Allnet ALL-SG8428PM User manual

ALL-SG8428PM
24x Port Gigabit PoE + 4 Combo Port Managed Switch
User Manual

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
2
Default-IP
192.168.2.1
Username & Password:
admin

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
3
Table of Con en s
Cha ter 1 Introduction ·························································································· 6
1.1 General Descri tion ······························································································ 6
1.2 The Front Panel ···································································································· 6
1.3 LEDs Definition ····································································································· 6
1.4 The Rear Panel ······································································································ 7
1.5 Hardware Installation ·························································································· 7
Cha ter 2 Getting Started ····················································································· 9
2.1 Pre aration for Web Interface ············································································ 9
2.2 System login·········································································································· 9
2.3 The Gra hic User Interface ················································································ 10
Cha ter 3 Status ····································································································· 13
3.1 System Information ···························································································· 13
3.2 Logging Message ································································································ 14
3.3 Port ······················································································································ 15
3.3.1 Statistics ··········································································································· 15
3.3.2 Bandwidth Utilization ····················································································· 16
3.4 Link Aggregation ······························································································· 17
3.5 MAC Address Table ···························································································· 18
Cha ter 4 Network ································································································ 19
4.1 IP Address ··········································································································· 19
4.2 System Time ········································································································ 20
Cha ter 5 Port ········································································································ 23
5.1 Port Setting ········································································································· 23
5.2 Link Aggregation ······························································································· 25
5.2.1 Trunk Grou Setting ························································································ 25
5.2.2 Port Setting ······································································································ 26
5.2.3 LACP ················································································································· 28
5.3 EEE ······················································································································· 30
5.4 Jumbo Frame ······································································································ 31
Cha ter 6 PoE········································································································· 33
6.1 Global Setting ····································································································· 33
6.2 Priority Setting ···································································································· 34
6.3 Power Limit ········································································································· 35
6.4 PoE ON/OFF ········································································································· 37
Cha ter 7 VLAN ····································································································· 38
7.1 VLAN ··················································································································· 38

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
4
7.1.1 Create VLAN ···································································································· 38
7.1.2 VLAN Configuration ························································································ 39
7.1.3 Membershi ····································································································· 40
7.1.4 Port Setting ······································································································ 42
7.2 Voice VLAN ········································································································· 44
7.2.1 Pro erty ··········································································································· 44
7.2.2 Voice OUI ········································································································· 46
Cha ter 8 MAC Address Table ··············································································· 48
8.1 Dynamic Address ································································································ 48
8.2 Static Address ····································································································· 48
Cha ter 9 S anning Tree ······················································································· 49
9.1 Pro erty ·············································································································· 49
9.2 Port Setting ········································································································· 50
9.3 Statistics ·············································································································· 52
Cha ter 10 Discovery ····························································································· 55
10.1 LLDP ·················································································································· 55
10.1.1 Pro erty ········································································································· 55
10.1.2 Port Setting ···································································································· 56
10.1.3 Packet View ··································································································· 57
10.1.4 Local Information ·························································································· 58
10.1.5 Neighbor ········································································································ 60
10.1.6 Statistics ········································································································· 60
Cha ter 11 Multicast ····························································································· 63
11.1 General ············································································································· 63
11.1.1 Pro erty ········································································································· 63
11.1.2 Grou Address ······························································································· 63
11.2 IGMP Snoo ing ································································································· 64
11.2.1 Pro erty ········································································································· 64
11.2.2 Querier ··········································································································· 67
11.2.3 Statistics ········································································································· 68
Cha ter 12 Security ································································································ 70
12.1 RADIUS ·············································································································· 70
12.2 TACACS+ ··········································································································· 71
12.3 AAA ··················································································································· 73
12.3.1 Method List ···································································································· 73
12.3.2 Login Authentication ···················································································· 74
12.4 Management Access ························································································· 74
12.4.1 Management VLAN ······················································································· 74
12.4.2 Management Service ····················································································· 75
12.5 Authentication Manager ················································································· 76

