Allied Telesis AT-MC102XLPCI User manual

613-001527 Rev. B
AT-MC102XLPCI
AT-MC102XLPCIe
100TX to 100FX(SC) PCI & PCI Express Bus Media
Converter
Installation Guide

Copyright ©2014 Allied Telesis, Inc.
All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc.
Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior
written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for
any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related
to this manual or the information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the
possibility of such damages.

3
Electrical Safety and Emissions
Standards
This product meets the following standards.
RFI Emissions
FCC Class B, CISPR 22 Class B, EN55022 Class B, VCCI Class B,
C-TICK
Immunity
EN55024
Electrical Safety
UL 60950-1 (CULUS), EN60950 (TUV), CSA, NRTL, CE
U.S. Federal Communications Commission
Declaration of Conformity
Manufacturer Name: Allied Telesis, Inc.
Declares that the product: Media Converter
Model Numbers: AT-MC102XLPCI, AT-MC102XLPCIe
This product complies with FCC Part 15B, Class B Limits:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
must not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Radiated Energy
Note: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15
of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with instructions, may cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes and modifications not expressly approved by the manufacturer or registrant of this equipment can void your
authority to operate this equipment under Federal Communications Commission rules.
Industry Canada
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

4
Translated Safety Statements
Important: The indicates that a translation of the safety statement is available in a PDF
document titled “Translated Safety Statements” posted on the Allied Telesis website at
www.alliedtelesis.com/support.

5
Preface ............................................................................................................................................................ 11
Safety Symbols.......................................................................................................................................... 12
Contacting Allied Telesis............................................................................................................................ 13
Chapter 1: Product Overview ....................................................................................................................... 15
Key Features.............................................................................................................................................. 16
Status LEDs............................................................................................................................................... 17
Auto MDI/MDIX.......................................................................................................................................... 18
Auto-Negotiation ........................................................................................................................................ 19
MissingLink & Link Test Features.............................................................................................................. 21
MissingLink Feature ............................................................................................................................ 21
Link Test Feature................................................................................................................................. 21
Configuring MissingLink & Link Test Features ....................................................................................22
Chapter 2: Installation ................................................................................................................................... 23
Reviewing Safety Precautions ................................................................................................................... 24
Pre-Installation Checklist............................................................................................................................ 26
Planning the Installation ...................................................................................................................... 26
Unpacking the Media Converter.......................................................................................................... 26
Replacing the Bracket ......................................................................................................................... 28
Configuring Auto-Negotiation .............................................................................................................. 29
Configuring MissingLink & Link Test ................................................................................................... 30
Installing a Network Media Converter........................................................................................................ 31
Connecting the Network Cables................................................................................................................. 34
Chapter 3: Troubleshooting ......................................................................................................................... 37
Twisted-Pair LED....................................................................................................................................... 38
Fiber Port LED ........................................................................................................................................... 39
Link Test..................................................................................................................................................... 40
Technical Specifications ............................................................................................................................... 41
Contents

Contents
6

7
Figures
Figure 1. AT-MC102XLPCI Media Converter..................................................................................................................... 16
Figure 2. Status LEDs ........................................................................................................................................................ 17
Figure 3. PC Board Location of Jumper J4......................................................................................................................... 19
Figure 4. PC Board Location of Jumper J5......................................................................................................................... 22
Figure 5. AT-MC102XLPCI Media Converter Items ........................................................................................................... 27
Figure 6. Removing the Low-Profile Bracket...................................................................................................................... 28
Figure 7. Installing the Standard Bracket............................................................................................................................ 29
Figure 8. Removing the PC Cover...................................................................................................................................... 31
Figure 9. Removing the Faceplate From PCI Slot.............................................................................................................. 32
Figure 10. Inserting the Adapter with a High-profile Bracket.............................................................................................. 32
Figure 11. Securing the Adapter with a High-profile Bracket.............................................................................................. 33
Figure 12. Connecting the Fiber Optic Cable to the AT-MC102XLPCI Media Converter................................................... 34
Figure 13. Connecting the Twisted-pair Cable to the AT-MC102XLPCI Media Converter................................................. 35
Figure 14. RJ-45 Connector and Port Pin Layout............................................................................................................... 43

