AT-MC105XL
AT-MC106XL
Fast Ethernet Media Converters
Installation Guide
PN 613-10800-00 Rev.A

Copyright 1999 Allied Telesyn International, Corp.
960 Stewart Drive Suite B, Sunnyvale CA 94086 USA
All rights reserved. No part of this publication may be reproduced without prior written permission
from AlliedTelesyn International, Corp.
Ethernet is a registered trademark of Xerox Corporation. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their
respective owners.
AlliedTelesyn International, Corp. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The information provided
herein is subject to change without notice. In no event shall AlliedTelesyn International, Corp. be
liable for any incidental, special, indirect, or consequential damages whatsoever, including but not
limited to lost profits, arising out of or related to this manual or the information contained herein,
even if AlliedTelesyn International, Corp. has been advised of, known, or should have known, the
possibility of such damages.

iii
Safety and InterferenceWarnings
STANDARDS:This product meets the following standards
RFI Emission EN55022 Class A
WARNING: In a domestic environment this product may cause radio interference in which case the user may be
required totake adequate measures.
Immunity EN50082-1
WARNING: This product requires shielded cables to comply with emission and immunity standards. If it is used
with unshieldedcables, theuser maybe required totake measures to correct the interference problem attheir own
expense.
Electrical Safety TUV-EN60950, UL1950, CSA 950
Laser EN60825
IMPORTANT: Appendix A contains translated safetystatements for installingthis equipment. When you see the
!, go to Appendix A for the translated safety statement in your language.
WICHTIG: Anhang A enthält übersetzte Sicherheitshinweise für die Installation dieses Geräts. Wenn Sie!
sehen, schlagenSie in Anhang Aden übersetzten Sicherheitshinweisin Ihrer Sprache nach.
VIGTIGT: Tillæg A indeholder oversatte sikkerhedsadvarsler, dervedrørerinstallation af dette udstyr. NårDe ser
symbolet !, skal De slå op i tillæg A og finde de oversatte sikkerhedsadvarsler i Deres eget sprog.
BELANGRIJK: Appendix A bevat vertaalde veiligheidsopmerkingenvoorhet installeren van deze apparatuur.
Wanneer u de !ziet, raadpleeg Appendix A voor vertaalde veiligheidsinstructies in uw taal.
IMPORTANT: L'annexe A contient les instructions de sécurité relativesà l'installationde cetéquipement. Lorsque
vous voyez le symbole !, reportez-vous à l'annexe A pour consulter la traduction deces instructions dans votre
langue.
TÄRKEÄÄ: LiiteA sisältää tämän laitteenasentamiseen liittyvät käännetytturvaohjeet. Kun näet !-symbolin,
katso käännettyäturvaohjettaliitteestä A.
IMPORTANTE: l’Appendice A contiene avvisi di sicurezza tradotti per l’installazione di questaapparecchiatura. Il
simbolo !,indica di consultare l’AppendiceA per l’avviso di sicurezza nella propria lingua.
VIKTIG: TilleggAinneholderoversattsikkerhetsinformasjonforinstalleringavdetteutstyret.Nårduser!,åpner
du til Tillegg A for å finne den oversatte sikkerhetsinformasjonenpå ønsket språk.
IMPORTANTE: OAnexoAcontémadvertênciasdesegurançatraduzidasparainstalaresteequipamento.Quando
vir o símbolo !, leia aadvertênciadesegurança traduzida no seu idioma no Anexo A.
IMPORTANTE: El ApéndiceA contiene mensajes de seguridad traducidos para la instalación de este equipo.
Cuando vea el símbolo !, vaya al Apéndice A para verel mensajede seguridadtraducido a suidioma.
OBS! Bilaga A innehåller översatta säkerhetsmeddelanden avseende installationen av denna utrustning. När du
ser !, skall du gå till Bilaga Aföratt läsa det översatta säkerhetsmeddelandet på ditt språk.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: Thisequipment hasbeentested andfound to comply with the limits fora Class A digitaldevicepursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energyand,if notinstalled and used inaccordance with this instruction manual,may cause
harmful interference toradio communications. Operation of this equipment in a residential area is likely to cause
harmful interferencein which case the user will be required to correct the interference at hisown expense.
Note: Modifications or changes notexpressly approved of by the manufacturer or theFCC, can void your right to
operatethis equipment.
Industry Canad
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte touteslesexigencesdu Règlement sur le matériel brouilleur du
Canada.