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
5
12.5.1 Pro erty ········································································································· 76
12.5.2 Port Setting ···································································································· 78
12.5.3 Sessions ·········································································································· 79
12.6 Protected Port ··································································································· 80
12.7 Storm Control ··································································································· 81
12.8 DoS ···················································································································· 83
12.8.1 Pro erty ········································································································· 84
12.8.2 Port Setting ···································································································· 85
Cha ter 13 QoS ······································································································ 87
13.1 General ············································································································· 87
13.1.1 Pro erty ········································································································· 87
13.1.2 Queue Scheduling ························································································· 90
13.1.3 CoS Ma ing ································································································· 91
13.1.4 DSCP Ma ing ······························································································· 91
13.1.5 IP Precedence Ma ing ················································································· 92
13.2 Rate Limit ·········································································································· 93
13.2.1 Ingress / Egress Port ······················································································· 93
13.2.2 Egress Queue ································································································· 95
Cha ter 14 Diagnostics ·························································································· 98
14.1 Logging ············································································································· 98
14.1.1 Pro erty ········································································································· 98
14.1.2 Remote Server ······························································································· 99
14.2 Mirroring··········································································································· 99
14.3 Ping ················································································································· 100
14.4 Co er Test ····································································································· 101
Cha ter 15 Management ···················································································· 103
15.1 User Account ··································································································· 103
15.2 Firmware ········································································································· 104
15.2.1 U grade / Backu ························································································ 104
15.2.2 Active Image ································································································ 106
15.3 Configuration ································································································· 106
15.3.1 U grade / Backu ························································································ 106
15.3.2 Save Configuration ······················································································ 108
15.4 SNMP ··············································································································· 109
15.4.1 Community ·································································································· 109
15.4.2 Tra Event ···································································································· 110
15.4.3 Notification ·································································································· 111
Product S ecifications ···························································································· 112

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
6
Chap er 1 In roduc ion
1.1 General Descrip ion
This switch is 24- ort 10/100/1000M PoE+ with 4 Combo RJ45/SFP Rack-mount Web Smart PoE
Switch, the switch su orts IEEE 802.3at PoE+ standard, maximum 390W ower consum tion
er system. The switch also rovides exce tionally smart Web management features, such as
VLAN, QoS, RSTP, IGMP Snoo ing, LACP, IEEE802.1X, Strom Control, PoE Schedule…etc. The
switch is standard 19” rack-mount design to fit into the rack environment. With these
features, the switch is a su erb choice for medium or large network environment to
strengthen its network connection and efficiency.
1.2 The Fron Panel
The following figure shows the front anel of the switch.
1.3 LEDs Defini ion
This device rovides extensive LEDs to show the activities on ower, system and orts.
See the following descri tion for your reference:
LED S a us Opera ion
SYS
Steady Green Power on.
Blinking Green
System booting u .
Off Power off or fail.
PoE/Max
Steady Green Over PoE max ower budget (390W)
Off No over PoE max ower budget (390W)
LINK/ACT
Steady Green 1000Mb s connected.
Steady Amber 10/100Mb s connected
Blinking Sending or receiving data.
Off Port disconnected or link fail.
PoE
Steady Green PoE ower out ut on.
Off PoE ower out ut off.
Blinking Green
PoE ower out ut over >30W (No Powering)

