and
components allowed to cool before the pipe can be
touched.
SW014
Safety Decals
Safety decals appear at crucial locations on the machine. Failure
to maintain legible safety decals could result in injury to the oper-
ator or service technician.
Use manufacturer-authorized spare parts to avoid safety hazards.
Operator Safety
WARNING
NEVER insert hands or objects into basket until it
has completely stopped. Doing so could result in se-
rious injury.
SW012
The following maintenance checks must be performed daily:
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
6 Part No. F8429301ENR18

1. Verify that all warning labels are present and legible, replace
as necessary.
2. Check door interlock before starting operation of the ma-
chine:
a. Attempt to start the machine with the door open. The ma-
chine should not start.
b. Close the door without locking it and start the machine.
The machine should not start.
c. Attempt to open the door while a cycle is in progress. The
door should not open.
If the door lock and interlock are not functioning properly, dis-
connect power and call a service technician.
3. Do not attempt to operate the machine if any of the following
conditions are present:
a. The door does not remain securely locked during the en-
tire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly grounded circuit.
Do not bypass any safety devices in the machine.
WARNING
Operating the machine with severe out-of-balance
loads could result in personal injury and serious
equipment damage.
W728
Safety Information
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
7 Part No. F8429301ENR18

Introduction
Model Identification
Information in this manual is applicable to Design 2 models or
later. Refer to the 12th position of the model number (e.g.
*CN040*YVXU 2 001):
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
8 Part No. F8429301ENR18

Models
20 Pound [9.1
Kg]
CCN020HNF
CCN020HNV
CCN020KNF
CCN020KNV
HCD020LDF
HCD020LDV
HCH020GNF
HCH020HDF
HCH020HNF
HCH020HNV
HCH020HXF
HCH020KCF
HCH020KCV
HCH020KDF
HCH020KDV
HCH020KEF
HCH020KEV
HCH020KXV
HCH020ZCF
HCH020ZCV
HCH020ZDF
HCH020ZDV
HCH020ZEF
HCH020ZEV
HCH020ZXV
HCL020GNF
HCL020HDF
HCL020HNF
HCL020HNV
HCL020HXF
HCL020KCF
HCL020KCV
HCL020KDF
HCL020KDV
HCL020KEF
HCL020KEV
HCL020KXV
HCL020ZCF
HCL020ZCV
HCL020ZDF
HCL020ZDV
HCL020ZEF
HCL020ZEV
HCL020ZXV
HCN020GNF
HCN020GNV
HCN020HCF
HCN020HDF
HCN020HEF
HCN020HNF
HCN020HNV
HCN020HXF
HCN020HYF
HCN020KCF
HCN020KCV
HCN020KDF
HCN020KDV
HCN020KEF
HCN020KEV
HCN020KXF
HCN020KYF
HCN020KYV
HCN020ZCF
HCN020ZCV
HCN020ZDF
HCN020ZDV
HCN020ZEF
HCN020ZEV
HCN020ZXF
HCN020ZYF
HCN020ZYV
HCU020GNF
HCU020HEF
HCU020HNF
HCU020HNV
HCU020HXF
HCU020KCF
HCU020KCV
HCU020KEV
HCU020KLF
HCU020KLV
HCU020KXV
HCU020KYF
HCU020KYV
HCU020ZCV
HCU020ZEV
HCU020ZLF
HCU020ZLV
HCU020ZXV
HCU020ZYF
HCZ020GNF
ICN020GNF
ICN020HNF
ICN020HNV
ICN020KCF
ICN020KCV
ICN020KDF
ICN020KDV
ICN020KEF
ICN020KEV
ICN020KNF
ICN020KNV
ICN020KXF
ICN020KYF
ICN020KYV
