Allied Medical Set-Up Guide
Varilite Icon Mid Back
Tools required:
• Tape measure
• 1x 4mm Allen key
• Paper & pen
• Script or brochure.
• Instruction manual
1. Required measurements for set up
Letter Body Part Required (Y/N)
AHip N
B Thigh (Right) N
B Thigh (Left) N
C Right Leg N
C Left Leg N
D Right back height (below scapula) Y
D Left back height (below scapula) Y
E Shoulder to seat Y
F Top of head to seat N
G Right elbow to seat N
G Left elbow to seat N
H Back width (below scapula) N
The required measurement is best taken, while the client is in a seated position,
from the base of the seat to the bottom of the scapular or top of the shoulders
to allow for maximum support.
For maximum support, the back height may fall in between these two
measurements. The Icon Mid Back can sometimes be used in place of a

support from being mounted in a lower position.

2. Available adjustments and options
Terminology

Angle Adjustments
Up to 20 degrees posterior or up to 20 degrees anterior.
• Adjustments are made by loosening the bolts on the side of the cane bracket that hold the
slide bracket housing.
• Once loosened you can adjust the back to the desired angle.
Depth Adjustments

changing the position of the cane bracket or slide bracket (see image below). 2 inches of depth
adjustment is also available through the slide bracket housing on the cane bracket.

Height Adjustments
The seatback can be adjusted up and down on the sliding shell brackets or through the cane
brackets.
• Cane brackets can be mounted in various positions depending on the canes on the chair, and
how much space is available for mounting. After setting these in the appropriate position the
back height can then be adjusted further by loosening the screws on the sliding bracket to
achieve the desired height.
Adjustable Air Foam Cushion
• Adjustable toggle on the bottom left hand corner of the back (when facing the front).
• Sit the user in the chair and allow them to sit back into the back, once in position turn the air

• 
Accessories
• PSIS Block – Corrects posterior pelvic tilt by supporting the sacrum at the PSIS.
• Supplemental Lateral Supports - Provides additional support where desired when placed inside
the Icon Back shell.
• Cane shims – each back comes standard with two sizes of shims, to be used with back canes

¾” cane.
• Mounting spacer block for headrest

3. Tips & Tricks
Easy Set-up
• 
• When mounting the brackets, ensure that the hardware is mounted parallel to the seat rails.
This will make it much easier when you are removing and inserting the seat back.
• Then attach back to the brackets and make height adjustments through the sliding shell
brackets.
*When making adjustments only loosen the adjustment screws by ¾ of a turn.
Trouble Shooting
If the back system is “sticking” or “binding”. Allow slide brackets to “self centre”.
• 
• Allow brackets to move so that there is room in the holsters.
• Retighten slide brackets.
Check cane brackets
• Make sure they are installed at same height on canes.
• 
Check angle adjustment
• Holsters to make sure the angle is same on each side.
• To correct:
- Loosen top adjustment screw ¾ turn
- Press backrest backwards
- Tighten screw while holding backrest backward
- Repeat slide bracket self centering
3. Checklist
What to check Done
Brackets are mounted parallel to the seat rails on both sides
Mounting brackets are mounted at the same height
Back height has been set to the top of the users shoulders
Check that seatback can be removed and inserted without sticking
or binding
Ensure all adjustment screws have been tightened at the end of the
setup