v
Table of Contents
Safety and Interference Warnings.............................................................iii
AT-MC105XL and AT-MC106XL Fast Ethernet Media Converters......1
Key Features....................................................................................................... 2
LEDs.................................................................................................................... 2
MDI/MDI-X Switch ..................................................................................... 2
NML/LNK TST Switch................................................................................ 3
Auto-Negotiation......................................................................................... 3
MissingLink.............................................................................................. 3
External AC-DC Power Adapter................................................................. 4
Package Contents............................................................................................... 4
Installing the Media Converter ......................................................................... 5
Standalone Installation............................................................................... 5
Back-to-Back Installation........................................................................... 7
Rack-mount Chassis Installation............................................................... 7
Configurations .................................................................................................... 8
Troubleshooting.................................................................................................. 9
Technical Specifications..................................................................................... 9
Recommended Cables and Cable Specifications...................................... 10
Technical Support and Service ........................................................................ 10
Warranty........................................................................................................... 10
Appendi xA
Electrical Safety and Installation Requirements.................................. 11
Appendi xB
AT-MC105XL and AT-MC106XL Installation Guide Feedback ...........17
Appendi xC
Technical Support Fax Order.................................................................... 19
Appendi xD
Where To Find Us.......................................................................................... 21

1
AT-MC105XL and AT-MC106XL Fast Ethernet
Media Converters
The AT-MC105XL and AT-MC106XL convert IEEE 802.3u 100Base-TX to
100Base-SX multimodeFast Ethernet network connections. The 100Base-SX
interface is available in ST or SC connectors for multimode fiber cabling. The
100Base-TX interface uses an RJ45 shielded connector.
Figure 1 AT-MC105XL Front Panel (ST multimode connector)
Figure 2 AT-MC106XLFront Panel(SC multimode connector)
100Base-SX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC105XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNK TST
100Base-SX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC106XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNK TST

2
Key Features
The media converters have the following key features:
❑LEDs for unit and port status
❑MDI/MDI-X Switch
❑NML/LNK TST Switch
❑100Base-TX ports participate in auto-negotiation for 100 Mbps and
half- or full-duplex modes
❑MissingLinkprovides link fault detection on 100Base-TX segments
❑External AC-DC Power Adapter
❑Standard, compact size for use with AT-MCR12 rack-mount chassis
❑Low power consumption
Note
For definitions of technical terms associated with Allied Telesyn products,
refer to the Glossary on Allied Telesyn’s website at
www.alliedtelesyn.com.
LEDs
The PWR LED in the upper right corner of the front panel lights when the
media converter is receiving power. Status LEDsare located on the front panel
next to each port and describedin Table 1.
Table 1 LEDs
MDI/MDI-X Switch
The MDI/MDI-X (Media Dependent Interface/Media Dependent Interface with
Crossover) switch, located on the front panel, is a straight-through or
crossover cable selection switch. It enables the RJ45 port to be connected to a
repeater or DTE device without using a special crossover cable. The default
position of the switch is MDI-X, whichmeans you can connect the RJ45 port to
a workstation or to any other DTE device using a straight-through cable.
LED Color State Description
PWR Green ON Power isapplied.
NML Green ON
OFF
Unit is operating in normal mode.
Unit is operating in link testmode.
REC Green ON Data is being received on the port.
LNK Green ON Link established on the port.