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
7
The Rese Bu on
Reset the switch to its factory default configuration via the RESET button. Press the Reset
button for ten seconds and release. The switch automatically reboots and reloads its factory
configuration file. The Reset button is on the front anel of the switch.
1.4 The Rear Panel
The following figure shows the rear anel of the switch:
Power Recep acle
To be com atible with the electric service standards around the world, the switch is designed
to afford the ower su ly in the range from 100 to 240 VAC, 50/60 Hz. Please make sure that
your outlet standard to be within this range.
To ower on the switch, lease lug the female end of the ower cord firmly into the
rece tacle of the switch, the other end into an electric service outlet. After the switch
owered on, lease check if the ower LED is lit for a normal ower status.
1.5 Hardware Ins alla ion
To install this switch, lease lace it on a large flat surface with a ower socket close by. This
surface should be clean, smooth, and level. Also, lease make sure that there is enough s ace
around this switch for RJ45 cable, ower cord and ventilation.
If you’re installing this switch on a 19-inch rack, lease make sure to use the rack-mount kit (L
brackets) and screws come with the roduct ackage. ALL screws must be fastened so the
rack-mount kit and your roduct are tightly conjoined before installing it on your 19-inch
rack.
E herne cable Reques
The wiring cable ty es are as below:
10 Base-T: 2- air UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
100 Base-TX: 2- air UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
1000 Base-T: 4- air UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
PoE: To deliver ower without roblems, the Cat 5e and Cat 6 cable is suggested. The high
quality Ethernet cable reduces the lost while ower transmission.

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
8
SFP Ins alla ion
While install the SFP transceiver, make sure the SFP ty e of the 2 ends is the same and the
transmission distance, wavelength, fiber cable can meet your request. It is suggested to
urchase the SFP transceiver with the switch rovider to avoid any incom atible issue.
The way to connect the SFP transceiver is to Plug in SFP fiber transceiver fist. The SFP
transceiver has 2 lug for fiber cable, one is TX (transmit), the other is RX (receive).
Cross-connect the transmit channel at each end to the receive channel at the o osite end.
Rack-moun Ins alla ion
Attach the brackets to the device by using the screws rovided in the Rack Mount kit. Mount
the device in the 19-inch rack by using four rack-mounting screws rovided by the rack
manufacturer.

Chap er 2 Ge ing S ar ed
2.1 Prepara ion for Web In erface
The web management age allows you to use a standard web-browser such as Microsoft
Internet Ex lorer, Google Chrome or Mozilla Firefox, to configure and interrogate the switch
from anywhere on the network.
Before you attem t to use the web user interface to manage switch o eration, verify that
your switch is ro erly installed on your network and that every PC on this network can access
the switch via the web browser.
1. Verify that your network interface card (NIC) is o erational, and that your o erating
system su orts TCP/IP rotocol.
2. Wire the switch ower and connect your com uter to the switch.
3. The switch default IP address is 192.168.2.1. The Switch and the connected PC should
locate within the same IP Subnet.
4. Change your com uter's IP address to 192.168.2.XX or other IP address which is located
in the 192.168.2.x (For exam le: IP Address: 192.168.2.100; Subnet Mask: 255.255.255.0)
subnet.
2.2 Sys em login
1. Start your web browser.
2. Ty e “htt ://”and the IP address of the switch (for exam le, the default management IP
address is 192.168.2.1) in the Location or Address field. Press [ENTER].

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
10
3. The login screen a ears. The default username and assword are “admin”, so you can
click Login and go to the web configuration screen directly.
2.3 The Graphic User In erface
After the assword authorization, the System age shows u . You may click on each folder
on the left column of each age to get access to each configuration age. The Gra hic User
Interface is as follows:

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
11
In the navigation anel, click a main link to reveal a list of submenu links shown as the
following:
The following table describes the links in the navigation anel.
LINKS
Submenu
S a us
System Information.
Logging Message
Port – Statistics, Bandwidth Utilization
Link Aggregation
MAC Address Table
Ne work
IP Address
System Time
Por
Port Setting
Link Aggregation – Grou , Port Setting, LACP
EEE
Jumbo Frame
PoE
Global Setting
Priority Setting
Power Limit
Power ON/OFF
VLAN
VLAN
-
Create VLAN, VLAN Configuration, Membershi , Port
Setting
Voice VLAN - Pro erty, Voice OUI
MAC Address Table
Dynamic Address
Static Address
Spanning Tree
Pro erty
Port Setting
Statistics
Discovery (LLDP)
Pro erty
Port Setting
Packet View
Local Information
Neighbor
Statistics
Mul icas
General
–
Pro erty, Grou Address, Router Port
IGMP Snoo ing – Pro erty, Querier, Statistics
Securi y
RADIUS
TACACS+
AAA – Method List, Login Authentication
Management Access – Management VLAN, Management Service
Authentication Manager – Pro erty, Port Setting, Sessions
Protected Port
Storm Control
DoS – Pro erty, Port Setting
QoS
General
–
Pro erty, Queue Scheduling, CoS Ma ing, DSCP
Ma ing, IP Precedence Ma ing
Rate Limit – Ingress/Egress Port, Egress Queue
Diagnos ics
Logging
–
Pro erty, Remove Server
Mirroring
Ping
Co er Test
Managemen
User Account
Firmware – U grade/Backu , Active Image
Configuration – U grade/Backu , Save Configuration