SCD020JDF
SCD020LDF
SCD020LDV
SCH020HNV
SCH020JCF
SCH020JCV
SCH020JDF
SCH020JDV
SCH020JEF
SCH020JEV
SCH020JXF
SCH020JXV
SCH020JYF
SCH020JYV
SCH020KNF
SCH020KNV
SCH020LCF
SCH020LDF
SCH020LDV
SCH020LEF
SCH020LEV
SCH020LLV
SCH020LXF
SCH020LXV
SCH020LYF
SCH020LYV
SCH020WCF
SCH020WCV
SCH020WEF
SCH020WEV
SCH020WLF
SCH020WLV
SCH020WXF
SCH020WXV
SCH020WYF
SCH020WYV
SCL020GNF
SCL020GNV
SCL020HNF
SCL020HNV
SCL020JCF
SCL020JCV
SCL020JDF
SCL020JDV
SCL020JEF
SCL020JEV
SCL020JXF
SCN020JXV
SCL020JYF
SCL020JYV
SCL020KNF
SCL020KNV
SCL020LCF
SCL020LDF
SCL020LDV
SCL020LEF
SCL020LEV
SCL020LLV
SCL020LXF
SCL020LXV
SCL020LYF
SCL020LYV
SCL020WCF
SCL020WCV
SCL020WEF
SCL020WEV
SCL020WLF
SCL020WLV
SCL020WXF
SCL020WXV
SCL020WYF
SCL020WYV
SCN020GNF
SCN020HNF
SCN020HNV
SCN020JCF
SCN020JCV
SCN020JDF
SCN020JEF
SCN020JXF
SCN020JYF
SCN020JYV
SCN020KNF
SCN020KNV
SCN020LCF
SCN020LCV
SCN020LDF
SCN020LDV
SCN020LEF
SCN020LEV
SCN020LXF
SCN020LYF
SCN020LYV
SCN020WCF
SCN020WCV
SCN020WDF
SCN020WDV
SCN020WEF
SCN020WEV
SCN020WYF
SCN020WYV
SCU020GNF
SCU020GNV
SCU020HNF
SCU020JCF
SCU020JCV
SCU020JDF
SCU020JDV
SCU020JEF
SCU020JEV
SCU020JLF
SCU020JLV
SCU020JXF
SCU020JXV
SCU020JYF
SCU020JYV
SCU020KNF
SCU020LCV
SCU020LDV
SCU020LEV
SCU020LLF
SCU020LLV
SCU020LXV
SCU020LYV
SCU020WCF
SCU020WCV
SCU020WDV
SCU020WEV
SCU020WLF
SCU020WLV
SCU020WXV
SCU020WYF
SCU020WYV
SCY020JDV
SCY020JEF
SCY020KNF
SCY020KNV
SCY020LEV
SCY020WEV
SCZ020GNF
SCZ020KNV
UCH020GNF
UCH020GNV
UCH020HNF
UCH020HNV
UCH020KNF
UCH020KNV
UCL020GNF
UCL020GNV
UCL020HNF
UCL020HNV
UCL020KNF
UCL020KNV
UCN020GNF
UCN020GNV
UCN020HNF
UCN020HNV
UCN020KNF
UCN020KNV
UCU020GNF
UCU020GNV
UCU020HNF
UCU020HNV
UCU020KNF
UCU020KNV
UCY020KNF
UCY020KNV
UCZ020GNF
UCZ020HNF
Table continues...
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
9 Part No. F8429301ENR18

Models
30 Pound [13.6
Kg]
CCN030HNF
CCN030HNV
CCN030KNF
CCN030KNV
HCD030LDF
HCD030LDV
HCH030GNF
HCH030HCF
HCH030HDF
HCH030HEF
HCH030HLF
HCH030HNF
HCH030HNV
HCH030HXF
HCH030KCF
HCH030KCV
HCH030KDF
HCH030KDV
HCH030KEF
HCH030KEV
HCH030KXV
HCH030KYF
HCH030ZCF
HCH030ZCV
HCH030ZDF
HCH030ZDV
HCH030ZEF
HCH030ZEV
HCH030ZXV
HCH030ZYF
HCL030GNF
HCL030HCF
HCL030HDF
HCL030HEF
HCL030HLF
HCL030HNF
HCL030HNV
HCL030HXF
HCL030KCF
HCL030KCV
HCL030KDF
HCL030KDV
HCL030KEF
HCL030KEV
HCL030KXV
HCL030KYF
HCL030ZCF
HCL030ZCV
HCL030ZDF
HCL030ZDV
HCL030ZEF
HCL030ZEV
HCL030ZXV
HCL030ZYF
HCN030GNF
HCN030GNV
HCN030HCF
HCN030HDF
HCN030HEF
HCN030HNF
HCN030HNV
HCN030HXF
HCN030HYF
HCN030KCF
HCN030KCV
HCN030KDF
HCN030KDV
HCN030KEF
HCN030KEV
HCN030KXF
HCN030KYF
HCN030KYV
HCN030ZCF
HCN030ZCV
HCN030ZDF
HCN030ZDV
HCN030ZEF
HCN030ZEV
HCN030ZXF
HCN030ZYF
HCN030ZYV
HCU030GNF
HCU030GNV
HCU030HLF
HCU030HNF
HCU030HNV
HCU030HXF
HCU030KCF
HCU030KCV
HCU030KEV
HCU030KLV
HCU030KXV
HCU030KYF
HCU030KYV
HCU030ZCF
HCU030ZCV
HCU030ZEV
HCU030ZLV
HCU030ZXV
HCU030ZYF
HCU030ZYV
HCZ030GNF
HCZ030HNF
HCZ030HNV
ICN030GNF
ICN030HNF
ICN030HNV
ICN030KCF
ICN030KCV
ICN030KDF
ICN030KDV
ICN030KEF
ICN030KEV
ICN030KNF