AT-MC105XL and AT-MC106XL Installation Guide
3
NML/LNK TST Switch
The NML/LNK TST (Normal/Link Test) switch, located on the front panel,
establishes a fiber/twisted pair link in the test position.
The default position of the switch is IN,which is the normal (NML) operating
mode and enables the MissingLink feature. With the switch in the OUT or
Link Test Mode (LNK TST) position, the MissingLink feature is disabled and
the optical transmitter TX is forced on. The NML LED lights when the NML/
TST LNK switch is in the default (IN) operating position.
Note
Using the Link Test Mode does not interfere with the media converter’s
ability to pass network traffic.
Auto-Negotiation
The 100Base-TX ports participate in IEEE 802.3u Standard auto-negotiation
with its local link partner.
Note
End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
Note
The media converters have an additional feature, allowing the unit to
operate in 100 Mbps half-duplex mode. Certain applications require this
mode, for example two media converters installed in a back-to-bac
configuration (fiber-to-fiber) which are attached to unmanaged repeaters
and/or switches that auto-negotiate with the other. Forinstructions on how
to set up the media converter for this application, visit the Technical
Support area of AlliedTelesyn’s web site at www.alliedtelesyn.com.
MissingLink
MissingLink gives the host (router,server,switch) attached to each end of the
converter critical information about the status of the other (remote) segment
link. If either link fails, the converter interacts with both hosts, making each
instantly aware of the link fault. Either host can then execute
preprogrammed, redundant transmission path selection.

4
External AC-DCPower Adapter
An external AC-to-DC power adapter is included with the fast switch for
standalone operation (see Figure 3).The power adapter supplies 12 volts DC to
the media converter.Allied Telesyn supplies an approved safety compliant AC
power adapter for the 120 and 240 V AC versions with an unregulated outp
of 12 V DC at 1 A. The power required for the media converter is 12 V DC, 500
mA.
Figure 3 External AC-DC Power Adapter (North American version)
Package Contents
Make sure the media converter package contains the following items:
❑AT-MC105XL or AT-MC106XL Fast Ethernet Media Converter
❑Four Protective Feet (for standalone use only)
❑External AC-DC Power Adapter
❑This Installation Guide.
Contact your sales representative if any items are missing or damaged.

AT-MC105XL and AT-MC106XL Installation Guide
5
Installing the Media Converter
Read the warnings below before beginning any installation.
Warning
LIGHTNING DANGER: DO NOT WORK on equipment or CABLES
during periods of LIGHTNING ACTIVITY!1
DO NOT BLOCK AIR VENTS!2
The following steps are for a standalone installation. Toinstall media
converters in a rack-mount chassis, see “Rack-mount Chassis Installation” on
page 7. For information concerning back-to-back converter configuration, see
“Back-to-Back Installation” on page 7.
Standalone Installation
1. Remove all equipment from the package and store the packaging in a safe
place
2. Attach the four rubber feet to the base of the unit, placing one rubber foot
in each corner.For rack-mount installation, do not attach the four rubber
feet.
3. Plug the AC-DC power adapter into an appropriate AC power outlet and
insert the power plug into the DC receptacle located on the rear panel.
Figure 4 12 V DC Connector onRear Panel
4. Verify that the PWR LED lights green.
5. Set the unit in Link Test Mode
6. Remove the dust cap from the fiber optic connectors.
7. Plug the appropriate fiber cable into the connector. See Table 3 for IEEE
802.3u cabling specifications
8. Connect the other end of the fiber cable to the desired end station. Verify
that the link LED is ON.
12VDC

6
9. If you are making a direct connection to a workstation using straight-
through cable, set the MDI/MDI-X switch to the MDI-X position. (MDI-X is
the default position.)
If you are connecting the media converter to a hub, switch, or another
media converter with a straight-through cable, set the MDI/MDI-X switch
to the MDI position. See Figure5.
Figure 5 MDI/MDI-X Switch
10. Plug a Category 5 twisted pair cable into the RJ45 connector.Connect the
other end of the twisted pair cable to the desired end station. Verify that
the Link LED is ON
11.Set the unit to Normal (NML) Mode for normal operation.
Note
End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
Note
The media converters have an additional feature, allowing the unit to
operate in 100 Mbps half-duplex mode. Certain applications require this
mode, for example two media converters installed in a back-to-bac
configuration (fiber-to-fiber) which are attached to unmanaged repeaters
and/or switches that auto-negotiate with the other. Forinstructions on how
to set up the media converter for this application, visit the Technical
Support area of AlliedTelesyn’s web site at www.alliedtelesyn.com.
100Base-FX
REC
LNK
100Base-TX
REC
LNK
PWR
NML
TX RX
MC105XL FAST ETHERNET MEDIA CONVERTER
MDI MDI-X
NML
LNKTST
C
KMDI MDI-X