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
12
SNMP
–
Community, Tra Event

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
13
Chap er 3 S a us
Use the Status ages to view system information and status.
3.1 Sys em Informa ion
Click S a us > Sys em Informa ion
This age shows switch anel, CPU utilization, Memory utilization and other system current
information. It also allows user to edit some system information.
Field
Descrip ion
Model
Model name of the switch
Sys em Name
System name of the switch. This name will al
so use as CLI refix of
each line
Sys em Loca ion
Location information of the switch
Sys em Con ac
Contact information of the switch
MAC Address
Base MAC address of the switch
IPv4 Address
Current system IPv4 address
IPv6 Address
Current system IPv6 address
Sys em OID
SNMP system object ID
Sys em Up ime
Total ela sed time from booting
Curren Time
Current system time
Loader Version
Boot loader image version
Loader Da e
Boot loader image build date

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
14
Firmware Version
Current running firmware image version
Firmware Da e
Current running firmware image build date
Telne
Current Telnet service enable/disable state
SSH
Current SSH service enable/disable state
HTTP
Current HTTP service enable/disable state
HTTPS
Current HTTPS service enable/disable state
SNMP
Current SNMP service enable/disable state
Click “Edi ” button on the table title to edit following system information.
Field
Descrip ion
Sys em Name
System name of the switch. This name will also use as CLI refix of
each line.
Sys em Loca ion
Location information of the switch.
Sys em Con ac
Contact information of the switch.
3.2 Logging Message
Click S a us > Logging Message
This age shows logging messages stored on the RAM and Flash.
Field
Descrip ion
Viewing
The logging view including
:
RAM: Show the logging messages stored on the RAM
Flash: Show the logging messages stored on the Flash.

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
15
Clear
Clear the logging messages.
Refresh
Refresh the logging messages.
Log ID
The log identifier.
Time
The time stam for the logging message.
Severi y
The severity for the logging message.
Descrip ion
The descri tion of logging message.
3.3 Por
The ort configuration age dis lays ort summary and status information.
3.3.1 S a is ics
Click S a us > Por > S a is ics
On this age user can get standard counters on network traffic from the interfaces,
Ethernet-like and RMON MIB. Interfaces and Ethernet-like counters dis lay errors on the
traffic assing through each ort. RMON counters rovide a total count of different frame
ty es and sizes assing through each ort.

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
16
The “Clear” button will clear MIB counter of current selected ort.
Field
Descrip ion
Por
Select one ort to show counter statistics.
MIB Coun er
Select the MIB counter to show different count
ty e
All: All counters.
In erface: Interface related MIB counters
E herlike: Ethernet-like related MIB counters
RMON : RMON related MIB counters
Refresh Ra e
Refresh the web age every eriod of seconds to get new counter
of s ecified ort.
3.3.2 Bandwid h U iliza ion
Click S a us > Por > Bandwid h U iliza ion
This age allow user to browse orts’ bandwidth utilization in real time. This age will refresh
automatically in every refresh eriod.