ICN030KNV
ICN030KXF
ICN030KYF
ICN030KYV
SCD030JDF
SCD030LDF
SCD030LDV
SCH030GCF
SCH030GNF
SCH030GNV
SCH030HNF
SCH030HNV
SCH030JCF
SCH030JCV
SCH030JDF
SCH030JDV
SCH030JEF
SCH030JEV
SCH030JXF
SCH030JXV
SCH030JYF
SCH030JYV
SCH030KNF
SCH030KNV
SCH030LCF
SCH030LCV
SCH030LEF
SCH030LEV
SCH030LXF
SCH030LXV
SCH030LYF
SCH030LYV
SCH030WCF
SCH030WCV
SCH030WEF
SCH030WEV
SCH030WLF
SCH030WLV
SCH030WXF
SCH030WXV
SCH030WYF
SCH030WYV
SCL030GCF
SCL030GNF
SCL030GNV
SCL030HNF
SCL030HNV
SCL030JCF
SCL030JCV
SCL030JDF
SCL030JDV
SCL030JEF
SCL030JEV
SCL030JXF
SCL030JXV
SCL030JYF
SCL030JYV
SCL030KNF
SCL030KNV
SCL030LCF
SCL030LCV
SCL030LEF
SCL030LEV
SCL030LXF
SCL030LXV
SCL030LYF
SCL030LYV
SCL030WCF
SCL030WCV
SCL030WEF
SCL030WEV
SCL030WLF
SCL030WLV
SCL030WXF
SCL030WXV
SCL030WYF
SCL030WYV
SCN030GNF
SCN030GNV
SCN030HNF
SCN030HNV
SCN030JCF
SCN030JCV
SCN030JDF
SCN030JEF
SCN030JXF
SCN030JXV
SCN030JYF
SCN030JYV
SCN030KNF
SCN030KNV
SCN030LCF
SCN030LCV
SCN030LDF
SCN030LDV
SCN030LEF
SCN030LEV
SCN030LXF
SCN030LXV
SCN030LYF
SCN030LYV
SCN030WCF
SCN030WCV
SCN030WDF
SCN030WDV
SCN030WEF
SCN030WEV
SCN030WLV
SCN030WYF
SCN030WYV
SCU030GNF
SCU030GNV
SCU030HNF
SCU030JCF
SCU030JCV
SCU030JDF
SCU030JDV
SCU030JEF
SCU030JEV
SCU030JLF
SCU030JLV
SCU030JXF
SCU030JXV
SCU030JYF
SCU030JYV
SCU030KNF
SCU030KNV
SCU030LCV
SCU030LDV
SCU030LEF
SCU030LEV
SCU030LLF
SCU030LLV
SCU030LXV
SCU030LYV
SCU030WCF
SCU030WCV
SCU030WDV
SCU030WEV
SCU030WLV
SCU030WXV
SCU030WYF
SCU030WYV
SCY030JDV
SCY030JEF
SCY030KNF
SCY030KNV
SCY030LDF
SCY030LEV
SCY030WEV
SCZ030GNF
UCH030GNF
UCH030GNV
UCH030HNF
UCH030HNV
UCH030KNF
UCH030KNV
UCL030GNF
UCL030GNV
UCL030HNF
UCL030HNV
UCL030KNF
UCL030KNV
UCN030GNF
UCN030GNV
UCN030HNF
UCN030HNV
UCN030KNF
UCN030KNV
UCU030GNF
UCU030GNV
UCU030HNF
UCU030HNV
UCU030KNF
UCU030KNV
UCY030KNF
UCY030KNV
UCZ030GNF
UCZ030HNF
Table continues...
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
10 Part No. F8429301ENR18

Models
40 Pound [18.1
Kg]
CCN040HNF
CCN040HNV
CCN040KNF
CCN040KNV
HCD040LDF
HCD040LDV
HCH040GNF
HCH040GNV
HCH040HCF
HCH040HDF
HCH040HEF
HCH040HNF
HCH040HNV
HCH040HXF
HCH040KCF
HCH040KCV
HCH040KDF
HCH040KDV
HCH040KEF
HCH040KEV
HCH040KXV
HCH040ZCF
HCH040ZCV
HCH040ZDF
HCH040ZDV
HCH040ZEF
HCH040ZEV
HCH040ZXV
HCL040GNF
HCL040GNV
HCL040HCF
HCL040HDF
HCL040HEF
HCL040HNF
HCL040HNV
HCL040HXF
HCL040KCF
HCL040KCV
HCL040KDF
HCL040KDV
HCL040KEF
HCL040KEV
HCL040KXV
HCL040ZCF
HCL040ZCV
HCL040ZDF
HCL040ZDV
HCL040ZEF
HCL040ZEV
HCL040ZXV
HCN040GNF
HCN040GNV
HCN040HCF
HCN040HDF
HCN040HEF
HCN040HNF
HCN040HNV
HCN040HXF
HCN040HYF
HCN040KCF
HCN040KCV
HCN040KDF
HCN040KDV
HCN040KEF
HCN040KEV
HCN040KXF
HCN040KXV
HCN040KYF
HCN040KYV
HCN040ZCF
HCN040ZCV
HCN040ZDF
HCN040ZDV
HCN040ZEF
HCN040ZEV
HCN040ZXF
HCN040ZXV
HCN040ZYF
HCN040ZYV
HCU040GNF
HCU040GNV
HCU040HLF
HCU040HNF
HCU040HNV
HCU040HXF
HCU040KCF
HCU040KCV
HCU040KEV
HCU040KLF
HCU040KLV
HCU040KXF
HCU040KXV
HCU040KYF
HCU040KYV
HCU040ZCF
HCU040ZCV
HCU040ZEV
HCU040ZLF
HCU040ZLV
HCU040ZXF
HCU040ZXV
HCU040ZYF
HCU040ZYV
ICN040GNF