AT-MC105XL and AT-MC106XL Installation Guide
7
Back-to-Back Installation
Review the following before doing a back-to-back installation. See Figure8 f or
an illustration of a back-to-back-media converter configuration.
❑During installation, setup, and testing of back-to-back media
converters, make sure each media converter is in the Link Test Mode.
❑When two media converters are connected back-to-back with no UTP/
STP cables connected and when the NML/LNK TST switch is in the
OUT position (Link Test Mode), the fiber RECLEDs oneach converter
may flash. This is normal and will not affect the normal operation of
the converters.
❑When operatingtwomediaconvertersina back-to-backconfiguration,
Allied Telesyn recommends that the MissingLink feature on one or
both of the converters be disabled. The MissingLink feature can be
disabled by placing the NML/LNK TST switch in the OUT position
(LNK TST Mode). Disabling the Link Test Mode does not interfere
with the converter’s ability to pass network traffic.
Rack-mount Chassis Installation
To install the media converter in the rack-mount chassis, refer to the
“AT-MCR12 Media Converter Chassis Installation Manual” or visit the
Technical Support area of Allied Telesyn’swebsite at
www.alliedtelesyn.com. Figure 6 shows the AT-MCR12 rack-mount chassis
Figure 6 AT-MCR12 Rack-mount Chassis
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
100Base-FX
RECPWR
LNK
100Base-TX
REC
LNK
MDI MDI-X
TX RX
MC102 FAST ETHERNET MEDIA CONVERTER
MCR12

8
Configurations
Figure 7 shows a typical network configuration with a workstation connected
to a switch.
Figure 7 Connectionto Workstation and Switch
Figure 8 shows two media converters in a back-to-back configuration.
Figure 8 AT-MC105XL Back-to-Back Configuration
RS-232
TERMINALPORT
STATUS
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
PORTACTIVITY
10BASE-T/ 100BASE-TX
AT-8124XL 10/100 Switch
AT-MC105XL
Workstation
100Base-SX
100Base-TX
Legend
10 Mbps
100 Mbps
100 Mbps (Fiber)
MMF
RS-232
TERMINALPORT
STATUS
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
PORTACTIVITY
10BASE-T/100BASE-TX
RS-232
TERMINALPORT
STATUS
10BASE-T/100BASE-TX
FASTETHERNET SWITCH
PORTACTIVITY
10BASE-T/100BASE-TX
Workstation
100Base-TX
10Base-T
AT-MC105XL AT-8124XL 10/100 Switch
Legend
10 Mbps
100 Mbps
100 Mbps (Fiber)
AT-MC105XL
AT-8124XL 10/100 Switch
100Base-TX
100Base-SX
MMF

AT-MC105XL and AT-MC106XL Installation Guide
9
Troubleshooting
To troubleshoot your media converter,perform the following:
1. Set the unit in the Link test Mode.
2. End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
3. Verify that the twisted pair cable is Category 5.
4. Verify that proper fiber cable is being used: multimode for the
AT-MC105XL and AT-MC106XL.
5. Verify that the near end node transmitter (TX) is connected to the far end
node receiver (RX) and vice versa on the fiber segment.
Technical Specifications
Table 2 lists the media converter technical specifications
Table 2 Media Converter Technical Specifications
Specifications
Dimensions (W x D x H) 4.125 in x 3.75 in x 1.0 in (10.5 cm x 9.5 cm x 2.5 cm )
Max. Operating temperature 0° C to 40° C (32° F to 104° F)
Max. Storage temperature -20 oC to 80o C (-4° F to 176° F)
Operating altitude up to 10,000 ft (3,048 m)
Humidity 5% to 80% (noncondensing)
EMI/RFI meets FCC Class A, EN55022 Class A
Safety EN60825
EN60950
Immunity EN50082-1 Immunity Standard
Power
Input supplyvoltage
Max. current
Power consumption
12 V DC +/-5%
500 mA
6W