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
17
Field
Descrip ion
Refresh Ra e
Refresh the web age e
very eriod of second to get new
bandwidth utilization data.
3.4 Link Aggrega ion
Click S a us > Link Aggrega ion
Dis lay the Link Aggregation status of web age.
Field
Descrip ion
LAG
LAG Name.
Name
LAG ort descri tion
Type
The ty e of the LAG

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
18
S
a ic
: The grou of orts assigned to a static LAG are always
active members.
LACP: The grou of orts assigned to dynamic LAG are candidate
orts. LACP determines which candidate orts are active member
orts.
Link S a us
LAG ort link status
Ac ive Me
mber
Active member orts of the LAG
Inac ive Member
Inactive member orts of the LAG
3.5 MAC Address Table
Click S a us > MAC Address Table
The MAC address table age dis lays all MAC address entries on the switch including static
MAC address created by administrator or auto learned from hardware.
The “Clear” button will clear all dynamic entries and “Refresh” button will retrieve latest
MAC address entries and show them on age.
Field
Descrip ion
VLAN
VLAN ID of the MAC address.
MAC Address
MAC address
Type
The ty e of MAC address
Managemen : DUT’s base MAC address for management ur ose.
S a ic: Manually configured by administrator.
Dynamic: Auto learned by hardware.
Por
The ty e of ort
CPU : DUT’s CPU ort for management ur ose
O her : Normal switch ort

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
19
Chap er 4 Ne work
Use the Network ages to configure settings for the switch network interface and how the
switch connects to a remote server to get services.
4.1 IP Address
Click Ne work > IP Address
Use the IP Setting screen to configure the switch IP address and the default gateway device.
The gateway field s ecifies the IP address of the gateway (next ho ) for outgoing traffic.
The switch needs an IP address for it to be managed over the network. The factory default IP
address is 192.168.2.1. The subnet mask s ecifies the network number ortion of an IP
address.
The factory default subnet mask is 255.255.255.0.
Field
Descrip ion
IPv4 Address Field

© ALLNET GmbH Com utersysteme 2017 - All rights reserved
Errors and omissions exce ted
20
Address Type
Select the address ty e of IP configuration
‧S a ic: Static IP configured by users will be used.
‧Dynamic: Enable DHCP to obtain IP information from a DHCP
server on the network.
IP Address
Enter the IP address of your switch in dotted decimal notation for
exam le 192.168.2.1. If static mode is enabled, enter IP address in
this field.
Subne Mask
Enter the IP subnet mask of your switch in dotted decimal notation
for exam le 255.255.255.0. If static mode is enabled, enter subnet
mask in this field.
Defaul Ga eway
S ecify the default gateway on the static configuration.
The
default gateway must be in the same subnet with switch IP address
configuration
DNS Server 1
If static mode is enabled, enter rimary DNS server address in this
field.
DNS Server 2
If static mode is enabled, enter secondary DNS server address in
this field.
IPv6 Address Field
Au o Configura ion
Select
Enable
or
Disable
the IPv6 auto configuration.
DHCPv6 Clien
DHCPv6 client state.
‧Enable: Enable DHCPv6 client function.
‧Disable: Disable DHCPv6 client function
IPv6 Address
S ecify the IPv6 add
ress, when the IPv6 auto configuration and
DHCPv6 client are disabled.
IPv6 Prefix
S ecify the refix for the IPv6 address, when the IPv6 auto
configuration and DHCPv6 client are disabled.
Ga eway
S ecify the IPv6 default gateway, when the IPv6 auto
configuration and DHCPv6 client are disabled.
DNS Server 1
S ecify the rimary user-defined IPv6 DNS server configuration.
DNS Server 2
S ecify the secondary user-defined IPv6 DNS server configuration.
Opera ional S a us
IPv4 Address
The o erational IPv4 address of the switch.
IPv4 Ga eway
The o erational IPv4 gateway of the switch.
IPv6 Address
The o erational IPv6 address of the switch.
IPv6 Ga eway
The o erational IPv6 gateway of the switch.
Link Local Address
The o erational IPv6 link local address for the switch.
4.2 Sys em Time
Click Ne work > Sys em Time
This age allow user to set time source, static time, time zone and daylight saving settings.
Time zone and daylight saving takes effect both static time or time from SNTP server.