ICN040HNF
ICN040HNV
ICN040KCF
ICN040KCV
ICN040KDF
ICN040KDV
ICN040KEF
ICN040KEV
ICN040KNF
ICN040KNV
ICN040KXF
ICN040KYF
ICN040KYV
SCD040JCF
SCD040JDF
SCD040LDF
SCD040LDV
SCH040GCF
SCH040GNF
SCH040GNV
SCH040HNF
SCH040HNV
SCH040JCF
SCH040JCV
SCH040JDF
SCH040JDV
SCH040JEF
SCH040JEV
SCH040JXF
SCH040JXV
SCH040JYF
SCH040JYV
SCH040KNF
SCH040KNV
SCH040LCF
SCH040LCV
SCH040LEF
SCH040LEV
SCH040LLF
SCH040LXF
SCH040LXV
SCH040LYF
SCH040LYV
SCH040WCF
SCH040WCV
SCH040WEF
SCH040WEV
SCH040WLF
SCH040WLV
SCH040WXF
SCH040WXV
SCH040WYF
SCH040WYV
SCL040GCF
SCL040GNF
SCL040GNV
SCL040HNF
SCL040HNV
SCL040JCF
SCL040JCV
SCL040JDF
SCL040JDV
SCL040JEF
SCL040JEV
SCL040JXF
SCL040JXV
SCL040JYF
SCL040JYV
SCL040KNF
SCL040KNV
SCL040LCF
SCL040LCV
SCL040LEF
SCL040LEV
SCL040LLF
SCL040LXF
SCL040LXV
SCL040LYF
SCL040LYV
SCL040WCF
SCL040WCV
SCL040WEF
SCL040WEV
SCL040WLF
SCL040WLV
SCL040WXF
SCL040WXV
SCL040WYF
SCL040WYV
SCN040GNF
SCN040GNV
SCN040HNF
SCN040HNV
SCN040JCF
SCN040JCV
SCN040JDF
SCN040JEF
SCN040JXF
SCN040JXV
SCN040JYF
SCN040JYV
SCN040KNF
SCN040KNV
SCN040LCF
SCN040LCV
SCN040LDF
SCN040LDV
SCN040LEF
SCN040LEV
SCN040LLF
SCN040LXF
SCN040LXV
SCN040LYF
SCN040LYV
SCN040WCF
SCN040WCV
SCN040WDF
SCN040WDV
SCN040WEF
SCN040WEV
SCN040WYF
SCN040WYV
SCU040GNF
SCU040GNV
SCU040HNF
SCU040JCF
SCU040JCV
SCU040JDF
SCU040JDV
SCU040JEF
SCU040JEV
SCU040JLF
SCU040JLV
SCU040JXF
SCU040JXV
SCU040JYF
SCU040JYV
SCU040KNF
SCU040KNV
SCU040LCV
SCU040LDV
SCU040LEF
SCU040LEV
SCU040LLF
SCU040LLV
SCU040LXV
SCU040LYV
SCU040WCF
SCU040WCV
SCU040WDV
SCU040WEV
SCU040WLV
SCU040WXV
SCU040WYF
SCU040WYV
SCY040JDV
SCY040JEF
SCY040KNF
SCY040KNV
SCY040LDF
SCY040LEV
SCY040WEV
UCH040GNF
UCH040GNV
UCH040HNF
UCH040HNV
UCH040KNF
UCH040KNV
UCL040GNF
UCL040GNV
UCL040HNF
UCL040HNV
UCL040KNF
UCL040KNV
UCN040GNF
UCN040GNV
UCN040HNF
UCN040HNV
UCN040KNF
UCN040KNV
UCU040GNF
UCU040GNV
UCU040HNF
UCU040HNV
UCU040KNF
UCU040KNV
UCY040KNF
UCY040KNV
Table continues...
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
11 Part No. F8429301ENR18

Models
60 Pound [27.2
Kg]
CCN060HNF
CCN060HNV
CCN060KNF
CCN060KNV
HCD060LDF
HCD060LDV
HCH060GNF
HCH060GNV
HCH060HCF
HCH060HDF
HCH060HNF
HCH060HNV
HCH060HXF
HCH060KCF
HCH060KCV
HCH060KDF
HCH060KDV
HCH060KEF
HCH060KEV
HCH060KXV
HCH060ZCF
HCH060ZCV
HCH060ZDF
HCH060ZDV
HCH060ZEF
HCH060ZEV
HCH060ZXV
HCL060GNF
HCL060GNV
HCL060HCF
HCL060HDF
HCL060HNF
HCL060HNV
HCL060HXF
HCL060KCF
HCL060KCV
HCL060KDF
HCL060KDV
HCL060KEF
HCL060KEV
HCL060KXV
HCL060ZCF
HCL060ZCV
HCL060ZDF
HCL060ZDV
HCL060ZEF
HCL060ZEV
HCL060ZXV
HCN060GNF
HCN060GNV
HCN060HCF
HCN060HDF
HCN060HEF
HCN060HNF
HCN060HNV
HCN060HXF
HCN060HYF
HCN060KCF
HCN060KCV
HCN060KDF
HCN060KDV
HCN060KEF
HCN060KEV
HCN060KXF
HCN060KYF
HCN060ZCF
HCN060ZCV
HCN060ZDF
HCN060ZDV
HCN060ZEF
HCN060ZEV
HCN060ZXF
HCN060ZYF
HCN060ZYV
HCN060KYV
HCU060GNF
HCU060GNV
HCU060HLF
HCU060HNF
HCU060HNV
HCU060HXF
HCU060KCF
HCU060KCV
HCU060KEV
HCU060KLF
HCU060KLV
HCU060KYF
HCU060KYV
HCU060ZCF
HCU060ZCV
HCU060ZEV
HCU060ZLF
HCU060ZLV
HCU060ZYF
HCU060ZYV