10
Recommended Cables and Cable Specifications
Table 3 lists the IEEE 802.3u cabling specifications for the media converters.
Refer to this table for cabling recommendations.
Technical Support and Service
You can contact the reseller or distributor where you purchased your product
for local assistance. If local support is unable to resolve the problem, Allied
Telesyn offers technical support via fax, e-mail or telephone.
Refer to Appendi xD or Allied Telesyn’s website at www.alliedtelesyn.com
for current world-wide office locations.
Warranty
The media converters have a lifetime warranty. The power adapter has a one
year warranty.
Table 3 IEEE 802.3u Cabling Specifications for AT-MC105XL and AT-MC106XL
100Base-SX 100Base-TX
Media 850nm multimode fiber, 50/125 micron
850nm multimode fiber, 62.5/125 micron Unshielded/Shielded TwistedPair Category
5 only
Topology Star, Tree Star, Tree
External Devices Network Adapter Card, Repeater, Switch,
or Router NetworkAdapterCard, Repeater, Switch, or
Router
Maximum Segment
Length Multi-mode fiber: 984 ft (300m) for full- or half-duplex 328 ft (100 m)

11
Appendix A
Electrical Safety and Installation
Requirements
STANDARDS:This product meets the following standards
RFI Emission EN55022 Class A
WARNING: In a domestic environment this product may cause radio interference in which case the user may be
required totake adequate measures.
Immunity EN50082-1
WARNING: This product requires shieldedcables to comply with emission and immunity standards. If it is used with
unshielded cables, the user maybe required to take measuresto correct the interference problem at their own
expense.
Electrical Safety TUV-EN60950, UL1950, CSA 950
Laser EN60825
This is a “CLASS 1 LED PRODUCT”
SAFETY
!1 LIGHTNING DANGER
DANGER: DO NOTWORK on equipment or CABLES during periods of LIGHTNING ACTIVITY.
!2DO NOTBLOCK AIR VENTS
Power tothe hub must be sourced only from the adapter.
USA/CANADA
Use a UL Listed/CSA Certified AC adapter of DC 12V, 500mA.
EUROPE - EU
Use TÜVlicensed AC adapter of DC 12V,500mA.
UK
Use a UK Safety Approved AC adapter ofDC 12V, minimum 500mA.
OPERATING TEMPERATURE
This product is designed for a maximum ambient temperature of 40 degrees C.
ALL COUNTRIES: Install product in accordance with local and National Electrical Codes.
U.S. Federal Communications Commissi
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part15of FCC Rules.Theselimits are designed to provide reasonable protectionagainst harmful interferencewhen
the equipmentis operated ina commercialenvironment. This equipment generates,uses,andcan radiate radio
frequency energy and, if not installed and used in accordance with this instruction manual, may cause harmful
interference to radio communications.Operation of this equipment in a residential area is likely tocause harmful
interference in which case the user will be required to correct the interference at hisown expense.
Note: Modifications orchanges not expressly approvedofby the manufacturer orthe FCC,can void your right to
operate this equipment.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cetappareilnumériquede la classe A respecte toutesles exigences duRèglement sur le matérielbrouilleurdu
Canada.