List of Figures
8

9
Tables
Table 1. LED Functions ......................................................................................................................................................17
Table 2. Auto-Negotiation Configuration- Jumper J4 Positions ..........................................................................................20
Table 3. MissingLink & Link Test - Jumper J5 Positions ....................................................................................................22
Table 4. Physical Specifications .........................................................................................................................................41
Table 5. Operating and Storage Conditions .......................................................................................................................41
Table 6. Electrical Rating ....................................................................................................................................................42
Table 7. Agency Certifications ............................................................................................................................................42
Table 8. Environmental Compliance ...................................................................................................................................42
Table 9. Twisted-Pair Cable Requirements for the 100Base-TX Ports ..............................................................................43
Table 10. RJ-45 Pin Signals for MDI and MDI-X ................................................................................................................43
Table 11. Fiber Optic Cable Loss Budget ...........................................................................................................................44
Table 12. Fiber Optic Launch Power ..................................................................................................................................44
Table 13. Fiber Optic Receive Power .................................................................................................................................44
Table 14. Fiber Optic Cable Distance .................................................................................................................................45
Table 15. Fiber Optic Loss Specifications ..........................................................................................................................45

Tables
10

11
Preface
This guide contains instructions on how to install an AT-MC102XLPCI &
AT-MC102XLPCIe 100Mbps Media Converters.
This preface contains the following sections:
❒“Safety Symbols” on page 12
❒“Contacting Allied Telesis” on page 13

Preface
12
Safety Symbols
This document uses the following conventions:
Note
Notes provide additional information.
Caution
Cautions inform you that performing or omitting a specific action
may result in equipment damage or loss of data.
Warning
Warnings inform you that performing or omitting a specific action
may result in bodily injury.
Warning
Warnings inform you that an eye and skin hazard exists due to the
presence of a Class 1 laser device.

AT-MC102XLPCI & AT-MC102XLPCIE 100Mbps Media Converter Installation Guide
13
Contacting Allied Telesis
If you need assistance with this product, you may contact Allied Telesis
technical support by going to the Support & Services section of the Allied
Telesis web site at www.alliedtelesis.com/support. You can find links for
the following services on this page:
❒24/7 Online Support - Enter our interactive support
center to search for answers to your questions in our
knowledge database, check support tickets, learn
about RMAs, and contact Allied Telesis technical
experts.
❒USA and EMEA phone support - Select the phone
number that best fits your location and customer type.
❒Hardware warranty information - Learn about Allied
Telesis warranties and register your product online.
❒Replacement Services - Submit a Return Merchandise
Authorization (RMA) request via our interactive support
center.
❒Documentation - View the most recent installation
guides, user guides, software release notes, white
papers and data sheets for your product.
❒Software Updates - Download the latest software
releases for your product.
For sales or corporate contact information, go to
www.alliedtelesis.com/purchase and select your region.

Preface
14

15
Chapter 1
Product Overview
The AT-MC102XLPCI & AT-MC102XLPCIe 100Mbps Media Converters
products are designed to connect with the PCI bus in a computer. The
MC102XLPCI is designed for a PCI card slot and the MC102XLPCIe is
designed to interface with a PCI Express card slot. The specifications for
these two products along with their respective installation instructions are
identical with one exception - the physical connector is different between
the two products to conform with the different dimensions of the PCI and
PCI Express connectors.
Note
For simplicity in the rest of this manual, the AT-MC102XLPCI & AT-
MC102XLPCIe 100Mbps Media Converters will be referred to as AT-
MC102XLPCI Media Converter.
The AT-MC102XLPCI Media Converter is designed to connect a copper
Ethernet medium with a fiber Ethernet medium. A common application for
this product is providing an interconnection between a computer's network
copper port and a fiber network infrastructure.
This chapter contains the following sections:
❒Key Features on page 16
❒Status LEDs on page 17
❒Auto MDI/MDIX on page 18
❒Auto-Negotiation on page 19
❒MissingLink & Link Test Features on page 21

Chapter 1: Product Overview
16
Key Features
The AT-MC102XLPCI Media Converter features a 100Base-TX twisted-
pair port and an 100Base-FX fiber optic port. The twisted-pair port has an
RJ-45 connector and a maximum operating distance of 100 meters (328
feet). The fiber optic port has a dual SC connector and a maximum
operating distance of 2 kilometers (1.2 miles).
This media converter operates at 100 Mbps and is configured from the
factory for Auto-Negotiation mode.
The AT-MC102XLPCI Media Converter is designed to be installed in a
PCI bus slot of a PC and does not require any software configuration or
management.
An AT-MC102XLPCI Media Converter is illustrated in Figure 1.
Figure 1. AT-MC102XLPCI Media Converter
The AT-MC102XLPCI Media Converter has the following key features:
❒100Base-TX twisted-pair port Half- or full-duplex operation - See
Figure 1.
❒100Base-FX fiber optic port - See Figure 1.
❒See Status LEDs on page 17 for more information.
❒See Auto MDI/MDIX on page 18 for more information.
❒See Auto-Negotiation on page 19 for more information.
❒See MissingLink & Link Test Features on page 21 for more
information.