ICN060GNF
ICN060HNF
ICN060HNV
ICN060KCF
ICN060KCV
ICN060KDF
ICN060KDV
ICN060KEF
ICN060KEV
ICN060KNF
ICN060KNV
ICN060KXF
ICN060KYF
ICN060KYV
SCD060JDF
SCD060LDF
SCD060LDV
SCH060GNF
SCH060GNV
SCH060HNF
SCH060HNV
SCH060JCF
SCH060JCV
SCH060JDF
SCH060JDV
SCH060JEF
SCH060JEV
SCH060JXF
SCH060JYF
SCH060JYV
SCH060KNF
SCH060KNV
SCH060LCF
SCH060LCV
SCH060LEF
SCH060LEV
SCH060LLF
SCH060LXF
SCH060LXV
SCH060LYV
SCH060WCV
SCH060WEF
SCH060WEV
SCH060WLF
SCH060WLV
SCH060WXF
SCH060WXV
SCH060WYF
SCH060WYV
SCL060GNF
SCL060GNV
SCL060HNF
SCL060HNV
SCL060JCF
SCL060JCV
SCL060JDF
SCL060JDV
SCL060JEF
SCL060JEV
SCL060JXF
SCL060JYF
SCL060JYV
SCL060KNF
SCL060KNV
SCL060LCF
SCL060LCV
SCL060LEF
SCL060LEV
SCL060LLF
SCL060LXF
SCL060LXV
SCL060LYV
SCL060WCV
SCL060WEF
SCL060WEV
SCL060WLF
SCL060WLV
SCL060WXF
SCL060WXV
SCL060WYF
SCL060WYV
SCN060GNF
SCN060GNV
SCN060HNF
SCN060HNV
SCN060JCF
SCN060JCV
SCN060JDF
SCN060JEF
SCN060JXF
SCN060JXV
SCN060JYF
SCN060JYV
SCN060KNF
SCN060KNV
SCN060LCF
SCN060LCV
SCN060LDF
SCN060LDV
SCN060LEF
SCN060LEV
SCN060LXF
SCN060LXV
SCN060LYF
SCN060LYV
SCN060WCF
SCN060WCV
SCN060WDF
SCN060WDV
SCN060WEF
SCN060WEV
SCN060WYF
SCN060WYV
SCU060GNF
SCU060GNV
SCU060HNF
SCU060HNV
SCU060JCF
SCU060JCV
SCU060JDF
SCU060JDV
SCU060JEF
SCU060JEV
SCU060JLF
SCU060JLV
SCU060JXF
SCU060JXV
SCU060JYF
SCU060JYV
SCU060KNF
SCU060KNV
SCU060LCV
SCU060LDV
SCU060LEV
SCU060LLF
SCU060LLV
SCU060LXV
SCU060LYV
SCU060WCF
SCU060WCV
SCU060WDV
SCU060WEV
SCU060WLV
SCU060WXV
SCU060WYF
SCU060WYV
SCY060JDV
SCY060JEF
SCY060KNF
SCY060KNV
SCY060LEV
SCY060WEV
UCH060GNF
UCH060GNV
UCH060HNF
UCH060HNV
UCH060KNF
UCH060KNV
UCL060GNF
UCL060GNV
UCL060HNF
UCL060HNV
UCL060KNF
UCL060KNV
UCN060GNF
UCN060GNV
UCN060HNF
UCN060HNV
UCN060KNF
UCN060KNV
UCU060GNF
UCU060GNV
UCU060HNF
UCU060HNV
UCU060KNF
UCU060KNV
UCY060KNF
UCY060KNV
Table continues...
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
12 Part No. F8429301ENR18

Models
80 Pound [36.3
Kg]
CCN080HNF
CCN080HNV
CCN080KNV
HCD080LDF
HCD080LDV
HCH080GNF
HCH080HNF
HCH080HNV
HCH080KDF
HCH080KDV
HCH080ZDF
HCH080ZDV
HCL080GNF
HCL080HNF
HCL080HNV
HCL080KDF
HCL080KDV
HCL080ZDF
HCL080ZDV
HCN080GNF
HCN080HCF
HCN080HCV
HCN080HDF
HCN080HNF
HCN080HNV
HCN080HYF
HCN080HYV
HCN080KCF
HCN080KCV
HCN080KDF
HCN080KDV
HCN080KEF
HCN080KEV
HCN080KXF
HCN080KYF
HCN080KYV
HCN080ZCF
HCN080ZCV
HCN080ZDF
HCN080ZDV
HCN080ZEF
HCN080ZEV
HCN080ZXF
HCN080ZYF
HCN080ZYV
HCU080GNF
HCU080HCF
HCU080HNF
HCU080HXF
HCU080KCF
HCU080KCV
HCU080KYF
HCU080KYV
HCU080ZCF
HCU080ZCV
HCU080ZYF
HCU080ZYV
ICN080GNF
ICN080HNF
ICN080HNV
ICN080KCF
ICN080KCV
ICN080KDF
ICN080KDV
ICN080KEF
ICN080KEV
ICN080KNF
ICN080KNV
ICN080KYF
ICN080KYV
SCD080LDF
SCD080LDV
SCH080GNF
SCH080HNF
SCH080KNF
SCH080KNV
SCH080LCF
SCL080GNF
SCL080HNF
SCL080KNF
SCL080KNV
SCL080LCF
SCN080GNF
SCN080HNF
SCN080JCF
SCN080JCV
SCN080JDF
SCN080JYF
SCN080JYV
SCN080KNF
SCN080KNV
SCN080LCF
SCN080LCV
SCN080LDF
SCN080LDV
SCN080LEF
SCN080LXF
SCN080LYF
SCN080LYV
SCN080WCF
SCN080WCV
SCN080WDF
SCN080WDV
SCN080WEV
SCN080WYF