12
NORMEN: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen
Hochfrequenzstörung EN55022 Klasse A
WARNUNG: Bei Verwendung zuHause kanndieses Produkt Funkstörungenhervorrufen. In diesem Fall müßte der
Anwender angemessene Gegenmaßnahmen ergreifen.
Störsicherheit EN50082-1
ACHTUNG: Für dieses Produkt sind abgeschirmte Kabel erforderlich, damit den Richtlinien für Emissionund
Interferenzschutz entsprochen wird. Falls das Produkt mit nicht abgeschirmten Kabeln verwendet wird, können
weitergehende Maßnahmen für die Korrektur vonInterferenzproblemen auf Kosten desBenutzersnotwendig werden.
Elektrische Sicherheit TUV-EN60950, UL1950, CSA 950
Laser EN60825
Das ist ein “LED Produkt der Klasse 1”
SICHERHEIT
!1 GEFAHR DURCH BLITZSCHLAG
GEFAHR: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters ausführen
!2ENTLÜFTUNGSÖFFNUNGEN NICHTVERSPERREN
Der Buchsedarf nur aus demAdapter Stromzugeführt werden.
EUROPE - EU
Gebrauchen Sieeinen vonTÜV zugelassenen Wechselstromadapterfür Gleichstrom12 V, 500 mA.
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betriebin einer Umgebungstemperatur von nicht mehr als 40°C entworfen.
ALLE LÄNDER: Installation muß örtlichen undnationalen elektrischen Vorschriften entsprechen.
STANDARDER: Detteprodukt tilfredsstiller de følgende standarder
Radiofrekvens forstyrrelsesemission EN55022 Klasse A
ADVARSEL: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse. Bliver det tilfældet, påkræves
brugeren muligvisat tage tilstrækkeligeforanstaltninger.
Immunitet EN50082-1
ADVARSEL: Dette produkt skal bruges med afskærmede kabler for at overholde bestemmelserne vedrørende
udstrålingogstøjimmunitet. Hvisdetbrugesmeduafskærmedekabler,kandetblivepåkrævetafbrugerenatkorrigere
interferensproblemerforegen regning.
Elektrisk sikkerhed TUV-EN60950, UL1950, CSA 950
Laser EN60825
Dette er et “PRODUKT UNDER KLASSE 1 LED”
SIKKERHED
!1 FARE UNDER UVEJR
FARE: UNDLAD at arbejde på udstyr eller KABLER i perioder med LYNAKTIVITET.
!2VENTILATIONSÅBNINGERNE MÅ IKKE BLOKERES
Strømforsyningen til apparatet må udelukkende tages fra tilpasningstransformatoren.
EUROPE - EU
Brug kun TÜV godkendt vekselstrømstransformator på 12 V jævnstrøm,500 mA.
BETJENINGSTEMPERATUR
Dette apparat er konstrueret til en omgivende temperatur på maksimum 40grader C.
ALLE LANDE: Installation af produktet skal ske i overensstemmelse med lokal og national lovgivning for elektriske
installationer.

AT-MC105XL and AT-MC106XL Installation Guide
13
EISEN: Dit productvoldoet aandevolgende eisen.
RFI Emissie EN55022 Klasse A
WAARSCHUWING: Binnenshuis kan ditproduct radiostoring veroorzaken, inwelk geval de gebruikerverplicht kan
wordenom gepaste maatregelentenemen.
Immuniteit EN50082-1
WAARSCHUWING: Om te voldoen aan de emissie- en immuniteitsnormen dient dit apparaat te zijn voorzien van
afgeschermdekabels.Alshetmetniet-afgeschermdekabelswordtgebruikt,kanhetzijndatdegebruikermaatregelen
moet treffen om interferentieproblemen voor eigen rekening op te lossen.
Electrische Veiligheid TUV-EN60950, UL1950, CSA 950
Laser EN60825
Dit is een “KLASSE 1 LED-PRODUKT
VEILIGHEID
!1 GEVAAR VOOR BLIKSEMINSLAG
GEVAAR: NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
!2VENTILATIEGATEN NIET BLOKKEREN
Stroom mag alleen via de adapter naar het apparaat toegevoerd worden.
EUROPE - EU
Gebruik een doorTÜV gekeurde wisselstroomadapter van 12Voltgelijkstroom, 500milliampères.
BEDRIJFSTEMPERATUUR
De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 40 graden Celsius.
ALLE LANDEN: het toestel installeren overeenkomstig de lokale en nationale elektrische voorschriften.
NORMES: ce produit est conforme aux normes de suivantes
Emission d'interférences radioélectriques EN55022 Classe A
MISEENGARDE:dansunenvironnementdomestique,ceproduitpeutprovoquerdesinterférencesradioélectriques.
Auquel cas, l'utilisateur devra prendre les mesures adéquates.
Immunité EN50082 - 1
AVERTISSEMENT: Il faut utiliser des câbles blindés pour ce produit afin de respecter les normes d’émission et
d’immunité. Sil’utilisateur choisitd’utiliser des câbles non blindés, il sera peut-être contraintde prendre les mesures
nécessaires pourcorriger les problèmes d’interférences, ainsique d’assumer le coût correspondant.
Sécurité électrique TUV-EN60950, UL1950, CSA 950
Laser EN60825
Ce matériel est un “PRODUIT À DIODE ÉLECTROLUMINESCENTE DE CLASSE 1”
SÉCURITÉ
!1 DANGER DE FOUDRE
DANGER: NE PAS MANIER le matérielou les CÂBLES lors d'activitéorageuse.
!2NE PAS BLOQUER LES FENTES D'AÉRATION
L'alimentation du concentrateur doit être uniquement fournie par l'adaptateur.
EUROPE - EU
Utiliser un adaptateur secteurconforme TÜVde 12 V, 500 mA encourant continu.
TEMPÉRATURE DE FONCTIONNEMENT
Ce matériel est capabledetolérerune température ambiante maximum de 40 degrés Celsius.
POUR TOUS PAYS:Installer lematérielconformément aux normes électriques nationales et locales.