AT-MC102XLPCI & AT-MC102XLPCIE 100Mbps Media Converter Installation Guide
17
Status LEDs
The AT-MC102XLPCI Media Converter has two status LEDs associated
with the 100Base-TX twisted-pair port and the 100Base-FX fiber optic port.
The location of these LEDs is shown in Figure 2.
Figure 2. Status LEDs
The functional description of the port Status LEDs are given in Table 1.
Table 1. LED Functions
LED Color Description
TX
Solid Green1,2
1. In Link Test mode, the TX and RX link LEDs indicate link independently of each
other based on whether their respective port has a compatible link.
Indicates a link is established on the copper
port.
OFF Indicates that a link is not established on the
copper port.
FX
Solid Green1,2
2. In Missing Link mode, the TX and FX LEDs will not indicate a link (OFF) until
both ports are simultaneously linked successfully (Solid Green).
Indicates a link is established on the fiber port.
OFF Indicates that a link is not established on the
fiber port.
Fiber
Link TX
Link
LED LED

Chapter 1: Product Overview
18
Auto MDI/MDIX
An RJ-45 twisted-pair port on an 100 Mbps Ethernet network device can
have one of two possible wiring configurations: MDI or MDI-X. The RJ-45
port on a PC, router, or bridge is typically wired as MDI, while the twisted-
pair port on a switch or hub is usually MDI-X.
The AT-MC102XLPCI Media Converter features automatic MDI/MDI-X.
The 100Base-TX port automatically determines the configuration of the
port on the device to which it is connected and then configures itself
appropriately. For example, if a port on a media converter is connected to
a PC, which is typically wired as MDI, the port on the media converter
automatically configures itself as MDI-X. This feature allows you to use a
straight-through cable when connecting to any type of device.

AT-MC102XLPCI & AT-MC102XLPCIE 100Mbps Media Converter Installation Guide
19
Auto-Negotiation
The Auto-Negotiation feature is used to automatically determine a
common duplex mode between the twisted-pair port and its link partner.
This feature is enabled at the factory and is compatible with the IEEE
802.3u specification.
The 100FX port usually operates in Full Duplex mode. The goal of the
Auto-Negotiation feature is to avoid a duplex mismatch between the
copper and fiber ports of the AT-MC102XLPCI by ensuring that the
twisted-pair port and its link partner are also configured to operate in Full
Duplex mode. In most configurations, the link partner of the twisted-pair
port is configured for Auto-Negotiation by default so the Auto-Negotiation
feature of the MC102XLPCI also needs to also be activated (factory
default configuration). If the twisted-pair link partner’s port is set to Fixed
Full Duplex mode, then the MC102XLPCI should be configured with the
Auto-Negotiation disabled. In both cases, these settings allow the twisted-
pair ports to operate in Full Duplex mode.
Note
If the twisted-pair link partner’s port is set to Fixed Half Duplex
mode, a duplex mismatch can occur with the fiber port assuming the
fiber port is operating in Full Duplex mode. This situation can result
in significant degradation of Ethernet traffic throughput. To avoid this
issue, ensure that the twisted-pair link partner’s port is configured for
either Auto-Negotiation or Fixed Full Duplex when the fiber port is
operating in Full Duplex mode.
The location of the jumper (J4) is shown in Figure 3. The Auto-Negotiation
configuration and jumper pin positions for jumper J4 are given in Table 2.
Figure 3. PC Board Location of Jumper J4

Chapter 1: Product Overview
20
Note
Although it is not marked on J4, Pin 2 is positioned between pins 1
and 3.
Note
If you choose to remove the jumper, Allied Telesis recommends that
you re-install the jumper on the center pin (2) only, 90 degrees from
the pins 1 and 3 so that it does not get lost.
Table 2. Auto-Negotiation Configuration- Jumper J4 Positions
Pin Position of Jumper Feature Configuration
1 and 2 (Factory Default) Auto-Negotiation feature enabled
2 and 3 Auto-Negotiation feature disabled
No Jumper Installed Auto-Negotiation feature enabled