SCN080WYV
SCU080GNF
SCU080HNF
SCU080JCF
SCU080JCV
SCU080JDF
SCU080JDV
SCU080JEF
SCU080JEV
SCU080JLF
SCU080JLV
SCU080JXF
SCU080JXV
SCU080JYF
SCU080JYV
SCU080KNV
SCU080LCV
SCU080LDV
SCU080LEV
SCU080LXV
SCU080LYV
SCU080WCV
SCU080WDV
SCU080WEV
SCU080WXV
SCU080WYV
SCY080KNF
SCY080KNV
UCH080GNF
UCH080HNF
UCH080HNV
UCH080KNF
UCH080KNV
UCL080GNF
UCL080HNF
UCL080HNV
UCL080KNF
UCL080KNV
UCN080GNF
UCN080HNF
UCN080HNV
UCN080KNF
UCN080KNV
UCU080GNF
UCU080HNF
UCU080HNV
UCU080KNF
UCU080KNV
UCY080KNF
UCY080KNV
100 Pound [45.4
Kg]
CCN100HNF
CCN100HNV
HCH100GNF
HCH100HNF
HCH100HNV
HCH100KDF
HCH100KDV
HCH100ZDF
HCH100ZDV
HCL100GNF
HCL100HNF
HCL100HNV
HCL100KDF
HCL100KDV
HCL100ZDF
HCL100ZDV
HCN100GNF
HCN100HCF
HCN100HNF
HCN100HNV
HCN100KCF
HCN100KCV
HCN100KDF
HCN100KDV
HCN100KEF
HCN100KEV
HCN100KXF
HCN100KXV
HCN100KYF
HCN100KYV
HCN100ZCF
HCN100ZCV
HCN100ZDF
HCN100ZDV
HCN100ZEF
HCN100ZEV
HCN100ZXF
HCN100ZXV
HCN100ZYF
HCN100ZYV
HCU100HNV
ICN100GNF
ICN100HNF
ICN100HNV
ICN100KCF
ICN100KCV
ICN100KDV
ICN100KEV
ICN100KNF
ICN100KNV
ICN100KXV
ICN100KYV
SCH100GNF
SCH100KNF
SCH100KNV
SCL100GNF
SCL100KNF
SCL100KNV
SCN100GNF
SCN100JCF
SCN100KNF
SCN100KNV
SCN100LCF
SCN100LCV
SCN100LDF
SCN100LDV
SCN100LEF
SCN100LEV
SCN100LXF
SCN100LXV
SCN100LYF
SCN100LYV
SCN100WCF
SCN100WCV
SCN100WDF
SCN100WDV
SCN100WEF
SCN100WEV
SCN100WXF
SCN100WXV
SCN100WYF
SCN100WYV
SCU100KNV
SCY100KNF
UCH100GNF
UCH100HNF
UCH100HNV
UCH100KNF
UCH100KNV
UCL100GNF
UCL100HNF
UCL100HNV
UCL100KNF
UCL100KNV
UCN100GNF
UCN100HNF
UCN100HNV
UCN100KNV
UCU100HNF
UCU100HNV
UCU100KNF
UCU100KNV
UCY100HNF
UCY100KNV
Delivery Inspection
Upon delivery, visually inspect crate, protective cover, and unit
for any visible shipping damage. If signs of possible damage are
evident, have the carrier note the condition on the shipping pa-
pers before the shipping receipt is signed, or advise the carrier of
the condition as soon as it is discovered.
Serial Plate Location
The serial plate is located at the rear of the machine and inside
door. Provide the machine’s serial number and model number
when ordering parts or seeking technical assistance. Refer to Fig-
ure 1 .
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
13 Part No. F8429301ENR18

CHM2433N_SVG
1
1. Serial Plate
Figure 1
Replacement Parts
If literature or replacement parts are required, contact the source
from which the machine was purchased or contact Alliance Laun-
dry Systems at [phone] for the name and address of
the nearest authorized parts distributor.
Customer Service
For technical assistance, contact your local distributor or contact:
Alliance Laundry Systems
Shepard Street
P.O. Box 990
Ripon, WI 54971-0990
U.S.A.
www.alliancelaundry.com
Phone: [phone] Ripon, Wisconsin
Manufacturing Date
The manufacturing date for your unit can be found on the serial
number. The first two digits indicate the year. The third and
fourth digits indicate the month. For example, a unit with serial
number 1505000001 was manufactured in May 2015.