14
STANDARDI : Tämä tuote on seuraavien standardien mukainen
Radioaaltojen häirintä EN55022 Luokka A
VAROITUS: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on
mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin.
Kestävyys EN50082-1
VAROITUS: Tämä tuotevaatii suojattuja kaapeleita toimiakseenemissio- ja häiriönsietostandardien mukaisesti. Jos
tuotettakäytetäänilmansuojattujakaapeleita,käyttäjävoijoutuakorjaamaanhäirinnänaiheuttamanongelmanomalla
kustannuksellaan.
Sähköturvallisuus TUV-EN60950, UL1950, CSA 950
Laser EN60825
Tämä on“ENSIMMÄISEN LUOKANVALODIODITUOTE”
TURVALLISUUS
!1 SALAMANISKUVAARA
ENGENVAARA: ÄLÄ TYÖSKENTELE laitteiden taiKAAPELEIDEN KANSSA SALAMOINNIN AIKANA.
!2ÄLÄ TUKI ILMAREIKIÄ
Tähtipisteeseen (hub) syötettävän virran pitää tulla ainoastaan sovittimesta.
EUROPE - EU
Käytä TÜV-lisenssillä valmistettua verkkosovitinta,jonka tasajännitteen nimellisarvot ovat DC 12 V, 500 mA
(milliampeeria).
KÄYTTÖLÄMPÖTILA
Tämä tuote on suunniteltu ympäröivän ilmanmaksimilämpötilalle 40° C.
KAIKKI MAAT: Asenna tuotepaikallistenja kansallisten sähköturvallisuusmääräysten mukaisesti.
STANDARD: Questo prodotto èconformeaiseguenti standard
Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A
AVVERTENZA: in ambientedomestico questoprodotto potrebbe causareradiointerferenza.Inquestocaso potrebbe
richiedersiall'utente di prendere gliadeguati provvedimenti.
Immunità EN50082-1
AVVERTENZA: questoprodotto, se utilizzato con cavi schermati, è conforme alle norme sulle emissioni e
sull’immunità.Incasodiusosenzacavischermati,l’utentepuòdoveradottareapropriespesemisurecorrettivecontro
le interferenze.
Sicurezza elettrica TUV-EN60950, UL1950, CSA 950
Laser EN60825
Questo è un “PRODOTTO CON LED DI CLASSE 1”
NORME DI SICUREZZA
!1 PERICOLO DI FULMINI
PERICOLO: NON LAVORARE sul dispositivo osui CAVI durante PRECIPITAZIONITEMPORALESCHE.
!2NON OSTRUIRE LE PRESE D'ARIA
Questo dispositivo deve essere alimentato solo mediante l’adattatore.
EUROPE - EU
Utilizzare l’adattatore per c.a. da 12 V c.c. e 500 mA conformealla normativa TÜV.
TEMPERATURA DI FUNZIONAMENTO
Questo prodotto è concepito per una temperatura ambientale massima di40 gradi centigradi.
TUTTI I PAESI: installare il prodotto inconformità delle vigenti normative elettriche nazionali.