Introduction
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
14 Part No. F8429301ENR18

Specifications and Dimensions
General Specifications
Model 20 30 40 60 80 100
Overall Dimensions
Overall width, in. [mm] 26.0 [660] 29.0 [737] 30.63 [778] 34.06 [865] 41.5 [1054] 41.5 [1054]
Overall height, in. [mm] Design 2 43.5 [1105] 46.45
[1180]
48.7 [1237] 51.39
[1305]
57.66
[1465]
57.66
[1465]
Design 3 44.5 [1130]
Overall depth, in. [mm] 30.85 [784] 35.29 [896] 42.25
[1073]
44.7 [1135] 48.6 [1234] 52.6 [1336]
Weight and Shipping Information
Net weight, lbs. [kg] 335 [152] 460 [209] 550 [249] 695 [315] 1210 [549] 1260 [572]
Standard shipping weight, lbs. [kg] 365 [166] 495 [225] 590 [268] 745 [338] 1260 [572] 1310 [594]
Standard shipping volume, ft3 [m3] Design 2 26.5 [0.75] 36 [1.01] 44 [1.24] 57 [1.61] 81 [2.29] 87 [2.4]
Design 3 27 [0.77]
Standard shipping dimensions
(WxDxH), in. [mm]
Design 2 28 x 33.8 x
48.4 [711 x
859 x
1229]
31.5 x 38.3
x 51.3 [800
x 973 x
1303]
32.5 x 43.5
x 53.6 [826
x 1105 x
1361]
37.5 x 46.9
x 56.3 [953
x 1191 x
1430]
44 x 54.5 x
58.6 [1118
x 1384 x
1488]
44 x 58.5 x
58.6 [1118
x 1486 x
1488]
Design 3 28 x 33.8 x
49.4 [711 x
859 x
1256]
Slat crate shipping weight, lbs. [kg ] 450 [204] 590 [268] 690 [313] 860 [390] 1385 [628] 1435 [651]
Slat crate shipping volume, ft3 [m3] Design 2 36.2 [1.04] 47 [1.33] 54 [1.52] 78 [2.20] 105 [2.97] 112 [3.17]
Design 3 38 [1.07]
Slat crate shipping dimensions
(WxDxH), in. [mm]
Design 2 32.5 x 36.8
x 49.8 [826
x 935 x
1240]
36 x 41.3 x
55 [914 x
1049 x
1397]
37 x 45.9 x
55 [940 x
1166 x
1397]
42 x 49.9 x
64 [1067 x
1267 x
1626]
48.5 x 57.5
x 65.1
[1232 x
1461 x
1654]
48.5 x 61.5
x 65.1
[1232 x
1562 x
1654]
Design 3 32.5 x 36.8
x 55 [826 x
935 x
1397]
Wash Cylinder Information
Cylinder diameter, in. [mm] 21 [533] 24 [610] 26.3 [668] 30 [762] 36 [914] 36 [914]
Cylinder depth, in. [mm] 13.8 [350] 16 [406] 20.3 [515] 22 [559] 21.9 [556] 25.9 [657]
Cylinder volume, ft3 [l] 2.8 [79.3] 4.2 [119] 6.3 [178] 9.00 [255] 12.9 [365] 15.2 [430]
Table 1 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
15 Part No. F8429301ENR18

Model 20 30 40 60 80 100
Perforation size, in. [mm] 0.188 [4.78] 0.188
[4.78]
0.188
[4.78]
0.188
[4.78]
0.188
[4.78]
0.188
[4.78]
Perforation open area, % 17.3 18.6 18.8 18.8 19.6 20.2
Door Opening Information
Door opening size, in. [mm] 11.6 [295] 14.3 [363] 16.3 [414] 16.3 [414] 18.5 [470] 18.5 [470]
Height of door bottom above floor, in.
[mm]
14.38 [365] 14 [356] 14.56 [370] 14.94 [379] 17.91 [455] 17.91 [455]
Height of door opening above floor,
in. [mm]
17 [432] 17 [431] 17.74 [451] 18.12 [460] 20.77 [528] 20.77 [528]
Power Consumption
Average power used per
cycle, kW-hr. (X-voltage
shown)
No load .05 .09 .10 .15 .19 .19
80 % load .06 .11 .14 .22 .28 .28
Estimated Building Heat Load
HVAC load, Btu/hr. [Kcal/hr.] (Non-
heat models)
400 [101] 450 [113] 510 [129] 750 [189] 950 [239] 950 [239]
Drive Train Information
Number of motors in drive train 1 1 1 1 1 1
Drive motor power, hp [kW] * 2 [1.5] 2 [1.5] 3 [2.2] 5 [3.7] 5 [3.7]
Cylinder Speeds
Gentle wash/reverse speed, RPM [G] 37 [0.4] 34 [0.4] 33 [0.4] 31 [0.4] 28 [0.4] 28 [0.4]
Wash/reverse speed, RPM [G] 51 [0.8] 48 [0.8] 46 [0.8] 43 [0.8] 39 [0.8] 39 [0.8]
Distribution speed, RPM [G] 92 [2.5] 86 [2.5] 82 [2.5] 77 [2.5] 70 [2.5] 70 [2.5]
Extract Speed 1 (very low), RPM [G] 301 [27] 282 [27] 269 [27] 252 [27] 230 [27] 230 [27]
Extract Speed 2 (low), RPM [G] 518 [80] 485 [80] 464 [80] 434 [80] 396 [80] 396 [80]
Extract Speed 3 (medium), RPM [G] 579 [100] 542 [100] 518 [100] 485 [100] 443 [100] 443 [100]
Extract Speed 4 (high), RPM [G] 648 [120] 606 [120] 579 [120] 542 [120] 495 [120] 495 [125]
Extract Speed 5 (very high), RPM [G] 710 [150] 664 [150] 635 [150] 594 [150] 542 [150] 542 [150]
Extract Speed 6 (ultra high), RPM [G] 819 [200] 766 [200] 733 [200] 686 [200] 626 [200] 568 [165]
Direct Steam Heating (Optional)
Steam inlet connection size, NPT 1/2 1/2 1/2 1/2 1/2 1/2
Number of steam inlets ** ** 1 1 1 1
Steam required to raise
bath water temperature
10°F/lbs. [10°C/kg]
LOW .74 [0.34] .94 [0.43] 2.09 [0.94] 3.80 [1.63] 3.80 [1.72] 3.80 [1.72]
MED 1.07 [0.49] 1.28 [0.58] 2.40 [1.09] 4.65 [2.11] 4.65 [2.11] 5.49 [2.49]
HIGH 1.44 [0.65] 1.74 [0.79] 2.84 [1.29] 5.79 [2.63] 5.79 [2.63] 6.84 [3.10]
Table 1 continues...
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
16 Part No. F8429301ENR18

Model 20 30 40 60 80 100
Average steam consumption per cycle,
bHP
.34 .41 .78 .98 1.34 1.58
Electrical Heating
Total electrical heating
capacity, kW
Input Volt-
age
200V 5.4 5.4 10.8 10.8 19.1 19.1
240V 7.8 7.8 15.6 15.6 27.4 27.4
380V 6.5 6.5 13.0 13.0 17.2 17.2
415V 7.8 7.8 15.5 15.5 20.5 20.5
480V N/A N/A 15.6 15.6 27.4 27.4
Electrical heating elements 3 3 6 6 6 6
Electrical heat element size, kW 2.6 2.6 2.6 2.6 4.2 4.2
Noise Emissions
dBA Wash 58 58 58 58 58 58
Extract 100G 52 59 59 59 69 69
200G 61 66 66 66 76 73
* For B, Q and X-voltage models = 1 hp [.75 kW] and for N and P-voltage models = 2 hp [1.7 kW]
** 20 and 30 models can be prep for steam and a kit is available for conversion.
N/A = Not Applicable
Table 1
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
17 Part No. F8429301ENR18

Machine Dimensions
20-60 Models
CHM2618N_SVG
G
F
E
D
C
B
A
W
V
U
T
S
R
Q
P
O
N
M
L
K
J
I
H
6
5
43
2
1
X
1. Supply Dispenser
2. Input Power Block Compartment
3. Hot Water Inlet
4. Cold Water Inlet
5. Vacuum Breaker
6. Drain Outlet
Figure 2
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
18 Part No. F8429301ENR18

Machine Dimensions - 20-60 Models, in. [mm]
Specification
20
(Design 2)
20
(Design 3) 30 40 60
A38.0 [965] 39.0 [991] 40.94 [1040] 43.19 [1097] 45.88 [11.65]
B35.0 [889] 36.0 [914] 37.94 [964] 40.19 [1021] 42.88 [1089]
C34.52 [902] 35.52 [902] 37.46 [951] 39.71 [1009] 42.4 [1077]
D4.7 [119] 4.7 [119] 4.14 [105] 4.51 [115] 4.87 [124]
E7.83 [199] 7.83 [199] 9.33 [237] 8.82 [224] 9.89 [251]
F2.99 [76] 2.99 [76] 2.99 [76] 2.99 [76] 2.99 [76]
G6.94 [176] 6.94 [176] 6.94 [176] 6.94 [176] 6.94 [176]
H8.82 [224] 8.82 [224] 8.82 [224] 8.82 [224] 8.82 [224]
I15.15 [385] 15.15 [385] 15.15 [385] 15.15 [385] 19.9 [505]
J15.65 [398] 15.65 [398] 15.65 [398] 15.65 [398] 20.4 [518]
KN/A N/A N/A 19.48 [495] 22.91 [582]
LN/A N/A N/A 44.61 [1133] 47.3 [1201]
M0.34 [9] 0.34 [9] 0.34 [9] 2.0 [51] 2.0 [51]
N26.83 [681] 26.83 [681] 31.5 [800] 35.52 [902] 38.62 [981]
O27.31 [694] 27.31 [694] 31.82 [808] 36.96 [939] 39.45 [1002]
P30.85 [784] 30.85 [784] 35.29 [896] 42.25 [1073] 44.7 [1135]
Q9.0 [254] 9.0 [254] 9.0 [254] 9.0 [254] 9.0 [254]
R23.01 [584] 23.01 [584] 24.0 [610] 26.0 [660] 26.38 [670]
S17.0 [432] 17.0 [432] 17.0 [432] 17.74 [451] 18.12 [460]
T14.38 [365] 14.38 [365] 14 [356] 14.56 [370] 14.94 [379]
U26.0 [660] 26.0 [660] 29.0 [737] 30.63 [778] 34.06 [865]
V42.0 [1067] 43.0 [1092] 44.95 [1142] 47.2 [1199] 49.89 [1267]
W1.5 [3] 1.5 [3] 1.5 [38] 1.5 [38] 1.5 [38]
X16.75 [426] 16.75 [426] 19.38 [429] 21.75 [552] 21.75 [552]
N/A = Not Applicable
Table 2
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
19 Part No. F8429301ENR18

80 and 100 Models
CHM2619N_SVG
G
F
E
D
C
B
A
W
X
Y
Z
AA
V
U
T
S
R
Q
P
O
N
M
L
K
J
I
H
8
56
7
4
3
2
1
AB
1. Supply Dispenser
2. Input Power Block Compartment
3. Auxiliary Hot Water Inlet
4. Auxiliary Cold Water Inlet
5. Cold Water Inlet
6. Hot Water Inlet
7. Vacuum Breaker
8. Drain Outlet
Figure 3
Specifications and Dimensions
© Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
20 Part No. F8429301ENR18
